Page 1
BE7314401
OVEN USER MANUAL
EN
Page 2
2
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have
created it to give you impeccable performance for many
years, with innovative technologies that help make life
simpler – features you might not find on ordinary
appliances. Please spend a few minutes reading to get the
very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to
keep all your AEG appliances looking spotless and
working perfectly. Along with a wide range of accessories
designed and built to the high quality standards you
would expect, from specialist cookware to cutlery baskets,
from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg.com/shop
Page 3
CONTENTS
4 Safety information
7 Product description
9 Before first use
10 Control panel
12 Daily use
14 Clock functions
16 Automatic programmes
18 Using the accessories
21 Additional functions
23 Care and cleaning
26 Technical data
27 What to do if…
28 Environment concerns
Contents
3
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
Page 4
4 Safety information
SAFETY INFORMATION
Before the installation and use, read this manual carefully:
• For your personal safety and the safety of your property
• For the respect of the environment
• For the correct operation of the appliance.
Always keep these instructions with the appliance also if you move or sell it.
The manufacturer is not responsible if incorrect installation or use results in damage.
Children and vulnerable people safety
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in safe
way and understand the hazards involved. Children shall not play with the appliance.
• Keep all packaging away from children. There is the risk of suffocation or physical injury.
• WARNING: Keep children and animals away from the appliance when the door is open
or the appliance is in the operation, because it becomes hot. There is the risk of injury or
other permanent disability.
• If the appliance has Child Lock or Key Lock (Control Lock) function, use it. It prevents
children and animals from accidental operation of the appliance.
General safety
• Do not change the specifications of this appliance. There is the risk of injury and damage
to the appliance.
• Do not let the appliance stay unattended during operation.
• Switch off the appliance after each use.
Installation
• Only an approved electrician can install and connect the appliance. Contact an approved
service centre. This is to prevent the risks of structural damage or physical injury.
• Make sure that the appliance is not damaged because of transport. Do not connect a
damaged appliance. If necessary, contact the supplier.
• Remove all packaging, stickers and layers from the appliance before first use. Do not remove the rating plate. It can invalidate the guarantee.
• Make sure that the appliance is disconnected from the power supply during the installation.
• Be careful when you move the appliance. The appliance is heavy. Always use safety
gloves. Do not lift the appliance by the handle.
• The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening
width of minimum 3 mm.
• You must have correct isolation devices: line protecting cut-outs, fuses (screw type fuses
removed from the holder), earth leakage trips and contactors.
Page 5
Safety information
• Before the installation, make sure that the kitchen cabinet has the recess dimensions applicable.
• Make sure that the appliance is installed below and adjacent safe structures.
• Keep the minimum distances to the other appliances and units.
• The appliance cannot be positioned on a base.
• Built in ovens and built in cooking surfaces are attached with special connection system.
To prevent damage to the appliance, only use an appliance with the appliances from the
same manufacturer.
Electrical connection
• The appliance must be earthed.
• Make sure that the electrical data on the rating plate agree with your domestic power
supply.
• Information on the voltage is on the rating plate.
• Always use a correctly installed shockproof socket.
• Do not use multi-way plugs, connectors and extension cables. There is the risk of fire.
• Do not replace or change the mains cable. Contact the service centre.
• Make sure not to squash or cause damage to the mains plug (if applicable) and cable
behind the appliance.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug – if
applicable.
Use
• The appliance is only for domestic use. Do not use the appliance for commercial and industrial use.
• Only use the appliance for domestic cooking tasks. This is to prevent physical injury to
persons or prevent damage to property.
• Do not use the appliance as a work surface or storage surface.
• The interior of the appliance becomes hot during use. There is the risk of burns. Do not
touch the heating elements in the appliance. Use gloves when you insert or remove the
accessories or pots.
• Be careful when you remove or install the accessories to prevent damage to the oven
enamel.
• Always stay away from the appliance when you open the door while the appliance is in
operation. Hot steam can release. There is the risk of skin burns.
• To prevent damage or discoloration to the enamel:
– do not put any objects directly on the appliance floor and do not cover it with alumi-
nium foil;
– do not put hot water directly into the appliance;
– do not keep moist dishes and food in the appliance after you finish the cooking.
• Discoloration of the enamel has no effect on the performance of the appliance so it is
not a defect in the sense of the warranty law.
• Do not apply pressure on the open door.
5
Page 6
6 Safety information
• Always close the appliance door when you cook, even while grilling.
Care and cleaning
• Before maintenance, switch off the appliance and disconnect the appliance from the
power supply.
• Before maintenance, make sure that the appliance is cold. There is the risk of burns.
There is the risk that the glass panels can break.
• Keep the appliance clean at all times. A build-up of fats or other foodstuff can result in a
fire.
• Regular cleaning prevents the surface material from deteriorating
• Use a deep baking tray for very moist cakes to prevent that fruit juices cause stains that
can be permanent.
• For your personal safety and the safety of your property, only clean the appliance with
water and a soap. Do not use flammable products or products that can cause corrosion.
• Do not clean the appliance with steam cleaners, high-pressure cleaners, sharp objects,
abrasive cleaning agents, abrasive sponges and stain removers
• If you use an oven spray, follow the instructions from the manufacturer.
• Do not clean the glass door with abrasive cleaning agents or metal scraper. Heat resistant surface of the inner glass can break and shatter.
• When the door glass panels are damaged they become weak and can break. You must
replace them. Contact the service centre.
• Be careful when you remove the door from the appliance. The door is heavy!
• Do not clean catalytic enamel (if applicable).
Risk of fire
• Open the door carefully. The use of ingredients with alcohol can cause a mixture of alcohol and air. There is the risk of fire.
• Do not let sparks or open flames come near the appliance when you open the door.
• Do not put flammable products or items that are wet with flammable products, and/or
fusible objects (made of plastic or aluminium) in, near or on the appliance.
Oven lamp
• Bulb lamps used in this appliance are special lamps selected for household appliances use
only. They cannot be used for the full or partial illumination of a household room.
• If it becomes necessary to replace the lamp use one of the same power and specifically
designed for household appliances only.
• Disconnect the appliance from the power supply before the replacement of the oven
lamp. There is the risk of electrical shock.
Service centre
• Only an approved engineer can repair or work on the appliance. Contact an approved
service centre.
• Use only original spare parts.
Page 7
Disposal of the appliance
• To prevent the risk of physical injury or damage
– Disconnect the appliance from the power supply.
– Cut off the mains cable and discard it.
– Discard the door catch. This prevents children or small animals from being closed in-
side of the appliance. There is the risk of suffocation.
PRODUCT DESCRIPTION
General overview
1
5
4
Product description
2
3
4
5
7
10
3
2
1
1 Control panel
2 Electronic programmer
3 Socket for the core temperature sensor
4 Heating element
5 Oven lamp
6 Fan
7 Rear wall heating element
8 Bottom heat
9 Shelf support, removable
10 Shelf positions
6
7
8
9
Page 8
8 Product description
Oven accessories
• Wire shelf
For cookware, cake tins, roasts.
• Baking tray
For cakes and biscuits.
• Combi pan
For cake and biscuits. To bake and roast or as
pan to collect fat.
• Core Temperature Sensor
To measure how far the food is cooked.
Page 9
Before first use 9
• Telescopic runners
For shelves and trays.
BEFORE FIRST USE
WARNING!
Refer to "Safety information" chapter.
Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
Refer to chapter "Care and Cleaning".
First connection to the mains
After first connection to the mains all symbols in the display are on for some seconds. For
the subsequent few seconds the display shows software version.
First setting the time of day
After the software version goes off, the display shows "h" and "12:00".
Setting the time of day:
1. Touch
2. Touch
3. Touch
4. Touch
The Temperature/Time display shows new time.
Changing the time of day
You can change the time of day only if the appliance is off.
Touch
or to set hours.
or .
or to set minutes.
or .
. flashes in the display. To set new time of day use the above procedure.
Page 10
10 Control panel
CONTROL PANEL
Electronic programmer
1
2 3 4 5 6 7 8 9 10
Use the sensor fields to operate the appliance.
Sensor Field Function Description
1
2
- DISPLAY Shows the current settings of the appliance.
ON/OFF To activate and deactivate the appliance.
3
OPTIONS To set an oven function or programme.
Straight access to the oven function when the
appliance is off.
4
MY FAVOURITE PRO-
GRAMME
You can store your favourite programme. Use it
to access your favourite programme directly, also
when the appliance is off.
5
TEMPERATURE / FAST
HEAT UP
To set and examine cavity temperature or core
temperature sensor temperature. If you press it
and hold for three seconds, it turns Fast heat up
function ON and OFF.
Straight access to the temperature setting of
the first oven function when the appliance is
off.
6
UP, DOWN To choose an oven function, clock function and
to set the minute minder, temperature or time of
day.
7
8
9
10
OK To confirms the selection or setting.
OVEN LIGHT To set the oven lamp on or off.
CLOCK To set the clock function.
MINUTE MINDER To set the minute minder.
Page 11
Display
Control panel
1 2 3
11
1 Oven function symbol
2 Temperature/Time display
3 Clock/Residual heat display (also Minute minder and Time of day)
4 Residual heat indicator
5 Indicators for the clock functions (refer to the table "Clock functions")
6 Heat up indicator
7 Number of oven function/programme
Other indicators of display
Symbols Name Description
Options You can choose an oven function.
Automatic programme You can choose an oven programme.
My favourite programme The favourite programme operates.
kgr/gr An oven programme with weight input operates.
/
/
h/min A clock function operates.
Temperature / fast heat up The function operates.
Temperature You can examine or change the temperature.
Core temperature sensor The core temperature sensor is in the core temperature
Oven light The light is off.
Minute minder The minute minder function operates.
6
sensor socket.
5 47
Heat up indicator
If you set an oven function, the bars in the display come on one by one. The bars show
that the temperature in the appliance increases or decreases.
When the appliance is at the set temperature Heat up indicator goes off the display.
Page 12
12 Daily use
DAILY USE
WARNING!
Refer to "Safety information" chapter.
To operate the appliance you can use:
• manual mode -to set an oven function, the temperature and the cooking time manually.
• automatic programmes -to prepare a dish when you do not have a knowledge or experience in cooking.
Setting the oven function
1. Touch .
The display shows a preset temperature, symbol and number of the oven function.
flashes in the display.
2. Touch
3. Touch
If you activate the appliance with or and do not set any oven function or programme
the appliance will deactivate automatically after 20 seconds.
1 True Fan Cooking To bake maximum on three shelf positions at the same time.
2 Pizza Setting To bake on one shelf position food with a more intensive
3 Slow Cook To prepare very lean, tender roasted food.
or to set an oven function.
or the appliance starts automatically after five seconds.
Oven function Application
Decrease the oven temperatures (20-40 °C) compared with
Conventional. And to dry food.
browning and a crispy base. Decrease the oven temperatures
(20-40 °C) compared with Conventional cooking.
4 Conventional
Cooking
5 Frozen Foods To make your convenience food like e.g. French Fries, Wedg-
6 Turbo Grilling To roast larger meat joints or poultry with bones on one
7 Fast Grilling To grill flat food in large quantities. To toast bread.
8 Grilling To grill flat food in the middle of the grill. To toast bread.
9 Keep Warm To keep food warm.
10 Defrost To defrost frozen food.
To bake and roast food on one shelf position.
es, spring rolls crispy.
shelf position. Also to brown food, for example gratin.
Page 13
Daily use
Oven function Application
11 Bottom Heat To bake cakes with a crispy base, and for the food preserva-
12 ECO Roasting ECO functions let you to optimize the energy consumption
tion.
during cooking. Thus it is necessary to set the cooking time
first. To get more information about the recommended settings, refer to the cooking tables with the equivalent usual
oven function.
Changing the oven temperature
Touch / to change the temperature in steps of 5 °C.
When the appliance is at the set temperature, an acoustic signal operates three times and
the Heat up indicator goes off.
Examining the oven temperature
You can examine the temperature in the appliance when the function or programme operates.
1. Touch
The Temperature/Time display shows the temperature in the appliance.
If you want to change the oven temperature, touch one more time and use or .
.
13
2. Touch
to go back to the set temperature or the display will show it automatically
after five seconds.
Fast heat up function
The fast heat up function decreases the heat up time.
Do not put food in the oven when the fast heat up function operates.
Activating the fast heat up function: Touch and hold
If you activate the fast heat up function, the bars on the display
show that the function operates.
The fast heat up is not available with every oven function. An acoustic signal operates if the
fast heat up is not available for set function.
for more then three seconds.
flash one by one to
Page 14
14 Clock functions
Energy saving
The appliance has some features that help you save energy during everyday cooking:
• Residual heat:
– the oven function or programme operates: the heating elements are deactivated 10%
time earlier (the lamp and fan continue to operate). The condition: the cooking time is
longer then 30 minutes or you use the clock functions (Duration, End, Time delay).
– the oven is off: you can use the heat to keep the food warm. The indication: the clock/
Residual heat display shows the remaining temperature, the bars show the decreasing
temperature.
• Oven lamp off - touch
• Display off - if necessary, deactivate the appliance. Touch
to deactivate the oven lamp during cooking;
and at the same time
until the display goes out (or on).
• Eco functions - refer to "Oven function".
CLOCK FUNCTIONS
SYMBOL FUNCTION DESCRIPTION
COUNT UP TIMER To set count up. It shows how long the appliance operates.
TIME OF DAY To examine the time of day. For changing the time of day re-
DURATION To set how long the appliance operates.
This function has no effect on the operation of the appliance.
fer to 'Setting the time of day'.
END To set when the appliance deactivates. You can use Duration
SET+GO To start the appliance with necessary settings with only one
and End at the same time (Time delay), if the appliance is to
be activate and deactivate automatically later.
touch of the sensor field, any time later.
Count Up Timer
Use the Count Up Timer to monitor how long the appliance operates. It is on immediately
when the appliance starts to heat.
Reset the Count Up Timer: touch
again and again until flashes in the display. Touch
until the display shows "00:00" and the Count Up Timer starts to count up again.
You can not use Count Up Timer when Duration or End is set.
Setting the DURATION
1. Activate the appliance and set an oven function and temperature.
Page 15
Clock functions 15
2. Touch again and again until the dis-
play shows
flashes in the display.
3. Use
TION.
4. Touch
5. Use
If you touch or during setting hours for DURATION, the appliance goes to setting of
the END function.
6. When the set time ends, an acoustic signal operates for two minutes.
symbol and time setting flash in the display. The appliance deactivates.
Touch any sensor field or open the oven door to stop an acoustic signal.
7. Deactivate the appliance.
.
or to set minutes for DURA-
to confirm
or to set hours for DURATION.
Setting the END
1. Activate the appliance and set an oven function and temperature.
2. Touch
3. Use
confirm.
4. When the set time ends, an acoustic signal operates for two minutes.
5. Touch any sensor field or open the oven door to stop an acoustic signal.
6. Deactivate the appliance.
again and again until the display shows .
flashes in the display.
or to set END (first you set minutes and then hours) and or to
symbol and time setting flash in the display. The appliance deactivates.
Setting the SET+GO
To start of the appliance with necessary settings with only one touch of the sensor field,
any time later.
1. Set an oven function (or programme) and temperature (refer to "Setting the oven
function" and "Changing the oven temperature").
2. Set DURATION (refer to "Setting the DURATION").
3. Touch
4. Touch
The display shows
ted.
5. Touch any sensor field (apart from ON/OFF) to start the SET+GO function.
You can use SET+GO function only if DURATION is set.
again and again until will flash in the display.
to set the SET+GO function.
and with a dot. This dot shows which clock function is activa-
Check result (selected models only)
If you set END or DURATION function, 2 minutes before end of cooking an acoustic signal
sounds and lamp activates. The appliance goes to the setting of the END or DURATION
Page 16
16 Automatic programmes
function. During these two minutes you can examine the cooking results and, if necessary,
add END or DURATION time.
Setting the Time delay function
DURATION and END can be used at the same time, if the oven is to be switched on
and off automatically later. In this case first set DURATION
(refer to "Setting the DURATION" and "Setting the END ").
When the Time delay function is activated the display shows static symbol of the oven
function,
Residual heat display.
with a dot and . The dot shows which clock function is on in the Clock/
and then END function
Setting the MINUTE MINDER
Use the MINUTE MINDER to set a countdown (maximum 23 h 59 min). This function has no
effect on the operation of the oven. You can set the MINUTE MINDER any time, also if the
appliance is off.
1. Touch
2. Use
First you set seconds and then minutes
and hours.
3. Touch
automatically after five seconds.
4. When set time ends, an acoustic signal
operates for two minutes and "00:00"
and
5. Touch any sensor field or open the oven door to stop an acoustic signal.
.
and "00" flash in the display.
or to set MINUTE MINDER.
or the MINUTE MINDER starts
flash in the display.
AUTOMATIC PROGRAMMES
WARNING!
Refer to "Safety information" chapter.
There are 20 automatic programmes and recipes. Use an automatic programme or recipe
when you do not have a knowledge or experience how to prepare a dish. You can find the
recipes for the automatic programmes in the "Recipe book".
There are three types of automatic programmes:
• Automatic recipes;
• Automatic programmes with weight input;
• Automatic programmes with core temperature sensor;
Automatic recipes
Setting an automatic recipe:
1. Touch
The display shows symbol and number of the automatic programme.
two times until the display shows .
Page 17
Automatic programmes
2. Touch or to choose the automatic recipes.
3. Touch
4. When set time ends, an acoustic signal operates for two minutes. Symbol
The appliance deactivates.
5. Touch any sensor field or open the oven door to stop an acoustic signal.
or the automatic recipe activates automatically after five seconds.
Automatic programmes with weight input
If you set the weight of the meat, the appliance calculates the roasting time.
1. Touch
2. Touch
The display shows: cooking time, duration symbol
measurement (kg, g).
3. Touch
4. The appliance starts. A symbol of the weight unit flashes in the display. During this
time you can change the default weight value with
5. When set time ends, an acoustic signal operates for two minutes.
The appliance deactivates.
6. Touch any sensor field or open the oven door to stop an acoustic signal.
again and again until the display shows .
or to set the weight programme (refer to "Recipe book").
, a default weight, a unit of
or the settings save automatically after five seconds.
or . Touch .
flashes.
Automatic programmes with core temperature sensor
The core temperature of the food is default and fixed in programmes with core temperature
sensor. The programme ends when the appliance is at the set core temperature.
1. Touch
2. Install the core temperature sensor (refer to "The core temperature sensor").
3. Touch
When a core temperature sensor programme is set, the display shows the cooking
time,
4. Touch
5. When set time ends, an acoustic signal operates for two minutes.
The appliance deactivates.
6. Touch any sensor field or open the oven door to stop an acoustic signal.
again and again until the display shows .
or to set the core temperature sensor programme.
and .
or the settings save automatically after five seconds.
flashes.
17
flashes.
My Favourite Programme function
Use this function to save your favourite settings of temperature and time for an oven function or programme.
1. Set the temperature and time for an oven function or programme.
2. Touch and hold
An acoustic signal sounds.
3. Deactivate the appliance.
Using My Favourite Programme function:
• To activate the function touch
for more than three seconds.
. The appliance activates your favourite programme.
Page 18
18 Using the accessories
• To deactivate the function touch . The appliance deactivates your favourite pro-
gramme.
When the function operates, you can change the time and temperature.
USING THE ACCESSORIES
WARNING!
Refer to "Safety information" chapter.
The core temperature sensor
The core temperature sensor measures the core temperature of the meat. When the meat is
at the set temperature, the appliance deactivates.
There are two temperatures to set:
• The oven temperature: refer to the table for roasting in the recipe book.
• The core temperature: refer to the table for the core temperature sensor in the recipe
book.
Only use the core temperature sensor supplied or original replacement parts.
1. Activate the appliance.
2. Put the point of the core temperature
sensor (with the symbol
handle) into the centre of the meat.
3. Put the plug of the core temperature
sensor into the socket at the front of
the appliance.
The display shows a flashing symbol
and the default set core temperature. The temperature is 60 °C during
the first use, and the last set value during each subsequent use.
4. Touch
ature.
5. Touch
matically after 5 seconds.
or to set the core temper-
or the settings save auto-
on the
You can set the core temperature only when the symbol flashes. If the display shows a
static symbol
value.
6. Set the oven function and, if necessary, the oven temperature.
The display shows the current core temperature and
tween the set oven temperature and the current oven temperature).
before you set the core temperature, use and or to set a new
(which shows the relation be-
Page 19
Using the accessories 19
The core temperature sensor must stay in the meat and in the socket during the cooking.
While the appliance calculates the approximate duration time, the value of the Count Up
Timer function shows in the Timer/Residual heat display. When the first calculation ends,
the Timer/Residual heat display shows -, and then the approximate duration of the cooking.
The appliance continues to calculate the duration during the cooking. The display updates
at intervals with the new duration value.
7.
When the meat is at the set core temperature, the core temperature and
acoustic signal sounds for two minutes.
Touch a sensor field to deactivate the acoustic signal.
8. Remove the core temperature sensor from the socket and remove the meat from the
appliance.
WARNING!
Be careful when you remove the core temperature sensor. It is hot. There is a risk of burns.
9. Deactivate the appliance.
When you put the core temperature sensor into the socket, you cancel the settings for the
clock functions.
When you cook with the core temperature sensor, you can change the temperature shown
in the Temperature/Time display. After you put the core temperature sensor in the socket
and set an oven function and temperature, the display shows the current core temperature.
Touch
• The current core temperature
• The oven set temperature
• The current oven temperature.
again and again to see three other temperatures:
flash. An
The set core temperature changes into current core temperature and current oven temperature changes into set oven temperature.
Installing the Oven Accessories
The deep pan and the wire shelf have side edges.
These edges and the shape of the guide-bars causes the anti-tilt safety for the oven accessories.
Page 20
20 Using the accessories
Installing the wire shelf and the deep pan together
Put the wire shelf on the deep pan. Push the deep
pan between the guide-bars of one of the oven
levels.
Telescopic runners - Inserting the Oven Accessories
Put the baking tray or the deep pan on the telescopic runners.
Put the wire shelf on the telescopic runners so
that the feet point downwards.
The high rim around the wire shelf is an additional device to prevent cookware from slipping.
Inserting the wire shelf and the deep pan together
Put the wire shelf on the deep pan. Put the wire
shelf and the deep pan on the telescopic runners.
Page 21
Additional functions 21
ADDITIONAL FUNCTIONS
Child safety
You cannot activate the appliance on if the child safety device operates.
Activating/Deactivating the child safety device:
1. Deactivate the appliance
2. Touch and hold
3. An acoustic signal sounds.
SAFE goes on in the display when you touch any key.
If the oven has "Pyro Cleaning" function, the door is locked.
and at the same time for minimum 2 seconds.
Control Lock
The Control Lock prevents you to accidentally change the oven functions.
You can activate the Control Lock only when the appliance operates.
Activate the Control Lock:
1. If necessary, activate the appliance.
2. Do the necessary settings.
3. Touch and hold
Loc goes on in the display. The Control Lock is on.
If you touch any of the sensor fields when the Control Lock, an acoustic signal operates.
To deactivate the Control Lock, touch and hold
The Control Lock does not prevent you accidentally deactivate the appliance. If you deactivate the appliance, the Control Lock is off.
and at the same time.
. Do not set any oven function.
and at the same time.
Settings menu
The settings menu lets you to add or remove functions from the main menu (for example:
you can set on or off the Residual heat indicator). Settings menu has maximum seven settings (from SET1 to SET7). The number of the settings is different for different models. Look
into the table below to see the possible value of each setting.
Settings menu
Indicator of the setting menu Description Value to set
SET1 SET+GO ON/OFF
SET2 RESIDUAL HEAT INDICATOR ON/OFF
SET3 KEY TONE CLIC/BEEP/OFF
SET4 FAULTY TONE ON/OFF
SET5 SERVICE MENU ON/OFF
SET6 RESTORE SETTINGS YES/NO
Page 22
22 Additional functions
Indicator of the setting menu Description Value to set
1)
SET7
1) Selected models only
TIME EXTENSION ON/OFF
You can set the settings menu only when the appliance is off.
Activate the Settings menu:
1. If necessary, deactivate the appliance
2. Touch and hold
for three seconds.
.
The display shows "SET1" and "1" flashes.
3. Touch
4. Touch
5. Touch
6. Touch
/ to set the setting.
.
/ to change the value of the setting.
.
Automatic switch-off
For safety reasons the appliance deactivates automatically after some time:
• if an oven function operates.
• if you do not change the oven temperature.
Oven temperature Switch-off time
30 °C -120 °C 12.5 h.
120 °C - 200 °C 8.5 h.
200 °C -250 °C 5.5 h.
250 °C -maximum °C 3.0 h.
After an automatic switch-off, touch a sensor field to operate the appliance again.
The Automatic switch-off works with all oven functions, apart from Light, Low temperature
cooking, core temperature sensor, Duration, End, Time delay.
Brightness of the display
There are two modes of display's brightness:
• Night brightness - when the appliance is off, the brightness of the display is lower be-
tween 22:00 and 06:00;
• Day brightness:
– when the appliance is on;
– if you touch any of the sensor fields during night brightness (apart from ON/OFF), the
display goes back to day brightness mode for next 10 seconds;
– if the appliance is off and you set the minute minder. When the minute minder func-
tion ends, the display goes back to night brightness;
Page 23
Care and cleaning 23
Cooling fan
When the appliance operates, the cooling fan activates automatically to keep the surfaces
of the appliance cool. If you deactivate the appliance, the cooling fan can continue to operate until the appliance cools down.
Mechanical door lock
The door lock is not active when you buy the appliance.
To activate the door lock: Pull the door lock forward until it locks in place.
To deactivate the door lock: Push the door lock back into the panel.
Opening the appliance door:
1. Push and hold the door lock.
2. Open the door.
Do not push the door lock when you close the appliance door!
When you deactivate the appliance it does not deactivate the mechanical door lock.
1
2
CARE AND CLEANING
WARNING!
Refer to "Safety information" chapter.
Notes on cleaning:
• Clean the front of the appliance with a soft cloth with warm water and cleaning agent.
• To clean metal surfaces use a usual cleaning agent
• Clean the oven interior after each use. Thus you can remove dirt more easily and it does
not burn on.
• Clean stubborn dirt with a special oven cleaner.
• Clean all oven accessories (with a soft cloth with warm water and cleaning agent) after
each use and let them dry.
• If you have nonstick accessories, do not clean them using an aggressive agents, sharp
edged objects or dishwasher. It can cause a damage to the nonstick coating.
Shelf support
You can remove the shelf support to clean the side walls.
Page 24
24 Care and cleaning
Removing the shelf support
1. Pull the front of the shelf support away
from the side wall.
2. Pull the shelf support from the back of
the side wall to remove it.
To install the shelf support follow the procedure in reverse.
Valid with telescopic runners:
The retaining pins on the telescopic shelf
runners must point to the front!
1
2
Oven Ceiling
You can fold down the heating element on the oven ceiling to clean the oven ceiling easily.
WARNING!
Before you fold down the heating element deactivate the appliance. Make sure that the
appliance is cold. There is a risk of burns!
Folding down the heating element
1. Remove the shelf supports.
2. Hold the heating element with the two
hands at the front
3. Pull it forwards against the spring pressure and out along the support on both
sides.
4. The heating element folds down.
The oven ceiling is ready to clean.
Installing the heating element
1. Install the heating element in opposite
sequence.
Install the heating element correctly on the two sides above the support on the inner wall
of the appliance.
2. Install the shelf supports.
Page 25
Care and cleaning 25
Oven lamp
WARNING!
There is a risk of electrical shock.
Oven lamp and the lamp glass cover can be hot.
Before you change the oven lamp:
• Deactivate the appliance.
• Remove the fuses from the fuse box or deactivate the circuit breaker.
CAUTION!
Put a cloth on the bottom of the interior of the appliance. It prevents damage to the lamp
glass cover and the cavity.
Replacing the oven lamp:
1. You can find the lamp glass cover at the cavity ceiling.
Turn the lamp glass cover counterclockwise to remove it.
2. Clean the glass cover.
3. If necessary, replace the oven lamp with applicable 300°C heat-resistant oven lamp.
Use the same oven lamp type.
4. Install the glass cover.
Replacing the oven lamp:
1. You can find the lamp glass cover at the left side of the cavity.
Remove the left shelf rail.
2. Use a narrow, blunt object (for example
a teaspoon) to remove the glass cover.
Clean the glass cover.
3. If necessary, replace the oven lamp
with applicable 300°C heat-resistant
oven lamp.
Use the same oven lamp type.
4. Install the glass cover.
5. Install the left shelf rail.
Oven door and glass panels
To clean the oven door, remove it.
CAUTION!
Be careful when you remove the door from the appliance. The door is heavy!
Page 26
26 Technical data
Removing the oven door
1. Open the oven door as far as it goes.
2. Fully press clamping levers (A) on the
two door hinges.
3. Close the oven door until the first position (angle approximately 70°).
4. Hold of the oven door with one hand on
each side and pull it away from the oven
at an up angle.
To install the door follow the procedure in
reverse.
The number of glass panels if different for the different models.
CAUTION!
Put the oven door with the outer side down on a soft and level surface to prevent scratches.
Removing and cleaning the door glass panels
1. Remove the oven door.
2. Hold the door trim (B) on the top edge
of the door at the two sides and push
inwards to release the clip seal.
3. Pull the door trim to the front to remove it.
B
A
A
4. Hold the door glass panels on their top
edge one by one and pull them up out
of the guide
5. Clean the door glass panels.
To install panels follow the procedure in reverse. Install the smaller panel first, then the
larger.
TECHNICAL DATA
Voltage 220-240 V
Frequency 50 Hz
Page 27
What to do if…
WHAT TO DO IF…
WARNING!
Refer to "Safety information" chapter.
Problem Possible cause Solution
The appliance does not heat up The appliance is deactivated Activate the appliance
The appliance does not heat up The time of day is not set Set the clock. Refer to "First
The appliance does not heat up The necessary settings are not
The appliance does not heat up The automatic switch-off is ac-
The appliance does not heat up The fuse is released Make sure, if the fuse is the
The oven lamp does not operate
The display shows F102 The door lock is defect • Close the door correctly
The display shows an error code
that is not in this list
set
tivated
The oven lamp is defective Replace the oven lamp.
There is an electronic error • Deactivate the appliance
If you cannot find a solution to the problem yourself, contact your dealer or the service
centre.
The necessary data for the service centre is on the rating plate. The rating plate is on the
front frame of the oven cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
setting the time of day"
Make sure, the settings are correct
Refer to „Automatic switchoff“
cause for the malfunction. If
the fuse releases again and
again, refer to an authorized
electrician
• Deactivate the appliance
with the house fuse or the
safety switch in the fuse box
and activate it again
• If the display shows F102
again, refer to the Service
Center
with the house fuse or the
safety switch in the fuse box
and activate it again
• If the display shows the error code again, refer to the
Service Center
27
Page 28
28 Environment concerns
ENVIRONMENT CONCERNS
The symbol on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it should be taken to the appropriate collection point
for the recycling of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of this product,
please contact your local council, your household waste disposal service or the shop where
you purchased the product.
Packaging material
The packaging material is environmentally-friendly and recyclable. Plastic parts are marked
with international abbreviations such as PE, PS, etc. Dispose of the packaging material in
the containers provided for this purpose at your local waste management facility.
Page 29
293031
Page 30
Page 31
Page 32
www.aeg.com/shop 892945149-F-092011
Loading...
