C e r a m i c G l a s s I n d u c t i o n H o b
Installation and Operating
Instructions
EHD 8690 P
822 930 055-B-310806-02 |
g |
Dear Customer,
Please read these user instructions carefully and keep them to refer to later. Please pass the user instructions on to any future owner of the appliance.
The following symbols are used in the text:
1 Safety instructions
Warning! Information that affects your personal safety. Important! Information that prevents damage to the appliance.
3 Useful tips and hints
2 Environmental information
2
Contents |
|
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4 |
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4 |
Description of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
Cooking surface layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
Control panel layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
Touch Control sensor fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Operating the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Switching the appliance on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Setting the heat setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Using the automatic warm-up function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Locking/unlocking the control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
10 |
Using the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
11 |
Switching the power function on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
12 |
Using the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
13 |
Safety cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
16 |
Tips on Cooking and Frying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
17 |
Cookware for induction cooking zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
17 |
Tips on energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
18 |
Examples of cooking applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
Cleaning and Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
20 |
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
21 |
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
23 |
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
24 |
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
25 |
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26 |
Rating Plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29 |
Warranty conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
30 |
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
35 |
3
Operating Instructions
1 Safety instructions
3 Please comply with these instructions. If you do not, any damage resulting is not covered by the warranty.
5 This appliance conforms with the following EU Directives:
–73/23/EEC dated 19.02.1973 Low Voltage Directive
–89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Directive 92/31/EEC
–93/68/EEC dated 22.07.1993 CE Marking Directive
Correct use
•This appliance should be used only for normal domestic cooking and frying of food.
•The appliance must not be used as a work surface or as a storage surface.
•Additions or modifications to the appliance are not permitted.
•Do not place or store flammable liquids, highly inflammable materials or fusible objects (e.g. plastic film, plastic, aluminium) on or near the appliance.
Children’s safety
•The cooking zones will become hot when you cook. Therefore, always keep small children away from the appliance.
For Australia:
•The appliance is not intended for use by young children or infirm persons without supervision.
•Young children should be supervised to ensure that they do not play with the appliance.
•To avoid small children and pets unintentionally switching the appliance on, we recommend activation of the child safety device.
General safety
•The appliance may only be installed and connected by trained, registered service engineers.
•Built-in appliances may only be used after they have built in to suitable built-in units and work surfaces that meet standards.
•In the event of faults with the appliance or damage to the glass ceramic (cracks, scratches or splits), the appliance must be switched off and dis-
4
connected from the electrical supply, to prevent the possibility of an electric shock.
•Repairs to the appliance must only be carried out by trained registered service engineers.
Safety during use
•Remove stickers and film from the glass ceramic.
•There is the risk of burns from the appliance if used carelessly.
•Cables from electrical appliances must not touch the hot surface of the appliance or hot cookware.
•Overheated fats and oils can ignite quickly. When cooking with fat or oil (e.g. chips) do not leave the appliance unattended.
•Switch the cooking zones off after each use.
•Users with implanted pacemakers should keep their upper body at least 30 cm from induction cooking zones that are switched on.
•Risk of burns! Do not place objects made of metal, such as knives, forks, spoons and saucepan lids on the cooking surface, as they can get hot.
Safety when cleaning
•For cleaning, the appliance must be switched off and cooled down.
•For safety reasons, the cleaning of the appliance with steam jet or highpressure cleaning equipment is not permitted.
How to avoid damage to the appliance
•The glass ceramic can be damaged by objects falling onto it.
•The edge of the glass ceramic can be damaged by being knocked by the cookware.
•Cookware made of cast iron, cast aluminium or with damaged bottoms can scratch the glass ceramic if pushed across the surface.
•Objects that melt and things that boil over can burn onto the glass ceramic and should be removed straightaway.
•Do not use the cooking zones with empty cookware or without cookware.
•To avoid damaging cookware and glass ceramics, do not allow saucepans or frying pans to boil dry.
•The ventilation gap of 5mm between the worktop and front of the unit underneath it must not be covered.
5
Description of the Appliance
Cooking surface layout
Induction cooking zone 1850 W with power function 2500 W
Induction cooking zone 1400 W with power function 1800 W
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Induction cooking zone |
|
2300 W |
Control |
|
panel |
|
|
|
|||
|
|
|
Induction cooking zone 1850 W |
||||||||
with power function 3700 W |
|
|
|
|
with power function 2500 W |
Control panel layout
Heat setting selection |
Cooking zone indicators |
Power function |
Timer function |
|
Timer display |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
On/Off |
Display |
|
|
Lock |
||
with power indicator |
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Timer |
6
Touch Control sensor fields
The appliance is operated using Touch Control sensor fields. Functions are controlled by touching sensor fields and confirmed by displays and acoustic signals.
Touch the sensor fields from above, without covering other sensor fields.
|
Sensor field |
Function |
|
|
|
|
On / Off |
To switch the appliance on and off |
|
|
|
|
Increase settings |
Increasing heat setting/time |
|
|
|
|
Decrease settings |
Decreasing heat setting/time |
|
|
|
|
Timer |
Timer selection |
|
|
|
|
Lock |
Locking/unlocking the control panel |
|
|
|
|
Power |
Switching the power function on |
|
|
and off |
|
|
|
1 Warning! Risk of burns from heat emitted. Lengthy cooking on higher settings with larger cookware on the front cooking zones can heat the sensor fields. Take care when touching sensor fields.
Displays
|
Display |
Description |
|
|
|
|
|
Cooking zone is switched off |
|
|
|
|
Keep warm setting |
Keep warm setting is set |
|
|
|
- |
Heat settings |
Heat setting is set |
|
|
|
|
Automatic warm up func- |
Automatic warm-up function is acti- |
|
tion |
vated |
|
|
|
|
Fault |
Malfunction has occurred |
|
|
|
|
Pan detection |
Cookware is unsuitable or too small |
|
|
or no cookware has been placed on |
|
|
the cooking zone |
|
|
|
|
Residual heat |
Cooking zone is still hot |
|
|
|
|
Child safety device |
Lock/child safety device is engaged |
|
|
|
|
Power |
Power function is switched on |
|
|
|
|
Safety cut-out |
Safety cut-out has been activated |
|
|
|
7
Residual heat indicator
1 Warning! Risk of burns from residual heat. After being switched off, the cooking zones need some time to cool down. Look at the residual heat indicator .
3 Residual heat can be used for melting and keeping food warm.
The induction cooking zones create the heat required for cooking directly in the base of the cookware. The glass ceramic is merely heated by the residual heat of the cookware.
The cooling fan switches itself on and off depending upon the temperature of the electronics.
Operating the appliance
3 Use the induction cooking zones with suitable cookware.
Switching the appliance on and off
|
Control panel |
Display |
Pilot light |
|
|
|
|
|
|
Switch on |
Touch |
for 2 seconds |
/ |
lights up |
|
|
|
|
|
Switch off |
Touch |
for 1 second |
/ none |
goes out |
|
|
|
|
|
3 After switching on, within approx. 10 seconds a heat setting or a function must be set, otherwise the appliance automatically switches itself off.
Setting the heat setting
|
Control panel |
|
Display |
|
|
|
|
|
|
|
|
Increase |
Touch |
|
|
to |
/ |
|
|
|
|
|
|
Decrease |
Touch |
|
|
to |
|
|
|
|
|
|
|
Switch off |
Touch |
and |
at the same time |
|
|
|
|
|
|
|
|
3 The keep warm setting lies between and . It is used to keep food warm.
8
Using the automatic warm-up function
All cooking zones are equipped with an automatic warm-up function. The automatic warm-up function sets the cooking zone to the highest setting for a certain period of time and then automatically switches back to the cooking setting that was originally set.
Step |
Control panel |
Display |
|
|
|
1. |
Setting the maximum setting |
/ |
|
|
|
2. |
Place to one side for a moment |
/ |
|
|
|
3. |
touch |
|
|
|
|
4. |
touch in order to set the desired |
until / |
|
cooking setting |
after 3 seconds |
|
|
|
3 If during the automatic warm up a higher heat setting is selected, e.g. from to , the automatic warm up is adjusted.
The length of time that the automatic warm up function operates depends on the heat setting selected.
Heat setting |
Length of the automatic warm up |
|
[min:sec] |
|
|
v |
0:10 |
|
|
1 |
0:10 |
|
|
2 |
0:10 |
|
|
3 |
3:10 |
|
|
4 |
5:50 |
|
|
5 |
10:10 |
|
|
6 |
2:00 |
|
|
7 |
2:30 |
|
|
8 |
2:50 |
|
|
9 |
--- |
|
|
9
Locking/unlocking the control panel
The control panel, with the exception of the “On/Off” sensor field, can be locked at any time in order to prevent the settings being changed e.g. by wiping over the panel with a cloth.
|
Control panel |
Display |
|
|
|
Switch on |
Touch |
(for 3 seconds) |
|
|
|
Switch off |
Touch |
previously set heat setting |
|
|
|
3 When you switch the appliance off, the locking function is automatically switched off.
10
Using the child safety device
The child safety device prevents unintentional use of the appliance.
Setting the child safety device
Step |
|
Control panel |
Display/Signal |
|
|
|
|
1. |
Switch on the appliance |
|
|
|
(Do not set a heat setting) |
|
|
|
|
|
|
2. |
Touch |
until the signal sounds |
Acoustic signal |
|
|
|
|
3. |
Touch |
|
|
|
|
|
|
Appliance switches off. The child safety device is engaged.
Releasing the child safety device
Step |
|
Control panel |
Display/Signal |
|
|
|
|
1. |
Switch on the appliance |
|
|
|
|
|
|
2. |
Touch |
until the signal sounds |
Acoustic signal |
|
|
|
|
3.Touch
Appliance switches off. The child safety device is released.
Overriding the child safety device
The child safety device can be released in this way for a single cooking session; it remains activated afterwards.
Step |
Control panel |
Display/Signal |
|
|
|
1. |
Switch on the appliance |
|
|
|
|
2. |
Touch and at the same time |
/ acoustic signal |
|
|
|
Until the appliance is next switched off, it can used as normal.
11
