Aeg IAE64851FB, 949 597 568 User Manual

USER
MANUAL

IAE64851FB

EN User Manual

Hob

www.aeg.com2

CONTENTS

1. SAFETY INFORMATION......................................................................................3

2. CONDITIONS OF USE......................................................................................... 5

3. SAFETY INSTRUCTIONS.................................................................................... 5

4. INSTALLATION.....................................................................................................7

5. PRODUCT DESCRIPTION...................................................................................8

6. QUICK GUIDE...................................................................................................... 9

7. BEFORE FIRST USE..........................................................................................11

8. DAILY USE......................................................................................................... 11

9. FLEXIBLE INDUCTION COOKING AREA..........................................................16

10. HINTS AND TIPS..............................................................................................18

11. CARE AND CLEANING.................................................................................... 21

12. TROUBLESHOOTING......................................................................................21

13. TECHNICAL DATA........................................................................................... 24

14. ENERGY EFFICIENCY.....................................................................................25

15. WARRANTY .....................................................................................................26

IMPORTANT INFORMATION THAT MAY IMPACT
YOUR MANUFACTURER'S WARRANTY

Adherence to the directions for use in this manual is extremely important for
health and safety. Failure to strictly adhere to the requirements in this manual
may result in personal injury, property damage and affect your ability to make a
claim under the AEG manufacturer’s warranty provided with your product.
Products must be used, installed and operated in accordance with this manual.
You may not be able to claim on the AEG manufacturer’s warranty in the event
that your product fault is due to failure to adhere to this manual.

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com

Register your product for better service:

www.registeraeg.com

CUSTOMER CARE AND SERVICE

Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.

1.1 Children and vulnerable people safety

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.

• Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.

• Children of less than 3 years of age should be kept

away from the appliance unless continuously
supervised.

• Do not let children play with the appliance.

• Keep all packaging away from children and dispose of

it appropriately.

• WARNING: Keep children and pets away from the

appliance when it operates or when it cools down.
Accessible parts become hot during use.

• If the appliance has a child safety device, it should be

activated.

• Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

ENGLISH 3

www.aeg.com4

1.2 General Safety

• WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to avoid
touching heating elements.

• WARNING: Unattended cooking on a hob with fat or

oil can be dangerous and may result in fire.

• NEVER try to extinguish a fire with water, but switch

off the appliance and then cover flame e.g. with a lid
or a fire blanket.

• CAUTION: The appliance must not be supplied

through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.

• CAUTION: The cooking process has to be supervised.

A short term cooking process has to be supervised
continuously.

• WARNING: Danger of fire: Do not store items on the

cooking surfaces.

• Metallic objects such as knives, forks, spoons and lids

should not be placed on the hob surface since they
can get hot.

• Do not use the appliance before installing it in the

built-in structure.

• Do not use a steam cleaner to clean the appliance.

• After use, switch off the hob element by its control and

do not rely on the pan detector.

• If the glass ceramic surface / glass surface is cracked,

switch off the appliance and unplug it from the mains.
In case the appliance is connected to the mains
directly using junction box, remove the fuse to
disconnect the appliance from power supply. In either
case contact the Authorised Service Centre.

• If the supply cord is damaged, it must be replaced by

the manufacturer, an authorized Service or similarly
qualified persons in order to avoid a hazard.

• WARNING: Use only hob guards designed by the

manufacturer of the cooking appliance or indicated by

the manufacturer of the appliance in the instructions
for use as suitable or hob guards incorporated in the
appliance. The use of inappropriate guards can cause
accidents.

2. CONDITIONS OF USE

ENGLISH 5

This appliance is intended to be used in
household and similar applications such
as:

• Farm houses

3. SAFETY INSTRUCTIONS

3.1 Installation

WARNING!

Only a qualified person must
install this appliance.

WARNING!

Risk of injury or damage to
the appliance.

• Remove all the packaging.

• Do not install or use a damaged
appliance.

• Follow the installation instructions
supplied with the appliance.

• Keep the minimum distance from
other appliances and units.

• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.

• Seal the cut surfaces with a sealant to
prevent moisture from causing
swelling.

• Protect the bottom of the appliance
from steam and moisture.

• Do not install the appliance next to a
door or under a window. This
prevents hot cookware from falling
from the appliance when the door or
the window is opened.

• Each appliance has cooling fans on
the bottom.

• If the appliance is installed above a
drawer:

– Do not store any small pieces or

sheets of paper that could be
pulled in, as they can damage the
cooling fans or impair the cooling
system.

• By clients in serviced apartments,
holiday apartments and other
residential type environments.

– Keep a distance of minimum 2 cm

between the bottom of the
appliance and parts stored in the
drawer.

• Remove any separator panels
installed in the cabinet below the
appliance.

3.2 Electrical Connection

WARNING!

Risk of fire and electric
shock.

• All electrical connections should be
made by a qualified electrician.

• The appliance must be earthed.

• Before carrying out any operation
make sure that the appliance is
disconnected from the power supply.

• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.

• Make sure the appliance is installed
correctly. Loose and incorrect
electricity mains cable or plug (if
applicable) can make the terminal
become too hot.

• Use the correct electricity mains
cable.

• Do not let the electricity mains cable
tangle.

• Make sure that a shock protection is
installed.

• Use the strain relief clamp on the
cable.

• Make sure the mains cable or plug (if
applicable) does not touch the hot

www.aeg.com6

appliance or hot cookware, when you
connect the appliance to the near
sockets.

• Do not use multi-plug adapters and
extension cables.

• Make sure not to cause damage to
the mains plug (if applicable) or to the
mains cable. Contact our Authorised
Service Centre or an electrician to
change a damaged mains cable.

• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.

• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.

• If the mains socket is loose, do not
connect the mains plug.

• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.

• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.

• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.

3.3 Use

WARNING!

Risk of injury, burns and
electric shock.

• Remove all the packaging, labelling
and protective film (if applicable)
before first use.

• This appliance is for household use
only.

• Do not change the specification of this
appliance.

• Make sure that the ventilation
openings are not blocked.

• Do not let the appliance stay
unattended during operation.

• Set the cooking zone to “off” after
each use.

• Do not rely on the pan detector.

• Do not put cutlery or saucepan lids on
the cooking zones. They can become
hot.

• Do not operate the appliance with wet
hands or when it has contact with
water.

• Do not use the appliance as a work
surface or as a storage surface.

• If the surface of the appliance is
cracked, disconnect immediately the
appliance from the power supply. This
to prevent an electrical shock.

• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.

• When you place food into hot oil, it
may splash.

WARNING!

Risk of fire and explosion

• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and
oils when you cook with them.

• The vapours that very hot oil releases
can cause spontaneous combustion.

• Used oil, that can contain food
remnants, can cause fire at a lower
temperature than oil used for the first
time.

• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.

WARNING!

Risk of damage to the
appliance.

• Do not keep hot cookware on the
control panel.

• Do not put a hot pan cover on the
glass surface of the hob.

• Do not let cookware boil dry.

• Be careful not to let objects or
cookware fall on the appliance. The
surface can be damaged.

• Do not activate the cooking zones
with empty cookware or without
cookware.

• Do not put aluminium foil on the
appliance.

• Cookware made of cast iron,
aluminium or with a damaged bottom
can cause scratches on the glass /
glass ceramic. Always lift these

min.
50mm

min.
500mm

ENGLISH 7

objects up when you have to move
them on the cooking surface.

• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.

3.4 Care and cleaning

• Clean the appliance regularly to
prevent the deterioration of the
surface material.

• Switch off the appliance and let it cool
down before cleaning.

• Do not use water spray and steam to
clean the appliance.

• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.

3.5 Service

• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.

4. INSTALLATION

WARNING!

Refer to Safety chapters.

• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.

3.6 Disposal

WARNING!

Risk of injury or suffocation.

• Contact your municipal authority for
information on how to discard the
appliance correctly.

• Disconnect the appliance from the
mains supply.

• Cut off the mains electrical cable
close to the appliance and dispose of
it.

4.4 Assembly

4.1 Before the installation

Before you install the hob, write down the
information below from the rating plate.
The rating plate is on the bottom of the
hob.

Serial number ...........................

4.2 Built-in hobs

Only use the built-in hobs after you
assemble the hob into correct built-in
units and work surfaces that align to the
standards.

4.3 Connection cable

• The hob is supplied with a connection
cable.

min. 12min.

60

min.
28

www.youtube.com/electrolux
www.youtube.com/aeg

How to install your AEG

Induction Hob - Worktop installation

1

2

1

3

1

32

4

5 6 7 8

10 911

12

www.aeg.com8

5. PRODUCT DESCRIPTION

5.1 Cooking surface layout

If the appliance is installed
above a drawer, the hob
ventilation can warm up the
items stored in the drawer
during the cooking process.

Induction cooking zone

1

Control panel

2

Flexible induction cooking area

3

consisting of four sections

5.2 Control panel layout

To see the available settings touch the appropriate symbol.

Symbol Comment

1

ENGLISH 9

ON / OFF To activate and deactivate the hob.

2

3

- Zone indicator To show for which zone the slider is active.

4

5

- Slider To adjust the heat setting.

6

7

8

9

10

0 - 9 - To show the current heat setting.

11

12

Menu To open and close the Menu.

Zone selection To open the slider for the selected zone.

- To set the timer functions.

PowerBoost To activate the function.

Lock To activate and deactivate the function.

- The window of the Hob²Hood infrared signal com‐

Pause To activate and deactivate the function.

FlexiBridge To switch between three modes of the function.

5.3 OptiHeat Control(3 step

Residual heat indicator)

WARNING!
III / II / I There is a risk of

burns from residual heat.
The indicator shows the
level of the residual heat.

municator. Do not cover it.

The induction cooking zones produce the
heat necessary for the cooking process
directly in the bottom of the cookware.
The glass ceramic is heated by the heat
of the cookware.

6. QUICK GUIDE

6.1 Using the display

• Only the backlit symbols can be used.

• To activate a given option, touch the
relevant symbol on the display.

• The selected function is activated
when you remove the finger from the
display.

• To scroll the available options, use a
quick gesture or drag your finger
across the display. The speed of the
gesture determines how fast the
screen moves.

• The scrolling can stop by itself or you
can stop it immediately if you touch
the display.

• You can change most of the
parameters shown on the display
when you touch the relevant symbols.

• To select the required function or time
you can scroll through the list and / or
touch the option you want to choose.

• When the hob is activated and some
of the symbols disappear from the
display, touch it again. All the symbols
come back on.

• For certain functions, when you start
them, a pop-up window with additional
information appears. To deactivate
the pop-up window permanently,

www.aeg.com10

check before you activate the
function.

Symbols useful for display navigation

• Select a zone first to activate the timer
functions.

Symbols useful for display navigation

To confirm the selection or setting.

To go back / forwards one level in
the Menu.

To scroll up / down the instructions
on the display.

6.2 Menu structure

Touch to access and change the
settings of the hob or activate some
functions. The table shows the basic
Menu structure.

Menu

Assisted Cooking

Hob Functions PowerSlide

Melting

Settings Child Lock

Stopwatch

Hob²Hood H0 - Off

Setup Assisted Cooking

Service Demo Mode

To activate / deactivate the options.

To close the pop-up window.

To cancel a setting.

H1 - Light only

H2 - Fan speed low

H3 - Auto Fan Low

H4 - Auto Fan Medium

H5 - Auto Fan High

H6 - Auto Fan Boost

Language

Key Tones

Buzzer Volume

Display Brightness

License

Show Software Version

Alarm History

Reset All Settings

ENGLISH 11

To leave the Menu touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu

use or .

When you touch and hold some of the
options available in the Menu, a short

7. BEFORE FIRST USE

WARNING!

Refer to Safety chapters.

7.1 First connection to the mains

When you connect the hob to the mains
you have to set Language, Display
Brightness and Buzzer Volume.

8. DAILY USE

WARNING!

Refer to Safety chapters.

8.1 Activating and deactivating

Touch for 1 second to activate or
deactivate the hob.

description appears. Follow the tips to
easily navigate through the Menu.

If you are at the bottom of the Menu

scroll the list up and use or touch to
leave the Menu.

You can change the setting in Menu >
Settings > Setup. Refer to "Daily use".

deactivates automatically after 2
minutes.

• you do not deactivate a cooking zone
or change the heat setting. After some
time a message comes on and the
hob deactivates.

The relation between the heat setting
and the time after which the hob
deactivates:

8.2 Automatic Switch Off

The function deactivates the hob
automatically if:

• all cooking zones are deactivated,

• you do not set the heat setting after
you activate the hob,

• you spill or put something on the
control panel for more than 10
seconds (a pan, a cloth, etc.). An
acoustic signal sounds and the hob
deactivates. Remove the object or
clean the control panel.

• the hob gets too hot (e.g. when a
saucepan boils dry). Let the cooking
zone cool down before you use the
hob again.

• you use incorrect cookware or there is
no cookware on a given zone. The
white cooking zone symbol blinks and
the induction cooking zone

Heat setting The hob deacti‐

vates after

1 - 2 6 hours

3 - 5 5 hours

6 4 hours

7 - 9 1.5 hour

When you use Pan Fry the
hob deactivates after 1.5
hours. For Sous Vide the
hob deactivates after 4
hours.

8.3 Heat setting

1. Activate the hob.

2. Place the pot on the selected cooking
zone.

www.aeg.com12

The slider for the active cooking zone
appears on the display and is active for 8
seconds.

3. Touch or slide your finger to set the
desired heat setting.

The symbol turns red and becomes
bigger.

You can also change the heat setting
while cooking. Touch the zone selection
symbol on the main view of the control
panel and move you finger to the left or
right (to lower or increase the heat
setting).

8.4 Using the cooking zones

Place the cookware in the centre of the
selected cooking zone. Induction cooking
zones adapt to the dimensions of the
bottom of the cookware automatically.

Once you place a pot on the selected
cooking zone the hob automatically
detects it and the relevant slider appears
on the display. The slider is visible for 8
seconds, after that time the display goes
back to the main view. To close the slider
faster tap the screen outside of the slider
area.

When other zones are active the heat
setting for the zone you want to use may
be limited. Refer to "Power
Management".

Make sure that the pot is
suitable for induction hobs.
For more information on
cookware types refer to
"Hints and tips". Check the
size of the pot in "Technical
data".

2. Touch or slide your finger to the
right to activate the function for the
chosen cooking zone.

The symbol turns red and becomes
bigger.
The function deactivates automatically.
To deactivate the function manually
select the zone and change its heat
setting.

For maximum duration
values, refer to "Technical
data".

8.6 Power Management

• Cooking zones are grouped according

to the location and number of the
phases in the hob. See the illustration.

• Each phase has a maximum

electricity loading of 3680 W.

• The function divides the power

between cooking zones connected to
the same phase.

• The function activates when the total

electricity loading of the cooking
zones connected to a single phase
exceeds 3680 W.

• The function decreases the power of

the other cooking zones connected to
the same phase, which has an
influence on the available heat
setting.

• The maximum heat setting is visible

on the slider. Only the digits in white
are active.

• If a higher heat setting is not available

reduce it for the other cooking zones
first.

8.5 PowerBoost

This function activates more power for
the appropriate induction cooking zone; it
depends on the cookware size. The
function can be activated only for a
limited period of time.

1. Touch the desired zone symbol first.

+STOP

+STOP

ENGLISH 13

8.7 Timer

Count Down Timer

Use this function to specify how long a
cooking zone should operate during a
single cooking session.

You can set the function for each
cooking zone separately.

1. Set the heat setting for the
appropriate cooking zone first and
then set the function.

2. Touch the zone symbol.

3. Touch .

The timer menu window appears on the
display.

4. Check

The symbols change to

to activate the function.

.

5. Slide your finger to the left or right to
select the desired time (e.g. hours
and/or minutes).

6. Touch OK to confirm your selection.

You can also choose to cancel your
selection.

When the time comes to an end, a signal

sounds and blinks. Touch to stop
the signal.

To deactivate the function set the heat

setting to 0. Alternatively, touch

to

the left of the timer value, touch next
to it and confirm your choice when a pop­up window appears.

Minute Minder

You can use this function when the hob
is activated but the cooking zones do not
operate.

The function has no effect on the
operation of the cooking zones.

1. Select any cooking zone.

The relevant slider appears on the
display.

2. Touch

The timer menu window appears on the
display.

3. Slide your finger to the left or right to
select the desired time (e.g. hours
and minutes).

4. Touch OK to confirm your selection.

.

You can also choose

to cancel your
selection.

When the time comes to an end, a signal

sounds and blinks. Touch to stop
the signal.

To deactivate the function touch

to

the left of the timer value, touch next
to it and confirm your choice when a pop­up window appears.

Stopwatch

The function automatically starts
counting immediately after you activate a
cooking zone. You can use this function
to monitor how long it operates.

1. Touch to access the Menu.

2. Scroll the Menu to select Settings >

Stopwatch.

3. Touch the switch to turn the function

on / off.

The function does not stop when you lift
the pot. To reset the function and start it

again manually touch , select Reset
from the pop-up window. The function
starts counting from 0. To Pause the

function for one cooking session touch
and select Pause from the pop-up
window. Select Start to continue
counting.

8.8 Pause

This function sets all cooking zones that
operate to the lowest heat setting.

When the function operates only and

symbols can be used. All other

symbols on the control panel are locked.

The function does not stop the timer
functions.

Touch to activate the function.

comes on. The heat setting is lowered

to 1.

To deactivate the function touch .

The function stops PowerBoost. The
highest heat setting reactivates when

you touch again.

www.aeg.com14

8.9 Lock

You can lock the control panel while the
hob operates. It prevents an accidental
change of the heat setting.

Set the heat setting first.

Touch to activate the function.

To deactivate the function, touch for 3
seconds.

When you deactivate the
hob, you also deactivate this
function.

8.10 Child Lock

This function prevents an accidental
operation of the hob.

1. Touch on the display to open the
Menu.

2. Select Settings > Child Lock from the
list.

3. Turn the switch on and touch the
letters A-O-X in the alphabetical
order to activate the function. To
deactivate the function turn the
switch off.

To leave the Menu, touch
side of the display, outside of the pop-up
window. To navigate through the Menu,

use or .

or the right

8.11 Language

1. Touch on the display to open the
Menu.

2. Select Settings > Setup > Language
from the list.

3. Choose the appropriate language
from the list.

If you chose the wrong language, touch

. A list appears. Select the third option
from the top, then the last but one option.
Next, select the second option. Scroll
down to choose the appropriate
language from the list. Finally, choose
the option on the right.

To leave the Menu, touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,

or .

use

8.12 Key Tones / Buzzer Volume

You can choose the type of sound your
hob emits or turn the sounds off entirely.
You can choose between the click
(default) or beep.

1. Touch
Menu.

2. Select Settings > Setup > Key
Tones / Buzzer Volume from the list.

3. Choose the appropriate option.

To leave the Menu, touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,

or .

use

on the display to open the

8.13 Display Brightness

You can change the brightness of the
display.

There are 4 brightness levels, 1 is the
lowest and 4 is the highest.

1. Touch on the display to open the
Menu.

2. Select Settings > Setup > Display
Brightness from the list.

3. Choose the appropriate level.

To leave the Menu, touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,

use or .

8.14 Assisted Cooking

This function adjusts the temperature to
different types of food and maintains it
throughout cooking. It can only be
activated for the left front cooking zone
or both zones on the left when bridged.

1. Touch on the display to open the
Menu.

2. Select Assisted Cooking and choose
the type of food you would like to
prepare from the list.
For each type of food there are a few
options available. Follow the
instructions shown on the display.

• You can touch OK on top of the

pop-up window to use the default
settings.

ENGLISH 15

• You can set the timer function.
When the pot reaches the
intended temperature you can
activate the timer.

• You can change the default heat
level.

3. Once the pot reaches the intended
temperature an acoustic signal
sounds and a pop-up window
appears. To close the window and
start the function touch OK. To
deactivate the window permanently

check before you activate the
function.

To stop the function touch and Stop

or touch and select Assisted
Cooking, choose any type of food and
touch Stop.

To leave the Menu touch

or the right
side of the display, outside of the pop-up
window. To navigate through the Menu

use or .

8.15 Melting

You can use this function to melt
different products, e.g. chocolate or
butter. You can use the function only for
one cooking zone at a time.

1. Touch on the display to open the

Menu.

2. Select Hob Functions > Melting from

the list.

3. Touch Start.

You need to select the desired
cooking zone.
If the cooking zone is already active
a pop-up window appears. Cancel
the previous heat setting to activate
the function.

To leave the Menu, touch

or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,

use or .

To stop the function, touch the zone
selection symbol and then touch Stop.

8.16 Hob²Hood

It is an advanced automatic function
which connects the hob to a special
hood. Both the hob and the hood have

an infrared signal communicator. The
speed of the fan is defined automatically
on the basis of the mode setting and the
temperature of the hottest pot on the
hob.

For most of the hoods the remote system
is originally deactivated. Activate it
before you use the function. For more
information refer to the hood user
manual.

To operate the function automatically, set
the automatic mode to H1 - H6. The hob
is originally set to H5. The hood reacts
whenever you operate the hob. The hob
recognizes the temperature of the
cookware automatically and adjusts the
speed of the fan. You can set the hob to
activate only the light by selecting H1.

If you change the fan speed
on the hood, the default
connection with the hob is
deactivated. To reactivate
the function, turn both
appliances OFF and ON
again.

ModeAuto‐

matic
light

H0 Off Off Off

H1 On Off Off

On Fan speed 1 Fan speed 1

3)

H2

H3 On Off Fan speed 1

H4 On Fan speed 1 Fan speed 1

H5 On Fan speed 1 Fan speed 2

H6 On Fan speed 2 Fan speed 3

1)
The hob detects the boiling process and acti‐

vates fan speed in accordance with the automatic
mode.

2)
The hob detects the frying process and acti‐

vates fan speed in accordance with the automatic
mode.

3)
This mode activates the fan and the light and

does not rely on the temperature.

Boiling

1)

Frying

2)

www.aeg.com16

Changing the modes

If you are not satisfied with the noise
level / fan speed, you can switch
between modes manually.

1. Touch

Select Settings > Hob²Hood from the list.

2. Choose the appropriate mode.

To leave the Menu touch or the right
side of the display, outside of the pop-up
window.

.

When you finish cooking and deactivate
the hob, the hood fan may still operate
for a certain period of time. After that
time the system deactivates the fan
automatically and prevents you from an
accidental activation for the next 30
seconds.

The light on the hood deactivates 2
minutes after deactivating the hob.

9. FLEXIBLE INDUCTION COOKING AREA

WARNING!

Refer to Safety chapters.

9.1 FlexiBridge

The area on the left side can be
combined into two cooking zones with
different sizes, or into one large cooking
area. You may choose a combination of
4 sections which depends on the size of
the cookware you want to use. The
cooking zone indicators change
automatically and show the possible
combination.

FlexiBridge Standard is the default mode
which activates automatically when you
activate the hob. Two cooking zones
operate independently.

Incorrect cookware position:

Touch to switch between the
FlexiBridge modes.

9.2 FlexiBridge Standard mode

This mode is active when you activate
the hob. It connects the sections into two
separate cooking zones. You can set the
heat setting for each zone separately.

Correct cookware position:

9.3 FlexiBridge Big Bridge mode

To activate the mode touch until you
see the correct mode indicator . This
mode connects three rear sections into
one cooking zone. The front section is
not connected and operates as a
separate cooking zone. You can set the

heat setting for each zone separately.

Correct cookware position:

To use this mode you have to place the
cookware on the three connected
sections. If you use cookware smaller

than two sections the
display and after 1 minute the zone
switches off.

blinks on the

ENGLISH 17

Correct cookware position:

To use this mode you have to place the
cookware on the four connected
sections. If you use cookware smaller

than three sections the display shows
and after 1 minute the zone switches off.

Incorrect cookware position:

9.4 FlexiBridge Max Bridge mode

To activate the mode touch until you
see the correct mode indicator . This
mode connects all sections into one
cooking zone.

Incorrect cookware position:

9.5 PowerSlide

This function allows you to adjust the
temperature by moving the cookware to
a different position on the induction
cooking surface. This function
automatically divides the left cooking
zones into three areas with different heat
settings. The hob detects the position of
the cookware and adjusts the pre-set
power level accordingly. You can place
the pot in the front, middle or rear

www.aeg.com18

position. If you place the cookware at the
front you get the highest heat setting (i.e.

9). To decrease it, move the cookware to
the middle (heat setting - 5) or rear
position (heat setting -1).

Use only one pot with a
minimum bottom diameter of
160 mm when you operate
the function.

1. Touch once.

2. Scroll the Menu > Hob Functions to
select the function from the list.

• If any of the left zones operates a

pop-up window appears asking
you to confirm whether or not you
want to cancel the previous heat
settings.

• The

You can change the default heat
setting in accordance with your
needs and the heat setting will be
saved for future use.

symbol and the symbols of
three zones with default heat
settings appear on the display.

10. HINTS AND TIPS

WARNING!

Refer to Safety chapters.

10.1 Cookware

For induction cooking zones
a strong electro-magnetic
field creates the heat in the
cookware very quickly.

Use the induction cooking
zones with suitable
cookware.

Cookware material

• correct: cast iron, steel, enamelled

steel, stainless steel, multi-layer
bottom (with a correct marking from a
manufacturer).

• not correct: aluminium, copper,

brass, glass, ceramic, porcelain.

Cookware is suitable for an induction
hob if:

• water boils very quickly on a zone set
to the highest heat setting.

3. Place the pot on the cooking zone
with the desired heat setting.
Place the cookware in the centre of
the desired zone and make sure you
do not cover the neighbouring zones.
Red indicators come on. Unless you
see the red indicators the function
cannot be activated.
If you want to change the position of
the pot lift it up and place on a
different zone. Sliding the cookware
can cause scratches and
discolouration of the surface.

To deactivate the function touch , a
pop-up window appears. Touch Stop to
deactivate the function. You can also
deactivate the function from the Menu.

Move the pot from time to
time. The function
deactivates after 10 minutes
of inactivity.

• a magnet pulls on to the bottom of the

cookware.

The bottom of the cookware
must be as thick and flat as
possible.
Ensure pan bases are clean
and dry before placing on
the hob surface.

Cookware dimensions

Induction cooking zones adapt to the
dimension of the bottom of the cookware
automatically.

The cooking zone efficiency is related to
the diameter of the cookware. The
cookware with a diameter smaller than
the minimum receives only a part of the
power generated by the cooking zone.

Refer to "Technical data".

ENGLISH 19

10.2 Correct pans for Pan Fry function

Use only pans with flat bottom. To check
if the pan is correct:

1. Put your pan upside down.

2. Put a ruler on the bottom of the pan.

3. Try to put a coin of 1, 2 or 5 Euro
Cent (or with similar thickness)
between the ruler and the bottom of
the pan.

a. The pan is incorrect if you can

put the coin between the ruler
and the pan.

b. The pan is correct if you cannot

put the coin between the ruler
and the pan.

• crack noise: cookware is made of
different materials (a sandwich
construction).

• whistle sound: you use a cooking
zone with a high power level and the
cookware is made of different
materials (a sandwich construction).

• humming: you use a high power level.

• clicking: electric switching occurs, the
pot is detected after you place it on
the hob.

• hissing, buzzing: the fan operates.

The noises are normal and do not
indicate any malfunction.

10.4 Öko Timer (Eco Timer)

To save energy, the heater of the
cooking zone deactivates before the
count down timer sounds. The difference
in the operation time depends on the
heat setting level and the length of the
cooking operation.

10.5 Examples of cooking

applications

The correlation between the heat setting
of a zone and its consumption of power
is not linear. When you increase the heat
setting, it is not proportional to the
increase of the consumption of power. It
means that a cooking zone with the
medium heat setting uses less than a
half of its power.

The data in the table is for
guidance only.

10.3 The noises during operation

If you can hear:

Heat setting Use to: Time

(min)

1 Keep cooked food warm. as nec‐

essary

Hints

Put a lid on the cookware.

www.aeg.com20

Heat setting Use to: Time

(min)

1 - 2 Hollandaise sauce, melt: but‐

ter, chocolate, gelatine.

1 - 2 Solidify: fluffy omelettes, baked

eggs.

2 - 3 Simmer rice and milkbased

dishes, heat up ready-cooked
meals.

3 - 4 Steam vegetables, fish, meat. 20 - 45 Add a couple of tablespoons

4 - 5 Steam potatoes. 20 - 60 Use max. ¼ l of water for 750

4 - 5 Cook larger quantities of food,

stews and soups.

6 - 7 Gentle fry: escalope, veal cor‐

don bleu, cutlets, rissoles,
sausages, liver, roux, eggs,
pancakes, doughnuts.

7 - 8 Heavy fry, hash browns, loin

steaks, steaks.

9 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.

Boil large quantities of water. PowerBoost is activated.

5 - 25 Mix from time to time.

10 - 40 Cook with a lid on.

25 - 50 Add at least twice as much liq‐

60 - 150 Up to 3 l of liquid plus ingredi‐

as nec‐
essary

5 - 15 Turn halfway through.

Hints

uid as rice, mix milk dishes
halfway through the proce‐
dure.

of liquid.

g of potatoes.

ents.

Turn halfway through.

10.6 Hints and Tips for Hob²Hood

When you operate the hob with the
function:

• Protect the hood panel from direct
sunlight.

• Do not spot halogen light on the hood
panel.

• Do not cover the hob control panel.

• Do not interrupt the signal between
the hob and the hood (e.g. with the
hand, a cookware handle or a tall
pot). See the picture.

The hood in the picture is only
exemplary.

Keep the window of the
Hob²Hood infrared signal
communicator clean.

ENGLISH 21

Other remotely controlled
appliances may block the
signal. Do not use any such
appliances near to the hob
while Hob²Hood is on.

Cooker hoods with the Hob²Hood
function

11. CARE AND CLEANING

WARNING!

Refer to Safety chapters.

11.1 General information

• Clean the hob after each use.

• Always use cookware with a clean
base.

• Scratches or dark stains on the
surface have no effect on how the hob
operates.

• Use a special cleaner suitable for the
surface of the hob.

• Use a special scraper for the glass.

The printing on the flexible
induction cooking area may
become dirty or change its
colour from sliding the
cookware. You can clean the
area in a standard way.

11.2 Cleaning the hob

• Remove immediately: melted plastic,
plastic foil, sugar and food with sugar,

To find the full range of cooker hoods
which work with this function refer to our
consumer website. The AEG cooker
hoods that work with this function must

have the symbol .

otherwise, the dirt can cause damage
to the hob. Take care to avoid burns.
Use a special hob scraper on the
glass surface at an acute angle and
move the blade on the surface.

• Remove when the hob is
sufficiently cool: limescale rings,
water rings, fat stains, shiny metallic
discoloration. Clean the hob with a
moist cloth and a non-abrasive
detergent. After cleaning, wipe the
hob dry with a soft cloth.

• Remove shiny metallic
discoloration: use a solution of water
with vinegar and clean the glass
surface with a cloth.

• The surface of the hob has horizontal
grooves. Clean the hob with a moist
cloth and some detergent with smooth
movement from left to right. After
cleaning, wipe the hob dry with a soft
cloth from left to right.

12. TROUBLESHOOTING

WARNING!

Refer to Safety chapters.

12.1 What to do if...

Problem Possible cause Remedy

You cannot activate or oper‐
ate the hob.

The hob is not connected to
an electrical supply or it is
connected incorrectly.

Check if the hob is correctly
connected to the electrical
supply. Refer to the connec‐
tion diagram.

www.aeg.com22

Problem Possible cause Remedy

The fuse is blown. Make sure that the fuse is

the cause of the malfunction.
If the fuse is blown again
and again, contact a quali‐
fied electrician.

You do not set the heat set‐

ting for 60 seconds.

Activate the hob again and
set the heat setting in less
than 60 seconds.

You touched 2 or more sen‐

Touch only one sensor field.

sor fields at the same time.

Pause operates. Refer to "Daily use".

The display does not react to
the touch.

Part of the display is covered
or the pots are placed too
near to the display.
There is some liquid or an
object on the display.

Remove the objects. Move
the pots away from the dis‐
play.
Clean the display, wait until
the appliance is cold. Dis‐
connect the hob from the
electrical supply. After 1 min,
connect the hob again.

An acoustic signal sounds
and the hob deactivates.

You put something on one or
more sensor fields.

Remove the object from the

sensor fields.
An acoustic signal sounds
when the hob is deactivated.

The hob deactivates. You put something on the

sensor field .

Residual heat indicator does
not come on.

The zone is not hot because
it operated only for a short
time or the sensor under the
hob surface is damaged.

You cannot activate the
highest heat setting.

The sensor fields become
hot.

Another zone is already set
to the highest heat setting.

The cookware is too large or
you put it too near to the

Remove the object from the

sensor field.

If the zone operated suffi‐

ciently long to be hot, speak

to an Authorised Service

Centre.

First reduce the power of the

other zone.

Put large cookware on the

rear zones if possible.

controls.

Hob²Hood does not work. You covered the control pan‐

el.

Hob²Hood operates, but only

You activated the H1 mode. Change the mode to H2 - H6

the light is on.

Remove the object from the

control panel.

or wait until the automatic

mode starts.

Hob²Hood modes H1 - H6
operate, but the light is off.

There might be a problem
with the light bulb.

Contact an Authorised Serv‐

ice Centre.

ENGLISH 23

Problem Possible cause Remedy

There is no sound when you
touch the panel sensor

The sounds are deactivated. Activate the sounds. Refer to

"Daily use".

fields.

Wrong language is set. You changed the language

by mistake.

Reset all functions to the
factory settings. Select Re‐
set All Settings from the
Menu.
Disconnect the hob from the
electrical supply. After 1 min,
connect the hob again. Set
Language, Display Bright‐
ness and Buzzer Volume.

The flexible induction cook‐
ing area does not heat up
the cookware.

The cookware is in a wrong
position on the flexible in‐
duction cooking area.

Place the cookware in the
correct position on the flexi‐
ble induction cooking area.
The position of the cookware
depends on the activated
function or function mode.
Refer to "Flexible induction
cooking area".

The diameter of the bottom

of the cookware is incorrect
for the activated function or
function mode.

Use cookware with a diame‐
ter applicable to the activa‐
ted function or function
mode. Use cookware with a
diameter smaller than 160
mm on a single section of
the flexible induction cooking
area. Refer to "Flexible in‐
duction cooking area".

A cooking zone deactivates.
A warning message saying
the cooking zone is going to

Automatic Switch Off deacti‐
vates the cooking zone.

Refer to "Daily use".
Deactivate the hob and acti‐
vate it again.

switch off comes on.

and a message come on.

Lock operates. Refer to "Daily use".

O - X - A appears. Child Lock operates. Refer to "Daily use".

blinks.

There is no cookware on the
zone.

Put cookware on the zone.

The cookware is unsuitable. Use suitable cookware. Re‐

fer to "Hints and tips".

The diameter of the bottom

of the cookware is too small
for the zone.

Use cookware with correct
dimensions. Refer to "Tech‐
nical data".

www.aeg.com24

Problem Possible cause Remedy

FlexiBridge operates. One or

more sections of the function
mode which operates are
not covered by the cook‐
ware.

PowerSlide operates. Two

pots are placed on the flexi‐
ble induction cooking area.

and a number come on.

You can hear a constant
beep noise.

There is an error in the hob. Deactivate the hob and acti‐

The electrical connection is
incorrect.

Place the cookware on the

correct number of sections

of the function mode which

operates or change the func‐

tion mode. Refer to "Flexible

induction cooking area".

Use only one pot. Refer to

"Flexible induction cooking

area".

vate it again after 30 sec‐

onds. If comes on again,

disconnect the hob from the

electrical supply. After 30

seconds, connect the hob

again. If the problem contin‐

ues, speak to an Authorised

Service Centre.

Disconnect the hob from the

electrical supply. Ask a

qualified electrician to check

the installation.

12.2 If you cannot find a solution...

If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre. Give the
data from the rating plate. Make sure,
you operated the hob correctly. If not the

13. TECHNICAL DATA

13.1 Rating plate

Model IAE64851FB PNC 949 597 568 00
Typ 62 B4A 05 CA 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.35 kW Made in Germany

Ser.Nr. ................. 7.35 kW

AEG

13.2 Software Licences

The software included in the hob
contains copyrighted software that is
licensed under the BSD, fontconfig, FTL,

servicing by a service technician or
dealer will not be free of charge, also
during the warranty period. The
instructions about the Service Centre
and conditions of guarantee are in the
guarantee booklet.

GPL-2.0, LGPL-2.0, LGPL-2.1, libJpeg,
zLib/ libpng, MIT, OpenSSL / SSLEAY
ISC, Apache 2.0 and others.

Check the full copy of the licence in:
Menu > Settings > Service > License.

ENGLISH 25

You can download the source code of
the open source software by following

13.3 Cooking zones specification

Cooking zone Nominal power

(maximum
heat setting)
[W]

Right front 1400 2500 4 125 - 145

Right rear 1800 2800 10 145 - 180

Flexible induc‐
tion cooking
area

2300 3200 10 minimum 100

The power of the cooking zones can be
different in some small range from the
data in the table. It changes with the
material and dimensions of the
cookware.

14. ENERGY EFFICIENCY

14.1 Product information according to EU 66/2014 valid for EU market only

Model identification IAE64851FB

Type of hob Built-In Hob

Number of cooking zones 2

Number of cooking areas 1

Heating technology Induction

Diameter of circular cook‐
ing zones (Ø)

Lenght (L) and width (W) of
the cooking area

Energy consumption per
cooking zone (EC electric
cooking)

Energy consumption of the
cooking area (EC electric
cooking)

Energy consumption of the
hob (EC electric hob)

Right front
Right rear

Left L 45.9 cm

Right front
Right rear

Left 187.0 Wh / kg

184.6 Wh / kg

the hyperlink present in the web product
page.

PowerBoost
[W]

For optimal cooking results use
cookware no larger than the diameter in
the table.

PowerBoost
maximum dura‐
tion [min]

Cookware di‐
ameter [mm]

14.5 cm

18.0 cm

W 21.4 cm

187.5 Wh / kg

174.6 Wh / kg

www.aeg.com26

EN 60350-2 - Household electric cooking
appliances - Part 2: Hobs - Methods for
measuring performance

14.2 Energy saving

You can save energy during everyday
cooking if you follow below hints.

• When you heat up water, use only the
amount you need.

15. WARRANTY

FOR SALES IN AUSTRALIA AND NEW
ZEALAND

ALL AEG BRANDED APPLIANCES

This document sets out the terms and
conditions of the product warranties
for AEG Appliances. It is an important
document. Please keep it with your
proof of purchase documents in a
safe place for future reference should
there be a manufacturing defect in
your Appliance. This warranty is in
addition to other rights you may have
under the Australian Consumer Law.

1. In this warranty:

a) ‘ACL’ or ‘Australian Consumer

Law’ means Schedule 2 to the
Competition and Consumer Act
2010;

b) ‘Appliance’ means any Electrolux

product purchased by you and
accompanied by this document;

c) ‘ASC’ means Electrolux’s

authorised serviced centres;

d) ‘AEG’ is the brand controlled by

Electrolux Home Products Pty
Ltd of 163 O’Riordan Street,
Mascot NSW 2020, ABN 51 004
762 341 in respect of Appliances
purchased in Australia and
Electrolux (NZ) Limited
(collectively “Electrolux”) of 3-5
Niall Burgess Road, Mount
Wellington, in respect of
Appliances purchased in New
Zealand;

e) ‘Warranty Period’ means the

period specified in clause 3 of
this warranty;

f) ‘you’ means the purchaser of the

Appliance not having purchased
the Appliance for re-sale, and

• If it is possible, always put the lids on
the cookware.

• Before you activate the cooking zone
put the cookware on it.

• Put the smaller cookware on the
smaller cooking zones.

• Put the cookware directly in the centre
of the cooking zone.

• Use the residual heat to keep the food
warm or to melt it.

‘your’ has a corresponding
meaning.

2. Application: This warranty only

applies to new Appliances,
purchased and used in Australia or
New Zealand and is in addition to
(and does not exclude, restrict, or
modify in any way) other rights and
remedies under a law to which the
Appliances or services relate,
including any non-excludable
statutory guarantees in Australia and
New Zealand.

3. Warranty Period: Subject to these

terms and conditions, this warranty
continues for in Australia for a period
of 60 months and in New Zealand for
a period of 60 months, following the
date of original purchase of the
Appliance.

4. Repair or replace warranty: During

the Warranty Period, Electrolux or its
ASC will, at no extra charge if your
Appliance is readily accessible for
service, without special equipment
and subject to these terms and
conditions, repair or replace any
parts which it considers to be
defective. Electrolux may, in its
absolute discretion, choose whether
the remedy offered for a valid
warranty claim is repair or
replacement. Electrolux or its ASC
may use refurbished parts to repair
your Appliance. You agree that any
replaced Appliances or parts become
the property of Electrolux.

5. Travel and transportation costs:

Subject to clause 7, Electrolux will
bear the reasonable cost of
transportation, travel and delivery of
the Appliance to and from Electrolux

ENGLISH 27

or its ASC. Travel and transportation
will be arranged by Electrolux as part
of any valid warranty claim.

6. Proof of purchase is required before

you can make a claim under this
warranty.

7. Exclusions: You may not make a

claim under this warranty unless the
defect claimed is due to faulty or
defective parts or workmanship. This
warranty does not cover:
a) light globes, batteries, filters or

similar perishable parts;

b) parts and Appliances not

supplied by Electrolux;

c) cosmetic damage which does not

affect the operation of the
Appliance;

d) damage to the Appliance caused

by:
– negligence or accident;
– misuse or abuse, including

failure to properly maintain or
service;

– improper, negligent or faulty

servicing or repair works done
by anyone other than an
Electrolux authorised repairer

or ASC;
– normal wear and tear;
– power surges, electrical storm

damage or incorrect power

supply;
– incomplete or improper

installation;
– incorrect, improper or

inappropriate operation;
– insect or vermin infestation;
– failure to comply with any

additional instructions

supplied with the Appliance;
In addition, Electrolux is not liable
under this warranty if:
– the Appliance has been, or

Electrolux reasonably

believes that the Appliance

has been, used for purposes

other than those for which the

Appliance was intended,

including where the Appliance

has been used for any non-

domestic purpose;
– the Appliance is modified

without authority from

Electrolux in writing;

– the Appliance’s serial number

or warranty seal has been
removed or defaced.

8. How to claim under this warranty:

To enquire about claiming under this
warranty, please follow these steps:
a. carefully check the operating

instructions, user manual and the
terms of this warranty;

b. have the model and serial

number of the Appliance
available;

c. have the proof of purchase (e.g.

an invoice) available;

d. telephone the numbers shown

below.

9. Australia: For Appliances and

services provided by Electrolux in
Australia: Electrolux goods come with
guarantees that cannot be excluded
under the Australian Consumer Law.
You are entitled to a replacement or
refund for a major failure and for
compensation for any other
reasonably foreseeable loss or
damage. You are also entitled to
have the Appliance repaired or
replaced if the Appliance fails to be of
acceptable quality and the failure
does not amount to a major failure.
‘Acceptable quality’ and ‘major
failure’ have the same meaning as
referred to in the ACL.

10. New Zealand: For Appliances and

services provided by Electrolux in
New Zealand, the Appliances come
with a guarantee by Electrolux
pursuant to the provisions of the
Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading
Act. Where the Appliance was
purchased in New Zealand for
commercial purposes the Consumer
Guarantee Act does not apply.

11. Confidentiality: You accept that if

you make a warranty claim,
Electrolux and its agents including
ASC may exchange information in
relation to you to enable Electrolux to
meet its obligations under this
warranty.

www.aeg.com28

Important Notice

Before calling for service, please ensure that the steps listed in clause 8 above have been

followed.

SERVICE AUSTRALIA

aeg.com/au

FOR SERVICE

or to find the address of your nearest au‐

thorised service centre in Australia

PLEASE CALL 1300 363 664

OR EMAIL

[e-mail]

For the cost of a local call (Australia only)

or to find the address of your nearest spare

[e-mail]

FOR SPARE PARTS

parts centre in Australia

PLEASE CALL 13 13 50

OR EMAIL

For the cost of a local call (Australia only)

SERVICE NEW ZEALAND

aegnewzealand.co.nz

FOR SERVICE

or to find the address of your nearest au‐

thorised service centre in New Zealand

PLEASE CALL 0800 234 234

OR EMAIL

[e-mail]

(New Zealand only)

or to find the address of your nearest spare

FOR SPARE PARTS

parts centre in New Zealand

PLEASE CALL 0800 10 66 20

OR EMAIL

[e-mail]

(New Zealand only)

AEG_Warr_May_17

16. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of

appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.

*

www.aeg.com/au

867358210-B-122021
