Page 1
EVY8740AA
................................................ .............................................
EN STEAMER USER MANUAL
Page 2
www.electrolux.com
2
CONTENTS
1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7. CLOCK FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8.
AUTOMATIC PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9. USING THE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10.
ADDITIONAL FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
11. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
12.
CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
13. WHAT TO DO IF… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
14.
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it
decades of professional experience and innovation. Ingenious and stylish, it has been designed
with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great
results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.electrolux.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
Page 3
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with
the appliance for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they are supervised by an adult or a person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
• If the appliance has a child safety device, we recommend that you activate it.
• Cleaning and user maintenance shall not be made by
children without supervision.
ENGLISH 3
1.2 General Safety
• Only a qualified person must install this appliance and
replace the cable.
• Internally the appliance becomes hot when in operation. Do not touch the heating elements that are in the
appliance. Always use oven gloves to remove or put in
accessories or ovenware.
• Do not use a steam cleaner to clean the appliance.
• Before maintenance cut the power supply.
Page 4
www.electrolux.com
4
• Do not use harsh abrasive cleaners or sharp metal
• To remove the shelf supports first pull the front of the
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
shelf support and then the rear end away from the side
walls. Install the shelf supports in the opposite sequence.
2.
SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appli-
ance.
• Obey the installation instruction sup-
plied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not pull the appliance by the handle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is installed
below and adjacent safe structures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical information
on the rating plate agrees with the power supply. If not, contact an electrician.
• Always use a correctly installed shock-
proof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Contact the Service or an electrician to
change a damaged mains cable.
• Do not let mains cables to come in
touch with the appliance door, specially
when the door is hot.
• The shock protection of live and insulated parts must be fastened in such a
way that it cannot be removed without
tools.
• Connect the mains plug to the mains
socket only at the end of the installation. Make sure that there is access to
the mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the
mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect the appliance from the mains at all
poles. The isolation device must have a
contact opening width of minimum 3
mm.
2.2 Use
WARNING!
Risk of injury, burns or electric
shock or explosion.
Page 5
• Use this appliance in a household environment.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended during operation.
• Deactivate the appliance after each
use.
• Be careful, when you open the appliance door while the appliance is in operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Always keep the appliance door closed
when the appliance is in operation.
• Open the appliance door carefully. The
use of ingredients with alcohol can
cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other objects
in the appliance directly on the bottom.
– do not put aluminium foil directly on
the bottom of the appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food in
the appliance after you finish the cooking.
– be careful when you remove or install
the accessories.
• Discoloration of the enamel has no effect on the performance of the appliance. It is not a defect in the sense of
the warranty law.
ENGLISH 5
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be permanent.
Steam Cooking
WARNING!
Risk of burns and damage to the
appliance.
• Do not open the appliance door during
steam cooking. Steam can release.
2.3 Care and Cleaning
WARNING!
Risk of injury, fire or damage to
the appliance.
• Before maintenance, deactivate the appliance and disconnect the mains plug
from the mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged. Contact the Service.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to prevent
the deterioration of the surface material.
• Remaining fat or food in the appliance
can cause fire.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
• If you use an oven spray, obey the safety instructions on the packaging.
• Do not clean the catalytic enamel (if applicable) with any kind of detergent.
2.4 Internal light
• The type of light bulb or halogen lamp
used for this appliance, is only for
household appliances. Do not use it for
house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
Page 6
www.electrolux.com
6
• Only use lamps with the same specifications.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
3. PRODUCT DESCRIPTION
1
4
3
2
7
1
3.1 Accessories
2 3
6
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children and pets to get closed in the appliance.
Control panel
1
Electronic programmer
2
Water drawer
3
Lamp
4
4
5
Steam generator with cover
5
Shelf support, removable
6
Shelf positions
7
Wire shelf
For cookware, cake tins, roasts.
Steam set
One unperforated and one perforated
food container.
The steam set drains the condensing water away from the food during steam
cooking. Use it to prepare food that
should not be in the water during the
cooking (e.g. vegetables, pieces of fish,
chicken breast). The set is not suitable for
food that needs to soak in the water (e.g.
rice, polenta, pasta).
Sponge
For absorbing the remaining water from
the steam generator.
Page 7
4. BEFORE FIRST USE
ENGLISH 7
WARNING!
Refer to the Safety chapters.
If the heating element hangs
down, push it to the top of the appliance above the supports which
are on the inner walls of the appliance.
4.1 Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
Refer to chapter "Care and Cleaning".
4.2 Setting and changing the
time
After the first connection to the mains, all
symbols in the display are on for some
5. CONTROL PANEL
5.1 Electronic programmer
1 112 3 4 65 7 8 9 10
seconds. For the subsequent few seconds the display shows the software version.
After the software version goes off, the
display shows h and 12:00.
Setting the time of day:
1.
Touch or to set the hours.
2.
Touch .
3.
Touch or to set the minutes.
4.
Touch or .
The Temperature / Time display shows
the new time.
Changing the time of day
You can change the time of day only
when the appliance is off. Touch
flashes in the display. To set the new time
of day, use the above procedure.
.
Use the sensor fields to operate the appliance.
Sensor
Function Description
Field
1
2
3
4
ON / OFF To activate and deactivate the appliance.
OPTIONS To set an oven function, an automatic
OVEN LIGHT To activate or deactivate the oven lamp.
TEMPERATURE To set and see the cavity temperature.
programme or a cleaning function.
Page 8
www.electrolux.com
8
Sensor
Function Description
Field
5
MY FAVOURITE
PROGRAMME
6
7
8
9
10
11
- DISPLAY Shows the current settings of the appli-
UP To move up in the menu.
DOWN To move down in the menu.
CLOCK To set the clock functions.
MINUTE MINDER To set the Minute Minder.
OK To confirm a selection or setting. To
5.2 Display
AB C
To store your favourite programme. Use
it to have access to your favourite programme directly or when the appliance is
deactivated.
ance.
move down in the menu.
A)
Full Steam function symbol
B)
Number of the oven function / programme
C)
Indicators for the clock functions (refer
to the table "Clock functions")
D)
Clock / residual heat display (also Mi-
DE
nute Minder and Time of Day)
E)
Temperature / time display
5.3 Other indicators in the display
Symbols Name Description
/
/
Automatic programme
My favourite programme
kg / g An automatic programme with weight input
h / min
Heat-up / residual
heat indicator
Temperature
You can choose an automatic programme.
The favourite programme operates.
operates.
A clock function operates.
Shows the temperature level in the appliance.
You can examine or change the temperature.
Page 9
Symbols Name Description
5.4 Heat up indicator
If you activate an oven function, the bars
come on in the display. The bars
6. DAILY USE
Minute minder
ENGLISH 9
The minute minder function operates.
show that the temperature in the appliance increases or decreases.
When the appliance is at the set temperature, the bars go off the display.
WARNING!
Refer to the Safety chapters.
To operate the appliance you can use:
• The manual mode - to set a heating
function, the temperature and the cooking time manually.
• automatic programmes - to prepare
a dish when you do not have knowledge or experience in cooking.
6.1 Steam cooking
The water drawer cover is in the control
panel.
1.
Press the cover to open the water
drawer.
2.
Fill the water drawer with 800 ml of
water.
The water supply is sufficient for approximately 50 minutes.
Do not put water directly into the
steam generator!
Use only water as the liquid. Do
not use filtered (demineralised) or
distilled water.
3.
Activate the appliance. The display
shows the Full Steam function
4.
Touch to set the DURATION or
END function (refer to "Setting the
END" or "Setting the DURATION").
The first steam shows after approximately 2 minutes. An acoustic signal
sounds when the appliance is approximately at the set temperature.
The signal sounds again at the end of
the cooking time.
5.
Touch to deactivate the acoustic
signal and the appliance.
.
When the steam generator is
empty, an acoustic signal sounds.
When the appliance becomes cool, soak
up all remaining water from the steam
generator with the sponge. If necessary,
clean the steam generator with vinegar.
Let the appliance dry fully with the door
open.
6.2 Changing the temperature
Touch / to change the temperature in steps of 5 °C.
When the appliance is at the set temperature, an acoustic signal sounds three
times and the Heat up indicator goes out.
6.3 Checking the temperature
You can see the temperature in the appliance when the function or programme
operates.
1.
Touch . The Temperature / Time
display shows the temperature in the
appliance. If you want to change the
oven temperature, touch
time and use
2.
Touch to go back to the set tem-
perature or the display shows it auto-
matically after five seconds.
or .
one more
6.4 Energy saving
The appliance contains features which help you save energy during everyday cooking:
Residual heat:
•
– When the heating function or
programme operates, the
heating elements are deactivated 10% earlier (the lamp
Page 10
www.electrolux.com
10
and fan continue to operate).
For this feature to operate,
the cooking time must be
longer than 30 minutes or
you must use the clock functions (Duration, End, Time
delay). This feature does not
operate with the grill functions.
– When the appliance is off,
you can use the heat to keep
food warm. The clock / residual heat display shows the re-
7. CLOCK FUNCTIONS
SYMBOL FUNCTION DESCRIPTION
TIME OF DAY To examine the time of day. For changing the
DURATION To set how long the appliance operates.
maining temperature, and the
bars show the temperature
as it decreases.
• Cooking with the lamp off Touch
lamp during cooking.
• Deactivating the display - If
necessary, you can fully deacti-
vate the appliance. Touch
and at the same time until
the display goes out. This step
also activates the appliance.
to deactivate the
time of day refer to 'Setting and changing the
time'.
END To set when the appliance deactivates. You can
use the Duration and End functions at the same
time (Time delay), if the appliance is to be acti-
7.1 Count Up Timer
Use the Count Up Timer to monitor how
long the appliance operates. It is on immediately when the appliance starts to
heat.
Reset the Count Up Timer: touch
and at the same time until the display
shows "00:00" and the Count Up Timer
starts to count up again.
You cannot use the Count Up
Timer when Duration or End is
set.
7.2 Setting the DURATION
1.
Activate the appliance and set an
oven function and temperature.
2.
Touch again and again until the
display shows
display.
3.
Use or to set the minutes for
DURATION.
. flashes in the
vated and deactivated automatically later.
4.
Touch to confirm.
5.
Use or to set the hours for
DURATION.
If you touch or while you
set the DURATION, the appliance
switches to the setting of the END
function.
6.
When the set time ends, an acoustic
signal sounds for two minutes.
and time setting flash in the dis-
play. The appliance deactivates.
Touch a sensor field or open the oven
door to stop the acoustic signal.
7.
Deactivate the appliance.
7.3 Setting the END
1.
Activate the appliance and set an
oven function and temperature.
2.
Touch again and again until the
display shows
display.
. flashes in the
Page 11
3.
Use or to set the END (first
you set the minutes and then the
hours) and
4.
When the set time ends, an acoustic
signal sounds for two minutes.
symbol and the time setting flash
in the display. The appliance deactivates.
5.
Touch a sensor field or open the oven
door to stop the acoustic signal.
6.
Deactivate the appliance.
or to confirm.
7.4 Check result (selected
models only)
If you set the END or DURATION function,
two minutes before the end of cooking an
acoustic signal sounds and the lamp activates. The appliance goes to the setting
of the END or DURATION function. During
these two minutes you can examine the
results of the cooking, and, if necessary,
add the END or DURATION time.
7.5 Setting the MINUTE
MINDER
Use the MINUTE MINDER to set a countdown (maximum 2 h 30 min). This function has no effect on the operation of the
oven. You can set the MINUTE MINDER
at any time and also when the appliance
is off.
ENGLISH 11
1.
Touch . and "00" flash in the
display.
2.
Use or to set the MINUTE
MINDER. First you set the seconds,
then the minutes and the hours.
3.
Touch or the MINUTE MINDER
starts automatically after five seconds.
4.
When the set time ends, an acoustic
signal sounds for two minutes and
00:00 and
5.
Touch a sensor field or open the oven
door to stop the acoustic signal.
flash in the display.
7.6 Setting the Time delay
function
The DURATION and END functions
can be used at the same time, if the oven
is to be activated and deactivated automatically later. In this case, first set the
DURATION
function (refer to "Setting the DURATION"
and "Setting the END" ).
When the Time delay function is activated,
the display shows a static symbol of the
oven function,
dot shows which clock function is on in
the Clock / residual heat display.
and then the END
with a dot and . The
8. AUTOMATIC PROGRAMMES
WARNING!
Refer to the Safety chapters.
8.1 RECIPE MENU
The display shows the shelf position and the default cooking times
for all automatic recipes.
8.2 Automatic programmes
Programme number Programme name
1 STUFFED CHICKEN BREAST
2 FISH TERRINE
There are 9 automatic programmes and recipes. Use an automatic programme or recipe
when you do not have the knowledge or experience on how to
prepare a dish.
Page 12
www.electrolux.com
12
8.3 Automatic recipes
Setting an automatic recipe:
1.
2.
Programme number Programme name
3 FLAN CARAMEL
4 CHOCOLATE CREAM
5 STUFFED LETTUCE
6 ASPARAGUS FLAN
7 VEGETABLES, MEDITERRANEAN
8 BOILED POTATOES
9 RICE
You can find the recipes for the
automatic programmes specified
for this appliance on our website.
To find the proper Recipe Book
check the PNC number on the
rating plate on the front frame of
the appliance cavity.
Activate the appliance.
Touch . The display shows the
number of the automatic programme
(P1 – P9).
3.
Touch or to choose the automatic recipe.
4.
Touch or the automatic recipe
activates automatically after five seconds.
5.
When the set time ends, an acoustic
signal sounds for two minutes. The
symbol
activates.
6.
Touch a sensor field or open the door
to stop the acoustic signal.
flashes. The appliance de-
9. USING THE ACCESSORIES
WARNING!
Refer to the Safety chapters.
9.1 Installing the accessories
Wire shelf:
Put the shelf in and make sure that the indentations point down.
Push the shelf between the guide bars of
the shelf support.
Page 13
All accessories have small indentations at the top of the right and
left side to increase safety. The indentations are also anti-tip devices.
The high rim around the shelf is a
device which prevents cookware
from slipping.
10. ADDITIONAL FUNCTIONS
10.1 My Favourite Programme
function
Use this function to save your favourite
temperature and time settings for an oven
function or programme.
1.
Set the temperature and time for an
oven function or programme.
2.
Touch and hold for more than
three seconds. An acoustic signal
sounds.
3.
Deactivate the appliance.
Using My Favourite Programme
function:
•
To activate the function touch
The appliance activates your favourite
programme.
•
To deactivate the function touch
. The appliance deactivates your favourite programme.
When the function operates, you
can change the time and temperature.
2.
Touch and hold and at the
same time for 2 seconds. An acoustic
signal sounds.
SAFE comes on or goes out in the display.
10.3 Function Lock
You can activate the function only when
the appliance operates. The Function
Lock prevents an accidental change of
the oven function.
Activating / deactivating the Function
Lock function:
1.
.
Activate the appliance.
2.
Activate an oven function or setting.
3.
Touch and hold and at the
same time for 2 seconds. An acoustic
signal sounds.
Loc comes on or goes out in the display.
You can deactivate the appliance when
the Function Lock is on. When you deactivate the appliance, the Function Lock
deactivates.
ENGLISH 13
10.2 Child Lock
The Child Lock prevents an accidental
operation of the appliance.
Activating and deactivating the Child
Lock function:
1.
Deactivate the appliance with . Do
not set an oven function.
Settings menu
Indicator of the setting
menu
SET1 RESIDUAL HEAT INDI-
Description Value to set
10.4 Settings menu
The settings menu lets you add or remove
functions from the main menu (for example: you can activate or deactivate the Residual heat indicator). The settings menu
has a maximum of six settings (from SET1
to SET6). Refer to the table below to see
the possible value of each setting.
ON / OFF
CATOR
Page 14
www.electrolux.com
14
Indicator of the setting
Description Value to set
menu
SET2
1)
KEY TONE CLICK / BEEP / OFF
SET3 FAULTY TONE ON / OFF
SET4 SERVICE ---
SET5 RESTORE SETTINGS YES / NO
2)
SET6
1)
It is not possible to deactivate the tone of the ON / OFF sensor field.
2)
Selected models only
You can set the settings menu only when the appliance is deactivated.
Activating the settings menu:
1.
If necessary, deactivate the appliance
with
.
2.
Touch and hold for three seconds.
The display shows "SET1" and "1"
flashes.
3.
Touch / to select the setting.
4.
Touch .
TIME EXTENSION ON / OFF
5.
Touch / to change the value
of the setting.
6.
Touch .
10.5 Automatic switch-off
For safety reasons the appliance deactivates automatically after some time:
• If an oven function operates.
• If you do not change the oven tempera-
ture.
Temperature Switch-off time
50 °C - 96 °C 12.5 h
After the Automatic switch-off, touch a
sensor field to operate the appliance
again.
The Automatic switch-off works
with all oven functions, apart from
Duration, End and Time delay.
10.6 Brightness of the display
There are two modes of display
brightness:
• Night brightness - when the appliance
is deactivated, the brightness of the
display is lower between 10 PM and 6
AM.
• Day brightness:
– When the appliance is activated.
– If you touch a sensor field during the
night brightness (apart from ON /
OFF), the display goes back to the
day brightness mode for the next 10
seconds.
– If the appliance is deactivated and
you set the Minute Minder. When the
Minute Minder function ends, the display goes back to the night brightness.
10.7 Cooling fan
When the appliance operates, the cooling
fan activates automatically to keep the
surfaces of the appliance cool. If you deactivate the appliance, the cooling fan can
continue to operate until the appliance
cools down.
Page 15
11. HELPFUL HINTS AND TIPS
ENGLISH 15
The temperature and baking times
in the tables are guidelines only.
They depend on the recipes and
the quality and quantity of the ingredients used.
11.1 Cooking with steam
Cookware for steam cooking
• Use only heat and corrosion resistant
cookware.
Chrome steel food containers are correct
too (see special accessories).
Oven levels
• There are the correct oven levels in the
table below. Count the oven levels from
the bottom to the top.
General notes
• When you cook longer than 30 minutes
or when you cook large quantities of
food, add water if it is necessary.
• Put the food in the correct cooking
containers on the shelves. Keep the
11.2 Steam water table
Water in the water drawer in ml
300 15 - 20
600 30 - 40
800 50 - 60
1)
The times are for guidance only
11.3 Steam cooking tables
WARNING!
Do not open the appliance door
when the function is active. Risk
of burns.
The function is suitable for all types of
food — fresh and frozen. You can use it
for cooking, warming, defrosting, poaching, or blanching vegetables, meat, fish,
pasta, rice, sweet corn, semolina and
eggs.
Cooking of menus: You can prepare
complete set in one go. To avoid under or
over cooked dishes choose those which
require similar cooking times. Use the
distance between the shelves to let the
steam get to each food.
• If you do not use the oven for a long
time, remove water from the water
drawer, connecting hoses and steam
generator (refer to section "Cleaning
and Care").
Note on the tables for Steam Cooking
• The tables give data for typical dishes.
The temperature and time are for guidance only and depend on the composition, size , quantity of food and the cookware.
Use almost the same recipe if you cannot
find the settings for your recipe.
Start the cooking with the cold oven if the
data in the tables does not recommend
differently.
Increase the amount of water for rice to
the ratio 1 : 1.5 - 1: 2 contrary to the
specifications in the table.
Time1) in min.
largest amount of water specified for individual component. Put the dishes on the
oven shelves in the suitable cookware.
Adjust the gap between the dishes to let
the steam circulate.
Sterilisation
• With this function you can sterilise containers ( e.g. baby bottles).
• Put the clean containers in the middle
of the shelf on the 1st level. Make sure
that the opening faces down at a small
angle.
• Fill the drawer with the maximum
amount of water and set a time of 40
min.
Page 16
www.electrolux.com
16
Vegetables
Artichokes 96 800 50 - 60 1
Auberginen 96 450 15 - 25 1
Cauliflower,
whole
Cauliflower,
florets
Broccoli,
whole
Broccoli, florets
Mushroom slices
Peas 96 450 20 - 25 1
Fennel 96 600 35 - 45 1
Carrots 96 600 35 - 45 1
Kohlrabi,
strips
Peppers,
strips
Leeks, rings 96 500 25 - 35 1
Green beans 96 550 35 - 45 1
Lamb’s lettuce, florets
Brussels
sprouts
Beetroot 96 800 + 400 70 - 90 1
Black salsify 96 600 35 - 45 1
Celery, cubed 96 500 20 - 30 1
Asparagus,
green
Asparagus,
white
Spinach, fresh 96 350 15 1
Peeling tomatoes
White haricot
beans
Food
Temperature
ºC
Water
amount in ml
Time1) in
min.
96 600 35 - 45 1
96 500 25 - 30 1
96 550 30- 40 1
96 400 20 - 25 1
96 400 15 - 20 1
96 550 30 - 40 1
96 400 15 - 20 1
96 450 20 - 25 1
96 550 30 - 40 1
96 500 25 - 35 1
96 600 35 - 45 1
96 350 15 1
96 500 25 - 35 1
Shelf position
Page 17
ENGLISH 17
Food
Savoy cab-
Temperature
ºC
96 400 20 - 25 1
bage
Courgette, sli-
96 350 15 1
ces
1)
The times are for guidance only.
Side dishes / accompaniments
Food
Yeast dumplings
Potato dumplings
Temperature
ºC
96 600 30 - 40 1
96 600 35 - 45 1
Unpeeled potatoes, medi-
96 750 45 - 55 1
um
Rice (water /
rice ratio
96 600 35 - 40 1
1.5:1)
Boiled potatoes, quar-
96 600 35 - 40 1
tered
Bread dumpling
Tagliatelle,
fresh
96 600 35 - 45 1
96 450 20 - 25 1
Polenta (liquid / polenta
96 750 40 - 45 1
ratio 3:1)
1)
The times are for guidance only.
Water
amount in ml
Water
amount in ml
Time1) in
min.
Time1) in
min.
Shelf position
Shelf posi-
tion
Fish
Food
Trout, approx.
250 g
Temperature
ºC
85 550 30 - 40 1
Water
amount in ml
Time1) in
min.
Shelf posi-
Prawns, fresh 85 450 20 - 25 1
Prawns, frozen
85 550 30 - 40 1
Salmon filets 85 500 25 - 35 1
tion
Page 18
www.electrolux.com
18
Food
Temperature
ºC
Water
amount in ml
Time1) in
min.
Shelf posi-
Salmon trout,
approx. 1000
85 600 40 - 45 1
g
Mussels 96 500 20 - 30 1
Flat fish filet 80 350 15 1
1)
The times are for guidance only.
Meat
Food
Cooked ham
1000 g
Temperature
ºC
96 800 + 150 55 - 65 1
Water
amount in ml
Time1) in
min.
Shelf posi-
Chicken
breast, poach-
90 500 25 - 35 1
ed
Chicken,
poached,
96 800 + 150 60 - 70 1
1000 - 1200 g
Veal / pork loin
without leg,
90 800 + 300 80 - 90 1
800 - 1000 g
Kasseler
(smoked loin
of pork),
90 800 + 300 70 - 90 1
poached
Tafelspitz
(prime boiled
96 800 + 700 110 - 120 1
beef)
Chipolatas 80 400 15 - 20 1
1)
The times are for guidance only.
tion
tion
Eggs
Food
Eggs, softboiled
Eggs, medium-boiled
Eggs, hardboiled
1)
The times are for guidance only.
Temperature
ºC
96 400 10- 12 1
96 450 13 - 16 1
96 500 18 - 21 1
Water
amount in ml
Time1) in
min.
Shelf posi-
tion
Page 19
12. CARE AND CLEANING
ENGLISH 19
WARNING!
Refer to the Safety chapters.
Notes on cleaning:
• Clean the front of the appliance with a
soft cloth with warm water and a cleaning agent.
• To clean metal surfaces, use a usual
cleaning agent.
• Clean the appliance interior after each
use. Then you can remove dirt more
easily and it does not burn on.
• Clean stubborn dirt with a special oven
cleaner.
• Clean all accessories after each use
and let them dry. Use a soft cloth with
warm water and a cleaning agent.
• If you have nonstick accessories, do
not clean them using aggressive
agents, sharp-edged objects or a dishwasher. It can cause damage to the
nonstick coating.
12.1 Steam cleaning
1.
Remove the worst of the dirt manually.
2.
Put approximately 250 ml of water
and 3 tablespoons of vinegar directly
into the steam generator.
3.
Touch again and again until the
display shows
4.
The display shows the duration (15
minutes) and the default temperature.
Touch
5.
An acoustic signal sounds when the
steam cleaning is completed. Touch a
sensor field to stop the signal.
6.
Clean the appliance with soft cloth.
Remove the water from the steam
generator with the sponge and rub it
dry.
Keep the door open for approximately 1 hour to let the appliance
dry fully.
You can use the End function to
delay the start of the cleaning. Refer to "Setting the END".
.
to start the cleaning.
12.2 Shelf support
Removing the shelf support
You can remove the shelf support to
clean the side walls.
1.
Carefully pull the support up and out
of the front catch.
Page 20
www.electrolux.com
20
Installing the shelf support
To install the shelf support follow the procedure in the opposite order.
12.3 Steam generation system
Cleaning the water drawer and the
steam generator:
1.
2.
3.
CAUTION!
Dry the steam generator after
each use. Remove the water with
the sponge.
Remove the limescale with water
and vinegar.
CAUTION!
Chemical de-scaling agents can
cause damage to the enamel. Follow the instructions of the manufacturer.
Put the water and vinegar mixture
(approximately 250 ml) through the
water drawer into the steam generator. Wait for approximately 10 minutes.
Remove the water and vinegar with
the sponge.
Put clean water (100 - 200 ml) into
the water drawer to flush the steam
generation system.
2.
Lightly move the support on the front
catch inwards.
3.
Pull the support out of the rear catch.
4.
Remove the water from the steam
generator with the sponge and rub it
dry.
5.
Keep the door open to let the appliance dry fully.
12.4 Lamp
WARNING!
There is a risk of electrical shock.
The lamp and the lamp glass cover can be hot.
Before you change the lamp:
• Deactivate the appliance.
• Remove the fuses from the fuse box or
deactivate the circuit breaker.
CAUTION!
Put a cloth on the bottom of the
interior of the appliance. It prevents damage to the lamp glass
cover and the cavity.
Always use the same lamp type.
Replacing the lamp at the cavity
ceiling:
1.
Turn the lamp glass cover counterclockwise to remove it.
2.
Remove the metal ring and clean the
glass cover.
3.
Replace the lamp with a suitable 300
°C heat-resistant lamp.
Page 21
4.
Attach the metal ring to the glass cover.
5.
Install the glass cover.
Replacing the lamp on the left side of
the cavity:
1.
Remove the left shelf support.
2.
Use a Torx 20 screwdriver to remove
the cover.
3.
Remove and clean the metal frame
and the seal.
A
A
45°
2
B
1
ENGLISH 21
4.
Replace the lamp with a suitable 300
°C heat-resistant lamp.
5.
Install the metal frame and the seal.
Tighten the screws.
6.
Install the left shelf support.
12.5 Door and glass panels
Remove the door to clean it.
Removing the door
CAUTION!
Be careful when you remove the
door from the appliance. The door
is heavy.
1.
Open the door as far as it goes.
2.
Fully lift up the clamping levers (A) on
the two door hinges.
3.
Close the door until it is at an angle
of approximately 45°.
4.
Hold the door with one hand on each
side and pull it away from the appliance at an upwards angle.
Put the door with the outer side
down on a soft and level surface
to prevent scratches.
5.
At this time you can remove the inner
glass panels and clean them.
To install the door do the above steps in
the opposite sequence.
Removing and cleaning the door
glasses
The door has 2, 3 or 4 panels of
glass (the number depends on the
model).
CAUTION!
Rough handling of the glass, especially around the edges of the
front panel, can cause the glass to
break.
1.
Hold the door trim (B) on the top
edge of the door at the two sides and
push inwards to release the clip seal.
Page 22
www.electrolux.com
22
13. WHAT TO DO IF…
WARNING!
Refer to the Safety chapters.
Problem Possible cause Remedy
The appliance does not
heat up.
The appliance does not
heat up.
The appliance does not
heat up.
The appliance does not
heat up.
The appliance does not
heat up.
The lamp does not operate.
The display shows an error code that is not in this
list.
If you cannot find a solution to the problem yourself, contact your dealer or the
service centre.
We recommend that you write the data here:
Model (MOD.) .........................................
2.
Pull the door trim to the front to re-
move it.
3.
Hold the door glass panels on their
top edges one by one and pull them
upwards from the guide.
4.
Clean the door glass panels.
To install the panels do the above
steps in the opposite sequence. In-
sert the smaller panel first, and then
the larger one.
The appliance is deacti-
Activate the appliance.
vated.
The clock is not set. Set the clock. Refer to
“Setting and changing the
time”.
The necessary settings
are not set.
The automatic cut-out is
activated.
Make sure that the settings are correct.
Refer to “Automatic
switch-off”.
The fuse is released. Make sure that the fuse is
the cause of the malfunction. If the fuse releases
again and again, contact
a qualified electrician.
The lamp is defective. Replace the lamp.
There is an electrical fault. • Deactivate the appli-
ance with the house
fuse or the safety
switch in the fuse box
and activate it again.
• If the display shows the
error code again, contact the Service Center.
The necessary data for the service centre
is on the rating plate. The rating plate is
on the front frame of the appliance cavity.
Page 23
Product number (PNC) .........................................
Serial number (S.N.) .........................................
14. INSTALLATION
ENGLISH 23
WARNING!
Refer to the Safety chapters.
448-452
min.
550
min.
560
The built-in unit must meet the
stability requirements of DIN
68930.
21
15
547
440
567
455
594
333
448-452
448-452
min.
550
min.
560
440
567
547
21
15
455
455
333
594
Page 24
www.electrolux.com
24
448-452
448-452
448-452
min. 560
440
440
547
21
15
455
455
min.
550
567
440
594
455
333
Page 25
90°
ENGLISH 25
2x3,5x25
15. ENVIRONMENT CONCERNS
Recycle the materials with the symbol
. Put the packaging in applicable
containers to recycle it.
13
20
Help protect the environment and human
health and to recycle waste of electrical
and electronic appliances. Do not dispose
appliances marked with the symbol
Page 26
www.electrolux.com
26
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
Page 27
ENGLISH 27
Page 28
www.electrolux.com/shop
892960368-A-072013
Loading...
