Your New Appliance
Thank you for purchasing an AEG appliance.
To enable you to use your new appliance efficiently and safely, please read
this instruction book carefully before installing or using the appliance, and
retain for future reference. Should the appliance be transferred to a new
owner please ensure this instruction book is left with the appliance in order
that the new owner can get to know the functions of the appliance and the
relevant warnings.
If you require further assistance or advice, please contact our Customer Care
Department either by letter or telephone:
Customer Care Department
AEG Domestic Appliances
55-77 High Street
Slough
SL1 1DZ
Tel: 08705 350350*
The symbol
product may not be treated as household waste. Instead it shall be handed
over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of
this product, please contact your local city office, your household waste
disposal service or the shop where you purchased the product.
on the product or on its packaging indicates that this
* calls to this number may be recorded for training purposes
2
31
Table of contents
Contents Page no
For the user
Your new appliance ...................................................................................... 2
Safety information ........................................................................................ 4
Description of the product ......................................................................... 5
Controlknobs ......................................................................................... 5
CHEC ................................................................................................... 5
Panel .................................................................................................... 5
Before use .................................................................................................... 7
Operating instructions ................................................................................ 9
Residual-Heat indicator ...................................................................... 10
CHEC-Control .................................................................................... 11
Advice and hints for using the cooking zones..................................... 15
Cleaning and maintenance ....................................................................... 17
Splashguard ........................................................................................ 17
Stainless steel surfaces ....................................................................... 18
The ceramic glass hob ........................................................................ 18
Somthing not working ............................................................................... 24
Service and spare parts ............................................................................ 26
Guarantee conditions ................................................................................ 28
30
For the installer
Installation .................................................................................................. 20
Electrical connection ................................................................................. 22
Technical data ............................................................................................. 23
Unpacking .................................................................................................. 23
How to read the operating instructions:
1... 2...Step by step
Safety information
3
Hint and tips
Environmental information
Safety information
These warnings are provided in the
interests of your safety. Ensure you
fully understand them before installing
or using the appliance. Your safety is of
paramount importance. If you are
unsure about the meaning of these
warnings contact the Customer Care
Department for assistance.
Installing
Do not install the hob if the ceramic
glass is damaged or cracked.
This hob must be installed according to
the instructions supplied. Any electrical
installation work must be undertaken
by a qualified electrician/ competent
person.
Do not alter the specifications or
attempt to modify the appliance in any
way.
During Use
The hob is intended for domestic
cooking only. It is not designed for
commercial/industrial purposes.
Ensure that all the control knobs are in
the OFF position when not in use.
Never use plastic or aluminum dishes
on the hob.
Never leave the hob unattended while
deep fat frying, or heating fats and oils.
Child Safety
Young children must not be allowed to
tamper with the hob or play with the
controls.
The hob gets hot when it is in use.
Children should be kept away until the
hob has cooled.
Maintenance and Cleaning
Only clean this hob in accordance with
the instructions given in this book.
Service
Repairs carried out by inexperienced
persons may cause injury or serious
malfunction of the appliance. Repairs
must only be carried out by a
qualified/competent person. Contact
your local AEG Service Force Centre.
Disposal
Make the hob unusable by cutting off
the cable.
Do not use the hob if it is damaged in
any way. If a fault or crack becomes
visible, disconnect the hob immediately
from the electricity supply and contact
your local AEG Service Force Centre.
Dispose of any packaging material and
old appliances at an authorised
disposal site.
4
29
Before you move please contact your
nearest Customer Care centre, listed
below, to give them details of your new
home. They will then ensure that the
local service organisation is aware of
your move and able to look after you
and your appliances.
France
Senlis +33 (0) 44 62 29 29
Description of the product
Germany
Nürnberg +49 (0) 911 323 2600
Italy
Pordenone +39 (0) 1678 47053
Sweden
Stockholm +46 (0) 8 738 79 10
UK
Slough + 44 (0) 1753 219899
Control knobs
CHEC
Control panel
Control knobs for operations
28
5
Guarantee conditions
Ceramic glass surface
The ceramic glass surface has four
cooking zones. When a zone is
turned on, it will illuminate at
various intervals depending on the
heat setting selected. Even at the
highest setting the zone is
disconnected occasionally to ensure
that the surface is not over-heated.
The glass is hard, and has been
tempered to withstand heat, cold
and temperature shocks. But like all
glass it is sensitive to impact. Do
not stand on the ceramic glass
surface.
At the front of the ceramic
glasssurface in the middle there are
four fields. Each field corresponds
to a cooking zone. When using a
zone, the field concerned will show
which CHEC function you are
using and the setting at which you
have set the zone.
Cooking zones
There are three single zones and
one double zone.
CHEC control
Information about how to use the
CHEC control function can be
found in the section entitled
“Operation instructions”. The
CHEC control function allows
electronic control of the zones.
CHEC control enables you to set
the heat with great precision, which
means that you do not have to
adjust the heat constantly. CHEC
control provides the zones with the
following functions:
Automatic disconnection of
“forgotten” zones.
AUTOMAX at all settings.
Setting of large zone on
double zones.
Child safety device on zones.
Residual heat indicator
When you switch off a zone, an
"H" in the display indicates that the
zone is still hot. The residual heat
indicator will continue to be
illuminated until the zone reaches a
temperature of approx. 80˚C.
AEG offer the following guarantee to
the first purchaser of this appliance:
1. The guarantee is valid for 12
months commencing when the
appliance is handed over to the first
retail purchaser, which must be
verified by purchase invoice or
similar documentation.
2. The guarantee covers all parts or
components which fail due to faulty
workmanship or faulty material.
The guarantee does not cover
appliances where defects or poor
performance are due to misuse,
accidental damage, neglect, faulty
installation, unauthorised
modification or attempted repair,
commercial use or failure to
observe requirements and
recommendations set out in the
instruction book.
3. Should guarantee repairs be
necessary the purchaser must
inform the nearest AEG Service
Force Centre. AEG reserves the
right to stipulate the place of repair
(i.e., the customer's home, place of
installation or AEG workshop).
4. The guarantee or free replacement
includes both labour and materials.
5. Repairs carried out under guarantee
do not extend the guarantee period
for the appliance. Parts removed
during guarantee repairs become
the property of AEG.
6. The purchaser's statutory rights are
not affected by this guarantee.
European guarantee
If you should move to another country
within Europe then your guarantee
moves with you to your new home
subject to the following qualifications:
The guarantee starts from the date you
first purchased your product.
The guarantee is for the same period
and to the same extent for labour and
parts as exists in the new country of
use for this brand or range of products.
This guarantee relates to you and
cannot be transferred to another user.
The product is installed and used in
accordance with our instructions and is
only used domestically, i.e. a normal
household.
The product is installed taking into
account regulations in your new
country.
6
27
Service & spare parts
Before use
In the event of your appliance requiring service, or if you wish to purchase spare
parts, contact your local AEG Service Force Centre by telephoning:
08705 929 929
Your call will automatically be routed to the Service Centre covering your post
code area.
In-guarantee customers should ensure that the recommended checks under the
heading "Something Not Working" have been made as the engineer will make a
charge if the fault is not a mechanical or electrical breakdown.
Please note that proof of purchase is required for in-guarantee service calls.
Help us to help you
Please determine your type of enquiry before writing or telephoning. When you
contact us we need to know:
1. Your name, address, post code and telephone number
2. Clear and concise details of the fault.
3. Date of purchase
4. The model and serial number
This information can be found on the rating plate.
Customer Care
For general enquires concerning your AEG appliance or for further information
on AEG products, please contact our Customer Care Department at the address
below or visit our website at www.aeghome.co.uk
Customer Care Department
AEG Domestic Appliances
55-77 High Street
Slough, Berkshire
SL1 1DZ
Tel 08705 350350*
*calls to this number may be recorded for training purposes
Connection of child safety
device on zones
Turn the 2 control buttons to
at the same time.
The display will show:
When you turn on a zone the display
will show:
To turn on a zone, turn the 2 control
buttons to at the same time. You
must then activate one of the zones
within 10 seconds.
The light under the symbol
in the display will disappear.
You can disconnect the child safety
device permanently as follows:
1. Turn the 2 control buttons to
and return to 0.
2. Turn one of the 2 control buttons
immediately to .
S A
F E
26
7
Protection of the glass
ceramic surface
A protective film should be applied
to the glass ceramic surface before
use. This will make it easier to
clean the surface, as well as
preventing substances from being
burnt onto the surface.
This is what to do:
1. Pour a few drops of ceramic
cleaning detergent such as
vitroclen onto a piece
of kitchen roll and rub the
detergent into the entire surface.
2. Polish the surface with a clean
cloth until it is dry.
Problems
Zones will not come on, Child
safety device has been activated.
S A
F E
Zones will not come on, Autostop
has been activated.
Solution
Turn the 2 display shows control
buttons with symbol for child safety
device to simultaneously. Then activate
one of the zones within 10 seconds.
Turn all the control display shows
buttons to 0. The zones can now be
used.
If after all these checks, your hob still does not operate correctly, contact
your local AEG Service Force Centre.
In-guarantee customers should ensure that the above checks have been made
as the engineer will make a charge if the fault is not a mechanical or
electrical breakdown.
Please note that it will be necessary to provide proof of purchase for any inguarantee service calls.
8
25
Something not working
Operating instructions
If the hob is not working correctly, please carry out the following checks before
contacting your local AEG Service Force Centre.
IMPORTANT: If you call out an engineer to a fault caused by incorrect use or
installation, a charge will be made even if the hob is under guarantee.
Sympton
The hob is not working
The fuses keep blowing
The cooking zones do not heat
sufficiently
Solution
Check that the appliance is connected
to the eletricity supply.
Check that the main house fuse has not
blown. Replace if necessary.
Contact your local AEG Service Force
Centre
The cooking utensils must match the
size of the cooking zone. Check that
the cooking utensils have level bases
by holding them against the edge of the
work top, for example. Bring a litre of
water to the boil in a saucepan with a
lid. The cooking zone should be
adjusted to the highest setting.
The boiling time on the 12 cm cooking
zone is approx. 25 min.
The boiling time on the 14 cm cooking
zone is approx. 13 min.
The boiling time on the 18 cm cooking
zone is approx. 10 min.
Switch symbols (to the left)
control for regulating the small
cooking zone at the rear
control for regulating the double
cooking zone at the front.
control for regulating the large
cooking zone at the rear
control for regulating the small
cooking zone at the front.
Regulating
The regulation of heat is step-free for all
plates on a scale from 1 to 9.
“1” Represents lowest heat
“9” Represents maximum heat.
“0” Represents “OFF”.
Double cooking zone
Small circle: When you control on the
cooking section it will always be the
small circle that is controled on. Choose
the wanted temperature.
From small to big circle (both circles
are on): Turn the button past “0”. Turn
back to the wanted temperature.
24
From big to small circle: Turn the
button back to “0”. Control on again and
choose the wanted temperature.
9
Technical data
Residual-Heat indicator
When you switch off a zone, an "H" in
the display indicates that the zone is
still hot. The residual heat indicator
will continue to be illuminated as long
as the temperature exceeds 80˚C.
Cooking zones
The control knobs are continuously
adjustable from 1 to 9 (9 is the highest
setting). There is AUTOMAX control
of all settings, enabling you to set the
setting required from the outset. Please
see the table of settings. The 14 and 18
cm zones are suitable for boiling and
preparing small and medium-sized
portions. The 21 cm zone is suitable
for frying, and for boiling and
preparing large portions. The 12 cm
zone is not suitable for boiling, but can
be used for melting, simmering and the
preparation of gravy, sauces etc. which
must not curdle.
Cell Voltage 240 V
Electrical connection
240V - 50Hz
Total wattage 6400W
Instant heat effect
Left front 12/18 cm 700/1700 W
Left Back 14 cm 1200 W
Right back 21 cm 2300 W
Right front 14 cm 1200 W
This unit is labelled to indicate
conformity with the lowvoltage directive
(73/23/EEC) and the EMC directive
(89/336/EEC).
Unpacking
Check that the hob has no faults and
is undamaged on delivery.
Transport damage
Any damage from transport which
you have not carried out yourself must
be reported to the retailer within one
week of receipt.
Serial number
You will find the serial number of the
hobs on the rating plate, which is on
the underside of the hob.
We recommned you write this number
on the cover of this instruction, so that
you have this information to in the
case of any service requirements
10
23
Electrical connection
The electrical connection may only be
performed by a qualified electrician/
competent person. The electrical
connection must be carried out in
accordance with prevailing regulations
for appliances using heavy current.
The connection must comply with any
specific requirements specified by the
local electricity supply authority.
There must be no interference with
any of the unit’s electrical parts.
The cable is mounted in the pegs as
shown.
Unscrew the cover while connecting
the cables.
A unit led directly to the power point
or the outlet rose.
More units may be connected via one
or more junction boxes.
The cable must be connected via an
external switch with a contact
separation of at least 3 mm in each
pole.
CHEC control
Autostop
If you forget to turn a cooking zone off
after use, it will be disconnected
automatically after a specific period of
time. The higher the setting, the shorter
the time before the zone is
disconnected.
Setting AUTOSTOP
1 6 hours
2 6 hours
3 5 hours
4 5 hours
5 4 hours
6 1½ hours
7 1½ hours
8 1½ hours
9 1½ hours
When the autostop function is activated
the display will show:
The zones cannot be used. Turn all the
control buttons to 0.
The zones can now be used.
Please observe these instructions,
otherwise the warranty will not
cover any damage that may occur.
Single-phase zero-earth
Cable type 6 mm² HO5VV-F, twin and
earth.
The cable outside diameter must be
between 7,5 and 10,5 mm.
22
Automax
AUTOMAX supplies the zone with full
heat for a specific period, and then
adjusts down to the setting you have
chosen. When you turn on a zone
AUTOMAX starts automatically. The
display alternates between A and the
setting chosen. The period for which
AUTOMAX is connected depends on
the setting chosen. Please see the table
of settings.
11
Recommended settings
when using AUTOMAX
The use of AUTOMAX means that the maximum power is connected for a
specific number of minutes, depending on the setting chosen. The table below
shows the length of time for which there is full power for each setting, and the
functions for which each setting is suitable.
Setting Full power time Function
1 1 minute Melting/simmering
2 3 minutes Melting/simmering
3 5 minutes Boiling
4 6.5 minutes Boiling
5 8.5 minutes Boiling
6 2.5 minutes Frying
7 3.5 minutes Frying
8 4.5 minutes Deep frying
9 N/A Deep frying
It is not necessary to attach the
reinforcement beam to the work top
surface, as it is held in place by a
specially designed moulding, which is
incorporated in the hob units flanges.
The units externally measured
length
145 mm:
Cooker hood
290 mm:
Two-zone ceramic-top electric hob
Two-burner gas hob
Grill
Fryer
Wok
580 mm:
Four-zone ceramic-top electric hob
Four-burner gas hob
12
725 mm:
Four-zone ceramic-top electric hob
Installation of a single unit
When mounting a single unit, be it a
half-or full size unit, in a
worktopsurface which is thicker than
30 mm, it is necessary to make a
special notch in both sides of the cut-
out hole, as shown in the adjacent
drawing.
The purpose of these notches is to
create space for the electrical cables.
21
Installation
Caution: In order to avoid a hazard this
appliance must be installed according to
these instructions for installation
The appliance unit can be mounted in
any type of kitchen with a work top
whose thickness is between 28 mm and
40 mm.
Clearance
The distance between the top side of the
work top and the carpentry underneath
must be at least 47 mm.
Fixing
Screw the fixing brackets out to such an
extent that they can be turned in under
the work top. Tighten the brackets on to
the work top with an ordinary
screwdriver.
Cut-out measurements
One rectangular hole is sawn out for the
appliance combination chosen.
The depth of the cut-out for any unit is:
490 mm
Length of hole = sum of all units`
externally measured length, less 20 mm.
Minimum distance
to side wall:
150 mm
Reinforcement
beams
Min. 47 mm
Minimum distance
to rear wall (nonflammable material):
50 mm
Disconnection of AUTOMAX:
If you do not wish to use AUTOMAX,
observe the following procedure:
1. Turn the control button to A
2. Then turn the control button to the
required setting.
OFF
.
Setting the large zone on the
double zones
1. Turn the control button to
The display will show:
2. Then turn the control button to the
required setting (e.g. setting 9).
If you wish to disconnect the large
zone, turn off the zone and then turn
the control button to the required
setting.
Child safety device
Connection and disconnection of the
child safety device is described in the
section entitled “Before use”.
When the child safety device is
activated the display will show:
Mounting of Reinforcement
Beams
A reinforcement Beam, with supporting
flanges at each end, is included with
each two-burner unit. For unit
combinations, a reinforcement beam
must be used between each unit.
20
13
When you turn on a zone the display
will show:
Observe the following procedure to
use a zone:
1. Turn the 2 buttons to
at the same time.
2. Use one of the zones within 10
seconds.
The light under the symbol
in the display will disappear.
You can disconnect the child safety
device permanently as follows:
1. Turn the 2 control buttons to
and return to 0.
2. Turn one of the 2 control buttons
immediately to .
S A
F E
The decorative pattern on the ceramic
surface can become scratched and
marred with use, depending upon
maintenance, but does not adversely
affect performance.
Such blemishes are not covered by the
warranty and do not affect the
operation of the hob.
Spills and melts must be removed
immediately, while the surface is still
warm, using the scraper supplied with
the unit. Especially damaging are melted
plastic, aluminum, or any foodstuff
containing sugar, including natural sugar,
as these can create permanent
“pockmarks” and craters on the ceramic
surface. After scraping polish thoroughly
with the cleaning agent supplied with the
unit.
Utensils which have been in contact with
the above-mentioned melted materials
must be cleaned throughly before used
again on the ceramic-top hob unit.
Defects in the ceramic surface which can
be related to the above are not covered
by the warranty.
Warning:
14
Aluminum foil and plastic utensils are
not to be placed on hot surfaces.
The surface may not be used for storage.
Do not stare at the heating units when
in operation.
19
Stainless steel surfaces
Clean the appliance after use with a
soft cloth well wrung out in warm
water, use a small amount of liquid
detergent for stubborn soiling.
Stainless steel parts may become straw
coloured with use, use a proprietary
stainless steel cleaner to remove this
straw discolouration.
Never use metal wool, metal sponges
or other abrasive cleaning agents.
The ceramic glass hob
Immediately scrape off stains caused
by food which has boiled over using
the scraper supplied with the hob,
spilled sugar, dishes containing sugar
(jam, juice, etc.), melted plastic and
aluminium foil while the ceramic hob
is still hot. If the ceramic hob is
allowed to cool it may become
damaged. A dirty ceramic hob
decreases the heat transfer between
cooking zones and cookware.
After use the cooking zones should be
wiped with a damp cloth with washing
up liquid. For severe soiling you can
follow these steps:
1. Remove stains etc., with the
ceramic hob scraper.
2. Make sure that the ceramic hob
has cooled down. Use a ceramic
cleaning agent, such as vitroclen.
3. Wipe the ceramic hob clean with
a damp cloth or kitchen roll.
Tough stains can be removed by
rubbing the stain hard with
kitchen roll.
4. Wipe off remaining cleaning
agent with a damp cloth.
5. Wipe with a dry cloth, if
required.
Make sure that the ceramic hob is dry
when you heat it up again. Ceramic
hobs can develop rainbow-like stripes
if heated while damp.
Advice and hints for using the
cooking zones
If you use the advice below
you will save energy and
make your cleaning tasks
easier.
Adjust the cooking zones
correctly.
for the cooking zones until the food is
brought to the boil. Then reduce the
setting as far as possible, without the
food going off the boil.
Use level saucepans. An
uneven saucepan may
increase the electricity
consumption by up to 50 per
cent. Check whether your
saucepans have level bases
by placing the item in question
upside down on a work top and
positioning a ruler on the base.
A curved base, both inwards and
outwards, will prolong the
cooking time and increase the
energy consumption
The saucepan should match
the cooking zone – or be
slightly larger. Remember
that a large saucepan can also
hold small quantities. If the
diameter of the base is too small,
the energy consumption will
increase, and any food boiling
Select the highest setting
over will burn onto the hot
cooking zone.
Saucepans with very
shiny/bright bases will
prolong the cooking time
slightly compared with
cooking utensils with
matt/dark bases.
Use a tightly fitting lid on the
saucepan. Without a lid you
use more than three times as
much electricity.
18
15
Cleaning and maintenance
Do not slide saucepans across the
surface of the hob - always lift the pan
when placing it on, or removing it
from the ceramic surface.
Wipe the bottom surface of the pots
and pans with a clean dry cloth before
placing them on the ceramic surface.
This helps to reduce cleaning and
prevents scratching the hob glass.
Wipe off spills whilst the hob is warm.
Select the highest setting for the
cooking zones until the food is brought
to the boil, then reduce the setting.
Use saucepans with an even base. An
uneven based saucepan may increase
the electricity consumption by up to
50%.
The saucepan should match the
cooking zone or be slightly larger.
For reasons of hygiene and
safety, the cooking zones
must be kept clean. Grease
stains and spilled food
generate smoke when heated,
and can even cause fire.
Splashguard
The splashguard can be removed to
make it easier to clean the surface.
What to do:
1. Hold the splashguard as shown
in the diagram.
2. Lift the splashguard straight up
3. Clean the top surface as
described in “cleaning the steel
surface”.
Be aware of the two retaining
pegs, which are sharp.
4. Replace the splashguard in
position ENSURE that it is
fitted the correct way round.
Use a tightly fitting lid on the saucepan
to reduce electricity consumption.
16
Never use hard or sharp
implements to lift off the
splashguard.
Do not wash the splashguard
in a dishwasher.
The hob must not be used
with the splashguard off.
17
Loading...
