COMPETENCE 5173 V73 V
The Versatile Stand-Alone Electric Cooker
Operating Instructions
Dear Customer,
Please read these operating instructions through carefully.
Above all, please take note of the “Safety” section on the first few
pages. Please keep these operating instructions for future reference.
Pass them on to any subsequent owner of the appliance.
The warning triangle and/or specific words (Warning!, Caution!,
1
Important!) are used to highlight instructions that are important for
your safety or for the function of the appliance. It is imperative that
these instructions are observed.
0 1. This symbol guides you step by step when operating the appliance.
2. ...
3. ...
Next to this symbol you receive additional information and practical
3
tips on using the appliance.
Tips and information about the economical and ecological use of the
2
machine are marked with a cloverleaf.
Before calling out an engineer to a fault please read the chapter „What
to do if...“ as you may be able to resolve the problem yourself.
For further assistence contact your local AEG Service Force Centre, see
the chapter „Service“.
Printed on paper manufactured with environmentally sound processes.
He who thinks ecologically acts accordingly ...
2
Contents
CONTENTS
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Description of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cooking Surface Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Oven Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Oven Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Utensils Drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Oven Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting/Changing the Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Initial Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Suitable Pans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using the Rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Switch on double ring frying/cooking zone. . . . . . . . . . . . . . . . . . . . . . . . . . 20
Operating the Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Inserting the Shelf and Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Switching the Oven On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using the Automatic Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Automatic Switching Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Automatic Switching On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Checking Automatic Programme Settings . . . . . . . . . . . . . . . . . . . . . . . 24
Changing Automatic Programme Settings . . . . . . . . . . . . . . . . . . . . . . . 24
Cancelling an Automatic Programme . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Information on the Automatic Function . . . . . . . . . . . . . . . . . . . . . . . . . 25
Countdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Changing the Signal Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Usage, Tables and Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Pans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Typical Heat Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3
Contents
Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Baking Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Pies and Gratins Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Frozen Ready Meals Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Roasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Roasting Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Grilling Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Defrosting Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Preserving Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Exterior of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Oven Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Oven Shelf Runner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Oven Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Grill Element . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Oven Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Oven Door Glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Utensils Drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
What to do if ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Installing and Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Appliance Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Regulations, Standards, Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Safety Instructions for the Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
4
Operating Instructions
OPERATING INSTRUCTIONS
1 Safety Instructions
The new appliance may only be assembled and connected by an approved installer.
Please observe this instruction, otherwise the warranty will not cover
any damage that may occur.
The safety features of AEG electrical appliances comply with accepted
technical standards and the German Appliance Safety Law. However, we
also consider it our obligation as a manufacturer to make you aware of
the following safety information.
General Safety
• Take care when plugging in electrical appliances near the appliance.
Mains cables must not be allowed to fall on hot rings and must not
be trapped under the hot oven door.
• Do not store flammable substances in the oven. They could ignite
when the oven is switched on.
• Cleaning the appliance with a steam or high pressure cleaner is for-
bidden for safety reasons.
• If force is used, especially on the edges of the front pane of glass, the
glass may break.
• If fractures, cracks or splits appear in the cooking surface:
– switch off all cooking zones,
– switch off the fuse for the cooking surface,
– inform customer service immediately.
• When cooking, roasting and grilling, the oven door will become hot.
Therefore always keep small children away from the door.
• Overheated fat and oil can catch fire quickly. Please always stay close
to the cooking surface when preparing food in fat or oil (e.g. chips).
• If you use alcoholic ingredients in the oven, it is possible that an
easily ignitable alcohol-air mixture might be produced. In this case
open the door carefully. When doing so, avoid having any hot embers,
sparks or open flames in the immediate vicinity. We recommend leaving the cooked food to cool in the oven with the door shut for
approx. 10-15 minutes after switching off the oven.
5
Operating Instructions
• Repairs to the appliance may only be performed by qualified service
engineers. Improper repairs can give rise to significant hazards. If
your appliance needs repairing, please contact our Customer Service
or your specialist dealer.
• In the case of the appliance malfunctioning: remove the fuses or
switch off the circuit breaker.
Intended use
• This appliance must not be used for purposes other than that intended, it must only be used for the cooking, roasting and baking of
food in the home.
• Only use the appliance to prepare food.
• Do not use the oven to heat the room.
In this way you avoid damaging your appliance
• Do not use the cooking surface for storage. In this way you will avoid
damaging the glass ceramic surface.
• If sugar or plastic comes into contact with the hot cooking surface
and melts, remove it immediately whilst still hot! If it cools, splits
may occur in the glass ceramic cooking surface.
• The glass ceramic cooking surface is insensitive to temperature shock
and very robust, however it is not unbreakable. Hard and sharp
objects, in particular, can damage the cooking surface if they fall on
it.
• Only use utensils with flat, smooth bases that are neither rough nor
burred. Otherwise permanent scratching may occur when the utensils
are slid.
• Do not place hot frying pans or saucepans on the cooking surface
frame and do not cover the cooking surface with protective foil.
• Do not place any pans or other items over the oven steam outlet in
the cooking surface frame.
• Do not place aluminium foil or plastic containers on the hot rings and
do not prepare food in aluminium foil or plastic containers on the hot
cooking surface.
• Do not line your oven with aluminium foil and do not place a baking
sheet or dish on the oven floor, otherwise the oven enamel will be
damaged by the resulting build up of heat.
• Clean the appliance after each use. Spills are then easier to clean up
and do not become burnt onto the surface.
6
Operating Instructions
• Any drops of fruit juice that fall from the baking sheet will leave
spots that cannot be removed. Use the universal sheet for very moist
cakes.
• Never pour water directly into the hot oven. The enamel may be
damaged.
• Do not sit on the open oven door/oven drawer.
• Do not store moist food in the oven.
Eco-Insulation
In the factory the oven is fitted with eco-insulation. This insulation has
been tested for pollutants by independent test institutes and categorised as harmless
2 Disposal
Disposing of the packaging materials
All materials used can be fully recycled.
The plastics are marked as follows:
• >PE< for polyethylene, e.g. as used for the outer wrapping and the
bags inside.
• >PS< for polystyrene foam, e.g. as used for the packing pieces, completely free of CFCs.
The cardboard is made from 80% recycled paper.
Disposal of old appliances
All old appliances must be correctly disposed of for environmental reasons.
Warning! When disposing of an old appliance, make it unusable by
1
cutting off the cable. Remove any door catches to prevent small children being trapped inside.
Information on disposal
2
• The appliance must not be disposed of in the household rubbish.
• You can obtain information about collection dates or public tips from
your local refuse department or council.
7
Operating Instructions
Description of the Appliance
Control panel
Oven functions
Rotary switch for setting the desired oven function.
Temperature selection
Rotary switch for setting the desired oven function.
Clock Functions and Time Display
Buttons for setting the clock functions. The current time or the time set
on the interval countdown is displayed.
Oven Power Indicator
The oven power indicator illuminates as soon as the oven or rings are
switched on.
Temperature Pilot Light
The temperature pilot light illuminates while the oven is heating up
and extinguishes when the selected temperature is reached. It then
cycles on and off during cooking to show that the temperature is being
maintained.
8
Operating Instructions
Ring switches
Rotary switches for switching on the cooking zones.
The oven is equipped with retractable switches.
3
Press the appropriate switch for use. The switch will then protrude.
9
Operating Instructions
Cooking Surface Features
Oven Steam Outlet
The steam from the oven is fed directly to the extraction hood via the
duct in the rear of the cooking surface.
Single Ring Cooking Zone
Switching on and regulation is
performed using the associated
switch on the control panel.
Double ring cooking zone
With the double ring cooking
zone the heated area can be
adapted to the diameter of the
saucepan base.
Residual Heat Indicator
The glass ceramic cooking surface
is equipped with an indicator
light that illuminates if one of
the cooking zones is hot. Once all
the cooking zones have cooled
down, the light goes out.
As long as the light is illuminated,
the residual heat can be utilised.
10
Oven Features
Shelf Positions
There are side rails on both sides of
the oven, each these has 6 shelf
positions for sliding in accessories.
At two positions, there are also
oven shelf runner rails to ease the
removal of cooked food.
Please note that the shelf positions
are counted from top to bottom.
Anti-Tip Device
All sheets are equipped with an
anti-tip device to prevent them
pulled out all the way inadvertently.
When inserting slide-in parts, the
anti-tip device must be at the rear.
Operating Instructions
Fat Filter
The fat filter supplied with your
appliance protects the fan in the
rear wall of the oven from soiling.
Always use the filter when roa-
sting uncovered food or using hot
air or Rotitherm.
✘
11
Operating Instructions
Oven Accessories
The following items are supplied:
Baking Sheet
For cakes and biscuits
Combination Shelf
For dishes, cake tins, ovenware
for roasting and grilling
Fat Tray
For roasting or for collecting fat
12
Operating Instructions
Utensils Drawer
Underneath the oven door there is
a drawer that can be pulled out. It
is used for storing utensils and
accessories.
WARNING: Heat can build up in
1
the utensils drawer when the oven
is in use. Therefore do not store
any flammable utensils in the drawer, e.g.:
–cleaner,
– plastic bags,
–oven cloths,
– paper, etc.
– Under no circumstances should oven cleaner spray be stored in
the drawer!
13
Operating Instructions
Oven Functions
The following functions are available for the oven:
L Oven lighting
With this function you can illuminate the oven interior, e.g., for
cleaning.
The heating element is not in use.
R Fast Warm Up
Using the fast warm up function you can very quickly pre-heat the
empty oven for the other cooking functions.
Several elements operate simultaneously for the fast warm up
function.
U Fan Cooking
Fan cooking is particularly suited to baking on several levels at the
same time.
Oven temperatures are generally 20-40 °C lower than for conventional
heat.
A ring heater and part of the bottom element are used.
In addition a fan in the rear wall of the oven ensures that the hot air in
the oven is circulated continuously. The food is heated from all sides.
14
S Pizza & Baking
Using this function you can bake cakes on one level.
This function is also suitable for dishes that require more intensive
browning and a crispy base, e.g. pizzas , quiche Lorraine, cheesecakes,
etc.
Oven temperatures are generally 20-40 °C lower than for conventional
heat.
Conventional heat is used and the fan is also switched on.
O Conventional
Conventional is suited to baking and roasting on one level.
Heat is supplied evenly from above and below.
Operating Instructions
I Rotitherm
Rotitherm is particularly suited to grilling or roasting larger pieces of
meat or game on one level. This function is also suitable for ’au gratin’
dishes and browning.
The grill element and fan are used simultaneously.
F Grill
Grilling is particularly suited to the grilling or toasting of flat foods,
for example, steaks, cutlets, fish or toast.
The heat is provided by the grill element on the roof of the oven.
A Defrosting
The oven's defrosting function allows you to evenly start to defrost or
to defrost. It is particularly suitable for delicate foods, for example,
flans, butter ice cream, bread, fruit.
With this function, the fan is in operation without heat.
15
Operating Instructions
Before using for the first time
Setting/Changing the Time
The time display will flash after the electrical supply is connected.
You must then first set the time.
If the time has not been set, the oven cannot be switched on.
Setting the Time
0 1. Press the M button.
2. Set the current time within
5 seconds using the + or - buttons.
The time appears in the display.
The oven is now ready for use.
By pressing the + or - button
3
for more than 2 seconds, the
minutes will start to run forwards
or backwards until the button is
released again. By this means you
can reach the required setting
quicker.
16
If the appliance has been isolated from the mains, e.g. due to a power
3
failure, the time display will flash again.
In this case reset the time again, as described above.
Changing the Time
If you wish to correct the time, e.g. on the change over from summer to
winter time, repeat the process described under “Setting the Time”.
Operating Instructions
Initial Cleaning
Hob
0 Wipe the glass ceramic cooking surface with a damp cloth to remove
any residues left from manufacturing.
Oven
Before using the oven for the first time, you should clean it
thoroughly. You can switch on the oven light to make cleaning
easier.
0 1. Turn the oven function switch to oven lighting L.
2. Remove all accessories and the side rails and clean with warm water
and washing-up liquid.
3. Also wash out the oven with warm water and washing-up liquid and
dry it.
4. Wipe off the front of the unit with a damp cloth only.
Important: Do not use any caustic, abrasive cleaners! The surface could
1
be damaged.
Suitable Pans
By using the right pans you avoid damage to the appliance.
• The base should be as thick and flat as possible. Rough bases scratch
the cooking surface when slid.
• Pans made of cast iron or with rough edges and burrs can leave
permanent scratches.
Important: Avoid boiling pans dry! The bases could be irreparably
1
damaged in the process and the glass ceramic cooking surface
damaged.
17
Operating Instructions
Using the Rings
When the cooking zones are switched on, they may hum briefly. This is
3
a characteristic of all glass ceramic cooking zones and does not impair
the function or life of the appliance.
Heat Settings
• Over the ranges 1-9, you can set 14 heat settings (including interme-
diate settings).
• You can select intermediate settings in the ranges 2 to 7. They are
marked with a dot between the heat settings.
1 = lowest setting
9 = highest setting
18
Cooking with the Rings
1. For heating up/browning, select a
high heat setting.
2. As soon as steam starts to form or
the oil is hot, turn back to the heat
setting necessary for further cooking.
3. To stop cooking, turn back to the zero
position.
Operating Instructions
Switch the cooking zone off approx. 5-10 minutes before cooking is
2
finished to make use of the residual heat. This saves electricity.
19
Operating Instructions
Switch on double ring frying/cooking zone.
Turn on the double ring frying/cooking zone by rotating the switch to
1
the right. Do not rotate it beyond the stop.
1. Turn switch for the double ring
frying/cooking zone to the right.
Continue to turn it past position 9
and slight resistance to the symbol
K until you reach a clearly noticeable stop.
2. Then turn the switch back to select
the desired heat.
3. Return the switch to the off position
to complete the cooking process.
When the two ring frying/cooking zone is switched again the larger
3
ring has to be switched on separately.
20
Operating the Oven
Inserting the Shelf and Sheet
The shelf is equipped with two
guide rails on the right and left,
these must always point downwards.
Inserting the Shelf
0 Insert the shelf such that the two
guide rails point downwards. Insert
the shelf on the oven shelf runners
such that the two holes engage
with the two retaining pins on the
oven shelf runner rails.
Inserting the Baking Sheet/Universal Sheet
0 Insert the sheets such that the anti-
tip device is at the rear. Insert the
sheets on the oven shelf runner
rails such that the two holes
engage with the retaining pins on
front of the oven shelf runner rails.
Operating Instructions
Inserting the Shelf and Sheet
0 When using the shelf and univer-
sal sheet together, carefully insert
the shelf guide pins in the protuberances on the sheet.
21
Operating Instructions
Switching the Oven On and Off
0 1. Set the required function by turning the „Oven Function“ selector.
2. Set the required temperature by turning the „Temperature Selector“
switch.
The oven power indicator illuminates as long as the oven or rings are in
use.
The temperature pilot light illuminates as long as the oven is warming
up and extinguishes as soon as the temperature set is reached.
It will then cycle on and off to show that the temperature is being
maintained.
3. To switch off the oven, turn the „Oven Function“ selector and the „Temperature Selector“ to the zero position.
22
Operating Instructions
Using the Automatic Function
There are two ways of using the automatic function:
• Automatic Switch Off: When you have the oven switched on and
simply do not want to forget to switch it off at the right time, you
can use the clock to set either the duration or the end of the coo-
king time. The oven then switches itself off automatically.
• Automatic Switching On and Off: When, for example, in the
morning or at lunch time you want to prepare a dish for the evening,
you can set the duration and also the end of the cooking time. The
oven then switches on automatically at the calculated start time, and
switches off again automatically at the end of cooking.
– Example: The roast requires cooking for 1 hour: COOK TIME = 1.00.
The roast should be ready at 18:00: END TIME = 18.00.
The oven function can be selected either before or after setting the
automatic function.
Automatic Switching Off
0 1. Select the required oven function.
2. Select the required temperature.
3. Press the “COOK TIME” < button.
4. Set the required cooking time within 5 seconds using the + and -
buttons.
The “AUTO” symbol illuminates and indicates that the oven is set up in
automatic mode.
As soon as the cooking time is at an end, the oven switches off automatically. The “AUTO” symbol flashes and an acoustic signal sounds for
approx. two minutes.
5. Press the “COOK TIME” < button to switch off the signal.
6. Press the “MANUAL” M button.
The “AUTO” symbol extinguishes. The oven is now set again to manual
mode.
7. To switch off the oven, turn the oven function and temperature
selectors to the off position.
23
Operating Instructions
Automatic Switching On and Off
For automatic switching on and off both the duration and the end of
the cooking time must be entered.
0 1. Select the required oven function.
2. Select the required temperature.
3. Press the “COOK TIME” < button and, using the + and - buttons,
within 5 seconds set the required cooking time.
4. Press the “END TIME” > button and using the + and - buttons,
within 5 seconds set the time when you want the meal to be ready.
Once the entries have been made, the current time is again shown in
the display. The “AUTO” symbol illuminates and indicates that the oven
is set up in automatic mode.
The oven switches on automatically at the calculated start time. When
the cooking time is at an end, the oven switches off automatically.
The “AUTO” symbol flashes and an acoustic signal sounds for approx.
two minutes.
5. Press the “COOK TIME” < button to switch off the signal.
6. Press the “MANUAL” M button.
The “AUTO” symbol extinguishes. The oven is now set again to manual
mode.
7. To switch off the oven, turn the oven function and temperature
selectors to the off position.
Checking Automatic Programme Settings
0 Press the “COOK TIME” < or "END TIME" > button.
The duration or the end of the cooking time set is displayed respectively.
Changing Automatic Programme Settings
You can still change the duration or the end of the cooking time during
cooking.
0 1. Using the “COOK TIME” < button call up the cooking time, or using
the "END TIME" > button, the end of the cooking time.
2. Within 5 seconds press the + or - button until the cooking time or
the end of the cooking time is set to the new time you require.
24
Operating Instructions
Cancelling an Automatic Programme
0 1. Using the “COOK TIME” < button call up the cooking time again.
2. Within 5 seconds set all entries to "0" using the - button.
3. Turn the oven function selector and the temperature selector to the off
position.
Information on the Automatic Function
3
The maximum COOK TIME that can be set is 10 hours.
25
Operating Instructions
Countdown
The countdown operates independently and can therefore be set when
the oven is switched on as well as switched off.
Setting the Countdown
0 1. Press the “CLOCK” C button.
2. Set the time required within
5 seconds using the + and buttons.
When the time set on the countdown has expired, an acoustic
signal sounds for approx. two
minutes.
3. Press the “CLOCK” C button to
switch off the signal.
Changing the Setting on the Countdown
0 1. Using the “CLOCK” C button, re-select the time set on the countdown.
2. Set the new time required within 5 seconds using the + or - buttons.
Switching Off the Countdown Early
0 1. Using the “CLOCK” C button, re-select the time set on the countdown.
2. Within 5 seconds set the time required to "0" using the - button.
Checking the Countdown Setting
A few seconds after the countdown has been set, the time display indicates the current time again. You can check the amount of time left on
the countdown at any time.
0 1. Using the “CLOCK” C button, re-select the time set on the countdown.
The time remaining on the countdown is displayed.
Changing the Signal Tone
The frequency of the signal tone can be set to 3 different tones.
0 1. Press the - button until the changed signal tone sounds and release.
The frequency is set to the next level.
2. Press the - button again until the changed signal tone sounds and
release.
The frequency is set to the next level.
26
Operating Instructions
Usage, Tables and Tips d Tips
Pans
The better the pan, the better the results.
• You can recognise good pans by their bases. The base should be thick
and as flat as possible.
• Pans with aluminium or copper bases can leave metal discoloration
on the glass ceramic surface that is very difficult or impossible to
remove.
• Do not use cast iron pans or pans with dama-
ged bases that are rough or burred. Permanent
scratching may occur when the pans are slid.
• When cold, pan bases are normally bowed
slightly inwards (concave). They should under
no circumstances be bowed outwards (convex).
Energy Saving Tips
2
You will save valuable energy if you observe the
following tips:
• Always place pans on the cooking zone before switching on.
• Soiled cooking zones and pan bases increase the electricity consump-
tion.
• If possible, always fit pans with a lid.
• Switch off the cooking zones before the end of
cooking to make use of the residual heat, e.g. to
keep food warm or for melting.
• The pan base and cooking zone should be the
same size.
When purchasing pans pay attention to the diameter of the base. Manufacturers often state the
diameter of the top of the pan.
• Cooking times are reduced by up to 50% when a
pressure cooker is used.
27
Operating Instructions
Cooking
The information given in the following tables is for guidance only. The
heat setting necessary for cooking is dependent on the quality of the
pans, and the type and quantity of the food.
Typical Heat Settings
Switch
Setting
9 Heating Up Heating up large amounts of water, boiling pasta
7-8
6-7
4-5 Boiling
3-4
2-3 Simmering
1-2 Melting
0 Residual heat, off position
Cooking Process/
Setting
Fast
Frying
Slow
Frying
Steaming,
Braising
Suitable for
Frying chips,
browning meat, e.g. goulash,
frying, e.g. potato pancakes
frying pieces of loin, steaks
Frying meat, schnitzels, cordon bleu
cutlets, rissoles, sausages, liver roux,
mild frying of
eggs, omelettes, frying doughnuts
Boiling larger quantities of food,
stews and soups,
steaming potatoes,
boiling meat stock
Braising vegetables,
braising meat
cooking rice pudding
Simmering rice and milk dishes
(stir occasionally),
Steaming smaller quantities of potatoes or
vegetables,
warming ready meals
Omelette, egg garnish, hollandaise sauce,
keeping dishes warm,
melting butter, chocolate, gelatine
28
When heating up or frying, we recommend heat setting “9“ and then
3
continue cooking foods at an appropriate lower heat setting.
Operating Instructions
Baking
Use the pizza & baking S, fan cooking U or conventional heat O oven
function for baking.
Important! Do not use a fat filter when baking!
1
Cake Tins
• Cake tins made of dark metal and coated tins are suitable for conven-
tional heat
• Light tins are also suitable for pizza & baking
Shelf Positions
• When using pizza & baking
sible to bake on one level.
• You can bake on up to 3 baking sheets simultaneously using fan
cooking
1 Baking Sheet:
Shelf Position 3
O.
S and fan cooking U.
S or conventional heat O is it only pos-
U:
1 Cake Tin:
Shelf Position 5
2 Baking Sheets:
Shelf Positions 2 and 5
3 Baking Sheets:
Shelf Positions 1, 3 and 5
29
Operating Instructions
General information
• Please note that the shelf positions are counted from top to bottom.
• Insert baking sheets with the bevelled edge to the front!
• Slide the baking sheet to the rear wall.
• Always place cakes in cake tins in the middle of the shelf.
You can also bake two cakes simultaneously using pizza & baking
or conventional heat
O. In this case place the tins side by side on the
shelf. The cooking time is then increased only slightly.
Notes on the Baking Tables
In the tables you will find information on temperatures, cooking times
and shelf positions for a selection of recipes.
• Ranges are given for the temperature and cooking time since these
are dependent on the mixture, quantity and cake tin used.
• When baking several cakes on baking sheets or in cake tins, the cook-
ing time can be 10-15 minutes longer.
• Moist items (e.g. pizzas & baking, fruit cakes, etc.) should be cooked
on a maximum of two levels.
• When using for the first time, we recommend setting the lower tem-
perature, and only if necessary, e.g. if increased browning is required
or the cooking time is too long, selecting a higher temperature.
• If you cannot find any specific information for one of your own reci-
pes, use information on a similar recipe for guidance.
• Variations in the height of the item to be baked can lead to different
degrees of browning at the start of baking. In this case, please do
not change the temperature setting. Variations in the amount of
browning will even themselves out during baking.
S
30
Switch off the oven 10-15 minutes before the end of the cooking time
2
to make use of the residual heat.
The information in the tables applies, when not otherwise stated, for a
cold oven.
Operating Instructions
Baking Tables
Baking on one level
Type of Cake or Pastry Pizza & Baking S Conventional O Time
Shelf
Position
from the
Top
Tempera-
ture
ºC
Shelf
Position
from the
Top
Tempera-
ture
ºC
for both
functions
Hr.: Min.
Cakes in Cake Tins
Ring Cakes 5. 150-160 5. 160-180 0:50-1:10
Madeira Cake/
Koenigskuchen
5. 140-160 5. 150-170 1:10-1:30
Sponge Cake 4. 150-160 5. 160-180 0:25-0:40
Shortcrust Pastry Flan
Base
3. 170-180 5.
190-210
1
0:10-0:25
Sponge Flan Base 3. 150-170 5. 170-190 0:20-0:25
Covered Apple Flan 5. 150-170 5. 170-190 0:50-1:00
Savoury Flan
(e.g. quiche Lorraine)
5. 180-200 5./6. 180-200 0:30-1:10
Cheesecake 5. 140-160 5. 160-180 1:00-1:30
Cakes and Pastries on
Baking Sheets
Plaited Roll/Ring 3. 160-170 3. 170-190 0:30-0:40
Christmas Stollen 3.
Bread (rye bread) first
...................................then
Cream Puffs/Eclairs 3.
.160-170
.180-200
5.
160-170
1
1
140-160
1
Swiss Roll 3. 160-170 3.
3.
160-180
5.
160-180
3. 190-210 0:15-0:30
180-200
250
1
1
0:40-1:00
0:30-1:00
1
0:10-0:20
0:20
Dry Streusel Cake 3. 150-160 3. 160-180 0:20-0:40
Butter Cake/Sugar Cake,
Bienenstich
Fruit Flan (on yeast
pastry/sponge base)
2
3.
3. 150-170 3. 170-190 0:25-0:50
160-170
1
3.
190-210
1
0:15-0:30
31
Operating Instructions
Type of Cake or Pastry Pizza & Baking S Conventional O Time
Fruit Flans on Shortcrust
Pastry Base
1
Shelf
Position
from the
Top
Tempera-
ture
ºC
3. 160-170 3. 170-190 0:40-1:20
Shelf
Position
from the
Top
Tempera-
ture
ºC
for both
functions
Hr.: Min.
Flat Cakes with
Delicate Toppings
3. 140-160 3. 160-180 0:40-1:20
(e.g. curd cheese, cream)
Pizza & baking
(with deep topping)
5. 180-200 5.
Pizza & baking (thin) 5. 200-220 5.
Unleavened Bread 3. 200-220 3.
Wähen (CH) 3.
180-200
1
5.
190-210
230-300
270-300
210-230
1
1
1
1
0:30-1:00
0:10-0:25
0:08-0:15
0:35-0:50
Biscuits
Shortcrust Biscuits 3. 150-160 3.
Small Piped Biscuits 3. 140-150 3.
170-190
160-180
1
1
0:06-0:20
0:10-0:40
Sponge Fingers 3. 150-160 3. 170-190 0:15-0:20
Meringues 3. 80-100 3. 100-120 2:00-2:30
Macaroons 3. 100-120 3. 120-140 0:30-0:60
Small Pastries with Yeast 3. 160-170 3. 170-190 0:20-0:40
Small Pastries made from
Puff Pastry
Bread Rolls 3.
3.
170-180
180-200
1
3.
1
5.
190-210
180-220
1
1
0:20-0:30
0:20-0:35
32
1) Pre-heat the oven
2) Use the combination/fat tray or the fat tray!
The information given in bold shows you the best oven function to use in each
case.
Operating Instructions
Baking at several shelf positions
Fan Cooking U
1
1
Time
Hr.: Min.
0:30-0:50
0:30-0:55
Type of Cake or Pastry
Cakes and Pastries on
Baking Sheets
Cream Puffs/Eclairs 2. and 5. - 170-180 0:35-0:60
Dry Streusel Cake 2. and 5. - 140-160 0:30-0:60
Pizza & baking 2. and 5. - 170-190 0:40-0:70
Biscuits
Shortcrust Biscuits 2. and 5. 1. 3. and 5. 150-160 0:15-0:35
Small Piped Biscuits 2. and 5. 1. 3. and 5. 140-150 0:20-0:60
Sponge Fingers 2. and 5. 1. 3. and 5. 160-170 0:25-0:40
Meringues 2. and 5. - 80-100 2:10-2:50
Macaroons 2. and 5. 1. 3. and 5. 100-120 0:40-1:20
Small Pastries with Yeast 2. and 5. - 160-170 0:30-0:60
Small Pastries made from
Puff Pastry
Bread Rolls 2. and 5. -
Shelf Position from the Top
2 Levels 3 Levels
2. and 5. -
Tempera-
ture ºC
170-180
180-190
Tips on Baking
This is how to tell if your cake
is cooked through
The cake collapses (is sticky,
not properly cooked through,
water marks)
The cake is too light
Cake with moist topping/
cake is not cooked through,
is unevenly browned
Tip
Push a wooden skewer into the highest point of the
cake. When no more cake mixture sticks to the wood,
you can switch off the oven and utilise the residual
heat.
Check your recipe. Next time use less liquid. Observe
mixing times, particularly when using kitchen
appliances.
Next time select a dark cake tin or place the cake one
level lower.
Next time bake at a lower temperature and increase
the cooking time.
33
Operating Instructions
Pies and Gratins Table
Conventional O Rothitherm I Time
Shelf
Position
from the
top
Pasta Bake 4. 200-220 3. 160-170 0:45-1:00
Lasagne 3. 180-200 3. 160-170 0:25-0:40
Gratinated
Vegetables
Browned
Baguettes
Sweet
Puddings
Fish Pies 3. 210-220 3. 160-170 0:30-1:00
Stuffed
Vegetables
3. 22-230 3. 160-170 0:15-0:30
3. 230-240 3. 160-170 0:15-0:30
4. 200-220 – – 0:40-0:60
3. 220-250 3. 160-170 0:30-1:00
Tempera-
ture
°C
Shelf
Position
from the
top
Tempera-
ture
°C
Hr.: Min.
Frozen Ready Meals Table
Food to be
Cooked
Shelf
Position from
the Top
Oven Function Temperature Time
34
Frozen Pizza 3.
1
Chips
(300-600 g)
Baguettes 2./3.
Fruit Flan 2./3.
1) Comment: Turn chips 2-3 times during cooking.
2. Rothitherm I 200-220 °C 15-25 Min.
Conventional
O
Conventional
O
Conventional
O
In accordance
with maker’s
instructions
In accordance
with maker’s
instructions
In accordance
with maker’s
instructions
In accordance
with maker’s
instructions
In accordance
with maker’s
instructions
In accordance
with maker’s
instructions
Operating Instructions
Roasting
For roasting, use the rothitherm I or conventional O oven function.
Ovenware for Roasting
• Any heat-resistant dish is suitable for roasting.
• In the case of dishes with plastic handles, ensure that the handles are
heat-resistant.
• Large roasts can be roasted directly on the universal sheet or on
the shelf with the universal sheet underneath (e.g. turkey, goose,
3-4 chickens, 3-4 knuckles).
• We recommend roasting all lean types of meat in a casserole with a
lid (e.g. veal, pork or beef pot roasts, frozen meat). This way the meat
will remain juicier.
• You can roast all types of meat that should have a crispy exterior in a
casserole without a lid (e.g. pork, meat loaf, lamb, mutton, duck,
1-2 knuckles, 1-2 chickens, small poultry, sirloin, filet, game).
• Tip: If you use dishes for roasting (particularly for small amounts), the
oven will not get so dirty!
Shelf Positions
• Please see the following table for the shelf positions to be used.
Notes on the Roasting Tables
Information is given in the table on suitable oven functions, temperature settings, cooking times and shelf positions for various types of
meat. The cooking times are only for guidance.
• We recommend roasting meat and fish in the oven from a weight of
1kg.
• In general the conventional
fish and game. For all other types of meat (particularly poultry) we
recommend the rothitherm
• The cooking time required is dependent on the type and quality of the meat.
• To stop juices that exude from the meat burning onto dishes, we
recommend adding a little liquid in the roasting dish.
• Turn the roast after approx. 2/3 of the cooking time.
Switch off the oven 10-15 minutes before the end of the cooking time
2
to make use of the residual heat.
O function is suitable for very lean meat,
I function.
35
Operating Instructions
Roasting Table
Type of Meat Quantity Conventional O Rothitherm I Time
Weight
Shelf
Position
from the
Top
Tempera-
ture
ºC
Shelf
Position
from the
Top
Tempera-
ture
ºC
Hr.:Min.
Beef
Pot Roast 1-1.5 kg 4. 200-250 – – 2:00-2:30
Roast Beef or
Fillet
- red inside
- pink inside
- cooked
through
per cm
height
per cm
height
per cm
height
4.
4.
4.
250-270
250-270
210-250
1
4. 190-200 0:05-0:06
1
4. 180-190 0:06-0:08
1
4. 170-180 0:08-0:10
per cm
height
Pork
Schoulder, Neck
Joint of Ham
1-1.5 kg 4. 210-220 4. 160-180 1:30-2:00
Chop, Kassler 1-1.5 kg 4. 180-190 4. 170-180 1:00-1:30
Meat Loaf
Knuckle of Pork
(pre-cooked)
750 g-1 kg
750 g-1 kg
4. 170-180 4. 160-170 0:45-1:00
4. 210-220 4. 150-170 1:30-2:00
36
Veal
Roast Veal 1kg 4. 210-220 4. 150-170 1:30-2:00
Knuckle of Veal 1.5-2 kg 4. 210-225 4. 150-170 2:00-2:30
Lamb
Leg of Lamb,
Roast Lamb
1-1.5 kg 4. 210-220 4. 150-170 1:15-2:00
Saddle of Lamb 1-1.5 kg 4. 210-220 4. 160-180 1:00-1:30
Operating Instructions
Type of Meat Quantity Conventional O Rothitherm I Time
Weight
Shelf
Position
from the
Top
Tempera-
ture
ºC
Shelf
Position
from the
Top
Tempera-
ture
ºC
Hr.:Min.
Game
Saddle of Hare,
Leg of Hare
up to
1kg
3.
220-250
1
3. 160-170 0:25-0:40
Saddle of Venison 1.5-2 kg 4. 210-220 4. 160-170 1:00-1:30
Leg of Venison 1.5-2 kg 4. 200-210 4. 150-160 1:15-1:50
Poultry
Poultry Pieces
4-6 pieces
Chicken Halves
2-4 pieces
Chicken,
Poulard
Duck
Goose
Turkey
per
200-250g
per
400-500 g
1-1.5 kg
1.5-2 kg
3.5-5 kg
2.5-3.5 kg
4-6 kg
3. 220-250 3. 180-200 0:35-0:50
3. 220-250 3. 180-200 0:35-0:50
4. 220-250 4. 170-180 0:45-1:15
4. 210-220 4. 160-180 1:00-1:30
5. 200-210 5. 150-160 2:30-3:00
5.
5.
200-210
180-200
5.
5.
150-160
140-150
1:30-2:00
2:30-4:00
Fish (steaming)
Whole Fish
1-1.5 kg
4. 210-220 4. 160-170 0:45-1:15
1) Pre-heat the oven.
The information given in bold shows you the best oven function for the respective dish.
37
Operating Instructions
Grilling
For grilling, use the oven function Grill F with the temperature 300 °C.
Attention: Always pre-heat the empty oven for 5 minutes using the
1
grill function!
It is not necessary to use the fat filter.
Ovenware for Grilling
• Use the shelf and fat tray together for grilling.
Shelf Positions
• For grilling flat foods, always use the 2nd shelf position from the
top.
Notes on the Grilling Table
The grilling times are only for guidance and are dependent on the type
and quality of the meat or fish.
• Grilling is particularly suitable for flat pieces of meat and fish.
• Turn pieces of meat or fish halfway through grilling.
Warning: Always grill with the oven door closed.
1
Risk of burning!
38
Grilling Table
Food for Grilling
Rissoles 2. 8–10 Min. 6–8 Min.
Fillet of Pork 2. 10–12 Min. 6–10 Min.
Grilled Sausages 2. 8–10 Min. 6–8 Min.
Beef Fillet Steaks,
Veal Steaks
Fillet of Beef, Sirloin
(approx. 1 kg)
Bread for Toasting 2. 2–3 Min. 2–3 Min.
Toast with Topping 2. 6–8 Min. –
Insert
from above
2. 6–7 Min. 5–6 Min.
2. 10–12 Min. 10–12 Min.
Grilling Time
1st Side 2nd Side
Operating Instructions
Defrosting
Use the defrost oven function A for defrosting.
Defrosting Dishes
• Put the food on a plate and put the plate on the tray.
• Use only parchment paper or film to cover the food. Do not use plates or dishes as they significantly increase the defrosting time.
Shelf Positions
• For defrosting, insert the tray in the 4th level from the top.
Notes on the Defrosting Table
The table below gives you a few reference points on the defrosting
times.
Defrosting Table
Defros-
Dish
Chicken, 1000 g 100-140 20-30
Meat, 1000 g 100-140 20-30
Meat, 500 g 90-120 20-30
Trout, 150 g 25-35 10-15 Defrost open.
Strawberries,
300 g
Butter, 250 g 30-40 10-15 Defrost open.
Cream, 2 x 200 g 80-100 10-15
Flan, 1400 g 60 60 Defrost open.
ting time
Min.
30-40 10-20 Defrost open.
Post
defrosting
time Min.
Place the chicken on an upside-down
saucer on a large plate. Defrost open
and turn after half the time, or defrost covered with film.
Defrost open and turn after half the
time or cover with film.
Defrost open and turn after half the
time or cover with film.
Defrost open
(Cream can also be whipped well if
parts of it are still slightly frozen).
Comment
39
Operating Instructions
Preserving
Use the fan cooking oven function U for preserving.
Preserving Jars
• Only use commercially available preserving jars (preserving jars with a
rubber ring and glass lid) for preserving.
• Jars with screw or bayonet tops are unsuitable, as are metal tins.
Shelf Positions
• For preserving use the 4th shelf position from the top.
Notes on Preserving
• Use the universal sheet for preserving. There is room for up to 6 preserving jars of 1-litre content on this sheet.
• Pour a cup of water onto the universal sheet to ensure that there is
sufficient humidity.
• Position the preserving jars on the universal sheet such that they do
not touch each other.
• The preserving jars should all be filled the same amount and closed.
Preserving Times
Fruit and Pickled Gherkins
0 1. Select the fan cooking oven function U and set the temperature to
160 °C.
2. As soon as bubbles begin to form in the liquid in some of the jars (in
the case of 1-litre jars after approx. 45 minutes), switch off the oven.
3. Leave the jars to stand in the closed oven for a further 30 minutes, in
the case of delicate fruits, e.g. strawberries approx. 15 minutes.
Vegetables and Meat
0 1. Select the fan cooking oven function U and set the temperature to
160 °C.
1. As soon as bubbles begin to form in the first jars, lower the temperature
to 100 °C.
2. Continue to cook at 100 °C for approx. 60-90 minutes.
3. Then switch off the oven and leave the preserving jars to stand in the
closed oven for a further 30 minutes.
40
Operating Instructions
Cleaning and Care
Hob
Important: Cleaners must not come into contact with the hot glass
1
ceramic cooking surface! All cleaners must be removed with plenty of
clean water after cleaning because they can have a caustic effect when
the rings are next heated!
Do not use any aggressive cleaners such as, e.g. grill or oven sprays,
coarse scourers or abrasive pan cleaners.
Clean the glass ceramic cooking surface after each use, when it is still
3
hand-hot or is cold. By this means you will avoid soiling becoming
burnt on.
Remove scale and water marks, fat spots and metallic shimmering discoloration with a commercially available glass ceramic or stainless steel
cleaner, e.g. with „Sidol-Edelstahlglanz“, „Stahl-Fix“, „WK-Top“ or „Cillit“.
Light Soiling
0 1. Wipe the glass ceramic surface with a damp cloth and a little washing
up liquid.
2. Then rub dry with a clean cloth. Remnants of cleaner must not be left
on the surface.
3. Thoroughly clean the entire glass ceramic cooking surface once a week
with a commercially available glass ceramic or stainless steel cleaner.
4. Then wipe the glass ceramic surface with plenty of clean water and rub
dry with a clean fluff-free cloth.
Stubborn Soiling
0 1. To remove food that has boiled over or
stubborn splashes, use a glass scraper.
2. Hold the glass scraper at an angle to the
glass ceramic surface.
3. Remove soiling by sliding the blade.
You can obtain glass scrapers and glass
3
ceramic cleaner from specialist retailers.
41
Operating Instructions
1 Problem Dirt
0 1. Remove burnt on sugar, melted plastic,
aluminium foil or other materials that
can melt immediately, whilst still hot,
using a glass scraper.
Important: When using the glass scraper
1
on the hot cooking zone, there is a risk of
burns!
2. Then clean the cooking surface normally
when it has cooled down.
If the cooking zone on which something
3
has melted has already cooled down, warm it up again for cleaning.
Scratches or dark marks on the glass ceramic cooking surface caused,
e.g. by pan bases with sharp edges, cannot be removed. However, they
do not impair the function of the cooking surface.
Cooking Surface Frame
Important! Do not put vinegar, lemons or scale removers on the hob
1
frame, otherwise mat spots will appear.
0 1. Wipe the frame with a damp cloth and a little washing up liquid.
2. Soften dried dirt with a wet cloth. Then wipe off and rub dry.
42
Operating Instructions
Exterior of the Appliance
0 Wipe the front of the appliance with a damp cloth and warm water
with washing up liquid.
Do not use scourers, caustic cleaners or abrasive items.
Oven Interior
Oven Lighting
You can switch on the oven light to make cleaning easier.
Cleaning
0 1. Wipe the oven clean after each use with water and washing up liquid
with a little vinegar added.
2. Then rub the oven dry with a cloth.
3. Remove stubborn marks with special oven cleaner.
Warning: Do not clean the appliance with a steam or high pressure
1
cleaner for safety reasons.
Important: When using oven spray, please ensure that you follow the
manufacturer’s instructions.
Accessories
0 After each use rinse all slide-in parts (shelf, etc.) and dry well. Soak
briefly to make them easier to clean.
Oven Shelf Runner
0 Clean the oven shelf runners with hot soapy water.
Important! Do not under any circumstances grease the oven shelf run-
1
ner rails.
For easier cleaning the oven shelf runner can be removed on the left
and right side of the oven.
43
Operating Instructions
Removing and Replacing the Oven Shelf Runner
0 1. Undo the bolt (if necessary use a coin).
2. Pull the oven shelf runner forwards at the base and unhook at the top.
3. To refit, hook the oven runner back in at the top and place in position.
4. Re-fit the bolt.
44
Operating Instructions
Oven Light
Warning: There is a risk of electric shock! Before changing the light
1
bulb in the oven:
– Switch off the oven!
– Isolate the oven from the power supply.
Replacing the Light Bulb in the Oven/Cleaning the Glass
0 1. Place a cloth on the floor of the
oven.
2. Remove the glass cover by turning
it anti-clockwise and then clean it.
3. Oven lighting replace with
40 Watt, 230 V, 300 °C
heat resistant light bulb.
4. Refit the glass cover.
5. Remove the cloth from the oven.
45
Operating Instructions
Grill Element
To make the cleaning of the oven roof easier, the grill element can be
folded down.
Warning: Only fold down the grill when the oven is switched off and is
1
cold.
Folding Down the Grill Element
0 Turn the two retaining hooks 90° (a quarter of a turn) towards the
middle.
The heater element swings downwards.
Important: Do not use excessive force to lower the heater element. The
1
heater element can break off if excessive force is used.
2 x 90˚
Fitting the Grill Element
0 Press the heater element gently upwards and turn the retaining hooks
90° towards the rear so that the heater element bracket is between the
retaining hooks.
Important: Never slide the retaining hooks onto the heater element.
1
There is a risk of fire.
46
Operating Instructions
Oven Door
The oven door on your appliance can be removed for cleaning.
Removing the Oven Door
0 1. Open the oven door completely.
2. Lift up fully the coloured clamping lever on both door hinges (1).
3. Close the oven door around 3/4 of the way, overcoming the resistance
(2).
4. Take hold of the side of the oven door with both hands. Lift the door
upwards (Caution: heavy!) and remove from the oven (3).
5. Place the door, with the outer surface downwards, on a soft, flat
surface, for example a blanket, to avoid scratches.
Hanging the Oven Door
0 1. Take hold of the sides of the door with both hands from the handle
side.
2. Hold the door at an angle of approx. 60°.
3. Slide the door hinges as far as possible into the two cut-outs on the
right and left on the bottom of the oven (1).
4. Lift the door up until resistance is met and then open fully (2).
47
Operating Instructions
5. Turn the clamping levers on both door hinges back into their original
position (3), so that the coloured marks again point upwards.
6. Close the oven door.
Oven Door Glass
The oven door is fitted with two panes of glass, these are fitted one
behind the other. The inner pane can be removed for cleaning.
Warning: Please only perform the following steps on the oven door
1
when it has been removed from the oven! When the door is fitted, the
reduction in the weight of the door when the glass is removed could
lead to the door suddenly closing and creating a hazard.
Removing the Door Inner Glass
0 1. Remove the oven door and place
on a soft, level surface with the
handle downwards.
2. Take hold of the pane of glass at
the upper edge and slide it against
the spring pressure in the direction
of the oven door handle until it is
free at the base (1).
3. Lift the pane gently at the base
and remove (2).
Replacing the Inner Door Glass
0 1. Guide the pane of glass at an angle
from above into the door section
on the handle side (1).
2. Lower the pane of glass (2). Place
the pane, against the force of the
spring on handle side, in front of
the retaining section on the lower
edge of the door and slide it
under the retaining section.
The pane of glass must sit securely!
3. Refit the oven door.
48
Operating Instructions
Utensils Drawer
The utensils drawer underneath the oven can be removed to make cleaning easier.
Removing / Replacing the Utensils Drawer
0 1. Pull the utensils drawer out of the cooker as far as possible.
2. Lift the utensils drawer slightly so that it can be lifted upwards at an
angle out of the drawer guide.
3. When replacing, ensure that the middle guide on the utensils drawer
engages in the middle guide rail.
4. Lower the utensils drawer until it is horizontal and push home.
49
Operating Instructions
What to do if ...
.... the cooking zones do not work?
0 Check whether
– the corresponding cooking zone is switched on,
– the mains fuse (fuse box) has blown.
.... the oven does not heat up?
0 Check whether
– the appliance is switched on,
– all the necessary settings have been made,
– the mains fuse (fuse box) has blown.
If the fuse blows several times, please call an approved electrician.
.... the oven lighting ceases to function?
0 Replace the light bulb in the oven (see Cleaning and Care).
If you call in customer service to resolve a problem listed in these notes,
or to rectify an error in the operation of the appliance, the customer
service engineer’s visit will not be free of charge, even during the warranty period.
If this information does not provide you with the necessary assistance, please seek specialist advice.
50
Warning: Repairs to the appliance are only to be made by qualified
1
service engineers! Improper repairs can give rise to significant hazards
for the user. If your appliance needs repairing, please contact your specialist dealer or customer service.
Installing and Connecting
+
_
INSTALLING AND CONNECTING
Important: Assembly and connection of the new appliance may only
1
be performed by an approved installer.
Please observe this instruction, otherwise the warranty will not cover
any damage that may occur.
Installation
Important Information
• The veneer or plastic coverings on kitchen furniture around the
appliance must be bonded with heat resistant adhesive (100 °C). If
plastic coverings or the adhesive are not sufficiently temperature
resistant, then the covering may distort or come loose.
• In respect of fire protection, this appliance corresponds to type Y
(EN 60335-2-6). Only this type of appliance may built into positions
with a high cupboard or wall on one side.
• The separation between the hob and the extractor hood must be at
least as large as that given in the extractor hood installation instructions.
Appliance Alignment
Underneath the appliance there
are 4 adjustable feet with the aid
of which you can compensate for
small amounts of unevenness in
the floor.
0 1. Remove the utensils drawer
2. Turn the adjustable feet to raise
or lower them until the cooker is
level.
3. Replace the utensils drawer.
The adjustable feet are easier to
3
turn if the cooker is tilted slightly
to take the load off the feet.
_
+
51
Installing and Connecting
Technical Data
Oven Exterior Dimensions
Height x Breadth x Depth 85 cm x 60 cm x 60 cm
Depth with the door open 105 cm
Oven Interior Dimensions
Height x Breadth x Depth 31 cm x 39.6 x 41.5 cm
Power consumption of the cooking zones
Single ring cooking zone
Single ring cooking zone
Double ring cooking zone
ø145 mm 1200 W
ø 180 mm 1800 W
ø 120/210 mm 2200 W
Regulations, Standards, Directives
This appliance meets the following standards:
• EN 60 335-1 and EN 60 335-2-6
in respect of the safety of electrical appliances for household use and
similar purposes and
• DIN 44546 / 44547 / 44548
in respect of the operating features of electric cookers for household
use.
• EN 55014-2 / VDE 0875 part 14-2
• EN 55014 / VDE 0875 part 14/12.93
• EN 61000-3-2 / VDE 0838 part 2
• EN 61000-3-3 / VDE 0838 part 3
in respect of the basic protection requirements for electromagnetic
compatibility (EMC).
52
This appliance complies with the following EU directives:
4
• 73/23/EWG dated 19.02.1973 (Low Voltage Directive)
• 89/336/EWG dated 03.05.1989 (EMC Directive including
Directive Amendment 92/31/EWG).
Installing and Connecting
1 Safety Instructions for the Installer
• A device is to be included in the electrical installation that makes it
possible to isolate the appliance from the mains supply with a minimum contact separation of 3 mm. Suitable isolation devices are e.g.
cut-outs, fuses (remove screw type fuses from the holder), earth leakage trips and circuit breakers.
• Make the electrical connection
to the appliance in accordance
with the wiring diagram on the
outside of the connector cover.
Important: Do not feed cable
1
through the holes!
53
54
SERVICE
In the “What to do, if …” section a number of malfunctions are listed
that you can rectify yourself. In the event of a malfunction, look there
first.
Is it a technical malfunction?
Then please contact your customer service centre. (You will find addresses and telephone numbers in the "Customer Service Centres" list.)
Always take the time to prepare yourself for the call. By this means you
will make diagnosis of the problem easier and also make it easier to
decide if a customer service visit is necessary:
Please determine as accurately as
possible:
• How is the malfunction noticea-
ble ?
• Under what circumstances does
the malfunction occur?
Prior to the telephone call it is
imperative that you make a note of
the following appliance code numbers that are given on the rating
plate:
• PNC Code (9 digits),
• S-No Code (8 digits).
We recommend you to record the code numbers here so that you
always have them at hand:
Service
PNC . . . . . . . . .
S-No . . . . . . . .
When will you be charged, also during the warranty period?
• when you could have rectified the malfunction with aid of the Table
of Malfunctions (see “What to do, if ...” section),
• if the customer service engineer has to make several calls because he
was not given important information prior to his visit, and therefore,
e.g., had to fetch replacement parts. You can avoid multiple calls if
you prepare yourself well for the telephone call, as described above.
55
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
© Copyright by AEG
822 923 194- 02- 0402 Subject to change without notice
Loading...
