Specifications and Main Features
- Model: EOB811
- Type: Built-In Oven
- Electrical Connection: 230/240 V, 50 Hz
- Required Protection Fuse: 13 Amps
- Total Electrical Power: 3000 W / 3200 W
- Oven Power : 2000 W (230 V)
- Grilling Power: 2900 W (230 V)
- Oven Lighting: 25 W (230 V)
- Type of Cleaning: Clean enamel (manual)
- Dimensions:
- Height: 580 mm
- Width: 540 mm
- Depth: 546 mm
- Internal volume: 561 liters
- nett weight: 26.5 kg
- Cooking levels: Five levels (physic 1- 5 counting from lower end)
- Included Accessories:
- 2 anti-tip wire shelvings
- 1 grill pan with grid and handles
- Optional Extras: Cool door kit (white and brown models available)
Frequently Asked Questions
- Q: What is the power supply requirement for the EOB811 oven?
A: It needs to be supplied by a power supply of 230/240 V, 50 Hz.
- Q: How many cooking levels does the oven have?
A: The oven has five cooking levels which are numbered from 1 to 5.
- Q: What is this oven's maximum consumption of electricity?
A: The maximum consumption of electrical power is 3000 W / 3200 W.
- Q: Is it possible to clean the oven using steam and high-pressure cleaning units?
A: Negative, steam and high pressure cleaning units are not allowed in cleaning the oven in accordance with electrical safety regulations.
- Q: What is the purchased equipment supplied with the oven?
A: This type of oven is supplied with 2 anti tip wire shelves and 1 grill pan with grid, handles.
- Q: Where can the rating plate be located?
A: The rating label is located on the lower front frame of the case of the oven and is visible when the door is opened.
- Q: What cleaning methods are applied to this oven?
A: The oven shall be manually cleaned with a damp soft cloth with suitable detergents.
