AEG EHH9967FOG User Manual
EHH9967FOG
................................................ .............................................
EN HOB USER MANUAL 2
DE KOCHFELD BENUTZERINFORMATION 20
www.electrolux.com
2
CONTENTS
1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8.
INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
9. TECHNICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
10.
ENVIRONMENT CONCERNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it
decades of professional experience and innovation. Ingenious and stylish, it has been designed
with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great
results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.electrolux.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with
the appliance for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they are supervised by an adult or a person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
• If the appliance has a child safety device, we recommend that you activate it.
• Cleaning and user maintenance shall not be made by
children without supervision.
ENGLISH 3
1.2 General Safety
• The appliance and its accessible parts become hot
during use. Do not touch the heating elements.
• Do not operate the appliance by means of an external
timer or separate remote-control system.
• Unattended cooking on a hob with fat or oil can be
dangerous and may result in fire.
www.electrolux.com
4
• Never try to extinguish a fire with water, but switch off
• Do not store items on the cooking surfaces.
• Do not use a steam cleaner to clean the appliance.
• Metallic objects such as knives, forks, spoons and lids
• If the glass ceramic surface is cracked, switch off the
• After use, switch off the hob element by its control and
the appliance and then cover flame e.g. with a lid or a
fire blanket.
should not be placed on the hob surface since they
can get hot.
appliance to avoid the possibility of electric shock.
do not rely on the pan detector.
2.
SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appli-
ance.
• Obey the installation instruction sup-
plied with the appliance.
• Keep the minimum distance from the
other appliances and units.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Seal the cut surfaces with a sealant to
prevent moisture to cause swelling.
• Protect the bottom of the appliance
from steam and moisture.
• Do not install the appliance adjacent to
a door or under a window. This prevents hot cookware to fall from the appliance when the door or the window is
opened.
• If the appliance is installed above draw-
ers make sure that the space, between
the bottom of the appliance and the up-
per drawer, is sufficient for air circulation.
• Make sure that the ventilation space of
2 mm, between the worktop and the
front of the below unit, is free. The warranty does not cover damages caused
by the lack of an adequate ventilation
space.
• The bottom of the appliance can get
hot. We recommend to install a noncombustile separation panel under the
appliance to prevent access to the bottom.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections must be made
by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure the mains cable or plug (if
applicable) does not touch the hot ap-
pliance or hot cookware, when you
connect the appliance to the near sockets
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Make sure that a shock protection is installed.
• Use the strain relief clamp on cable.
• Make sure not to cause damage to the
mains plug (if applicable) or to the
mains cable. Contact the Service or an
electrician to change a damaged mains
cable.
• The electrical installation must have an
isolation device which lets you disconnect the appliance from the mains at all
poles. The isolation device must have a
contact opening width of minimum 3
mm.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
2.2 Use
WARNING!
Risk of injury, burns or electric
shock.
• Use this appliance in a household environment.
• Do not change the specification of this
appliance.
• Do not use an external timer or a separate remote-control system to operate
the appliance.
• Do not let the appliance stay unattended during operation.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not put cutlery or saucepan lids on
the cooking zones. They can become
hot.
• Set the cooking zone to “off” after each
use. Do not rely on the pan detector.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is
cracked, disconnect immediately the
ENGLISH 5
appliance from the power supply. This
to prevent an electrical shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the appliance is in operation.
WARNING!
Risk of fire or explosion.
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food remnants, can cause fire at a lower temperature than oil used for the first time.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
• Do not try to extinguish a fire with water. Disconnect the appliance and cover
the flame with a lid or a fire blanket.
WARNING!
Risk of damage to the appliance.
• Do not keep hot cookware on the control panel.
• Do not let cookware to boil dry.
• Be careful not let objects or cookware
fall on the appliance. The surface can
be damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the appliance.
• Cookware made of cast iron, aluminium
or with a damaged bottom can cause
scratches on the glass ceramic. Always
lift these objects up when you have to
move them on the cooking surface.
2.3 Care and Cleaning
WARNING!
Risk of damage to the appliance.
• Clean regularly the appliance to prevent
the deterioration of the surface material.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
www.electrolux.com
6
not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
2.4 Disposal
WARNING!
Risk of injury or suffocation.
3. PRODUCT DESCRIPTION
3.1 General overview
• Contact your municipal authority for information on how to discard the appliance correctly.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
1 2
67 5
3
Induction cooking zone
1
Induction cooking zone
2
Induction cooking zone
3
Induction cooking zone
4
Induction cooking zone
5
Induction cooking zone
6
Control panel
7
4
3.2 Control panel layout
7 8 1110 1252 3 4
961
141517 1316
Use the sensor fields to operate the appliance. The displays, indicators and
sounds tell which functions operate.
sensor field function
1
2
3
4
To activate and deactivate the appliance.
To lock and unlock the control panel.
To activate and deactivate the STOP+GO
function.
To activate the Chef function.
sensor field function
A heat setting display To show the heat setting.
5
Timer indicators of cooking
6
zones
Timer display To show the time in minutes.
7
8
To show for which of the cooking zones
you set the time.
To show that the Count Up operates (1
to 59 minutes).
9
To show that the Count Down Timer operates (1 to 99 minutes) or the Minute
Minder operates.
10
To show for which of the cooking zones
you set the heat setting.
11
To show that the cookware is incorrect,
the diameter of the bottom of the cookware is to small or there is no cookware
on the cooking zone.
12
To activate and deactivate the Bridge
function.
13
To activate and deactivate the Power
function.
14
15
/
To increase or decrease the time.
To set the cooking zone for the Timer
function.
16
Control bar To set the heat setting.
17
To set the Timer functions.
ENGLISH 7
3.3 Heat setting displays
Display Description
The cooking zone is deactivated.
-
+ digit
/ /
The cooking zone operates.
The function operates.
The Automatic Heat Up function operates.
Power function operates.
There is a malfunction.
OptiHeat Control (3 step Residual heat indicator) : continue cook / stay warm / residual heat.
Lock / The Child Safety Device operates.
Not correct cookware or too small or no cookware on the
cooking zone.
The Automatic Switch Off function operates.
www.electrolux.com
8
3.4 OptiHeat Control (3 step
Residual heat indicator)
WARNING!
from residual heat!
4. DAILY USE
\ \ The risk of burns
OptiHeat Control shows the level of the
residual heat. The induction cooking
zones make the heat necessary for cooking directly in the bottom of the cookware.
The glass ceramic is hot from the heat of
the cookware.
4.1 Activation and deactivation
Touch for 1 second to activate or deactivate the appliance.
4.2 Automatic Switch Off
The function deactivates the
appliance automatically if:
•
All cooking zones are deactivated (
).
• You do not set the heat setting after
you activate the appliance.
• You spill something or put something
on the control panel for more than 10
seconds, (a pan, a cloth, etc.). An
acoustic signal sounds some time and
the appliance deactivates. Remove the
object or clean the control panel.
• The appliance becomes too hot (e.g.
when, a saucepan boils dry). Before
you use the appliance again, wait for
the cooking zone to cool down.
• You use incorrect cookware. The sym-
comes on and the cooking zone
bol
deactivates automatically after 2 minutes.
• You do not deactivate a cooking zone
or change the heat setting. After some
comes on and the appliance
time
deactivates. See below.
• The relation between heat setting and
times of the Automatic Switch Off function:
•
, - — 6 hours
•
- — 5 hours
•
- — 4 hours
•
- — 1.5 hours
4.3 The heat setting
Touch the control bar at the heat setting.
Move your finger along the control bar to
change the setting. Do not release before
you have a correct heat setting. The display shows the heat setting.
When you use cookware larger than 180
mm the manufacturer recommends that
you put it on the rear cooking zones.
4.4 Bridge function
The Bridge function connects two cooking zones and they operate as one. You
can use this function for cookware larger
than 260 mm.
First set the heat setting for one of the
cooking zones.
To activate the Bridge function touch
and the indicator comes on. To set or
change the heat setting, touch one of the
control sensors.
To deactivate the Bridge function touch
and the indicator goes off. The cook-
ing zones operate independently.
4.5 Automatic Heat Up
You can get a necessary heat setting in a
shorter time if you activate the Automatic
Heat Up function. This function sets the
highest heat setting for some time (see
the diagram), and then decreases to the
necessary heat setting.
To start the Automatic Heat Up function
for a cooking zone:
1.
Touch ( comes on in the display).
2.
Immediately touch the necessary heat
setting. After 3 seconds
comes on
in the display.
To stop the function change the heat setting.
12
11
10
9
8
7
6
5
4
3
2
1
0
1 2 3 4 5 6 7 8 9 101112 1314
4.6 Power function
The Power function makes more power
available to the induction cooking zones.
The Power function can be activated for a
limited period of time ( see Technical Information chapter). After that, the induction cooking zone automatically sets back
to highest heat setting. To activate, touch
, comes on. To deactivate, change
the heat setting.
ENGLISH 9
4.8 Chef function
The Chef function activates all cooking
zones and automatically activates the
Bridge function for all of the zones. This
function sets the same heat setting as the
one you set the last time.
For the first activation the heat setting of
the left pair of zones is set to
middle pair is set to
is set to
.
and the right pair
To activate this function:
•
Touch
, and the indicator comes on.
All cooking zones operate for 9 minutes. If the cooking zones stay empty,
the symbol
comes on. After 9 mi-
nutes an acoustic signal sounds and
the empty cooking zones are set to
.
To resume this function:
•
Touch
to put or move cookware on
the deactivated pair of cooking zones.
To deactivate this function:
•
Touch
to deactivate the Chef function for the cooking zones you chose
and keep the last heat setting of the
cooking zones for this pair. The indicator goes off.
•
Set the heat setting to
Count Down Timer deactivate the
cooking zones. The indicator goes off.
, the
or let the
4.7 Power management
The power management divides the power between two cooking zones in a pair
(see the illustration). The power function
increases the power to the maximum level
for one cooking zone in the pair. The
power in the second cooking zone automatically decreases. The heat setting display for the reduced zone changes between two levels.
When the Chef function is off, the pot detection time is 2 minutes.
4.9 The Timer
The Count Down Timer.
Use the Count Down Timer to set how
long the cooking zone operates for only
this operation.
Set the Count Down Timer after the
selection of the cooking zone.
The selection of the Timer function
is possible for cooking zones that
are active and after the heat setting is set.
00
00
www.electrolux.com
10
•
•
• To see the remaining time: set the
• To change the Count Down Timer:
• To deactivate the Count Down
When the timer countdown comes to an
end, the sound operates and
es. The cooking zone deactivates.
•
The Count Up timer
Use the Count Up timer to monitor how
long the cooking zone operates.
•
•
•
To set the cooking zone: touch
again and again until the indicator of the
necessary cooking zone comes on.
When this function is activated,
comes on.
To activate the Count Down Timer:
touch
00
of the cooking zone starts to flash slowly, the time counts down.
cooking zone with
the cooking zone starts to flash quickly.
The display shows the remaining time.
set the cooking zone with
Time: set the cooking zone with
and touch . The remaining time
counts down to
the cooking zone goes out.
To deactivate the sound: touch
The selection of the cooking zone
(if more than 1 cooking zone oper-
ates): touch
the indicator of the necessary cooking
zone comes on.
When this function is activated,
comes on.
To activate the Count Up timer:
Touch
The symbol
on.
To see how long the cooking zone
operates: set the cooking zone with
starts to flash quickly. The display
shows how long the zone has operated. During the first minute the display
shows the time in seconds, and after
the first minute the display shows the
time in minutes. The display shows the
of the timer to set the time (
- 99 minutes). When the indicator
. The indicator of
and touch
or .
. The indicator of
flash-
.
again and again until
.
goes out and comes
. The indicator of the cooking zone
length of time of the cooking zone
which has operated for the longer period of time.
• To deactivate the Count Up timer:
set the cooking zone with
or to deactivate the timer. The
symbol
goes out and comes on.
When the two Timer functions operate at the same time, the display
shows the Count Up Timer first.
and touch
The Minute minder.
You can use the timer as the minute
minder when the cooking zones are not
in operation. Touch
Touch
time. When the time comes to an end, the
sound operates and
•
or of the timer to set the
To stop the sound: touch .
.
00
flashes.
4.10 STOP+GO
The function sets all cooking zones
that operate to the lowest heat setting (
).
When
the heat setting.
The
function.
•
•
operates, you cannot change
function does not stop the timer
To activate this function touch
The symbol
To deactivate this function touch .
The heat setting that you set before
comes on.
comes on.
.
4.11 Lock
When the cooking zones operate, you
can lock the control panel, but not
prevents an accidental change of the heat
setting.
First set the heat setting.
To start this function touch
bol
comes on for 4 seconds.
The Timer stays on.
To stop this function touch
setting that you set before comes on.
When you stop the appliance, you also
stop this function.
. It
. The sym-
. The heat
4.12 The Child Safety Device
This function prevents an accidental operation of the appliance.
To activate The Child Safety Device
•
Activate the appliance with
set the heat settings.
•
Touch
•
Deactivate the appliance with .
To deactivate The Child Safety Device
•
Activate the appliance with
set the heat settings. Touch
seconds. The symbol
•
Deactivate the appliance with
To override The Child Safety Device
for only one cooking time
•
Activate the appliance with
symbol
•
Touch for 4 seconds. Set the heat
setting in 10 seconds. You can operate the appliance.
• When you deactivate the appliance with
again.
for 4 seconds. The symbol
comes on.
comes on.
, The Child Safety Device operates
. Do not
. Do not
for 4
comes on.
.
. The
ENGLISH 11
Touch
come on and go out. Touch
onds.
Touch
When this function operates, you can hear
the sounds only when:
•
• the Minute Minder comes down
• the Count Down Timer comes down
• you put something on the control panel.
for 3 seconds. The displays
for 3 sec-
comes on, the sound is on.
, comes on, the sound is off.
you touch
Activation of the sounds
Deactivate the appliance.
Touch
come on and go out. Touch
onds.
is off. Touch
sound is on.
for 3 seconds. The displays
for 3 sec-
comes on, because the sound
, comes on. The
4.13 OffSound Control
(Deactivation and activation of
the sounds)
Deactivation of the sounds
Deactivate the appliance.
5. HELPFUL HINTS AND TIPS
INDUCTION COOKING ZONES
For induction cooking zones a strong
electro-magnetic field creates the heat in
the cookware very quickly.
5.1 Cookware for induction
cooking zones
Use the induction cooking zones
with correct cookware.
Cookware material
• correct: cast iron, steel, enamelled
steel, stainless steel, the bottom made
of multi-layer (with correct mark from a
manufacturer).
• not correct: aluminium, copper, brass,
glass, ceramic, porcelain.
Cookware is correct for an induction
hob if …
• ... some water boils very quickly on a
zone set to the highest heat setting..
www.electrolux.com
12
• ... a magnet pulls on to the bottom of
5.2 Use of the cooking zones
Put the cookware on the square which is
on the surface that you cook. Cover the
square fully. The magnetic part of the bottom of the cookware must be 125 mm
minimum. Induction cooking zones adapt
to the dimension of the bottom of the
cookware automatically. You can cook
with the large cookware on two cooking
zones at the same time.
5.3 The noises during operation
If you can hear
• crack noise: cookware is made of dif-
• whistle sound: you use one or more
• humming: you use high power levels.
• clicking: electric switching occurs.
• hissing, buzzing: the fan operates.
The noises are normal and do not refer to appliance malfunction.
5.4 Energy saving
He
at
set
tin
g
1
1 -3Hollandaise sauce,
the cookware.
The bottom of the cookware
must be as thick and flat as possible.
IMPORTANT
• If it is possible, always put the lids on
the cookware.
• Put cookware on a cooking zone before you start it.
• Use the residual heat to keep the food
warm or to melt it.
The cooking zone efficiency
The cooking zone efficiency is related to
the diameter of the cookware. The cookware with a smaller diameter than the
minimum receives only a part of the power generated by the cooking zone. For the
minimum diameters see the Technical Information chapter.
5.5 Öko Timer (Eco Timer)
To save energy, the heater of the
cooking zone deactivates before
the count down timer sounds. The
difference in the operation time
depends on the heat setting level
ferent materials (Sandwich construction).
cooking zones with high power levels
and the cookware is made of different
materials (Sandwich construction).
How to save energy
Use to: Time Hints Nominal
Keep warm the food
as required Put a lid on a cook-
you cooked
5 - 25 min Mix from time to time 3 – 8 %
melt: butter, chocolate,
gelatine
and the length of the cooking operation.
5.6 The Examples of cooking
applications
The relation between the heat setting and
the cooking zone consumption of power
is not linear.
When you increase the heat setting it is
not proportional to the increase of the
cooking zone consumption of power.
It means that the cooking zone with the
medium heat setting uses less than a half
of its power.
The data in the table is for guidance only.
ware
power
consumption
3 %
Loading...
