LAVAMAT 14950
User manual |
Washer-dryer |
2 Contents
Thank you for choosing one of our high-quality products.
To ensure optimal and regular performance of your appliance please read this instruction manual carefully. It will enable you to navigate all processes perfectly and most efficiently. To refer to this manual any time you need to, we recommend you to keep it in a safe place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
Contents
Operating instructions |
3 |
Safety information |
3 |
General safety |
3 |
Installation |
4 |
Use |
4 |
Child safety |
5 |
Product description |
5 |
Detergent dispenser drawer |
6 |
Control panel |
6 |
Display |
7 |
First use |
9 |
Personalization |
9 |
Acoustic signals |
9 |
Child safety lock |
9 |
Daily use |
9 |
Load the laundry |
9 |
Washing Only |
10 |
Measure out the detergent and the fabric |
|
softener |
10 |
Select the required programme by turning |
|
the programme selector dial (1) |
10 |
Select the spin speed, NIGHT CYCLE or RINSE |
|
HOLD option (button 2) |
11 |
Programme option buttons |
11 |
PREWASH option |
12 |
STAIN option |
12 |
SENSITIVE option |
12 |
DAILY option |
12 |
SUPER QUICK option |
12 |
EXTRA RINSE option (additional rinse) |
12 |
Select the START/PAUSE (button 7) |
13 |
Select the DELAY START (button 8) |
13 |
Altering an option or a running programme 13 14 14
Opening the door after the programme has
started |
14 |
|
At the end of the programme |
14 |
|
Use - Drying |
15 |
|
Drying only |
15 |
|
Automatic washing and drying (NON-STOP |
||
programme) |
16 |
|
Washing programmes |
17 |
|
Drying Programmes |
20 |
|
Automatic Programmes |
20 |
|
Timed Programmes |
20 |
|
Helpful hints and tips |
21 |
|
Sorting out the laundry |
21 |
|
Temperatures |
21 |
|
Before loading the laundry |
21 |
|
Maximum loads |
21 |
|
Laundry weights |
21 |
|
Removing stains |
22 |
|
Detergents and additives |
22 |
|
Degrees of water hardness |
23 |
|
Drying Hints |
23 |
|
Preparing the drying cycle |
23 |
|
Laundry not suitable for drying |
23 |
|
Garment labels |
24 |
|
Drying cycle duration |
24 |
|
Additional drying |
24 |
|
Care and cleaning |
24 |
|
Descaling |
24 |
|
After each wash |
25 |
|
Maintenance wash |
25 |
|
External cleaning |
25 |
|
Detergent dispenser drawer |
25 |
|
Washing drum |
25 |
|
Door seal |
26 |
|
Drain pump |
26 |
|
Cleaning the water inlet filters |
28 |
|
Frost precautions |
29 |
|
|
|
|
|
Safety information |
3 |
|
|
|
|
|
|
|
|
|
Emergency emptying out |
29 |
|
Water inlet |
0 |
|
What to do if… |
29 |
|
Water-stop device |
0 |
|
|
|
|
|
|
Water drainage |
0 |
|
Technical data |
33 |
|
||||
|
In the interest of the environment |
0 |
|
|||
|
|
|
|
|
||
Consumption values |
33 |
|
||||
|
Electrical connection |
0 |
|
|||
|
|
|
|
|
|
|
Installation instructions |
0 |
|
|
|
|
|
|
Environment concerns |
0 |
|
|||
|
|
|
|
|
|
|
Installation |
0 |
|
|
|
|
|
|
Packaging materials |
0 |
|
|||
|
Unpacking |
0 |
|
Ecological hints |
0 |
|
|
Positioning and levelling |
0 |
|
|
|
|
Subject to change without notice
Operating instructions
Safety information
Read carefully & keep for future reference.
•The safety of Your appliance complies with the industry standards and with legal requirements on the safety of appliances. However, as manufacturers, we feel it is our duty to provide the following safety notes.
•It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings.
•You MUST read them carefully before installing or using the appliance.
•Before first starting up, check the appliance for any damage incurred during transport. Never connect up a damaged appliance . If parts are damaged, contact your supplier.
•If the appliance is delivered in the winter months when there are minus temperatures. Store it at room temperature for 24 hours before using for the first time.
General safety
|
• |
It is dangerous to alter the specifications or attempt to modify this product in any way. |
|
|
• |
During high temperature wash programmes the door glass may get hot. Do not touch |
|
|
|
it! |
|
|
• |
Make sure that small pets do not climb into the drum. To avoid this, please check into |
|
052010 |
• |
the drum before using. |
|
material can cause extensive damage and must not be placed into the machine. |
|||
|
Any objects such as coins, safety pins, nails, screws, stones or any other hard, sharp |
||
- |
• |
Only use the advised quantities of fabric softener and detergent. Damage to the fabric |
|
- 00 |
|
can ensue if you over-fill. Refer to the manufacturer’s recommendations of quantities. |
|
780 |
• Wash small items such as socks, laces, washable belts etc in a washing bag or pillow case |
||
|
as it is possible for such items to slip down between the tub and the inner drum. |
||
953 |
|
||
• |
Do not use your washing machine to wash articles with whalebones, material without |
||
132 |
|||
|
hems or torn material. |
4Safety information
•Always unplug the appliance and turn off the water supply after use, cleaning and maintenance.
•Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced people may cause injury or serious malfunctioning. Contact your local Service Centre. Always insist on genuine spare parts.
Installation
•This appliance is heavy. Care should be taken when moving it.
•When unpacking the appliance, check that it is not damaged. If in doubt, do not use it and contact the Service Centre.
•All packing and transit bolts must be removed before use. Serious damage can occur to the product and to property if this is not adhered to. See relevant section in the user manual.
•After having installed the appliance, check that it is not standing on the inlet and drain hose and the worktop is not pressing the electrical supply cable against the wall.
•If the machine is situated on a carpeted floor, please adjust the feet in order to allow air to circulate freely under the appliance.
•Always be sure, that there is no water leakage from hoses and their connections after the installation.
•If the appliance is installed in a location subject to frost, please read the “dangers of freezing” chapter.
•Any plumbing work required to install this appliance should be carried out by a qualified plumber or competent person.
•Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
Use
•This appliance is designed for domestic use. It must not be used for purposes other than those for which it was designed.
•Only wash and dry fabrics which are designed to be machine washed or dried. Follow the instructions on each garment label
•Do not overload the appliance. See the Washing Programme Table.
•Before washing, ensure that all pockets are empty and buttons and zips are fastened. Avoid washing frayed or torn articles and treat stains such as paint, ink, rust, and grass before washing. Underwired bras must NOT be machine washed.
•Garments which have been in contact with volatile petroleum products should not be machine washed. If volatile cleaning fluids are used, care should be taken to ensure that the fluid is removed from the garment before placing in the machine.
•As some duvets and eiderdowns should be washed/dried in large commercial machines because of their bulk, please check with the manufacturer of the item before washing in a domestic machine.
•The users should always check that they have not left their gas lighters (disposable or otherwise) in their clothing.
•Never tumble dry items that have had contact with chemicals such as dry cleaning fluid. These are of a volatile nature and could cause an explosion. Only tumble dry items which have been washed in water or require airing.
Product description |
5 |
|
|
•Plastic detergent dispensers should not remain in the drum during the drying cycle, as the plastic used is not designed to withstand the heat. If you wish to wash-through-to- dry you should use the conventional detergent dispenser drawer.
•Never pull the power supply cable to remove the plug from the socket; always take hold of the plug itself.
•Never use your new appliance if the power supply cable, the control panel, the working surface or the base are damaged so that the inside of the appliance is accessible.
Child safety
•This appliance is not intended for use by person (including children) with reduced physical sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•The packaging components (e.g. plastic film, polystyrene) can be dangerous to children - danger of suffocation! Keep them out of children’s reach.
•Keep all detergents in a safe place out of children’s reach.
•Make sure that children or pets do not climb into the drum. To prevent children and pets becoming trapped inside the drum the machine incorporates a special feature. To activate this device, rotate the button (without pressing it) inside the door clockwise until the groove is horizontal. If necessary use a coin.
To disable this device and restore the possibility of closing the door, rotate the button counterclockwise until the groove is vertical.
Product description
Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption.
The NEW JET system allows total use of detergent and reduces water consumption so saving energy.
6 Control panel
2
1
3
4
5
6
1Detergent dispenser drawer
2Control panel
3Door opening handle
4Rating plate
5Drain pump
6Adjustable feet
Detergent dispenser drawer
Compartment for prewash phase or stain re-
mover. The prewash detergent is added at the beginning
of the wash programme.
The stain remover is added during the STAIN-Ac- tion phase in the main wash.
Compartment for powder or liquid detergent used for main wash .
Compartment for liquid additives (fabric softener, starch).
Follow the product manufacturer’s recommendations on quantities to use and do not exceed the «MAX» mark in the detergent dispenser drawer. Any fabric softener or starching additives must be poured into the compartment before starting the wash programme.
Control panel
Below is a picture of the control panel. It shows the programme selector dial as well as the buttons and the display. These are presented by relevant numbers on the following pages.
7
1 |
7 |
8 |
1Programme selector dial
2SPIN reduction button
3AUTODRY button
4DRYING TIME button
5OPTION button
6OK button
7START/PAUSE button
8DELAY START button
9Display
Symbols on the control panel
= Handwash
Display
9.1 |
|
9.2 |
|
9.3 |
|
9.4 |
9.9 |
9.8 |
9.5 |
|
9.6 |
|
9.7 |
9.1- Spin Speed indicator, RINSE HOLD , NIGHT CYCLE
- symbols
9.2- Drying degree indicator, allowed by the set programme: IRON DRY , CUPBOARD DRY
and EXTRA DRY
- symbols, selectable by pressing the button 3 ; indicator AUTO, connected to the drying programme and to button 4 .
8
9.3 - Programme progress indicator: PREWASH , MAIN WASH
, RINSE
, SPIN
, OVERDOSAGE
, EXTRA RINSE
, DRYING
, DRYING ANTI-CREASE phase
- symbols,
The programme progress display shows the washing or drying phases of the selected programme. During a cycle, a black line blinks under the phase symbol of the running programme. At the end of each phase, the line under the corresponding symbol becomes fixed.
If the OVERDOSAGE symbol lights up at the end of the programme, it indicates that too much detergent has been used.
9.4 - DOOR |
- symbol (Door locked) |
•This symbol indicates if the door can be opened:
–the symbol is on: the door cannot be opened. The appliance is performing a washing or drying programme.
–the symbol is off: the door can be opened. The washing programme or drying is finished.
9.5- Options: PREWASH , STAIN
, SENSITIVE
, DAILY
, SUPER QUICK
- symbols
9.6- CHILD SAFETY LOCK - symbol
9.7- The display shows the following information:
•Duration of the selected programme
After selecting a programme, the duration is displayed in hours and minutes (for example
) . The duration is calculated automatically on the basis of the maximum recommended load for each type of fabric. After the programme has started, the time remaining is updated every minute.
•Delay start
The selected delay (20 hours max) set by pressing the relevant button appears on the
display for a few seconds (for example), then the duration of the previously selected programme is displayed.
The DELAY START symbol will appear on the display. The delay time value decreases by one unit every hour and then, when 1 hour remains, the time decreases every minute.
•Selected drying time
After selecting a drying programme, the drying time is displayed in minutes and/or hours (max 250 mins).
After the programme has started , the time remaining id updated every minutes.
•Incorrect option selection
If an option, which is not compatible with the set wash programme is selected, the message Err is displayed for a few seconds and the yellow light of button 7 starts blinking.
•Alarm codes
In the event of operating problems, some alarm codes can be displayed, for example (see chapter «What to do if...»).
•End of the programme
When the programme has finished a blinking zero is displayed, the DOOR symbol disappears and the door can be opened.
9.8- DRYING TIME duration - symbol
9.9- DELAY START - symbol
First use |
9 |
|
|
First use
• Ensure that the electrical and water connections comply with the installation instructions.
•Remove the polystyrene block and any material from the drum.
•Before the first wash, run a cotton cycle at the highest temperature without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the main wash compartment and start the machine.
Personalization
Acoustic signals
The machine is provided with an acoustic device, which sounds in the following cases:
•at the end of the cycle
•in the event of operating problems.
By pressing the 3 and 4 buttons simultaneously for about 6 seconds, the acoustic signal is deactivated (except for the events of operating problems). By pressing these two buttons again, the acoustic signal is reactivated.
Child safety lock
This device permits you to leave the appliance unattended and not to worry that children might be injured by or cause damage to the appliance.
This function remains able also when the washing machine is not working. There are two different ways to set this option:
•Before pressing button 7 : it will be impossible to start the machine.
•after pressing button 7 : it will be impossible to change any other programme or option. To enable or disable this option press simultaneously for about 6 seconds buttons 4 and 5 until the symbol 9.6 appears or disappears on or from the display.
Daily use
Load the laundry
1.Open the door by carefully pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible.
2.Close the door firmly. You must hear a click during closing.
WARNING!
Do not embed the laundry between the door and the rubber joint.
10 Daily use
Washing Only
Measure out the detergent and the fabric softener
Your new appliance was designed to reduce water, energy and detergent consumption.
1.Pull out the dispenser drawer until it stops. Measure out the amount of detergent required, pour it into the main wash compartment and, if you wish to carry
out the prewash phase or to perform the stain function, pour the detergent or the stain remover into the compartment marked .
2.If required, pour fabric softener into the compartment marked (the amount
used must not exceed the MAX mark in the drawer). Close the drawer gently.
Select the required programme by turning the programme selector dial (1)
You can choose the right programme for any type of laundry following the descriptions on the washing programme tables (see «Washing Programmes»).
Turn the programme selector dial to the required programme. The programme selector determines the type of washing cycle (e.g. water level, drum movement, number of rinses) and the washing temperature according to the type of laundry.
By selecting a programme, the programme progress indicator symbols and the symbol corresponding to the drying degree allowed by the set programme appear on the display. The pilot light of button 7 starts blinking and the display shows the duration of the selected programme.
The selector dial can be turned either clockwise or anticlockwise.
Position corresponds to a cold wash, the position
to Reset programme/ Switching OFF of the machine.
At the end of the programme the selector dial must be turned to position , to switch the machine off.
Daily use 11
If you turn the programme selector dial to another programme when the machine is working, the yellow pilot light of button 7 will blink 3 times and the message Err is displayed on the display to indicate a wrong selection. The machine will not perform the new selected programme.
Select the spin speed, NIGHT CYCLE or RINSE HOLD option (button 2)
When the required programme has been selected, your appliance automatically proposes the maximum spin speed provided for that programme.
Press this button repeatedly to change the spin speed, if you want your laundry to be spun at a speed different from the one proposed by the washer-dryer.
RINSE HOLD: by selecting this option the water of the last rinse is not emptied out to prevent the fabrics from creasing. At the end of the programme, a blinking and the RINSE HOLD symbol appear on the display, the DOOR symbol (door locked) remains lit and the pilot light of button 7 goes off. The door is locked to indicate that the water must be emptied out.
NIGHT CYCLE: by selecting this option, the machine will not drain the water of the last rinse, so as not to wrinkle the laundry. As all spinning phases are suppressed, this washing cycle is very quiet and it can be selected at night or in times with a more economical power rate. In some programmes the rinses will be performed with more water. At the end of the programme, a blinking and the RINSE HOLD symbol appear on the display, the DOOR symbol remains lit and the pilot light of button 7 goes off. The door is locked to indicate that the water must be emptied out.
RINSE HOLD or NIGHT CYCLE option cannot be selected with a NON-STOP programme (see Drying section).
To empty out the water, please read chapter «At the end of the programme».
Programme option buttons
Depending on the programme, different functions can be combined.
WARNING!
Not all the options are compatible among themselves. The symbols of the incompatible options disappear.
Anyway, if an option, which is not compatible with the set washing programme or any other option, is selected, the Err message is displayed for few seconds and the yellow pilot of button 7 light starts blinking.
You must select the options after you have selected the programme but before pressing the button 7 . Press the button 5 : all the option symbols appear on the display.
To scroll all the available options, press the button 5 . The corresponding symbol appears on the display and starts blinking.
Press the button 6 to activate and confirm your choice. A black dash appears under the selected symbol to indicate that this option has been set. Press the same button to deactivate the option.
12 Daily use
After selecting the options, wait a few seconds until the display gets back to the default status. The selected options appear on the display.
For the compatibility among the options and the washing programmes see chapter «Washing Programmes».
PREWASH option
Select this option if you wish your laundry to be prewashed at 30°C before the main wash. The Prewash ends with a short spin in programmes for cotton and synthetic fabrics, whereas in the programmes for delicate fabrics the water is only drained.
The relevant symbol will appear on the display.
This option is recommended for heavily soiled laundry.
STAIN option
Select this option to treat heavily soiled or stained laundry with stain remover (extended main wash with time optimized stain action phase). The relevant symbol will appear on the display.
This option is not available with a temperature lower than 40°C.
If you wish to perform a programme with the stain option, pour stain remover into stain compartment .
SENSITIVE option
By selecting this option the washing intensity will be reduced. The machine adds one rinse in the programmes for cottons and synthetics. The relevant symbol will appear on the display.
This option cannot be selected together with Extra Rinse option.
This option is recommended for non fast coloured items and for frequently washed items.
DAILY option
By selecting this option, you will be able to modify the washing duration to wash daily soiled laundry.
The display will show the corresponding symbol and the reduced washing time. To be used for daily soiled laundry.
SUPER QUICK option
By selecting this option, it will be possible to reduce the washing duration to wash lightly soiled laundry.
The display will show the corresponding symbol and the reduced washing time. To be used for very lightly soiled laundry only. We recommend that you reduce the laundry load.
EXTRA RINSE option (additional rinse)
This appliance is designed for saving water. However, for people with a very delicate skin (allergic to detergents) it may be necessary to rinse the laundry using an extra quantity of water (extra rinse). The relevant symbol will appear on the display and this option is active for selected washing programme.
If you wish to activate this option permanently press simultaneously buttons 2 and 3 for a few seconds: the relevant symbol appears on the display. If you wish to cancel it press the same buttons until the symbol disappears.
Daily use 13
Select the START/PAUSE (button 7)
To start the selected programme, press the button 7 , the corresponding red pilot light stops blinking.
The DOOR symbol appears on the display to indicate that the appliance has started operating and the door is locked.
To interrupt a programme which is running, press the button 7 : the corresponding red pilot light starts blinking.
To restart the programme from the point at which it was interrupted, press the button 7 again. If you have chosen a delayed start the machine will begin the countdown.
If an incorrect option is selected, the yellow pilot light of the button 7 blinks 3 times and the message Err is displayed for a few seconds.
Select the DELAY START (button 8)
The corresponding symbol will appear on the display. The wash programme can be delayed from 30 min - 60 min - 90 min, 2 hours and then by 1 hour up to a maximum of 20 hours by means of this button.
Before you start the programme , if you wish to delay the start, press this button repeatedly, to select the desired delay.
The delay time value will appear on the display for about 3 seconds, then the duration of the programme will appear again. The selected symbol appears on the display.
You must select this option after you have set the programme and before you press the button 7 .
You can modify or cancel the delay time at any moment, before you press the button 7 . The door will be locked throughout the delay time. If you wish to add laundry in the machine during the delay time, press the button 7 to set the machine to pause. When the Door symbol disappears, the door can be opened. Add the laundry, close the door and press the button 7 again.
Selecting the delayed start.
•Select the programme and the required options.
•Select the delay start.
•Press button 7 : the appliance starts its hourly countdown. The programme will start
after the selected delay has expired. Cancelling the delayed start
•Set the washing machine to PAUSE by pressing the button 7 ;
•Press button 8 until the symbol ’ is displayed;
•Press the button 7 again to start the programme.
The selected delay can be changed only after selecting the washing programme again.
The Delay Start can not be selected with the draining programme.
Altering an option or a running programme
It is possible to change some options before the programme carries it out. Before you make any change, you must pause the washing machine by pressing the button 7 .
Changing a running programme is possible only by resetting it . Turn the programme
selector dial to and then to the new programme position. Start the new programme by pressing the 7 button again. The washing water in the tub will not emptied out.
14
Interrupting a programme
Press the button 7 to interrupt a programme which is running, the corresponding light starts blinking. Press the button again to restart the programme.
Cancelling a programme
Turn the selector dial to to cancel a programme which is running. Now you can select a new programme.
Opening the door after the programme has started
When the machine is working and through the delay time, the door is locked. If, for any reason, it is necessary to open it, set firstly the machine to pause by pressing the button
7 .
•If the DOOR symbol disappears from the display, the door can be opened.
•If the DOOR symbol stays on, and the door remains locked, this means that the machine
is already heating or that the water level is too high. In this case the door can not be opened.
If you cannot open the door but you need to open it you have to switch the machine off by turning the selector dial to . After a few minutes the door can be opened (pay attention to the water level and temperature !) .
After closing the door, it is necessary to select the programme and options again and to press button 7 .
At the end of the programme
The machine stops automatically. The pilot light of button 7 goes off and a blinking appears on the display. The acoustic signal sounds for a few minutes.
If you have chosen a programme or an option that ends with water left in the tub, follow the below instruction to empty the water out:
•turn the programme selector dial to
•select the draining or spinning programme
•reduce the spin speed if needed, by pressing the relevant button
•press the button 7
•when the programme has finished the display shows a blinking . On the display the DOOR symbol disappears. The door can now be opened.
Turn the programme selector dial to to switch the machine off. Remove the laundry from the drum and carefully check that the drum is empty.
If you do not intend to carry out another wash, close the water tap. Leave the door open to prevent the formation of mildew and unpleasant smells.
Stand by : once the programme has finished after a few minutes the energy saving system will be enabled. The brightness of the display is reduced. By pressing any button the appliance will come out of the energy saving status.
