A/E/3-2. (04.)200362936
ER 5763 C
REFRIGERATOR
INSTRUCTION BOOK
2
This instruction book contains safety precautions, information on use and helpful hints and tips.
To ensure you see this appliance effectively and safely, please read this instruction book carefully
before installing or using this appliance and retain for future reference.
The symbols below help you to find things more easily:
Safety precautions
Warnings and Safety information
Hints, useful information
Environmental information
The Electrolux Group. The world's No.1 choice.
The Electrolux Group is the world's largest producer of powered appliances for kifchen, cleaning and outdoor use. More than 55 million Electrolux Group
products (such as refrigerations, cookers, washing machines, vaccum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
USD 14 billion in more than 150 countries around the world.
Child Safety
Do not allow children to tamper with the controls
or play with the product.
There is a risk of suffocation! Keep packaging
material away from children!
During Use
This appliance is designed for domestic use
only, specifically for the storage of edible
foodstuffs. It is not intended for commercial or
industrial use.
Maintenance and Cleaning
Before cleaning, always switch off the appliance
and disconnect from the electrical supply.
When unplugging always pull the plug from the
mains socket, do not pull on the cable.
Servicing
This product should be serviced by an
authorised engineer and only genuine spare
parts should be used.
Under no circumstances should you attempt to
repair the appliance yourself. Repairs carried out
by inexperienced persons may cause injury or
serious malfunctioning. Contact Expert
Appliance Care.
At the end of the Appliance Life
When disposing of your appliance use an
authorised disposal site.
Remove the plug and ensure that any locks or
catches are removed, to prevent young children
being trapped inside.
The Appliance and the Environment
This appliance does not contain gasses which
could damage the ozone layer.
Avoid damaging the cooling unit.
The packaging used on this appliance marked with
the symbol is recyclable.
Keep this instruction book for future
reference and ensure it is passed on to any
new owner.
3
IMPOR
IMPORTT
ANT S
ANT S
AFET
AFET
Y INS
Y INS
TR
TR
UCTIONS
UCTIONS
These warnings are provided in the interests of your safety. Ensure that you understand them all
before installing or using this appliance. Your safety is of paramount importance. If you are unsure
about any of the meanings or these warnings contact the Customer Care Department.
Prior to installation
Check the appliance for transport damage. Under
no circumstances should a damaged appliance be
installed. In the event of damage please contact
your retailer.
Installation
This appliance is heavy. Care should be taken when
moving it.
It is dangerous to alter the specifications or attempt
to modify this product in any way.
Ensure that the appliance does not stand on the
electrical supply cable. If the supply cable is
damaged, it must be replaced by a cable available
from Expert Appliance Care.
Make sure that the power plug is not squashed
or damage the back of the fridge/freezer.
- A damaged power plug may overheat and cause a
fire.
Do not place heavy articles or the
fridge/freezer itself on the power cord.
- There is a risk of a short circuit and fire.
Do not remove the power cord by pulling on its
lead, particularly when the fridge/freezer is
being pulled out of its niche.
- Damage to the cord may cause a short-circuit, fire
and/or electric shock.
- If the power cord is damaged, it must be replaced
by a certified service agent or qualified service
personnel.
If the power plug socket is loose, do not insert
the power plug.
- There is a risk of electric shock or fire.
Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
Parts which heat up should not be exposed.
Whenever possible, the back of the appliance
should be close to a wall, but leaving the required
distance for ventilation, as stated in the installation
instructions.
The appliance should be left for 2 hours after
installation before it is turned on, in order to allow
the refrigerant to settle.
4
CONTENT
CONTENTSS
Instructions for the User
Guide to use the instruction book 2
Important Safety Instructions 3
Instructions for the User 5
Description of the Appliance 5
Using the Appliance 6
Before Use 6
To Start the Appliance 6
Thermostat Control 6
Hints for storage 6
Storage Shelf 7
The Ice-making Compartment 7
Hints and Tips 7
Food Storage 7
Frozen food storage 7
Energy Saving Advice 7
Storage time chart 8
Maintenance and Cleaning 9
Internal cleaning 9
External cleaning 9
When the appliance is not in use 9
Something Not Working 10
Service and Spare Parts 10
Instructions for the Installer
Technical Data 11
Location 11
Installing the Appliance 11
Transportation, Unpacking 11
Location 11
Ventilation Requirements 12
Door Reversal 12
Electrical Connection 13
5
Ins
Instrtr
uctions f
uctions f
or the User
or the User
General information
This appliance is desiged for the refrigeration of food
in a domestic home. It also has an ice-making
compartment.
To ensure correct operation, this appliance should
be located where the ambient temperature is
between 12-32 °C
Description of the appliance
1. Ice-making compartment
2. Data plate
3. Ice tray
4. Wire shelf
5. Drip tray
6. Feet
7. Door gasket
8. Door compartment
9. Thermostat with knob
10. Condenser
11. Air circulation
12. Compressor
13. Spacer
1
2
3
4
5
10
11
9
12
6 7 8
13
6
Hints for storage
Suggested storage locations for different types of
food produce:
1. Storing frozen foods, making ice and ice-cream.
2. Confectionery, ready-cooked foods
3. Foods in dishes
4. Opened cans
5. Milk, dairy products
6. Fresh meat, cold cuts, sausages, etc.
7. Fruits, vegetables, salads
8. Cheese, butter
9. Eggs
10. Yoghurt, sour cream
11. Bottles, drinks
Using the Appliance
Before Use
Remove all securing tapes.
Wash the inside of the appliance with lukewarm water
with a little bicarbonate of soda added (5 ml to 0,5 litre
of water). Do not use soap or detergent as the smell
may linger. Dry the appliance thoroughly.
Do not use detergents, abrasive powders,
highly perfumed cleaning products, wax
polishes or products containing alcohol.
FF
To Start the Appliance
1. Allow the appliance to stand for 2 hrs after
installation.
2. Plug in the appliance and switch on at the mains
supply.
3. Turn the thermostat control knob to the required
setting. A setting of 4 is usually suitable for normal
operation (see thermostat control).
4. Leave the appliance for approximately 4 hours for
the correct temperature to be reached before
placing food inside.
Thermostat Control
The thermostat control knob situated inside the
refrigerator regulates the temperature of the
refrigerator and ice-making compartment. Thermostat
control knob is marked from 1-7 the higher the
number, the colder the setting.
Position 0 - Off
Position 1 - Cold
Position 7 - Coldest
7
Storage Shelf
The shelf inside the appliance has a flap on the
left side that makes storing large sized bottles
possible.
The door shelves taken out of appliance can be used
for serving foods (fruit, salads, etc.)
The Ice-making Compartment
This compartment is suitable for the storing of
commercially frozen food and for making and storing
ice cubes.
Hints & Tips
Food Storage
To obtain the best results from your appliance
neither hot foods nor liquids which may evaporate,
should be placed in the refrigerator.
Keep the time between buying chilled food and
placing it in your fridge as short as possible.
Do not push food together too much, try to allow air
to circulate around each item.
Do not store food uncovered.
Remove suspect food from your refrigerator and
clean, refer to Cleaning and Maintenance.
Frozen food storage
Storing ready-frozen foods is quite straightforward.
The packs can be placed beside each other or on top
of each other.
You are strongly advised to place ready-frozen food in
the compartment as quickly as possible after
purchase and we therefore recommend that you buy
them last. Also ensure that the external packaging is
intact.
Packaging which is swollen or has traces of
refrozen water droplets on the pack could indicate
that the product has not been kept at a suitable
temperature and that it may have lost its original
quality.
Partially thawed food must not be refrozen, it must
be consumed within 24 hours.
Never exceed the storage times indicated.
Do not open the ice-making compartment door too
often and do not leave open longer than necessary.
Important
In the event of a power cut the food in the icemaking compartment will not be affected if the
power cut is short and if the compartment is full. Do
not open the door. Should the food begin to thaw,
it must be consumed quickly and must not be
refrozen.
Energy Saving Advice
Do not install the cabinet close to sources of
heat, such as a cooker, dishwasher or radiator.
Locate the appliance in a cool well ventilated
room and make sure that the air openings of the
cabinet are not obstructed.
Always leave warm food to cool down to room
temperature before placing in the fridge.
Try to avoid keeping the door open for long
periods, or opening the door too frequently as
warm air will enter the cabinet, and cause the
compressor to switch on unnecessarily often.
Ensure there are no obstructions preventing the
door from closing properly.
It is advisable to periodically clean the
refrigeration system at the back of the appliance
with a duster or vacuum cleaner.
8
SSttor
or
age time char
age time chartt
Time and method of storage of fresh foods in the refrigerator
Foods Storage time in days Method of packaging
1234567
Raw meat XXx x x cling film, airtight
Cooked meat XXXx x x dish covered
Roasted meat XXXx x dish covered
Raw minced meat X dish covered
Cooked minced meat XXx x dish covered
Cold cuts XX x x cling film, cellophane, grease-
proof paper
Fresh fish X x x cling film, airtight
Cooked fish XXx x dish covered
Tinned fish, open X x x dish covered
Fresh chicken XXXx x x cling film, airtight
Fried chicken XXXx x x dish covered
Fresh duck, goose XXXx x x cling film, airtight
Roasted duck, goose XXXXx x x dish covered
Butter unopened XXXXXXXoriginal packaging
Butter opened XXxxxxxoriginal packaging
Milk XXXx x original packaging
Cream XXx x plastic box
Sour cream XXXXx x x plastic box
Cheese (hard) XXXXXXXaluminium foil
Cheese (soft) XXXX x x x cling film
Egg XXXXXXX
Spinach, sorrel XXx x cling film
Green peas, green beans XXXXx x x cling film
Mushroom XXx x x cling film
Carrot XXXXXXXcling film
Toma to XXXXXXXcling film
Cabbage XXXXX x x cling film
Strawberry, raspberry, etc. XXXx x cling film
Tinned fruits opened XXXx x dish covered
Cakes filled with cream XXx x dish covered
Notation:
X recommended storage time
x maximum recommended storage time
9
Maint
Maint
enance & Cleaning
enance & Cleaning
Before any maintenance of cleaning work is
carried out DISCONNECT the appliance from
the ELECTRICITY SUPPLY.
Internal Cleaning
Clean the inside and accessories with warm water and
bicarbonate of soda (5 ml to 0.5 litre of water). Rinse
and dry thoroughly.
NEVER use detergents, abrasive powders,
highly perfumed cleaning products or wax
polishes to clean the interior as these will
damage the surface and leave a strong
odour.
External Cleaning
Wash the outer cabinet with warm soapy water.
When the appliance is not in use
When the appliance is not in use for long periods,
disconnect from the electricity supply, empty all foods
and clean the appliance, leaving the door open to
prevent unpleasant smells.
Defrosting
While the appliance is in operation the ice-making
compartment becomes progressively covered with
frost.
This frost, acts as an insulator and prevents the
cold from reaching the insulator food. The frost
should be removed whenever the thickness of the
frost exceeds 1/4. To carry out complete
defrosting proceed as follows.
Pull out the plug from the wall socket or turn the
thermostat control knob to the '0' position.
Leave the fridge and ice-making compartment
doors open, when defrosting is completed, dry the
appliance thoroughly. Remove any defrost water
collected in the tray.
Replace the plug in the socket or return the
thermostat to the initial position and, after letting
the appliance run for at least an hour, place the
food in the refrigerator.
10
Problem
No power to the
appliance
The temperature in the
appliance is too high
The temperature in the
appliance is too low
Excessive frost and ice
has built up
The appliance is noisy.
Possible Cause
No power at the socket.
There is a power cut.
The fuse has blown.
Thermostat control is set at 0.
The appliance is located in an unsuitable position.
The thermostat control is set too low.
The thermostat control is set too high.
The door has been left open.
Something is obstructing the door.
The door gasket is dirty.
The appliance is not level.
Solution
Check there is power at the socket.
Check there is not a power cut by checking the
household lights.
Check the fuse has not blown.
Check the thermostat setting.
Check the ambient temperature is within the
appliances operating limits of 12 °C to 32 °C.
Check that the thermostat control knob is turned
to the correct setting relative to ambient
conditions.
Set the thermostat control knob to a lower
position.
Check the door has not been left open.
Check nothing is preventing the door from closing.
Check the door gasket is intact and clean.
Check if the appliance stands stable (all four feet
should be on the floor).
Some
Some
thing N
thing Noo
t W
t W
or
or
king
king
If the appliance is not working correctly, please carry out the following checks before contacting
Expert Appliance Care.
If after the above checks your appliance still does not
operate correctly, contact Expert Appliance Care.
Please note that it will be necessary to provide proof
of purchase for any in-guarantee service calls.
In-guarantee customers should ensure that the
above checks have been made, as the
engineer will make a charge if the fault is not a
mechanical or electrical breakdown.
Ser
Ser
vice and Spar
vice and Spar
e P
e P
ar
ar
ts
ts
If you require further information regarding the appliance, the terms and conditions of the guarantee, or wish
to call out engineer, please contact Expert Appliance Care by telephoning:
0870 9099100
11
Ins
Instrtr
uctions f
uctions f
or the Ins
or the Instt
aller
aller
Technical data
ER 5763 C
Ice-making comp.: 5
Fresh food comp.: 65
Ice-making comp.: 5
Fresh food comp.: 62
525
520
587
0,42
153
B
55
24
Model
Gross capacity (l)
Net capacity (l)
Width (mm)
Height (mm)
Depth (mm)
Energy consumption (kWh/24h)
(kWh/year)
Energy class, according to EU standards
Rated power (W)
Weight (kg)
Installing the appliance
Transportation, unpacking
The appliance and the interior fitting are protected
for transport.
Remove all packaging and any adhesive tape.
Any remnants of adhesive can be removed using
white spirit.
After transportation the appliance must not be
switched on for 2 hours. This is to allow the
refrigerant to settle.
Cleaning
Clean the accessories and the inside of the
appliance with warm water and bicarbonate of soda
(5 ml to 0.5 litres of water). Rinse and dry
thoroughly.
Do not use detergents, abrasive powders, highly
perfumed cleaning products, wax polishes or
cleaning products containing bleach or alcohol.
Location
The appliance should be positioned in a well
ventilated, dry room.
Energy use is affected by the ambient temperature.
The appliance should therefore:
not be installed next to radiators, cookers or other
sources of heat
only be installed at a location where the ambient
temperature corresponds to the climate
classification, for which the appliance is designed.
The climate classification can be found on the data
plate.
The following table shows which ambient temperature
is correct for each climate classification:
Climate Classification Ambient Temperature
SN +10 to +32 °C
N +16 to +32 °C
ST +18 to +38 °C
12
Ventilation Requirements
The appliance must have adequate ventilation to
ensure correct operation.
Diagram shows the ventilation requirements when
installed:
A* Under a worktop, or cupboard.
* The clearance space of 10 cm above the appliance
may be reduced to 5 cm providing a clearance
space 2.5 cm is left on either side of the appliance.
B When freestanding
Door Reversal
If required the opening direction of the door can be
changed as follows:
To reverse the bottom hinge assembly proceed as
follows:
Disconnect the appliance from the electricity
supply.
Remove the top hinge cover.
Unscrew the 2 retaining screws, and remove the
hinge from the appliance.
Take the door off.
Unscrew the lower hinge retaining screws, and
remove the hinge according to the diagram.
Fit the lower hinge on the opposite side.
Fix the door onto the lower hinge pin.
To fit top door hinge, remove the plastic blanking
plugs carefully, and refit them in the holes left by the
hinge retaining screws.
Refit the top hinge using the 2 retaining screws,
taking care that the edge of the door is parallel with
side of the cabinet.
Replace the hinge cover.
Remove screw covers (if fitted) and handle retaining
screws. Remove blanking plugs on the opposite
side
using a punch
.
Relocate the handle to the opposite side and refit
retaining screws (covers if fitted), and
push the
plastic plugs supplied with the instruction book into
the holes where the handle was previously fitted
.
13
Electrical connection
Any electrical work required to install this
appliance should be carried out by a
qualified electrician or competent person.
This appliance must be earthed.
The manufacturer declines any liability should
these safety measures not be observed.
Electrical Requirements
Before switching on, make sure the electricity supply
voltage is the same as that indicated on the appliance
rating plate.
The appliance is supplied with a 13 amp plug fitted. In
the event of having to change the fuse in the plug
supplied, a 13 amp ASTA approved (BS 1362) fuse
must be used. Should the plug need to be replaced
for any reason. The wires in the mains lead are
coloured in accordance with the following code:
Green and Yellow: Earth
Blue: Neutral
Brown: Live
The wire coloured green and yellow must be
connected to the terminal marked with the letter E or
by the earth symbol or coloured green and yellow.
The wire coloured blue must be connected to the
terminal N or coloured black.
The wire coloured brown must be connected to the
terminal marked L or coloured red.
Upon completion there must be no cut, or stray
strands of wire present and the cord clamp must be
secure over the outer sheath.
This appliance complies with the following
E.E.C. Directives:
73/23 EEC of 19.02.73 (Low Voltage Directive)
and subsequent modifications,
89/336 EEC of 03.05.89 (Electromagnetic
Compatibility Directive) and subsequent
modifications.
2004. 03. 28.Printed by Xerox Hungary Ltd.
The Electrolux Group. The worlds No.1 choice.
The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux
Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of
approx. USD 14 billion in more than 150 countries around the world.
ELECTROLUX HOME PRODUCTS OPERATIONS EUROPE
© Electrolux plc 2003
Loading...
