AEG-Electrolux 63070 K-MN User Manual
63070 K-MN
User Manual
Notice d’utilisation
Gebruiksaanwijzing
Ceramic glass induction
hob
Table de cuisson
vetrocéramique à
induction
Glaskeramische
inductie-kookplaat
2
1
To ensure optimal and regular performance of your appliance please read this instruc-
Thank you for choosing one of our high-quality products.
tion manual carefully. It will enable you to navigate all processes perfectly and most ef-
To refer to this manual any time you need to, we recommend you to keep it in a safe
place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
Contents
Operating Instructions 3
Safety instructions 3
Description of the Appliance 4
Cooking surface layout 4
Control panel layout 5
Operating the appliance 6
Setting the heat setting 6
Switching the power function on and off 6
Using the child safety device 7
Automatic cut-out 7
ficiently.
Tips on Cooking and Frying 8
Cookware for induction cooking zones 8
Tips on energy saving 9
Examples of cooking applications 9
Cleaning and Care 10
What to do if … 11
Disposal 13
Installation Instructions 14
Service 15
Assembly 48
Rating Plate 51
The following symbols are used in this user information:
Warning! This must be read! Important advice for the safety of persons and information
on avoiding damage to the appliance
3 General information and advice
2 Information on environmental protection
z Dangerous voltage
3Operating Instructions
Operating Instructions
1 Safety instructions
Please comply with these instructions. If you do not, any damage resulting is not covered by the warranty.
Correct use
• This appliance is not intended for use by children or other persons whose physical,
sensory or mental capabilities or lack of experience and knowledge prevents them
from using the appliance safely without supervision or instruction by a responsible
person to ensure that they can use the appliance safely.
• Do not leave the appliance unattended during operation.
• This appliance should be used only for normal domestic cooking and frying of food.
• The appliance must not be used as a work surface or as a storage surface.
• Additions or modifications to the appliance are not permitted.
• Do not place or store flammable liquids, highly inflammable materials or fusible ob-
jects (e.g. plastic film, plastic, aluminium) on or near the appliance.
Children’s safety
• Small children must be kept away from the appliance.
• Only let bigger children work on the appliance under supervision.
• To avoid small children and pets unintentionally switching the appliance on, we rec-
ommend activation of the child safety device.
General safety
• The appliance may only be installed and connected by trained, registered service engineers.
• Built-in appliances may only be used after they have built in to suitable built-in units
and work surfaces that meet standards.
• In the event of faults with the appliance or damage to the glass ceramic (cracks,
scratches or splits), the appliance must be switched off and disconnected from the
electrical supply, to prevent the possibility of an electric shock.
• Repairs to the appliance must only be carried out by trained registered service engineers.
Safety during use
• Remove stickers and film from the glass ceramic.
• There is the risk of burns from the appliance if used carelessly.
• Cables from electrical appliances must not touch the hot surface of the appliance or
hot cookware.
• Overheated fats and oils can ignite very quickly. Warning! Fire hazard!
• Switch the cooking zones off after each use.
• Users with implanted pacemakers should keep their upper body at least 30 cm from
induction cooking zones that are switched on.
Description of the Appliance4
• Risk of burns! Do not place objects made of metal, such as knives, forks, spoons and
saucepan lids on the cooking surface, as they can get hot.
Safety when cleaning
• For cleaning, the appliance must be switched off and cooled down.
• For safety reasons, the cleaning of the appliance with steam jet or high-pressure
cleaning equipment is not permitted.
How to avoid damage to the appliance
• The glass ceramic can be damaged by objects falling onto it.
• The edge of the glass ceramic can be damaged by being knocked by the cookware.
• Cookware made of cast iron, cast aluminium or with damaged bottoms can scratch
the glass ceramic if pushed across the surface.
• Objects that melt and things that boil over can burn onto the glass ceramic and
should be removed straightaway.
• Do not use the cooking zones with empty cookware or without cookware.
• To avoid damaging cookware and glass ceramics, do not allow saucepans or frying
pans to boil dry.
• The ventilation gap of 5mm between the worktop and front of the unit underneath it
must not be covered.
Description of the Appliance
Cooking surface layout
Induction cooking zone 1400 W
with power function 2500 W
Induction cooking zone 2200 W
with power function 3700 W
Induction cooking zone 1800 W
with power function 2800 W
Induction cooking zone
1400 W
with power function
2500 W
Ring switch
with digital display
Control panel layout
5Description of the Appliance
Designation of ring switches to cooking zones
front left (1)
digital display
Displays
Cooking zone is switched off
- Heat settings Heat setting is set
Fault Malfunction has occurred
Pan detection Cookware is unsuitable or too small or no
Residual heat Cooking zone is still hot
Child safety device Child safety device is engaged
Power Power function is switched on
Automatic switch off Switch off is active.
left rear (2) right rear (3) front right (4)
Ring switch
Display Description
cookware has been placed on the cooking
zone
Residual heat indicator
1 Warning! Risk of burns from residual heat. After being switched off, the cooking zones
need some time to cool down. Look at the residual heat indicator
.
3 Residual heat can be used for melting and keeping food warm.
The induction cooking zones create the heat required for cooking directly in the base
of the cookware. The glass ceramic is merely heated by the residual heat of the cookware.
The cooling fan switches itself on and off depending upon the temperature of the electronics.
Operating the appliance6
Operating the appliance
3 Use the induction cooking zones with suitable cookware.
Setting the heat setting
Ring switch Fan level
To increase turn to the right to
To decrease turn to the left to
To switch off turn to zero /
Switching the power function on and off
The power function makes more power available to the induction cooking zones, e.g. to
bring a large quantity of water to the boil quickly.
Ring switch Display
To switch on Briefly turn to the right past the stop position
To switch off turn to the left Æ to
The power function remains activated for differing periods of time:
Cooking zone
diameter [mm]
210 10
180 10
140 4
Power Management
The cooking zones of the cooking surface have
a maximum power.
The maximum power is reached when the heat
setting 9 has been set for all cooking zones.
Two cooking zones generate a pair (see figure)
and therefore, the power management shares
the maximum available power between these
cooking zones.
When the power function is selected for one
cooking zone, the power management makes
the additional power for this cooking zone
available by reducing the power of the corresponding other cooking zone.
Power time [min]
Example: the heat setting 9 is selected on one
cooking zone. The power function is switched
on for the corresponding cooking zone. The
power function is carried out but the heat setting 9 of one of the cooking zones and the
power function for the other cooking zone of
the pair exceed the maximum power for both
at the same time. For this purpose, the power management reduces the power of the
cooking zone that switched on first from 9 to example 5 and the display of this cooking
zone changes between 9 and 5 and then stays at the current possible maximum 5. (If the
display changes between 9 and 5 or 9 and 3 or another value depends on the type of
appliance and the size of the cooking zone.).
Using the child safety device
The child safety device prevents unintentional use of the appliance.
Ring switch
To switch on Simultaneously briefly turn
ring switches 1 and 3 to
the left away from the zero
setting
To switch off Repeat the action The child safety device is switched
7Operating the appliance
appears in all 4 displays when
an attempt is made to switch on a
heat setting.
off again. Each heat setting can be
switched on as normal for each
element.
Automatic cut-out
Induction cooking zones
• When overheating occurs (e.g. if a pot has boiled dry) the cooking zone automatically
switches itself off. is shown. Before being used again, the cooking zone must be set
to .
• If unsuitable implements are used, lights up for two minutes in the display of the
cooking zone. Following this is displayed. If the setting of the ring switch is
changed while is lit, appears in the. display. Before being used again, the cooking zone must be set to .
• If one of the cooking zones is not switched off after a certain time, or if the heat setting is not modified, the relevant cooking zone switches off automatically. is displayed. Before being used again, the cooking zone must be set to .
Heat setting Switches off after
1 - 2 6 hours
3 - 4 5 hours
5 4 hours
6 - 9 1.5 hours
Tips on Cooking and Frying8
Tips on Cooking and Frying
3 Information on acrylamides
According to the latest scientific knowledge, intensive browning of food, especially in
products containing starch, can constitute a health risk due to acrylamides. Therefore
we recommend cooking at the lowest possible temperatures and not browning foods
too much.
Cookware for induction cooking zones
Cookware material
Cookware material suitable
Cast iron +
Steel, enamelled steel +
Stainless steel +*
Multi-layer pan bottom +*
Aluminium, copper, brass -
Glass, ceramic, porcelain -
3 * Cookware for induction cooking zones is labelled as suitable by the manufacturer.
Suitability test
Cookware is suitable for induction cooking, if …
• ... a little water on an induction cooking zone set to heat setting 9 is heated very
quickly.
• ... a magnet sticks to the bottom of the cookware.
Cookware base
The bottom of the cookware should be as thick and flat as possible.
Pan size
Up to a certain limit, induction cooking zones adapt themselves to the size of the bottom of the cookware automatically. However, depending on the cooking zone size, the
magnetic part of the bottom of the cookware must have a minimum diameter.
Diameter of cooking zone
[mm]
210 180
180 145
140 120
Minimum diameter of dish base [mm]
3 The cookware must be placed centrally on the cooking zone.
Tips on energy saving
2 Place cookware on the cooking zone before it is switched on.
2 If possible, always place a lid on the cookware.
Examples of cooking applications
The information in the table is for guidance only.
9Tips on Cooking and Frying
Heat
setting
The power function is suitable for heating large quantities of liquid.
Cooking-
process
0 Off position
Keeping
1
food warm
1-2
2-3
3-4
4-5 Boiling
6-7
7-8
Melting
Solidifying Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
Simmer-
ing on low
heat
Steaming
Braising
Gentle
Frying
Heavy
Frying
Boiling
Searing
9
Deep
frying
suitable for
To keep cooked foods warm as necessary Cover
Hollandaise sauce,
to melt butter, chocolate,
gelatine
To simmer rice and milk-
based dishes
To heat up ready meals
To steam vegetables, fish
to braise meat
To steam potatoes 20-60 mins.
To cook larger quantities of
food, stews and soups
To fry escalopes, veal cordon
bleu, cutlets, rissoles, sausages, liver, roux, eggs, pancakes,
doughnuts
Hash browns, loin steaks,
steaks, Flädle (pancakes for
garnishing soup)
To boil large quantities of water, to cook pasta,
to sear meat (goulash, pot roast), deep frying chips
Cooking
time
5-25 mins. Stir occasionally
Add minimum twice as
25-50 mins.
20-45 mins.
60-150 mins.
Steady frying Turn occasionally
5-15 mins.
per pan
much liquid as rice, stir
milk dishes some times
With vegetables add only
some liquid (some table-
Use only some liquid, e.g.:
3 l liquid maximum plus
Hints
spoons)
max.
¼ l water for
750 g potatoes
ingredients
Turn occasionally
Cleaning and Care10
Cleaning and Care
1 Take care! Risk of burns from residual heat.
1 Warning! Sharp objects and abrasive cleaning materials will damage the appliance.
Clean with water and washing up liquid.
1 Warning! Residues from cleaning agents will damage the appliance. Remove residues
with water and washing up liquid.
Cleaning the appliance after each use
1. Wipe the appliance with a damp cloth and a little washing up liquid.
2. Rub the appliance dry using a clean cloth.
Removing deposits
1. Place a scraper on the glass ceramic surface at an angle.
2. Remove residues by sliding the blade over the surface.
3. Wipe the appliance with a damp cloth and a little washing up liquid.
4. Rub the appliance dry using a clean cloth.
Remove
Type of dirt
sugar, food containing sugar yes ---
plastics, tin foil yes ---
limescale and water rings --- yes
fat splashes --- yes
shiny metallic discolouration --- yes
*Scrapers and cleaners for glass ceramic and stainless steel can be purchased in specialized shops
immedi-
ately
when the appliance has
cooled down
using
a scraper*
cleaner for glass ceram-
ic or stainless steel*
3 Remove stubborn residues with a cleaner for glass ceramic or stainless steel.
3 Scratches or dark stains on the glass ceramic that cannot be removed do not however
affect the functioning of the appliance.
What to do if …
Problem Possible cause Remedy
The cooking zones are not
functioning
The residual heat indicator is
not displaying anything
Display is switching between
two heat settings
lights up Unsuitable cookware Use suitable cookware
lights up Cooking zone on for more
and number are displayed Electronics fault Disconnect the appliance from
The desired heat setting is not
set
The fuse in the house’s electrical wiring (fuse box) has been
tripped.
The child safety device is
switched on.
The cooking zone was only on
for a short time and is therefore not hot
Power management is reducing the power of this cooking
zone
No cookware on the cooking
zone
The diameter of the bottom of
the cookware is too small for
the cooking zone
than two minutes without
cookware
Automatic switch-off has
been triggered
is lit
11What to do if …
Set heat setting
Check the fuses.
If the fuses trip repeatedly,
please call an authorised electrician.
Switching off the child safty
device (see section “Child safety device” in the hob user
manual)
If the cooking zone is supposed to be hot, call the Customer Service Department.
See the section “Switching the
power function on and off”
Place cookware on the cooking zone
Move onto a smaller cooking
zone
Use suitable cookware
Switch off cooking zone, place
cookware on cooking zone,
switch on cooking zone
Switch off the cooking zone.
Switch the cooking zone on
again
the electrical supply for a few
minutes (Take the fuse out of
the house’s wiring system)
If after switching on again,
is displayed again, call the customer service department
If you are unable to remedy the problem by following the above suggestions,
please contact your local Service Force Centre.
1 Warning! Repairs to the appliance are only to be carried out by qualified service engi-
neers. Considerable danger to the user may result from improper repairs.
What to do if …12
3 If the appliance has been operated incorrectly, the engineer's visit will be chargeable,
even during the warranty period.
Operating noises
Depending on the material and the processing of the base, the following noises may occur when using induction cooking zones.
• Cracking noise (1)
when using cookware made of different materials (Sandwich construction)
• Whistling (1)
when using an individual cooking zone or several cooking zones with high powers
when the cookware is made of different materials (Sandwich construction)
• Humming (2)
can occur at high power levels
• Clicking (2)
during electric switching processes
• Hissing, buzzing (3)
The device is fitted with a fan for cooling the electrics. A whiring noise can be heard
when operating the fan which may deviate depending on the performance and may
continue for a while after the appliance is switched off.
The noises described are normal and do not refer to any defects.
2
1
3
Disposal
2 Packaging material
The packaging materials are environmentally friendly and can be recycled. The plastic
components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at the community waste disposal facilities.
2 Old appliance
13Disposal
The symbol
be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential negative consequences
for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of
this product, please contact your local city office, your household waste disposal service
or the shop where you purchased the product.
W on the product or on its packaging indicates that this product may not
Installation Instructions14
Installation Instructions
1 Safety instructions
Warning! This must be read!
The laws, ordinances, directives and standards in force in the country of use are to be
followed (safety regulations, proper recycling in accordance with the regulations, etc.)
Installation may only be carried out by a qualified electrician.
The minimum distances to other appliances and units are to be observed.
Anti-shock protection must be provided by the installation, for example drawers may
only be installed with a protective floor directly underneath the appliance.
The cut surfaces of the worktop are to be protected against moisture using a suitable
sealant.
The sealant seals the appliance to the work top with no gap.
Do not use silicon sealant between the appliance and the work top.
When building in, protect the underside of the appliance from steam and moisture, e.g.
from a dishwasher or oven.
Avoid installing the appliance next to doors and under windows. Otherwise hot cookware may be knocked off the rings when doors and windows are opened.
z Risk of injury from electrical current.
• The electrical mains terminal is live.
• Make electrical mains terminal free of voltage.
• Follow connection schematic.
• Observe electrical safety rules.
• Ensure anti-shock protection by installing correctly.
• The appliance must be connected to the electrical supply by a qualified electrician.
z Risk of injury from electrical current.
• Loose and inappropriate plug and socket connections can make the terminal overheat.
• Have the clamping connections correctly installed by a qualified electrician.
• Use strain relief clamp on cable.
• In the event of single-phase or two-phase connection, the appropriate mains cable of
type H05BB-F Tmax 90°C(or higher) or an equivalent type must be used.
• If this appliance’s mains cable is damaged, it must be replaced by a special cable (type
H05BB-F Tmax 90°C; or higher) or an equivalent type. The latter is available from the
Customer Care Department.
A device must be provided in the electrical installation which allows the appliance to be
disconnected from the mains at all poles with a contact opening width of at least 3 mm.
Suitable isolation devices include line protecting cut-outs, fuses (screw type fuses are to
be removed from the holder), earth leakage trips and contactors.
Service
In the event of technical faults, please first check whether you can remedy the problem
yourself with the help of the operating instructions (section “What to do if…”).
If you were not able to remedy the problem yourself, please contact the Customer Care
Department or one of our service partners.
In order to be able to assist you quickly, we require the following information:
– three digit letter-number combination for
– Model description
– Product number (PNC)
– Serial number (S No.)
– Type of fault
– Any error messages displayed by the appliance
So that you have the necessary reference numbers from your appliance at hand, we recommend that you write them in here:
Model description: .....................................
15Service
glass ceramic
(for numbers see rating plate)
PNC: .....................................
S No: .....................................
16
1
Afin de garantir une performance optimale et constante de votre appareil, veuillez lire
Nous vous remercions d’avoir choisi l’un de nos produits de qualité.
attentivement cette notice d'utilisation. Il vous permettra d’utiliser correctement et ef-
ficacement toutes les fonctions de l’appareil. Nous vous recommandons de conserver
cette notice à proximité pour une utilisation rapide et optimale. Si l'appareil devez être
vendu ou cédé à une autre personne, assurez-vous que la notice d'utilisation l'accompa-
Nous vous souhaitons beaucoup de plaisir avec votre nouvel appareil.
Sommaire
Notice d'utilisation 17
Avertissements importants 17
Description de l'appareil 19
Equipement du plan de cuisson 19
Bandeau de commande 19
Utilisation de l’appareil 20
Sélectionner le niveau de cuisson 20
Activer/désactiver la fonction Puissance 21
Utilisation de la sécurité enfants 22
Arrêt automatique 22
gne.
Conseils de cuisson 23
Plats pour cuisson sur zones de cuisson
à induction 23
Conseils d’économie d’energie 24
Exemples d’utilisation pour la cuisson 24
Nettoyage et entretien 25
Que faire si … 26
Protection de l’environnement 29
Instructions d'installation 30
Service après-vente 31
Montage 48
Plaque signalétique 51
Les symboles suivants sont utilisés dans ce guide d'utilisateur :
Attention ! A lire impérativement ! Remarques importantes relatives à la sécurité des
personnes et informations destinées à prévenir les dommages causés à l'appareil
3 Remarques générales et recommandations
2 Remarques relatives à la protection de l'environnement
z Risque dû à l'alimentation électrique
Loading...
