USER MANUAL

LFR74944AD

EN User Manual

Washing Machine

My AEG Care app

www.aeg.com2

1. SAFETY INFORMATION......................................................................................3

2. SAFETY INSTRUCTIONS.................................................................................... 5

3. PRODUCT DESCRIPTION...................................................................................7

4. TECHNICAL DATA............................................................................................... 8

5. INSTALLATION.....................................................................................................9

6. CONTROL PANEL..............................................................................................14

7. DIAL AND BUTTONS......................................................................................... 17

8. SETTINGS.......................................................................................................... 20

9. BEFORE FIRST USE..........................................................................................21

10. THE AUTODOSE TECHNOLOGY (AUTODOSING)........................................22

11. PROGRAMMES................................................................................................28

12.

WI-FI - CONNECTIVITY SETUP................................................................. 34

13. DAILY USE....................................................................................................... 37

14. HINTS AND TIPS..............................................................................................41

15. CARE AND CLEANING.................................................................................... 43

16. TROUBLESHOOTING......................................................................................50

17. CONSUMPTION VALUES................................................................................55

18. QUICK GUIDE.................................................................................................. 57

19. ENVIRONMENTAL CONCERNS......................................................................59

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information:

www.aeg.com/support

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number. The information can be found on the rating plate.

Warning / Caution-Safety information General information and tips Environmental information

ENGLISH 3

Subject to change without notice.

1. SAFETY INFORMATION

Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

1.1 Children and vulnerable people safety

• This appliance can be used by children aged from 8

years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

www.aeg.com4

• Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised.

• Children of less than 3 years of age should be kept

away from the appliance unless continuously supervised.

• Children should be supervised to ensure that they do

not play with the appliance.

• Keep all packaging away from children and dispose of

it appropriately.

• Keep detergents away from children.

• Keep children and pets away from the appliance when

the door is open.

• If the appliance has a child safety device, it should be

activated.

• Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

• This appliance is for washing domestic-type, machine-

washable laundry only.

• This appliance is designed for single household

domestic use in an indoor environment.

• This appliance may be used in, offices, hotel guest

rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels.

• Do not change the specification of this appliance.

• The appliance maximum load is 9.0 kg. Do not exceed

the maximum load of each programme (refer to the “Programmes” chapter).

• The operating water pressure at the water entry point

from the outlet connection must be between 0.5 bar (0.05 MPa) and 10 bar (1.0 MPa).

• The ventilation opening in the base must not be

covered by a carpet, mat, or any floor covering.

• The appliance must be connected to the water mains

using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre.

• Old hose sets must not be reused.

• If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.

• Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the socket.

• Do not use high pressure water sprays and/or steam

to clean the appliance.

• Clean the appliance with a moist cloth. Use only

neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.

2. SAFETY INSTRUCTIONS

ENGLISH 5

2.1 Installation

The installation must comply with relevant national regulations.

• Remove all the packaging and the

transit bolts including rubber bush with plastic spacer.

• Keep the transit bolts in a safe place.

If the appliance is to be moved in the future they must be reattached to lock the drum to prevent an internal damage.

• Always take care when moving the

appliance as it is heavy. Always use safety gloves and enclosed footwear.

• Follow the installation instructions

supplied with the appliance.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature can be less than 0°C or where it is exposed to the weather.

• The floor area on which the appliance

is to be installed must be flat, stable, heat resistant and clean.

• Make sure that there is air circulation between the appliance and the floor.

• When the appliance is in its permanent position, check if it is levelled correctly with the aid of a spirit level. If it is not, adjust the feet accordingly.

• Do not install the appliance directly above a floor drain.

• Do not spray water on the appliance and do not expose it to excessive humidity.

• Do not install the appliance where the appliance door cannot be fully opened.

• Do not put a closed container to collect possible water leakage under the appliance. Contact the Authorised Service Centre to ensure which accessories can be used.

2.2 Electrical connection

WARNING!

Risk of fire and electric shock.

• WARNING: This appliance is designed to be installed / connected

www.aeg.com6

to a grounding connection in the building.

• Always use a correctly installed shockproof socket.

• Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.

• Do not use multi-plug adapters and extension cables.

• Make sure not to cause damage to the mains plug and to the mains cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre.

• Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.

• Do not touch the mains cable or the mains plug with wet hands.

• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

• This appliance is fitted with a 13 A mains plug. If it is necessary to change the mains plug fuse, use only a 13 A ASTA (BS 1362) fuse (UK and Ireland only).

2.3 Water connection

• The inlet water shall not exceed 25 °C.

• Do not cause damage to the water hoses.

• Before connection to new pipes, pipes not used for a long time, where repair work has been carried out or new devices fitted (water meters, etc.), let the water flow until it is clean and clear.

• Ensure that there are no visible water leaks during and after the first use of the appliance.

• Do not use an extension hose if the inlet hose is too short. Contact the Authorised Service Centre for the replacement of the inlet hose.

• When unpacking the appliance, It is possible to see water flowing from the drain hose. This is due to the testing of the appliance with the use of water in the factory.

• You can extend the drain hose to maximum 400 cm. Contact the Authorised Service Centre for the other drain hose and the extension.

• Make sure that there is access to the tap after the installation.

2.4 Use

WARNING!

Risk of injury, electric shock, fire, burns or damage to the appliance.

• Follow the safety instructions on the detergent packaging.

• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

• Do not wash fabrics which are heavily soiled with oil, grease or other greasy substances. It can damage rubber parts of the washing machine. Prewash such fabrics by hand before loading them into the washing machine.

• Do not touch the glass door while a programme operates. The glass can get hot.

• Make sure that all metal objects are removed from the laundry.

2.5 Service

• To repair the appliance contact the Authorised Service Centre. Use original spare parts only.

• Please note that self-repair or nonprofessional repair can have safety consequences and might void the guarantee.

• The following spare parts will be available for 10 years after the model has been discontinued: motor and motor brushes, transmission between motor and drum, pumps, shock absorbers and springs, washing drum, drum spider and related ball bearings, heaters and heating elements, including heat pumps, piping and related equipment including hoses, valves, filters and aquastops, printed circuit boards, electronic displays, pressure switches, thermostats and sensors, software and firmware including reset software, door, door hinge and seals, other seals, door

ENGLISH 7

locking assembly, plastic peripherals such as detergent dispensers. Please note that some of these spare parts are only available to professional repairers, and that not all spare parts are relevant for all models.

• Concerning the lamp(s) inside this product and spare part lamps sold separately: These lamps are intended to withstand extreme physical conditions in household appliances, such as temperature, vibration, humidity, or are intended to signal information about the operational status of the appliance. They are not intended to be used in other applications and are not suitable for household room illumination.

3. PRODUCT DESCRIPTION

3.1 Special features

Your new washing machine meets all modern requirements for an effective treatment of laundry with low water, energy and detergent consumption and proper care of fabric.

• The Wi-Fi connection and Remote Start enable you to start a cycle, to interact with your washing machine and to check the washing cycle status in remote control.

• The ProSense technology detects the laundry load size defining the programme duration in 30 seconds. The washing programme is tailored to the laundry load and the type of fabric without consuming more time, energy and water than necessary.

• The steam has a quick and easy way to refresh the clothes. The gentle steam programmes remove odours and reduce creases in dry fabrics so they need little ironing.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the mains electrical and water supplies.

• Cut off the mains electrical cable close to the appliance and dispose of it.

• Remove the door catch to prevent children or pets from becoming trapped in the drum.

• Dispose of the appliance in accordance with local requirements for the disposal of Waste Electrical and Electronic Equipment (WEEE).

The Plus Steam option, finishes every cycle with gentle steam that relaxes the fibres and reduces fabric creasing. Ironing will be easier!

• The AutoDose technology automatically dispenses the right amount of detergent according to the load; the drawer has two integrated tanks (detergent + softener or second detergent type) and two additional chambers for detergent and additives manual load. It gaves the highest use flexibility.

• The AEG Steam Fragrance, thanks to the steam programmes offers the perfect solution for refreshing even the most delicate garments without washing. Use the delicate fragrance exclusively developed by AEG to add a pleasant feeling of "just-washed" garment to the removing odours and wrinkles action.

1 2 3

11 12

00000000

00A

Mod.

xxxxxxxxx

000V ~ 00Hz 0000 W

910000000

Prod.No.

B C D EA

www.aeg.com8

3.2 Appliance overview

Worktop

Detergent dispenser with AutoDose

tanks and manual compartments Control panel

Door handle

Rating plate

Drain pump filter

4. TECHNICAL DATA

Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /66.0 cm

Electrical connection Voltage

Overall power Fuse Frequency

Feet for levelling the appliance

Drain hose

Inlet hose connection

Mains cable

Transit bolts

Hose support

The rating plate reports:

A. QR code B. model name C. product number D. electrical ratings E. serial number

230-240 V 2200 W 13 A 50 Hz

ENGLISH 9

Level of protection against ingress of solid particles and moisture ensured by the protective cover, except where the low voltage equipment has no protection against mois‐ ture

Water supply pressure

Water supply

Maximum Load Cotton 9.0 kg

Spin Speed Maximum spin speed 1351 rpm

1) The appliance works correctly if the water pressure is not lower than 0.05 MPa (0.5 bar). If you cannot

connect the water inlet hose to the cold water tap of the primary hydraulic system, connect it to your do‐ mestic cold water storage system. Make sure not to exceed a distance of 5.02 m (16.5 ft) between the appliance inlet hose and the bottom of the water storage tank.

2) Connect the water inlet hose to a water tap with a 3/4'' thread.

5. INSTALLATION

WARNING!

Refer to Safety chapters.

5.1 Unpacking

WARNING!

Remove all the packaging and the transit bolts before installing the appliance.

Minimum Maximum

IPX4

0.5 bar (0.05 MPa) 10 bar (1.0 MPa)

Cold water

WARNING!

Use the gloves.

1. Remove the external film. If

necessary, use a cutter.

2. Remove the cardboard top and the

polystyrene packaging materials.

3. Remove the internal film.

4. Open the door and remove the polystyrene piece from the door seal and all the items from the drum.

www.aeg.com10

5. Carefully put the appliance down on its rear side.

6. Put the front polystyrene packaging element on the floor under the appliance.

Make sure not to damage the hoses.

9. Remove the power supply cable and the drain hose from the hose holders.

It is possible to see water flowing from the drain hose. This is due to the testing with water of the appliance in factory.

7. Remove the polystyrene protection from the bottom.

8. Pull up the appliance in vertical position.

10. Remove the three bolts by using the spanner supplied with the appliance.

11. Pull out the plastic spacers.

12. Put the plastic caps, that you find in the user manual bag, in the holes.

We recommend that you

keep the packaging and the transit bolts for any movement of the appliance.

5.2 Installation on suspended flooring

Suspended wooden floors are particularly susceptible to vibration.

To limit vibration we recommend placing a waterproof wooden panel, at least 15 mm thick, under the appliance. It should be screwed to at least 2 floor beams and should extend beyond the front feet.

If possible, install the appliance where the floor is more stable.

5.3 Positioning and levelling

1. Install the appliance on a flat hard floor.

Make sure that carpets do not stop the air circulation below the appliance. Make sure that the appliance does not touch the wall or other units.

2. Loosen or tighten the feet to adjust the level.

WARNING!

Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.

ENGLISH 11

The appliance must be level and stable.

A correct adjustment of the appliance level prevents the vibration, noise and the movement of the appliance when in operation.

When the appliance is installed on a plinth or a tumble dryer is stacked on the washing machine, use the accessories described in chapter 'Accessories'. Read carefully the instructions supplied with the appliance and with the accessory.

5.4 Fixing plate kit

If you install the appliance on a plinth that is not an accessory supplied by AEG, secure the appliance with the fixing plates. This spare part is available in web shop or from authorised dealer.

Read carefully the instructions supplied with the accessory.

20º20º

45º45º

www.aeg.com12

5.5 The inlet hose

1. Connect the water inlet hose to the back of the appliance.

2. Position it toward left or right depending on the position of the water tap.

Make sure that the inlet hose is not in vertical position.

3. If necessary, loose the ring nut to set it in the correct position.

4. Connect the water inlet hose to the cold water tap with 3/4" thread.

5.6 Water drainage

The drain hose should be positioned at a height of not less than 60 cm and not more than 100 cm from the floor.

You can extend the drain hose to maximum 400 cm. Contact the authorized service centre for the other drain hose and the extension.

It is possible to connect the drain hose in different ways:

1. Make a U shape with the drain hose and put it around the plastic hose guide.

2. On the edge of a sink - Fasten the guide to the water tap or to the wall.

Make sure that the plastic guide cannot move when the appliance drains.

WARNING!

The inlet water shall not exceed 25 °C.

CAUTION!

Make sure that there are no leaks from the couplings.

Do not use an extension hose if the inlet hose is too short. Contact the service centre for the replacement of the inlet hose.

Make sure that the drain hose end is not immersed in the water. There may be a return of dirty water into the appliance.

3. To a stand pipe with vent-hole Insert the drain hose directly into a drain pipe. Refer to the illustration.

ENGLISH 13

6. Position the hose directly to a built- in drain pipe in the room wall and tighten it with a clamp.

The end of the drain hose must always be ventilated , i.e. the inner diameter of the drain pipe (min. 38 mm min. 1.5") must be larger than the external diameter of the drain hose.

4. If the end of the drain hose looks like this (see the picture), you can push it directly into the stand pipe.

5. Without the plastic hose guide, to a sink spigot - Put the drain hose in the spigot and tighten it with a clamp. Refer to the illustration.

5.7 Electrical connection

At the end of installation you can connect the mains plug to the mains socket.

The rating plate and the 'Technical Data' chapter indicate the necessary electrical ratings. Make sure that they are compatible with the mains power supply.

Check that your domestic electrical installation can take the maximum load required, also taking into account any other appliances in use.

Connect the appliance to an earthed socket.

The power supply cable must be easily accessible after installing the appliance.

For any electrical work required to install this appliance, contact our Authorised Service Centre.

The manufacturer does not accept any responsibility for damage or injury through failure to comply with the above safety precaution.

Make sure that the drain hose makes a loop to prevent particles going into the appliance from the sink.

Spor ts Home Spec ial

7 86

14 13 11 10 9

www.aeg.com14

6. CONTROL PANEL

6.1 Control panel description

The options are not selectable with all washing programmes. Check the compatibility between options and washing programmes in the "Options compatibility with programmes" paragraph in the "Programmes" chapter. An option can exclude another one, in this case the appliance doesn't allow you to set the incompatible options together. Make sure the screen and touch buttons are always clean and dry.

On/Off push button

Programme dial

2 3

Favourite programmes Display

4 5

AutoDose Liquid Detergent and

Fabric Softener touch buttons Wi-fi connection and Remote Start

touch button Finish In touch button

Start / Pause touch button Plus Steam touch button

Extra Rinse touch button

Time Save touch button

Stains/Prewash touch button and

permanent Child Lock option Spin touch button

Temperature touch button

6.2 Display

ENGLISH 15

Door locked indicator.

Washing phase indicator. It flashes during pre-wash and wash phase.

Rinsing phase indicator. It flashes during rinse phase.

Spinning and draining phase indicator. It flashes during spin and drain phase.

Steam phase indicator.

Anti-crease phase indicator.

Eco programme indicator: it lights on when the selected programme and options have an eco profile.

Add garments indicator: it lights on when the programme starts and the user can still pause the appliance and add more laundry.

Extra Rinse indicator.

ProSense indicator.

Finish In indicator.

www.aeg.com16

The digital indicator can show:

• Programme duration (e. g. ).

The time shown when the programme is set could not correspond to effective duration and change af‐ ter ProSense phase.

• Maximum load.

• Finish in time (e. g. or ).

• Cycle end (

• Warning code (e.g. ).

• Liquid detergents and softener quantity indicator:

. Refer to

"The AutoDose technology (Autodosing)" chapter.

• Indication of total operating hours of the appliance. Refer to the 'Op‐ erating hours counter' section in the 'Settings' paragraph for more details.

• When working with the APP: , (access point), (up‐ date). Please refer to the chapter 'Wi-FI - Connectivity setup'.

Maximum load indicator. The value is shown for three seconds after programme selection, alternated with cycle duration.

Maximum laundry indicator. It blinks if the laundry amount exceeds the declared load.

AutoDose liquid detergent tank indicator. When it lights, appliance auto‐ matically doses the detergent.

These indicators will appear next to and when increasing or de‐ creasing the automatic detergent or softener dosage.

AutoDose status indicator. It lights when AutoDose function for addi‐ tives is disable.

These indicators appears when setting the automatic detergent or soft‐ ener dosage. (refer to "The AutoDose technology (Autodosing)" chap‐ ter)

This indicator reminds to run a cleaning cycle.

APP notification to check.

Remote connection indicator. Wi-Fi connection indicator.

Child safety lock indicator.

The Temperature area: Temperature indicator Cold water indicator

The spin area: Spin speed indicator No Spin indicator. Spin phase is off.

Quiet indicator.

Rinse hold indicator.

Pre-wash indicator.

Stain indicator.

Indicators for options downloadable via App only

Linked mode indicator. It lights when both AutoDose tanks are linked and filled with the same detergent. AutoDose function for softener is

disable: the indicator disappears and the display shows two liquid

detergent tank indicators .

These indicators will appear next to and when increasing or de‐ creasing the automatic detergent or softener dosage.

7. DIAL AND BUTTONS

ENGLISH 17

7.1 On/Off

Pressing this button for a few seconds allows to activate or deactivate the appliance. Two different tunes sound while switching the appliance on or off.

As the Stand-by function automatically deactivates the appliance to decrease the energy consumption in a few cases, you may need to activate the appliance again.

For more details, refer to Stand-by paragraph in Daily Use chapter.

7.2 Programme dial

By rotating the programme dial it is possible to select the desired programme.

7.3 Favourite programmes

These selector positions are available after the appliance have been connected to Wi-Fi.

The favourite programmes can be set and saved via App only choosing from the available ones which are divided into

the three categories indicated on the control panel.

Once the favourite programmes have been set, you can select one of them via App or by turning the programme dial to relevant position: the relevant led comes on and the information on the display are updated accordingly.

The favourite programmes can be cancelled through the related App command or pressing the Factory Default key combination.

www.aeg.com18

7.4 Introduction

The options/functions are not selectable with all washing programmes. Check the compatibility between options/functions and washing programmes in the "Programme Chart". An option/function can exclude another one, in this case the appliance doesn't allow you to set the incompatible options/functions together. Make sure the screen and touch buttons are always clean and dry.

7.5 AutoDose Liquid Detergent

and Fabric

Softener

By means of this buttons you can:

• : activate and deactivate the automatic detergent loading.

• : activate and deactivate the automatic fabric softener loading.

Refer to "The AutoDose Technology (Autodosing)" chapter for more details.

appears on the display: to reset the Network Credentials.

7.7 Finish In

Set this option as last after programme and other options selection, otherwise it can be cancelled if you change some setting.

This option allows choosing the time within which a programme should terminate. The programme end can be postponed by one 1 hour every button touch until 24 hours maximum.

The display shows the normal programme duration alternatively with the set programme end time (expressed in hours 0h). The minimum selectable time corresponds to rounded up hour of the maximum duration of a programme (e.g. if the cycle duration lasts 3:15 hours, the minimum selectable time will be 4h).

After programme start, the door is locked and the appliance starts the ProSense phase. When load estimation ends, on the display the icon of running phase blinks and the time digit counts down in steps of one hour and in steps of 1 minute during the last hour.

7.6 Remote start

A quick touch of this button activates the Remote Start function that allows you to start, pause and stop the appliance remotely.

The related led comes on and the related icon appears on display.

If you set a programme via App and it does not match

with the knob position, text appears alternating with programme duration.

Press and hold this button for longer time to provide two other functions:

• hold it down for 3 seconds as long as a click sounds: the Wi-Fi is turned on and off.

• hold it down for 10 seconds as long

as a double beep sounds and

7.8 Start / Pause

Touch the Start / Pause button to start, pause the appliance or interrupt a running programme.

7.9 Plus Steam

This option adds a steam phase followed by a short anti-crease phase at the end of the washing programme.

The steam phase reduces fabric creasing and facilitates the fabric ironing. The recommended maximum load decreases on the display.

The indicator during steam phase.

This option can affect the programme duration.

blinks on the display

ENGLISH 19

When the programme stops the display

shows a zero , the indicator is

steady on and the indicator starts

blinking, and the Start / Pause led remains lit. The drum performs smooth movements for about 30 minutes to keep the steam benefit. By touching any button the anti-crease movements stop and the door unlocks, the appliance proposes again the previous set programme.

To interrupt the anti-crease phase, you can also:

• Press the On/Off button for a few seconds to activate or the deactivate the appliance.

• Turning the programme dial in another position.

An half laundry load helps to reach better results.

7.10 Extra Rinse

With this option you can add a few rinses to the selected washing programmes and optimise the fabric softener distribution and improve the fabric softness.

It is suggested when you use the fabric softener.

Useful for people allergic to detergents and in areas where the water is soft.

This option increases the programme duration.

The button indicator comes on.

7.11 Time Save

With this option you can decrease the programme duration.

• If your laundry is normally or lightly soiled, it may be advisable to shorten the washing programme. Touch this button once to decrease the duration.

• In case of smaller load, touch this button twice to set an extra quick programme. In this case, the temperature 95°C is not selectable.

The led of the button is on and the display shows the set programme duration.

This option can also be used to shorten the steam programme duration.

7.12 Stains/Prewash

Press this button repeatedly to activate one of the two options or both.

The relevant indicator comes on in the display.

Stains

• By setting this option, the indicator

appears close to detergent symbol

, and the appliance will automatically dose an extra amount of detergent when automatic detergent tank is enabled. If automatic detergent tank is Off, it is possible to run this option as in traditional washing machine by filling detergent or additive in the manual compartment.

If you press detergent tank button while Stains option is active, AutoDose function is switched off, but Stains option still remains active in manual mode.

• Prewash Use this option to add a pre-wash phase at 30 °C before the washing phase. This option is recommended for heavily soiled laundry, especially if containing sand, dust, mud and other solid particles.

When selecting a prewash phase and AutoDose is active, the appliance will automatically dose the detergent. When AutoDose is switched off, put the detergent/additive in a dosing ball inside the drum.

The options can increase the programme duration.

www.aeg.com20

7.13 Spin

When you set a programme, the appliance automatically selects the default spin speed.

Touch this button repeatedly to:

• Change the spin speed.

The display shows only the spin speeds available for the set programme.

• Activate the Rinse Hold option . The water of the last rinse is not drained out to prevent the fabrics from creasing. The washing programme ends with water in the drum and the final spin phase is not performed.

The display shows the indicator . The drum turns regularly to reduce creasing. The door stays locked. The drum turns regularly to reduce creasing. You must drain the water to unlock the door.

Touch Start / Pause button : the appliance performs the spinning phase and drains the water.

• Activate the Quiet option. All spinning phases (intermediate spin and final spin) are suppressed and the programme ends with water in the drum. This helps to reduce creasing. As the programme is very quiet, it is suitable for use at night time when cheaper electricity tariffs are available. In some programmes the rinses are performed with more water.

The display shows the indicator . The door stays locked. The drum turns regularly to reduce creasing. You must drain the water to unlock the door. Touch the Start / Pause button: the appliance performs only the draining phase.

• No Spin . Set this option to deactivate all spin phases. The display shows the

indicator . The appliance performs the only draining phase of the selected washing programme. Set this option for very delicate fabrics. The rinses phase uses more water for some washing programmes

The appliance empties the water out automatically after approximately 18 hours.

7.14 Temperature

When you select a washing programme, the appliance automatically proposes a default temperature.

Touch this button repeatedly until the desired temperature value appears on the display.

When the display shows the indicators

and , the appliance does not heat

the water.

8. SETTINGS

8.1 Introduction

When pressing a key combination, do not tilt your fingers downwards . The sensors of the underneath buttons are sensitive and may interfere with Your choice.

8.2 Acoustic signals

This appliance is provided with different acoustic signals, that operate when:

• You activate the appliance (special short tune).

• You deactivate the appliance (special short tune).

• You touch the buttons (click sound).

• You make a wrong selection (3 short sounds).

• The programme is completed (sequence of sounds for about 2 minutes).

• The appliance has a malfunction (sequence of short sounds for about 5 minutes).

ENGLISH 21

• When a laundry overload is detected during ProSense phase (a double sound played one).

To activate/deactivate this option, hold down the Extra Rinse button until a beep or a double beep sounds.

If you deactivate this function, the acoustic signals stops playing at the end of the programme only.

8.3 Child Lock

With this option you can prevent children from playing with the control panel.

To activate/deactivate this option, hold

down the Stains/Prewash button until comes on/goes off on the display.

The appliance will default to this option after you switch it off.

8.4 Operating Hours Counter

It is possible to visualise the total operating time of the appliance in hours, starting from the first switching on. This value will count operating time of the cycles (does not include pauses, delayed start time). To visualise this value, proceed as follows:

1. Switch the appliance on by pressing

the On/Off button.

2. Press and hold the Extra Rinse and Plus Steam buttons for some seconds.

3. After 3 seconds the total hours operated by the appliance are shown in the display: e.g. 1276 hours, the display shows the text Hr for 2 seconds, 12 (thousands and hundreds) for 2 seconds and 76 (tens and units).

4. To exit this mode, press any button or switch the appliance off by means of theOn/Off button.

If the procedure does not work (due to timeout or wrong keys combination), switch the appliance off and repeat sequence from the beginning.

8.5 Factory Defaults

This function allows to restore the factory default options. To activate this option follow steps below:

1. Switch the appliance on by pressing On/Off button.

2. Press and hold the Stains/Prewash and Time Save buttons for some seconds.

3. The display will show for about 5 seconds.

9. BEFORE FIRST USE

During installation or before first use you may observe some water in the appliance. This is a residual water left in the appliance after a full functional test in the factory to ensure the appliance is delivered to customers in perfect working order and is no cause for concern.

1. Make sure that all transit bolts have been removed from the appliance.

2. Make sure that the electrical power is available and the water tap is open.

3. Make sure to fill the AutoDose tanks

with liquid detergent and fabric

softener . Refer to "AutoDose basic setting " paragraph in "The AutoDose technology" chapter.

4. Pour 2 litres of water inside the drum.

This action activates the drain system.

5. Set and start a programme for cotton at the highest temperature without any laundry in the drum.

This removes all possible dirt from the drum and the tub.

www.aeg.com22

10. THE AUTODOSE TECHNOLOGY (AUTODOSING)

Read this chapter carefully.

10.1 Introduction

Right detergent and fabric softener dosage takes better care of the laundry and ensuring good wash performances.

Too much detergent damages your clothes and too little doesn’t ensure good wash performances.

This appliance is equipped with an auto dosing system able to automatically provide the right detergent and fabric softener dosage to preserve the fabric integrity and colour brightness.

AutoDose liquid detergent tank.

AutoDose fabric softener tank.

The appliance is pre-set by the factory to suit most users habits.

Once started the programme, the appliance will automatically release the right amount of detergent and softener according to the real fabric load, if AutoDose is activated and the indicators

and/or are visible on the display.

In some programmes, AutoDose is deactivated (the

indicators and/or are not displayed and the display shows OFF) because there are garments requiring special detergents or treatments. If this is the case, pour the detergent and other treatments in the proper manual filling compartment. Please refer to "AutoDose and options compatibility with programmes" in "Programmes" chapter.

Further explanations on AutoDose and activation of advanced settings are available downloading the APP.

10.2 Detergent dispenser with AutoDose tanks and manual compartments

When using detergent and any other treatments, always follow the instructions that you find on the packaging of the detergent products. Anyway, we recommend not to exceed the maximum indicated level in each

compartment ( ).

If both AutoDose tanks are enabled in the set programme, liquid detergent and fabric softener are automatically loaded.

If one of the AutoDose tank or both are disabled (OFF ) in the set

programme, proceed by manually filling in the proper manual compartment.

Manual

Aut oDo se

(Manual)

• AutoDose tanks for liquid

Manual

detergent and fabric softener

WARNING! Do not put powder detergent in the AutoDose compartment.

• Manual compartment for washing phase: powder or liquid detergent.

When using liquid detergent, make sure that the special container for liquid detergent is inserted. Refer to the "Manual filling the detergent and additives" paragraph in this chapter. The liquid detergent container is supplied inside the drum.

•

Manual compartment for liquid additives (fabric softener, fabric conditioner, starch).

ENGLISH 23

• Maximum level for detergent/ additives quantity.

10.3 AutoDose basic setting

The factory pre-set doses for a large load are 90 ml for detergent tank and 25 ml for fabric softener tank: the optimal configuration to meet majority of use condition. The appliance will use these settings to calculate the precise dosage for each wash based on load size.

However, under extreme conditions (very soft or very hard water) and particular type of detergent (such as super compact), we recommend to adjust the pre-set dosage by following the indication given on detergent and fabric softener container: e.g when using super compact detergent you may need to reduce the pre-set dosage considerably.

If the washing results are not satisfying or there is too much foam during washing, you may need to change the factory setting. Read in the paragraph 'AutoDose configuration mode' how to change the basic setting, but before:

1. Identify the water hardness level.

Check the water hardness level in your area. The levels are generally indicated as: soft, medium and hard. If necessary, please contact your local water authority to check the water hardness in your area.

2. Identify the customized detergent

dosage.

Check the label in the detergent/ fabric softener container and identify the quantity to use. The suggested quantity is the combination of three different factors:

• Water hardness level (see the following table);

• Normal soil level;

• Rated capacity of the appliance (e.g. maximum load capacity 9.0 kg). If the rated capacity on the product container refers to lower capacity appliances, the customized dosage should be increased.

www.aeg.com24

Water hardness levels

Levels Water hardness range

°f

Soft <15 <8 <10 <1.4 <140

Medium

Hard >25 >14 >17 >2.5 >250

1) French degrees

2) German degrees

3) English degrees

4) Factory setting, able to satisfy most of the use conditions.

15 - 25 8 - 14 0 - 17 1.5 - 2.5 150 - 250

10.4 AutoDose configuration

mode

°d

°e

mmol/l ppm

or shows tank indicator when it is enabled.

Enter the AutoDose configuration mode before proceeding with any programme setting. The configuration mode may cancel temporary settings .

1. Press the On/Off button for a few

seconds to activate the appliance.

2. Wait about 10 seconds for appliance

internal check.

3. To enter in configuration mode, hold

pressed the Temperature and the Spin buttons simultaneously for a few

seconds until and the blinking

detergent tank and softener tank

5. To set basic dosage touch related tank buttons until default dosage laundry product and two arrows on bottom of display appear. Touch the Temperature button repeatedly to decrease the dosage and the Spin button to increase it: minimum step is 1 ml (each single step) or 10 ml (when button is hold pressed).

indicators appear in the display. After 10 seconds without interacting with control panel the appliance exits the configuration mode.

4. Touch related tank buttons to toggle function off and on. The display shows OFF when a tank is disabled

6. After about 10 seconds the display returns to the programme information screen or hold pressed the Temperature and the Spin buttons again to exit immediately.

10.5 Filling the detergent and additives on AutoDose system

Please read "Detergents and other treatments" in "Hints and tips" chapter.

We recommend that you do not exceed the maximum

indicated level ( ).

1. Open the detergent dispenser.

2. Lift up the AutoDose cover lid.

ENGLISH 25

4. Gently pour only liquid softener in the

AutoDose fabric softener tank . Fill up to the maximum indicated level

3. Gently pour only liquid detergent in

the AutoDose detergent tank . Fill up to the maximum indicated level

5. Lift down the AutoDose cover lid.

6. Gently close the detergent dispenser, till click engagement.

www.aeg.com26

10.6 AutoDose low level indication

Do not refill the AutoDose tanks unless appliances indicates that one or both tanks are empty.

When the activated tank reaches a low level of detergent, related indicator blinks slowly and continuously on the display.

It will stop blinking when the compartment is refilled.

If tank is not refilled, once a programme has started, the indicator will stop blinking and stay steadily lit. Once the programme is finished, it will start blinking again.

Unless AutoDose is turned OFF, if a compartment has reached low level, the set dosage for that compartment will be shown by the display for a few seconds each time the drawer is opened, to remind refill is needed.

If in both tanks detergent level is low, both indicators blink, but only the set dosage for detergent will be displayed.

If the tanks are filled before the appliance is powered on for the first time, the AutoDose indicator will not blink.

CAUTION!

The tanks refill must be carries out with the same brand and type of detergent/ fabric softener/additive used before, otherwise clean the tanks before refilling.

10.7 Switching from AutoDose to manual dosing

It is possible to disable AutoDose function for one or both tanks by pressing related button symbol.

Example:

• To switch Fabric Softener tank off,

press the Softner display shows OFF.

• If you need to use different detergent than ones present in AutoDose tanks, you could switch Detergent tank off by

pressing the Detergent button until the display shows OFF.

button until the

10.8 Deactivating the

AutoDose

If you prefer to use the compartments for manual filling as default choice, you can deactivated the AutoDose tanks completely. Once you have entered the AutoDose configuration mode by pressing Temperature and the Spin buttons:

1. Tap on the Detergent

the Softner

shows : the AutoDose is excluded completely for related tank or both.

button until display

button or

2. After about 10 seconds the display

Manual

returns to the programme information screen.

10.9 Manual filling the detergent and additives

You may need to use a different detergent or fabric softener than the ones used in the AutoDose tanks. First, make sure that the AutoDose tanks are disabled and then pour the detergent and/or other treatments in the manual compartments.

Do not exceed the maximum

indicated level ( ).

ENGLISH 27

3. If desired, pour the fabric softener in

the compartment

1. Open the detergent dispenser.

2. Put the powder detergent in the

compartment . When using liquid detergent, refer to "Manual filling the liquid detergent".

4. Gently close the detergent dispenser, till click engagement.

Manual filling the liquid detergent

1. Insert the container for liquid detergent.

www.aeg.com28

10.10 Drawer open indication

When a programme is running, the detergent drawer must always be closed.

A sensor in the drawer detects if the drawer is open (or not properly closed) while the programme is running. In such case, the appliance will immediately be paused.

2. Pour the liquid detergent in the

compartment

3. Gently close the detergent dispenser, till click engagement.

If the machine has not been used for more than 4 weeks with filled tanks, detergent/ softener can become viscous or dry out. It is needed to clean the drawer as indicated in 'Care and Cleaning' chapter.

11. PROGRAMMES

If you press the Start / Pause an error sound is generated and everything in the display will turn off except the AutoDose indicators remain lit for a few seconds. Then the display returns to the previous paused state.

This will happen even if the user turned AutoDose off.

To restart the programme, ensure the drawer is properly closed and press

Start / Pause

button.

button,

11.1 My AEG Care app and additional hidden programmes

My AEG Care app provides you with a wide choice of additional hidden programmes. Connect the appliance to My AEG Care and you will be able to choose the programme that suits your needs most.

You can also memorize any of the hidden cycles in the favourite programme positions. To select the programme from the appliance directly refer to the "Favourite programmes" paragraph in "Dial and buttons" chapter.

Programme names are subject to change depending on market requirements without notice. In the App you can find a complete description of each programme.

ENGLISH 29

Sportswear Daily Training Down Jackets Soccer/Rugby Skiing Gear Running Shoes

Bed Linen Curtains Pillow Towels Duvet Pet Hair

Denim Silk Baby Linen Business Shirts Steam Cashmere

11.2 Programme Chart

The programmes are described in this chart following the order of the selector dial from the top to the bottom.

Washing programmes

Programme Programme description

Cotton and mixed synthetic fabrics. Ideal to wash your daily

MixLoad 69min

Eco 40-60

Cottons

Synthetics

Delicates

Wool

20min 3kg

Steam

load in a short time, for a better clothes care and good cleaning already at 30°C.

Low energy cycle for cottons. Decreases temperature and ex‐ tends time to reach good washing results.

White and coloured cotton fabrics. Ideal for normal and heavy soil.

Synthetic items or mixed fabric items. Normal soil.

Delicate fabrics such as acrylics, viscose and mixed fabrics re‐ quiring gentler washing. Normal soil.

Machine washable wool, hand washable wool and other fabrics

with «hand washing» care symbol1).

Cotton and synthetic items lightly soiled or worn only once.

Cotton, synthetic and mixed items. Special steam cycle without washing that can be used to prepare your dried laundry for ironing or refreshing garments worn once. This programme re‐ duces creases, odours and relaxes the fibres. Do not use any detergent. When the programme is completed, quickly remove the laun‐

dry from the drum2). If necessary, remove stains by washing or using localized stain removal. Steam programmes do not per‐ form any hygienic cycle. Do not set a Steam programme with these types of items:

• Items that are not suitable for tumble drying.

• Items with label "Dry clean only".

Machine Clean 1 Item Fast Anti-Allergy Vapour Easy Iron

Manual

www.aeg.com30

Programme Programme description

Outdoor

there is no softener residue in the detergent dispenser.

Outdoor clothing, technical, sport fabrics, waterproof and breathable jackets, shell jackets with a removable fleece or in‐ ner insulation. The recommended laundry load is 2.0 kg. This programme can also be used as water-repellent restoring cy‐ cle, specifically tailored for treating clothes with a hydrophobic coating. To perform the water-repellent restoring cycle, pro‐ ceed as follows:

• Pour the washing detergent in the compartment .

• Pour a special water-repellent restorer for fabric in the

Do not use fabric softener and make sure that

drawer compartment for fabric softener

• Reduce the laundry load to 1.0 kg.

To further improve the water-repellent restor‐ ing action, dry the laundry in a tumble dryer by setting the Outdoor drying programme (if avail‐ able and if the garment care label permits tum‐ ble drying).

White cotton items. This high-performance wash programme

Hygiene

combined with steam vapour, removes more than 99,99% of

bacteria and viruses3) keeping the temperature above 60°C throughout the washing phase; with an additional action on the fibers thanks to a vapour phase, an enhanced rinsing phase ensures a proper removal of detergent and micro-organism residues. This programme ensures also a proper reduction of pollens/allergenic items.

All fabrics, except woollens and very delicate fabrics. Pro‐

Rinse

gramme for rinsing and spinning the laundry. The default spin speed is the one used for cotton programmes. Reduce the spin speed accordingly to the type of laundry. If necessary, set the Extra Rinse option to add rinses. With a low spin speed the ap‐ pliance performs delicate rinses and a short spin.

To spin the laundry and to drain the water in the drum. All fab‐

Spin/Drain

During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't

rotate or doesn't rotate properly, but this is normal for this programme.

If you set a Steam programme with dried laundry, at the end of the cycle the laundry can be humid.

Line dry the items for about 10 minutes. This programme does not remove particularly intense odour.

Tested for Staphylococcus aureus, Enterococcus faecium, Candida albicans, Pseudomonas aerugino‐ sa and MS2 Bacteriophage in external test performed by Swissatest Testmaterialien AG in 2021 (Test Report No. 202120117).

rics, except woollens and delicate fabrics.

Programme temperature, maximum spin speed and maximum load

Programme Default tempera‐

ture Temperature

Reference spin speed Spin speed range

range

ENGLISH 31

Maximum load

MixLoad 69min

Eco 40-60

Cottons

Synthetics

Delicates

Wool

20min 3kg

Steam

Outdoor

Hygiene

30 °C 60 °C - 30 °C

40 °C

40 °C 95 °C - Cold

40 °C 60 °C - Cold

30 °C 40 °C - Cold

40 °C 40 °C - Cold

30 °C 40 °C - 30 °C

- - 1.0 kg

30 °C 40 °C - Cold

60 °C

1400 rpm 1400 rpm - 400 rpm

1200 rpm 1200 rpm - 400 rpm

800 rpm 1200 rpm - 400 rpm

1200 rpm 1200 rpm - 400 rpm

1200 rpm 1400 rpm - 400 rpm

1200 rpm 1200 rpm - 400 rpm

1400 rpm 1400 rpm - 400 rpm

5.0 kg

9.0 kg

4.0 kg

2.0 kg

1.5 kg

3.0 kg

2.0 kg

1.0 kg

9.0 kg

Rinse

Spin/Drain

1) According to UK Ecodesign for Energy-Related Products and Energy Information Regulations, this

programme at 40 °C is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.

For the reached temperature in the laundry, the programme duration and other data, please refer to 'Consumption Values' chapter. The most efficient programmes in terms of energy consumption are generally those that perform at lower temperatures and longer duration.

2) Washing programme.

3) Washing programme and waterproofing phase.

1400 rpm 1400 rpm - 400 rpm

9.0 kg

www.aeg.com32

11.3 Steam programme with AEG Steam Fragrance

Available in www.aeg.com/shop .

Steam programmes can be used for reducing wrinkles and odours of garments that just need to be refreshed, avoiding washing. Steam programme doesn't remove particularly intense odour.

The fabric fibres are relaxed and afterwards ironing becomes effortless. When the programme is completed, quickly remove the laundry from the drum. Steam programme does not perform any hygienic cycle. Do not set a steam programme with the following type of items:

• Items that are not suitable for tumble drying.

• Items with label "Dry clean only".

After the steam treatment the laundry can be humid. Hang items out for a few minutes.

11.4 Woolmark Wool Care - Blue

The wool wash cycle of this machine has been approved by The Woolmark Company for the washing of wool garments labelled as «hand wash» provided that the products are washed according to the instructions on the garment label and those issued by the manu‐ facturer of this washing machine. M1230 The Woolmark symbol is a Certification mark in many countries.

The fragrance. If you use this special gentle fragrance, your laundry will scent as just washed. Read carefully the instructions supplied with the fragrance. Reduce the fragrance dosage when treating smaller load. By means of the Time Save button, you can reduce the programme duration when treating items labeled to be washed at low temperature.

DO NOT:

• Tumble dry the garments treated with fragrance. Its benefit would evaporate.

• Use the fragrance with different purposes than those here described.

• Use the fragrance on new garments. New garments may contain residual finishing compounds which are not compatible with it.

The fragrance dose bottles are available on AEG web shop or by authorised dealer.

11.5 Options compatibility with programmes

AutoDose

Cottons

Eco 40-60

MixLoad 69min

Synthetics

Wool

Delicates

20min 3kg

Steam

Hygiene

Outdoor

Rinse

Spin/Drain

ENGLISH 33

Cottons

Eco 40-60

Synthetics

Wool

Delicates

Steam

20min 3kg

Hygiene

Outdoor

Rinse

MixLoad 69min

AutoDose Deter‐

■ ■ ■ ■ ■ ■ ■ ■

gent

AutoDose Fabric

■ ■ ■ ■ ■ ■ ■ ■ ■

Softener

Others

Spin ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

Rinse Hold

Quiet

No Spin

Stains

■ ■ ■ ■ ■ ■ ■ ■ ■

■ ■ ■

Spin/Drain

■

Prewash

Time Save

■ ■

■ ■ ■ ■

Extra Rinse ■ ■ ■ ■ ■ ■ ■

Plus Steam

■ ■ ■ ■

Finish In ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

1) If you set the No Spin option, the appliance performs draining only.

2) This option is not available with temperature lower than 40 °C.

3) If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully

load the appliance, however the washing results can be less satisfactory.

00000000

00A

Mod.

xxxxxxxxx

000V ~ 00Hz 0000 W

910000000

Prod.No.

SCANNING...

www.aeg.com34

Suitable detergents for washing programmes

Programme Universal

powder

MixLoad 69min

-- ▲ ▲ -- --

Liquid Uni‐ versal

Liquid for coloureds

Eco 40-60 ▲ ▲ ▲ -- --

Cottons ▲ ▲ ▲ -- --

Synthetics ▲ ▲ ▲ -- --

Delicates -- -- -- ▲ ▲

Wool -- -- -- ▲ ▲

20min 3kg -- ▲ ▲ -- --

Outdoor -- -- -- ▲ ▲

Hygiene ▲ ▲ -- -- ▲

1) At temperature higher than 60 °C the use of powder detergent is recommended.

▲ = Recommended -- = Not recommended

12. WI-FI - CONNECTIVITY SETUP

Delicates woollens

Special

This chapter describes how to connect the smart appliance to the Wi-Fi network and to link it to mobile devices.

By this functionality you can receive notifications, control and monitor your appliance from your mobile devices.

The Wi-Fi functionality is off as factory default setting.

To connect the appliance to enjoy the full range of features and services you need:

• Wireless network at home with

internet connection enabled.

• Mobile device connected to wireless

network.

Frequency 2.412 - 2.472 GHz

for European mar‐ ket

Protocol IEEE 802.11b/g/n

Max Power <20 dBm

12.1 QR code on rating plate

QR code can be used in two ways:

• Scan the QR code with the built-in camera app to download the My AEG Care application from the App store on your smart device and follow the required steps.

• Pairing your smart device with appliance to simplify the process. Scan the QR code with QR code scanner built-in My AEG Care application.

ENGLISH 35

12.2 Installing and configuring My AEG Care

My AEG Care allows you to control your laundry through a mobile device. It contains a large number of programmes, useful features and product information tailored perfectly to the appliance. Through the app you can select the programmes already available from the appliance control panel, plus unlock additional programmes available only from a mobile device. Additional programmes can change over the time along with new versions of the app. It's personalized laundry care - all from your mobile device.

When connecting the appliance to the application, stand near it with your smart device.

Make sure that your smart device is connected to the wireless network.

1. Go to the App Store on your smart device or scan QR code (

code on rating plate' paragraph

2. Download and install the My AEG Care App.

3. Make sure you started a Wi-fi connection in the appliance. If not, read the next paragraph 'Configuring the appliance wireless connection'.

4. Start the application. Select the country and language and login with Your email and password. If you do not have an account, create a new one following the instructions in My AEG Care.

5. Follow the instructions on the App for the appliance registration and configuration.

see 'QR

12.3 Configuring the appliance wireless connection

1. Press the On/Off button for a few seconds to activate the appliance. Wait about 10 seconds before proceeding with wireless configuration.

2. Select a programme by turning the programme dial.

3. Press and hold the Remote Start button for a few seconds until a 'click'

sounds. Release the button. appears on the display for 5 seconds and the indicator starts blinking.

The wireless module begins starting up.

Make sure that you APP is ready for connection.

4. After about 10 seconds, (Access Point) appears on the display.

The access point will be open for about 3 minutes.

5. Configure the My AEG Care app on your smart device and follow the instructions to connect the appliance to your Wi-Fi network.

6. If the connectivity is configured, when the programme information screen returns, the indicator is on the display.

www.aeg.com36

Every time you switch the appliance on, the appliance takes about 10 seconds to connect to the network automatically. When the indicator stops blinking the connection is ready.

To switch the wireless connection off,

press and hold the Remote Start button for a few seconds until the first acoustic signal. Release the button.

appears on the display for 5

seconds.

If you switch the appliance off and on again, the wireless connection is automatically off.

To remove the wireless credentials,

press and hold the Remote Start button for a few seconds until the second

acoustic signal: appears on the display for a few seconds.

12.4 Remote Start

The Remote Start enables you to start a cycle in remote control.

The Remote Control activates automatically when you press the Start / Pause

button to start the programme, but it is also possible to start a washing programme remotely. This function is deactivated when door is open.

When the App is installed and the wireless connection is complete, you can activate the Remote Start:

1. Touch the Remote Start button

and the indicator blinks on the display for a few seconds.

2. Touch the Start / Pause button to activate the Remote Start before the

indicator stops blinking.

The indicators and appear on the programme summary screen and the door is locked. Now it is possible to start the programme remotely.

When touching the Start /

Pause button after the

indicator stops blinking, the Remote Start is not activated, but the set programme starts.

To remove the Remote Start, tap on the

Remote Start

pressing the Start / Pause button.

button and confirm by

12.5 Over-the-air update

The App may propose an update for your appliance.

The update is accepted via App only.

If a programme is running, the App notifies that the update will start at the end of the programme.

During the update, the appliance shows

in the display.

Do not switch off or unplug the appliance during update.

The appliance will usable again at the end of the update, without any notification about successful update.

If an error occurs, the appliance shows

in the display: just press any buttons or turn the knob to return to normal use.

ENGLISH 37

12.6 Wi-Fi Always On

The Wi-Fi Always On function is available in the App.

This function keeps the appliance connected to the network even when the appliance is turned off.

The indicator intermittently (1 second on , 5 seconds off).

13. DAILY USE

WARNING!

Refer to Safety chapters.

13.1 Activating the appliance

1. Connect the mains plug to the mains socket.

2. Open the water tap.

3. Press the On/Off button for a few seconds to activate the appliance.

A short tune sounds. The appliance automatically proposes a default programme. The relevant indicator illuminates.

The display shows the cycle duration, the maximum load (for a few seconds), the default temperature, the default spin speed and the indicators of the phases making up the programme.

It is possible to turn the appliance on by pressing the On/Off button or through the App.

The Wi-Fi Always On function may affect your energy consumption.

goes on and off

CAUTION!

Make sure that no laundry stays between the seal and the door. There is a risk of water leakage or damage to the laundry.

13.2 Loading the laundry

1. Open the appliance door.

2. Shake the items before you put them in the appliance.

3. Put the laundry in the drum, one item at a time.

Make sure not to put too much laundry in the drum.

4. Close the door firmly.

CAUTION!

Washing heavily oiled, greasy stains could cause damage rubber parts of the washing machine.

13.3 Using detergent and other treatments

If both AutoDose tanks are enabled in

the set programme, detergent and fabric softener are automatically loaded.

If one of the AutoDose tank or both are disabled (OFF) in the set

programme, proceed by manually filling the product in the proper compartment.

www.aeg.com38

13.4 Setting a programme

If you wish to change the automatic detergent or fabric softener dosage, enter the AutoDose configuration mode before proceeding with any programme setting. The configuration mode may cancel temporary settings. Please refer to "AutoDose configuration mode" paragraph in "The AutoDose Technology (Autodosing)" chapter.

1. Turn the programme dial to select the desired washing programme. The related programme indicator comes on.

The indicator of the Start / Pause button flashes. The display shows an indicative programme duration, the maximum declared load for the set programme (only for a few seconds), the default temperature, the default spin speed and the washing phase indicators (when available).

2. To change the temperature and/or the spin speed, touch the related buttons.

3. If desired, set one or more options by touching the related buttons. The related indicators come on in the display and the given information changes accordingly.

In case a selection is not possible, no indicator comes on and an acoustic signal sounds.

13.5 Starting a programme

WARNING!

Make sure that the detergent dispenser is firmly closed, otherwise programme won't start.

Touch the Start / Pause button to start the programme.

The related indicator stops flashing and stays on.

In the display, the indicator of the operating phase starts flashing. The programme starts, the door is locked. The display shows the indicator

The drain pump can operate shortly before the appliance fills water.

13.6 Starting a programme with the Finish In option

1. Touch this repeatedly until the display shows the desired time within the programme should end. The

indicator comes on.

2. Touch the Start / Pause The drum starts rotating to perform the ProSense estimation, if foreseen in the selected programme.

3. The appliance starts the countdown to the end of the programme and the programme will start at the right moment for ending at the time set through this option.

button.

To change or cancel this option:

1. Switch the appliance off by means of the On/Off button.

2. Switch the appliance on again.

3. Set the programme again.

13.7 The ProSense load

detection

The programme duration in the display is referred to a medium/high load.

After setting a washing programme, the

the programme supports it.

After touching the Start / Pause button, the ProSense starts the laundry load detection:

1. The appliance detects the load in the

icon lights up on the display if

first 30 seconds: the indicator

flashes, the bars under the icon move back and forth and the drum rotates shortly.

ENGLISH 39

2. When the drum stops rotating, the display shows the new programme duration, that could increase or decrease, adjusted accordingly the load detected, the number of bars indicates the load in quarter (from 1 to 4, 4 bars in case of overload), the maximum declared load indicator comes on again. After further 30 seconds, the water filling starts.

In case of in case of drum overload, the maximum declared load indicator comes on again

with the indicator blinking. In this case, during these 30 seconds, it is possible to pause the appliance and remove the exceeding garments. Once removed the exceeding garments, touch the Start / Pause

button to start the programme again. The ProSense phase can be repeated up to three times (see point 1).

Important! If the laundry amount will not be reduced, the washing programme starts anyway, despite the overload. In this case, it will be not possible to guarantee the best washing results.

About 20 minutes after the programme start, the programme duration could be adjusted again depending on the capacity of water absorption of the fabrics.

The ProSense detection is carried out with complete washing programmes only (no skipping phase selected).

The ProSense is not available with some programmes, such as Wool, programmes with short cycles and without washing phase.

13.8 Programme phase indicators

When the programme starts the indicator of the running phase flashes and the other phase indicators are steady on.

E.g. the washing or pre wash phase is

running:

When the phase ends the relevant indicator stops flashing and is steady on. The next phase indicator starts flashing.

E.g. the rinse phase is running: .

If you select the Plus Steam the steam phase indicators come on.

The steam phase is running:

The anti-crease phase is running:

13.9 Interrupting a programme and changing the options

When the programme is running, you can change only some options:

1. Touch the Start / Pause button.

The related indicator flashes.

2. Change the options. The given information in the display changes accordingly.

3. Touch the Start / Pause again.

The washing programme continues.

button

13.10 Cancelling a running

programme

1. Press the On/Off button to cancel the programme and to deactivate the appliance.

2. Press the On/Off button again to activate the appliance.

Now, you can set a new washing programme.

www.aeg.com40

If the ProSense phase is already carried out and the water filling is already started, the new programme starts without repeating the ProSense phase. The water and the detergent are not drained out in order to avoid waste. The display shows the maximum duration of the programme, updating it about 20 minutes after the starting of the new programme.

13.11 Opening the door Adding garments

While a programme or the delay start operates, the appliance door is locked.

If the temperature and level of the water in the drum are too high and/or the drum still rotates you cannot open the door.

You can easily open the door for adding or removing some items when the icon

is lighted on.

1. Touch the Start / Pause button.

In the display the related door lock indicator goes off.

2. Open the appliance door. If necessary, add or remove the items.

3. Close the door and touch the Start /

Pause button.

The programme or the delay start continues.

When the icon goes off, the door can be opened when the programme is complete. You may also set a spinning or draining programme/option and than

press Start / Pause button. If the spin and drain programmes are not available in the programme dial, they can be set via App.

13.12 End of the programme

When the programme has finished, the appliance stops automatically. The

acoustic signals operate (if they are active).

In the display all washing phase indicators become steady and the time

area shows .

The indicator of the Start / Pause button goes off.

The door unlocks and the indicator goes off.

1. Press the On/Off button to deactivate the appliance.

After five minutes from the end of the programme, the energy saving function automatically deactivates the appliance.

When you activate the appliance again, the display show the end of the last selected programme. Turn the programme dial to set a new cycle.

2. Remove the laundry from the appliance.

3. Make sure that the drum is empty.

4. Keep the door and the detergent dispenser slightly ajar to prevent mildew and odours.

5. Close the water tap.

13.13 Draining water out after

end of cycle

If you have chosen a programme or an option that does not empty out the water of the last rinse, the programme is completed, but:

• The display shows the indicator , the

option indicator or and the

door locked indicator . The

indicator of the running phase flashes.

• The drum still turns at regular

intervals to prevent the creases in the laundry.

• The door stays locked.

• You must drain the water to open the

door:

1. If necessary, touch the Spin button to decrease the spin speed proposed by the appliance.

2. Touch the Start / Pause button:

ENGLISH 41

• If you have set , the appliance drains the water and spins.

• If you have set , the appliance only drains the water.

The option indicator or goes off,

while the indicator goes off.

3. When the programme is completed

and the door locked indicator goes off, you can open the door.

4. Press the On/Off button a few seconds to deactivate the appliance.

In any case, the appliance empties the water out automatically after approximately 18 hours.

flashes and then

13.14 Stand-by option

The Stand-by function automatically deactivates the appliance to decrease the energy consumption when:

• You do not use the appliance for 5

minutes before you touch the Start /

Pause

button.

14. HINTS AND TIPS

Press the On/Off button to activate the appliance again.

• After 5 minutes from the end of the washing programme Press the On/Off button to activate the appliance again. The display shows the end of the last set programme. Turn the programme dial to set a new cycle.

If you set a programme or an option that ends with water in the drum, the Stand-by function doesn't deactivate the appliance to remind you to drain the water.

If the Wi-Fi Always On function is active, only the indicator goes on and off intermittently.

WARNING!

Refer to Safety chapters.

14.1 The laundry load

• Divide the laundry into: white, coloured, synthetics, delicates and wool.

• Follow the washing instructions on the laundry care labels.

• Do not wash white and coloured items together.

• Some coloured items can discolour with the first wash. We recommend that you wash them separately for the first couple of times.

• Turn multilayered fabrics, wool and items with printed illustrations inside out.

• Pre-treat stubborn stains.

• Wash stubborn stains with a special detergent.

• Be careful with curtains. Remove the hooks and put the curtains in a washing bag or pillowcase.

• A very small load can cause balance problems with the spin phase leading to excessive vibration. If this occurs:

a. interrupt the programme and

open the door (refer to "Daily Use" chapter);

b. manually redistribute the load so

that the items are spaced evenly around the tub;

c. press the Start / Pause button.

The spin phase continues.

• Button up pillowcases, close zippers, hooks and poppers. Tie up belts, cords, shoelaces, ribbons and any other loose elements.

• Do not wash laundry without hems or with cuts. Use a washing bag to wash small and/or delicate items (e.g. underwired bras, belts, tights, shoelaces, ribbons, etc. ).

www.aeg.com42

• Empty pockets and unfold the items.

14.2 Stubborn stains

For some stains, water and detergent is not sufficient.

We recommend that you pre-treat these stains before you put the items in the appliance.

Special stain removers are available. Use the special stain remover that is applicable to the type of stain and fabric.

Do not spray stain remover on garments near the appliance as it is corrosive to the plastic parts.

14.3 Detergent type and quantity

The choice of detergent and use of correct quantities not only affects your wash performance, but also helps to avoid waste and protect the environment:

• Use only detergents and other treatments specially made for

washing machines. First, follow these generic rules:

– powder detergents (also tablets

and single-dose detergents) for all types of fabric, excluding delicate. Prefer powder detergents containing bleach for whites and laundry sanitization,

– liquid detergents (also single-dose

detergents) , preferably for low temperature wash programmes (60 °C max) for all types of fabric, or special ones for woollens only.

• The choice and quantity of detergent will depend on: type of fabric (delicates, woollens, cottons, etc), the colour of clothes, size of the load, degree of soiling, wash temperature and hardness of the water used.

• Follow the instructions that you find on packaging of the detergents or other treatments without exceeding

the indicated maximum level (

• Do not mix different types of detergents.

• Use less detergent if:

– you are washing a small load, – the laundry is lightly soiled, – there is large amounts of foam

during washing.

• When using detergent tabs or pods, always put them inside the drum, not in the detergent dispenser and follow the manufacturer's recommendations .

Insufficient detergent may cause:

• unsatisfactory washing results,

• the wash load to turn grey,

• greasy clothes,

• mould in the appliance.

Excessive detergent may cause:

• sudsing,

• reduced washing effect,

• inadequate rinsing,

• a greater impact for the environment.

14.4 Ecological hints

To save water, energy and to help protect the environment, we recommend that you follow these tips:

• Normally soiled laundry may be washed without prewash in order to save detergent, water and time (the environment is protected too!).

ENGLISH 43

• Loading the appliance to the

maximum capacity indicated for each programmes helps to reduce energy and water consumption.

• With adequate pre-treatment, stains and limited soiling can be removed; the laundry can then be washed at a lower temperature.

• To use the correct quantity of detergent, refer to the quantity suggested by the detergent producer and check the water hardness of you domestic system. Refer to 'Water hardness'.

• Set the maximum possible spin speed for the selected washing programme before drying your

15. CARE AND CLEANING

WARNING!

Refer to Safety chapters.

15.1 Periodic cleaning

schedule

Periodic cleaning helps to extend the life of your appliance.

After each cycle, keep the door and the detergent dispenser slightly ajar to get air circulation and dry the humidity inside the appliance: this will prevent mildew and odours.

If the appliance is not used for a long time: close the water tap and unplug the appliance.

Indicative periodic cleaning schedule:

Descaling Twice a year

Maintenance wash Once a month

Clean door seal Every two months

Clean drum Every two months

Clean detergent dis‐ penser and Auto‐ Dose tanks

Clean drain pump filter

Twice a year

laundry in a tumble dryer. This will save energy during drying!

14.5 Water hardness

If the water hardness in your area is high or moderate, we recommend that you use a water softener for washing machines. In areas where the water hardness is soft it is not necessary to use a water softener.

To find out the water hardness in your area, contact your local water authority.

Use the correct quantity of water softener. Follow the instructions that you find on the packaging of the product.

Clean the inlet hose and the valve filter

The following paragraphs explain how you should clean each part.

Twice a year

15.2 Removing foreign objects

Make sure that pockets are empty and all loose elements are tied up before running your cycle. Refer to "The laundry load" in "Hints and tips".

Remove any foreign objects (such as metal clip, buttons, coins, etc) that you may find in the door seal, the filters and the drum. Refer to "Door seal with double lip trap", "Cleaning the drum", "Cleaning the drain pump" and "Cleaning the inlet hose and the valve filter" paragraphs. If necessary, please contact the Authorised Service Centre.

15.3 External cleaning

Clean the appliance with mild soap and warm water only. Fully dry all the surfaces.

Do not use a scouring pads or any scratching material.

www.aeg.com44

CAUTION!

Do not use alcohol, solvents or chemical products.

CAUTION!

Do not clean the metal surfaces with chlorine-based detergent.

15.4 Descaling

If the water hardness in your area is high or moderate, we recommend that you use a water descaling product for washing machines.

Regularly examine the drum to check for limescale.

The regular detergents already contain water softening agents, but we recommend to run a cycle with empty drum and a descaling product occasionally.

Always follow the instructions that you find on the packaging of the product.

15.5 Maintenance wash

The repeated and prolonged use of low temperature and short programmes can cause detergent deposits, fluff residues, bacterial growth and biofilm formation inside the drum and the tub. This could generate bad odours and mildew.

To eliminate these deposits and hygienize the inner part of the appliance, run a maintenance wash at least once a month:

1. Remove all laundry from the drum.

2. Deactivate AutoDose function for detergent and softener.

3. Run a cotton programme with the highest temperature with a small quantity of powder detergent or, if available, run the Machine Clean programme.

15.6 Door seal

This appliance is designed with a self cleaning draining system, allowing light

fluff fibers that fall off the clothes to be drained out with the water. Regularly examine the seal. Coins, buttons, other small items can be recovered at the end of the cycle.

Clean it when needed, using ammonia cream cleanser agent without scratching the seal surface.

Always obey the instructions that you find on the packaging of the product.

15.7 Cleaning the drum

Regularly examine the drum to prevent unwanted deposits.

Rust deposits in the drum may occur due to rusting foreign body in the washing or tap water containing iron

Clean the drum with special products for stainless steel.

Always follow the instructions that you find on the packaging of the product. Do not clean the drum with acidic descaling products, scouring products containing chlorine or iron or steel wool.

For a thorough clean:

1. Clean the drum with special products for stainless steel.

Always follow the instructions that you find on the packaging of the product.

2. Remove all laundry from the drum.

3. Deactivate AutoDose function for detergent and softener.

4. Run a short cotton programme at high temperature with empty drum and with a small quantity of powder detergent or, if available, run the Machine Clean programme. If your appliance can be connected to Wi-Fi, the special programme Machine Clean is also downloadable through the APP.

5. Add a manually small quantity of powder detergent or a specific product into the empty drum, in order to rinse out any left residues.

Occasionally, at the end of a cycle the display may show

the icon : this is a recommendation to perform the “drum cleaning”. Once the drum cleaning has been performed, the icon disappears.

15.8 Cleaning the detergent

dispenser and the AutoDose tanks

ENGLISH 45

2. Remove the insert for the softener and, if inserted, the container for liquid detergent.

CAUTION! Do not change brand or type of detergent, fabric softener or additives inside the tanks without cleaning both tanks before.

Before cleaning, make sure that the all compartments are empty.

To prevent possible deposits of dried detergent, clotted fabric softener, formation of mould in the detergent dispenser and/or clotted liquid additives in the AutoDose tanks, once in a while

carry out the following cleaning procedure:

1. Open the detergent dispenser. Press the catch as indicated in the picture and pull the detergent dispenser out.

3. Open the drain plugs of each tank and empty them into a sink.

www.aeg.com46

4. Press the catch on the back as indicated in the picture and lift up the top cover to remove it.

5. Wash the drawer and all inserts under running water.

7. Make sure that all detergent residue is removed from the conveyor. Use only soft damp clothes.

8. Put bottom cover back to its position by aligning its holes on drawer hooks as indicated in the picture. Close it till "click" sound.

CAUTION! Do not use sharp or metal brushes and sponges.

6. Turn the dispenser up side down and open the bottom cover as indicated in the picture.

CAUTION! Press the bottom cover as indicated in the picture. Make sure that it is closed properly.

WARNING! Do not clean with any sharp and metal brushes ora any tools, pumps or sensors allocated on the back of the detergent drawer. If necessary, use only soft damp clothes.

ENGLISH 47

9. Make sure that all detergent residue is removed from the upper and lower part of the recess. Use a small brush to clean the recess.

WARNING!

If some residues remain on the back area of tanks, soak detergent drawer in a warm water. Do not use tools to clean it. Before soaking, remove the handle by pressing red button and slide the handle as indicated in the picture.

10. Reassembly the drawer as follows:

a. Place the handle if was

disassembled.

b. Place the bottom cover and

press till "click" sound.

c. Place the top cover on the tanks

compartment and press till "click" sound.

d. Replace components on manual

compartment.

11. Insert the detergent dispenser into the guide rails and gently close it till "click" sound. Run the rinsing programme without any clothes in the drum.

www.aeg.com48

To restore the functionality, refill tanks with detergent and softener. If you place a wrong additives in the tanks, you can easily recover it by using the drain plug on both side of the drawer. Before opening drain plugs ensure to place below the drawer a basin or suitable containers to collect the liquid. Ensure to properly close the plugs before refilling.

15.9 Cleaning the drain pump

WARNING!

Disconnect the mains plug from the mains socket.

Proceed as follows to clean the pump:

1. Open the pump cover.

2. Place a suitable bowl below the drain pump access to collect the water that flows out.

3. Open the chute downwards. Always keep a rag nearby to dry up any water spillages when removing the filter.

Regularly check the drain pump filter and make sure that it is clean.

Clean the drain pump if:

• The appliance does not drain the water.

• The drum does not turn.

• The appliance makes an unusual noise because of the blockage of the drain pump.

• The display shows the alarm code

WARNING!

• Do not remove the filter while the appliance operates.

• Do not clean the pump if the water in the appliance is hot. Wait until the water cools down

4. Turn the filter 180 degrees in anticlockwise direction to open it, without removing. Let the water flow out.

5. When the bowl is full of water, turn the filter back and empty the container.

6. Repeat the steps 4 and 5 until the

water stops to flow out.

7. Turn the filter anti-clockwise to remove it.

8. If it is necessary, remove fluff and objects from the filter recess.

9. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre.

ENGLISH 49

12. Close the pump cover.

When you drain the water with the emergency drain procedure, you must activate the drain system again:

a. Put 2 litres of water in the main

wash compartment of the detergent dispenser.

b. Start the programme to drain the

water.

10. Clean the filter under the water tap.

15.10 Cleaning the inlet hose and the valve filter

It is recommended to clean both the filters of the inlet hose and valve occasionally to remove any deposit, collected over the time:

1. Remove the inlet hose from the tap and clean the filter.

11. Put the filter back into the special guides by turning it clockwise. Make sure that you tighten the filter correctly to prevent leakages.

45°

20°

www.aeg.com50

2. Remove the inlet hose from the appliance by loosening the ring nut.

3. Clean the valve filter on the back of the appliance with a toothbrush.

4. When you reconnect the hose to the back of the appliance, turn it left or right (not in vertical position) depending on the position of your water tap.

15.11 Emergency drain

If the appliance cannot drain the water, carry out the same procedure, described in 'Cleaning the drain pump' paragraph. If necessary, clean the pump.

When you drain the water with the emergency drain procedure, you must activate the drain system again:

1. Put 2 litres of water in the main wash compartment of the detergent dispenser.

2. Start the programme to drain the water.

15.12 Frost precautions

If the appliance is installed in an area where the temperature can reach the values around 0° C or drop below, remove the remaining water from the inlet hose and the drain pump.

1. Disconnect the mains plug from the mains socket.

2. Close the water tap.

3. Put the two ends of the inlet hose in a container and let the water flow out of the hose.

4. Empty the drain pump. Refer to the emergency drain procedure.

5. When the drain pump is empty, install the inlet hose again.

WARNING!

Make sure that the temperature is higher than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures.

16. TROUBLESHOOTING

WARNING!

Refer to Safety chapters.

ENGLISH 51

16.1 Alarm Codes and Possible failures

The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables).

WARNING!

Deactivate the appliance before carrying out any check.

With some problems, the display shows an alarm code and the

Start / Pause button may flash continuously:

If the appliance is overloaded, remove some items from the drum and/or keep pressed the door while touching the Start / Pause button until the indicator

stops flashing (see the picture below).

Problem Possible solution

• Make sure that the water tap is open.

The appliance does not fill with water prop‐ erly.

The appliance does not drain the water.

• Make sure that the pressure of the water supply is not too low. For this information, contact your local water authority.

• Make sure that the water tap is not clogged.

• Make sure that the inlet hose has no kinks, damages or bends.

• Make sure that the connection of the water inlet hose is cor‐ rect.

• Make sure that the filter of the inlet hose and the filter of the valve are not clogged. Refer to 'Care and cleaning'.

• Make sure that the sink spigot is not clogged.

• Make sure that the drain hose has no kinks or bends.

• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Refer to "Care and cleaning".

• Make sure that the connection of the drain hose is correct.

• Set the drain programme if you set a programme without drain phase. If the drain programme is not available in the pro‐ gramme dial, it can be set via App.

• Set the drain programme if you set an option which ends with water in the tub.

www.aeg.com52

• Make sure that the door is properly closed.

The appliance door is open or not closed correctly.

• The programme was not finished properly or the appliance

Internal fail. No com‐ munication between electronic elements of

stopped too early. Switch the appliance off and on again.

• If the alarm code appears again, contact the Authorised Serv‐ ice Centre.

the appliance.

: Frequency of power supply is out of range.

: Supply voltage is too high.

: Supply voltage is too low.

• Disconnect the appliance and close the water tap. Contact the

The anti-flood device

Authorised Service Centre.

is on.

If the display shows other alarm codes, deactivate and activate the appliance. If the problem continues, contact the Authorised Service Centre. In case of different problem with the washing machine check the table below for possible solutions.

Problem Possible solution

• Make sure that the mains plug is connected to the mains socket.

• Make sure that the appliance door is closed.

• Make sure that there is no damaged fuse in the fuse box.

The programme does

not start.

• Make sure that the Start / Pause has been touched.

• If the delay start is set, cancel the setting or wait for the end of countdown.

• Make sure that the detergent dispenser is firmly closed.

• Deactivate the Child Lock function if it is on.

• Check the position of the knob on the selected programme.

The appliance fills with water and drains im‐ mediately.

• Make sure that the drain hose is in the correct position. The hose may be positioned too low. Refer to "Installation instruc‐ tion".

• Set the spin programme. If the drain programme is not availa‐

The spin phase does not operate or the washing cycle lasts longer than usual.

ble in the programme dial, it can be set via App’.

• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Refer to "Care and cleaning".

• Adjust manually the items in the tub and start the spin phase again. This problem may be caused by balance problems.

Problem Possible solution

• Make sure that the couplings of the water hoses are tight and there is not water leakages.

There is water on the floor.

• Make sure that the water inlet hose and the drain hose have no damages.

• Make sure you use the correct detergent and the correct quantity of it.

• Make sure that a washing programme that ends with water in tub, has not been selected.

• Make sure that the washing programme is finished.

• Set the drain or the spin programme if there is water in the drum. If the spin and drain programmes are not available in

You cannot open the appliance door.

the programme dial, they can be set via App.

• Make sure that the appliance receives electrical power.

• This problem may be caused by a failure of the appliance. Contact the Authorised Service Centre. If you need to open the door, please read carefully "Emergen‐ cy door opening".

• Make sure that the Remote Start Mode is not activated. Deac‐ tivate it.

• Check the wireless signal.

• Make sure that the wireless connection is on. Refer to para‐

The display does not show the wireless indi‐ cator .

graph "Configuring the washing machine wireless connection" in "Wi-Fi - Connectivity setup" chapter.

• Check your home network and router.

• Restart the router.

• Contact your wireless service provider if there are further problems with the wireless network.

• Check the wireless signal.

• Check if your smart device is connected to the wireless net‐ work.

• Check your home network and router.

The App cannot con‐ nect to the appliance.

• Restart the router.

• Contact your wireless service provider if there are problems with the wireless network.

• The appliance, the smart device, or both, need to be config‐ ured again because a new router has been installed or the router configuration has been changed.

• Make sure that the wireless signal reaches the appliance. Try

The App cannot fre‐ quently connect to the appliance.

to move the home router as near the appliance as possible or consider purchasing a wireless range extender.

• Make sure the wireless signal is not disrupted by microwave. Turn the microwave off. Avoid using the microwave and the remote control at the same time.

ENGLISH 53

www.aeg.com54

Problem Possible solution

The display shows

. All buttons are inactive, except the the On/Off .

• The appliance is downloading any available updates. Wait un‐ til the update process is complete. If you deactivate the appli‐ ance during update, it resumes when you activate the appli‐ ance again.

• Make sure the levelling of the appliance is correct. Refer to

The appliance makes an unusual noise and vibrates.

"Installation instruction".

• Make sure that the packaging and/or the transit bolts are re‐ moved. Refer to "Installation instruction".

• Add more laundry in the drum. The load may be too small.

The programme dura‐ tion increases or de‐ creases during pro‐

• The ProSense System is able to adjust the programme dura‐ tion according to the type and the laundry load size. Refer to "The ProSense System load detection" in "Daily Use" chapter.

gramme execution.

• Increase the detergent quantity or use a different detergent.

• Use special products to remove the stubborn stains before you wash the laundry.

• Make sure that you set the correct temperature.

• Decrease the laundry load.

The washing results are not satisfactory.

• When using AutoDose tanks, make sure that they are not empty.

• When using AutoDose tanks, verify the pre-set detergent/ fabric softener dosage. Refer to "Basic setting" paragraph in "The AutoDose Technology" chapter.

• Make sure that you have cleaned the AutoDose tanks before using different brand and type of detergent, fabric softener or other additives.

• Reduce the quantity of detergent or the number of tablets or

Too much foam in the drum during the wash‐ ing cycle.

single-dose detergents.

• When using AutoDose tanks, verify the pre-set detergent/ fabric softener dosage. Refer to "Basic setting" paragraph in "The AutoDose Technology" chapter.

The detergent/fabric softener level does not

• This is normal: tanks are quite large and detergent consump‐ tion may be not so evident.

decrease in the Auto‐ Dose tanks after wash‐ ing.

After the check, activate the appliance. The programme continues from the point of interruption. If the problem occurs again, contact the Authorised Service Centre. The necessary data for the service centre are on the rating plate.

ENGLISH 55

16.2 Emergency door opening

In case of power failure or functioning failure the appliance door remains locked. The washing programme continues when the power is restored. If the door remains locked in case of failure, it is possible to open it using the emergency unlock function.

Before opening the door:

CAUTION! Risk of burns! Make sure that the water temperature is not too high and the laundry is not hot. If necessary, wait until they cool down.

CAUTION! Risk of injury! Make sure that the drum is not rotating. If necessary, wait until the drum stops rotating.

Make sure that the water level inside the drum is not too high. If necessary, proceed with an emergency drain (refer to «Emergency drain» in «Care and cleaning» chapter).

To open the door, proceed as follows:

1. Press the On/Off button to switch the appliance off.

2. Disconnect the mains plug from the mains socket.

3. Open the filter flap.

4. Pull the emergency unlock trigger downward once. Pull it downward once again, keep it tensed and, in the meanwhile, open the appliance door.

5. Take out the laundry and then close the appliance door.

6. Close the filter flap.

17. CONSUMPTION VALUES

17.1 Introduction

See the web link www.theenergylabel.eu for detailed information about Energy Label.

For Non EU

The QR code on the energy label supplied with the appliance provides a web link to the product information sheet. Keep the energy label for reference together with the user manual and all other documents provided with this appliance.

www.aeg.com56

17.2 Legend

kg Laundry load. hh:mm Programme duration.

kWh Energy consumption. °C Temperature in the laundry.

Litres Water consumption. rpm Spin speed.

% Remaining moisture at the end of spinning phase. The higher is the spin speed,

the higher is the noise and the lower is the remaining moisture.

Values and programme duration may differ depending on different conditions (e.g. room temperature, water temperature and pressure, load size and type of laundry, supply voltage) and also if you change the default setting of a programme.

17.3 According to UK Ecodesign for EnergyRelated Products and Energy Information Regulations

Eco 40-60 pro‐ gramme

Full load 9.0 0.820 55.0 03:40 53.00 35.0 1351

Half load 4.5 0.540 45.0 02:35 53.00 33.0 1351

Quarter load 2.5 0.185 38.0 02:30 54.00 23.0 1351

1) Maximum spin speed.

kg kWh Litres hh:mm % °C

rpm

Power consumption in different modes

Off (W) Stand-by (W)

0.50 0.50 4.00

Time to Off/Standby mode is 15 minutes maximum.

1) The energy consumption of the connected function is approximately 17.5 kWh per year. To disconnect

this function, please refer to the chapter 'Wi-fi - Connectivity setup'.

Delay start

(W)

Networked

standby (W)

2.00

17.4 Common programmes

These values are indicative only.

3 3

ENGLISH 57

Programme

Cottons 95°C

Cottons 60°C

Cottons 20°C

Synthetics 40°C

Delicates

30°C

Wool 30°C

1) Reference indicator of the spin speed.

2) Suitable for washing heavily soiled textiles.

3) Suitable for washing lightly soiled cottons, synthetic and mixed fabrics.

4) It also performs as quick washing cycle for lightly soiled laundry.

18. QUICK GUIDE

18.1 Daily use

kg kWh Litres hh:mm % °C

rpm

9.0 2.700 90.0 04:05 52.00 85.0 1400

9.0 1.600 85.0 03:50 52.00 55.0 1400

9.0 0.350 85.0 03:00 52.00 20.0 1400

4.0 0.800 55.0 02:15 35.00 40.0 1200

2.0 0.400 60.0 01:05 35.00 30.0 1200

1.5 0.300 65.0 01:05 30.00 30.0 1200

• Connect the mains plug to the mains

socket.

• Open the water tap.

• Push the On/Off button to turn the

appliance on (1).

• Turn the programme dial to set the

desired programme (2).

• Set the desired options by means of

the corresponding touch buttons (3).

• Put the laundry in the drum, one item

a time without exceeding the maximum suggested load. Close the door and make sure that no laundry stays between the seal and the door.

• When using AutoDose tanks, the detergent and fabric softener are uploaded automatically. Make sure that tanks are not empty. When using manual compartments, pour the detergent and other treatments in the proper compartment.

Manual

Aut oDo se

(Manual)

1 32

180˚

www.aeg.com58

When using a liquid detergent in manual compartment, insert the container for liquid detergent.

18.2 Cleaning the drain pump filter

• To start the programme, touch the

Start / Pause button (4).

• The appliance starts.

• At the and of the programme, remove the laundry.

• Push the On/Off button to turn the appliance off.

Clean the filter regularly and, especially,

if the alarm code appears on the display.

18.3 Programmes

Programmes Load Product description

MixLoad 69min

Eco 40-60

Cottons

Synthetics

Cotton and synthetic items. This programme

5.0 kg

9.0 kg

4.0 kg Synthetic items or mixed fabric items.

ensures a good washing performance in a short time.

Low energy cycle for cottons. Decreases tem‐ perature and extends time to reach good washing results.

White and coloured cotton fabrics. Ideal for normal and heavy soil.

Programmes Load Product description

ENGLISH 59

Delicate fabrics such as acrylics, viscose, pol‐ yester items.

Machine washable wool, hand washable wool and delicates.

Cotton and synthetic lightly soiled items or once worn items.

Cotton and synthetic items that need to dewrinkle.

Modern outdoor sporting garments.

Delicates

Wool

20min 3kg

Steam

Outdoor

2.0 kg

1.5 kg

3.0 kg

1.0 kg

2.0 kg

1.0 kg

White cotton items. This programme removes

Hygiene

Rinse

9.0 kg

more than 99,99% of bacteria and viruses 3). It also ensure a proper reduction of allergens.

All fabrics, except woollens and very delicate fabrics. Programme for rinsing and spinning.

To spin the laundry and to drain the water in

Spin/Drain

1) Washing programme.

2) Washing programme and waterproofing phase.

3) Tested for Staphylococcus aureus, Enterococcus faecium, Candida albicans, Pseudomonas aerugino‐

sa and MS2 Bacteriophage in external test performed by Swissatest Testmaterialien AG in 2021 (Test Report No. 202120117).

9.0 kg

the drum. All fabrics, except woollens and del‐ icate fabrics.

19. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol . Put the packaging in relevant containers to recycle it. Help protect the environment and human health by recycling waste of electrical and electronic appliances. Do not dispose of

appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.

My AEG Care app

The software in this product contains components that are based on free and open source software. AEG gratefully acknowledges the contributions of the open software and robotics communities to the development project.

To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, please visit: http://aeg.opensoftwarerepository.com (folder NIUS)

www.aeg.com/shop

157059821-A-312022

Aeg LFR74944AD, 914 501 016 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

CONTENTS

1. SAFETY INFORMATION

1.1 Children and vulnerable people safety

1.2 General Safety

2. SAFETY INSTRUCTIONS

2.1 Installation

2.2 Electrical connection

2.3 Water connection

2.4 Use

2.5 Service

3. PRODUCT DESCRIPTION

3.1 Special features

2.6 Disposal

3.2 Appliance overview

4. TECHNICAL DATA

5. INSTALLATION

5.1 Unpacking

5.2 Installation on suspended flooring

5.3 Positioning and levelling

5.4 Fixing plate kit

5.5 The inlet hose

5.6 Water drainage

5.7 Electrical connection

6. CONTROL PANEL

6.1 Control panel description

6.2 Display

7. DIAL AND BUTTONS

7.1 On/Off

7.2 Programme dial

7.3 Favourite programmes

7.4 Introduction

7.7 Finish In

7.6 Remote start

7.8 Start / Pause

7.9 Plus Steam

7.10 Extra Rinse

7.11 Time Save

7.12 Stains/Prewash

7.13 Spin

7.14 Temperature

8. SETTINGS

8.1 Introduction

8.2 Acoustic signals

8.3 Child Lock

8.4 Operating Hours Counter

8.5 Factory Defaults

9. BEFORE FIRST USE

10. THE AUTODOSE TECHNOLOGY (AUTODOSING)

10.1 Introduction

10.2 Detergent dispenser with AutoDose tanks and manual compartments

10.3 AutoDose basic setting

10.5 Filling the detergent and additives on AutoDose system

10.6 AutoDose low level indication

10.7 Switching from AutoDose to manual dosing

10.9 Manual filling the detergent and additives

Manual filling the liquid detergent

10.10 Drawer open indication

11. PROGRAMMES

11.1 My AEG Care app and additional hidden programmes

11.2 Programme Chart

11.3 Steam programme with AEG Steam Fragrance

11.4 Woolmark Wool Care - Blue

11.5 Options compatibility with programmes

12. WI-FI - CONNECTIVITY SETUP

12.1 QR code on rating plate

12.2 Installing and configuring My AEG Care

12.3 Configuring the appliance wireless connection

12.4 Remote Start

12.5 Over-the-air update

12.6 Wi-Fi Always On

13. DAILY USE

13.1 Activating the appliance

13.2 Loading the laundry

13.3 Using detergent and other treatments

13.4 Setting a programme

13.5 Starting a programme
