USER MANUAL

LFR8W8140BI

EN User Manual

Washing Machine

My AEG Care app

www.aeg.com2

1. SAFETY INFORMATION......................................................................................3

2. SAFETY INSTRUCTIONS.................................................................................... 5

3. PRODUCT DESCRIPTION...................................................................................7

4. TECHNICAL DATA............................................................................................... 8

5. INSTALLATION.....................................................................................................9

6. CONTROL PANEL..............................................................................................19

7. DIAL AND BUTTONS......................................................................................... 21

8. PROGRAMMES..................................................................................................24

WI-FI - CONNECTIVITY SETUP................................................................... 30

10. SETTINGS........................................................................................................ 32

11. BEFORE FIRST USE........................................................................................33

12. DAILY USE....................................................................................................... 33

13. HINTS AND TIPS..............................................................................................38

14. CARE AND CLEANING.................................................................................... 40

15. TROUBLESHOOTING......................................................................................46

16. CONSUMPTION VALUES................................................................................50

17. ENVIRONMENTAL CONCERNS......................................................................52

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information:

www.aeg.com/support

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number. The information can be found on the rating plate.

Warning / Caution-Safety information General information and tips Environmental information

ENGLISH 3

Subject to change without notice.

1. SAFETY INFORMATION

Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

1.1 Children and vulnerable people safety

• This appliance can be used by children aged from 8

years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

www.aeg.com4

• Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised.

• Children of less than 3 years of age should be kept

away from the appliance unless continuously supervised.

• Children should be supervised to ensure that they do

not play with the appliance.

• Keep all packaging away from children and dispose of

it appropriately.

• Keep detergents away from children.

• Keep children and pets away from the appliance when

the door is open.

• If the appliance has a child safety device, it should be

activated.

• Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

• This appliance is for washing domestic-type, machine-

washable laundry only.

• This appliance is designed for single household

domestic use in an indoor environment.

• This appliance may be used in, offices, hotel guest

rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels.

• Do not change the specification of this appliance.

• The appliance maximum load is 8.0 kg. Do not exceed

the maximum load of each programme (refer to the “Programmes” chapter).

• The operating water pressure at the water entry point

from the outlet connection must be between 0.5 bar (0.05 MPa) and 10 bar (1.0 MPa).

• The ventilation opening in the base must not be

covered by a carpet, mat, or any floor covering.

• The appliance must be connected to the water mains

using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre.

• Old hose sets must not be reused.

• If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.

• Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the socket.

• Do not use high pressure water sprays and/or steam

to clean the appliance.

• Clean the appliance with a moist cloth. Use only

neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.

2. SAFETY INSTRUCTIONS

ENGLISH 5

2.1 Installation

The installation must comply with relevant national regulations.

• Remove all the packaging and the

transit bolts including rubber bush with plastic spacer.

• Keep the transit bolts in a safe place.

If the appliance is to be moved in the future they must be reattached to lock the drum to prevent an internal damage.

• Always take care when moving the

appliance as it is heavy. Always use safety gloves and enclosed footwear.

• Follow the installation instructions

supplied with the appliance.

• Do not use the appliance before

installing it in the built-in structure due to safety manner.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature can be less than 0°C or where it is exposed to the weather.

• The floor area on which the appliance is to be installed must be flat, stable, heat resistant and clean.

• Make sure that there is air circulation between the appliance and the floor.

• When the appliance is in its permanent position, check if it is levelled correctly with the aid of a spirit level. If it is not, adjust the feet accordingly.

• Do not install the appliance directly above a floor drain.

• Do not spray water on the appliance and do not expose it to excessive humidity.

• Do not install the appliance where the appliance door cannot be fully opened.

• Do not put a closed container to collect possible water leakage under the appliance. Contact the Authorised Service Centre to ensure which accessories can be used.

www.aeg.com6

2.2 Electrical connection

WARNING!

Risk of fire and electric shock.

• WARNING: This appliance is designed to be installed / connected to a grounding connection in the building.

• Always use a correctly installed shockproof socket.

• Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.

• Do not use multi-plug adapters and extension cables.

• Make sure not to cause damage to the mains plug and to the mains cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre.

• Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.

• Do not touch the mains cable or the mains plug with wet hands.

• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

of the appliance with the use of water in the factory.

• You can extend the drain hose to maximum 400 cm. Contact the Authorised Service Centre for the other drain hose and the extension.

• Make sure that there is access to the tap after the installation.

2.4 Use

WARNING!

Risk of injury, electric shock, fire, burns or damage to the appliance.

• Follow the safety instructions on the detergent packaging.

• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

• Do not wash fabrics which are heavily soiled with oil, grease or other greasy substances. It can damage rubber parts of the washing machine. Prewash such fabrics by hand before loading them into the washing machine.

• Do not touch the glass door while a programme operates. The glass can get hot.

• Make sure that all metal objects are removed from the laundry.

2.3 Water connection

• The inlet water shall not exceed 25 °C.

• Do not cause damage to the water hoses.

• Before connection to new pipes, pipes not used for a long time, where repair work has been carried out or new devices fitted (water meters, etc.), let the water flow until it is clean and clear.

• Ensure that there are no visible water leaks during and after the first use of the appliance.

• Do not use an extension hose if the inlet hose is too short. Contact the Authorised Service Centre for the replacement of the inlet hose.

• When unpacking the appliance, It is possible to see water flowing from the drain hose. This is due to the testing

2.5 Service

• To repair the appliance contact the Authorised Service Centre. Use original spare parts only.

• Please note that self-repair or nonprofessional repair can have safety consequences and might void the guarantee.

• The following spare parts will be available for 10 years after the model has been discontinued: motor and motor brushes, transmission between motor and drum, pumps, shock absorbers and springs, washing drum, drum spider and related ball bearings, heaters and heating elements, including heat pumps, piping and related equipment including hoses, valves, filters and aquastops, printed circuit boards, electronic displays, pressure switches, thermostats and sensors, software and firmware

ENGLISH 7

including reset software, door, door hinge and seals, other seals, door locking assembly, plastic peripherals such as detergent dispensers. Please note that some of these spare parts are only available to professional repairers, and that not all spare parts are relevant for all models.

• Concerning the lamp(s) inside this product and spare part lamps sold separately: These lamps are intended to withstand extreme physical conditions in household appliances, such as temperature, vibration, humidity, or are intended to signal information about the operational status of the appliance. They are not intended to be used in other applications and are not suitable for household room illumination.

3. PRODUCT DESCRIPTION

3.1 Special features

Your new washing machine meets all modern requirements for an effective treatment of laundry with low water, energy and detergent consumption and proper care of fabric.

• The Wi-Fi connection and Remote Start enable you to start a cycle, to interact with your washing machine and to check the washing cycle status in remote control.

• The OkoMix technology has been designed to protect the fabric fibres thanks to different pre-mixing phases that dissolves first the detergent and then fabric softener in the water before they are distributed in the laundry. So every fibre is reached and cared for.

• The steam has a quick and easy way to refresh the clothes. The gentle steam programmes remove odours and reduce creases in dry fabrics so they need little ironing. The Plus Steam option, finishes every cycle with gentle steam that

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the mains electrical and water supplies.

• Cut off the mains electrical cable close to the appliance and dispose of it.

• Remove the door catch to prevent children or pets from becoming trapped in the drum.

• Dispose of the appliance in accordance with local requirements for the disposal of Waste Electrical and Electronic Equipment (WEEE).

relaxes the fibres and reduces fabric creasing. Ironing will be easier!

• Thanks to the Soft Plus option, the fabric softener is uniformly spread out in the laundry and deeply penetrates the fabric fibres favouring a perfect softness.

• The ProSense System detects the laundry load size defining the programme duration in 30 seconds. The washing programme is tailored to the laundry load and the type of fabric without consuming more time, energy and water than necessary.

• The AEG Steam Fragrance, thanks to the steam programmes offers the perfect solution for refreshing even the most delicate garments without washing. Use the delicate fragrance exclusively developed by AEG to add a pleasant feeling of "just-washed" garment to the removing odours and wrinkles action.

11 12

21 3

00000000

00A

Mod.

xxxxxxxxx

000V ~ 00Hz 0000 W

910000000

Prod.No.

B C D EA

www.aeg.com8

3.2 Appliance overview

Hinge supports

Detergent dispenser

Control panel

Magnetic plate

Door handle

Rating plate

Plate with rubber beater

4. TECHNICAL DATA

Dimension Width/ Height/ Total depth 59.6 cm /81.9 cm /55.3 cm

Electrical connection Voltage

Level of protection against ingress of solid particles and moisture ensured by the protective cover, except where the low voltage equipment has no protection against mois‐ ture

Overall power Fuse Frequency

Drain pump filter

Front feet for levelling the appliance

Drain hose

Mains cable

Inlet hose connection

Back feet for levelling the appliance

The rating plate reports:

QR code

A. B. model name C. product number D. electrical ratings E. serial number

230 V 2100 W 10 A 50 Hz

IPX4

x1 x2

x4 x1 x1

BA C D

F G H L

ENGLISH 9

Water supply pressure Minimum

Water supply

Maximum Load Cotton 8.0 kg

Spin Speed Maximum spin speed 1351 rpm

1) Connect the water inlet hose to a water tap with a

5. INSTALLATION

WARNING!

Refer to Safety chapters.

5.1 Be prepared for

installation

It is recommended that installation is carried out by two persons.

Maximum

0.5 bar (0.05 MPa) 10 bar (1.0 MPa)

Cold water

3/4'' thread.

5.2 The appliance is equipped with ...

5.3 Unpacking

WARNING!

Use the gloves.

WARNING!

Remove all the packaging and the transit bolts before installing the appliance.

www.aeg.com10

1. Put two polystyrene packaging elements on the floor under the appliance.

WARNING!

It is strongly recommended that this action is carries out by two persons.

2. Carefully put the appliance down on its rear side.

Make sure not to damage the hoses.

3. Remove the polystyrene protection from the bottom.

4. Return the appliance in vertical position and remove the socket polystyrene protection.

5. Remove the power supply cable and the drain hose from the hose holders.

It is possible to see water flowing from the drain hose. This is due to the testing with water of the appliance in factory.

We recommend that you keep the packaging and the transit bolts for any

movement of the appliance.

5.4 Positioning and levelling

ENGLISH 11

6. Remove the three bolts, the hose holders and plastic spacers by using the spanner supplied with the appliance.

7. Close the holes with the plastic caps you find in the user manual bag. Put the smallest cap F in upper hole and the two bigger caps G in lower holes.

1. Install the appliance on a flat hard floor.

WARNING!

Make sure that carpets do not stop the air circulation below the appliance.

Bring the appliance near the furniture recess before levelling it. For more details, refer to paragraph "Building in".

2. Loosen or tighten the feet to adjust the level.

A correct adjustment of the appliance level prevents the vibration, noise and the movement of the appliance when in operation.

1100 mm 1450 mm

960 mm1230 mm

900 mm

1360 mm

max 1000 mm

min. 600 mm

max 1000 mm

min. 600 mm

www.aeg.com12

5.5 Hose and cable connection

The appliance must be level and stable.

CAUTION!

Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.

The inlet hose

1. Remove the inlet hose from inside the

drum.

2. To connect the water inlet hose towards the proper direction and with the proper inclination, check the position of the water tap before connecting it to the back of the appliance.

Make sure the hose is nor kinked, squashed but neither tensed.

20O20

45O45

3. Connect the hose to the back of the

Ø 40 mm

appliance. Do not turn the inlet hose downwards, but turn it left or right depending on the position of your water tap.

4. Loosen the ring nut to fix it in the correct position.

5. Connect the water inlet hose to the cold water tap with 3/4 thread.

Use the hose supplied with appliance.

ENGLISH 13

WARNING!

The inlet water shall not exceed 25 °C.

WARNING!

Make sure that there are no leaks from the couplings.

Do not use an extension hose if the inlet hose is too short. Contact the Authorised Service Centre for an inlet hose replacement.

Water drainage

The drain hose can be connected:

To a stand pipe with vent-hole

Directly into a drain pipe at a height of not less than 60 cm (23.6”) and not more than 100 cm (39.3”). The end of the drain hose must always be ventilated , i.e. the inner diameter of the drain pipe (min. 40 mm - min. 1.6”) must be larger than the external diameter of the drain hose.

max.

600 mm

min.

820 mm

min.

560 mm

16-22 mm

min.

553 mm

596 mm

140 mm

76 mm

50 mm

819 mm

www.aeg.com14

You can extend the drain hose to maximum 400 cm. Contact the service centre for the other drain hose and the extension.

5.6 Building in

To a sink spigot

Put the drain hose in the spigot and tighten it with the supplied cable tie L. Make sure that the drain hose makes a loop to prevent particles going into the appliance from the sink.

To a wall-pipe

Directly to a built-in drain pipe in the room wall and tighten it with the supplied cable tie L.

This appliance has been designed to be built into the kitchen furniture. See the minimum recess dimensions in the drawings.

If hoses run behind the appliance, make sure that nothing closes the small recess indicated with the measures 50 x 50 mm.

The appliance is also equipped with an adhesive sponge pad H that you can find inside the drum. Attach it on the top of the appliance where indicated in the drawing. When levelling the appliance under the furniture, DO NOT squeeze the sponge pad.

Before proceeding with appliance building in, bring it near the recess and preposition the inlet hose, the drain hose and the mains cable.

WARNING!

Make sure they are not kinked or squashed.

5.7 Preparation and assembly of the cupboard door

ENGLISH 15

The dimensions of the cupboard door should be:

• width min. 595 - max. 598 mm;

• thickness 16-22 mm.

Factory pre setting

The appliance is originally pre set for the assembly of a cupboard door opening from right to left.

The best solution would be to screw the upper hinge to the upper hole of the top plate and the lower hinge to the lower hole of the bottom plate.

www.aeg.com16

Reversibility of the cupboard door

Carry out the cupboard door reversibility before the appliance is built in completely.

If the cupboard door has to be opened from left to right, invert the position of the hinge supports M with the magnetic plate N and lower plate O.

Make sure that the plate with magnet is on the upper position.

Cupboard door preparation

For countersinking the door, it is recommended to call a professional.

Align the cupboard door to the furniture correctly. Measure the distance X to fix the height of the hole to countersink the upper hinge. The centre of the hole Y should be at the same height of the stroke on the hinge support.

16-22 mm

22±1,5 mm

449 mm

595-598 mm

Ø 35 mm

12,5 - 14 mm

max. 105°

ENGLISH 17

Set the position of the lower hole respecting dimensions and distances shown in the drawing (449 mm). Countersink the holes.

Hinges

To mount the hinges it is necessary to drill two holes (dia. 35 mm, depth 12.5 - 14 mm depending on the depth of cupboard door) on the inner side of the door. The hinges will be fixed to the door by means of the four supplied screws A.

To align the door perfectly, make sure that the edge of cupboard door is parallel with the appliance edge and to respect the proper opening angle (max. 105 °).

Mounting the door

Fix the hinges to the hinge supports on the appliance by means of the two supplied screws B.

The hinges can be adjusted to compensate for possible uneven thickness of the door.

www.aeg.com18

Counter-magnet

The appliance is pre set for a magnetic closure. For a correct closure:

1. Position the screw C and the countermagnet D on the magnetic plate N. Lean the cupboard door against the screw until it leaves a mark.

2. Open the cupboard door and screw the counter-magnet D (steel disk + rubber ring E) with the screw C in the inner side of the cupboard door, where the screw left the mark as described in the first step.

Flexible machine stopper

The supplied plastic stopper can be only installed when the appliance installation is complete, to avoid movement outward. Fix it on the furniture, near the front panel taking as reference height the middle of the door, on the opposite

side of the hinges.

5.8 Electrical connection

At the end of installation you can connect the mains plug to the mains socket.

The rating plate and the 'Technical Data' chapter indicate the necessary electrical ratings. Make sure that they are compatible with the mains power supply.

Check that your domestic electrical installation can take the maximum load

The power supply cable must be easily accessible after installing the appliance.

For any electrical work required to install this appliance, contact our Authorised Service Centre.

The manufacturer does not accept any responsibility for damage or injury through failure to comply with the above safety precaution.

required, also taking into account any other appliances in use.

Connect the appliance to an earthed socket.

6. CONTROL PANEL

1 2 3 4 5 6 7

13 12 11 10 9 8

MIX

6.1 Control panel description

ENGLISH 19

Programme dial

Spin touch button

Temperature touch button

Display

Delay Start touch button

and Remote Start function Time Save touch button

6 7

Start / Pause touch button

Plus Steam touch button and

permanent Child Lock option Soft Plus touch button

Extra Rinse touch button

Stains touch button

On/Off push button

Prewash touch button

6.2 Display

MIX

www.aeg.com20

The Temperature area:

Temperature indicator .

Cold water indicator.

Child safety lock indicator.

Wi-Fi connection indicator.

Remote Start indicator.

Door locked indicator.

Delay start indicator.

The digital indicator can show:

• Programme duration (e. g. ).

• Delay time (e. g. ).

•

Cycle end (

• Warning code (e.g. ).

•

Error indicator (

When working with the APP:

•

, (access point), (update). Please refer to the chapter 'Wi-FI - Connectivity se‐ tup'.

•

Indication of total operating hours of the appliance. Refer to the 'Operating hours counter' section in the 'Settings' paragraph for more details.

Time Save indicator.

OkoMix indicator.

Steam phase indicator.

Anti-crease phase indicator.

Drum clean indicator. This is a recommendation to perform the drum cleaning.

The spin area: Spin speed indicator

No Spin indicator. Spin phase is off.

Silent indicator.

Rinse Hold indicator.

Add garments indicator. It lights at the beginning of the washing phase, when it is still possible to pause the appliance and add more laundry.

Maximum load indicator (refer to "The ProSense System load de‐ tection " paragraph).

It flashes when the laundry load exceeds the maximum de‐

clared load of the selected programme.

7. DIAL AND BUTTONS

ENGLISH 21

7.1 Introduction

The options/functions are not available with all washing programmes. Check the compatibility between options/functions and washing programmes in the "Programme Chart". An option/function can exclude another one, in this case the appliance doesn't allow you to set incompatible options/ functions.

7.2 On/Off

Press this button for a few seconds to activate or deactivate the appliance. Two different tunes sound while switching the appliance on or off.

As the Stand-by function automatically deactivates the appliance after several minutes to reduce the energy consumption, you may need to activate the appliance again.

For more details, refer to Stand-by paragraph in Daily Use chapter.

7.3 Programme dial

For selecting the desired washing programme. Refer to 'Programmes' chapter for more details.

The position is a "Reset" function, which stops and resets the running programme. The display shows empty dashes to indicate that no programme was selected.

7.4 Temperature

When you select a washing programme, the appliance automatically proposes a default temperature.

Touch this button repeatedly until the desired temperature value appears on the display.

When the display shows the indicators

, the appliance does not heat the

water.

7.5 Spin

When you set a programme, the appliance automatically sets the programme's default spin speed. With this option you can decrease the default spin speed.

Touch repeatedly this button to:

• Decrease the spin speed. The display shows only the spin speeds available for the set programme.

• Additional spin options No Spin

. Set this option to deactivate all spin phases. The appliance performs the only draining phase of the selected washing programme. Set this option for very delicate fabrics. The rinses phase uses more water for some washing programmes

• Activate the Rinse Hold The final spin is not performed. The water of the last rinse is not drained out to prevent the fabrics from creasing. The washing programme ends with water in the drum.

The indicator remains displayed. The door stays locked and the drum turns regularly to reduce creasing. You must drain the water to unlock the door.

If you touch the Start / Pause button, the appliance performs the spinning phase and drains the water.

option.

www.aeg.com22

The appliance empties the water out automatically after 18 hours approximately.

• Activate the Silent option. The intermediate and the final spinning phases are suppressed and the programme ends with water in the drum. This helps to reduce creasing.

The indicator remains displayed. The door stays locked. The drum turns regularly to reduce creasing. You must drain the water to unlock the door. As the programme is very quiet, it is suitable for use at night time when cheaper electricity tariffs are available. In some programmes the rinses are performed with more water.

If you touch the Start / Pause button, the appliance performs the only draining phase.

The appliance empties the water out automatically after 18 hours approximately.

7.6 Prewash

With this option you can add a prewash phase to a washing programme.

The corresponding indicator above the touch button illuminates.

• Use this option to add a pre-wash phase at 30 °C before the washing phase. This option is recommended for heavily soiled laundry, especially if containing sand, dust, mud and other solid particles.

The options can increase the programme duration.

7.7 Stains

Touch this button to add the stain phase to a programme.

The corresponding indicator above the touch button illuminates.

Use this option for laundry with hard stains to remove.

When you set this option, put the stain

remover into compartment .

The stain remover is pre-mixed and heated with detergent in order to improve its effectiveness.

This option increases the programme duration. This option is not available with a temperature lower than 40 °C.

7.8 Permanent Extra Rinse

With this option you can add a few rinses according to the selected washing programme.

Use this option for people with allergies to detergent residues and with sensitive skin.

This option increases the programme duration.

The corresponding indicator above the touch button illuminates and also stays permanently on during next cycles until this option is deactivated.

7.9 Permanent Soft Plus

Set this option to optimise the fabric softener distribution and improve fabric softness.

Recommended when you use fabric softener.

This option increases the programme duration.

The corresponding indicator above the touch button illuminates and also stays permanently on during next cycles until this option is deactivated.

7.10 Plus Steam

This option adds a steam phase followed by a short anti-crease phase at the end of the washing programme.

The steam phase reduces fabric creasing and facilitates the fabric ironing.

The corresponding indicator above the touch button illuminates.

ENGLISH 23

The indicator is steady on during steam phase.

This option can increase the programme duration.

When the programme stops the display

shows

, the indicator goes off

and the indicator and the Start /

Pause led are steady on. The drum performs smooth movements for about 30 minutes to keep the steam benefit. By touching any button the anti-crease movements stop and the door unlocks, the appliance proposes again the previous set programme.

To interrupt the anti-crease phase, you can also:

• Press the On/Off button for a few seconds to activate or the deactivate the appliance.

• Turning the programme dial in another position.

A small laundry load helps to reach better results.

7.11 Child Lock

With this option you can prevent children from playing with the control panel.

• To activate/deactivate this option, hold down the Plus Steam button until

comes on/goes off on the

display.

The appliance will default to this option after you switch it off.

7.12 Delay Start

With this option you can delay the start of a programme to a more convenient time.

Touch the button repeatedly to set the required delay. The time increases in steps of 1 hour up to 20 hours.

The display shows the indicator and the selected delay time. After touching

the Start / Pause button, the appliance begins the countdown and the door is locked.

7.13 Time Save

With this option you can reduce the programme duration depending on the load size and the degree of soiling.

When you set a washing programme, the display shows the default duration and

dashes.

Touch Time Save button to reduce the programme duration according to your needs. The display shows the new programme duration and a number of dashes will decrease accordingly:

suitable for a full load of normally

soiled garments.

a quick cycle for a full load of lightly

soiled garments.

very quick cycle for a smaller lightly soiled load (max. half load recommended).

the shortest cycle to freshen up a small amount of laundry.

The Time Save is available only with the programmes in the table.

indicator

Cottons

Default duration for all programmes.

■ ■

Time Save with steam programmes

When setting a steam programme, this button allows to chose three steam levels and the programme duration is reduced accordingly:

Synthetics

www.aeg.com24

• : maximum.

• : medium.

• : minimum.

8. PROGRAMMES

8.1 Programme Chart

Programme Default tem‐ perature Temperature range

Washing programmes

Eco 40-60

40 °C

Cottons 40 °C 90 °C - Cold

Synthetics 40 °C 60 °C - Cold

Delicates 30 °C 40 °C - Cold

OKOPower 30 °C 60 °C - 30 °C

Reference spin speed Spin speed range

1400 rpm (1400- 400 rpm)

1200 rpm (1200 - 400 rpm)

1200 rpm (1200- 400 rpm)

1400 rpm (1400- 400 rpm)

7.14 Start / Pause

Touch the Start / Pause button to start, pause the appliance or interrupt a running programme.

Maxi‐

mum

load

8.0 kg White cotton and fast-coloured cotton. Nor‐ mally soiled items. The energy consumption de‐ creases and the time of the washing programme is extended, ensuring good washing results.

8.0 kg White cotton and coloured cotton. Normally, heavily and lightly soiled items.

3.0 kg Synthetic items or mixed fabric items. Nor‐ mally soiled items.

2.0 kg Delicate fabrics such as acrylics, viscose and mixed fabrics requiring gentler washing. Nor‐ mally and lightly soiled items.

4.0 kg Cotton and fast-coloured synthetic items. Complete washing programme that, in only 59 minutes, washes the daily soiled laundry inten‐ sively and ensures a good washing performance in a short time.

Programme description

(Type of load and level of soiling)

Steam programme

ENGLISH 25

Programme Default tem‐ perature Temperature range

Reference spin speed Spin speed range

Maxi‐

1.0 kg Cotton, synthetic and mixed items. Special

Steam

Special programmes

Spin/Drain 1400 rpm

8.0 kg All fabrics, except woollens and delicate fab‐ (1400 - 400 rpm)

Rinse 1400 rpm

8.0 kg All fabrics, except woollens and very delicate (1400- 400 rpm)

Additional washing programmes

Programme description

mum

(Type of load and level of soiling)

load

steam cycle without washing that can be used to prepare your dried laundry for ironing or refresh‐ ing garments worn once. This programme re‐ duces creases, odours and relaxes the fibres. Do not use any detergent. When the programme is completed, quickly re‐

move the laundry from the drum2). If necessary, remove stains by washing or using localized stain removal. Steam programmes do not per‐ form any hygienic cycle. Do not set a Steam pro‐ gramme with these types of items:

• Items that are not suitable for tumble drying.

• Items with label "Dry clean only".

rics. To spin the laundry and to drain the water in the drum.

fabrics. Programme for rinsing and spinning the laundry. The default spin speed is the one used for cotton programmes. Reduce the spin speed according to the type of laundry. If necessary, set the Extra Rinse option to add rinses. With a low spin speed, the appliance performs delicate rin‐ ses and a short spin.

www.aeg.com26

Programme Default tem‐ perature Temperature range

Outdoor 30 °C 40 °C - Cold

Reference spin speed Spin speed range

1200 rpm (1200- 400 rpm)

Maxi‐

mum

load

2.0 kg

1.0 kg

Programme description

(Type of load and level of soiling)

Do not use fabric softener and make sure that there is no soften‐ er residue in the detergent dis‐ penser.

Synthetic sport items. This programme is de‐ signed to gently wash modern outdoor sports‐ wear and is also suitable for gym, cycling or jog‐ ging clothes or similar. The recommended laun‐ dry load is 2.0 kg.

Waterproof, waterproof-breathable and water repellent fabrics. This programme can also be

used as a water repellency restoring cycle, spe‐ cifically tailored for treating clothes with a hydro‐ phobic coating. To perform the water repellency restoring cycle, proceed as follows:

• Pour the washing detergent in the compart‐

ment

• Pour a special water repellency restorer for fabric into the softener compartment of the

drawer .

• Reduce the laundry load to 1.0 kg.

To further improve the water re‐ pellency restoring action, dry the laundry in a tumble dryer by set‐ ting the Outdoor drying pro‐ gramme (if available and if the garment care label permits tum‐ ble drying).

Hygiene 60 °C

20min 3kg 30 °C 40 °C - 30 °C

1400 rpm 1400 rpm 400 rpm

1200 rpm (1200- 400 rpm)

8.0 kg White cotton items. This high-performance wash programme combined with steam vapour, re‐ moves more than 99,99% of bacteria and viru‐

ses5) keeping the temperature above 60°C throughout the washing phase; with an additional action on the fibers thanks to a vapour phase, an enhanced rinsing phase ensures a proper re‐ moval of detergent and micro-organism residues. This programme ensures also a proper reduction of pollens/allergenic items.

3.0 kg Cotton and synthetic items lightly soiled or once worn.

ENGLISH 27

Programme Default tem‐ perature Temperature range

Sport 30 °C 40 °C - Cold

Denim 30 °C 40 °C - Cold

Reference spin speed Spin speed range

1200 rpm (1200- 400 rpm)

800 rpm (1200 - 400 rpm)

Maxi‐

mum

Programme description

(Type of load and level of soiling)

load

3.0 kg Synthetic sportswear. Intensive short cycle to deeply wash sportswear.

3.0 kg Special programme for Denim clothing with

delicate washing phase to minimize colour fading and marks. For better care a reduced

load size is recommended.

Wool / Silk 40 °C

1200 rpm (1200 - 400 rpm)

1.5 kg Machine washable wool, hand washable wool and other fabrics with «hand washing» care

symbol6).

40 °C - Cold

1) According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to clean normal‐

ly soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.

For the reached temperature in the laundry, the programme duration and other data, please refer to 'Consumption Values' chapter. The most efficient programmes in terms of energy consumption are generally those that perform at lower temperatures and longer duration.

2) If you set a Steam programme with dried laundry, at the end of the cycle the laundry can be humid.

Line dry the items for about 10 minutes. This programme does not remove particularly intense odour.

3) Washing programme.

4) Washing programme and waterproofing phase.

5) Tested for Staphylococcus aureus, Enterococcus faecium, Candida albicans, Pseudomonas aerugino‐

sa and MS2 Bacteriophage in external test performed by Swissatest Testmaterialien AG in 2021 (Test Report No. 202120117).

6) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't

rotate or doesn't rotate properly, but this is normal for this programme.

Programme options compatibility

Programme

No Spin

Spin

Stains

Prewash

Soft Plus

Extra Rinse

Delay Start

Plus Steam

Time Save

Eco 40-60 ■ ■ ■

Cottons ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

Synthetics ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

Delicates ■ ■ ■ ■ ■ ■ ■

www.aeg.com28

Programme

No Spin

Spin

Stains

Prewash

Soft Plus

Extra Rinse

Plus Steam

OKOPower ■ ■ ■ ■ ■ ■

Time Save

Delay Start

Steam

Spin/Drain

■ ■

■

Rinse ■ ■ ■ ■ ■

Outdoor

Hygiene

■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■ ■ ■ ■

20min 3kg ■ ■ ■

Sport ■ ■ ■ ■ ■ ■

Denim ■ ■ ■ ■ ■ ■ ■ ■ ■

Wool / Silk

1) Prewash and Stains cannot be selected together.

2) This option is not available with temperature lower than 40 °C.

3) If you set the No Spin option, the appliance performs draining only.

■ ■ ■ ■

Suitable detergents for each programme

Programme Universal

powder

Liquid Uni‐ versal

Liquid for coloureds

Delicates woollens

Special

Eco 40-60 ▲ ▲ ▲ -- --

Cottons ▲ ▲ ▲ -- --

Synthetics ▲ ▲ ▲ -- --

Delicates -- -- -- ▲ ▲

OKOPower -- ▲ ▲ -- --

Outdoor

-- -- -- ▲ ▲

ENGLISH 29

Programme Universal

powder

Hygiene

20min 3kg -- ▲ ▲ -- --

Sport -- ▲ ▲ -- ▲

Denim -- -- ▲ ▲ ▲

Wool / Silk

1) At temperature higher than 60 °C the use of powder detergent is recommended.

▲ ▲ -- -- ▲

-- -- -- ▲ ▲

▲= Recommended

-- = Not recommended

8.2 Steam programmes

The Steam programmes can be used for reducing wrinkles and odours on garments (such as cottons, synthetics, mixed fabrics, including delicates) that just need to be refreshed, in a short time, avoiding washing.

The fabric fibres are relaxed and afterwards ironing becomes effortless. When the cycle is completed, quickly remove the laundry from the drum.

The cycle duration can be reduced till 15 minutes by means of the Time Save option.

DO NOT set this mode with the following type of items:

• Items that are not suitable for tumble

drying.

• Items with label "Dry clean only".

Do not use any detergent! The Steam programmes do not remove particularly intense odour and do not perform any hygienic cycle. After the steam treatment the laundry can be humid. Hang items out for a few minutes.

Liquid Uni‐ versal

Liquid for coloureds

Delicates woollens

Special

The fragrance (AEG Steam Fragrance)

The AEG Steam Fragrance allows you to refresh even your delicate clothes, removing wrinkles and adding freshness with a gentle fragrance developed exclusively by AEG. By refreshing your garments with steam, rather than running full wash cycles, you will keep your clothes looking and feeling new longer. You can even safely use the fragrance with Cashmere and Steam programmes if they are available - for delicate fabrics like cashmere and wool. When treating smaller load reduce the fragrance dosage and the cycle duration: in only fifteen minutes, your clothes will regain that "just washed" feeling.

Read carefully the instructions supplied with the fragrance.

DO NOT:

• Tumble dry the garments treated with fragrance. Its benefit would evaporate.

• Use the fragrance with different purposes than those here described.

• Use the fragrance on new garments. New garments may contain residual finishing compounds which are not compatible with it.

The fragrance is available on AEG web shop or by authorised dealer.

www.aeg.com30

8.3 Woolmark Wool Care - Green

The wool wash cycle of this machine has been approved by The Woolmark Company for the washing of wool garments labelled as «hand wash» provided that the products are washed according to the instructions on the garment label and those issued by the manu‐ facturer of this washing machine. M1756 The Woolmark symbol is a Certification mark in many countries.

9. WI-FI - CONNECTIVITY SETUP

This chapter describes how to connect the smart appliance to the Wi-Fi network and to link it to mobile devices.

By this functionality you can receive notifications, control and monitor your appliance from your mobile devices.

The Wi-Fi functionality is off as factory default setting.

To connect the appliance to enjoy the full range of features and services you need:

• Wireless network at home with internet connection enabled.

• Mobile device connected to wireless network.

Frequency 2.412 - 2.472 GHz

for European mar‐ ket

Protocol IEEE 802.11b/g/n

Max Power <20 dBm

9.1 Installing and configuring My AEG Care

My AEG Care allows you to control your laundry through a mobile device. It contains a large number of programmes, useful features and product information tailored perfectly to the appliance. Through the app you can select the programmes already available from the appliance control panel, plus unlock additional programmes available only from a mobile device. Additional programmes can change over the time along with new versions of the app. It's personalized laundry care - all from your mobile device.

When connecting the appliance to the application, stand near it with your smart device.

Make sure that your smart device is connected to the wireless network.

1. Go to the App Store on your smart device or scan QR code (

code on rating plate' paragraph

2. Download and install the My AEG Care App.

3. Make sure you started a Wi-fi connection in the appliance. If not,

see 'QR

ENGLISH 31

read the next paragraph 'Configuring the appliance wireless connection'.

4. Start the application. Select the country and language and login with Your email and password. If you do not have an account, create a new one following the instructions in My AEG Care.

5. Follow the instructions on the App for the appliance registration and configuration.

9.2 Configuring the washing

machine wireless connection

1. Press the On/Off button for a few seconds to activate the appliance. Wait about 10 seconds before proceeding with wireless configuration.

2. Select a programme by turning the programme dial.

3. Press and hold the Delay Start and the Time Save buttons simultaneously for a few seconds until a 'click' sounds. Release the

buttons. appears on the display for 5 seconds and the indicator starts blinking.

The wireless module begins starting up.

As long as the appliance is activated, it will keep trying to connect with saved credentials until the Wi-Fi is deactivated or resets the credentials.

5. Configure the "My AEG" app on your smart device and follow the instructions to connect the appliance to your Wi-Fi network.

6. If the connectivity is configured, when the programme information screen returns, the indicator is on the display.

To switch the wireless connection off, press and hold the Delay Start and the Time Save buttons simultaneously for a few seconds until the first acoustic

signal. Release the buttons. appears on the display for 5 seconds.

If you switch the appliance off and on again, the wireless connection is automatically off.

Make sure that you APP is ready for connection.

4. After about seconds, (Access Point) appears on the display.

The access point will be open for about 3 minutes.

To remove the wireless credentials, press and hold the Delay Start and the Time Save buttons simultaneously for 10 seconds until the second acoustic signal:

appears on the display.

9.3 Remote Start

The Remote Start enables you to start a cycle in remote control.

The Remote Control activates automatically when you press the Start / Pause

button to start the programme, but it is also possible to start a washing programme remotely.

www.aeg.com32

When the App is installed and the wireless connection is complete, you can activate the Remote Start:

1. Touch the Remote Start button

and the indicator appears on the display for a few seconds.

2. Touch the Start / Pause button to activate the Remote Start before the

indicator stops blinking.

The indicators and appear on the programme summary screen and the door is locked. Now it is possible to start the programme remotely.

When touching the Start /

Pause button after the

indicator stops blinking, the Remote Start is not activated, but the set programme starts.

To remove the Remote Start, tap on the

Remote Start button and confirm by

pressing the Start / Pause button.

The reset position deactivates the Remote Start.

9.4 Over-the-air update

The App may propose an update for your appliance.

The update is accepted via App only.

If a programme is running, the App notifies that the update will start at the end of the programme.

During the update, the appliance shows

in the display.

Do not switch off or unplug the appliance during update.

The appliance will usable again at the end of the update, without any notification about successful update.

If an error occurs, the appliance shows

in the display: just press any buttons or turn the knob to return to normal use.

10. SETTINGS

10.1 Acoustic signals

This appliance has different acoustic signals, that operate when:

• You activate the appliance (special short tune).

• You deactivate the appliance (special short tune).

• You touch the buttons (click sound).

• You make an invalid selection (3 short sounds).

• The programme is completed (sequence of sounds for about 2 minutes).

• The appliance has a malfunction (sequence of short sounds for about 5 minutes).

To activate/deactivate the acoustic signals when the programme is completed, touch the Prewash and the

Stains buttons simultaneously for about 2 seconds. The display shows On or Off.

If you deactivate the acoustic signals, they continue to operate when the appliance has a malfunction.

10.2 Operating Hours Counter

It is possible to visualise the total operating time of the appliance in hours, starting from the first switching on. This value will count operating time of the cycles (does not include pauses, delayed start time). To visualise this value, proceed as follows:

ENGLISH 33

1. Switch the appliance on by pressing On/Off button.

2. Turn the programme knob to the Eco 40-60 programme (1st position clockwise).

3. Press and hold the Prewash and Stains buttons for some seconds (within 10 seconds after the switching on. After these 10 seconds, the key combination activates and deactivates the acoustic signals).

4. After 3 seconds the total hours operated by the appliance are shown in the display: e.g. 1276 hours, the display shows the text Hr for 2 seconds, 12 (thousands and hundreds) for 2 seconds and 76 (tens and units).

If the procedure does not work (due to timeout, wrong programme dial position or wrong keys combination), switch the appliance off and repeat sequence from the beginning.

10.3 Factory Reset

This function allows to restore the factory default options. To activate this option follow steps below:

1. Switch the appliance on by pressing On/Off button.

2. Turn the programme knob to the Synthetics programme (3rd position clockwise).

4. The display will show for about 5 seconds.

If the procedure does not work (due to timeout, wrong programme dial position or wrong keys combination), switch the appliance off and repeat sequence from the beginning.

11. BEFORE FIRST USE

1. Make sure that the electrical power is available and the water tap is open.

2. Pour 2 litres of water into the detergent compartment marked by

This action activates the drain system.

3. Pour a small quantity of detergent

into the compartment marked by .

12. DAILY USE

WARNING!

Refer to Safety chapters.

12.1 Activating the appliance

1. Connect the mains plug to the mains socket.

2. Open the water tap.

4. Set and start a programme for cotton at the highest temperature without any laundry in the drum.

This removes all possible dirt from the drum and the tub.

3. Press the On/Off button for a few seconds to activate the appliance.

A short tune sounds.

12.2 Loading the laundry

1. Open the appliance door.

www.aeg.com34

2. Empty the pockets and unfold the items before you put them in the appliance.

3. Put the laundry in the drum, one item at a time.

Do not put too much laundry in the drum.

4. Close the door firmly.

CAUTION!

Make sure that no laundry gets caught between the seal and the door to avoid risk of water leakage and damage to the laundry.

Washing heavily oiled, greasy stains could cause damage to rubber parts of the washing machine.

12.3 Filling the detergent and

additives

- Compartment for fabric softener and other liquid treatments(fabric conditioner, starch).

- Maximum level for quantity of liq‐

uid additives.

- Flap for powder or liquid deter‐

gent.

Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum

indicated level ( ). This quantity will however guarantee the best washing results.

After a washing cycle, if necessary, remove any detergent residue from the detergent dispenser.

12.4 Check the position of the detergent flap

1. Pull out the detergent dispenser until it stops.

- Compartment for prewash phase,

soak programme or stain remover.

- Compartment for washing phase.

2. Press the lever down to remove the dispenser.

3. To use powder detergent, turn the flap up.

4. To use liquid detergent, turn the flap down.

With the flap in the position DOWN:

• Do not use gelatinous or thick liquid detergents.

• Do not exceed to liquid detergent dose indicated on the flap.

• Do not set the prewash phase.

• Do not set the delay start function.

5. Measure out the detergent and the fabric conditioner.

6. Carefully close the detergent dispenser.

Make sure that the flap does not cause a blockage when you close the drawer.

12.5 Setting a programme

1. Turn the programme dial to select the desired washing programme. The first programme on the top right of the programme dial is Eco 40-60, the programme to which the information of the energy label relates.

The indicator of the Start / Pause button flashes. The display shows an indicative programme duration.

2. To change the temperature and/or the spin speed, touch the related buttons.

3. If desired, set one or more options by touching the related buttons. The

ENGLISH 35

related indicators will light up and the given information will change on the display accordingly.

If a selection is not possible an acoustic signal sounds and the display shows

12.6 Starting a programme

Touch the Start / Pause button to start the programme. It is not possible to start the programme when the indicator of the button is off and doesn't flash (e.g. programme dial on a wrong position).

The related indicator stops flashing and stays on. The programme starts, the door is locked. The display shows the indicator

The drain pump can operate shortly before the appliance fills water.

12.7 Starting a programme with the delay start

1. Touch the Delay Start button repeatedly until the display shows the desired delay time. On the display

the indicator shows

2. Touch the Start / Pause button. The appliance door locks and starts the countdown of the delay start. The

display shows the indicator

When the countdown is completed, the programme starts automatically.

Cancelling the delay start after the countdown has started

To cancel the delay start:

1. Touch the Start / Pause button to pause the appliance. The related indicator flashes.

2. Touch the Delay Start button

repeatedly until the display shows

and the indicator goes off.

www.aeg.com36

3. Touch the Start / Pause button again to start the programme immediately.

Changing the delay start after the countdown has started

To change the delay start:

1. Touch the Start / Pause pause the appliance. The related indicator flashes.

2. Touch the Delay Start button repeatedly until the display shows the desired delay time.

3. Touch the Start / Pause button again to start the new countdown.

button to

12.8 The ProSense System

load detection

The programme duration in the display is referred to a medium/high load.

After touching the Start / Pause button, the maximum declared load indicator goes off, the ProSense System starts the laundry load detection:

1. The appliance detects the load in the first 30 seconds. In the programmes where Time Save is available, during

this phase the Time Save bars placed below the time digits play a simple animation. The drum rotates shortly.

2. The programme duration could be adjusted accordingly and could increase or decrease. After further 30 seconds, the water filling starts.

At the end of the load detection, in case

of drum overload, the indicator flashing in the display:

In this case, for 30 seconds, it is possible to pause the appliance and remove the exceeding garments.

Once removed the exceeding garments,

touch the Start / Pause button to start the programme again. The ProSense phase can be repeated up to three times (see point 1).

Important! If the laundry amount will not be reduced, the washing programme starts anyway, despite the overload. In this case, it will be not possible to guarantee the best washing results.

About 20 minutes after the programme start, the programme duration could be adjusted again depending on the capacity of water absorption of the fabrics.

The ProSense detection is carried out with complete washing programmes only and if the programme duration has not been reduced by means of the Time Save button.

The ProSense System is not available with all programmes such as :Wool / Silk, Rinse and programmes with short cycles.

12.9 Interrupting a programme and changing the options

When the programme is running, you can change only some options:

1. Touch the Start / Pause

The related indicator flashes.

2. Change the options. The given information in the display changes accordingly.

3. Touch the button Start / Pause again.

The washing programme continues.

button.

12.10 Cancelling a running

programme

1. Press the button On/Off to cancel the programme and to deactivate the appliance.

2. Press the button On/Off again to activate the appliance.

ENGLISH 37

If the ProSense System has completed and the water filling has already started, the new programme starts

without repeating the ProSense System. The

water and the detergent are not drained out in order to avoid waste. The display shows the maximum duration of the programme, updating it about 20 minutes after the starting of the new programme.

There is also an alternative way of cancelling:

1. Rotate the selector knob to the "Reset"

position .

2. Wait for 1 second. The display shows

. Now, you can set a new washing programme.

12.11 Opening the door Adding garments

While a programme or the delay start operates, the appliance door is locked.

If the temperature and level of the water in the drum are too high and/or the drum still rotates you cannot open the door.

You can easily open the door for adding or removing some items when the icon

is lighted on.

1. Touch the Start / Pause button.

In the display the related door lock indicator goes off.

2. Open the appliance door. If

necessary, add or remove the items.

3. Close the door and touch the Start /

Pause button.

The programme or the delay start continues.

When the icon goes off, the door can be opened when the programme is complete. You may also set a spinning or draining programme/option and than

press Start / Pause

button. If the spin

and drain programmes are not available in the programme dial, they can be set via App.

12.12 End of the programme

When the programme has finished, the appliance stops automatically. The acoustic signals operate (if they are

active). The display shows

The indicator of the Start / Pause button goes off.

The door unlocks and the indicator goes off.

1. Press button On/Off to deactivate the appliance.

After five minutes from the end of the programme, the energy saving function automatically deactivates the appliance.

When you activate the appliance again, the display shows the end of the previous programme. Turn the programme dial to set a new cycle.

2. Remove the laundry from the appliance.

3. Make sure that the drum is empty.

4. Keep the door and the detergent dispenser slightly ajar to prevent mildew and odours.

12.13 Draining water out after

end of cycle

If you have chosen a programme or an option that does not empty out the water of the last rinse, the programme is completed, but:

• The time area shows and the

display shows the door locked

• The indicator of the Start / Pause

button starts flashing.

• The drum still turns at regular

intervals to prevent creases in the laundry.

• The door stays locked.

• You must drain the water to open the

door:

www.aeg.com38

1. If necessary, touch the Spin button to decrease the spin speed proposed by the appliance.

2. Press the Start / Pause button: the appliance drains the water and spins.

The option indicator Rinse Hold or

disappears.

If you have set Silent and the spin speed is not changed, when you press

the Start / Pause button, the appliance only drains the water.

3. When the programme is completed

and the door locked indicator goes off, you can open the door.

4. Press the On/Off button for a few seconds to deactivate the appliance.

12.14 Stand-by function

The Stand-by function automatically deactivates the appliance to reduce the energy consumption when:

• You do not use the appliance for 5

minutes when no programme is running.

Press the button On/Off to activate the appliance again.

• 5 minutes after the end of the washing programme. Press the On/Off button to activate the appliance again. The display shows the end of the last programme. Turn the programme dial to set a new cycle.

If the dial is rotated to the "Reset"

position , the appliance automatically turns off in 30 seconds.

If you set a programme or an option that ends with water in the drum, the Stand-by function doesn't deactivate the appliance to remind you to drain the water.

The remote control inhibits the Stand-by option, but after 15 minutes the appliance enters in Network Stand-by mode and the display shows the indicator

only.

13. HINTS AND TIPS

WARNING!

Refer to Safety chapters.

13.1 The laundry load

• Divide the laundry into: white, coloured, synthetics, delicates and wool.

• Follow the washing instructions on the laundry care labels.

• Do not wash white and coloured items together.

• Some coloured items can discolour with the first wash. We recommend that you wash them separately for the first couple of times.

• Turn multilayered fabrics, wool and items with printed illustrations inside out.

• Pre-treat stubborn stains.

• Wash stubborn stains with a special detergent.

• Be careful with curtains. Remove the hooks and put the curtains in a washing bag or pillowcase.

• A very small load can cause balance problems with the spin phase leading to excessive vibration. If this occurs:

a. interrupt the programme and

open the door (refer to "Daily Use" chapter);

b. manually redistribute the load so

that the items are spaced evenly around the tub;

c. press the Start / Pause button.

The spin phase continues.

• Button up pillowcases, close zippers, hooks and poppers. Tie up belts, cords, shoelaces, ribbons and any other loose elements.

ENGLISH 39

• Do not wash laundry without hems or with cuts. Use a washing bag to wash small and/or delicate items (e.g. underwired bras, belts, tights, shoelaces, ribbons, etc. ).

• Empty pockets and unfold the items.

13.2 Stubborn stains

For some stains, water and detergent is not sufficient.

We recommend that you pre-treat these stains before you put the items in the appliance.

Special stain removers are available. Use the special stain remover that is applicable to the type of stain and fabric.

Do not spray stain remover on garments near the appliance as it is corrosive to the plastic parts.

13.3 Detergent type and

quantity

The choice of detergent and use of correct quantities not only affects your

wash performance, but also helps to avoid waste and protect the environment:

• Use only detergents and other treatments specially made for washing machines. First, follow these generic rules:

– powder detergents (also tablets

and single-dose detergents) for all types of fabric, excluding delicate. Prefer powder detergents containing bleach for whites and laundry sanitization,

– liquid detergents (also single-dose

detergents) , preferably for low temperature wash programmes (60 °C max) for all types of fabric, or special ones for woollens only.

• The choice and quantity of detergent will depend on: type of fabric (delicates, woollens, cottons, etc), the colour of clothes, size of the load, degree of soiling, wash temperature and hardness of the water used.

• Follow the instructions that you find on packaging of the detergents or other treatments without exceeding

the indicated maximum level ( ).

• Do not mix different types of detergents.

• Use less detergent if:

– you are washing a small load, – the laundry is lightly soiled, – there is large amounts of foam

during washing.

• When using detergent tabs or pods, always put them inside the drum, not in the detergent dispenser and follow the manufacturer's recommendations .

Insufficient detergent may cause:

• unsatisfactory washing results,

• the wash load to turn grey,

• greasy clothes,

• mould in the appliance.

Excessive detergent may cause:

• sudsing,

• reduced washing effect,

• inadequate rinsing,

• a greater impact for the environment.

13.4 Ecological hints

To save water, energy and to help protect the environment, we recommend that you follow these tips:

www.aeg.com40

• Normally soiled laundry may be washed without prewash in order to save detergent, water and time (the environment is protected too!).

• Loading the appliance to the

maximum capacity indicated for each programmes helps to reduce energy and water consumption.

• With adequate pre-treatment, stains and limited soiling can be removed; the laundry can then be washed at a lower temperature.

• To use the correct quantity of detergent, refer to the quantity suggested by the detergent producer and check the water hardness of you domestic system. Refer to 'Water hardness'.

• Set the maximum possible spin

speed for the selected washing

14. CARE AND CLEANING

WARNING!

Refer to Safety chapters.

14.1 Periodic cleaning

schedule

Periodic cleaning helps to extend the life of your appliance.

After each cycle, keep the door and the detergent dispenser slightly ajar to get air circulation and dry the humidity inside the appliance: this will prevent mildew and odours.

If the appliance is not used for a long time: close the water tap and unplug the appliance.

Indicative periodic cleaning schedule:

Descaling Twice a year

Maintenance wash Once a month

Clean door seal Every two months

Clean drum Every two months

Clean detergent dis‐ penser

Clean drain pump filter

Every two months

Twice a year

programme before drying your laundry in a tumble dryer. This will save energy during drying!

13.5 Water hardness

If the water hardness in your area is high or moderate, we recommend that you use a water softener for washing machines. In areas where the water hardness is soft it is not necessary to use a water softener.

To find out the water hardness in your area, contact your local water authority.

Use the correct quantity of water softener. Follow the instructions that you find on the packaging of the product.

Clean the inlet hose and the valve filter

The following paragraphs explain how you should clean each part.

Twice a year

14.2 Removing foreign objects

Make sure that pockets are empty and all loose elements are tied up before running your cycle. Refer to "The laundry load" in "Hints and tips".

Remove any foreign objects (such as metal clip, buttons, coins, etc) that you may find in the door seal, the filters and the drum. Refer to "Door seal with double lip trap", "Cleaning the drum", "Cleaning the drain pump" and "Cleaning the inlet hose and the valve filter" paragraphs. If necessary, please contact the Authorised Service Centre.

14.3 External cleaning

Clean the appliance with mild soap and warm water only. Fully dry all the surfaces. Do not use a scouring pads or any scratching material.

CAUTION!

Do not use alcohol, solvents or chemical products.

CAUTION!

Do not clean the metal surfaces with chlorine-based detergent.

ENGLISH 41

14.4 Descaling

If the water hardness in your area is high or moderate, we recommend that you use a water descaling product for washing machines.

Regularly examine the drum to check for limescale.

Regular detergents already contain water softening agents, but we recommend to run a cycle with an empty drum and a descaling product.

Always follow the instructions that you find on the packaging of the product.

14.5 Maintenance wash

The repeated and prolonged use of low temperature programmes can cause detergent deposits, fluff residues, bacterial growth inside the drum and the tub. This could generate bad odours and mildew. To eliminate these deposits and clean the inner part of the appliance, run a maintenance wash regularly (at least once a month).

Refer to "Cleaning the drum" paragraph.

14.6 Door seal with double lip trap

This appliance is designed with a self cleaning draining system, allowing light

fluff fibers that fall off the clothes to be drained out with the water. Regularly examine the seal. Coins, buttons, other small items can be recovered at the end of the cycle.

Clean it when needed, using ammonia cream cleanser agent without scratching the seal surface.

Always obey the instructions that you find on the packaging of the product.

Check and remove objects (if there are any) that could be trapped in the fold.

Make sure that no laundry remains between the seal and the door.

Use a moist cloth to wipe off any dirt or water residue left behind in the door seal after completion of program cycle.

14.7 Cleaning the drum

Regularly examine the drum to prevent unwanted deposits.

Rust deposits in the drum may occur due to rusting foreign body in the washing or tap water containing iron

Clean the drum with special products for stainless steel.

Always follow the instructions that you find on the packaging of the product. Do not clean the drum with acidic descaling products, scouring products containing chlorine or iron or steel wool.

For a thorough clean:

1. Remove all laundry from the drum.

2. Run a Cottons programme with the highest temperature.

3. Add a small quantity of powder detergent into the empty drum, in order to rinse out any left residues.

www.aeg.com42

Occasionally, at the end of a cycle the display may show

the icon : this is a recommendation to perform the “drum cleaning”. Once the drum cleaning has been performed, the icon disappears.

14.8 Cleaning the detergent dispenser

To prevent possible deposits of dried detergent or clotted fabric softener and/or formation of mould in the detergent dispenser drawer, once in a while carry out the following cleaning procedure:

1. Open the drawer. Press the catch downwards as indicated in the picture and pull it out.

part of the recess. Use a small brush to clean the recess.

4. Insert the detergent drawer into the guide rails and close it. Run the rinsing programme without any clothes in the drum.

2. Remove the top part of the additive compartment to aid cleaning and flush it out under running warm water, to remove any traces of accumulated detergent. After cleaning, put the top part back into position.

3. Make sure that all detergent residue is removed from the upper and lower

14.9 Cleaning the drain pump

WARNING!

Disconnect the mains plug from the mains socket.

Regularly check the drain pump filter and make sure that it is clean.

Clean the drain pump if:

• The appliance does not drain the water.

• The drum does not turn.

• The appliance makes an unusual noise because of the blockage of the drain pump.

• The display shows the alarm code

WARNING!

180˚

• Do not remove the filter while the appliance operates.

• Do not clean the pump if the water in the appliance is hot. Wait until the water cools down

Proceed as follows to clean the pump:

ENGLISH 43

1. Open the pump cover.

2. Place a suitable bowl below the drain pump

access to collect the water that flows out. Always keep a rag nearby to dry up any water spillages when removing the filter.

3. Turn the filter 180 degrees in anti-clockwise direction to open it, without removing. Let the water flow out.

4. When the bowl is full of water, turn the filter back and empty the container.

5. Repeat the steps 3 and 4 until the water stops to flow out.

www.aeg.com44

6. Turn the filter anti-clockwise to remove it

7. If it is necessary, remove fluff and objects

from the filter recess. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre.

8. Clean the filter under the water tap.

9. Put the filter back into the special guides by

turning it clockwise. Make sure that you tighten the filter correctly to prevent leakages.

45°

20°

ENGLISH 45

10. Close the pump cover.

When you drain the water with the emergency drain procedure, you must activate the drain system again:

1. Put 2 litres of water in the main wash compartment of the detergent dispenser.

2. Start the programme to drain the water.

14.10 Cleaning the inlet hose and the valve filter

14.11 Emergency drain

If the appliance cannot drain the water, carry out the same procedure, described in 'Cleaning the drain pump' paragraph. If necessary, clean the pump.

When you drain the water with the emergency drain procedure, you must activate the drain system again:

1. Put 2 litres of water in the main wash compartment of the detergent dispenser.

2. Start the programme to drain the water.

14.12 Frost precautions

If the appliance is installed in an area where the temperature can reach values

www.aeg.com46

around 0° C or drop below, remove the remaining water from the inlet hose and the drain pump.

1. Disconnect the mains plug from the mains socket.

2. Close the water tap.

3. Put the two ends of the inlet hose in a container and let the water flow out of the hose.

4. Empty the drain pump. Refer to the emergency drain procedure.

15. TROUBLESHOOTING

WARNING!

Refer to Safety chapters.

15.1 Alarm Codes and Possible failures

The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables).

WARNING!

Deactivate the appliance before carrying out any check.

With some problems, the display shows an alarm code and the

Start / Pause button may flash continuously:

If the appliance is overloaded, remove some items from the drum and/or keep pressed the door while touching the Start / Pause button until the indicator

stops flashing (see the picture below).

5. When the drain pump is empty, install the inlet hose again.

WARNING!

Make sure that the temperature is higher than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures.

Problem Possible solution

The appliance does not fill with water prop‐ erly.

The appliance does not drain the water.

The appliance door is open or not closed correctly.

Internal fail. No com‐ munication between electronic elements of the appliance.

The mains supply is unstable.

The anti-flood device is on.

ENGLISH 47

• Make sure that the water tap is open.

• Make sure that the pressure of the water supply is not too low. For this information, contact your local water authority.

• Make sure that the water tap is not clogged.

• Make sure that the inlet hose has no kinks, damages or bends.

• Make sure that the connection of the water inlet hose is cor‐ rect.

• Make sure that the filter of the inlet hose and the filter of the valve are not clogged. Refer to 'Care and cleaning'.

• Make sure that the sink spigot is not clogged.

• Make sure that the drain hose has no kinks or bends.

• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Refer to "Care and cleaning".

• Make sure that the connection of the drain hose is correct.

• Set the drain programme if you set a programme without drain phase. If the drain programme is not available in the pro‐ gramme dial, it can be set via App.

• Set the drain programme if you set an option which ends with water in the tub.

• Make sure that the door is properly closed.

• The programme was not finished properly or the appliance stopped too early. Switch the appliance off and on again.

• If the alarm code appears again, contact the Authorised Serv‐ ice Centre.

• Wait until mains supply is stable.

• Disconnect the appliance and close the water tap. Contact the Authorised Service Centre.

If the display shows other alarm codes, deactivate and activate the appliance. If the problem continues, contact the Authorised Service Centre. In case of different problem with the washing machine check the table below for possible solutions.

www.aeg.com48

Problem Possible solution

• Make sure that the mains plug is connected to the mains socket.

• Make sure that the appliance door is closed.

The programme does

not start.

• Make sure that there is no damaged fuse in the fuse box.

• Make sure that the Start / Pause has been touched.

• If the delay start is set, cancel the setting or wait for the end of countdown.

• Deactivate the Child Lock function if it is on.

• Check the position of the knob on the selected programme.

The appliance fills with water and drains im‐ mediately.

• Make sure that the drain hose is in the correct position. The hose may be positioned too low. Refer to "Installation instruc‐ tion".

• Set the spin programme. If the drain programme is not availa‐

The spin phase does not operate or the washing cycle lasts longer than usual.

ble in the programme dial, it can be set via App’.

• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Refer to "Care and cleaning".

• Adjust manually the items in the tub and start the spin phase again. This problem may be caused by balance problems.

• Make sure that the couplings of the water hoses are tight and there is not water leakages.

There is water on the floor.

• Make sure that the water inlet hose and the drain hose have no damages.

• Make sure you use the correct detergent and the correct quantity of it.

• Make sure that a washing programme that ends with water in tub, has not been selected.

• Make sure that the washing programme is finished.

• Set the drain or the spin programme if there is water in the drum. If the spin and drain programmes are not available in

You cannot open the appliance door.

the programme dial, they can be set via App.

• Make sure that the appliance receives electrical power.

• This problem may be caused by a failure of the appliance. Contact the Authorised Service Centre. If you need to open the door, please read carefully "Emergen‐ cy door opening".

• Make sure that the Remote Start Mode is not activated. Deac‐ tivate it.

• Check the wireless signal.

• Make sure that the wireless connection is on. Refer to para‐

The display does not show the wireless indi‐ cator .

graph "Configuring the washing machine wireless connection" in "Wi-Fi - Connectivity setup" chapter.

• Check your home network and router.

• Restart the router.

• Contact your wireless service provider if there are further problems with the wireless network.

Problem Possible solution

• Check the wireless signal.

• Check if your smart device is connected to the wireless net‐ work.

• Check your home network and router.

The App cannot con‐ nect to the appliance.

• Restart the router.

• Contact your wireless service provider if there are problems with the wireless network.

• The appliance, the smart device, or both, need to be config‐ ured again because a new router has been installed or the router configuration has been changed.

• Make sure that the wireless signal reaches the appliance. Try

The App cannot fre‐ quently connect to the appliance.

to move the home router as near the appliance as possible or consider purchasing a wireless range extender.

• Make sure the wireless signal is not disrupted by microwave. Turn the microwave off. Avoid using the microwave and the remote control at the same time.

The display shows

. All buttons are inactive, except the the On/Off .

• The appliance is downloading any available updates. Wait un‐ til the update process is complete. If you deactivate the appli‐ ance during update, it resumes when you activate the appli‐ ance again.

• Make sure the levelling of the appliance is correct. Refer to

The appliance makes an unusual noise and vibrates.

"Installation instruction".

• Make sure that the packaging and/or the transit bolts are re‐ moved. Refer to "Installation instruction".

• Add more laundry in the drum. The load may be too small.

The programme dura‐ tion increases or de‐ creases during pro‐

• The ProSense System is able to adjust the programme dura‐ tion according to the type and the laundry load size. Refer to "The ProSense System load detection" in "Daily Use" chapter.

gramme execution.

• Increase the detergent quantity or use a different detergent.

The washing results are not satisfactory.

• Use special products to remove the stubborn stains before you wash the laundry.

• Make sure that you set the correct temperature.

• Decrease the laundry load.

Too much foam in the drum during the wash‐

• Reduce the quantity of detergent or the number of tablets or single-dose detergents.

ing cycle.

After the washing cy‐ cle, there are some detergent residues in the dispenser drawer.

• Make sure that the flap is in the correct position (UP for pow‐ der detergent - DOWN for liquid detergent).

• Make sure you have used the detergent dispenser according the indications given in this user manual.

ENGLISH 49

After the check, activate the appliance. The programme continues from the point of interruption. If the problem occurs again, contact the Authorised Service Centre. The necessary data for the service centre are on the rating plate.

www.aeg.com50

15.2 Emergency door opening

In case of power failure or functioning failure the appliance door remains locked. The washing programme continues when the power is restored. If the door remains locked in case of failure, it is possible to open it using the emergency unlock function.

Before opening the door:

CAUTION! Risk of burns! Make sure that the water temperature is not too high and the laundry is not hot. If necessary, wait until they cool down.

CAUTION! Risk of injury! Make sure that the drum is not rotating. If necessary, wait until the drum stops rotating.

Make sure that the water level inside the drum is not too high. If necessary, proceed with an emergency drain (refer to «Emergency drain» in «Care and cleaning» chapter).

To open the door, proceed as follows:

1. Press the On/Off button to switch the appliance off.

2. Disconnect the mains plug from the mains socket.

3. Pull the emergency unlock trigger downward once. Pull it once again, keep it tensed and, in the meanwhile, open the appliance door. The emergency unlock trigger is located where indicated by the following picture.

4. Take out the laundry and then close the appliance door.

16. CONSUMPTION VALUES

16.1 Introduction

See the web link www.theenergylabel.eu for detailed information about Energy Label.

The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database. Keep the energy label for reference together with the user manual and all other documents provided with this appliance. It is also possible to find the same information in EPREL using the link https://eprel.ec.europa.eu and the model name and product number that you find on the rating plate of the appliance. Refer to 'Product description' chapter for the position of the rating plate.

ENGLISH 51

16.2 Legend

kg Laundry load. hh:mm Programme duration.

kWh Energy consumption. °C Temperature in the laundry.

Litres Water consumption. rpm Spin speed.

% Remaining moisture at the end of spinning phase. The higher is the spin speed,

the higher is the noise and the lower is the remaining moisture.

Values and programme duration may differ depending on different conditions (e.g. room temperature, water temperature and pressure, load size and type of laundry, supply voltage) and also if you change the default setting of a programme.

16.3 According to Commission Regulation Eu 2019/2023

Eco 40-60 pro‐ gramme

Full load 8.0 0.770 54.0 03:20 53.00 37.0 1351

Half load 4.0 0.430 44.0 02:25 53.00 32.0 1351

Quarter load 2.0 0.180 34.0 02:25 54.00 24.0 1351

1) Maximum spin speed.

kg kWh Litres hh:mm % °C

rpm

Power consumption in different modes

Off (W) Stand-by (W)

0.50 0.50 4.00

Time to Off/Standby mode is 15 minutes maximum.

1) The energy consumption of the connected function is approximately 17.5 kWh per year. To disconnect

this function, please refer to the chapter 'Wi-fi - Connectivity setup'.

Delay start

(W)

Networked

standby (W)

2.00

16.4 Common programmes

These values are indicative only.

www.aeg.com52

Programme

Cottons

95°C

Cottons 60°C

Cottons

20°C

Synthetics 40°C

Delicates

30°C

Wool 30°C

1) Reference indicator of the spin speed.

2) Suitable for washing heavily soiled textiles.

3) Suitable for washing lightly soiled cottons, synthetic and mixed fabrics.

4) It also performs as quick washing cycle for lightly soiled laundry.

kg kWh Litres hh:mm % °C

8.0 2.200 85.0 04:15 52.00 85.0 1400

8.0 1.350 85.0 03:25 52.00 55.0 1400

8.0 0.250 85.0 02:50 52.00 20.0 1400

3.0 0.650 75.0 02:25 35.00 40.0 1200

2.0 0.360 50.0 01:10 35.00 30.0 1200

1.5 0.200 55.0 01:05 30.00 30.0 1200

17. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol . Put the packaging in relevant containers to recycle it. Help protect the environment and human health by recycling waste of electrical and electronic appliances. Do not dispose of

appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.

rpm

My AEG Care app

The software in this product contains components that are based on free and open source software. AEG gratefully acknowledges the contributions of the open software and robotics communities to the development project.

To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, please visit: http://aeg.opensoftwarerepository.com (folder NIUS)

www.aeg.com/shop

157067010-A-452022

AEG LFR8W8140BI User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

CONTENTS

1. SAFETY INFORMATION

1.1 Children and vulnerable people safety

1.2 General Safety

2. SAFETY INSTRUCTIONS

2.1 Installation

2.2 Electrical connection

2.4 Use

2.3 Water connection

2.5 Service

3. PRODUCT DESCRIPTION

3.1 Special features

2.6 Disposal

3.2 Appliance overview

4. TECHNICAL DATA

5. INSTALLATION

5.2 The appliance is equipped with ...

5.3 Unpacking

5.4 Positioning and levelling

5.5 Hose and cable connection

The inlet hose

Water drainage

5.6 Building in

5.7 Preparation and assembly of the cupboard door

5.8 Electrical connection

6. CONTROL PANEL

6.1 Control panel description

6.2 Display

7. DIAL AND BUTTONS

7.1 Introduction

7.2 On/Off

7.3 Programme dial

7.4 Temperature

7.5 Spin

7.6 Prewash

7.7 Stains

7.8 Permanent Extra Rinse

7.9 Permanent Soft Plus

7.10 Plus Steam

7.11 Child Lock

7.12 Delay Start

7.13 Time Save

8. PROGRAMMES

8.1 Programme Chart

7.14 Start / Pause

8.2 Steam programmes

The fragrance (AEG Steam Fragrance)

8.3 Woolmark Wool Care - Green

9. WI-FI - CONNECTIVITY SETUP

9.1 Installing and configuring My AEG Care

9.3 Remote Start

9.4 Over-the-air update

10. SETTINGS

10.1 Acoustic signals

10.2 Operating Hours Counter

10.3 Factory Reset

11. BEFORE FIRST USE

12. DAILY USE

12.1 Activating the appliance

12.2 Loading the laundry

12.4 Check the position of the detergent flap

12.5 Setting a programme

12.6 Starting a programme

12.7 Starting a programme with the delay start

Cancelling the delay start after the countdown has started

Changing the delay start after the countdown has started

12.9 Interrupting a programme and changing the options

12.12 End of the programme

12.14 Stand-by function

13. HINTS AND TIPS

13.1 The laundry load

13.2 Stubborn stains

13.4 Ecological hints

14. CARE AND CLEANING

13.5 Water hardness

14.2 Removing foreign objects
