USER
MANUAL
L8TE73C
EN User Manual
Washing Machine
www.aeg.com
2
CONTENTS
1. SAFETY INFORMATION.............................................................................................3
2. SAFETY INSTRUCTIONS.............................................................................................4
3. PRODUCT DESCRIPTION...........................................................................................6
4. CONTROL PANEL....................................................................................................... 7
5. PROGRAMME CHART................................................................................................ 9
6. CONSUMPTION VALUES......................................................................................... 14
7. OPTIONS....................................................................................................................15
8. SETTINGS...................................................................................................................17
9. BEFORE FIRST USE................................................................................................... 18
10. DAILY USE................................................................................................................18
11. HINTS AND TIPS..................................................................................................... 22
12. CARE AND CLEANING.......................................................................................... 23
13. TROUBLESHOOTING.............................................................................................26
14. TECHNICAL DATA..................................................................................................29
15. QUICK GUIDE.........................................................................................................29
16. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION
1369/2017........................................................................................................................31
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
• Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when
the door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH
3
General Safety
1.2
• Do not change the specification of this appliance.
• This appliance is intended to be used in household
and similar applications such as:
www.aeg.com4
– staff kitchen areas in shops, offices and other
working environments;
– by clients in hotels, motels, bed & breakfast and
other residential type environments;
– areas for communal use in blocks of flats or in
launderettes.
• Do not exceed the maximum load of 7 kg (refer to the
"Programme chart" chapter).
• The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
• The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
• The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
• Old hose sets must not be reused.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
• Do not use high pressure water sprays and/or steam
to clean the appliance.
• Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2.
SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Remove all the packaging and the
transit bolts including rubber bush
with plastic spacer.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Follow the installation instructions
supplied with the appliance.
ENGLISH
5
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
• Do not install the appliance directly
above a floor drain.
• Do not spray water on the appliance
and do not expose it to excessive
humidity.
• Do not install the appliance where the
appliance lid cannot be fully opened.
• Do not put a closed container to
collect possible water leakage under
the appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance complies with the
E.E.C. Directives.
2.3 Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes,
pipes not used for a long time, where
repair work has been carried out or
new devices fitted (water meters,
etc.), let the water flow until it is clean
and clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
Authorised Service Centre for the
replacement of the inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing
of the appliance with the use of water
in the factory.
• You can extend the drain hose to
maximum 400 cm. Contact the
Authorised Service Centre for the
other drain hose and the extension.
• Make sure that there is access to the
tap after the installation.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber
parts of the washing machine.
Prewash such fabrics by hand before
loading them into the washing
machine.
• Make sure that all metal objects are
removed from the laundry.
6
www.aeg.com
2.5 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
3. PRODUCT DESCRIPTION
3.1 Special features
Your new washing machine meets all
modern requirements for an effective
treatment of laundry with low water,
energy and detergent consumption and
proper care of fabric.
• The Oko-Mix technology has been
designed to protect the fabric fibres
thanks to different pre-mixing phases
that dissolves first the detergent and
then fabric softener in the water
before they are distributed in the
laundry. So every fibre is reached and
cared for.
• The ProSense technology detects
the laundry load size defining the
programme duration in 30 seconds.
The washing programme is tailored to
the laundry load and the type of fabric
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
without consuming more time, energy
and water than necessary.
• The steam has a quick and easy way
to refresh the clothes. The gentle
steam programmes remove odours
and reduce creases in dry fabrics so
they need little ironing.
The Plus Steam option, finishes every
cycle with gentle steam that relaxes
the fibres and reduces fabric creasing.
Ironing will be easier!
• The Vlekken option pre-treats
stubborn stains optimizing the
effectiveness of the stain remover.
• Thanks to the Soft Plus option, the
fabric softener is uniformly spread out
in the laundry and deeply penetrates
the fabric fibres favouring a perfect
softness.
3.2 Appliance overview
21
4
6
7
5
3
9
81012 1113
1 2 3 4
5
7
6
4. CONTROL PANEL
4.1 Control panel description
Control panel
1
Lid
2
Lid push handle
3
Drain pump filter
4
Lever to move the appliance
5
Feet for levelling the appliance
6
Rating plate
7
ENGLISH 7
1
Aan/Uit push button
Programme dial
2
Display
3
4
Eco touch button
5
Tijd Besparen touch button
6
Extra touch button
• Only Rinse
• Only Spin
• Only Drain
7
Start/Pauze touch button
8
Extra Spoelen touch button
9
Startuitstel touch button
10
Plus Steam touch button
11
Vlekken/Voorwas touch button
MIX
MIX
www.aeg.com8
12
TPM touch button
4.2 Display
13
Temp. °C touch button
Maximum load indicator. The icon flashes during laundry load estimation (refer to "PROSENSE load detection" paragraph).
Maximum laundry indicator. It flashes when the laundry load exceeds the
maximum declared load of the selected programme.
Delay start indicator.
Door locked indicator.
The digital indicator can show:
• Programme duration (e. g. ).
• Delay time (e. g. or ).
• Cycle end ( ).
• Warning code (e.g. ).
Energy saving indicators. The indicator appears by selecting a programme for cotton at 40 °C or 60 °C.
Washing phase indicator: it flashes during prewash and wash phase.
Rinsing phase indicator: it flashes during rinse phase.
The indicator appears when the Soft Plus option is activated.
Spin and drain phase indicator. It flashes during spin and drain phase.
OKO MIX indicator.
Steam phase indicator.
Anti-crease phase indicator.
Child safety lock indicator.
Time saving indicator.
Temperature indicator. The indicator appears when a cold wash is
set.
Spin speed indicator.
Rinse hold indicator.
Extra Silent indicator.
Pre-wash indicator.
Stain indicator.
Extra rinse indicator.
5. PROGRAMME CHART
Washing programmes
Programme Default
temperature
Temperature
range
40 °C
Katoen
95 °C Cold
Reference
spin speed
Spin speed
range
1300 rpm
1300 - 400
rpm
Maximum
load
7 kg
ENGLISH 9
Programme description
White cotton and coloured cotton.
Normal, heavy and light soil.
Standard programmes for the Energy Label consumption values. Ac-
cording to regulation 1061/2010, the
programme Katoen at 60 °C and the
programme Katoen at 40 °C with the
option are respectively the
«Standard 60°C cotton programme»
and the «Standard 40°C cotton programme». They are the most efficient
programmes in terms of combined energy and water consumption for washing normally soiled cotton laundry.
The water temperature
of the washing phase
may differ from the
temperature declared
for the selected programme.
www.aeg.com10
Programme Default
temperature
Temperature
range
40 °C
Synthetica
60 °C Cold
30 °C
Fijne Was
40 °C Cold
40 °C
Wol/Zijde
Stoom
40 °C Cold
- - 1 kg
30 °C
ÖKOPower
60 °C 30 °C
Reference
spin speed
Spin speed
range
1200 rpm
1200- 400
rpm
1200 rpm
1200 - 400
rpm
1200 rpm
1200- 400
rpm
1300 rpm
1300 rpm 400 rpm
Maximum
load
3 kg
2 kg
1,5 kg
3 kg
Programme description
Synthetic items or mixed fabric
items. Normal soil.
Delicate fabrics such as acrylics, viscose and mixed fabrics requiring
gentler washing. Normal soil.
Machine washable wool, hand washable wool and other fabrics with
«hand washing» care symbol1).
Steam programme for cotton and
synthetic items. Steam can be used
for dried2), washed or worn once laundry. This programme reduce creases
and odours3) and relaxes the fibres.
When the programme is completed,
quickly remove the laundry from the
drum. After a steam programme, ironing becomes effortless. Do not use
any detergent. If necessary, remove
stains by washing or using localized
stain removal. Steam programmes do
not perform any hygienic cycle. Do
not set a Steam programme with
these types of items:
• Items that are not suitable for tumble drying.
• All items with plastic, metal, wooden parts or alike.
Cotton and fast-coloured synthetic
items. Complete washing programme
that, in only 59 minutes, washes the
daily soiled laundry intensively and ensures a good washing performance in
a short time.
ENGLISH
11
Programme Default
temperature
Temperature
range
Anti-Allergie
60 °C
30 °C
20 min. - 3 kg
40 °C 30 °C
30 °C
Outdoor
40 °C Cold
Reference
spin speed
Spin speed
range
1300 rpm
1300 - 400
rpm
1200 rpm
1200 - 400
rpm
1200 rpm
1200 - 400
rpm
Maximum
load
7 kg
3 kg
2 kg
1 kg
Programme description
White cotton items. This programme
removes micro-organisms thanks to a
washing phase with the temperature
maintained above 60°C for several minutes. This helps remove germs, bacteria, micro-organism and particles.
An additional rinsing phase ensures a
proper removal of detergent residues
and pollens/allergenic items. In this
way the wash is more effective.
Cotton and synthetic items lightly
soiled or once worn.
Do not us fabric softener and make sure there
is no softener residue in
the detergent dispenser.
Outdoor clothing, technical, sport
fabrics, waterproof and breathable
jackets, shell jackets with a removable fleece or inner insulation.The
recommended laundry load is 2 kg.
This programme can also be used as
water-repellent restoring cycle, specifically tailored for treating clothes with
4)
a hydrophobic coating. To perform
5)
the water-repellent restoring cycle,
proceed as follows:
• Pour the washing detergent in the
compartment .
• Pour a special water-repellent restorer for fabric in the drawer com-
partment for fabric softener
• Reduce the laundry load to 1 kg.
To further improve the water repellency restoring action, dry the laundry in
a tumble dryer by setting the Outdoor
drying programme (if available and if
the garment care label permits tumble
drying).
.
www.aeg.com12
Programme Default
temperature
Temper-
Reference
spin speed
Spin speed
range
Maximum
load
Programme description
ature
range
Maintenance cycle with hot water to
clean and freshen the drum and to remove residue that may cause odour.
For the best result use this cycle once
a month. Before running this cycle, remove all items from the drum. In the
washing phase compartment of the
detergent dispenser, put the flap of
the compartment in upward position.
Pour a cup of chlorine bleach or a
washing machine cleaner in the washing phase compartment. DO NOT use
Machine
Clean
60 °C
1200 rpm
1200 - 400
rpm
-
both together.
After the drum cleaning, run a further rinse
cycle with empty drum
and no detergent to remove any residue of
bleach.
1)
During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
2)
If you set a Steam programme with dried laundry, at the end of the cycle the laundry can be humid.
Line dry the items for about 10 minutes.
3)
Steam programme doesn't remove particularly intense odour.
4)
Washing programme.
5)
Washing programme and waterproofing phase.
Programme options compatibility
Katoen
Fijne Was
Synthetica
Stoom
Wol/Zijde
ÖKOPower
Anti-Allergie
Outdoor
20 min. - 3 kg
TPM ■ ■ ■ ■ ■ ■ ■ ■ ■
Rinse Hold
■ ■ ■ ■ ■ ■ ■
Machine Clean
ENGLISH 13
Stoom
Wol/Zijde
ÖKOPower
Anti-Allergie
Outdoor
20 min. - 3 kg
Extra Silent
1)
Vlekken
Katoen
Fijne Was
Synthetica
■ ■ ■
■ ■ ■
Voorwas ■ ■ ■
Extra Spoelen ■ ■ ■ ■ ■ ■
Eco2)
Tijd Besparen
Only Rinse
Only Spin
Only Drain
3)
■ ■ ■
■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■ ■ ■
Startuitstel ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
Plus Steam
1)
■ ■ ■
Soft Plus ■ ■ ■ ■ ■
1)
This option is not available with temperature lower than 40 °C.
2)
This option is not available with a temperature lower than 30 °C.
3)
If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully
load the appliance, however the washing results can be less satisfactory.
Machine Clean
5.1 Woolmark Apparel Care - Green
The wool wash cycle of this machine has been
approved by The Woolmark Company for the
washing of wool garments labelled as «hand
wash» provided that the garments are washed according to the instructions issued by the
manufacturer of this washing machine. Follow
the garment care label for drying and other
laundry instructions. M1734
The Woolmark symbol is a Certification mark
in many countries.
www.aeg.com14
6. CONSUMPTION VALUES
Stated values are obtained in laboratory conditions with relevant standards. Different causes can change the data: the quantity and type of
laundry and ambient temperature. Water pressure, the supply voltage
and the temperature of inlet water may also affect the washing programme duration.
Technical specifications may be changed without prior notice to improve
the quality of product.
During the washing programme, the Prosense technology can vary the
wash duration and the consumption values. For more details see 'The
Prosense load detection' paragraph in 'Daily Use' chapter.
Programmes Load
(kg)
Katoen 60°C 7 1,44 84 205 53
Katoen 40°C 7 0,98 85 215 53
Synthetica 40°C 3 0,54 50 140 35
Fijne Was 40°C 2 0,50 49 75 35
Wol/Zijde 30°C 1,5 0,19 38 70 30
Standard cotton programmes
Standard 60°C cotton
Standard 60°C cotton
Standard 40°C cotton
1)
At the end of spin phase.
Off Mode (W) Left On Mode (W)
0.30 0.30
The information given in the chart above is compliant with the EU Commission regulation
1015/2010 implementing directive 2009/125/EC .
Energy
consumption (kWh)
7 0,77 43 275 53
3,5 0,37 34 215 53
3,5 0,33 34 215 53
Water
consumption (litre)
Approximate programme
duration
(minutes)
Remaining mois-
ture (%)
1)
7. OPTIONS
ENGLISH
15
7.1 Introduction
The options/functions are
not selectable with all
washing programmes. Check
the compatibility between
options/functions and
washing programmes in the
"Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set the incompatible
options/functions together.
Make sure the screen and
touch buttons are always
clean and dry.
7.2 Aan/Uit
Pressing this button for a few seconds
allows to activate or deactivate the
appliance. Two different tunes sound
while switching the appliance on or off.
As the Stand-by function automatically
deactivates the appliance to decrease
the energy consumption in a few cases,
you may need to activate the appliance
again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
7.3 Eco
The option reduces the energy
consumption and maintaining good
washing results.
Set this option for slightly or normally
soiled items washed at 30°C or higher
temperatures.
Water and energy consumption may
depend on different causes, such as
water pressure, its hardness and
temperature, ambient temperature, type
and quantity of laundry, the set options,
spin speed and voltage fluctuations in
the electricity network. The display shows
the indicator .
If you select the Cotton
programme at 40°C or 60°C
and no other options are set,
the display shows the
indicator ; these are
the standard cotton
programmes, the most
efficient programmes in
terms of combined energy
and water consumption.
7.4 Tijd Besparen
With this option you can decrease the
programme duration.
• If your laundry is normally or lightly
soiled, it may be advisable to shorten
the washing programme. Touch this
button once to decrease the duration.
• In case of smaller load, touch this
button twice to set an extra quick
programme.
The display shows the indicator .
This option can also be used
to shorten the Stoom
programme duration.
7.5 Temp. °C
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Set this option to change the default
temperature.
The indicator
temperature comes on (the appliance
does not heat the water).
= cold water of the set
7.6 TPM
When you set a programme, the
appliance automatically selects the
maximum spin speed.
Touch this button repeatedly to:
• Decrease the spin speed.
The display shows only
the spin speeds available
for the set programme.
• Activate the Rinse Hold option .
16
www.aeg.com
The water of the last rinse is not
drained out to prevent the fabrics
from creasing. The washing
programme ends with water in the
drum and the final spin phase is not
performed.
The display shows the indicator .
The lid stays locked. The drum turns
regularly to reduce creasing. You
must drain the water to unlock the lid.
Touch Start/Pauze button: the
appliance performs the spinning
phase and drains the water.
• Activate the Extra Silent option.
All spinning phases (intermediate spin
and final spin) are suppressed and the
programme ends with water in the
drum. This helps to reduce creasing.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are available.
In some programmes the rinses are
performed with more water.
The display shows the indicator .
The lid stays locked. The drum turns
regularly to reduce creasing. You
must drain the water to unlock the lid.
Touch the Start/Pauze button: the
appliance performs only the draining
phase.
The appliance empties the
water out automatically after
approximately 18 hours.
7.7 Vlekken/Voorwas
Press this button repeatedly to activate
one of the two options.
The relevant indicator goes on in the
display.
• Vlekken
Select this option to add an anti-stain
phase to a programme in order to
treat heavily soiled or stained laundry
with stain remover.
Pour the stain remover into
compartment
will be added in the appropriate
phase of the washing programme.
. The stain remover
This option can increase
the programme duration
and is not available with a
temperature lower than
40 °C.
• Voorwas
Use this option to add a prewash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
containing sand, dust , mud and other
solid particles.
This option can increase
the programme duration.
7.8 Extra Spoelen
With this option you can add up to 3
rinses accordingly to the selected
washing programmes.
Useful for people allergic to detergents
and in areas where the water is soft.
The indicator shows the selected
number of rinses.
This option increases the programme
duration.
If the Extra Spoelen is set as
a default option and you
select a compatible washing
programme, the display
shows . In this case, by
pressing the Extra Spoelen
button , it is possible to add
just one rinse.
7.9 Skipping phase button (Extra)
By touching this button you can set:
• Only Rinse option. The appliance
performs only the rinsing phase , the
spinning and the draining phases of
the selected programme.
• Only Spin
performs only the spinning phase of
the selected washing programme.
• Only Drain option. The appliance
performs the only draining phase of
the selected washing programme.
option. The appliance
ENGLISH
17
At firth touch the appliance
proposes the default setting
of the washing programme
again.
7.10 Plus Steam
This option adds a steam phase followed
by a short anti-crease phase at the end
of the washing programme.
The steam phase reduces fabric creasing
and facilitates the fabric ironing.
The indicator flashes on the display
during steam phase.
This option can increase the
programme duration.
When the programme stops the display
shows a zero
steady on and the indicator starts
flashing. The drum performs smooth
movements for about 30 minutes to keep
the steam benefit. By touching any
8. SETTINGS
8.1 Acoustic signals
To deactivate the acoustic signals when
the programme is completed touch the
Startuitstel and the Extra Spoelen
buttons simultaneously for about 3
seconds.
The acoustic signals, they
continue operate when the
appliance has a malfunction.
8.2 Child Lock
With this option you can prevent that the
children play with the control panel.
• To activate/deactivate this option,
touch the Vlekken/Voorwas and the
Extra Spoelen buttons simultaneously
until the indicator
off on the display.
You can activate this option:
• After you touch the Start/Pauze
button: all the buttons and the
programme dial are deactivated
(except Aan/Uit button ).
, the indicator is
comes on/goes
button the anti-crease movements stop
and the lid unlocks.
A small laundry load helps to
reach better results.
7.11 Startuitstel
With this option you can delay the start
of a programme in a more convenient
time.
Touch the button repeatedly to set the
required delay. The time increases by
steps of 30 minutes up to 90' and from 2
hours up to 20 h.
After touching the Start/Pauze button,
the display shows the indicator
the selected delay time and the
appliance begins the countdown.
and
7.12 Start/Pauze
Touch the Start/Pauze button to start,
pause the appliance or interrupt a
running programme.
• Before you touch the Start/Pauze
button: the appliance cannot start.
The appliance keeps the selection of this
option after you switch it off.
8.3 Soft Plus
Set the Soft Plus option to optimise the
fabric softener distribution and improve
the fabric softness.
It is suggested when you use the fabric
softener.
This option increases slightly
the programme duration.
To activate/deactivate this option touch
the Temp. °C button and the TPM.
button simultaneously until the
indicator comes on/goes off above the
indicator.
8.4 Permanent Extra Rinse
With this option you can permanently
have an extra rinse when you set a
programme where it is selectable.
A
www.aeg.com18
• To activate/deactivate this option
touch the Extra Spoelen button and
the Extra button simultaneously the
relevant indicator comes on/goes off.
9. BEFORE FIRST USE
1. Connect the mains plug to the mains
socket.
2. Open the water tap.
3. Put 2 litre of water in the detergent
compartment for washing phase.
This activates the drain system.
4. Put a small quantity of detergent in
the compartment for washing phase.
10. DAILY USE
WARNING!
Refer to Safety chapters.
10.1 Activating the appliance
1. Connect the mains plug to the mains
socket.
2. Open the water tap.
3. Press button Aan/Uit to activate the
appliance.
A short tune sounds.
10.2 Loading the laundry
1. Open the appliance lid.
2. Push the button A.
This option adds two rinses and the
display shows .
5. Set and start a programme for cotton
at the highest temperature without
laundry.
This removes all possible dirt from the
drum and the tub.
The drum opens automatically.
3. Put the laundry in the drum, one item
at a time.
4. Shake the items before you put them
in the appliance.
Make sure not to put too much laundry
in the drum.
5. Close the drum and the lid.
CAUTION!
Before you close the lid of
your appliance, make sure
that you close the drum
correctly.
10.3 Detergent
compartments. Using
detergent and additives
1. Measure out specified detergents for
washing machine the detergent and the
fabric conditioner.
2. Put the detergent and the fabric
conditioner into the proper
compartments.
Always obey the instructions
that you find on the
packaging of the detergent
products.
10.4 Liquid or powder
CLICK
A
CLICK
B
detergent
ENGLISH 19
Detergent compartment for
prewash phase.
The marks MAX are the maximum levels of the quantity of
detergent (powder or liquid).
When you set a programme
with a stain, add detergent
(powder or liquid).
Detergent compartment for
washing phase.
The marks MAX are the maximum levels of the quantity of
detergent (powder or liquid).
Compartment for liquid additives (fabric conditioner, starch).
The mark M is the maximum
level for the quantity liquid additives.
Flap for powder or liquid detergent.
1.
3.
2.
4.
20
www.aeg.com
• Position A for powder detergent (factory setting).
• Position B for liquid detergent.
When you use the liquid detergent:
• Do not use gelatinous or thick liquid detergents.
• Do not put more liquid then the maximum level.
10.5 Setting a programme
1. Turn the programme knob. The
related programme indicator comes
on.
The indicator of button Start/Pauze
flashes with red colour.
The display shows the default
temperature, the spin speed and the
empty indicator bars of the available
functions.
2. To change the temperature and/or
the spin speed, press the related
buttons.
3. Set the available functions.
10.6 Starting a programme
without the delay start
Press button Start/Pauze to start the
programme.
The relevant indicator stops to flash and
stays on.
On the display the indicator of the phase
is operation starts to flash.
The programme starts, the lid is locked.
The display show the indicator .
The drain pump can operate
for a short time when the
appliance fills water.
10.7 Cycle time recalculation
After approximately 15
minutes from the start of the
programme:
• The appliance adjusts
automatically the cycle
time to the laundry you
have put in the drum to
have perfect washing
results in the minimum
necessary time.
• The display shows the
new time value.
10.8 Starting a programme with the delay start
1. Press button Startuitstel again and
again until the display shows the
number of minutes or hours of delay.
The related indicator comes on.
2. Press button Start/Pauze.
The appliance starts the countdown of
the delay start.
When the countdown is completed, the
programme starts automatically.
Before you press button
Start/Pauze to start the
appliance, you can cancel or
change the set of the delay
start.
10.9 Cancelling the delay start
To cancel the delay start:
1. Press button Start/Pauze to set the
appliance to pause.
The related indicator flashes.
2. Press button Startuitstel repeatedly
until the display shows .
3. Press button Start/Pauze again to
start the programme immediately.
10.10 Interrupting a programme and changing a option
You can change only some options
before they operate.
1. Press button Start/Pauze.
The related indicator flashes.
2. Change the option set.
3. Press the button Start/Pauze again.
The programme continues.
ENGLISH
21
10.11 Cancelling a running
programme
1. Press button Aan/Uit to cancel the
programme and to deactivate the
appliance.
2. Press button Aan/Uit again to
activate the appliance.
Now, you can set a new washing
programme.
Before starting the new
programme the appliance
could drain the water. In this
case, make sure that the
detergent is still in the
detergent compartment, if
not fill the detergent again.
10.12 The ProSense load detection
The programme duration in
the display is referred to a
medium/high load.
After touching the Start/Pauze button,
the maximum declared load indicator
goes off, the indicator
ProSense starts the laundry load
detection:
1. The appliance detects the load in the
first 30 seconds: the indicator and
the time dots
rotates shortly.
2. At the end of the load detection, the
indicator goes off and the time
dots stop flashing. The programme
duration will be adjusted accordingly
and could increase or decrease. After
further 30 seconds, the water filling
starts.
At the end of the load detection, in case
of drum overload, the indicator
flashing in the display:
In this case, for 30 seconds, it is possible
to pause the appliance and remove the
exceeding garments.
Once removed the exceeding garments,
touch the Start/Pauze button to start the
programme again. The ProSense phase
can be repeated up to three times (see
point 1).
flashes, the
flash, the drum
Important!
be reduced, the washing programme
starts anyway, despite the overload. In
this case, it will be not possible to
guarantee the best washing results.
If the laundry amount will not
About 20 minutes after the
programme start, the
programme duration could
be adjusted again
depending on the capacity
of water absorption of the
fabrics.
The ProSense detection is
carried out with complete
washing programmes only
(no skipping phase
selected).
10.13 Opening the Lid when the programme operates
CAUTION!
If the temperature and level
of the water in the drum are
too high, the indicator
stays on and you cannot
open the lid.
To open the lid proceed as follows:
1. Press the button Aan/Uit for some
seconds to deactivate the appliance.
2. Wait for some minutes and then
open carefully the lid.
3. Close the lid.
4. Activate the appliance and set the
programme again.
10.14 Opening the Lid when the delay start is active
While the delay start operates, the
appliance lid is locked.
To open the appliance lid:
is
1. Press button Start/Pauze.
The indicator goes off.
2. Open the appliance lid.
3. Close the lid and press button Start/
Pauze.
The delay start continues.
www.aeg.com22
10.15 End of cycle
When the programme has finished, the
appliance stops automatically. The
acoustic signal operates (if it is active).
In the display comes on and the lid
locked indicator
The indicator of Start/Pauze button goes
off.
1. Press button Aan/Uit to deactivate
the appliance.
After five minutes from the end of the
programme, the energy saving function
automatically deactivates the appliance.
When you activate the
appliance again, the display
show the end of the last set
programme. Turn the
programme knob to set a
new cycle.
2. Remove the laundry from the
appliance.
3. Make sure that the drum is empty.
4. Keep the door ajar, to prevent
mildew and odours
goes off.
10.16 Draining water out after end of cycle
The washing programme is completed,
but there is water in the drum:
The drum turns regularly to prevent the
creases in the laundry.
The lid lock indicator is on. The lid
stays locked.
You must drain the water to open the lid:
1. If necessary, decrease the spin
speed.
2. Press the Start/Pauze button.
The appliance drains the water and
spins.
3. When the programme is completed
and the door lock indicator
off, you can open the door .
4. Press Aan/Uit some seconds to
deactivate the appliance.
The appliance drains and
spins automatically after
approximately18 hours.
goes
10.17 AUTO OFF option
The AUTO OFF function automatically
deactivates the appliance to decrease
the energy consumption when:
• You do not use the appliance for 5
minutes before you press Start/Pauze
button.
Press the button Aan/Uit to activate
the appliance again.
• After 5 minutes from the end of the
washing programme
Press the button Aan/Uit to activate
the appliance again.
The display shows the end of the last
set programme.
Turn the programme knob to set a
new cycle.
If you set a programme or an
option that ends with water
in the drum, the AUTO OFF
function doesn't deactivate
the appliance to remind you
to drain the water.
11. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
11.1 The laundry load
• Divide the laundry in: white, coloured,
synthetics, delicates and wool.
• Obey the washing instructions that
are on the laundry care labels.
• Do not wash white and coloured
items together.
• Some coloured items can discolour
with the first wash. We recommend
that you wash them separately for the
first times.
• Button up pillowcases, close zippers,
hooks and poppers. Tie up belts.
• Empty the pockets and unfold the
items.
• Turn multilayered fabrics, wool and
items with painted illustrations inside
out.
ENGLISH 23
• Remove hard stains with a special
detergent.
• Wash and pre-treat heavy soil stains
before putting items in drum
• Be careful with the curtains. Remove
the hooks and put the curtains in a
washing bag or pillowcase.
• Do not wash laundry without hems or
with cuts. Use a washing bag to wash
small and/or delicate items (e.g.
underwired bras, belts, tights, etc. ).
• A very small load can cause balance
problems with the spin phase. If this
occurs, adjust manually the items in
the tub and start the spin phase
again.
11.2 Stubborn stains
For some stains, water and detergent is
not sufficient.
We recommend that you pre-treat these
stains before you put the items in the
appliance.
Special stain removers are available. Use
the special stain remover that is
applicable to the type of stain and fabric.
11.3 Detergents and additives
• Only use detergents and additives
specially made for washing machines:
– powder detergents for all types of
fabric,
– powder detergents for delicate
fabrics (40 °C max) and woollens,
– liquid detergents, preferably for
low temperature wash
programmes (60 °C max) for all
types of fabric, or special for
woollens only.
• Do not mix different types of
detergents.
• To help the environment, do not use
more than the correct quantity of
detergent.
• Obey the instructions that you find on
the on packaging of these products.
• Use the correct products for the type
and colour of the fabric, the
programme temperature and the
level of soil.
• If your appliance does not have the
detergent dispenser with the flap
device, add the liquid detergents with
a dosing ball (supplied by the
detergent's manufacturer).
11.4 Ecological hints
• Set a programme without the
prewash phase to wash laundry with
normal soil.
• Always start a washing programme
with the maximum load of laundry
allowed.
• If necessary, use a stain remover when
you set a programme with a low
temperature.
• To use the correct quantity of
detergent, check the water hardness
of your domestic system. Refer to
"Water hardness".
11.5 Water hardness
If the water hardness in your area is high
or moderate, we recommend that you
use a water softener for washing
machines. In areas where the water
hardness is soft it is not necessary to use
a water softener.
To know the water hardness in your area,
contact your local water authority.
Use the correct quantity of the water
softener. Obey the instructions that you
find on the packaging of the product.
CARE AND CLEANING
12.
WARNING!
Refer to Safety chapters.
12.1 External cleaning
Clean the appliance with soap and warm
water only. Fully dry all the surfaces.
www.aeg.com24
CAUTION!
Do not use alcohol, solvents
or chemical products.
12.2 Descaling
If the water hardness in your area is high
or moderate, we recommend that you
use a water descaling product for
washing machines.
Regularly examine the drum to prevent
limescale and rust particles.
To remove rust particles use only special
products for washing machines. Do this
separately from the laundry wash.
Always obey the instructions
that you find on the
packaging of the product.
the drum. Perform a maintenance wash
regularly. To do this:
• Remove all laundry from the drum.
• Run the Machine Clean programme.
For more details, refer to washing
programme table.
12.4 Lid seal
Regularly examine the seal. Clean it
when needed, using ammonia cream
cleanser agent without scratching the
seal surface,
12.3 Maintenance wash
With the low temperature programmes it
is possible that some detergent stays in
12.5 Cleaning the detergent dispenser
1. 2.
Always obey the instructions
that you find on the
packaging of the product.
3.
12.6 Cleaning the drain filter
Do not clean the drain filter if the water in the appliance is hot.
1. 2.
3. 4.
ENGLISH 25
5.
1
2
3
90˚
www.aeg.com26
12.7 Cleaning the inlet hose and the valve filter
1.
3. 4.
12.8 Emergency drain
Because of a malfunction, the appliance
cannot drain the water.
If this occurs, do steps (1) through (5) of
'Cleaning the drain filter'. If necessary,
clean the pump.
12.9 Frost precautions
If the appliance is installed in an area
where the temperature can be less than
0° C, remove the remaining water from
the inlet hose and the drain pump.
1. Disconnect the mains plug from the
mains socket.
2.
2. Close the water tap.
3. Put the two ends of the inlet hose in
a container and let the water flow out
of the hose.
4. Empty the drain pump. Refer to the
emergency drain procedure.
5. When the drain pump is empty,
install the inlet hose again.
WARNING!
Make sure that the
temperature is higher than 0
°C before you use the
appliance again.
The manufacturer is not
responsible for damages
caused by low temperatures.
13. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
13.1 Introduction
The appliance does not start or it stops
during operation.
ENGLISH 27
First try to find a solution to the problem
(refer to the table). If the problem
persists, contact the Authorised Service
Centre.
With some problems, the acoustic
signals operate and the display shows
an alarm code:
• - The appliance does not fill with
water properly. Start the appliance
again by pressing Start/Pauze button.
After 10 seconds the lid will be
unlocked.
• - The appliance does not drain
the water.
13.2 Possible failures
Problem Possible solution
• Make sure that the mains plug is connected to the mains
socket.
• Make sure that the appliance lid and drum doors are closed
The programme does
not start.
The appliance does not
fill with water properly.
The appliance fills with
water and drains immediately
properly.
• Make sure that there is no damaged fuse in the fuse box.
• Make sure that the Start/Pauze has been touched.
• If the delay start is set, cancel the setting or wait for the end
of countdown.
• Deactivate the Child Lock function if it is on.
• Make sure that the water tap is open.
• Make sure that the pressure of the water supply is not too
low. For this information, contact your local water authority.
• Make sure that the water tap is not clogged.
• Make sure that the inlet hose has no kinks, damages or
bends.
• Make sure that the connection of the water inlet hose is
correct.
• Make sure that the filter of the inlet hose and the filter of
the valve are not clogged. Refer to 'Care and cleaning'.
• Make sure that the drain hose is in the correct position. The
hose may be positioned too low. Refer to "Installation instruction".
• - The appliance lid is open or
not closed correctly. Please check the
lid!
•
- The mains supply is unstable.
Wait until the mains supply is stable.
•
- The anti-flood device is on.
Disconnect the appliance and close
the water tap. Contact the Authorised
Service Centre.
WARNING!
Deactivate the appliance
before you do the checks.
www.aeg.com28
Problem Possible solution
• Make sure that the sink spigot is not clogged.
• Make sure that the drain hose has no kinks or bends.
• Make sure that the drain filter is not clogged. Clean the fil-
The appliance does not
drain the water.
ter, if necessary. Refer to "Care and cleaning".
• Make sure that the connection of the drain hose is correct.
• Set the drain programme if you set a programme without
drain phase.
• Set the drain programme if you set an option which ends
with water in the tub.
• Set the spin programme.
The spin phase does not
operate or the washing
cycle lasts longer than
usual.
• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Refer to "Care and cleaning".
• Adjust manually the items in the tub and start the spin
phase again. This problem may be caused by balance problems.
• Make sure that the couplings of the water hoses are tight
and there is not water leakages.
There is water on the
floor.
• Make sure that the water inlet hose and the drain hose have
no damages.
• Make sure you use the correct detergent and the correct
quantity of it.
You cannot open the appliance lid
• Make sure that the washing programme is finished.
• Set the drain or the spin option if there is water in the tub.
•
• Make sure the levelling of the appliance is correct. Refer to
The appliance makes an
unusual noise and vibrates.
"Installation instruction".
• Make sure that the packaging and/or the transit bolts are
removed. Refer to "Installation instruction".
• Add more laundry in the drum. The load may be too small.
The programme duration
increases or decreases
during programme execution.
• The ProSense function is able to adjust the programme duration according to the type and the laundry load size. Refer to "The ProSense load detection" in "Daily Use" chapter.
• Increase the detergent quantity or use a different detergent.
The washing results are
not satisfactory.
• Use special products to remove the stubborn stains before
you wash the laundry.
• Make sure that you set the correct temperature.
• Decrease the laundry load.
Too much foam in the
• Reduce the quantity of detergent.
drum during the washing
cycle.
Problem Possible solution
After the washing cycle,
there are some detergent residues in the dispenser drawer.
After the check, activate the appliance. The programme continues from the point of
interruption.
If the problem occurs again, contact the Authorised Service Centre.
If the display shows other alarm codes. Deactivate and activate the appliance. If the
problem continues, contact the Authorised Service Centre.
• Make sure that the flap is in the correct position (left for
• Make sure you have used the detergent dispenser accord-
14. TECHNICAL DATA
ENGLISH 29
powder detergent - right for liquid detergent).
ing the indications given in this user manual.
Dimension Width/ Height/ Depth/
Electrical connection Voltage
Level of protection against ingress of solid particles
and moisture ensured by the protective cover, except where the low voltage equipment has no protection against moisture
Water supply pressure Minimum
Water supply
Maximum Load Cotton 7 kg
Energy Efficiency Class A+++
Spin Speed Maximum spin speed 1251 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
1)
15. QUICK GUIDE
15.1 Daily use
Connect the mains plug to the mains
socket.
Open the water tap.
Total depth
Overall power
Fuse
Frequency
Maximum
400 mm/ 890 mm/ 600 mm/ 600 mm
230 V
2200 W
10 A
50 Hz
IPX4
0.5 bar (0.05 MPa)
8 bar (0.8 MPa)
Cold water
Load the laundry.
Pour the detergent and other treatment
in the proper compartment of the
detergent dispenser.
1
2
1 32
www.aeg.com30
1. Push the Aan/Uit button to turn the
appliance on. Turn the programme
dial to set the desired programme.
2. Set the desired options (1) by means
of the corresponding touch buttons.
To start the programme, touch the
3. The appliance starts.
At the end of the programme, remove
the laundry.
Push the Aan/Uit button to turn the
appliance off.
Start/Pauze (2) button.
15.2 Cleaning the drain pump filter
Clean the filter regularly and, especially,
if the alarm code appears on the
display.
15.3 Programmes
Programmes Load Product description
Katoen
Katoen
7 kg White cotton and coloured cotton.
White cotton and coloured cotton. Standard
7 kg
programmes for the Energy Label consumption values.
Synthetica
Fijne Was
3 kg Synthetic items or mixed fabric items.
2 kg
Delicate fabrics such as acrylics, viscose, polyester items.
Programmes Load Product description
ENGLISH 31
Wol/Zijde
Stoom
ÖKOPower
Anti-Allergie
20 min. - 3 kg
Outdoor
Machine Clean
1)
Washing programme.
2)
Washing programme and waterproofing phase.
1,5 kg
1 kg
3 kg
7 kg
3 kg
2 kg
1 kg
- Maintenance cycle for drum cleaning.
Machine washable wool, hand washable wool
and delicates.
Steam programme for cotton, synthetic and
delicate garments.
Cotton and fast-coloured synthetic items.
Complete washing programme that, in only
59 minutes, washes the daily soiled laundry intensively and ensures a good washing performance in a short time.
White cotton items. This programme helps to
remove germs and bacteria.
Cotton and synthetic lightly soiled or once
worn items.
1)
Modern outdoor sporting garments.
2)
16. PRODUCT INFORMATION SHEET IN REFERENCE
TO E.U. REGULATION 1369/2017
Product Information Sheet
Trade Mark AEG
Model L8TE73C, PNC913123845
Rated capacity in kg 7
Energy efficiency class A+++
Energy consumption in kWh per year, based on 220
standard washing cycles for cotton programmes at 60 °C
and 40 °C at full and partial load, and the consumption of
the low-power modes. Actual energy consumption will
depend on how the appliance is used.
Energy consumption of the standard 60°C cotton programme at full load in kWh
Energy consumption of the standard 60°C cotton programme at partial load in kWh
120
0,77
0,37
32
www.aeg.com
Energy consumption of the standard 40°C cotton programme at partial load kWh
Power consumption of the off-mode in W 0,30
Power consumption in left-on mode in W 0,30
Water consumption in litres per year, based on 220 standard washing cycles for cotton programmes at 60 °C and
40 °C at full and partial load. Actual water consumption
will depend on how the appliance is used.
Spin-drying efficiency class on a scale from G (least efficient) to A (most efficient)
Maximum spin speed in rpm 1251
Remaining moisture content in % 53
The 'standard 60 °C cotton programme' and the 'standard 40 °C cotton programme' are the standard washing
programmes to which the information in the label and the
fiche relates, these programmes are suitable to clean normally soiled cotton laundry and they are the most efficient in terms of combined energy and water consumption.
Programme time of the standard 60°C cotton programme
at full load in minutes
Programme time of the standard 60°C cotton programme
at partial load in minutes
Programme time of the "standard 40°C cotton programme at partial load in minutes
Duration of the left on mode in minutes 5
Airborne acoustical noise emission in db(A) washing 49
Airborne acoustical noise emission in db(A) spinning 79
Built in appliance Y/N No
0,33
9990
B
-
275
215
215
The information given in the chart above is compliant with the EU Commission regulation
1015/2010 implementing directive 2009/125/EC .
17. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
ENGLISH 33
www.aeg.com34
ENGLISH 35
www.aeg.com/shop
192932421-A-102019
Loading...
