AEG ENB43391W User Manual
User manual
ЕгчейсЯдйп чсЮуфз
Kullanma K lavuzu
ENB 43391 W
Fridge-Freezer
Шхгейпкбфбшэкфзт
So utucu - dondurucu
electrolux
3
Welcome to the world of Electrolux
You’ve chosen a first class product from Electrolux, which hopefully will provide
you with lots of pleasure in the future. Electrolux ambition is to offer a wide variety
of quality products that would make your life even more comfortable. You can look
at some examples on the cover in this manual. But now it’s time to study this
manual and start using and enjoying the benefits from your new machine. We
promise that it’ll make your life a little easier. Good luck!
4
electrolux
The following symbols are used in this manual:
Important information concerning your personal safety and information on
how to avoid damaging the appliance.
General information and tips
Environmental information
The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased
the product.
electrolux
5
CONTENTS
Safety IImformation 6
Use 99
Cleaning the interior 9
Control panel 9
Operation 9
Temperature regulation 10
Fresh food refrigeration 10
Air recycling 11
Ice-cube production 16
Movable shelves 12
Bottle rack 12
Positioning the door shelves 12
Humidity Control 13
Drawer 13
Ice-cube production 14
Freezing fresh food 15
Storage of frozen food 15
Thawing 15
Hints 16
Hints for refrigeration 16
Hints for freezing 16
Hints for storage of frozen food 17
Interior light 17
Maintenance 118
Periodic cleaning 18
Defrosting 18
Technical information 19
Customer sservice aand sspare pparts 119
Installation 20
Location 20
Rear spacers 20
Shelf holders 20
Electrical connection 21
Door reversibility 21
European GGuarantee 24
www.electrolux.com 25
6
electrolux
SAFETY INFORMATION
It is most important that this
instruction book should be retained
with the appliance for future reference.
Should the appliance be sold or
transferred to another owner, or
should you move house and leave the
appliance, always ensure that the
book is supplied with the appliance in
order that the new owner can be
acquainted with the functioning of the
appliance and the relevant warnings.
If this appliance featuring magnetic door
seals is to replace an older appliance
having a spring lock (latch) on the door
or lid, be sure to make that spring lock
unusable before you discard the old
appliance. This will prevent it from
becoming a death-trap for a child.
These warnings are provided in the
interest of safety. You must read them
carefully before installing or using the
appliance.
General Safety
• This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible
for their safety.
Children should be supervised to
ensure that they do not play with
the appliance.
• It is dangerous to alter the
specifications or modify this
product in any way.
• Before any cleaning or maintenance
work is carried out, be sure to
switch off and unplug the appliance.
• This appliance is heavy. Care
should be taken when moving it
• Ice lollies can cause frost burns if
consumed straight from the
appliance.
• Take uutmost ccare wwhen hhandling yyour
appliance sso aas nnot tto ccause aany
damages tto tthe ccooling uunit ww
ith
consequent ppossible ffluid lleakages.
• The aappliance mmust nnot bbe llocated
close tto rradiators oor ggas ccoo
kers.
• Avoid pprolonged eexposure oof tthe
appliance tto ddirect ssunlight.
• There mmust bbe aadequate vventilation
round tthe bback oof tthe aappliance
and aany ddamage tto tthe rrefrigerant
circuit mmust bbe aavoided.
• For ffreezers
oonly ((except bbuilt-iin
models): aan iideal llocation iis tthe
cellar oor bbasement.
• Do nnot uuse oother eelectrica
l
appliances ((such aas iice ccream
makers) iinside oof rrefrigerating
appliances.
Service/Repair
• Any electrical work required to
install this appliance should be
carried out by a qualified electrician
or competent person
• This product should be serviced by an
authorized Service Centre, and only
genuine spare parts should be used.
• Under no circumstances should
you attempt to repair the appliance
yourself. Repairs carried out by
inexperienced persons may cause
injury or more serious
malfunctioning. Refer to your local
Service Centre, and always insist
on genuine spare parts.
• This appliance contains
hydrocarbons in its cooling unit;
electrolux
7
maintenance and recharging must
therefore only be carried out by
authorized technicians.
Use
• The domestic refrigerators and
freezers are designed to be used
specifically for the storage of edible
foodstuffs only.
• Best performance is obtained with
ambient temperature between +18°C
and +43°C (class T); +18°C and
+38°C (class ST); +16°C and +32°C
(class N); +10°C and +32°C (class
SN). The class of your appliance is
shown on its rating plate.
Warning: when the ambient
temperature is not included within
the range indicated for the class of
this appliance, the following
instructions must be observed:
when the ambient temperature
drops below the minimum level, the
storage temperature in the freezer
compartment cannot be
guaranteed; therefore it is advisable
to use the food stored as soon as
possible.
• Frozen food must not be re-frozen
once it has been thawed out.
• Manufacturers’ storage
recommendations should be strictly
adhered to. Refer to relevant
instructions.
• The inner lining of the appliance
consists of channels through which
the refrigerant passes. If these
should be punctured this would
damage the appliance beyond
repair and cause food loss. DO
NOT USE SHARP INSTRUMENTS
to scrape off frost or ice. Frost may
be removed by using the scraper
provided. Under no circumstances
should solid ice be forced off the
liner. Solid ice should be allowed to
thaw when defrosting the appliance.
• Do not place carbonated or fizzy
drinks in the freezer as it creates
pressure on the container, which
may cause it to explode, resulting
in damage to the appliance.
Installation
• During normal operation, the
condenser and compressor at the
back of the appliance heat up
considerably. For safety reasons,
minimum ventilation must be as
shown in the instructions.
Attention: kkeep vventilation oopenings
clear oof oobstruction.
• Care must be taken to ensure that
the appliance does not stand on
the electrical supply cable.
Important:
if the supply cord is
damaged, it must be replaced by a
special cord or assembly availa-ble
from the manufacturer or its service
agent.
• If the appliance is transported
horizontally, it is possible that the
oil contained in the compressor
flows in the refrigerant circuit. It is
advisable to wait at least two hours
before connecting the appliance to
allow the oil to flow back in the
compressor.
• There are working parts in this
product which heat up. Always
ensure that there is adequate
ventilation as a failure to do this will
result in component failure and
possible food loss. See installation
instructions.
8
electrolux
• Parts which heat up should not be
exposed. Wherever possible the
back of the product should be
against a wall.
Environment
Protection
This aappliance ddoes nnot ccontain
gasses wwhich ccould ddamage tthe
ozone llayer, iin eeither iits rrefrigerant
circuit oor iinsulation mmaterials. TThe
appliance sshall nnot bbe ddiscarded
together wwith tthe uurban rrefuse aand
rubbish. AAvoid ddamaging tthe ccooling
unit, eespecially aat tthe rrear nnear tthe
heat eexchanger. IInformation oon yyour
local ddisposal ssites mmay bbe oobtained
from mmunicipal aauthorities. TThe
materials uused oon tthis aappliance
marked bby tthe ssymbol aare
recyclable.
electrolux
9
USE
Cleaning the interior
Before using the appliance for the first
time, wash the interior and all internal
accessories with luke-warm water and
some neutral soap so as to remove
the typical smell of a brand-new
product, then dry thoroughly.
Do nnot uuse ddetergents oor
abrasive ppowders, aas tthese wwill
damage tthe ffinish.
Contrtol Panel
A. Thermostat
B. Button for D.A.C.
C. Light for D.A.C
D. Pilot light
Operation
Insert the plug into the wall socket.
Open the refrigerator door and turn
the thermostat knob, clockwise,
beyond the «O» (STOP) position.
The pilot light (D) will light up,
indicating that the appliance is
powered.
To stop operation, simply turn the
thermostat knob to position «O»
10
electrolux
Fresh food refrigeration
To obtain the best performance:
• do not store warm food or
evaporating liquids in the
refrigerator;
• do cover or wrap the food,
particularly if it has a strong flavour.
• Position food so that air can
circulate freely round it.
Temperature regulation
The temperature is automatically
regulated and can be increased to
achieve a higher temperature (warmer)
by rotating the thermostat knob
toward lower settings or reduced
(colder) rotating the knob towards
higher settings.
However, the exact setting should be
chosen keeping in mind that the
temperature inside the refrigerator
depends on:
• room temperature;
• how often the door is opened;
• the quantity of food stored;
• location of appliance.
A mmedium ssetting iis ggenerally tthe mmost
suitable.
Important
If tthe aambient ttemperature iis hhigh oor
the aappliance iis ffully lloaded, aand tthe
appliance iis sset tto tthe llowest
temperatures, iit mmay rrun ccontinuously
causing ffrost tto fform oon tthe rrear wwall.
In tthis ccase tthe ddial mmust bbe sset tto aa
higher ttemperature tto aallow aautomatic
defrosting aand ttherefore rreduced
energy cconsumption.
electrolux
11
Air recycling
The refrigerator compartment is
equipped with a special
D.A.C.(Dynamic Air Cooling) fan which
can be turned on with the switch B.
The yellow light (C), when on, means
that the fan is working.
It is suggested that the fan (D.A.C.) be
used when the ambient temperature
exceeds 25°C .
It should be remembered that the
thermostat knob A must be placed
within the sector
This device allows for rapid cooling of
foods and a more uniform temperature
in the compartment.
12
electrolux
Movable shelves
The walls of the refrigerator are
equipped with a series of runners so
that the shelves can be positioned as
desired.
Bottle rack
Place bottles in the rack with the
bottleneck to the front.
Important: Only store unopened
bottles horizontally.
The bottle rack can be tilted for storing
opened bottles.
To do this pull the bottle rack forward
until it can be tilted upwards, then
slide the front support into the next
level up.
Positioning the door
shelves
To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
To make these adjustments proceed
as follows: Gradually pull the shelf in
the direction of the arrows until it
comes free, then reposition as
required.
D338
electrolux
13
Drawer
The drawer is suitable for storing fruit
and vegetables. There is a separator
inside the drawer that can be placed in
different positions to allow for the
subdivision best suited to personal
needs.
There is a grille (if forseen) on the
bottom of the drawer to separate the
fruit and vegetables from any humidity
that may form on the bottom surface.
All parts inside the drawer can be
removed for cleaning purposes.
Humidity Control
The drawer incorporates a device with
slits (adjustable by means of a sliding
lever),which makes it possible to regulate
the temperature in the vegetable
drawer(s).
The opening in the ventilation slots can be
adjusted with the slider. Right slider:
Ventilation slots opened.
With the ventilation slots open, more air
circulation results in a lower air moisture
content in the fruit and vegetable
compartments. Left slider: Ventilation slots
closed. When the ventilation slots are
closed, the natural moisture content of the
food in the fruit and vegetable
compartments is preserved for longer.
PR271
14
electrolux
Ice-cube production
This appliance is equipped with one or
more trays for the production of icecubes.
These are insert on the sides of the
upper freezer drawer.
Pull out the upper freezer drawer.
Extract the ice-tray.
Pull out the tap.
Fill with water to the limit indicated.
“MAX”.
Refit the tap and insert the tray in the
appropriate place.
To remove the ice cubes rotate the tray
with the ice needles towards the top and
hit on a rigid surface.
To semplify the release of the ice needles
it is recommended to keep the closed
tray under if possible luke warm water for
a few seconds.
Do not use metallic instruments to
remove the ice cubes from the
tray.
electrolux
15
Thawing
Deep-frozen or frozen food, prior to
being used, can be thawed in the
refrigerator compartment or at room
temperature, depending on the time
available for this operation.
Small pieces may even be cooked still
frozen, directly from the freezer: in this
case, cooking will take longer.
Freezing fresh food
The 4-star compartment is
suitable for long term storage of
commercially frozen food, and for
freezing fresh food.
To freeze fresh foods it is not
necessary to change the setting of the
thermostat knob with respect to the
normal running position.
However, for a quicker freezing
operation, turn the thermostat knob to
the coldest setting; but remember
that, in this condition, the refrigerating
compartment temperature might drop
below 0°C.
If this occurs reset thermostat knob to
a warmer setting.
Storage of frozen food
When first starting-up or after a period
out of use, before putting the products
in the compartment let the appliance
run for at least two hours on the
coldest setting, then turn the
thermostat knob to the normal
operating position.
Important
In tthe eevent oof aaccidental ddefrosting,
for eexample ddue tto aa ppower ffailure, iif
the ppower hhas bbeen ooff ffor llonger tthat
the vvalue sshown iin tthe ttechnical
characteristics cchart uunder ““rising
time”, tthe ddefrosted ffood mmust bbe
consumed qquickly oor ccooked
immediately aand tthen rrefrozen ((after
cooling).
16
electrolux
Hints for freezing
To help you make the most of the
freezing process, here are some
important hints:
• Place the food to be frozen on the
upper drawer as this is the coldest
place.
• the maximum quantity of food
which can be frozen in 24 hrs. is
shown on the rating plate;
• the freezing process takes 24
hours. No further food to be frozen
should be added during this period;
• only freeze top quality, fresh and
thoroughly cleaned, foodstuffs;
• prepare food in small portions to
enable it to be rapidly and
completely frozen and to make it
possible subsequently to thaw only
the quantity required;
• wrap up the food in aluminium foil
or polythene and make sure that
the packages are airtight;
• do not allow fresh, unfrozen food to
touch food which is already frozen,
thus avoiding a rise in temperature
of the latter;
• lean foods store better and longer
than fatty ones; salt reduces the
storage life of food;
• water ices, if consumed
immediately after removal from the
freezer compartment, can possibly
cause the skin to be freeze burnt;
• it is advisable to show the freezingin date on each individual pack to
enable you to keep tab of the
storage time;
• do nnot pput ccarbonated lliquids ((fizzy
drinks, eetc.) iin tthe ffreezer
compartment aas tthey mmay bburst.
HINTS
Hints for refrigeration
Useful hints:
Meat ((all ttypes):
wrap in polythene
bags and place on the glass shelf
above the vegetable drawer.
For ssafety, sstore iin tthis wway oonly oone
or ttwo ddays aat tthe mmost.
Cooked ffoods, ccold ddishes, eetc..:
these should be covered and may be
placed on any shelf.
Fruit aand vvegetables:
these should be
thoroughly cleaned and placed in the
special drawer(s) provided.
Butter aand ccheese:
these should be
placed in special airtight containers or
wrapped in aluminium foil or polythene
bags to exclude as much air as
possible.
Milk bbottles:
these should have a cap
and should be stored in the bottle rack
on the door.
Bananas, ppotatoes, oonions aand ggarlic,
if nnot ppacked, mmust nnot bbe kkept iin tthe
refrigerator.
electrolux
17
Interior light
If it becomes necessary to replace the
lamp, pressing as shown in the figure.
Attention
Replace the lamp with one of the same
power (the maximum power is shown
on the light diffuser).
Hints for storage of
frozen food
To obtain the best performance from
this appliance, you should:
• make sure that the commercially
frozen foodstuffs were adequately
stored by the retailer;
• be sure that frozen foodstuffs are
transferred from the foodstore to
the freezer in the shortest possible
time;
• not open the door frequently or
leave it open longer than absolutely
necessary.
• Once defrosted, food deteriorates
rapidly and cannot be refrozen.
• Do not exceed the storage period
indicated by the food manufacturer.
18
electrolux
MAINTENANCE
Unplug tthe aappliance bbefore
carrying oout aany mmaintenance
operation.
Warning
This appliance contains hydrocarbons in
its cooling unit; maintenance and
recharging must therefore only be carried
out by authorized technicians.
Periodic cleaning
Many pproprietary kkitchen ssurface
cleaners ccontain cchemicals tthat ccan
attack/damage tthe pplastics uused iin
this aappliance. FFor tthis rreason iit iis
recommended tthat tthe oouter ccasing oof
this aappliance iis oonly ccleaned wwith
warm wwater wwith aa llittle wwashing-uup
liquid aadded.
Clean the inside with warm water and
bicarbonate of soda.
Rinse and dry thoroughly.
Clean the condenser (black grill) and
the compressor at the back of the
appliance with a brush or a vacuum
cleaner. This operation will improve the
performance of the appliance and
save electricity consumption.
Defrosting
Frost is automatically eliminated from
the evaporator of the refrigerator
compartment every time the motor
compressor stops, during normal use.
The defrost water drains out through a
trough into a special container at the
back of the appliance, over the motor
compressor, where it evaporates.
It iis iimportant tto pperiodically cclean tthe
defrost wwater ddrain hhole iin tthe mmiddle
of tthe rrefrigerator ccompartment
channel tto pprevent tthe wwater
overflowing aand ddripping oonto tthe ffood
inside. UUse tthe sspecial ccleaner
provided, wwhich yyou wwill ffind aalready
inserted iinto tthe ddrain hhole.
Freezer
Your appliance is frost free, which
means there is no need to manually
defrost your appliance as this will be
carried out automatically.
D037
electrolux
19
CUSTOSERVICE AND
SPARE PARTS
If the appliance is not functioning
properly, check that:
• the plug is firmly in the wall socket
and the mains power switch is on;
• there is an electricity supply (find
out by plugging in another
appliance);
• the temperature is set correctly.
• If there are water drops on the
bottom of the cabinet, check that
the defrost water drain opening is
not obstructed (see “Defrosting”
section).
• If your appliance is still not working
properly after making the above
checks, contact the nearest service
centre.
To obtain fast service, it is essential
that when you apply for it you specify
the model and serial number of your
appliance which can be found on the
guarantee certificate or on the rating
plate located inside the appliance, on
the bottom left-hand side.
TECHNICAL INFORMATION
305
102
1,112
406
1950
695
661
Net Fridge Capacity lt.
Energy Consumption kWh/24h
Energy Consumption kWh/year
Dimensions mm
High
Net Freezer Capacity lt
Width
Depth
The technical infomation are situated in the rating plate on the internal left side of
the appliance.
20
electrolux
Shelf holders
Your appliance is equipped with shelf
retainers that make it possible to
secure the shelves during
transportation.
To remove them proceed as follows:
Move the shelf holders in the direction
of the arrow, raise the shelf from the
rear and push it forward until it is freed
and remove the retainers.
INSTALLATION
Location
The appliance should be installed well
away from sources of heat such as
radiators, boilers, direct sunlight etc.
Ensure that air can circulate freely
around the back of the cabinet. To
ensure best performance, if the
appliance is positioned below an
overhanging wall unit, the minimum
distance between the top of the
cabinet and the wall unit must be at
least 100 mm . Ideally, however, the
appliance should not be positioned
below overhanging wall units. Accurate
levelling is ensured by one or more
adjustable feet at the base of the
cabinet.
Attention
It must be possible to disconnect
the appliance from the mains power
supply; the plug must therefore be
easily accessible after installation.
Rear spacers
In tthe aappliance, tthere aare ttwo sspacers
which mmust bbe ffitted aas sshown iin tthe
figure ..
Slacken the screws and insert the
spacer under the screw head, then retighten the screws.
NP008
100 mm15 mm
15 mm
A
B
A
B
C
electrolux
21
Electrical connection
Before plugging in, ensure that the
voltage and frequency shown on the
serial number plate correspond to your
domestic power supply. Voltage can
vary by ±6% of the rated voltage.
For operation with different voltages, a
suitably sized auto-transformer must
be used.
The aappliance mmust bbe eearthed.
The power supply cable plug is provided
with a contact for this purpose.
If the domestic power supply socket is
not earthed, connect the appliance to
a separate earth in compliance with
current regulations, consulting a
specialist technician.
The MManufacturer ddeclines aall
responsibility iif tthe aabove ssafety
precautions aare nnot oobserved.
This appliance complies with
the following E.E.C. Directives:
•
87/308 EEEC
of 2/6/87 relative to
radio interference suppression.
•
73/23 EEEC
of 19.2.73 (Low Voltage
Directive) and subsequent
modifications;
•
89/336 EEEC
of 3.5.89
(Electromagnetic Compatibility
Directive) and subsequent
modifications.
Door reversibility
The side at which the door opens can be
changed from the right side (factory
adjustment) to the left side, if the
installation site requires.
Warning!
When changing the side
at which the door opens, the appliance
may not be connected to the mains.
Remove plug from the mains beforehand.
Procced aas ffollows:
To carry out the following operations, we
suggest that this be made with another
person that will keep a firm hold on the
doors of the appliance during the
operations.
Before carrying out any operations,
remove the plug from the power
socket.
1. Remove the upper hinge taking
care for the upper door not to fall
off and keep it for future actions;
2. remove the upper door;
3. Remove the upper support and
mount it in the opposite side
4. unscrew the middle hinge.(H)
Unscrew the plastic plugs located on
the opposite side of the central hinge
and introduce them in the holes
occupied before by the hinge;
22
electrolux
11.Carefully replace the appliance in its
working position and adjust the
level of the appliance by screwing/
unscrewing the adjustable feet at
the bottom of the cabinet using
your fingers or a tool;
12.Slide the hole cover out of the
ventilation grille by pushing it in the
direction of the arrow and
reassemble it on the opposite side;
13.refit the ventilation grille, fixing the
screws;
14.reassemble the lower door;
15.reassemble the middle hinge (H) in
the opposite side;
16.reassemble the upper door.
17.In your documentation bag you will
find the upper hinge necessary to
make the reversibility. Please screw
it in place.
5. remove the lower door;
6. pull off the ventilation grille which is
fixed by two screws;
7. Carefully place the appliance on its
back, totally unscrew the adjustable
foot and screw it in the opposite
side.
8. remove the bottom hinge by
unscrewing its fixing screws;
9. using a 12 mm spanner, unscrew
the hinge pin and reassemble it on
the opposite side of the hinge;
10.reassemble the lower hinge in the
opposite side, using the screws
previously removed;
H
electrolux
23
18.Dismount the handle cover making
pressure and using a screwdriver.
Dismantle the handles and reassemble
them on the opposite side. Cover the
holes with the plastic lids that were
situated where the handles are
presently.Place the handle cover.
Warning:
After hhaving rreversed tthe oopening
direction oof tthe ddoors ccheck tthat aall tthe
screws aare pproperly ttightened aand tthat
the mmagnetic sseal aadheres tto tthe
cabinet.
If the ambient temperature is
cold (i.e. in Winter), the gasket may not
fit perfectly to the cabinet. In that case,
wait for the natural fitting of the gasket
or accelerate this process by heating
up the part involved with a normal
hairdrier.
24
electrolux
EUROPEAN GUARANTEE
This appliance is guaranteed by Electrolux in each of the countries listed at the
back of this user manual, for the period specified in the appliance guarantee or
otherwise by law. If you move from one of these countries to another of the
countries listed, the appliance guarantee will move with you subject to the
following qualifications:
• The appliance guarantee starts from the date you first purchased the appliance
which will be evidenced by production of a valid purchase document issued by
the seller of the appliance.
• The appliance guarantee is for the same period and to the same extent for
labour and parts as exists in your new country of residence for this particular
model or range of appliances.
• The appliance guarantee is personal to the original purchaser of the appliance
and cannot be transferred to another user.
• The appliance is installed and used in accordance with instructions issued by
Electrolux and is only used within the home, i.e. is not used for commercial
purposes.
• The appliance is installed in accordance with all relevant regulations in force
within your new country of residence.
The provisions of this European Guarantee do not affect any of the rights granted
to you by law.
Loading...
