AEG LAV6410, LAV64600 User Manual
LAVAMAT 66600
Washing Machine
User information
Dear Customer,
Please read this user information carefully and keep it to refer to later.
Please pass the user information on to any future owner of the appliance.
The following symbols are used in the text:
1 Safety instructions
Warning! Information that affects your personal safety.
Important! Information that prevents damage to the appliance.
3 Useful tips and hints
2 Environmental information
2
Contents
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Programme overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Before the first wash. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Preparing and sorting washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Running a wash cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Opening the door/loading washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Adding detergent /conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Switching on the appliance/selecting a programme . . . . . . . . . . . . . . . . . . . 13
Changing the spin speed/selecting rinse hold . . . . . . . . . . . . . . . . . . . . . . . . 13
Selecting additional programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
RINSE + . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
TIME SAVER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
PRE WASH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
STAIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the delay timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Starting a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Interrupting a programme/adding washing . . . . . . . . . . . . . . . . . . . . . . . . . . 16
End of the wash cycle/removing the washing . . . . . . . . . . . . . . . . . . . . . . . . 16
Child safety device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
What to do if.... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Remedying small faults yourself . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
If the wash result is not satisfactory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Carrying out an emergency drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Drain pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Consumption values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3
Installation and connection instructions. . . . . . . . . . . . . . . . . 26
Safety information concerning installation . . . . . . . . . . . . . . . . . . . . . . . . 26
Installing the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Transporting the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Removing the transit packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Where to install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Making the appliance level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Connecting the appliance to the water supply . . . . . . . . . . . . . . . . . . . . . 31
Water inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Water Drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Service and Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4
Operating Instructions
1 Safety
Prior to using the appliance for the first time
• Follow the “Installation and connection instructions”.
• If the appliance is delivered in the winter months when there are mi-
nus temperatures: store the washing machine at room temperature
for 24 hours before using for the first time.
Correct use
• The washing machine is only designed for the washing of normal domestic laundry at home.
• Additions or modifications to the washing machine are not permitted.
• Only use detergents/conditioners that are suitable for use in domestic
washing machines.
• The washing must not contain any flammable solvent. The risk of explosion exists.
• Do not use the washing machine for dry cleaning.
• Dyes/colour removers may only be used in the washing machine, if
the manufacturer of these products expressly permits this. We cannot
accept liability for any damage arising.
Child safety
• Keep packaging away from children. There is a risk of suffocation.
• Children often do not recognise the hazards associated with electrical
appliances. Don’t allow children to use the washing machine unsupervised.
• Make sure that children and pets don’t climb into the drum of the
washing machine. The risk of death exists.
5
General safety
• Repairs to the washing machine may only be carried out by qualified/
authorised service engineers.
• Never use the appliance when the electrical cable is damaged or the
control panel, worktop or plinth area are damaged to such an extent
that the inside of the appliance is openly accessible.
• Switch off the washing machine prior to cleaning it and carrying out
maintenance. In addition, remove the power plug from the power
point or – if the appliance has been hard-wired – switch off the cutout in the fuse box or completely remove the fuse.
• If operation is stopped, disconnect the appliance from the mains supply and turn off the tap.
• Never remove the power plug from the power point by pulling on the
cable. Always pull the plug.
• Multiway-plugs, connectors and extension cables must not be used.
Resulting overheating may constitute a fire hazard.
• Never wash the washing machine down with a water jet. Danger of
electric shock.
• When using wash programmes with high temperatures the glass in
the door will become hot. Do not touch it!
• Before emergency emptying of the appliance, before cleaning the
drain pump or opening the door in an emergency, let the water cool
down.
• Small animals can nibble on electrical cables and water hoses. This
can constitute a risk of electrocution and water damage. Keep small
animals away from the washing machine.
6
Description of the appliance
A
Detergent drawer
Rating plate
(behind door)
Screw feet
(height adjustable)
Control panel
Spin/RINSE HOLD button
DELAY TIMER button
Control panel
Plinth flap/
Drain pump
Multi-display
Programme progress display
dditional programme
buttons
START/PAUSE button
DOOR indicator
Programme selector
7
Programme overview
Programme
1)
Additional programmes Spin speed
ENERGY SAVING
COTTONS/LINEN
95, 60, 50, 40, 30
EASY-CARES
60, 50, 40, 30
max. load
2)
5kg • • • • • •
5kg • •
2,5kg • • • •
RINSE +
TIME SAVER
PRE WASH
STAIN
1600
(dry washing)
3)
• •
4)
• • •
4)
700
• •
EASY IRON 40 1kg • • • • • •
DELICATES
40, 30
WOOL/SILK H (Hand-washing)
40, 30, COLD
2,5kg • • • • •
2kg • •
RINSE 2,5kg • •
DRAIN
SPIN 5kg • •
REFRESH 2,5kg • •
RINSE HOLD
1) A 10 litre bucket contains approx. 2.5 kg dry washing (cotton)
2) Programme settings for tests in accordance with or in the style of EN 60 456 and IEC 60 456 are described in the chapter “Consumption values”.
3) Recommended load for short progammes is 2,5 kg; full loading is possible however with somewhat reduced cleaning results.
4) STAIN can only be set from 40° upwards, as stain removal agent only becomes effective at higher temperatures.
8
Application/Features
Care
symbols
1)
Energy-saving programme which washes at 60 °C for lightly to normally
soiled whites or coloureds made of cotton/linen.
Programme for normally to heavily soiled whites/coloureds made of cotton/
linen.
Programme for easy-care mixed fibres and synthetics.
Special programme which washes at 40 °C for easy-care fabrics which after
being washed using this programme need to be ironed only lightly or not at
Gentle programme for delicate textiles such as bonded fibres, micro-fibres,
synthetics, net curtains (load max. 15 to 20 m
with RINSE HOLD, also suitable for fabrics with climatic membranes, e.g.
Specially gentle programme for machine and hand-washable wool/silk.
Separate gentle rinse (3 rinse cycles, liquid conditioner is washed in from the
compartment
Draining following a rinse hold.
Draining and spinning, e.g. following a rinse hold, or separate spinning of
hand-washed cottons/linen.
Special programme which washes at 30 °C, approx. 30 minutes, for brief
washing of e.g. worn-once, lightly soiled sports clothing or new clothes.
1) The figures in the care symbols indicate the maximum temperatures.
, gentle spin).
&
2
curtains). If used together
M O
J M O
I K N
K N
I K
Q L H
I K N
Q L
H
J M O
J M O
I K N
9
Before the first wash
1. Open the detergent drawer.
2. Pour approx. 1 litre of water through the detergent drawer into the
washing machine.
This closes the water container when the next programme is started
and the economy valve can function properly
3. To remove any production-related residues from the drum and water
tank, perform the first wash cycle without a load. Programme: COTTONS/LINEN 60, press the TIME SAVER button, add approx. 1/4 measuring cup of detergent.
Preparing and sorting washing
Preparing washing
• Empty the pockets. Remove foreign bodies (e.g. coins, paper clips,
nails, etc.).
• Do up zips, button up covers to prevent damage to washing.
• Remove the runners from net curtains or cover them with a net or a
bag.
• Wash delicate and small items in a net/pillowcase, e. g. net curtains,
tights, small socks, handkerchiefs, bras.
Important: Bras and other items containing wires should only be
washed in a net bag. The wires can work loose and damage the appliance.
10
Sorting washing
• By colour: Wash white and coloured washing separately. Washing can
run.
• By temperature, type of washing and care symbol.
Important: Do not wash fabrics with the G care symbol (= do not
wash!) in the washing machine.
Running a wash cycle
Opening the door/loading washing
1. Open the door: pull the handle on the door.
When the appliance is switched on, the DOOR and START/PAUSE indicators show whether the door can be opened:
DOOR indicator START/PAUSE indicator Can the door be opened?
illuminated green
illuminated green illuminated red
illuminated red
or not illuminated
flashing red or not illumi-
nated
flashing red
or illuminated red
yes, after pressing the
START/PAUSE button
no, water level and/or
temperature too high
2. Separate washing and load it loosely. Mix large and small items.
Important: Do not get any washing
caught between the door and the
rubber seal.
3. Firmly push the door shut. Door
catch must audibly click shut.
Adding detergent /conditioner
Important: Only use detergents/conditioners that are suitable for use
in household washing machines.
Add detergent/conditioner in accordance with the detergent/condi-
tioner manufacturer’s instructions. Observe instructions on the packaging.
The amount of detergent used depends on:
– the degree of soiling,
– the load size
– the hardness of the tap water.
• If the manufacturer does not make any recommendations with re-
gard to small volumes of washing: For a half-load use a third less, and
for a very small load use only the half the amount of detergent that
is recommended for a full load.
yes
11
