AEG-Electrolux EOB6740X, EOB6740X-X User Manual

Electric built-in oven

INSTRINSTR

INSTR

INSTRINSTR

UCTION BOOKLETUCTION BOOKLET

UCTION BOOKLET

UCTION BOOKLETUCTION BOOKLET

35690-4501

Model EOB 6740

Important Safety Information

It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred, always ensure that the book is left with the appliance in order that the new owner can get to know the functions of the appliance and the relevant warnings. These warnings are provided in the interest of safety. You MUST read them carefully before installing or using the appliance.

Installation

• This oven is heavy and care must be taken when moving it.

• Ensure that all packaging, both inside and outside the oven, has been removed before the oven is used.

• The oven must be installed according to the instructions supplied. Any electrical work must be undertaken by a qualified electrician.

• It is dangerous to alter the specifications in any way.

• After installation, please dispose of the packaging with due regard to safety and the environment.

Child Safety

• The appliance is not intended for use by young children or infirm persons without supervision. Young children must not be allowed to tamper with the controls or play near or with the oven.

• Ovens become very hot, and retain their heat for a long period of time after use. Children should be kept well away from the oven until it has cooled.

• CAUTION - accessible parts will become hot when in use. To avoid burns and scalds children should be

kept away.

During Operation

• This oven has been designed for cooking edible foodstuffs only and must not be used any other purposes.

• Do not use this oven if it is in contact with water and never operate it with wet hands.

• Ensure that the oven shelves are installed in the correct way.

• Appliances become very hot with use, and retain their heat for long periods after use. Care should be taken to avoid touching heating elements inside the oven.

• Take great care when heating fats and oils as they will ignite if they become too hot.

• Never place plastic or any other material which may melt in or on the oven.

• Only clean this oven in accordance with the instructions.

• Take care to follow the recommendations given for tending the food when grilling. Use the handles provided in the recommended way.

• Always grill with the oven door closed.

• Always use oven gloves to remove and replace food in the oven.

• Ensure that you support the grill pan when removing it from the oven.

• Never line any part of the oven with aluminium foil.

• Do not allow heatproof cooking material, e.g. roasting bags, to come into contact with oven elements.

• Always stand back from the oven when opening the oven door, to allow any build-up of steam or heat to release.

• Stand clear when opening the side swing oven door.

• Do not allow it to fall open - support it using the door handle, until it is fully open.

• Do not place sealed cans or aerosols inside the oven. They may explode if they are heated.

• Do not hang towels or clothes from the oven or its handle. They are a safety hazard.

After Use

• Ensure that all control knobs are in the OFF position when not in use.

• For hygiene and safety reasons, this oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan.

• Only clean this oven in accordance with the instructions.

• Never use steam or high pressure steam cleaners to clean the appliance.

• Always allow the oven to cool down before switching off at the wall prior to carrying out any cleaning or maintenance work.

• Do not leave utensils containing foodstuffs, e.g. fat or oil in or on the oven in case it is inadvertently switched ON.

• Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Refer to your local Service Centre. Always insist on genuine spare parts.

Environmental Information

• After installation, please dispose of the packaging with due regard to safety and the environment.

• When disposing of an old appliance, make it unusable, by cutting off the cable. Remove any door catches, to prevent small children being trapped inside.

The symbol on the product or on its packaging indicates that this product may not be treated as

household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

Contents

For the User For the Installer

Important Safety Information 2

Description of the Oven 4

Controls 5

Before the First Use 6

Shelf supports 6

Electronic Programmer 7

Using the Oven 9

Hints and Tips 10

Using the Conventional Oven 11

Using the Fan Oven 12

Cooking chart-Conventional and Fan Oven 13

Grilling 14

Defrosting 16

Cleaning the Oven 17

Something not Working 22

Installation 23

Technical data 23

Electrical Connection 24

Building In 25

Guide to use the instructions

The following symbols will be found in the text to guide you throughout the Instructions:

Safety Instructions

Step by step instructions for an operation

Hints and Tips

Environmental information

This appliance complies with the following E.E.C.

Directives: *73/23 - 90/683 (Low VoltageDirective); *93/68 (General Directives); *89/336 (Electromagnetical Compatibility Directive)

and subsequent modifications.

Your safety is of paramount importance. Therefore, if you are unsure about any of the meanings of these WARNINGS, contact the Customer Care Department.

Description of the Oven

65 2

Oven accessories

Grill/roasting

pan

1. Control panel

2. Oven Function Control Knob

3. Electronic Programmer

4. Thermostat Control Knob

5. Mains on Light

6. Thermostat Control Light

Grill trivet

7. Air Vents for Cooling Fan

8. Grill

9. Oven Light

10.Oven Fan

11. Rating Plate

Anti-tip shelf (x 2)

Baking tray

Controls

Oven Function Control Knob

The oven is off.

Oven light - The oven light will be on without

any cooking function.

Conventional cooking - The heat comes

from both the top and bottom element, ensuring even heating inside the oven.

Top heating element - The heat comes from

the top element only (outer section).

Bottom heating element - The heat comes

from the bottom of the oven only.

Inner grill element only - Can be used for

grilling small quantities.

Full Grill - The full grill element will be on.

Thermal Grilling - This function offers an al-

ternative method of cooking food items, normally associated with conventional grilling. The grill element and the oven fan operate alternately, circulating hot air around the food.

When using the thermal grill cooking function, select a maximum temperature of 200°C.

Fan cooking - This allows you to roast or roast

and bake simoultaneously using any shelf, without flavour transference.

Defrost Setting - This setting is intended to

assist in thawing of frozen food.

Mains on Light

The mains on light will come on when the oven function control knob is set.

Thermostat Control Knob

Turn the thermostat control knob clockwise to select temperatures between 50°C and 230°C (MAX).

Thermostat Control Light

The thermostat control light will come on when the thermostat control knob is turned. The light will remain on until the correct temperature is reached. It will then cycle on and off to show the temperature is being maintained.

The Safety Thermostat

This oven is provided with a safety thermostat. In case of malfunctioning of the main thermostat, and consequent over-heating, the safety device will stop the power supply to the appliance. If this happens, call your local Service Force Centre. Under no circumstances should you attempt to repair the appliance yourself.

The cooling fan

The cooling fan operates during cooking. Air is expelled through vents between the oven door and the control panel, as shown in the diagram. The cooling fan may run on after the oven is switched off to keep the controls cool. This is quite normal.

Before the First Use

Before using the appliance, remove all packaging, both inside and outside the appliance,

including the advertising labels and any protective film.

Before first use, the oven should be heated without food. During this time, an unpleasant odour may be emitted. This is quite normal.

Ensure the room is well ventilated.

The oven will work only if the time of day has been set (see the relevant instructions).

1. Set the time of day with the electronic programmer

(see chapter "Electronic Programmer").

2. Switch the oven function control knob to fan

cooking function .

3. Set the thermostat control knob to MAX.

4. Open a window for ventilation.

5. Allow the oven to run empty for approximately 45 minutes.

This procedure should be repeated with the full grill

cooking function for approximately 5-10 minutes.

Electronic Programmer

1. Push button for selecting a function

5 6

2. Decreasing control button “ ”

3. Increasing control button “ ”

4. Display

5. “Cooking Duration” pilot lamp

6. “End of cooking” pilot lamp

123

The oven will work only if the time of day has been set.

However, the oven can also be operated without any programme.

7. “Minute minder” pilot lamp

8. “Time of day” pilot lamp

Setting the time of day

When the power supply is switched on, or after a power failure, the “Time of day” pilot lamp will flash on the display.

To set the correct time of day:

1. Press button “ ” or “ ”.

2. After the setting is carried out, wait for 5 seconds: the “Time of day” pilot

lamp will go out and the display will show the set time. The appliance is ready for use.

To reset the correct time of day:

1. Press button repeatedly to select the “Time of day” function. The

relevant pilot lamp will start flashing. Then proceed as described above. The time of day can only be reset if no automatic function (cook duration

or end of cooking ) has been set.

“Cooking Duration” function

This function allows the oven to automatically switch off at the end of a programmed cooking duration time. Place food in the oven, select a cooking function and adjust the cooking temperature. Press button repeatedly to select the “Cooking Duration” function. The relevant pilot lamp will start flashing. Then, proceed as follows:

To set the duration time:

1. Press button “ ” or “ ”.

2. After the setting is carried out, wait for 5 seconds: the "Cooking Duration"

pilot lamp will come on and the display will revert to the time of day.

3. When cooking time is over, the oven will be switched off automatically and an acoustic alarm will be heard, while the pilot lamp will start flashing. Turn the oven function and the thermostat control knob to zero. To switch off the acoustic alarm, press any button. NOTE: turning the acoustic alarm off will reset the oven to manual, and if the oven function and the thermostat knobs are not set to zero the oven will start to heat again.

To cancel the duration time:

1. Press button repeatedly to select the “Cooking Duration” function.

The relevant pilot lamp will flash and the display will show the remaining cooking time.

2. Press button “ ” until the display shows “0:00”. After 5 seconds the pilot lamp will go out and the display will revert to the time of day.

“End of cooking” function

With this function, you can set the oven to switch off automatically when a programmed end of cooking time is over. Place food in the oven, select a cooking function and adjust the cooking temperature. Press button repeatedly to select the “End of cooking” function. The relevant pilot lamp proceed as follows:

To set the End of cooking time:

1. Press button “ ” or “ ”.

2. After the setting is carried out, wait for 5 seconds: the “End of cooking” pilot

lamp will come on and the display will revert to the time of day.

To cancel the End of cooking time:

1. Press button

relevant pilot lamp will flash and the display will show the programmed End of cooking time.

2. Press button “ ” until the display shows the current time of day. The programmer will beep and the pilot lamp will go out.

repeatedly to select the “End of cooking” function. The

will start flashing. Then,

“Cooking duration” and “End of cooking time” combined

The functions “Cooking duration” and “End of cooking time” can be used

simultaneously to set the oven to switch on and off automatically at a later time.

1. With the “Cooking duration” function (carry out the cooking duration setting as described in the relevant chapter) set the duration time. Then, press button

: the display will show the programmed setting.

2. With the “End of cooking time” function (carry out the End of cooking setting as described in the relevant chapter) set the end of cooking time. The relevant pilot lamps will come on and the display will show the time of day. The oven will switch on and off according to the set programmes.

“Minute minder” function

The minute minder alarm will sound at the end of a timed period, but THE OVEN WILL REMAIN ON, if it is in use.

To set the minute minder:

1. Press button repeatedly to select the “Minute minder” function. The relevant

pilot lamp will start flashing.

2. Then, press button “ ” or “ ” (maximum: 2 hours, 30 minutes).

3. After the setting is carried out, wait for 5 seconds: the “Minute minder” pilot

lamp will come on.

4. At the end of the timed period, the pilot lamp will start flashing and an acoustic alarm will be heard. To switch off the acoustic alarm, press any button.

To cancel the minute minder:

1. Press button repeatedly to select the “Minute minder” function. The relevant

pilot lamp will flash and the display will show the remaining time.

2. Press button “ ” until the display shows “0:00”. After 5 seconds the pilot lamp will go out and the display will revert to the time of day.

How to switch off the display

1. Press two or three programmer push buttons simoultaneously and keep

them pressed for about 5 seconds. The display will switch off.

2. To switch on the display, press any button.

The display can be switched off only if no other functions have been set.

Using the Oven

Always cook with the oven door closed.

Stand clear when opening the side swing oven door.

The oven has four shelf levels, and is supplied with two shelves. The shelf positions are counted from the bottom of the oven as shown in the diagram.

It is important that these shelves are correctly positioned.

Do not place cookware directly on the oven base.

Attention! - Do not place objects on the oven base

and do not cover any part of the oven with aluminium foil while cooking, as this could cause a heat build-up which would affect the baking results and damage the oven enamel. Always place pans, heat-resisting pans and aluminium trays on the shelf which has been inserted in the shelf runners.

To open the oven door, always catch the handle in its central part.
