AEG FAV55VI1P User Manual [nl]

Download
USER MANUAL
FAV55VI1P
EN User Manual 2
Dishwasher
DE Benutzerinformation 25
Geschirrspüler
www.aeg.com
2

CONTENTS

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number. The information can be found on the rating plate.
Warning / Caution-Safety information General information and tips Environmental information
Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

1.1 Children and vulnerable people safety

• This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
• Do not let children play with the appliance.
• Keep detergents away from children.
• Keep children and pets away from the appliance door
when it is open.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH
3

General Safety

1.2
• This appliance is intended to be used in household
and similar applications such as:
– farm houses; staff kitchen areas in shops, offices
and other working environments;
– by clients in hotels, motels, bed & breakfast and
other residential type environments.
• Do not change the specification of this appliance.
• The operating water pressure (minimum and
maximum) must be between 0.5 (0.05) / 8 (0.8) bar (MPa)
• Obey the maximum number of 15 place settings.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard.
www.aeg.com
4
• Put knives and cutlery with sharp points in the cutlery
basket with the points down or in a horizontal
position.
• Do not keep the appliance door open without
supervision to prevent to fall on it.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
• Do not use high pressure water sprays and/or steam
to clean the appliance.
• The ventilation openings in the base (if applicable)
must not be obstructed by a carpet.
• The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.
• Do not install or use a damaged appliance.
• Do not install or use the appliance where the temperature is less than 0 °C.
• Follow the installation instruction supplied with the appliance.
• Make sure that the appliance is installed below and adjacent to safe structures.

2.2 Electrical connection

WARNING!
Risk of fire and electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information on the rating plate agrees with the power supply. If not, contact an electrician.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and to the mains
cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre.
• Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• This appliance complies with the E.E.C. Directives.
• Only for UK and Ireland. The appliance has a 13 amp mains plug. If it is necessary to change the fuse in the mains plug, use fuse: 13 amp ASTA (BS 1362).

2.3 Water connection

• Do not cause damage to the water hoses.
• Before connection to new pipes, pipes not used for a long time, where repair work has been carried out or new devices fitted (water meters, etc.), let the water flow until it is clean and clear.
ENGLISH
5
• Ensure that there are no visible water leaks during and after the first use of the appliance.
• The water inlet hose has a safety valve and a sheath with an inner mains cable.
WARNING!
Dangerous voltage.
• If the water inlet hose is damaged, immediately close the water tap and disconnect the mains plug from the mains socket. Contact the Authorised Service Centre to replace the water inlet hose.

2.4 Use

• Do not sit or stand on the open door.
• Dishwasher detergents are dangerous. Obey the safety instructions on the detergent packaging.
• Do not drink and play with the water in the appliance.
• Do not remove the dishes from the appliance until the programme is
completed. There can be detergent on the dishes.
• The appliance can release hot steam if you open the door while a programme operates.
• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

2.5 Service

• Contact the Authorised Service Centre to repair the appliance. We recommend only the use of original spare parts.
• When you contact the Authorised Service Centre, ensure that you have the following information that is available on the rating plate. Model : PNC : Serial Number :

2.6 Disposal

WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children and pets to get closed in the appliance.
5
4
10
9
67
11
12
2
3
1
8
www.aeg.com6

3. PRODUCT DESCRIPTION

Top spray arm
1
Upper spray arm
2
Lower spray arm
3
Filters
4
Rating plate
5
Salt container
6
Air vent
7

3.1 TimeBeam

The TimeBeam is a display that is shown on the floor below the appliance door.
• When the programme starts, the programme duration comes on.
• When the programme is completed, 0:00 and CLEAN come on.
• When the delay start starts, the countdown duration and DELAY come on.
• When the appliance has a malfunction, an alarm code appears.
Rinse aid dispenser
8
Detergent dispenser
9
Lower basket
10
Upper basket
11
Cutlery drawer
12
When AirDry is activated
1
2
3 4 5 6 7 8
9
during the drying phase, the projection on the floor may not be completely visible. To check the remaining time of the running programme, look at the control panel display.

4. CONTROL PANEL

ENGLISH 7
On/off button
1
Display
2
Delay button
3
Program button
4
Sanitize button
5

4.1 Indicators

Indicator Description
End indicator.
Rinse aid indicator. It is always off while the programme operates.
Salt indicator. It is always off while the programme operates.

5. PROGRAMMES

Programme Degree of soil
Type of load
P1
1)
• Normal soil
• Crockery and cutlery
TimeSaver button
6
XtraDry button
7
Reset button
8
Indicators
9
Programme phases Options
• Prewash
• Wash 50 °C
• Rinse
• Dry
• Sanitize
• TimeSaver
• XtraDry
www.aeg.com8
Programme Degree of soil
Programme phases Options
Type of load
P2
2)
• All
• Crockery, cut­lery, pots and pans
• Prewash
• Wash from 45 °C to 70 °C
• Rinse
• Sanitize
• XtraDry
• Dry
P3 • Heavy soil
• Crockery, cut­lery, pots and pans
P5 • Normal or light
soil
• Delicate crock-
• Prewash
• Wash 70 °C
• Rinse
• Dry
• Wash 45 °C
• Rinse
• Dry
• Sanitize
• XtraDry
• TimeSaver
• XtraDry
ery and glass­ware
P4
P6
3)
• Fresh soil
• Crockery and
• Normal soil
• Crockery and
4)
cutlery
cutlery
• Wash 60 °C
• Rinse
• Prewash
• Wash 50 °C
• Rinse
• Sanitize
• XtraDry
• XtraDry
• Dry
1)
With this programme you have the most efficient use of water and energy consumption for crockery
and cutlery with normal soil. (This is the standard programme for test institutes).
2)
The appliance senses the degree of soil and the quantity of items in the baskets . It automatically ad-
justs the temperature and the quantity of water, the energy consumption and the programme duration.
3)
With this programme you can wash a load with fresh soil. It gives good washing results in a short time.
4)
This is the most silent programme. The pump works at a very low speed to decrease the level of noise.
Because of the low speed, the programme duration is long.

5.1 Consumption values

Programme
1)
Water
(l)
P1 11 0.857 225
P2 7 - 14 0.6 - 1.6 40 - 170
P3 12.5-14.5 1.4-1.7 170-190
Energy
(kWh)
Duration
(min)
ENGLISH
9
Programme
P5 12 - 14 0.7 - 0.9 82-92
P4 10 0.9 30
P6 9 - 10 1.1 - 1.3 230 - 250
1)
The pressure and the temperature of the water, the variations of the mains supply, the options and the
quantity of dishes can change the values.

5.2 Information for test institutes

For all the necessary information for test performance, send an email to:

6. SETTINGS

6.1 Programme selection
mode and user mode
When the appliance is in programme selection mode it is possible to set a programme and to enter the user mode.
In user mode, the following settings can be changed:
• The level of the water softener according to the water hardness.
• The activation or the deactivation of the acoustic signal for end of programme.
• The selection of the colour for TimeBeam.
• The activation or deactivation of the rinse aid empty notification.
• The level of rinse aid according to the required dosage.
• The activation or the deactivation of AirDry.
These settings will be saved until you change them again.
1)
Water
(l)
Energy
(kWh)
info.test@dishwasher-production.com
Write down the product number (PNC) that is on the rating plate.
Duration
(min)

How to set the programme selection mode

The appliance is in programme selection mode when the display shows the programme number P1.
When you activate the appliance, usually it is in programme selection mode. However, if this does not happen, you can set the programme selection mode in the following way:
Press and hold Reset until the appliance is in programme selection mode.

6.2 The water softener

The water softener removes minerals from the water supply, which would have a detrimental effect on the washing results and on the appliance.
The higher the content of these minerals, the harder your water is. Water hardness is measured in equivalent scales.
The water softener should be adjusted according to the hardness of the water in your area. Your local water authority can advise you on the hardness of the water in your area. It is important to set the right level of the water softener to assure good washing results.
10
www.aeg.com
Water hardness
German de-
grees (°dH)
47 - 50 84 - 90 8.4 - 9.0 58 - 63 10
43 - 46 76 - 83 7.6 - 8.3 53 - 57 9
37 - 42 65 - 75 6.5 - 7.5 46 - 52 8
29 - 36 51 - 64 5.1 - 6.4 36 - 45 7
23 - 28 40 - 50 4.0 - 5.0 28 - 35 6
19 - 22 33 - 39 3.3 - 3.9 23 - 27
15 - 18 26 - 32 2.6 - 3.2 18 - 22 4
11 - 14 19 - 25 1.9 - 2.5 13 - 17 3
4 - 10 7 - 18 0.7 - 1.8 5 - 12 2
<4 <7 <0.7 < 5
1)
Factory setting.
2)
Do not use salt at this level.
French degrees
(°fH)
mmol/l Clarke de-
grees
Water softener lev-
el
1)
5
2)
1
Whether you use a standard detergent or multi-tabs (with or without salt), set the proper water hardness level to keep the salt refill indicator active.
Multi-tabs containing salt are not effective enough to soften hard water.

How to set the water softener level

The appliance must be in programme selection mode.
1. To enter the user mode, press and
hold simultaneously the indicators , , , , and start to flash and the
display is blank.
2. Press .
• The indicators
and go off.
• The indicator
flash.
• The display shows the current
setting: e.g.
and until
, , ,
continues to
= level 5.
3. Press again and again to change
the setting.
4. Press the on/off button to confirm
the setting.

6.3 The rinse aid dispenser

The rinse aid helps to dry the dishes without streaks and stains.
The rinse aid is automatically released during the hot rinse phase.
You can set the released quantity of rinse aid between level 1 (minimum quantity) and level 6 (maximum quantity). Level 0 will deactivate the rinse aid dispenser and no rinse aid will be released.
Factory setting: level 4.

How to set the rinse aid level

The appliance must be in programme selection mode.
1. To enter the user mode, press and
hold simultaneously the indicators , , , , and start to flash and the
display is blank.
and until
ENGLISH
11
2. Press .
• The indicators , , , and go off.
• The indicator continues to flash.
• The display shows the current setting: e.g. = level 4.
– The levels of rinse aid are
from 0A to 6A.
– Level 0 = no rinse aid is
released.
3. Press again and again to change
the setting.
4. Press the on/off button to confirm
the setting.

6.4 The rinse aid empty notification

The rinse aid helps to dry the dishes without streaks and stains.
The rinse aid is automatically released during the hot rinse phase.
When rinse aid chamber is empty, the rinse aid indicator is turned on notifying to refill rinse aid. If you are using multi­tabs containing rinse aid and you are satisfied with the drying result, you can deactivate the notification for refilling rinse aid. However, we recommend that you always use rinse aid for best drying performance.
If you use standard detergent or multi­tablets without rinse aid, activate the notification to keep the rinse aid refill indicator active.

How to deactivate the rinse aid empty notification

The appliance must be in programme selection mode.
1. To enter the user mode, press and
hold simultaneously and until the indicators and start to flash and the
display is blank.
2. Press
, , , ,
.
• The indicators , , , and go off.
• The indicator continues to flash.
• The display shows the current setting: = the rinse aid empty
notification is activated (factory setting).
3. Press
= the rinse aid empty notification is
deactivated.
4. Press the on/off button to confirm
the setting.
to change the setting.

6.5 Acoustic signals

Acoustic signals sound when a malfunction of the appliance occurs. It is not possible to deactivate these acoustic signals.
There is also an acoustic signal that sounds when the programme is completed. By default this acoustic signal is deactivated but it is possible to activate it.

How to activate the acoustic signal for the end of programme

The appliance must be in programme selection mode.
1. To enter the user mode, press and
hold simultaneously and until the indicators , , , , and start to flash and the
display is blank.
2. Press
• The indicators , , , and go off.
• The indicator flash.
• The display shows the current setting: = Acoustic signal off.
3. Press
= Acoustic signal on.
4. Press the on/off button to confirm
the setting.
to change the setting.
continues to
12
www.aeg.com
6.6 How to set the colour of
the TimeBeam
It is possible to change the colour of the TimeBeam to match the colour of the kitchen floor. There are several colours available. The TimeBeam can also be deactivated.
The appliance must be in programme selection mode.
1. To enter the user mode, press and
hold simultaneously and until the indicators , , , , and start to flash and the
display is blank.
2. Press .
• The indicators and go off.
• The indicator flash.
• The display shows a number and the letter C. Each number refers to a different colour.
– = TimeBeam
deactivated.
3. Press
the colour.
• You can see the different colours
4. Press the on/off button to confirm
the setting.
again and again to change
on the kitchen floor.
, , ,
continues to

6.7 AirDry

AirDry improves the drying results with less energy consumption.
While the drying phase operates, a device opens the appliance door. The door is then kept ajar.
CAUTION!
Do not try to close the appliance door within 2 minutes after automatic open. This can cause damage to the appliance.
To improve the drying performance refer to the XtraDry option or activate AirDry.

How to deactivate AirDry

The appliance must be in programme selection mode.
1. To enter the user mode, press and
hold simultaneously and until the indicators and start to flash and the
display is blank.
2. Press
• The indicators , , , and go off.
• The indicator continues to flash.
• The display shows the current setting: = AirDry activated.
3. Press to change the setting:
= AirDry deactivated.
4. Press the on/off button to confirm
the setting.
, , , ,
.

7. OPTIONS

ENGLISH 13
Desired options must be activated every time before you start a programme. It is not possible to activate or deactivate options while a programme is running.
Not all options are compatible with each other. If you have selected non compatible options, the appliance will automatically deactivate one or more of them. Only the indicators of the options still active will stay on.

7.1 XtraDry

Activate this option when you want to boost the drying performance. With use of this option, the duration of some programmes, water consumption and the last rinse temperature can be affected.
The XtraDry option is a permanent option for all programmes other than
and need not to be selected at
every cycle.
Every time is activated, XtraDry option is off and needs to be chosen manually. In other programmes, the setting of XtraDry is permanent and it is automatically used in next cycles. This configuration can be changed at any time.
Activating XtraDry option deactivates TimeSaver.

How to activate XtraDry

Press . The related indicator comes on. The display shows the updated programme duration.

7.2 TimeSaver

The TimeSaver allows to reduce the time of the selected programme.
The total programme duration decreases by approximately 50%.
The washing results are the same as with the normal programme duration. The drying results can decrease.
This option increases the pressure and the temperature of the water. The washing and the drying phases are shorter.
By default, TimeSaver is off, but it is possible to activate it manually. This option cannot be combined with XtraDry at the same time.

How to activate TimeSaver

Press , the related indicator comes on. If the option is not applicable to the programme, the related indicator does not come on or it flashes quickly for a few seconds and then goes off. The display shows the updated programme duration.

7.3 Sanitize

This option provides better hygiene results by keeping the temperature at 70 °C for at least 10 minutes during the last rinsing phase.

How to activate Sanitize

Press , the related indicator comes on If the option is not applicable to the programme, the related indicator does not come on or it flashes quickly for a few seconds and then goes off. The display shows the updated programme duration.
8.

BEFORE FIRST USE

1. Make sure that the current level of the water softener agrees with the
A
B
C
14
www.aeg.com
hardness of the water supply. If not, adjust the level of the water softener.
2. Fill the salt container.
3. Fill the rinse aid dispenser.
4. Open the water tap.
5. Start a programme to remove any
processing residuals that can still be inside the appliance. Do not use detergent and do not load the
baskets. When you start a programme, the appliance can take up to 5 minutes to recharge the resin in the water softener. It seems that the appliance is not working. The washing phase starts only after this procedure is completed. The procedure will be repeated periodically.

8.1 The salt container

CAUTION!
Only use salt specifically designed for dishwashers.
The salt is used to recharge the resin in the water softener and to assure good washing results in the daily use.
Turn the cap of the salt container
5.
clockwise to close the salt container.
CAUTION!
Water and salt can come out of the salt container when you fill it. After you fill the salt container, immediately start a programme to prevent corrosion.

8.2 How to fill the rinse aid dispenser

How to fill the salt container

1. Turn the cap of the salt container
counterclockwise and remove it.
2. Put 1 litre of water in the salt
container (Only for the first time).
3. Fill the salt container with dishwasher
salt.
4. Remove the salt around the opening
of the salt container.
CAUTION!
Only use rinse aid specifically designed for dishwashers.
1. Open the lid (C).
2. Fill the dispenser (B) until the rinse
aid reaches the marking ''MAX''.
3. Remove the spilled rinse aid with an
absorbent cloth to prevent too much foam.
4. Close the lid. Make sure that the lid
locks into position.
A
B
C
ENGLISH
15
Fill the rinse aid dispenser when the indicator (A) becomes clear.

9. DAILY USE

1. Open the water tap.
2. Press the on/off button to activate
the appliance. Make sure that the appliance is in programme selection mode.
• If the salt indicator is on, fill the salt container.
• If the rinse aid indicator is on, fill the rinse aid dispenser.
3. Load the baskets.
4. Add the detergent.
5. Set and start the correct programme
for the type of load and the degree of soil.

9.1 Using the detergent

If you use multi-tablets and the drying performance is satisfactory, the rinse aid refill indication can be disabled. We recommend to always use rinse aid for better drying performance, also in combination with multi­tablets containing rinsing agent.
3. If the programme has a prewash
phase, put a small quantity of detergent on the inner part of the appliance door.
4. Close the lid. Make sure that the lid
locks into position.

9.2 Setting and starting a programme

The Auto Off function

This function decreases energy consumption by deactivating automatically the appliance when it is not operating.
The function comes into operation:
• 5 minutes after the completion of the programme.
• After 5 minutes if the programme has not started.

Starting a programme

1. Keep the appliance door ajar.
2. Press the on/off button to activate
the appliance. Make sure that the appliance is in programme selection mode.
CAUTION!
1. Press the release button (A) to open
2. Put the detergent, in powder or
Only use detergent specifically designed for dishwashers.
the lid (C).
tablets, in the compartment (B).
3. Press repeatedly
shows the number of the programme you want to start. The display will show the programme number for approximately 3 seconds and then show the programme duration.
4. Set the applicable options.
5. Close the appliance door to start the
programme.
until the display
www.aeg.com16

Starting a programme with delay start

1. Set a programme.
2. Press again and again until the
display shows the delay time you want to set (from 1 to 24 hours).
The delay indicator comes on.
3. Close the appliance door to start the
countdown. While a countdown is running it is possible to increase the delay time but not to change the selection of the programme and options. When the countdown is completed, the programme starts.

Opening the door while the appliance operates

If you open the door while a programme is running, the appliance stops. It may affect the energy consumption and the programme duration. When you close the door, the appliance continues from the point of interruption.
If the door is opened for more than 30 seconds during the drying phase, the running programme will end. This will not happen if the door is opened by AirDry.

Cancelling the delay start while the countdown operates

When you cancel the delay start you have to set the programme and options again.
Press and hold Reset until the appliance is in programme selection mode.

Cancelling the programme

Press and hold Reset until the appliance is in programme selection mode. Make sure that there is detergent in the detergent dispenser before you start a new programme.

End of programme

When the programme is completed and you open the door, the appliance is automatically deactivated.
Close the water tap.
CAUTION!
Do not try to close the appliance door within 2 minutes after AirDry automatically opens it, as this may cause damage to the appliance. If, afterwards, the door is closed for another 3 minutes, the running programme ends.

10. HINTS AND TIPS

10.1 General

The following hints will ensure optimal cleaning and drying results in daily use and also help to protect the environment.
• Remove larger residues of food from
the dishes into the waste bin.
• Do not pre-rinse dishes by hand. When needed, use the prewash programme (if available) or select a programme with a prewash phase.
• Always use the whole space of the baskets.
• When loading the appliance, make sure that the dishes can be
Loading...
+ 36 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
