ÖKO-SANTO
Tisch-Kühlautomat
Réfrigérateur automatique
table top
Automatic Refrigerator
Gebrauchsanweisung
Mode d’emploi
Operating Instructions
41
Dear customer,
Before placing your new refrigerator/freezer into operation please
read these operating instructions carefully. They contain important
information for safe use, for installation and for care of the appliance.
Please keep these operating instructions for future reference. Pass
them on to possible new owners of the appliance.
These operating instructions are for use with several technically
comparable models with varying accessories. Please observe the notes
which apply to your model.
Notes which are important for your safety or for the proper functioning of the appliance are stressed with a warning triangle and/ or
with signal words (Warning!, Caution!, Attention!). Please observe the
following carefully.
This symbol guides you step by step in the operation of the appliance.
Supplementary information regarding operation and practical applications of the appliance appear after this symbol.
Tips and notes concerning economical and environmentally sound use
of the appliance are marked with the cloverleaf.
The operating instructions contain instructions for the correction of
possible malfunctions by the user in the section "What to do if ...". If
these instructions should not be sufficient, our customer service
department is always available to you.
Printed on paper manufactured with environmentally sound processes.
he who thinks ecologically acts accordingly ...
☞
42
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Appliance Packaging Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Disposal of old Appliances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Remove transport safeguard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Your refrigerator needs air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Detaching the worktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Mounting under a continuous worktop . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Rehingeing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Prior to Initial Start–Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Plug socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
View of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Starting up and temperature regulation . . . . . . . . . . . . . . . . . . . . . . . . . 51
Interior Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Storage shelves/wire trays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
VARIO glass storage shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Variable door interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Correct storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
The fridge defrosts automatically . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Switching off the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Cleaning and Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Energy Saving Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
What to do if .... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Correcting Malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Changing the light bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Noises during Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Regulations, Standards, Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Technical terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
43
Safety
The safety aspects of our refrigerators/freezers comply with accepted
technical standards and the German Appliance Safety Law.
Nevertheless, we consider it our obligation to make you aware of the
following safety information:
Intended use
• The refrigerator is intended for use in the home. It is suitable for
cooling food at low temperature.
If the appliance is used for purposes other than those intended or
used incorrectly, no liability can be accepted by the manufacturer
for any damage that may be caused.
• Alterations or changes to the refrigerator are not permitted for rea
sons of safety.
• If you use the refrigerator in a commercial application or for purposes other than the cooling of foods, please observe all valid legal
regulations for your application.
Prior to initial start–up
• Check the refrigerator for transport damage. Under no circumstance
should a damaged appliance be plugged in! In the event of damage,
please contact the vendor.
Refrigerant
The refrigerant isobutane (R600a) is contained within the refrigerant
circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable.
• During transportation and installation of the appliance, be certain
that none of the components of the refrigerant circuit become
damaged.
• If the refrigerant circuit should become damaged:
– avoid open flames and sources of ignition;
– thoroughly ventilate the room in which the appliance is situated.
Safety of children
• Packaging (e.g. wraps, polystyrene) can be dangerous for children.
There is a risk of suffocation! Keep packaging material away from
children!
• Please make old appliances unusable prior to disposal. Pull out the
mains plug, cut off the mains cable, break or remove spring or bolt
catches, if fitted. By doing this you ensure that children cannot lock
44
themselves in the fridge when playing (there is risk of suffocation!)
or get themselves into other dangerous situations.
• Often children cannot recognise the hazards present in household
appliances. It is therefore important that you ensure adequate
supervision and never let children play with the appliance!
Daily Operation
• Containers with flammable gases or liquids can leak at low tempe
ratures. There is a risk of an explosion! Do not store any containers
with flammable materials such as, for example, spray cans, fire
extinguisher refill cartridges etc in the refrigerator/freezer.
• Do not operate any electrical appliances in the refrigerator/freezer
(e.g. electric ice cream makers, mixers etc.).
• Before cleaning the appliance, always switch off the appliance and
unplug it, or pull the house fuse or switch off the circuit breaker.
• When unplugging always pull the plug from the mains socket, do
not pull on the cable.
In case of malfunction
• If the a malfunction occurs on the appliance, please look first in the
"What to do if ..." section of these instructions. If the information
given there does not help, please do not perform any further repairs
yourself.
• Refrigerators/freezers may only be repaired by qualified service
engineers. Improper repairs can give rise to significant hazards. If
your appliance needs repairing, please contact your specialist dealer
or our Customer Service.
45
Disposal
Appliance Packaging Information
All materials are environmentally sound! They can be dumped or burned at an incinerating plant without danger!
About the materials: The plastics can be recycled and are identified as
follows:
>PE< for polyethylene, e.g. the outer covering and the bags in the
interior.
>PS< for polystyrene foam, e.g. the pads, which are all free of
chlorofluorocarbon.
The carton parts are made from recycled paper and should be dispo-
sed of at a waste-paper recycling collection location.
Disposal of old Appliances
For environmental reasons, refrigeration appliances must be disposed
of properly. This applies to your old appliance, and - at the end of its
service life - for your new appliance as well.
Warning! Before disposing of old appliances make them inoperable.
Remove plug from mains, sever the power cable, remove or destroy
any snap or latch closures. This eliminates the danger that playing
children lock themselves into the appliance (danger of suffocation!)
or place themselves into other life-endangering situations.
Disposal:
• The appliance may not be disposed of with domestic waste or bulky
refuse.
• The refrigerant circuit, especially the heat exchanger at the back of
the appliance, may not be damaged.
• Information concerning collection schedules or locations can be
obtained from the local disposal authorities or town hall.
46
Remove transport safeguard
The appliance and the interior fittings are protected for transport.
Pull off the adhesive tape on the left and right side of the door.
You can remove any remnants of adhesive using white spirit.
Remove all adhesive tape and packing pieces from the interior of the
appliance.
Installation
Installation Location
The appliance should be set up in a well ventilated, dry room.
Energy use and efficient performance of the appliance is affected by
the ambient temperature. The appliance should therefore
– not be exposed to direct sunlight;
– not be installed next to radiators, cookers or other sources of heat;
– only be installed at a location whose ambient temperature corre
sponds to the climate classification, for which the appliance is designed.
The climate classification can be found on the serial plate, which is
located at the left on the inside of the appliance.
The following table shows which ambient temperature is correct for
each climate classification: each climate classification:
If installation next to a source of heat is unavoidable, the following
minimum clearances must be maintained at the sides of the appliance:
– for electric cookers 3 cm;
– for oil and coal fired ranges 30 cm.
If these clearances cannot be maintained a heat insulating pad is
required between the cooker and the refrigeration appliance.
If the refrigeration appliance is installed next to another refrigerator
or freezer a clearance of 5 cm at the sides is required, in order to prevent the formation of condensation on the outside of the appliance.
☞
☞
Climate classification for an ambient temperature of
SN +10 to +32 °C
N +16 to +32 °C
ST +18 to +38 °C
T +18 to +43 °C
47
Your refrigerator needs air
The refrigerating unit of your refrigerator is designed for maintenance-free operation. What it should never lack is good ventilation. Air is
supplied under the door through the ventilation slot between the refrigerator an storage surface. Air is extracted through the upper ventilation grille. Never obstruct these openings by plinth screens or
crockery.
If your refrigerator is installed under a
continuous worktop, an air outlet
opening of at least 200 cm 2 and a
ventilation grille (A/B) matching the
worktop design should be provided at
the rear of the worktop. The cut surfaces of the worktop (C) should be
varnished to avoid swelling due to
penetration of moisture.
The appliance wall distance must be
at least 30 mm and should be checked
before the ventilation grille is inserted.
Special accessories:
A Ventilation grille, brown
B Ventilation grille, white
Detaching the worktop
After the worktop has been removed the appliance can be installed
underneatch a continuous worktop.
The procedure is as follows:
Unscrew the Phillips screws (F) on the
right and the left.
Lift the work-top slightly, push it
about 20 mm towards the rear, and
lift it off upwards (G).
Unscrew the holding bracket (H) and
keep it in a safe place.
☞
☞
A/B
200 cm
2
105
C
570
550
93-103
AEG56
F
G
H
Mounting under a continuous worktop
If installed under a continuous worktop, the appliance is fastened with a
mounting screw (A) under the panel.
Rehingeing the door
The side at which the door opens can be changed from the right side
(factory adjustment) to the left side, if the installation site requires.
Warning! When changing the side at which the door opens, the appli
ance may not be connected to the mains. Remove plug from the
mains beforehand.
Tilt the appliance slightly towards the
rear and drop it securely.
Unscrew the door hinge screws (K)
and take the door bearing (1) downwards out of its cavity.
Open the door a little way and take it
out downwards.
Unscrew the upper pin (A) and srew it
into place on the opposite side.
Fit the door into the upper pin (A)
and close it.
Insert the pin of the door bearing (1)
into the left hand cavity and screw
the bearing firmly into place with the
screws (K).
☞
☞
☞
☞
☞
☞
48
A
K
1
A
12
Unscrew the handle. Refit it on the opposite side after having pierced the plugs
with a punch. Cover the holes left open
with the plugs contained in the documentation pack.
Prior to Initial Start–Up
Please clean the appliance interior and all accessories prior to initial
start-up (see section: “Cleaning and Care”).
Plug socket
The plug socket necessary for connection of your appliance to the
electricity supply should be positioned so that it is possible to pull out
the appliance plug.
If your appliance is installed under a
continuous worktop, the plug socket
should be provided as shown.
A concealed protective contact plug
socket requires 10 A/16 A fusing.
If the socket is not accessible once the
appliance is built in, the electrical
installation must include suitable
means of isolating the appliance from
the mains (e.g. fuse, cut-out, current
trip or similar with a minimum
contact separation of 3 mm).
☞
☞
49
130
300
Description of the appliance
View of the appliance
➆
➅
➀
➁
➂
➇
➄
➃
Butter/cheese compartments with flap and egg storage insert
➀
Door storage compartment with retaining rail
➁
Door storage compartment
➂
Bottle shelf
➃
Vegetable baskets
➄
Storage shelves
➅
Temperature regulator and light switch
➆
Rating plate
➇
50
Starting up and temperature regulation
Insert the plug of the connection lead into the plug socket with protective earth contact. When the refrigerator compartment door is
opened, the internal lighting is switched on.
The temperature selector knob is located on the RH side of the refrigerator
compartment.
Setting „0“ means: Off.
Turning clockwise in direction „1“:
Refrigerating unit on, the latter
then operating automatically.
Setting „1“ means:
Hightest temperature, warmest setting.
Setting „6“ (end-stop) means:
Lowest temperature, coldest setting.
At a low ambient temperature of around 16°C, setting „1“ should be
selected. At ambient temperatures of around 25°C, select setting „2“.
If you require a lower temperature, select setting „3“ or „4”.
Important!
High ambient temperatures (e.g. on hot summer days) and a cold setting on the temperature regulator (position"5" to "6") can cause the
compressor to run continuously.
Reason: when the ambient temperature is high, the compressor must
run continuously to maintain the low temperature in the appliance.
The fridge will not be able to defrost since automatic defrosting of
the fridge is only possible when the compressor is not running (see
also "Defrosting" section). The result is the build up of a thick layer of
frost on the fridge rear wall.
If this happens, turn the temperature regulator back to a warmer setting (position "3" to "4"). At this setting the compressor will be switched on and off as usual and automatic defrosting recommenced.
☞
51
Interior Accessories
Storage shelves/wire trays
Various glass or plastic storage shelves and wire trays are included
with your appliance - different models have different combinations.
You should always slide one of the full size glass storage shelf into
the lowest set of guides, above the fruit and the vegetable containers,
and keep it in this position.
The height of the storage shelves can be adjusted:
To do this pull the storage shelf forward until it can be swivelled
upwards or downwards and removed.
Please do the same in reverse to insert the shelf at a different height.
VARIO glass storage shelf
Your appliance is equipped with two
half size glass storage shelves.
Storing tall items:
Slide the front half of the Vario storage shelf in another level to the rear.
By this means you will gain space to
place tall items on the storage shelf
below.
Variable door interior
Depending on your requirements, the storage compartments on the
door can be removed and repositioned in a different place.
☞
☞
☞
☞
52
53
Correct storage
➀ Butter and cheese
➁ Eggs, tubes, preserves
➂ Drinks
➃ Cheese storage, fruit, and
vegetables
➄ Meat, salami, cold cuts, dairy
produce
➅ Ready meals, pastries, preser-
ves
The length of storage time depends on the type of food – see manufacturer’s instructions.
Tip: Food in the fridge should always be covered or packaged, to prevent drying and tainting of other food.
The following are suited for packaging:
– Polyethylene airtight bags and wraps;
– Plastic containers with lids;
– Special plastic covers with elastic;
– aluminium foil.
Defrosting
The fridge defrosts automatically
The rear wall of the fridge covers with frost when the compressor is
running, and defrosts when the compressor is off.
The water from the thawing frost evaporates by itself.
➀
➁
➁
➂
➃
➄
➄
➅
➅
54
Switching off the appliance
To switch off the appliance, turn the temperature regulator to position
"0".
If the appliance is not going to be used for an extended period:
Remove all refrigerated packages.
Switch off the appliance by turning the temperature regulator to
position "0".
Remove the mains plug or switch off or turn out the circuit breaker or
fuse.
Clean thoroughly (see section: “Cleaning and Care”).
Leave the door open to avoid the build up of odours.
Cleaning and Care
For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly.
Warning!
• The appliance may not be connected to the mains during cleaning.
Danger of electrical shock! Before cleaning switch the appliance off
and remove the plug from the mains, or switch off or turn out the
circuit breaker or fuse.
• Never clean the appliance with a steam cleaner. Moisture could
accumulate in electrical components, danger of electrical shock! Hot
vapours can lead to the damage of plastic parts.
• The appliance must be dry before it is placed back into service.
Attention!
• Ethereal oils and organic solvents can attack plastic parts, e.g.
– lemon juice or the juice from orange peals;
– butyric acid;
– cleansers which contain acetic acid.
Do not allow such substances to come into contact with appliance
parts.
• Do not use any abrasive cleansers.
Remove the food from the refrigerator. Store it in a cool place, well
covered.
☞
☞
☞
☞
☞
☞
☞
55
Switch the appliance off and remove the plug from the mains, or
switch off or turn out the circuit breaker or fuse.
Clean the appliance and the interior accessories with a cloth and lukewarm water. Commercially available dish washing detergents may also
be used.
After cleaning wipe with fresh water and rub dry.
Accumulation of dust at the condenser increases energy consumption.
For this reason carefully clean the condenser at the back of the appliance once a year with a soft brush or a vacuum cleaner.
Check the water drain hole on the rear
wall of the fridge. Clear a blocked drain
hole with the aid of the green peg in
the pack of accessories included with
the appliance.
After everything is dry place appliance
back into service.
Energy Saving Tips
• Do not install the appliance near cookers, radiators or other sources
of warmth. High ambient temperatures cause longer, more frequent
operation of the compressor.
• Ensure sufficient air circulation and exhaust at the appliance base
and at the back wall of the appliance. Never cover air vent ope
nings.
• Do not place warm foods into the appliance. Allow warm foods to
cool first.
• Only leave door open as long as necessary.
• Do not set temperature any colder than necessary.
• Keep the heat emitting condenser, the metall grille on the rear wall
of your appliance, always clean.
☞
☞
☞
☞
☞
56
What to do if ...
Correcting Malfunctions
Spare parts:
Minor repairs you can carry out yourself, spare parts can be ordered
from the service centre. You can fit these yourself without any special
skill or training, e.g.:
– butter/cheese compartment,
– egg holders,
– door racks,
– fruit and vegetable drawers,
– storage racks
A malfunction may be caused by only a minor fault that you can rectify yourself using the following instructions. Do not perform any
other work on the appliance if the following information does not
provide assistance in your specific case.
Warning! Repairs to refrigerators/freezers may only be performed by
qualified service engineers. Improper repairs can give rise to significant
hazards for the user. If your appliance needs repairing, please contact
your specialist dealer or our Customer Service.
Malfunction
Appliance does not work.
Possible Cause
Appliance is not switched
on.
Mains plug is not plugged
in or is loose.
Fuse has blown or is defective.
Socket is defective.
Mains malfunctions are to
be corrected by an electrician.
Remedy
Switch on the appliance.
Insert mains plug.
Check fuse, replace if
necessary.
Appliance cools too much. Temperature is set too cold.
Turn the temperature regulator to a warmer setting
temporarily.
57
Malfunction
The food is too warm.
Possible Cause
Carefully warm the leaking
sections of the door seal
with a hair dryer (not hotter than approx. 50 °C).
At the same time shape the
warmed door seal by hand
such that it sits correctly.
Door seal is not air tight
(possibly after changing
over the hinges).
Heavy build up of frost,
possibly also on the door
seal.
Remedy
Temperature is not properly
adjusted.
Please look in the "Initial
Start Up" section.
Door was open for an
extended period.
Open the door only as long
as necessary.
A large quantity of warm
food was placed in the
appliance within the last
24 hours.
Turn the temperature regu-
lator to a colder setting
temporarily.
The appliance is near a
heat source.
Please look in the
"Installation location"sec-
tion.
Light bulb is defective.
Please look in the
"Changing the Light Bulb”.
Interior lighting does not
work.
Unusual noises.
Appliance is not level.
The appliance is touching
the wall or other objects.
A component, e.g. a pipe,
on the rear of the appliance is touching another part
of the appliance or the
wall.
Readjust the feet.
Move the appliance slight-
ly.
If necessary, carefully bend
the component out of the
way.
Water on the floor or on
storage shelves.
Water drain hole is
blocked.
See the "Cleaning and
Care" section.
This is normal, no error has
occurred.
The compressor starts after
a period of time.
The compressor does not
start immediately after
changing the temperature
setting.
Changing the light bulb
Warning! There is a risk of electric shocks! Before changing the light
bulb, switch off the appliance and unplug it, or pull the fuse or the
circuit breaker.
Light bulb data: 220-240 V, max. 15 W
To switch off the appliance, turn the temperature regulator to positi-
on "0".
Unplug the mains plug.
To change the light bulb, undo the
screw.
Press the light bulb cover as shown
and slide it backwards.
Change the defective light bulb.
Refit the light bulb cover and the
screw.
Put the refrigerator back into operation.
☞
☞
☞
☞
☞
☞
☞
58
Customer Service
If you cannot find the remedy for a malfunction in these operating
instructions, please contact your dealer or our customer service
department. Addresses and telephone numbers are listed in the
accompanying booklet "Guarantee Conditions/Customer Service
Locations".
Selective ordering of replacement parts can save unnecessary travel
and costs. For this reason always provide the following appliance
information:
• Model Name
• Model Number (PNC)
• Serial Number (S-No.)
This information can be found on the serial plate in the interior at the
left of the appliance. We recommend that you enter this information
here, so that it is handy if needed.
Note: The customer bears the costs of unjustified customer service
calls even during the guarantee period.
59
Noises during Operation
The following noises are characteristic of refrigeration appliances:
•
Clicks Whenever the compressor switches on or off, a click can
be heard.
• Humming As soon as the compressor is in operation, you can hear
it humming.
•
Bubbling/ When refrigerant flows into thin tubes, you can hear
Splashing bubbling or splashing noises. Even after the compressor
has been switched off, this noise can be heard for a
short time.
Regulations, Standards, Guidelines
This appliance was designed for household use and was manufactured
in accordance with the appropriate standards. The necessary measures
in accordance with appliance safety legislation regulations (GSG), accident prevention regulations for refrigeration appliances (VBG 20) and
the regulations of the German Society of Electrical Engineers (VDE)
were observed in the manufacture of this appliance.
The refrigerant circuit has been checked for leaks.
This appliance is in accordance with the following EU guidelines:
– 73/23/EWG dated 19 February 1973 - low voltage guidelines.
– 89/336/EWG dated 3 May 1989
(including guideline change notice 92/31/EWG) - EMV guideline
60
Technical terminology
• Refrigerant
• Refrigerant
Circuit
• Evaporator
• Compressor
• Condenser
Liquids that can be used to a generate a cooling
effect are known as refrigerants. They have a relatively low boiling-point, indeed so low, that the
warmth from the food stored in the fridge or freezer can cause the refrigerant to boil and vaporise.
Closed circulation system that contains the refrigerant. The refrigerant circuit comprises primarily of
an evaporator, a compressor, a condenser and pipe
work.
The refrigerant is evaporated in the evaporator.
Similar to all other liquids, refrigerant requires heat
to evaporate. This heat is removed from the interior
of the appliance, as a result the interior is cooled.
The evaporator is therefore located inside the appliance or placed in foam immediately behind the
inner wall and thus not visible.
The compressor looks like a small drum. It is driven
by a built-in electric motor and is mounted on the
base of the appliance at the rear. The task of the
compressor is to draw in vaporised refrigerant from
the evaporator, to compress it, and to pass it on to
the condenser.
The condenser normally has the form of a grid. The
refrigerant compressed in the compressor is liquefied in the condenser. During this process, heat is
released to the surrounding air at the surface of the
condenser. The condenser is mounted on the base of
the appliance.
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
© Copyright by AEG
01-0200
2222 618-22
Loading...
