Page 1
USER
MANUAL
L7FEC14VX
EN User Manual
Washing Machine
Page 2
www.aeg.com2
CONTENTS
1. SAFETY INFORMATION......................................................................................3
2. SAFETY INSTRUCTIONS.................................................................................... 4
3. PRODUCT DESCRIPTION...................................................................................6
4. TECHNICAL DATA............................................................................................... 7
5. INSTALLATION.....................................................................................................8
6. ACCESSORIES.................................................................................................. 12
7. CONTROL PANEL..............................................................................................13
8. DIAL AND BUTTONS......................................................................................... 15
9. PROGRAMMES..................................................................................................18
10. BEFORE FIRST USE........................................................................................23
11. SETTINGS........................................................................................................ 23
12. DAILY USE....................................................................................................... 24
13. HINTS AND TIPS..............................................................................................29
14. CARE AND CLEANING.................................................................................... 31
15. TROUBLESHOOTING......................................................................................37
16. CONSUMPTION VALUES................................................................................41
17. ENVIRONMENTAL CONCERNS......................................................................43
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
Page 3
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
• Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do
not play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when
the door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH 3
1.2 General Safety
• This appliance is for washing domestic-type, machine-
washable laundry only.
Page 4
www.aeg.com4
• This appliance is designed for single household
domestic use in an indoor environment.
• This appliance may be used in, offices, hotel guest
rooms, bed & breakfast guest rooms, farm guest
houses and other similar accommodation where such
use does not exceed (average) domestic usage levels.
• Do not change the specification of this appliance.
• The appliance maximum load is 10 kg. Do not exceed
the maximum load of each programme (refer to the
“Programmes” chapter).
• The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
• The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
• The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
• Old hose sets must not be reused.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
• Do not use high pressure water sprays and/or steam
to clean the appliance.
• Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Remove all the packaging and the
transit bolts including rubber bush
with plastic spacer.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
Page 5
ENGLISH 5
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Follow the installation instructions
supplied with the appliance.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
• Do not install the appliance directly
above a floor drain.
• Do not spray water on the appliance
and do not expose it to excessive
humidity.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Do not put a closed container to
collect possible water leakage under
the appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Water connection
• The inlet water shall not exceed
25 °C.
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
Authorised Service Centre for the
replacement of the inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing
of the appliance with the use of water
in the factory.
• You can extend the drain hose to
maximum 400 cm. Contact the
Authorised Service Centre for the
other drain hose and the extension.
• Make sure that there is access to the
tap after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
Page 6
www.aeg.com6
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber
parts of the washing machine.
Prewash such fabrics by hand before
loading them into the washing
machine.
• Do not touch the glass door while a
programme operates. The glass can
get hot.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or nonprofessional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 10 years after the model
has been discontinued: motor and
motor brushes, transmission between
motor and drum, pumps, shock
absorbers and springs, washing drum,
drum spider and related ball bearings,
heaters and heating elements,
including heat pumps, piping and
related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware
including reset software, door, door
hinge and seals, other seals, door
locking assembly, plastic peripherals
such as detergent dispensers. Please
note that some of these spare parts
are only available to professional
repairers, and that not all spare parts
are relevant for all models.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. PRODUCT DESCRIPTION
3.1 Special features
Your new washing machine meets all
modern requirements for an effective
treatment of laundry with low water,
energy and detergent consumption and
proper care of fabric.
• The UniversalDose drawer with a
compartment dedicated to each type
of detergent, including a compartment
for PODS, equipped with a system
able to spread and mixing the
detergent in an optimal way, and to to
dissolve the detergent residues after
each cycle.
• The ProSense technology detects
the laundry load size defining the
programme duration in 30 seconds.
The washing programme is tailored to
the laundry load and the type of fabric
without consuming more time, energy
and water than necessary.
• The steam has a quick and easy way
to refresh the clothes. The gentle
steam programmes remove odours
and reduce creases in dry fabrics so
they need little ironing.
The Vapore finale option, finishes
every cycle with gentle steam that
relaxes the fibres and reduces fabric
creasing. Ironing will be easier!
Page 7
1 2 3
9
5
6
7
4
10
8
11 12
00000000
00A
Mod.
xxxxxxxxx
000V ~ 00Hz 0000 W
910000000
00
A
B
C
Prod.No.
D
ENGLISH 7
• Thanks to the Più morbido option,
the fabric softener is uniformly spread
out in the laundry and deeply
3.2 Appliance overview
Worktop
1
Detergent dispenser
2
Control panel
3
Door handle
4
Rating plate
5
Drain pump filter
6
Feet for levelling the appliance
7
penetrates the fabric fibres favouring
a perfect softness.
Drain hose
8
Inlet hose connection
9
Mains cable
10
Transit bolts
11
Hose support
12
4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /66.0 cm
Electrical connection Voltage
The rating plate reports the model name
(A), product number (B), electrical ratings
(C) and serial number (D).
230 V
Overall power
Fuse
Frequency
2200 W
10 A
50 Hz
Page 8
www.aeg.com8
Level of protection against ingress of solid particles and
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against mois‐
ture
Water supply pressure Minimum
Water supply
Maximum Load Cotton 10 kg
Spin Speed Maximum spin speed 1351 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
1)
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
WARNING!
Remove all the packaging
and the transit bolts before
installing the appliance.
WARNING!
Use the gloves.
Maximum
IPX4
0.5 bar (0.05 MPa)
8 bar (0.8 MPa)
Cold water
3. Remove the internal film.
1. Remove the external film. If
necessary, use a cutter.
2. Remove the cardboard top and the
polystyrene packaging materials.
4. Open the door and remove the
polystyrene piece from the door seal
and all the items from the drum.
Page 9
1
2
ENGLISH 9
5. Carefully put the appliance down on
its rear side.
6. Put the front polystyrene packaging
element on the floor under the
appliance.
Make sure not to
damage the hoses.
7. Remove the polystyrene protection
from the bottom.
It is possible to see
water flowing from the
drain hose. This is due
to the testing with water
of the appliance in
factory.
10. Remove the three bolts by using the
spanner supplied with the appliance.
8. Pull up the appliance in vertical
position.
9. Remove the power supply cable and
the drain hose from the hose holders.
11. Pull out the plastic spacers.
12. Put the plastic caps, that you find in
the user manual bag, in the holes.
We recommend that you
keep the packaging and the
transit bolts for any
movement of the appliance.
5.2 Positioning and levelling
1. Install the appliance on a flat hard
floor.
Page 10
x4
20º20º
45º45º
www.aeg.com10
Make sure that carpets do
not stop the air circulation
below the appliance.
Make sure that the appliance
does not touch the wall or
other units.
2. Loosen or tighten the feet to adjust
the level.
WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
5.3 The inlet hose
1. Connect the water inlet hose to the
back of the appliance.
2. Position it toward left or right
depending on the position of the
water tap.
The appliance must be level and stable.
A correct adjustment of the
appliance level prevents the
vibration, noise and the
movement of the appliance
when in operation.
When the appliance is
installed on a plinth or a
tumble dryer is stacked on
the washing machine, use
the accessories described in
chapter 'Accessories'. Read
carefully the instructions
supplied with the appliance
and with the accessory.
Make sure that the inlet hose
is not in vertical position.
3. If necessary, loose the ring nut to set
it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4" thread.
WARNING!
The inlet water shall not
exceed 25 °C.
Page 11
CAUTION!
A
Make sure that there are no
leaks from the couplings.
Do not use an extension
hose if the inlet hose is too
short. Contact the service
centre for the replacement of
the inlet hose.
5.4 Water-stop device
The inlet hose has a water stop device.
This device prevents water leaks in the
hose because of its natural ageing.
The red sector in the window «A» shows
this fault.
ENGLISH 11
2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the plastic
guide cannot move when the
appliance drains.
If this occurs, close the water tap and
contact the authorized service centre to
replace the hose.
5.5 Water drainage
The drain hose should be positioned at a
height of not less than 60 cm and not
more than 100 cm from the floor.
You can extend the drain
hose to maximum 400 cm.
Contact the authorized
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose
guide.
Make sure that the drain
hose end is not immersed in
the water. There may be a
return of dirty water into the
appliance.
3. To a stand pipe with vent-hole Insert the drain hose directly into a
drain pipe. Refer to the illustration.
The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm min. 1.5") must be larger
than the external diameter of
the drain hose.
Page 12
www.aeg.com12
4. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
5. Without the plastic hose guide, to
a sink spigot - Put the drain hose in
the spigot and tighten it with a clamp.
Refer to the illustration.
Make sure that the drain
hose makes a loop to
prevent particles going into
the appliance from the sink.
6. Position the hose directly to a built-
in drain pipe in the room wall and
tighten it with a clamp.
5.6 Electrical connection
At the end of installation you can connect
the mains plug to the mains socket.
The rating plate and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are
compatible with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any
other appliances in use.
Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install
this appliance, contact our Authorised
Service Centre.
The manufacturer does not accept any
responsibility for damage or injury
through failure to comply with the above
safety precaution.
6. ACCESSORIES
6.1 Available in
www.aeg.com/shop or from
authorised dealer
Read carefully the instructions supplied
with the accessory.
Only appropriate
accessories approved by
AEG ensure the safety
standards of the appliance. If
unapproved parts are used,
any claims will be
invalidated.
Page 13
Piu’ Morb
i
d
o
Solo Scar
ico
S
olo
Centrifu
g
a
S
o
lo Riscia cquo
Opzione
2
3
6
12 11 10 8
1
4
5
7
9
13
ENGLISH 13
6.2 Fixing plate kit
If you install the appliance on a plinth
that is not an accessory supplied by
AEG, secure the appliance in the fixing
plates.
Read carefully the instructions supplied
with the accessory.
6.3 Stacking kit
The tumble dryer can be stacked on the
top of the washing machine only by
using the correct stacking kit.
WARNING!
Do not put the tumble dryer
under the washing machine.
Verify the compatible
stacking kit by checking the
depth of your appliances.
6.4 Pedestal with the drawer
To raise your appliance and make
loading and unloading laundry easier.
The drawer can be used for laundry
storage e.g.: towels, cleaning products
and more.
7. CONTROL PANEL
7.1 Control panel description
Programme dial
1
2
Display
Page 14
www.aeg.com14
Delay start touch button (Partenza
3
Ritardata)
Time saving touch button (Risparmio
4
Tempo)
Skipping phase touch button
5
(Opzione)
• Wash phase skipping (Solo
Risciacquo)
• Wash and rinse phase skipping
(Solo Centrifuga)
• Only drain (Solo Scarico)
Start/Pause touch button (Avvio/
6
Pausa)
Extra rinse touch button (Extra
7
Risciacquo)
7.2 Display
Pods® touch button
8
Super steam touch button (Vapore
9
finale)
Anti-stain and prewash touch button
10
(Macchie/Prelavaggio)
Spin reduction touch button
11
(Centrifuga)
12
On/Off push button (On/Off)
Temperature touch button
13
(Temperatura)
Maximum load indicator. The icon flashes during laundry load estima‐
tion (refer to "PROSENSE load detection" paragraph).
Maximum laundry indicator. It flashes when the laundry load exceeds the
maximum declared load of the selected programme.
Delay start indicator.
Door locked indicator.
The digital indicator can show:
• Programme duration (e. g. ).
• Delay time (e. g. or ).
• Cycle end (
• Warning code (e.g. ).
Washing phase indicator: it flashes during prewash and wash phase.
).
Page 15
ENGLISH 15
Rinsing phase indicator: it flashes during rinse phase.
The indicator appears when the Più morbido option is activated.
Spin and drain phase indicator. It flashes during spin and drain phase.
Steam phase indicator.
Anti-crease phase indicator.
Child safety lock indicator.
Time saving indicator.
Temperature indicator. The indicator appears when a cold wash is
set.
Spin speed indicator.
Rinse hold indicator.
Extra Silent indicator.
Pre-wash indicator.
Stain indicator.
Extra rinse indicator.
8. DIAL AND BUTTONS
8.1 On/Off
Pressing this button for a few seconds
allows to activate or deactivate the
appliance. Two different tunes sound
while switching the appliance on or off.
As the Stand-by function automatically
deactivates the appliance to decrease
the energy consumption in a few cases,
you may need to activate the appliance
again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
8.2 Introduction
The options/functions are
not selectable with all
washing programmes.
Check the compatibility
between options/functions
and washing programmes in
the "Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set the incompatible
options/functions together.
Make sure the screen and
touch buttons are always
clean and dry.
Page 16
www.aeg.com16
8.3 Temperatura
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Touch this button repeatedly until the
desired temperature value appears on
the display.
When the display shows the indicators
and , the appliance does not heat
the water.
8.4 Centrifuga
When you set a programme, the
appliance automatically selects the
default spin speed.
Touch this button repeatedly to:
• Change the spin speed.
The display shows only
the spin speeds available
for the set programme.
• Activate the Rinse Hold option .
The water of the last rinse is not
drained out to prevent the fabrics from
creasing. The washing programme
ends with water in the drum and the
final spin phase is not performed.
The display shows the indicator .
The drum turns regularly to reduce
creasing.
The door stays locked. The drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
Touch Avvio/Pausa button: the
appliance performs the spinning
phase and drains the water.
• Activate the Extra silent option.
All spinning phases (intermediate spin
and final spin) are suppressed and
the programme ends with water in the
drum. This helps to reduce creasing.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are
available. In some programmes the
rinses are performed with more water.
The display shows the indicator
The door stays locked. The drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
.
Touch the Avvio/Pausa button: the
appliance performs only the draining
phase.
The appliance empties the
water out automatically after
approximately 18 hours.
8.5 Macchie/Prelavaggio
Press this button repeatedly to activate
one of the two options.
The relevant indicator goes on in the
display.
• Macchie
Select this option to add an anti-stain
phase to a programme in order to
treat heavily soiled or stained laundry
with stain remover.
Pour the stain remover into
compartment . The stain remover
will be added in the appropriate phase
of the washing programme.
This option can increase
the programme duration.
This option is not
available with a
temperature lower than
40 °C.
• Prelavaggio
Use this option to add a prewash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
containing sand, dust , mud and other
solid particles.
This option can increase
the programme duration.
These two options cannot be
set together.
8.6 Extra Risciacquo
With this option you can add up to 3
rinses accordingly to the selected
washing programmes.
Useful for people allergic to detergents
and in areas where the water is soft.
Page 17
ENGLISH 17
The indicator shows the selected
number of rinses.
This option increases the programme
duration.
If the Extra Risciacquo is set
as a default option and you
select a compatible washing
programme, the display
shows . In this case, by
pressing the Extra
Risciacquo button , it is
possible to add just one
rinse.
8.7 Vapore finale
This option adds a steam phase followed
by a short anti-crease phase at the end
of the washing programme.
The steam phase reduces fabric
creasing and facilitates the fabric ironing.
The indicator
during steam phase.
This option can increase the
programme duration.
When the programme stops the display
shows a zero , the indicator is
steady on and the indicator starts
flashing, and the Avvio/Pausa led
remains lit. The drum performs smooth
movements for about 30 minutes to keep
the steam benefit. By touching any
button the anti-crease movements stop
and the door unlocks, the appliance
proposes again the previous set
programme.
To interrupt the anti-crease phase, you
can also:
• Press the On/Off button for a few
seconds to activate or the deactivate
the appliance.
• Turning the programme dial in
another position.
A small laundry load helps to
reach better results.
flashes on the display
8.8 Partenza Ritardata
With this option you can delay the start of
a programme in a more convenient time.
Touch the button repeatedly to set the
required delay. The time increases by
steps of 30 minutes up to 90' and from 2
hours up to 20 h.
After touching the Avvio/Pausa button,
the display shows the indicator
the selected delay time and the
appliance begins the countdown.
and
8.9 Risparmio Tempo
With this option you can decrease the
programme duration.
• If your laundry is normally or lightly
soiled, it may be advisable to shorten
the washing programme. Touch this
button once to decrease the duration.
• In case of smaller load, touch this
button twice to set an extra quick
programme.
The display shows the indicator
This option can also be used
to shorten the steam
programme duration.
.
8.10 Skipping phase button
(Opzione)
By touching this button you can set:
• Solo Risciacquo at first touch. The
washing programme starts from the
rinsing phase by skipping the wash
phase.
All set options (except
permanent extra rinse)
are deselected
automatically.
• Solo Centrifuga at second touch. The
appliance skips wash and rinse
phase.
• Solo Scarico at third touch. The
appliance performs only the drain
phase.
At firth touch the appliance
proposes the default setting
of the washing programme
again.
Page 18
www.aeg.com18
8.11 Pods®
Touch this button to activate or
deactivate the Pods® option .
When activated the relevant indicator is
on.
Follow the Pods manufacturer's dosage
and storage recommendations.
Put maximum two tablets or single-dose
detergents in the Pods® compartment in
the detergent dispenser drawer.
9. PROGRAMMES
9.1 Programme Chart
Washing programmes
Programme Programme description
Washing programmes
Eco 40-60
Cotoni
Sintetici
Delicati
Lana/Seta
Steam programme
The option remains active also for next
cycles until it is deactivated and if it is
selectable with the set programme.
8.12 Avvio/Pausa
Touch the Avvio/Pausa button to start,
pause the appliance or interrupt a
running programme.
White cotton and fast-coloured cotton. Normally soiled
items. The energy consumption decreases and the time of the
washing programme is extended, ensuring good washing re‐
sults.
White cotton and coloured cotton. Normally, heavily and
lightly soiled items.
Synthetic items or mixed fabric items. Normally soiled
items.
Delicate fabrics such as acrylics, viscose and mixed fab‐
rics requiring gentler washing. Normally and lightly soiled
items.
Machine washable wool, hand washable wool and other
fabrics with «hand washing» care symbol1).
Page 19
Programme Programme description
Cotton, synthetics and mixed items. Special steam cycle
Vapore
Washing programmes
MyMix 69min
20 min. - 3 kg
without washing that can be used to prepare your dried laundry
for ironing or refreshing garments worn once2). This pro‐
gramme reduces creases and odours
When the programme is completed, quickly remove the laun‐
dry from the drum. After a steam programme, ironing becomes
effortless. Do not use any detergent. If necessary, remove
stains by washing or using localized stain removal. Steam pro‐
grammes do not perform any hygienic cycle. Do not set a
Steam programme with these types of items:
• Items that are not suitable for tumble drying.
• Items with label "Dry clean only".
Cotton and mixed synthetic fabrics. Ideal to wash your daily
load in a short time, for a better clothes care and good cleaning
already at 30°C.
Cotton and synthetic items lightly soiled or once worn.
ENGLISH 19
3)
and relaxes the fibres.
Outdoor
Do not use fabric softener and make sure that
there is no softener residue in the detergent
dispenser.
Outdoor clothing, technical, sport fabrics, waterproof and
breathable jackets, shell jackets with a removable fleece
or inner insulation. The recommended laundry load is 2.5 kg.
This programme can also be used as water-repellent restoring
cycle, specifically tailored for treating clothes with a hydropho‐
bic coating. To perform the water-repellent restoring cycle, pro‐
ceed as follows:
• Pour the washing detergent in the compartment
• Pour a special water-repellent restorer for fabric in the
drawer compartment for fabric softener .
• Reduce the laundry load to 1 kg.
.
To further improve the water-repellent restor‐
ing action, dry the laundry in a tumble dryer by
setting the Outdoor drying programme (if avail‐
able and if the garment care label permits tum‐
ble drying).
Page 20
www.aeg.com20
Programme Programme description
White cotton items. This high-performance wash program
Anti-Allergy
combined with steam vapour, removes more than 99,99% of
bacteria and viruses4) keeping the temperature above 60°C
throughout the washing phase; with an additional action on the
fibers thanks to a vapour phase, an enhanced rinsing phase
ensures a proper removal of detergent and micro-organism
residues. This program ensures also a proper reduction of pol‐
lens/allergenic items.
1)
During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
2)
If you set a Steam programme with dried laundry, at the end of the cycle the laundry can be humid.
Line dry the items for about 10 minutes.
3)
Steam programme doesn't remove particularly intense odour.
4)
Tested for Staphylococcus aureus, Enterococcus faecium, Candida albicans, Pseudomonas aerugino‐
sa and MS2 Bacteriophage in external test performed by Swissatest Testmaterialien AG in 2021 (Test
Report No. 202120117).
Programme temperature, maximum spin speed and maximum load
Programme Default temperature
Temperature range
Reference spin
speed
Maximum load
Spin speed range
Eco 40-60
Cotoni
Sintetici
Delicati
Lana/Seta
Vapore
MyMix 69min
20 min. - 3 kg
Outdoor
1)
40 °C
40 °C
95 °C - Cold
40 °C
60 °C - Cold
30 °C
40 °C - Cold
40 °C
40 °C - Cold
1400 rpm
1400 rpm - 400 rpm
1400 rpm
1400 rpm - 400 rpm
1200 rpm
1200 rpm - 400 rpm
800 rpm
1200 rpm - 400 rpm
1200 rpm
1200 rpm - 400 rpm
10 kg
10 kg
4 kg
2 kg
1.5 kg
- - 1 kg
30 °C
60 °C - 30 °C
30 °C
40 °C - 30 °C
30 °C
40 °C - Cold
1400 rpm
1400 rpm - 400 rpm
1200 rpm
1200 rpm - 400 rpm
1200 rpm
1200 rpm - 400 rpm
5 kg
3 kg
2.5 kg
1 kg
2)
3)
Page 21
ENGLISH 21
Programme Default temperature
Temperature range
Reference spin
speed
Maximum load
Spin speed range
Anti-Allergy
1)
According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to clean normal‐
ly soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
For the reached temperature in the laundry, the programme duration and other data,
please refer to 'Consumption Values' chapter.
The most efficient programmes in terms of energy consumption are generally those that
perform at lower temperatures and longer duration.
2)
Washing programme.
3)
Washing programme and waterproofing phase.
60 °C
1400 rpm
1400 rpm - 400 rpm
10 kg
Programme options compatibility
Cotoni
Delicati
Sintetici
Vapore
Lana/Seta
MyMix 69min
20 min. - 3 kg
Outdoor
Centrifuga
Eco 40-60
■ ■ ■ ■ ■ ■ ■ ■ ■
Anti-Allergy
■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■
Macchie1)
Prelavaggio
Extra Risciac‐
quo
■ ■ ■ ■
■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■
Pods® ■ ■ ■ ■ ■ ■ ■ ■
Risparmio Tem‐
po 2)
■ ■ ■ ■ ■
Solo Risciacquo ■ ■ ■ ■ ■ ■ ■ ■ ■
Solo Centrifuga ■ ■ ■ ■ ■ ■ ■ ■ ■
Solo Scarico ■ ■ ■ ■ ■ ■ ■ ■ ■
Page 22
www.aeg.com22
Eco 40-60
Cotoni
Delicati
Sintetici
Vapore
Lana/Seta
MyMix 69min
20 min. - 3 kg
Outdoor
Anti-Allergy
Partenza Ritar‐
data
Vapore finale
3)
Più morbido
1)
This option is not available with temperature lower than 40 °C.
2)
If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully
load the appliance, however the washing results can be less satisfactory.
3)
This option is not available with temperature lower than 40 °C.
■ ■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■
■ ■ ■ ■ ■ ■
Suitable detergents for washing programmes
Programme Universal
powder
1)
Liquid Uni‐
versal
Liquid for
coloureds
Delicates
woollens
Special
Eco 40-60 ▲ ▲ ▲ -- --
Cotoni ▲ ▲ ▲ -- --
Sintetici ▲ ▲ ▲ -- --
Delicati -- -- -- ▲ ▲
Lana/Seta -- -- -- ▲ ▲
MyMix 69min -- ▲ ▲ -- --
20 min. - 3 kg -- ▲ ▲ -- --
Outdoor -- -- -- ▲ ▲
Anti-Allergy ▲ ▲ -- -- -- ▲
1)
At temperature higher than 60 °C the use of powder detergent is recommended.
▲ = Recommended -- = Not recommended
Page 23
9.2 Woolmark Apparel Care - Blue
10. BEFORE FIRST USE
ENGLISH 23
The wool wash cycle of this machine has
been approved by The Woolmark Company
for the washing of wool garments labelled as
«hand wash» provided that the garments are
washed according to the instructions issued
by the manufacturer of this washing machine.
Follow the garment care label for drying and
other laundry instructions. M1230
The Woolmark symbol is a Certification mark
in many countries.
During installation or before
first use you may observe
some water in the appliance.
This is a residual water left
in the appliance after a full
functional test in the factory
to ensure the appliance is
delivered to customers in
perfect working order and is
no cause for concern.
1. Make sure that all transit bolts have
been removed from the appliance.
2. Make sure that the electrical power is
available and the water tap is open.
11. SETTINGS
11.1 Child Lock
With this option you can prevent that the
children play with the control panel.
• To activate/deactivate this option,
touch the Macchie/Prelavaggio and
the Extra Risciacquo buttons
simultaneously until the indicator
comes on/goes off on the display.
You can activate this option:
• After you touch the Avvio/Pausa
button: all the buttons and the
programme dial are deactivated
(except On/Off button ).
• Before you touch the Avvio/Pausa
button: the appliance cannot start.
The appliance keeps the selection of this
option after you switch it off.
3. Pour 2 litres of water into the
detergent compartment marked by
.
This action activates the drain system.
4. Pour a small quantity of detergent
into the compartment marked by .
5. Set and start a programme for cotton
at the highest temperature without
any laundry in the drum.
This removes all possible dirt from the
drum and the tub.
11.2 Acoustic signals
This appliance is provided with different
acoustic signals, that operate when:
• You activate the appliance (special
short tune).
• You deactivate the appliance (special
short tune).
• You touch the buttons (click sound).
• You make a wrong selection (3 short
sounds).
• The programme is completed
(sequence of sounds for about 2
minutes).
• The appliance has a malfunction
(sequence of short sounds for about 5
minutes).
To deactivate/activate the acoustic
signals when the programme is
completed, touch the Extra Risciacquo
Page 24
www.aeg.com24
and the Pods buttons simultaneously for
about 6 seconds.
If you deactivate the
acoustic signals, they
continue operate when the
appliance has a malfunction.
11.3 Permanent Extra Rinse
With this option you can permanently
have an extra rinse when you set a
programme where it is selectable.
• To activate/deactivate this option
touch the Extra Risciacquo button and
the Opzione button simultaneously
the relevant indicator comes on/goes
off.
This option adds two rinses and the
display shows .
12. DAILY USE
WARNING!
Refer to Safety chapters.
12.1 Activating the appliance
1. Connect the mains plug to the mains
socket.
2. Open the water tap.
3. Press the On/Off button for a few
seconds to activate the appliance.
A short tune sounds (if activated). The
appliance automatically proposes a
default programme. The relevant
indicator illuminates.
The display shows the maximum load,
the default temperature, the default spin
speed, the indicators of the phases
making up the programme and the cycle
duration.
11.4 Più morbido
Set the Più morbido option to optimise
the fabric softener distribution and
improve the fabric softness.
It is suggested when you use the fabric
softener.
This option increases slightly
the programme duration.
To activate/deactivate this option touch
the Temperatura button and the
Centrifuga button simultaneously until
the
indicator comes on/goes off
above the indicator.
CAUTION!
Make sure that no laundry
stays between the seal and
the door. There is a risk of
water leakage or damage to
the laundry.
12.2 Loading the laundry
1. Open the appliance door.
2. Shake the items before you put them
in the appliance.
3. Put the laundry in the drum, one item
at a time.
Make sure not to put too much laundry in
the drum.
4. Close the door firmly.
CAUTION!
Washing heavily oiled,
greasy stains could cause
damage rubber parts of the
washing machine.
Page 25
ENGLISH 25
12.3 Filling the detergent and additives
- Compartment for detergent pods
(Max 2 pods). When using detergent tab‐
lets, make sure that the Pods option is ac‐
tivated.
- Compartment for prewash phase
an soak programme (powder detergent
only).
- Compartment for washing phase
(powder detergent only).
Make sure that the Pods
option is deactivated when
using this compartment.
After a washing cycle, if
necessary, remove any
detergent residue from the
detergent dispenser.
Proceed as follows
1. Open the detergent dispenser.
2. If a prewash phase is set, put the
powder detergent in compartment
.
3. For main wash, chose the proper
compartment depending on the type
of detergent:
a) Put the powder detergent in the
compartment .
If using liquid detergent, re‐
member to insert the con‐
tainer for liquid detergent
.
- Compartment for fabric softener
and other liquid treatments (fabric condi‐
tioner, starch).
- Always follow the instructions that
you find on the packaging of the detergent
products, but we recommend that you do
not exceed the maximum indicated level
( ). This quantity will however guaran‐
tee the best washing results.
b) Pour the liquid detergent in the same
compartment after inserting the relevant
container .
Page 26
www.aeg.com26
c) Put the tablets in the compartment
. Make sure that the Pods option is
activated.
4. Pour fabric softener in the
compartment .
5. Close the detergent dispenser.
12.4 Bleach
Alternatively the softener, it is also
possible to use a bleach agent in the
compartment with the programmes
for white cottons.
Proceed as follows:
1. Put the bleach in the compartment
.
Do not exceed the «MAX» mark in the
detergent dispenser drawer.
2. Run a programme for white cottons.
3. At the end of the programme, run the
rinse programme or a programme
with the rinse option. Use softener, if
desired.
This helps to eliminate any bleach
residues.
Never pour bleach and
softener into the
compartment at the same
time.
12.5 Setting a programme
1. Turn the programme dial to select the
desired washing programme. The
related programme indicator comes
on.
The indicator of the Avvio/Pausa button
flashes.
The display shows the maximum
declared load for the programme, the
default temperature, the default spin
speed, the washing phase indicators
(when available) and an indicative
programme duration.
2. To change the temperature and/or
the spin speed, touch the related
buttons.
3. If desired, set one or more options by
touching the related buttons. The
related indicators come on in the
display and the given information
changes accordingly.
In case a selection is not
possible, no indicator
comes on and an acoustic
signal sounds.
12.6 Starting a programme
Touch the Avvio/Pausa button to start
the programme.
The related indicator stops flashing and
stays on.
In the display, the indicator of the
operating phase starts flashing.
The programme starts, the door is
locked. The display shows the indicator
.
Page 27
ENGLISH 27
The drain pump can operate
shortly before the appliance
fills water.
12.7 Starting a programme with the delay start
1. Touch this repeatedly until the
display shows the desired delay time.
The indicator comes on.
2. Touch the Avvio/Pausa button.
The appliance starts the countdown of
the delay start.
When the countdown is completed, the
programme starts.
The ProSense estimation
starts at the end of the
countdown.
Cancelling the delay start after the countdown has started
To cancel the delay start:
1. Touch the Avvio/Pausa button to
pause the appliance. The related
indicator flashes.
2. Touch the Partenza Ritardata button
repeatedly until the display shows .
3. Touch the Avvio/Pausa button again
to start the programme immediately.
Changing the delay start after the countdown has started
To change the delay start:
1. Touch the Avvio/Pausa button to
pause the appliance. The related
indicator flashes.
2. Touch the Partenza Ritardata button
repeatedly until the display shows the
desired delay time.
3. Touch the Avvio/Pausa button again
to start the new countdown.
12.8 The ProSense load
detection
The programme duration in
the display is referred to a
medium/high load.
After touching the Avvio/Pausa button,
the maximum declared load indicator
goes off, the indicator flashes, the
ProSense starts the laundry load
detection:
1. The appliance detects the load in the
first 30 seconds: the indicator and
the time dots
shortly.
2. At the end of the load detection, the
indicator goes off and the time
dots stop flashing. The programme
duration will be adjusted accordingly
and could increase or decrease. After
further 30 seconds, the water filling
starts.
At the end of the load detection, in case
of drum overload, the indicator is
flashing in the display:
In this case, for 30 seconds, it is possible
to pause the appliance and remove the
exceeding garments.
Once removed the exceeding garments,
touch the Avvio/Pausa button to start the
programme again. The ProSense phase
can be repeated up to three times (see
point 1).
Important! If the laundry amount will not
be reduced, the washing programme
starts anyway, despite the overload. In
this case, it will be not possible to
guarantee the best washing results.
About 20 minutes after the
programme start, the
programme duration could
be adjusted again depending
on the capacity of water
absorption of the fabrics.
The ProSense detection is
carried out with complete
washing programmes only
(no skipping phase
selected).
The ProSense is not
available with some
programmes, such as Lana/
Seta, programmes with short
cycles and without washing
phase.
flash, the drum rotates
Page 28
www.aeg.com28
12.9 Programme phase indicators
When the programme starts the indicator
of the running phase flashes and the
other phase indicators are steady on.
E.g. the washing or pre wash phase is
running:
When the phase ends the relevant
indicator stops flashing and is steady on.
The next phase indicator starts flashing.
E.g. the rinse phase is running: .
If you select the Vapore finale the steam
phase indicators come on.
The steam phase is running:
The anti-crease phase is running:
.
.
.
12.10 Interrupting a programme and changing the options
When the programme is running, you
can change only some options:
1. Touch the Avvio/Pausa button.
The related indicator flashes.
2. Change the options. The given
information in the display changes
accordingly.
3. Touch the Avvio/Pausa button again.
The washing programme continues.
12.11 Cancelling a running
programme
1. Press the On/Off button to cancel the
programme and to deactivate the
appliance.
2. Press the On/Off button again to
activate the appliance.
Now, you can set a new washing
programme.
If the ProSense phase is
already carried out and the
water filling is already
started, the new programme
starts without repeating the
ProSense phase. The water
and the detergent are not
drained out in order to avoid
waste. The display shows
the maximum duration of the
programme, updating it
about 20 minutes after the
starting of the new
programme.
12.12 Opening the door Adding garments
While a programme or the delay start
operates, the appliance door is locked.
If the temperature and level
of the water in the drum are
too high and/or the drum still
rotates you cannot open the
door.
1. Touch the Avvio/Pausa button.
In the display the related door lock
indicator goes off.
2. Open the appliance door. If
necessary, add or remove the items.
3. Close the door and touch the Avvio/
Pausa button.
The programme or the delay start
continues.
4. The door can be opened when the
programme is complete, or set
spinning or draining programme/
option and than press Avvio/Pausa
button.
12.13 End of the programme
When the programme has finished, the
appliance stops automatically. The
acoustic signals operate (if they are
active).
In the display all washing phase
indicators become steady and the time
area shows .
The indicator of the Avvio/Pausa button
goes off.
Page 29
ENGLISH 29
The door unlocks and the indicator
goes off.
1. Press the On/Off button to deactivate
the appliance.
After five minutes from the end of the
programme, the energy saving function
automatically deactivates the appliance.
When you activate the
appliance again, the display
show the end of the last
selected programme. Turn
the programme dial to set a
new cycle.
2. Remove the laundry from the
appliance.
3. Make sure that the drum is empty.
4. Keep the door and the detergent
dispenser slightly ajar to prevent
mildew and odours.
5. Close the water tap.
12.14 Draining water out after
end of cycle
If you have chosen a programme or an
option that does not empty out the water
of the last rinse, the programme is
completed, but:
• The display shows the indicator , the
option indicator
door locked indicator . The
indicator of the running phase
flashes.
• The drum still turns at regular
intervals to prevent the creases in the
laundry.
• The door stays locked.
• You must drain the water to open the
door:
1. If necessary, touch the Centrifuga
button to decrease the spin speed
proposed by the appliance.
or and the
2. Touch the Avvio/Pausa button:
• If you have set , the appliance
drains the water and spins.
• If you have set , the appliance
only drains the water.
The option indicator or goes off,
while the indicator
goes off.
3. When the programme is completed
and the door locked indicator
goes off, you can open the door.
4. Press the On/Off button a few
seconds to deactivate the appliance.
In any case, the appliance
empties the water out
automatically after
approximately 18 hours.
flashes and then
12.15 Stand-by option
The Stand-by function automatically
deactivates the appliance to decrease
the energy consumption when:
• You do not use the appliance for 5
minutes before you touch the Avvio/
Pausa button.
Press the On/Off button to activate
the appliance again.
• After 5 minutes from the end of the
washing programme
Press the On/Off button to activate
the appliance again.
The display shows the end of the last
set programme.
Turn the programme dial to set a new
cycle.
If you set a programme or an
option that ends with water
in the drum, the Stand-by
function doesn't deactivate
the appliance to remind you
to drain the water.
13. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
13.1 The laundry load
• Divide the laundry into: white,
coloured, synthetics, delicates and
wool.
• Follow the washing instructions on the
laundry care labels.
Page 30
www.aeg.com30
• Do not wash white and coloured items
together.
• Some coloured items can discolour
with the first wash. We recommend
that you wash them separately for the
first couple of times.
• Turn multilayered fabrics, wool and
items with printed illustrations inside
out.
• Pre-treat stubborn stains.
• Wash stubborn stains with a special
detergent.
• Be careful with curtains. Remove the
hooks and put the curtains in a
washing bag or pillowcase.
• A very small load can cause balance
problems with the spin phase leading
to excessive vibration. If this occurs:
a. interrupt the programme and
open the door (refer to "Daily
Use" chapter);
b. manually redistribute the load so
that the items are spaced evenly
around the tub;
c. press the Avvio/Pausa button.
The spin phase continues.
• Button up pillowcases, close zippers,
hooks and poppers. Tie up belts,
cords, shoelaces, ribbons and any
other loose elements.
• Do not wash laundry without hems or
with cuts. Use a washing bag to wash
small and/or delicate items (e.g.
underwired bras, belts, tights,
shoelaces, ribbons, etc. ).
• Empty pockets and unfold the items.
13.2 Stubborn stains
For some stains, water and detergent is
not sufficient.
We recommend that you pre-treat these
stains before you put the items in the
appliance.
Special stain removers are available.
Use the special stain remover that is
applicable to the type of stain and fabric.
Do not spray stain remover on garments
near the appliance as it is corrosive to
the plastic parts.
13.3 Detergent type and quantity
The choice of detergent and use of
correct quantities not only affects your
wash performance, but also helps to
avoid waste and protect the environment:
• Use only detergents and other
treatments specially made for
washing machines. First, follow these
generic rules:
– powder detergents (also tablets
and single-dose detergents) for all
types of fabric, excluding delicate.
Prefer powder detergents
containing bleach for whites and
laundry sanitization,
– liquid detergents (also single-dose
detergents) , preferably for low
temperature wash programmes
(60 °C max) for all types of fabric,
or special ones for woollens only.
• The choice and quantity of detergent
will depend on: type of fabric
(delicates, woollens, cottons, etc), the
colour of clothes, size of the load,
degree of soiling, wash temperature
and hardness of the water used.
• Follow the instructions that you find
on packaging of the detergents or
Page 31
ENGLISH 31
other treatments without exceeding
the indicated maximum level ( ).
• Do not mix different types of
detergents.
• Use less detergent if:
– you are washing a small load,
– the laundry is lightly soiled,
– there is large amounts of foam
during washing.
Insufficient detergent may cause:
• unsatisfactory washing results,
• the wash load to turn grey,
• greasy clothes,
• mould in the appliance.
Excessive detergent may cause:
• sudsing,
• reduced washing effect,
• inadequate rinsing,
• a greater impact for the environment.
13.4 Ecological hints
To save water, energy and to help
protect the environment, we recommend
that you follow these tips:
• Normally soiled laundry may be
washed without prewash in order to
save detergent, water and time (the
environment is protected too!).
• Loading the appliance to the
maximum capacity indicated for
each programmes helps to reduce
energy and water consumption.
• With adequate pre-treatment, stains
and limited soiling can be removed;
the laundry can then be washed at a
lower temperature.
• Set the maximum possible spin
speed for the selected washing
programme before drying your
laundry in a tumble dryer. This will
save energy during drying!
13.5 Water hardness
If the water hardness in your area is high
or moderate, we recommend that you
use a water softener for washing
machines. In areas where the water
hardness is soft it is not necessary to use
a water softener.
To find out the water hardness in your
area, contact your local water authority.
Use the correct quantity of water
softener. Follow the instructions that you
find on the packaging of the product.
14. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
14.1 Periodic cleaning schedule
Periodic cleaning helps to extend the
life of your appliance.
After each cycle, keep the door and the
detergent dispenser slightly ajar to get air
circulation and dry the humidity inside
the appliance: this will prevent mildew
and odours.
If the appliance is not used for a long
time: close the water tap and unplug the
appliance.
Indicative periodic cleaning schedule:
Descaling Twice a year
Maintenance wash Once a month
Clean door seal Every two months
Clean drum Every two months
Clean detergent dis‐
penser
Clean drain pump
filter
Clean the inlet hose
and the valve filter
The following paragraphs explain how
you should clean each part.
Every two months
Twice a year
Twice a year
Page 32
www.aeg.com32
14.2 Removing foreign objects
Make sure that pockets are
empty and all loose
elements are tied up before
running your cycle. Refer to
'The laundry load' in 'Hints
and tips'.
Remove any foreign objects (such as
metal clip, buttons, coins, etc) that you
may find in the door seal, the filters and
the drum. Refer to 'Door seal with double
lip trap', 'Cleaning the drum', 'Cleaning
the drain pump' and 'Cleaning the inlet
hose and the valve filter' paragraphs. If
necessary, please contact the Authorised
Service Centre.
14.3 External cleaning
Clean the appliance with mild soap and
warm water only. Fully dry all the
surfaces.
Do not use a scouring pads or any
scratching material.
CAUTION!
Do not use alcohol, solvents
or chemical products.
CAUTION!
Do not clean the metal
surfaces with chlorine-based
detergent.
Always follow the
instructions that you find on
the packaging of the
product.
14.5 Maintenance wash
The repeated and prolonged use of low
temperature programmes can cause
detergent deposits, fluff residues,
bacterial growth inside the drum and the
tub. This could generate bad odours and
mildew.
To eliminate these deposits and
hygienize the inner part of the appliance,
run a maintenance wash regularly (at
least once a month):
1. Remove all laundry from the drum.
2. Run a cotton programme with the
highest temperature with a small
quantity of powder detergent or, if
available, run the Pulizia programme.
14.6 Door seal
This appliance is designed with a self
cleaning draining system, allowing light
fluff fibers that fall off the clothes to be
drained out with the water. Regularly
examine the seal. Coins, buttons, other
small items can be recovered at the end
of the cycle.
14.4 Descaling
If the water hardness in your
area is high or moderate, we
recommend that you use a
water descaling product for
washing machines.
Regularly examine the drum to check for
limescale.
The regular detergents already contain
water softening agents, but we
recommend to run a cycle with empty
drum and a descaling product
occasionally.
Clean it when needed, using ammonia
cream cleanser agent without scratching
the seal surface.
Always obey the instructions
that you find on the
packaging of the product.
14.7 Cleaning the drum
Regularly examine the drum to prevent
unwanted deposits.
Page 33
Rust deposits in the drum may occur due
2
1
to rusting foreign body in the washing or
tap water containing iron.
Clean the drum with special products for
stainless steel.
Always follow the
instructions that you find on
the packaging of the
product.
Do not clean the drum with
acidic descaling products,
scouring products containing
chlorine or iron or steel.
For a thorough clean:
1. Clean the drum with special products
for stainless steel.
Always follow the
instructions that you find on
the packaging of the
product.
2. Run a short cotton programme at
high temperature with empty drum
and with a small quantity of powder
detergent or, if available, run the
Pulizia programme.
14.8 Cleaning the detergent
dispenser
To prevent possible deposits of dried
detergent, clotted fabric softener,
formation of mould in the detergent
dispenser, once in a while carry out the
following cleaning procedure:
1. Open the detergent dispenser. Press
the catch downwards as indicated in
the picture and pull it out.
ENGLISH 33
3. Lift up the top cover of the
compartments to remove it.
4. Wash the detergent dispenser and
any insert under running water.
5.
CAUTION!
Do not use sharp or
metal brushes and
sponges.
2. Remove the container for liquid
detergent, if inserted.
Make sure that all detergent residue
is removed from the upper and lower
part of the recess. Use a small brush
to clean the recess.
Page 34
CLICK
www.aeg.com34
6. Turn the dispenser up side down and
open the bottom cover as indicated in
the picture.
7. Make sure that all detergent residue
is removed from the conveyor. Use
only soft damp clothes.
8. Put bottom cover back to its position
by aligning its holes on drawer hooks
as indicated in the picture. Close it till
"click" sound.
CAUTION!
Press the bottom cover as
indicated in the picture.
Make sure that it is closed
properly.
9. Reassembly the drawer as follows:
a. Place the bottom cover and
press till "click" sound.
b. Place the top cover and press till
"click" sound.
c. Insert the container for liquid
detergent, if needed.
10. Insert the detergent dispenser into
the guide rails and close it. Run the
rinsing programme without any
clothes in the drum.
.
14.9 Cleaning the drain pump
WARNING!
Disconnect the mains plug
from the mains socket.
Regularly check the drain
pump filter and make sure
that it is clean.
Page 35
Clean the drain pump if:
1
2
1
2
• The appliance does not drain the
water.
• The drum does not turn.
• The appliance makes an unusual
noise because of the blockage of the
drain pump.
• The display shows the alarm code
.
WARNING!
• Do not remove the filter
while the appliance
operates.
• Do not clean the pump if
the water in the appliance
is hot. Wait until the water
cools down
Proceed as follows to clean the pump:
1. Open the pump cover.
ENGLISH 35
5. When the bowl is full of water, turn
the filter back and empty the
container.
6. Repeat the steps 4 and 5 until the
water stops to flow out.
7. Turn the filter anti-clockwise to
remove it.
2. Place a suitable bowl below the drain
pump access to collect the water that
flows out.
3. Open the chute downwards. Always
keep a rag nearby to dry up any
water spillages when removing the
filter.
4. Turn the filter 180 degrees in anticlockwise direction to open it, without
removing. Let the water flow out.
8. If it is necessary, remove fluff and
objects from the filter recess.
9. Make sure that the impeller of the
pump can rotate. If it does not rotate,
contact the Authorised Service
Centre.
10. Clean the filter under the water tap.
Page 36
2
1
2
1
1
2
3
www.aeg.com36
11. Put the filter back into the special
guides by turning it clockwise. Make
sure that you tighten the filter
correctly to prevent leakages.
occasionally to remove any deposit,
collected over the time:
1. Remove the inlet hose from the tap
and clean the filter.
2. Remove the inlet hose from the
appliance by loosening the ring nut.
12. Close the pump cover.
3. Clean the valve filter on the back of
the appliance with a toothbrush.
When you drain the water with the
emergency drain procedure, you must
activate the drain system again:
a. Put 2 litres of water in the main
wash compartment of the
detergent dispenser.
b. Start the programme to drain the
water.
4. When you reconnect the hose to the
back of the appliance, turn it left or
right (not in vertical position)
depending on the position of your
water tap.
14.10 Cleaning the inlet hose and the valve filter
It is recommended to clean both the
filters of the inlet hose and valve
Page 37
45°
20°
14.11 Emergency drain
If the appliance cannot drain the water,
carry out the same procedure, described
in 'Cleaning the drain pump' paragraph. If
necessary, clean the pump.
When you drain the water with the
emergency drain procedure, you must
activate the drain system again:
1. Put 2 litres of water in the main wash
compartment of the detergent
dispenser.
2. Start the programme to drain the
water.
ENGLISH 37
14.12 Frost precautions
If the appliance is installed in an area
where the temperature can reach the
values around 0° C or drop below,
remove the remaining water from the
inlet hose and the drain pump.
1. Disconnect the mains plug from the
mains socket.
2. Close the water tap.
3. Put the two ends of the inlet hose in
a container and let the water flow out
of the hose.
4. Empty the drain pump. Refer to the
emergency drain procedure.
5. When the drain pump is empty,
install the inlet hose again.
WARNING!
Make sure that the
temperature is higher than
0 °C before you use the
appliance again.
The manufacturer is not
responsible for damages
caused by low temperatures.
15. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
15.1 Alarm Codes and Possible failures
The appliance does not start or it stops during operation. First try to find a solution to the
problem (refer to the tables).
WARNING!
Deactivate the appliance before carrying out any check.
Page 38
www.aeg.com38
With some problems, the display shows an alarm code and the
Avvio/Pausa button may flash continuously:
If the appliance is overloaded, remove some items
from the drum and/or keep pressed the door while
touching the Avvio/Pausa button until the indicator
stops flashing (see the picture below).
Problem Possible solution
• Make sure that the water tap is open.
The appliance does
not fill with water prop‐
erly.
The appliance does
not drain the water.
The appliance door is
open or not closed
correctly.
• Make sure that the pressure of the water supply is not too low.
For this information, contact your local water authority.
• Make sure that the water tap is not clogged.
• Make sure that the inlet hose has no kinks, damages or
bends.
• Make sure that the connection of the water inlet hose is cor‐
rect.
• Make sure that the filter of the inlet hose and the filter of the
valve are not clogged. Refer to 'Care and cleaning'.
• Make sure that the sink spigot is not clogged.
• Make sure that the drain hose has no kinks or bends.
• Make sure that the drain filter is not clogged. Clean the filter, if
necessary. Refer to "Care and cleaning".
• Make sure that the connection of the drain hose is correct.
• Set the drain programme if you set a programme without drain
phase.
• Set the drain programme if you set an option which ends with
water in the tub.
• Make sure that the door is properly closed.
Page 39
• The programme was not finished properly or the appliance
Internal fail. No com‐
munication between
electronic elements of
stopped too early. Switch the appliance off and on again.
• If the alarm code appears again, contact the Authorised Serv‐
ice Centre.
the appliance.
• Disconnect the appliance and close the water tap. Contact the
The anti-flood device
Authorised Service Centre.
is on.
If the display shows other alarm codes, deactivate and activate the
appliance. If the problem continues, contact the Authorised Service
Centre.
In case of different problem with the washing machine check the
table below for possible solutions.
Problem Possible solution
• Make sure that the mains plug is connected to the mains
socket.
• Make sure that the appliance door is closed.
The programme does
not start.
• Make sure that there is no damaged fuse in the fuse box.
• Make sure that the Avvio/Pausa has been touched.
• If the delay start is set, cancel the setting or wait for the end of
countdown.
• Deactivate the Child Lock function if it is on.
• Check the position of the knob on the selected programme.
The appliance fills with
water and drains im‐
mediately.
The spin phase does
not operate or the
washing cycle lasts
longer than usual.
• Make sure that the drain hose is in the correct position. The
hose may be positioned too low. Refer to "Installation instruc‐
tion".
• Set the spin programme.
• Make sure that the drain filter is not clogged. Clean the filter, if
necessary. Refer to "Care and cleaning".
• Adjust manually the items in the tub and start the spin phase
again. This problem may be caused by balance problems.
• Make sure that the couplings of the water hoses are tight and
there is not water leakages.
There is water on the
floor.
• Make sure that the water inlet hose and the drain hose have
no damages.
• Make sure you use the correct detergent and the correct
quantity of it.
ENGLISH 39
Page 40
www.aeg.com40
Problem Possible solution
• Make sure that a washing programme that ends with water in
tub, has not been selected.
• Make sure that the washing programme is finished.
• Set the drain or the spin programme if there is water in the
You cannot open the
appliance door.
The appliance makes
an unusual noise and
vibrates.
The programme dura‐
tion increases or de‐
creases during pro‐
gramme execution.
The washing results
are not satisfactory.
Too much foam in the
drum during the wash‐
ing cycle.
After the washing cy‐
cle, there are some
detergent residues in
the dispenser drawer.
drum.
• Make sure that the appliance receives electrical power.
• This problem may be caused by a failure of the appliance.
Contact the Authorised Service Centre.
If you need to open the door, please read carefully "Emergen‐
cy door opening".
• Make sure the levelling of the appliance is correct. Refer to
"Installation instruction".
• Make sure that the packaging and/or the transit bolts are re‐
moved. Refer to "Installation instruction".
• Add more laundry in the drum. The load may be too small.
• The ProSense System is able to adjust the programme dura‐
tion according to the type and the laundry load size. Refer to
"The ProSense System load detection" in "Daily Use" chapter.
• Increase the detergent quantity or use a different detergent.
• Use special products to remove the stubborn stains before
you wash the laundry.
• Make sure that you set the correct temperature.
• Decrease the laundry load.
• Reduce the quantity of detergent or the number of tablets or
single-dose detergents.
• Make sure you have used the detergent dispenser according
the indications given in this user manual.
• Make sure to use fresh tablets or single-dose detergents.
Store them in their box and close it after use, according to the
manufacturer's recommendations.
Direct exposure to environment can modify their characteristic
and their behaviour in the Pods® compartment, specially in
combination with certain options (e.g. Partenza Ritardata).
After the check, activate the appliance. The programme continues
from the point of interruption.
If the problem occurs again, contact the Authorised Service Centre.
The necessary data for the service centre are on the rating plate.
15.2 Emergency door opening
In case of power failure or functioning
failure the appliance door remains
locked. The washing programme
continues when the power is restored. If
the door remains locked in case of
failure, it is possible to open it using the
emergency unlock function.
Before opening the door:
Page 41
ENGLISH 41
CAUTION!
Risk of burns! Make sure
that the water temperature
is not too high and the
laundry is not hot. If
necessary, wait until they
cool down.
CAUTION!
Risk of injury! Make sure
that the drum is not
rotating. If necessary, wait
until the drum stops
rotating.
Make sure that the water
level inside the drum is
not too high. If necessary,
proceed with an
emergency drain (refer to
«Emergency drain» in
«Care and cleaning»
chapter).
To open the door, proceed as follows:
16. CONSUMPTION VALUES
16.1 Introduction
1. Press the On/Off button to switch the
appliance off.
2. Disconnect the mains plug from the
mains socket.
3. Open the filter flap.
4. Pull the emergency unlock trigger
downward once. Pull it downward
once again, keep it tensed and, in the
meanwhile, open the appliance door.
5. Take out the laundry and then close
the appliance door.
6. Close the filter flap.
See the web link www.theenergylabel.eu for
detailed information about Energy Label.
The QR code on the energy label supplied with the
appliance provides a web link to the information
related to the performance of the appliance in the
EU EPREL database. Keep the energy label for
reference together with the user manual and all
other documents provided with this appliance.
It is also possible to find the same information in
EPREL using the link https://eprel.ec.europa.eu
and the model name and product number that you
find on the rating plate of the appliance. Refer to
'Product description' chapter for the position of the
rating plate.
16.2 Legend
kg Laundry load. h:mm Programme duration.
Page 42
www.aeg.com42
kWh Energy consumption. °C Temperature in the laundry.
Litres Water consumption. rpm Spin speed.
% Remaining moisture at the end of spinning phase. The higher is the spin speed,
the higher is the noise and the lower is the remaining moisture.
Values and programme duration may differ depending on different
conditions (e.g. room temperature, water temperature and pressure, load
size and type of laundry, supply voltage) and also if you change the
default setting of a programme.
16.3 According to Commission Regulation Eu 2019/2023
Eco 40-60 pro‐
gramme
Full load 10 0.900 61 3:50 53 37 1351
Half load 5 0.605 47 2:50 53 33 1351
Quarter load 2.5 0.200 38 2:30 54 23 1351
1)
Maximum spin speed.
kg kWh Litres h:mm % °C
rpm
Power consumption in different modes
Off (W) Stand-by (W) Delay start (W)
0.50 0.50 4.00
Time to Off/Standby mode is 15 minutes maximum.
16.4 Common programmes
These values are indicative only.
Programme
2)
Cotoni
95°C
Cotoni
60°C
kg kWh Litres h:mm % °C
10 2.90 90 4:05 52 85 1400
10 1.70 85 3:50 52 55 1400
rpm
1)
1)
Page 43
ENGLISH 43
Programme
3)
Cotoni
20°C
Sintetici
40°C
4)
Delicati
30°C
Lana
30°C
1)
Reference indicator of the spin speed.
2)
Suitable for washing heavily soiled textiles.
3)
Suitable for washing lightly soiled cottons, synthetic and mixed fabrics.
4)
It also performs as quick washing cycle for lightly soiled laundry.
kg kWh Litres h:mm % °C
10 0.35 85 3:00 52 20 1400
4 0.80 55 2:15 35 40 1200
2 0.40 60 1:05 35 30 1200
1.5 0.30 65 1:05 30 30 1200
17. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
rpm
1)
*
Page 44
www.aeg.com/shop
157040771-A-382021
Loading...
