INSTRUCTION BOOKLET
2222 740-55
EUU 1172 / EUU 6174
freezer
UK
2
Instructions for the User
Before use 5 Freezer controls 5 Starting your appliance 5 Temperature control 5 Warning light (red) 5 Temperature acoustic alarm 5 Freezing fresh food 5 Frozen food storage 6 Thawing 6 Ice making 6
Internal cleaning 9 Periodic cleaning 9 When the appliance is not in use 9
Something Not Working? 10 Service and Spare Parts 11 Customer Care Departments 11
Guarantee Conditions 12
Instructions for the Installer
Technical Specifications 13 Installation 13
Positioning 13
Electrical Connection 14 Building-in Instructions 15
Grid preparation 15 Door reversal 15 Building the appliance in under a worktop 16 Fitting the plinth 20
CONTENTS
Prior to Installation
¥ Check the appliance for transport damage. Under
no circumstance should a damaged appliance be installed. In the event of damage please contact your retailer.
Installation
¥ This appliance is heavy . Care should be taken when
moving it.
¥ It is dangerous to alter the specifications or attempt
to modify this product in any way.
¥ Ensure that the appliance does not stand on the
electrical supply cable. Important: if the supply cable is damaged, it must be replaced by autho­rised service or qualified personnel using a special cable of the same type.
¥ Any electrical work required to install this appliance
should be carried out by a qualified electrician or competent person.
¥ Parts which heat up should not be exposed.
Whenever possible, the back of the appliance should be close to a wall, but leaving the required distance for ventilation, as stated in the installation instructions.
¥ The appliance should be left for 2 hours after instal-
lation before it is turned on, in order to allow the refrigerant to settle.
Refrigerant
¥ The refrigerant isobutane (R600a) is contained
within the refrigerant circuit of the appliance, a nat­ural gas with a high level of environmental compat­ibly, which is nevertheless flammable.
¥ During transportation and installation of the appli-
ance, be certain that none of the components of the refrigerant circuit become damaged.
¥ If the refrigerant circuit should become damaged: -
avoid open flames and sources of ignition.
- thoroughly ventilate the room in which the appli­ance is situated.
Child Safety
¥ Do not allow children to tamper with the controls or
play with the product.
¥ There is a risk of suffocation! Keep packaging mate-
rial away from children!
General Safety
¥ This appliance contains hydrocarbons in its
cooling unit; maintenance and recharging must therefore only be carried out by authorised technicians.
¥ Take utmost care when handling your appliance
so as not to cause any damages to the cooling unit with consequent possible fluid leakages.
¥ The appliance must not be located close to radi-
ators or boilers.
¥ Avoid prolonged exposure of the appliance to
direct sunlight.
¥ Do not use other electrical appliances (such as
ice cream makers) inside of refrigerating appli­ances.
During Use
¥ This appliance is designed for domestic use only,
specifically for the storage of edible foodstuffs only. It is not intended for commercial or industrial use.
¥ Containers with flammable gases or liquids can leak
at low temperatures. Do not store any containers with flammable materials, such as spray cans, fire extinguisher refill cartridges etc. in the refrigerator.
¥ Frozen food should not be refrozen once it has
thawed out.
¥ Do not place carbonated or fizzy drinks in the freez-
er compartment.
¥ Ice lollies can cause ‘frost/freezer burns’ if con-
sumed straight from the star compartement.
¥ Do not remove items from the freezer comparte-
ment if your hands are damp/wet, as this could cause skin abrasions or frost/freezer burns.
¥ Bottles and cans must not be placed in the freezer
compartment they can burst when the contents freeze.
¥ Manufacturers’ recommended storage times should
be adhered to. Refer to relevant instructions.
Maintenance and Cleaning
¥ Before cleaning, always switch off the appliance
and disconnect from the electrical supply.
¥ When unplugging always pull the plug from the
mains socket, do not pull on the cable.
3
IMPORTANT SAFETY INSTRUCTIONS
These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department.
4
Servicing
¥ This product should be serviced by an authorised
engineer and only genuine spare parts should be used.
¥ Under no circumstances should you attempt to
repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force Centre.
At the end of the Appliance Life
¥ When disposing of your appliance use an autho-
rised disposal site.
¥ Remove the plug and ensure that any locks or
catches are removed, to prevent young children being trapped inside.
Thermostat control knob
Push button ON/OFF
Pilot light (green)
Warning light (red)
Fast-freezing indicator light (yellow)
Push button for fast-freezing
Symbol for audible alarm (temperature warning ­only for EUU11727)
5
OPERATION
Freezer controls
Before use
Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or deter­gent as the smell may linger. Dry thoroughly.
Starting your appliance
Insert the plug into the wall socket. The appliance can be activated/deactivated by pressing the ON/OFF but-
ton.When the pilot light ➂is illuminated this shows that the appliance is on.
Temperature control
The temperature within the freezer is controlled by the thermostat ➀ situated at the bottom of the cabinet .
To operate the freezer proceed as follows: Turn the thermostat control knob beyond the «■» position. When you first start the freezer, we suggest that you turn the thermostat control knob to a medium setting. For easier turning of this control, use a small coin. The internal temperature of the freezer is auto­matically adjusted by the thermostat to ensure safe food storage. However, if the appliance is working in unfavourable room conditions such as high tempera­ture and frequent door openings, it may be necessary to select a more suitable setting. To obtain a lower temperature, turn the thermostat control knob towards max.; to obtain a higher temper­ature turn the control knob towards min.
Warning light (red)
If the temperature warning light ➃lights up, it indi­cates that the temperature within the freezer has reached a level where the safe food storage is no longer ensured. When the freezer is first switched on, the warning light will stay on until the temperature has dropped to a safe level for the storage of frozen food.
Temperature acoustic alarm
(only for EUU1172)
This appliance incorporates an alarm which gives off an audible signal whenever the warning light comes on. This signal can be temporarily stopped by
depressing the push button for fast-freezing
.
The fast-freezing push button can be released as soon as the warning light is off.
Freezing fresh food
In any 24 hour period you can freeze up to 18 kg of fresh food. Activate fast freeze by depressing the fast-freeze switch ➅24 hours before you want to freeze your
Thawing
Frozen food, prior to being used, can be thawed in the fridge or at room temperature depending on the time available. Small food items may even be cooked from frozen; in this case cooking will take longer.
Any frozen food which is allowed to thaw accidentally should either be eaten as soon as possible or thrown away. Alternatively, if the food is uncooked and has not been completely defrosted it can be cooked and then refrozen.
Defrosted cooked food must never be refrozen.
6
fresh food, the yellow light ➄ illuminates. This time
can be shortened, depending on the quantity of food to be frozen. After the time has elapsed place the food to be frozen in the two top compartments of the freez­er as this is the coldest part; if freezing only a small amount of food, always use the top compartment. Once the food is completely frozen (which could take up to 24 hours) press the fast freeze switch to deacti­vate the fast freeze mode; the yellow light ➄goes off. Distribute the frozen food packages in the other com­partments, so that the top compartments can be used for a further freezing operation. Only freeze top quality, fresh and thoroughly cleaned foodstuffs. Do not allow fresh food to touch food which is already frozen. During the freezing process, ensure that the freezer door remains closed.
Frozen food storage
When you first start the freezer or if the freezer has been out of use for some time, we advise you to run your appliance for at least two hours in the «fast freeze» mode before storing frozen food.
To obtain the best performance from this appliance, we strongly recommend that you make sure that the commercially frozen foodstuffs were adequately stored by the retailer and, furthermore, be sure that these frozen foodstuffs are transferred from the food­store to the consumer in the shortest possible time (a temperature increase of the frozen food could shorten its storage period).
It is also advisable not to exceed the storage period indicated by the producer of the food.
Finally, do not open the door frequently or leave it open longer than is absolutely necessary.
Important
Do not put carbonated liquids, (fizzy drinks etc.), in the freezer compartment.
Ice lollies, if consumed immediately after removal from the freezer, can possibly result in a low temperature skin burn.
Do not remove items from the freezer if your hands are damp/wet, as this could cause skin abrasions or "frost/freezer burns".
If there is a power failure during the storage of frozen food, do not open the door during the whole time of the power failure. If the freezer is fully loaded, the frozen food will not be affected if the power cut is of short duration; otherwise, it is recommended to consume the food within a very short time.
To remove the drawers, proceed as follows: pull the drawer out until it comes to a stop, then tilt it upwards (see figure).
Making ice cubes
The appliance is provided with a plastic ice cube tray. Fill the tray 3/4 full to allow the ice to expand and place it in the freezer. To turn out the ice cubes simply give the tray a slight twist to release the cubes.
Never tray to free an ice tray that is frozen to the freezer using a sharp or pointed object.
PR001c
7
Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible.
HEALTH AND SAFETY GUIDELINES
¥ Keep the freezer door closed as much as possible. ¥ Do not push food together too much, try to allow air
to circulate around each item.
¥ Cool cooked food as quickly as possible but do
NOT place in the freezer until cool. (Leave food in a place as cool as possible in order that it can then be placed in the refrigerator as soon as possible).
¥ Do not store food uncovered. ¥ The best way to defrost food is to put it in the refrig-
erator to thaw slowly.
¥ Ensure that food placed in the freezer is dated and
labelled and used in date order to ensure that food is consumed at its best.
¥ It is important that food is used before its “best
before” date.
¥ Always wash your hands with soapy water and dry
them with a clean towel before handling food.
¥ Keep work surfaces clean and avoid cross contam-
ination by not using the same work surface or knife, without washing them thoroughly in between.
¥ The foods to be frozen must be fresh and of the
best quality.
¥ The size of each pack should be small enough to
ensure that it is used in one go. Small packs freeze more quickly and uniformly and give better results.
¥ Frozen food, once thawed, must not be refrozen.
Lean food keeps better and longer than fatty food, salt reduces the storage time.
¥ Wrap the food in polythene or aluminium freezing
bags or foil so that they adhere to the food and pro­vide an airtight seal.
¥ Packaging which is swollen or has traces of
refrozen water droplets on the pack could indicate that the product has not been kept at a suitable tem­perature and that it may have lost its original quali­ty. Partially thawed food must not be refrozen, it must be consumed within 24 hours. Never exceed the storage time indicated.
¥ Never place hot food, bottles or cans of fizzy drink
in the freezer as they may explode. Containers with a lid must not be filled to the brim.
¥ Do not open the door or place extra fresh food in the
freezer next to food which is already frozen as this could cause the temperature of the frozen food to rise and its quality and storage life to reduce.
8
The freezer compartment will become progressively covered with frost. This should be removed with the special plastic scraper provided, whenever the thick­ness of the frost exceeds 1/4".
During this operation it is not necessary to switch off the power supply or to remove the foodstuffs. However, when the ice becomes very thick on the inner liner, complete defrosting should be carried out and it is advisable to carry out this operation when the appliance is empty.
To carry out complete defrosting proceed as follows:
1. Remove any stored food, wrap it in several layers of newspaper and put it in a cool place.
2. Turn the thermostat control ➀to the «» setting.
3. Leave the door open.
4. Remove the three large drawers.
5. When defrosting is completed, remove the water
that has collected in the small bottom drawer and dry the interior thoroughly.
Turn the thermostat control to a medium setting and, after letting the appliance run for at least two hours in the «fast freeze» mode, replace the previously removed food into the compartments.
Important
A temperature rise of the frozen food packs during defrosting may shorten their storage life.
Never use sharp metal tools to scrape off frost from the evaporator as you could damage the appliance beyond repair.
Important In the event of a power failure causing t h e
temperature within your freezer to rise, do not re-freeze the food without checking its condition. The following guidelines should assist you:
Ice-cream: once thawed should be discard-ed. Fruits & Vegetables: if soft should be cooked
and used up. Breads & Cakes: can be re-frozen without danger. Shellfish: should be refrigerated and used up quickly. Cooked Dishes: i.e. casseroles should be refrigerated and used up. Large Pieces of Meat: can be re-frozen pro­viding there are still ice crystals remaining with­in them. Small Joints: should be cooked and can then be re-frozen as cooked dishes. Chicken: should also be cooked and re-frozen as a cooked dish.
DEFROSTING
Warning Before any maintenance or cleaning work is
carried out, DISCONNECT the appliance from the ELECTRICITY supply.
Important This appliance contains hydrocarbons in its
cooling unit maintenance and recharging must therefore only be carried out by autho­rised technicians.
Internal cleaning
Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly.
NEVER USE DETERGENTS, ABRASIVE POW­DERS, HIGHLY PERFUMED CLEANING PROD­UCTS OR WAX POLISHES, TO CLEAN THE INTE­RIOR AS THESE WILL DAMAGE THE SURFACE AND LEAVE A STRONG SMELL.
Important Do not use abrasive products.
Periodic cleaning
The appliance is equipped with a ventilation grid. Keep clean to guarantee good ventilation and good working order of the appliance.
An accumulation of dust will affect the performance of the appliance and cause excessive electricity con­sumption. The structure of the appliance permits cleaning of the rear zone close to the wall, using a vacuum cleaner.
1. Remove the plinth (1), then the ventilation grid (2);
2. Carefully pull the air deflector out (3).
When the appliance is not in use
When the appliance is not in use for long periods, dis­connect from the electricity supply, empty all foods and clean the appliance, leaving the door ajar to pre­vent unpleasant smells.
9
MAINTENANCE AND CLEANING
S.I.013
3
21
10
If after the above checks, there is still a fault, call your local Service Force Centre. In-guarantee customers should ensure that the above checks have been made as the engineer will make a
charge if the fault is not a mechanical or electrical breakdown. Please note that proof of purchase is required for any in-guarantee service calls.
Symptom Solution
No power to the appliance
The temperature in the freezer is too high
The freezer door will not open
The compressor runs continuously
Excessive frost and ice has built up.
Noise
- Check there is power at the socket.
- Check there is not a power cut by checking the house­hold lights.
- Check the fuse has not blown.
- Check the thermostat control knob is turned to the cor­rect setting relative to ambient conditions.
- Check the ambient temperature is within the appliances operating limits of 10°C to 38°C.
- Has door just been opened?
- If so leave for a few minutes to allow the air pressure to equalise.
- Adjust the thermostat control knob to give correct tem­perature control. See page 5.
- Check that the door is closed.
- Large quantities of food have recently been placed in the cabinet and/or door is frequently opened.
- Check that air ventilation is not obstructed.
- Ensure the door is not left opened.
- Check that nothing is preventing the door from closing.
- Is the door gasket intact and clean.
- Has advised periodic defrosting been carried out.
Refer to normal operating sounds.
SOMETHING NOT WORKING?
Before contacting your local Service Force Centre check the following points.
IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or
installation, a charge will be made even if the appliance is under guarantee.
11
SERVICE AND SPARE PARTS
In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Service Force Centre by telephoning:-
08705 929929
Your telephone call will be automatically routed to the Service Force Centre covering your post code area.
For the address of your local Service Force Centre and further information about Service Force, please visit the website at www.serviceforce.co.uk
Before calling out an engineer, please ensure you have read the details under the heading “Something Not Working.”
When you contact the Service Force Centre you will need to give the following details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details of the fault
4. The model and serial number of the appliance
(found on the rating plate)
5. The purchase date Please note that a valid purchase receipt or guaran-
tee documentation is required for in-guarantee ser­vice calls.
CUSTOMER CARE DEPARTMENT
For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk
Customer Care Department Electrolux 55-77 High Street Slough Berkshire SL1 1DZ 08705 950 950 (*)
* calls to this number may be recorded for training purposes.
12
GUARANTEE CONDITIONS
Standard guarantee conditions
We, Electrolux, undertake that if within 12 months of the date of purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:
• The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
• The appliance has been used for normal domestic purposes only, and in accordance with the manufactuer's instructions.
• The appliance has not been serviced, maintained repaired, taken apart or tampered with by any person not authoried by us.
• All service work under this guarantee must be undertaken by an Electrolux Service Force Centre.
• Any appliance or defective part replaced shall become the Company's property.
• This guarantee is in addition to your statutory and other legal rights.
Home visits are made between
8.30am and 5.30pm Monday to Friday. Visits may be available outside these
hours in which case a premium will be charged.
Exclusions
This guarantee does not cover:
• Damage or calls resulting from transportation, improper use or neglect, the replacement of any light bulbs or removable parts of glass or plastic.
• Costs incurred for calls to put right an appliance which is improperly installed or calls to appliances outside the United Kingdom.
• Appliances found to be in use within a commercial environment, plus those which are subject to rental agree­ments.
• Products of Electrolux manufacture which are not marketed by Electrolux.
European Guarantee
If you should move to another country within Europe then your guarantee moves with you to your new home sub­ject to the following qualifications:
• The guarantee starts from the date you first purchased your product.
• The guarantee is for the same period and to the same extent for labour and parts as exists in the new country of use for this brand or range of products.
• This guarantee relates to you and cannot be transferred to another user.
• Your new home is within European Community (EC) or European Free Trade Area.
• The product is installed and used in accordance with our instructions and is only used domestically, i.e. a nor­mal household.
• The product is installed taking into account regulations in your new country.
Before you move please contact your nearest Customer Care centre, listed below, to give them details of your new home. They will then ensure that the local Service Organisation is aware of your move and able to look after you and your appliance.
France Senlis +33 (0) 3 44 62 20 13 Germany Nürnberg +49 (0) 800 234 7378 Italy Pordenone +39 (0) 800 117 511 Sweden Stockholm +46 (0) 20 78 77 50 UK Slough +44 (0) 1753 219898
13
DIMENSIONS Height 81,5 cm
Width 59,6 cm Depth 54 cm
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOT ALPOWER ABSORBED 90 W AVERAGE DAILY UNITS ELECTRICITY(*) 0,78 kWh
GROSS CAPACITY 108 l NET CAPACITY 100 l
STAR RATING
(*)This figure is based on standard test results in accordance with European Standard EN153. Actual con­sumption will depend on how the appliance is used and where it is located.
TECHNICAL SPECIFICATIONS
Positioning
This appliance should only be installed at a location where the ambient temperature corresponds to the cli­mate classification indicated on the rating plate, which is located on the inside left of the appliance.
The following table shows which ambient temperature is correct for each climate classification.
SN +10°C to +32°C ST +18°C to +38°C The appliance should be located in a dry atmosphere,
out of direct sunlight and away from continuous heat and extreme temperature, e.g. not next to a boiler or radiator, or in a very cold room e.g. an outhouse. If these temperatures are exceeded i.e. warmer or cold­er, then the appliance may not operate correctly.
For building-in and door reversal instructions please refer to the relevant instructions on the following pages.
INSTALLATION
14
ELECTRICAL CONNECTION
WARNING THIS APPLIANCE MUST BE EARTHED.
The manufacturer declines any liability should this safety measure not be observed.
If the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate plug fitted.
Remove the fuse from the cut off plug. The cut off plug should then be disposed of to prevent
the hazard of shocks in case it should be plugged into a 13amp socket in another part of your home.
Important
The wires in the mains lead are coloured in accordance with the following code:
Green and Yellow- Earth Blue - Neutral Brown - Live
If you fit your own plug, the colours of the wires in the mains lead of your appliance, may not correspond with the markings identifying the terminals in your plug, proceed as follows:
Connect the Green and the Yellow (earth) wire to the terminal in the plug which is marked with the letter
«E» or the earth symbol , or coloured green and yellow.
Connect the blue (neutral) wire to the terminal in the plug which is marked with the letter «N» or coloured black.
Connect the brown (live) wire to the terminal in the plug which is marked with the letter «L» or coloured red.
The plug moulded onto the lead incorporates a fuse. For replacement, use a 13amp BS1362 fuse. Only ASTA or BSI approved fuses should be used.
The plug must not be used if the fuse cover/carrier is lost. The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Service Force Centre.
This appliance complies with the following E.E.C. Directive:
-73/23 EEC of 19.2.73 (Low Voltage Directive)
and subsequent amendments.
- 87/308 of 2.6.87 (Radio Interference Suppression) and subsequent amendments.
- 89/336 EEC of 3.5.89 (Electromagnetic Compatibility Directive) and subsequent amendments.
Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of breakdown.
GREEN & YELLOW
13 AMP. FUSE
D207
BLUE
13 AMP
BROWN
CORD CLAMP
15
BUILDING-IN INSTRUCTIONS
Door reversal
To reverse the opening direction of the door, proceed as shown in the figures:
Before carrying out any work, remove the plug from the power socket.
Grid preparation
Left door opening:
Remove the left side (A) of the grid cutting it from the rear (see figure).
Right door opening:
Remove the right side (B) of the grid cutting it from the rear (see figure).
To position the grid on the appliance proceed as fol­lows:
Apply the grid to the base of the appliance by pushing on to the clasps (a) until they click.
A
B
DO002/2
a
a
DO001
4
1
5
2
1
3
6
7
8
2
16
Attention
After completion of the door reversing opera­tion, check that the door gasket adheres to the cabinet. If the ambient temperature is cold (i.e. in Winter), the gasket may not fit perfectly to the cabinet. In that case, wait for the natural fit­ting of the gasket or accelerate this process by heating up the part involved with a normal hairdryer on a low setting.
Building the appliance in under a worktop
1. The dimensions of the recessed installation area
must correspond with those indicated in the figure.
2. Installation kit
3
10
13
9
12
11
600
DO013
1
1xA
550
min.
600
1xB
2
2
1
1
2xC
12
2
2/a
17
3. Two cabinet securing brackets are supplied with the installation pack. They need to be assembled onto the cabinet prior to cabinet being pushed into the Kitchen aperture.
- To fit these brackets remove the two screws at the
top left and right hand front corners of the cabinet.
- Position the two brackets as shown in the figure
and replace the two securing screws.
N.B. The joint cover (B) is to be assembled after hav-
ing installed the appliance in the recess.
596
555 max
Li89
+
-
4. Push the appliance into place. The plug socket necessary for connection of the appliance to the electricity supply should be positioned, so that the plug is not placed in the recess.
5. To adjust the height proceed as follows:
- Loosen or tighten the two front feet.
- The rear feet are adjusted by turning the screw in
the front kick plate to the left or right.
6. If necessary, pads are supplied for the rear feet to make sliding the appliance in and out of the recess easier. To fit the pads, press them onto the rear feet.
If required, the dimensions of these pads can be reduced by breaking them where marked.
2
Left hand bracket
Right hand bracket
1/a
2
1
II52
3
B
115°
4
18
7. Screw appliance into place and retain the cabinet with screws through the securing brackets into the worktop or adjacent woodwork as necessary.
8. To mount the furniture door proceed as shown in the figures:
5
2
1
10
a
C
4
3
b
6
ab
C
clic
C
clic
7
8
c
19
UPPER PART OF KITCHEN FURNITURE PANEL
LOWER PART OF KITCHEN FURNITURE PANEL
12
1
a
=
=
2
275 275
max 100
9
b
9/a
10
45
°
1
2
=
3
10
=
11
20
Fitting the plinth
Important
For the efficient operation of the appliance, it is important that the original ventilation grid is used.
¥ For an opening height dimension A=820 mm and a
plinth height dimension a=100 mm, the plinth may be fitted without adjustments. The same applies to an opening height dimension B=870 mm and a plinth height dimension b=150 mm.
¥ For plinth heights greater than a=100 mm,
b=150 mm, a cut should be made in the plinth, 580 mm wide, in the centre of the appliance posi­tion, leaving a remaining height of a=100 mm, b=150 mm.
¥ Attach plinth to the kitchen units.
Important
The plinth must be positioned at a minimun dis­tance of 25 mm from the door.
9. Refit the covering strip.
A
13
DO008
A = 820
B = 870
25
25 - 80
580
a = 100
b = 150
© Electrolux Household Appliances Limited 2003
ELECTROLUX HOME PRODUCTS OPERATIONS EUROPE
922 822 666 / 922 822 667
Loading...
