Thank you for choosing an Electrolux Cycloniclite vacuum cleaner. These
operating instructions cover all Cycloniclite models. This means that with
your specific model, some accessories may not be included.

Accessories and safety precautions 3
Before starting 4
Getting the best results 4
Emptying the dust container 5
Cleaning/Replacing the motor filter, exhaust filter and
cartridge filter 5
Cleaning the hose and nozzle 6
Troubleshooting and customer information 7

3

ACCESSORIES AND SAFETY PRECAUTIONS

Accessories

1. Cartridge filter

2. Telescopic extension tube (Z7118)

3. Metal extension tubes (Z7108)

4. Hose

5. Hose handle with suction control

6. Dual purpose floor nozzle

7. Upholstery nozzle with plush plate

8. Crevice nozzle

9. Dusting brush

10. Caddy

Safety precautions

The Cycloniclite should only be used by adults for normal vacuuming in a
domestic environment. The vacuum cleaner features double insulation
and does not need to be earthed.

Never vacuum:

• In wet areas

• Close to flammable gas, etc.

• Without filters (this may damage the cleaner). A safety device is fitted
which prevents the dust container closing without a cartridge filter in
place. Do not attempt to force the dust container shut.

Never vacuum:

• Sharp objects

• Fluids (this can cause serious damage to the machine)

• Hot or cold cinders, lit cigarette butts, etc.

• Fine dust from plaster, concrete, flour or ash, for example.

The above can cause serious damage to the motor - damage which is not
covered by the warranty.

Electrical cable precautions:

• A damaged cable must be replaced by an authorised Electrolux service
engineer. Damage to the cleaner cable will not be covered by the war­ranty.

• Never pull or lift the vacuum cleaner by the cable.

• Disconnect the plug from the mains before cleaning or maintenance of
the vacuum cleaner.

• Regularly check that the cable is not damaged. Never use the vacuum
cleaner if the cable is damaged.

All service and repairs must be carried out by an authorised Electrolux serv­ice engineer. Always keep the vacuum cleaner in a dry place.
