USER
MANUAL
L6FBK74W
EN User Manual
Washing Machine
www.aeg.com
2
CONTENTS
1. SAFETY INFORMATION.............................................................................................3
2. SAFETY INSTRUCTIONS.............................................................................................4
3. INSTALLATION............................................................................................................6
4. ACCESSORIES........................................................................................................... 10
5. PRODUCT DESCRIPTION.........................................................................................11
6. CONTROL PANEL..................................................................................................... 11
7. DIAL AND BUTTONS................................................................................................13
8. PROGRAMMES .........................................................................................................15
9. SETTINGS...................................................................................................................20
10. BEFORE FIRST USE.................................................................................................20
11. DAILY USE................................................................................................................20
12. HINTS AND TIPS..................................................................................................... 24
13. CARE AND CLEANING.......................................................................................... 26
14. TROUBLESHOOTING.............................................................................................30
15. CONSUMPTION VALUES.......................................................................................33
16. TECHNICAL DATA..................................................................................................34
17. QUICK GUIDE.........................................................................................................34
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away unless continuously supervised.
• Children of less than 3 years of age should be kept
away unless continuously supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when
the door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH
3
General Safety
1.2
• Do not change the specification of this appliance.
• This appliance is intended to be used in household
and similar applications such as:
– staff kitchen areas in shops, offices and other
working environments;
www.aeg.com4
– by clients in hotels, motels, bed & breakfast and
other residential type environments;
– areas for communal use in blocks of flats or in
launderettes.
• Do not exceed the maximum load of 7 kg (refer to the
"Programme chart" chapter).
• The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
• The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
• The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
• Old hose sets must not be reused.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
• Do not use high pressure water sprays and/or steam
to clean the appliance.
• Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2.
SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Remove all the packaging and the
transit bolts including rubber bush
with plastic spacer.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
ENGLISH
5
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
• Do not install the appliance directly
above a floor drain.
• Do not spray water on the appliance
and do not expose it to excessive
humidity.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Do not put a closed container to
collect possible water leakage under
the appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance complies with the
E.E.C. Directives.
2.3
Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes,
pipes not used for a long time, where
repair work has been carried out or
new devices fitted (water meters,
etc.), let the water flow until it is clean
and clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
Authorised Service Centre for the
replacement of the inlet hose.
• It is possible to see water flowing
from the drain hose. This is due to the
testing of the appliance with the use
of water in the factory.
• You can extend the drain hose to
maximum 400 cm. Contact the
Authorised Service Centre for the
other drain hose and the extension.
2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Make sure that all metal objects are
removed from the laundry.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber
parts of the washing machine.
Prewash such fabrics by hand before
loading them into the washing
machine.
• Do not touch the glass door while a
programme is in operation. The glass
can get hot.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
www.aeg.com6
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Unpacking
WARNING!
Remove all the packaging
and the transit bolts before
installing the appliance.
WARNING!
Use the gloves.
1. Use a cutter to cut through external
film.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
4.
Open the door and remove the
polystyrene piece from the door seal
and all the items from the drum.
2. Remove the external film.
3. Remove the cardboard top and the
polystyrene packaging materials.
5. Put the front polystyrene packaging
element on the floor behind the
appliance.
6. Carefully put down the appliance
with the rear side on it.
Make sure not to
damage the hoses.
1
2
ENGLISH
7
7. Remove the polystyrene protection
from the bottom.
8. Pull up the appliance in vertical
position.
9. Remove the power supply cable and
the drain hose from the hose holders.
It is possible to see
water flowing from the
drain hose. This is due to
the testing with water of
the appliance in factory.
10. Remove the three bolts and pull out
the plastic spacers.
11. Put the plastic caps, that you find in
the user manual bag, in the holes.
We recommend that you
keep the packaging and the
transit bolts for any
movement of the appliance.
3.2 Positioning and levelling
1. Install the appliance on a flat hard
floor.
Make sure that carpets do
not stop the air circulation
below the appliance.
Make sure that the
appliance does not touch
the wall or other units.
2. Loosen or tighten the feet to adjust
the level.
x4
20O20
O
45O45
O
8
www.aeg.com
WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
The appliance must be level and stable.
A correct adjustment of the
appliance level prevents the
vibration, noise and the
movement of the appliance
when in operation.
When the machine is
installed on a plinth or if a
washer dryer is stacked on
the washing machine, use
the accessories described in
chapter 'Accessories'. Read
carefully the instructions
supplied with the appliance
and with the accessory.
2. Position it toward left or right
depending on the position of the
water tap.
Make sure that the inlet hose
is not in vertical position.
3. If necessary, loose the ring nut to set
it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4" thread.
CAUTION!
Make sure that there are no
leaks from the couplings.
Do not use an extension
hose if the inlet hose is too
short. Contact the service
centre for the replacement
of the inlet hose.
3.3 The inlet hose
1. Connect the water inlet hose to the
back of the appliance.
3.4 Water drainage
The drain hose should be positioned at a
height of not less than 60 cm and not
more than 100 cm from the floor.
You can extend the drain
hose to maximum 400 cm.
Contact the authorized
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose
guide.
2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the plastic
guide cannot move when
the appliance drains.
ENGLISH 9
The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm min. 1.5") must be larger
than the external diameter
of the drain hose.
4. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
Make sure that the drain
hose end is not immersed in
the water. There may be a
return of dirty water into the
appliance.
3. To a stand pipe with vent-hole -
Insert the drain hose directly into a
drain pipe. Refer to the illustration.
5. Without the plastic hose guide, to
a sink spigot - Put the drain hose in
the spigot and tighten it with a
clamp. Refer to the illustration.
Make sure that the drain
hose makes a loop to
prevent particles going into
the appliance from the sink.
www.aeg.com10
6. Position the hose directly to a builtin drain pipe in the room wall and
tighten it with a clamp.
4. ACCESSORIES
4.1 Available in
www.aeg.com/shop or from
authorised dealer
Only appropriate
accessories approved by
AEG ensure the safety
standards of the appliance. If
unapproved parts are used,
any claims will be
invalidated.
4.2 Fixing plate kit
(4055171146)
Available from your authorised dealer.
If you install the appliance on a plinth,
secure the appliance in the fixing plates.
Read carefully the instructions supplied
with the accessory.
4.3 Stacking kit
The tumble dryer can be stacked on the
top of the washing machine only by
using the correct stacking kit
manufactured and approved by AEG.
Verify the compatible
stacking kit by checking the
depth of your appliances.
The stacking kit can be used only with
the appliances specified in the leaflet
provided with the accessory.
Read carefully the instructions supplied
with the appliance and with the
accessory.
WARNING!
Do not put the tumble dryer
under the washing machine.
5. PRODUCT DESCRIPTION
1 2 3
9
5
6
7
4
10
8
11 12
ENGLISH 11
5.1 Special features
Your new washing machine meets all
modern requirements for an effective
treatment of laundry with low water,
energy and detergent consumption and
respectful of fabric care.
5.2 Appliance overview
• The ProSense technology adjusts
automatically the programme
duration to the laundry in the drum to
achieve perfect washing results in the
minimum possible time.
Worktop
1
Detergent dispenser
2
Control panel
3
Door handle
4
Rating plate
5
Drain pump filter
6
Feet for levelling the appliance
7
6. CONTROL PANEL
6.1 Control panel description
Drain hose
8
Inlet hose connection
9
Mains cable
10
Transit bolts
11
Hose support
12
7
8
9
1 2 3
5
4
6
A
B
ED
C
www.aeg.com12
Aan /Uit - Marche/Arrêt touch button
1
Programme dial
2
Display
3
Startuitstel - Départ Différé touch
4
button
Tijd Besparen - Gain de Temps touch
5
button
Start/Pauze - Départ/Pause touch
6
button
7
Extra - Option touch button
• Vlekken - Taches option
• Voorwas - Prélavage option
Centrifugeren - Essorage reduction
8
touch button
9
Temp. touch button
6.2 Display
A The digital indicator can show:
B Extra rinse indicator. It lights on when this option is se-
C
D Child safety lock indicator.
E Door locked indicator.
7. DIAL AND BUTTONS
ENGLISH
• Programme duration (e. g. ).
• Delay time (e. g. or ).
• Cycle end ( ).
• Warning code ( ).
lected .
The indicator blink during the laundry load detections.
13
7.1 Programme dial
For selecting the desired washing
programme. Refer to 'Programmes'
chapter for more details.
The position is a "Reset" function,
which stops and resets the running
programme. When the selector is in this
position, display shows
that no programme was selected.
. It indicates
7.2 Aan /Uit - Marche/Arrêt
Pressing this button for a few seconds
allows to activate or deactivate the
appliance. Two different tunes sound
while switching the appliance on or off.
As the Stand-by function automatically
deactivates the appliance to decrease
the energy consumption in a few cases,
you may need to activate the appliance
again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
7.3 Introduction
The options/functions are
not selectable with all
washing programmes. Check
the compatibility between
options/functions and
washing programmes in the
"Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set the incompatible
options/functions together.
Make sure the screen and
touch buttons are always
clean and dry.
7.4 Temp.
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Set this option to change the default
temperature.
The indicator = cold water of the set
temperature comes on (the appliance
does not heat the water).
14
www.aeg.com
7.5 Centrifugeren - Essorage
When you set a programme, the
appliance automatically sets the
maximum spin speed allowed.
Touch repeatedly this button to:
Decrease the spin speed
Activate the Spülstopp option
• Set this option to prevent the laundry
creases.
• The related indicator comes on.
• There is a water in the drum when the
programme is completed.
• The door stays locked and the drum
turns regularly to reduce creasing.
• You must drain the water to unlock
the door.
• If you touch the Start/Pauze - Départ/
Pause button, the appliance performs
the spinning phase and drains the
water.
The appliance empties the
water out automatically after
18 hours approximately.
Activate the Ohne Schleudern option
• Set this option to deactivate all spin
phases. Only the drain phase is
available.
• The related indicator comes on.
• Set this option for very delicate
fabrics.
• The rinses phase uses more water for
some washing programmes.
The spin speed can be
reduce.
7.6 Extra - Option
Press this button repeatedly to activate
one of the available options.
• Vlekken - Taches
Select this option to add an anti-stain
phase to a programme in order to
treat heavily soiled or stained laundry
with stain remover.
Pour the stain remover into
compartment . The stain remover will
be added in the appropriate phase of
the washing programme.
This option can increase
the programme duration.
This option is not
available with a
temperature lower than
40 °C.
• Voorwas - Prélavage
Use this option to add a prewash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
containing sand, dust, mud and other
solid particles.
This option can increase
the programme duration.
The relevant indicator comes on.
7.7 Startuitstel - Départ Différé
With this option you can delay the start
of a programme in a more convenient
time.
Touch repeatedly the button to set the
required delay. The time increases by
steps of 30 minutes up to 90' and from 2
hours up to 20 h.
The indicator of the option and the
indicator of the set value are on. After
touching theStart/Pauze - Départ/Pause
button the appliance begins the
countdown.
7.8 Tijd Besparen - Gain de Temps
This option may be advisable to shorten
the washing programme.
Use this option for items with normal or
light soil or items to refresh.
Touch this button once to decrease the
duration.
In case of smaller load, touch this button
twice to set an extra quick programme.
The indicator of the option and the
indicator of the set value are on.
7.9 Start/Pauze - Départ/Pause
Touch the Start/Pauze - Départ/Pause
button to start, pause the appliance or
interrupt a running programme.
8. PROGRAMMES
8.1 Programme Chart
Washing programmes
Programme Programme description
Washing programmes
Katoen - Coton
Katoen Eco - Coton Eco
ENGLISH 15
White and coloured cotton heavily and normally soiled cotton
items.
White and coloured cotton heavily and normally soiled cotton
items.
Standard programmes for the Energy Label consumption
values. According to regulation 1061/2010, the programme
Katoen - Coton at 60 °C and the programme Katoen - Coton at
40 °C with the option are respectively the «Standard 60°C
cotton programme» and the «Standard 40°C cotton programme». They are the most efficient programmes in terms of
combined energy and water consumption for washing normally
soiled cotton laundry.
The water temperature of the washing phase
may differ from the temperature declared for
the selected programme.
Synthetica - Synthétiques
Strijkvrij - Repassage facile
Fijne Was - Délicats
Wol/Zijde - Laine/Soie
Synthetic items or mixed fabric items. Normal soil.
Synthetic items requiring a gentle wash. Normal and light
1)
soil.
Delicate fabrics such as acrylics, viscose and mixed fabrics
requiring gentler washing. Normal soil.
Machine washable wool, hand washable wool and other
fabrics with «hand washing» care symbol2).
www.aeg.com16
Programme Programme description
Maintenance cycle with hot water to clean and freshen the
Machine Clean - Lavage
tambour
drum and to remove residue that may cause odour. For the
best result use this cycle once a month. Before running this cycle, remove all items from the drum. In the washing phase
compartment of the detergent dispenser, put the flap of the
compartment in upward position. Pour a cup of chlorine bleach
or a washing machine cleaner in the washing phase compartment. DO NOT use both together.
After the drum cleaning, run a further rinse cycle with empty drum and no detergent to remove any residue of bleach.
To spin the laundry and to drain the water in the drum. All fab-
Centr./Pompen - Essorage/Vidange
Spoelen - Rinçage
Anti-allergie
Jeans
Sport
rics, except woollens and delicate fabrics.
All fabrics, except woollens and very delicate fabrics. Pro-
gramme for rinsing and spinning the laundry. The default spin
speed is the one used for cotton programmes. Reduce the
spin speed accordingly to the type of laundry. If necessary, set
the Spoelen+ Rinçage+ option to add rinses. With a low spin
speed the appliance performs delicate rinses and a short spin.
White cotton items. This programme removes micro-organisms thanks to a washing phase with the temperature maintained above 60°C for several minutes. This helps remove
germs, bacteria, micro-organism and particles. An additional
rinsing phase ensures a proper removal of detergent residues
and pollens/allergenic items. In this way the wash is more effective.
Denim clothing and jersey items. Normal soil. This programme performs a gentle rinsing phase, designed for denim,
that reduces fading and does not cause washing powder residues on the fibres.
Mixed fabric sportswear like polyester, polyester, elastane
blends, polyamide. A cycle for outdoor sport clothes normal
soiled
Katoen 20° - Coton 20°
Mixed fabric (cotton and synthetic items)3).
ENGLISH 17
Programme Programme description
Cotton and synthetic items lightly soiled or once worn.
20 min. - 3 kg
1)
To reduce creasing, this cycle regulates the water temperature and performs a soft wash and spin
phase. The appliance adds some rinses.
2)
During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
3)
This programme is for daily use and has the lowest energy and water consumption whilst maintaining
a good washing performance.
Programme temperature, maximum spin speed and maximum load
Programme Default tempera-
ture
Temperature
Reference spin
speed
Spin speed range
Maximum load
range
Washing programmes
Katoen - Coton
Katoen Eco - Coton Eco
Synthetica - Synthétiques
Strijkvrij - Repassage facile
Fijne Was - Délicats
Wol/Zijde - Laine/Soie
Machine Clean - Lavage
tambour
Centr./Pompen - Essorage/Vidange
1)
Spoelen - Rinçage
40 °C
95 °C - Cold
40 °C
60 °C - 40 °C
40 °C
60 °C - Cold
40 °C
60 °C - Cold
30 °C
40 °C - Cold
40 °C
40 °C - Cold
60 °C
1400 rpm
1400 rpm - 800 rpm
1400 rpm
1400 rpm - 800 rpm
1200 rpm
1200 rpm - 800 rpm
800 rpm
800 rpm - 800 rpm
1200 rpm
1200 rpm - 800 rpm
1200 rpm
1200 rpm - 800 rpm
1200 rpm
1200 rpm - 800 rpm
1400 rpm
1400 rpm - 800 rpm
1400 rpm
1400 rpm - 800 rpm
7 kg
7 kg
3 kg
2 kg
3 kg
1,5 kg
-
7 kg
7 kg
www.aeg.com18
Programme Default tempera-
ture
Temperature
Reference spin
speed
Spin speed range
Maximum load
range
Anti-allergie
60 °C
40 °C
Jeans
60 °C - Cold
30 °C
Sport
Katoen 20° - Coton 20°
40 °C - Cold
Cold
30 °C
20 min. - 3 kg
1)
Set the spin speed. Make sure it is suitable for the type of fabric being washed. If you set the No Spin
option then only the drain phase is available.
40 °C - 30 °C
1400 rpm
1400 rpm - 800 rpm
1200 rpm
1200 rpm - 800 rpm
1200 rpm
1200 rpm - 800 rpm
1400 rpm
1400 rpm - 800 rpm
1200 rpm
1200 rpm - 800 rpm
7 kg
7 kg
3 kg
7 kg
3 kg
Programme options compatibility
2)
1)
Spülstopp
Ohne Schleudern
Voorwas - Prélavage
Vlekken - Taches
Centrifugeren - Essorage
Programme
Tijd Besparen - Gain de Temps
Katoen - Coton ■ ■ ■ ■ ■ ■ ■ ■
Katoen Eco - Coton
Eco
Synthetica - Synthétiques
Strijkvrij - Repassage
facile
■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■
Fijne Was - Délicats ■ ■ ■ ■ ■ ■
Startuitstel - Départ Différé
Programme
Wol/Zijde - Laine/Soie
ENGLISH 19
2)
1)
Spülstopp
Ohne Schleudern
Voorwas - Prélavage
Vlekken - Taches
Centrifugeren - Essorage
Tijd Besparen - Gain de Temps
■ ■ ■ ■
Startuitstel - Départ Différé
Machine Clean - Lavage tambour
Centr./Pompen - Essorage/Vidange
■ ■ ■
■ ■ ■
Spoelen - Rinçage ■ ■ ■
Anti-allergie ■ ■ ■ ■ ■ ■ ■
Jeans ■ ■ ■ ■ ■ ■ ■ ■
Sport ■ ■ ■ ■ ■ ■
Katoen 20° - Coton
20°
■ ■ ■ ■ ■ ■ ■
20 min. - 3 kg ■ ■ ■
1)
This option is not available with temperature lower than 40 °C.
2)
If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully
load the appliance, however the washing results can be less satisfactory.
8.2 Woolmark Apparel Care - Blue
The wool wash cycle of this machine has been
approved by The Woolmark Company for the
washing of wool garments labelled as «hand
wash» provided that the garments are washed according to the instructions issued by the
manufacturer of this washing machine. Follow
the garment care label for drying and other
laundry instructions. M1511
The Woolmark symbol is a Certification mark
in many countries.
www.aeg.com20
9. SETTINGS
9.1 Child Lock
With this option you can prevent children
from playing with the control panel.
• To activate/deactivate this option,
touch the Centrifugeren - Essorage
and the Extra - Option buttons
simultaneously until the indicator
comes on/goes off on the display.
You can activate this option:
• After you touch the Start/Pauze -
Départ/Pause button: all the buttons
and the programme dial are
deactivated (except Aan /Uit Marche/Arrêt button ).
• Before you touch the Start/Pauze -
Départ/Pause button: the appliance
cannot start.
The appliance keeps the selection of this
option after you switch it off.
9.2 Acoustic signals
The acoustic signals operate when the
programme is completed (sequence of
sounds for about 2 minutes).
10. BEFORE FIRST USE
1. Make sure that all transit bolts have
been removed from the appliance.
2. Make sure that the electrical power is
available and the water tap is open.
3. Pour a small quantity of detergent
To deactivate/activate the acoustic
signals, touch the Startuitstel - Départ
Différé and the Tijd Besparen - Gain de
Temps buttons simultaneously for about
6 seconds.
If you deactivate the
acoustic signals, they
continue operate when the
appliance has a malfunction.
9.3 Permanent Extra Rinse
With this option you can permanently
have an extra rinse when you set a new
programme.
• To activate/deactivate this option
touch the Temp. button and the
Centrifugeren - Essorage button
simultaneously until relevant indicator
comes on/goes off on display.
4. Set and start a programme for cotton
at the highest temperature without
any laundry in the drum.
This removes all possible dirt from the
drum and the tub.
into the compartment marked .
11. DAILY USE
WARNING!
Refer to Safety chapters.
11.1 Activating the appliance
1. Connect the mains plug to the mains
socket.
2. Open the water tap.
3. Press the Aan /Uit - Marche/Arrêt
button for a few seconds to activate
the appliance.
A short tune sounds.
11.2 Loading the laundry
1. Open the appliance door.
2. Shake the items before you put them
in the appliance.
3. Put the laundry in the drum, one item
at a time.
Make sure not to put too much laundry
in the drum.
4. Close the door firmly.
2
1
ENGLISH
Always follow the
instructions that you find on
the packaging of the
detergent products, but we
recommend that you do not
exceed the maximum
indicated level ( ). This
quantity will however
guarantee the best washing
results.
21
CAUTION!
Make sure that no laundry
stays between the seal and
the door. There is a risk of
water leakage or damage to
the laundry.
11.3 Filling the detergent and additives
Compartment for prewash phase,
soak programme or stain remover.
Compartment for washing phase.
Compartment for liquid additives
(fabric conditioner, starch).
Maximum level for quantity of liquid
additives.
Flap for powder or liquid detergent.
After a washing cycle, if
necessary, remove any
detergent residue from the
detergent dispenser.
11.4 Check the position of the flap
1. Pull out the detergent dispenser until
it stops.
2. Press the lever down to remove the
dispenser.
3. To use powder detergent, turn the
flap up.
22
www.aeg.com
4. To use liquid detergent, turn the flap
down.
With the flap in the
position DOWN:
• Do not use
gelatinous or thick
liquid detergents.
• Do not put more
liquid detergent than
the limit shown on
the flap.
• Do not set the
prewash phase.
• Do not set the delay
start function.
5. Measure out the detergent and the
fabric conditioner.
6. Carefully close the detergent
dispenser.
The display shows an indicative
programme duration.
2. If necessary, change the
temperature, the spin speed, the
cycle duration, or add available
options. When you activate an
option, the indicator of the set
option comes on.
In case a selection is not
possible, no indicator
comes on and an
acoustic signal sounds.
11.6 Starting a programme with the delay start
Touch the Start/Pauze - Départ/Pause
button.
The appliance starts the countdown of
the delay start.
When the countdown is completed, the
programme starts.
The PROSENSE adapts
starts at the end of the
countdown.
Cancelling the delay start after the countdown has started
To cancel the delay start:
1. Touch the Start/Pauze - Départ/
Pause button to pause the appliance.
The related indicator flashes.
2. Touch the Startuitstel - Départ
Différé button repeatedly until the
display shows .
3. Touch the Start/Pauze - Départ/
Pause button again to start the
programme immediately.
Make sure that the flap does not cause a
blockage when you close the drawer.
11.5 Setting a programme
1. Turn the programme knob to set the
washing programme.
The indicator of the Start/Pauze Départ/Pause button flashes.
Changing the delay start after the countdown has started
To change the delay start:
1. Touch the Start/Pauze - Départ/
Pause button to pause the appliance.
The related indicator flashes.
2. Touch the Startuitstel - Départ
Différé button repeatedly until the
display shows the desired delay time.
3. Touch the Start/Pauze - Départ/
Pause button again to start the new
countdown.
ENGLISH
23
11.7 Starting a programme
Touch the Start/Pauze - Départ/Pause
button to start the programme.
The related indicator stops flashing and
stays on.
The programme starts, the door is
locked. The display shows the indicator
.
The drain pump can operate
shortly before the appliance
fills water.
11.8 The ProSense load detection
After touching the Start/Pauze - Départ/
Pause button the ProSense technology
starts the laundry load detection:
1. The appliance detects the load
within a few minutes, the indicator
blink, the drum rotates shortly.
2. At the end of the load detection, the
indicator goes off .
About 20 minutes after the
programme start, the
programme duration could
be adjusted depending on
the capacity of water
absorption of the fabrics.
11.10
Cancelling a running
programme
1. Press the button Aan /Uit - Marche/
Arrêt to cancel the programme and
to deactivate the appliance.
2. Press the button Aan /Uit - Marche/
Arrêt again to activate the appliance.
Now, you can set a new washing
programme.
If the ProSense phase is
already carried out and the
water filling is already
started, the new programme
starts without repeating
the ProSense phase. The
water and the detergent are
not drained out in order to
avoid waste.
There is also an alternative way of
cancelling:
1. Rotate the selector knob to the
"Reset" position
2. Wait for 1 second. The display shows
.
Now, you can set a new washing
programme.
.
11.11 Opening the door Adding garments
The ProSense detection is
carried out with complete
washing programmes only
(no skipping phase
selected).
11.9 Interrupting a programme and changing the options
When the programme is running, you
can change only some options:
1. Touch the button Start/Pauze -
Départ/Pause.
The related indicator flashes.
2. Change the options. The given
information in the display changes
accordingly.
3. Touch the button Start/Pauze -
Départ/Pause again.
The washing programme continues.
While a programme or the delay start
operates, the appliance door is locked.
If the temperature and level
of the water in the drum are
too high and/or the drum
still rotates you cannot open
the door.
1. Touch the button Start/Pauze -
Départ/Pause.
In the display the related door lock
indicator goes off.
2. Open the appliance door. If
necessary, add or remove the items.
3. Close the door and touch the button
Start/Pauze - Départ/Pause.
The programme or the delay start
continues.
4. The door can be opened when the
programme is complete, or set
www.aeg.com24
Centr./Pompen - Essorage/Vidange
programme and than press Start/
Pauze - Départ/Pause button.
11.12 End of the programme
When the programme has finished, the
appliance stops automatically. The
acoustic signals operate (if they are
active).
In the display all washing phase
indicators become steady and the time
area shows .
The indicator of the Start/Pauze -
Départ/Pause button goes off.
The door unlocks and the indicator
goes off.
1. Press the Aan /Uit - Marche/Arrêt
button to deactivate the appliance.
After five minutes from the end of the
programme, the energy saving function
automatically deactivates the appliance.
When you activate the
appliance again, the display
show the end of the last set
programme. Turn the
programme knob to set a
new cycle.
2. Remove the laundry from the
appliance.
3. Make sure that the drum is empty.
4. Keep the door and the detergent
dispenser slightly ajar to prevent
mildew and odours.
5. Close the water tap.
11.13 Draining water out after
end of cycle
If you have chosen a programme or an
option that does not empty out the
water of the last rinse, the programme is
completed, but:
• The display shows the door locked
indicator
• The drum still turns at regular intervals
to prevent the creases in the laundry.
• The door stays locked.
• You must drain the water to open the
door:
1. If necessary, touch the Centrifugeren
- Essorage button to decrease the
spin speed proposed by the
appliance.
2. Press Start/Pauze - Départ/Pause to
continue the cycle
3. When the programme is completed
and the door locked indicator
goes off, you can open the door.
4. Press the Aan /Uit - Marche/Arrêt
button a few seconds to deactivate
the appliance.
In any case, the appliance
empties the water out
automatically after
approximately 18 hours.
11.14 Stand-by option
The Stand-by function automatically
deactivates the appliance to decrease
the energy consumption when:
• You do not use the appliance for 5
minutes before you touch the Start/
Pauze - Départ/Pause button.
Press the button Aan /Uit - Marche/
Arrêt to activate the appliance again.
• After 5 minutes from the end of the
washing programme
Press the Aan /Uit - Marche/Arrêt
button to activate the appliance
again.
The display shows the end of the last
set programme.
Turn the programme dial to set a new
cycle.
If you set a programme or an
option that ends with water
in the drum, the Stand-by
function doesn't deactivate
the appliance to remind you
to drain the water.
12. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
ENGLISH
25
12.1 The laundry load
• Divide the laundry into: white,
coloured, synthetics, delicates and
wool.
• Follow the washing instructions on the
laundry care labels.
• Do not wash white and coloured
items together.
• Some coloured items can discolour
with the first wash. We recommend
that you wash them separately for the
first couple of times.
• Button up pillowcases, close zippers,
hooks and poppers. Tie up belts.
• Empty pockets and unfold.
• Turn multilayered fabrics, wool and
items with printed illustrations inside
out.
• Pre-treat tough stains.
• Wash heavy soil stains with a special
detergent.
• Be careful with curtains. Remove the
hooks and put the curtains in a
washing bag or pillowcase.
• Do not wash laundry without hems or
with cuts.
• Use a washing bag to wash small
and/or delicate items (e.g. underwired
bras, belts, tights, etc. ).
• A very small load can cause balance
problems with the spin phase leading
to excessive vibration. If this occurs:
a. interrupt the programme and
open the door (refer to "Daily
Use" chapter);
b. manually redistribute the load so
that the items are spaced evenly
around the tub;
c. press the Start/Pauze - Départ/
Pause button. The spin phase
continues.
12.2 Stubborn stains
For some stains, water and detergent is
not sufficient.
We recommend that you pre-treat these
stains before you put the items in the
appliance.
Special stain removers are available. Use
the special stain remover that is
applicable to the type of stain and fabric.
12.3 Detergents and other treatments
• Only use detergents and other
treatments specially made for
washing machines:
– powder detergents for all types of
fabric, excluding delicate. Prefer
powder detergents containing
bleach for whites and laundry
sanitization
– liquid detergents, preferably for
low temperature wash
programmes (60 °C max) for all
types of fabric, or special ones for
woollens only.
• Do not mix different types of
detergents.
• To help the environment, do not use
more than the recommended quantity
of detergent.
• Follow the instructions that you find
on packaging of the detergents or
other treatments without exceeding
the indicated maximum level ( ).
• Use the recommended detergents for
the type and colour of the fabric, the
programme temperature and the
level of soil.
12.4 Ecological hints
• Set a programme without the
prewash phase to wash laundry with
normal soil.
• Always start a washing programme
with the maximum load of laundry
allowed.
• If you pre-treat the stains or use a
stain remover, set a programme with
a low temperature.
• To use the correct quantity of
detergent, check the water hardness
of your domestic system. Refer to
"Water hardness".
12.5 Water hardness
If the water hardness in your area is high
or moderate, we recommend that you
additive for water softening. In areas
where the water hardness is soft it is not
necessary to use him.
To find out the water hardness in your
area, contact your local water authority.
26
www.aeg.com
Use the correct quantity of additive for
water softening. Follow the instructions
13. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
13.1 External cleaning
Clean the appliance with mild soap and
warm water only. Fully dry all the
surfaces.
CAUTION!
Do not use alcohol, solvents
or chemical products.
CAUTION!
Do not clean the metal
surfaces with chlorine-based
detergent.
13.2 Descaling
If the water hardness in your
area is high or moderate, we
recommend that you use a
water descaling product for
washing machines.
Regularly examine the drum to check for
limescale.
The regular detergents already contain
water softening agents, but we
recommend to run a cycle with empty
drum and a descaling product
occasionally.
Always follow the
instructions that you find on
the packaging of the
product.
that you find on the packaging of the
product.
of powder detergent into empty
drum, in order to rinse out any left
residues.
13.4 Door seal
Regularly examine the seal and remove
all objects from the inner part.
13.5 Cleaning the drum
Regularly examine the drum to prevent
rust particles.
For a complete cleaning:
1. Clean the drum with special products
for stainless steel.
Always follow the
instructions that you find on
the packaging of the
product.
2. Run a short cotton programme at
high temperature or use if is available
programme Machine Clean - Lavage
tambour. Add a small quantity of
powder detergent into empty drum,
in order to rinse out any left residues.
13.3 Maintenance wash
With the low temperature programmes it
is possible that some detergent stays in
the drum. Perform a maintenance wash
regularly. To do this:
• Remove all laundry from the drum.
• Select the cotton programme with the
highest temperature or use if is
available programme Machine Clean Lavage tambour. Add a small quantity
13.6 Cleaning the detergent dispenser
To prevent possible deposits of dried
detergent or clotted fabric softener
and/or formation of mould in the
detergent dispenser drawer, once in a
while carry out the following cleaning
procedure:
1. Open the drawer. Press the catch
2
1
downwards as indicated in the
picture and pull it out.
ENGLISH
13.7 Cleaning the drain pump
27
2. Remove the top part of the additive
compartment to aid cleaning and
flush it out under running warm
water, to remove any traces of
accumulated detergent. After
cleaning, replace the top part in its
position.
3. Make sure that all detergent residue
is removed from the upper and lower
part of the recess. Use a small brush
to clean the recess.
WARNING!
Disconnect the mains plug
from the mains socket.
Regularly check the drain
pump filter and make sure
that it is clean.
Clean the drain pump if:
• The appliance does not drain the
water.
• The drum does not turn.
• The appliance makes an unusual
noise because of the blockage of the
drain pump.
• The display shows the alarm code
.
WARNING!
• Do not remove the filter
while the appliance
operates.
• Do not clean the pump if
the water in the
appliance is hot. Wait
until the water cools
down
Proceed as follows to clean the pump:
1. Open the pump cover.
4. Insert the detergent drawer into the
guide rails and close it. Run the
rinsing programme without any
clothes in the drum.
1
2
180˚
2
1
28
www.aeg.com
2. Place a suitable bowl below the drain
pump access to collect the water that
flows out.
3. Open the chute downwards. Always
keep a rag nearby to dry up any
water spillages when removing the
filter.
4. Turn the filter 180 degrees in anti-
clockwise direction to open it,
without removing. Let the water flow
out.
8. If it is necessary, remove fluff and
objects from the filter recess.
9. Make sure that the impeller of the
pump can rotate. If it does not
rotate, contact the Authorised
Service Centre.
10. Clean the filter under the water tap.
5. When the bowl is full of water, turn
the filter back and empty the
container.
6. Repeat the steps 4 and 5 until the
water stops to flow out.
7. Turn the filter anti-clockwise to
remove it.
11. Put the filter back into the special
guides by turning it clockwise. Make
sure that you tighten the filter
correctly to prevent leakages.
2
1
2
1
1
1
2
3
45°
20°
ENGLISH
29
12. Close the pump cover.
13.8 Cleaning the inlet hose
and the valve filter
It is recommended to clean both the
filters of the inlet hose and valve
occasionally to remove any deposit,
collected over the time:
1. Remove the inlet hose from the tap
and clean the filter.
3. Clean the valve filter on the back of
the appliance with a toothbrush.
4. When you reconnect the hose to the
back of the appliance, turn it left or
right (not in vertical position)
depending on the position of your
water tap.
13.9 Emergency drain
If the appliance cannot drain the water,
2. Remove the inlet hose from the
appliance by loosening the ring nut.
carry out the same procedure, described
in 'Cleaning the drain pump' paragraph.
If necessary, clean the pump.
13.10 Frost precautions
If the appliance is installed in an area
where the temperature can reach the
www.aeg.com30
values around 0° C or drop below,
remove the remaining water from the
inlet hose and the drain pump.
1. Disconnect the mains plug from the
mains socket.
2. Close the water tap.
3. Put the two ends of the inlet hose in
a container and let the water flow out
of the hose.
4. Empty the drain pump. Refer to the
emergency drain procedure.
14. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
14.1 Introduction
The appliance does not start or it stops
during operation.
First try to find a solution to the problem
(refer to the "Possible failures" table). If
the problem persists, contact the
Authorised Service Centre.
In case of major problems, the acoustic
signals operate, the display shows an
alarm code and the Start/Pauze -
Départ/Pause button may flash
continuously:
• - The appliance does not fill with
water properly. After the proper
check, start the appliance again by
pressing Start/Pauze - Départ/Pause
button. If the error persist the alarm
code will appear again.
• - The appliance does not drain
the water.
•
- The appliance door is open or
not closed correctly. Please check the
door!
If the appliance is
overloaded, remove
some items from the
drum and/or keep
pressed the door while
touching the Start/Pauze
- Départ/Pause button
until the indicator
stops flashing (see the
picture below).
5. When the drain pump is empty,
install the inlet hose again.
WARNING!
Make sure that the
temperature is higher than 0
°C before you use the
appliance again.
The manufacturer is not
responsible for damages
caused by low temperatures.
•
• - No communication between
•
- The mains supply is unstable.
Wait until the mains supply is stable.
electronic elements of the appliance.
Switch the appliance off and switch it
on again. If the alarm code appears
again, contact the Authorised Service
Centre.
- The anti-flood device is on.
Disconnect the appliance and close
the water tap. Contact the Authorised
Service Centre.
WARNING!
Deactivate the appliance
before carrying out any
check.
14.2 Possible failures
Problem Possible solution
• Make sure that the mains plug is connected to the mains
socket.
• Make sure that the appliance door is closed.
The programme does
not start.
The appliance does not
fill with water properly.
The appliance fills with
water and drains immediately
The appliance does not
drain the water.
The spin phase does not
operate or the washing
cycle lasts longer than
usual.
There is water on the
floor.
• Make sure that there is no damaged fuse in the fuse box.
• Make sure that the Start/Pauze - Départ/Pause has been
touched.
• If the delay start is set, cancel the setting or wait for the end
of countdown.
• Deactivate the Child Lock function if it is on.
• Make sure that the water tap is open.
• Make sure that the pressure of the water supply is not too
low. For this information, contact your local water authority.
• Make sure that the water tap is not clogged.
• Make sure that the inlet hose has no kinks, damages or
bends.
• Make sure that the connection of the water inlet hose is
correct.
• Make sure that the filter of the inlet hose and the filter of
the valve are not clogged. Refer to 'Care and cleaning'.
• Make sure that the drain hose is in the correct position. The
hose may be positioned too low. Refer to "Installation instruction".
• Make sure that the sink spigot is not clogged.
• Make sure that the drain hose has no kinks or bends.
• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Refer to "Care and cleaning".
• Make sure that the connection of the drain hose is correct.
• Set the drain programme if you set a programme without
drain phase.
• Set the drain programme if you set an option which ends
with water in the tub.
• Set the spin programme.
• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Refer to "Care and cleaning".
• Adjust manually the items in the tub and start the spin
phase again. This problem may be caused by balance problems.
• Make sure that the couplings of the water hoses are tight
and there is not water leakages.
• Make sure that the water inlet hose and the drain hose have
no damages.
• Make sure you use the correct detergent and the correct
quantity of it.
ENGLISH 31
www.aeg.com32
Problem Possible solution
• Make sure that a washing programme that ends with water
in tub, has been selected.
• Make sure that the washing programme is finished.
You cannot open the appliance door.
• Set the drain or the spin programme if there is water in the
drum.
• Make sure that the appliance receives electrical power.
• This problem may be caused by a failure of the appliance.
Contact the Authorised Service Centre.
• Make sure the levelling of the appliance is correct. Refer to
The appliance makes an
unusual noise and vibrates.
"Installation instruction".
• Make sure that the packaging and/or the transit bolts are
removed. Refer to "Installation instruction".
• Add more laundry in the drum. The load may be too small.
The programme duration
increases or decreases
during programme execution.
• The ProSense function is able to adjust the programme duration according to the type and the laundry load size. Refer to "The ProSense load detection" in "Daily Use" chapter.
• Increase the detergent quantity or use a different detergent.
The washing results are
not satisfactory.
• Use special products to remove the stubborn stains before
you wash the laundry.
• Make sure that you set the correct temperature.
• Decrease the laundry load.
Too much foam in the
• Reduce the quantity of detergent.
drum during the washing
cycle.
After the washing cycle,
there are some detergent residues in the dispenser drawer.
• Make sure that the flap is in the correct position (UP for
powder detergent - DOWN for liquid detergent).
• Make sure you have used the detergent dispenser according the indications given in this user manual.
After the check, activate the appliance. The programme continues from the point of
interruption.
If the problem occurs again, contact the Authorised Service Centre.
If the display shows other alarm codes. Deactivate and activate the appliance. If the
problem continues, contact the Authorised Service Centre.
15. CONSUMPTION VALUES
Stated values are obtained in laboratory conditions with relevant standards. Different causes can change the data: the quantity and type of
laundry and ambient temperature. Water pressure, the supply voltage
and the temperature of inlet water may also affect the washing programme duration.
Technical specifications may be changed without prior notice to improve
the quality of product.
During the washing programme, the Prosense technology can vary the
wash duration and the consumption values. For more details see 'The
Prosense load detection' paragraph in 'Daily Use' chapter.
ENGLISH 33
Programmes Load
(kg)
Katoen - Coton 60°C 7 1,3 68 210 52
Katoen - Coton 40°C 7 1,12 61 205 52
Synthetica - Synthétiques
40°C
Fijne Was - Délicats 40°C 3 0,55 59 95 35
Wol/Zijde - Laine/Soie 30°C 1,5 0,45 62 75 30
Standard cotton programmes
Standard 60°C cotton
Standard 60°C cotton
Standard 40°C cotton
1)
At the end of spin phase.
Off Mode (W) Left On Mode (W)
0.30 0.30
The information given in the chart above is compliant with the EU Commission regulation
1015/2010 implementing directive 2009/125/EC .
Energy
consumption (kWh)
3 0,60 56 140 35
7 0,73 45 269 52
3,5 0,49 34 222 52
3,5 0,49 34 224 52
Water
consumption (litre)
Approximate programme
duration
(minutes)
Remaining mois-
ture (%)
1)
1
2
1
2
3
www.aeg.com34
16. TECHNICAL DATA
Dimension Width/ Height/ Depth/
Electrical connection Voltage
Level of protection against ingress of solid particles
and moisture ensured by the protective cover, except where the low voltage equipment has no protection against moisture
Water supply pressure Minimum
Water supply
Maximum Load Cotton 7 kg
Energy Efficiency Class A+++ -20%
Spin Speed Maximum 1400 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
1)
17. QUICK GUIDE
17.1 Daily use
Connect the mains plug to the mains
socket.
Open the water tap.
Total depth
Overall power
Fuse
Frequency
Maximum
600 mm/ 850 mm/ 547 mm/ 600 mm
230 V
2200 W
10 A
50 Hz
IPX4
0,5 bar (0,05 MPa)
8 bar (0,8 MPa)
Cold water
Load the laundry.
Pour the detergent and other treatment
in the proper compartment of the
detergent dispenser.
1. Push the Aan /Uit - Marche/Arrêt
button to turn the appliance on. Turn
the programme dial to set the
desired programme.
2. Set the desired options (1) by means
of the corresponding touch buttons.
To start the programme, touch the
Start/Pauze - Départ/Pause (2)
button.
3. The appliance starts.
At the end of the programme, remove
the laundry.
Push the Aan /Uit - Marche/Arrêt
button to turn the appliance off.
17.2 Cleaning the drain pump filter
2
1 32
Clean the filter regularly and, especially,
if the alarm code appears on the
display.
17.3 Programmes
Programmes Load Product description
ENGLISH 35
Katoen - Coton
Katoen Eco - Coton Eco
Synthetica - Synthétiques
Strijkvrij - Repassage
facile
Fijne Was - Délicats
Wol/Zijde - Laine/Soie
Machine Clean - Lavage
tambour
Centr./Pompen - Essorage/Vidange
Spoelen - Rinçage
Anti-allergie
Jeans
7 kg White cotton and coloured cotton.
White cotton and coloured cotton. Standard
7 kg
3 kg Synthetic items or mixed fabric items.
2 kg
3 kg
1,5 kg
7 kg
7 kg
7 kg
7 kg Denim clothing and jersey items.
programmes for the Energy Label consumption
values.
Synthetic items requiring a gentle wash. Normal and light soil.
Delicate fabrics such as acrylics, viscose, polyester items.
Machine washable wool, hand washable wool
and delicates.
- Maintenance cycle for drum cleaning.
All fabrics, except woollens and very delicate
fabrics. Programme for spinning and draining
the water.
All fabrics, except woollens and very delicate
fabrics. Programme for rinsing and spinning.
White cotton items. This programme helps to
remove germs and bacteria.
1)
Sport
3 kg Sportswear.
36
www.aeg.com
Programmes Load Product description
Katoen 20° - Coton 20°
7 kg White cotton and coloured cotton.
20 min. - 3 kg
1)
To reduce creasing, this cycle regulates the water temperature and performs a soft wash and spin
phase. The appliance adds some rinses.
3 kg
Synthetic and mixed fabric. Lightly soiled items
and garments to freshen up.
18. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
ENGLISH 37
www.aeg.com38
ENGLISH 39
www.aeg.com/shop
192932660-A-262018
Loading...
