AEG B5712-5-M User Manual

B5712-5
User manual Built-In Electric Oven
Contents2
1
To ensure optimal and regular performance of your appliance please read this instruc-
tion manual carefully. It will enable you to navigate all processes perfectly and most ef-
To refer to this manual any time you need to, we recommend you to keep it in a safe
Contents
Thank you for choosing one of our high-quality products.
ficiently.
place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
Operating Instructions 3
Safety instructions 3
Description of the Appliance 4
General Overview 4 Control Panel 5 Oven Features 5 Oven accessories 6
Before Using for the first time 7
Setting and changing the time 7 Initial Cleaning 8
Using the Oven 8
Switching the Oven On and Off 8 Rapid heat up 11 Oven Functions 11 Inserting the Oven Shelf, Baking Tray and Roasting Pan 12 Inserting/Removing the Fat Filter 13 Rotary Spit 13 Clock Functions 14 Other Functions 19
The following symbols are used in this user manual:
Important information concerning your personal safety and information on how to avoid damaging the appliance.
3 General information and tips
Uses, Tables and Tips 20
Baking 20 Roasting 26 Grill Sizes 28 Grilling with the rotary spit 29 Defrosting 29 Drying 30 Making preserves 30
Cleaning and Care 31
Outside of the appliance 31 Oven interior 31 Accessories 32 Fat Filter 32 Shelf Support Rails 32 Oven lighting 33 Oven door 33 Oven door glass 35
What to do if … 38
Disposal 39
Service 40
2 Environmental information
Operating Instructions
1 Safety instructions
Electrical safety
This appliance must be only connected by a registered electrician.
In the event of a fault or damage to the appliance: Take the fuses out or switch off.
Repairs to the appliance must only be carried out by qualified service engineers.
Considerable danger may result from improper repairs. If repairs become necessary, please contact our Customer Services or your dealer.
Child Safety
Never leave children unsupervised when the appliance is in use.
Safety whilst using
People (including children) who, because of their physical, sensory or mental capabili­ties or their inexperience or ignorance are not able to use the device safely, should not use this device without supervision or instruction by a responsible person.
This appliance is intended to be used for cooking, roasting and baking food in the home.
Take care when connecting electric appliances to sockets nearby. Do not allow con- necting leads to come into contact with or to catch beneath the hot oven door.
Warning: Risk of burns! The interior of the oven becomes hot during use.
Using ingredients containing alcohol in the oven may create an alcohol-air mixture
that is easily ignited. In this case, open the door carefully. Do not have embers, sparks or naked flames in the vicinity when opening the door.
3Operating Instructions
3 Information on acrylamides
According to the latest scientific knowledge, intensive browning of food, especially in products containing starch, can constitute a health risk due to acrylamides. Therefore we recommend cooking at the lowest possible temperatures and not browning foods too much.
How to avoid damage to the appliance
Do not line the oven with aluminium foil and do not place baking trays, pots, etc. on the oven floor, as the heat that builds up will damage the oven enamel.
Fruit juices dripping from the baking tray will leave stains, which you will not be able to remove. For very moist cakes, use a deep tray.
Do not put any strain on the oven door when open.
Never pour water directly into the oven when it is hot. This could cause damage to or
discolouration of the enamel.
Rough handling, especially around the edges of the front panel, can cause the glass to break.
Do not store any flammable materials inside the oven. These could ignite when the oven is switched on.
Description of the Appliance4
Do not store any moist foods inside the oven. This could damage the oven enamel.
After switching off the cooling fan, do not keep uncovered dishes in the oven. Mois-
ture may condense in the oven interior or on the glass doors and may get into the units.
3 Note on enamel coating
Changes in the colour of the oven’s enamel coating as a result of use do not affect the appliance’s suitability for normal and correct use. They therefore do not constitute a de­fect in the sense of the warranty law.
Description of the Appliance
General Overview
Control panel
Door handle
Full glass door
Control Panel
5Description of the Appliance
Oven Power Indicator Oven Power Indicator
Temperature / Time Display
Oven Features
All interior oven walls, except the floor of the oven, are coated with a special enamel (catalytic coating).
Spit drive
mechanism
Shelf positions
Oven Functions
Temperature / Time Selection
Function buttons
Top heat and heating elements
Oven lighting
Fat Filter
Fan heating element Fan
Bottom Heat
Oven shelf runners,
removable
Description of the Appliance6
Inside of door
On the inside of the oven door you will find the numbers of the different oven shelves.
You will also find some brief information about the oven's functions, recommended shelves and temperatures for cooking the most popular dishes.
Oven accessories
Oven shelf
For cookware, cake tins, roasts and grilled foods.
Baking tray
For cakes and biscuits.
Roasting Pan
For baking and roasting or as a pan for collect­ing fat.
Turnspit with support
For roasting larger joints of meat and poultry.
Before Using for the first time
Setting and changing the time
3 The oven only operates when the time has been set.
When the appliance has been connected to the electrical supply or when there has been a power cut, the function indicator Time of day flashes automatically.
1. To change a time that has already been set, press the Selection button repeatedly until the func­tion indicator Time of day flashes.
2. Using the / control knob, set the current time.
7Before Using for the first time
After approx. 5 seconds, the flashing stops and the clock displays the time of day set.
The appliance is now ready to use.
3 The time can only be modified, if the child safety
device is deactivated, none of the Minute Minder
, Duration or End clock functions and no
oven function is set.
Initial Cleaning
Before using the oven for the first time, you must clean it.
1 Important: Do not use sharp, abrasive cleaning agents! These could damage the surface.
3 For metal fronts, use normal commercially available cleaning agents.
1. Open door. The oven light is activated.
2. Remove all accessories and the slide-in grids and clean with warm water and washing-up liq­uid.
3. Wipe the floor of the oven clean with warm washing-up solution and dry.
4. Wipe the front of the appliance with a damp cloth.
Using the Oven8
/
O
Using the Oven
3 The oven is equipped with retractable buttons for “Oven functions” and “Temperature
selection”. To use, press the relevant button. The button then sticks out.
Switching the Oven On and Off
Oven Power Indicator
Temperature
Speedcook
Time
Display
Heat indicator
ven Power Indicator
Selector Button
Oven Functions
Button Speedcook
Change display
Switching the oven on
Turn the oven functions selector to the desired function. The power indicator light lights up. The temperature display shows the suggested temperature for the oven function selected.
The oven starts to heat up. When the temperature set is reached, an audi-
ble signal sounds.
Changing the oven temperature
Turn the / knob to raise or lower the tem­perature.
The setting changes in 5 °C steps.
Temperature / Time Selection
Checking the temperature
Press Rapid heat up and Selection but­tons at the same time.
The current oven temperature appears in the temperature display.
Switching the oven off
To turn the oven off, turn the oven functions selector to the OFF position.
3 Cooling fan
The fan switches on automatically in order to keep the appliance’s surfaces cool. When the oven is switched off, the fan continues to run to cool the appliance down, then switches itself off automatically.
9Using the Oven
3 Heat indicator
Indicates warming up
When the oven function has been switched on the bars that slowly light up one after the other indi­cate how far the oven has heated up.
Fast heat indicator When the fast heat function has been switched on the bars that flash one after the other in-
dicate that fast heat is operating. In addition the bars next to the symbol light up.
Using the Oven10
Residual heat indicator
When the oven has been switched off, the bars that are still lit indicate the remaining residual heat in the oven.
Rapid heat up
After an oven function is selected, using the addi­tional function Rapid heat up the empty oven can be pre-heated in a relatively short time.
1 Important: Do not put the food to be cooked into
the oven, until Rapid heat up is completed and the oven is operating using the desired function.
1. Set the desired oven function (e. g., Conventional ). If necessary, change the suggested tem- perature.
2. Press the Rapid heat up button. The bars next to the symbol light up. When the bars flash one after another it shows that Rapid heat up is operating. When the temperature set is reached, the bars of the heat indicator light up and the bars next to the symbol go out. An audible signal sounds. The oven now continues heating according to the pre-set oven function and temperature. You
can now place the food in the oven.
3 The Rapid heat up function can be switched on with the oven functions True fan , Fan
baking , Conventional and Rotitherm + turnspit .
Oven Functions
The oven has the following functions:
Oven function Application
True fan For baking on up to three oven levels at the same time.
Set the oven temperatures 20-40 °C lower than when using Conventional.
Fan baking For baking on one oven level dishes that require more inten-
Conventional For baking and roasting on one oven level.
Rotitherm + turns­pit
Dual grill + turnspit For grilling large poultry and roasts.
Grill + turnspit For grilling flat foodstuffs placed in the middle of the grill
Defrost For defrosting e. g. flans and gateaux, butter, bread, fruit or
Base heat For baking cakes with crispy or crusty bases.
sive browning and a crispy base.
Set the oven temperatures 20-40 °C lower than when using Conventional.
For roasting larger joints of meat or poultry on one level. The function is also suitable for gratinating and browning.
and for toasting.
other frozen foods.
Inserting the Oven Shelf, Baking Tray and Roasting Pan
3 Shelf runner safety and anti-tip device
As a shelf runner safety device, all insertable components have a small curved indenta­tion at the bottom on the right and left-hand edge. Always insert insertable components so that this indentation is at the back of the oven interior. This indentation is also important for preventing the insertable components from tipping.
Inserting the baking tray or roasting pan
Push the baking tray or roasting pan between the guide bars of the selected oven level.
Inserting the oven shelf:
Insert the oven shelf so that the feet point downwards.
Push the oven shelf between the guide bars of the selected oven level.
11Using the Oven
3 The high rim around the oven shelf is an addi-
tional device to prevent cookware from slip­ping.
Inserting the oven shelf and roasting pan together
Lay the oven shelf on the roasting pan. Push the roasting pan between the guide bars of the selected oven level.
Using the Oven12
Inserting/Removing the Fat Filter
Only use the fat filter when roasting to pro­tect the rear heating elements from fat splash­es.
Inserting the fat filter
Hold the fat filter by the grip and insert the two mounts downwards into the opening on the rear wall of the oven (fan opening).
Taking out the fat filter
Hold the fat filter by the grip and un­hook it.
Rotary Spit
Attaching the food to be grilled
1. Place a fork on the rotary spit.
2. Then position the food to be grilled and a second
fork.
3 Make sure the food is in the middle of the spit.
3. Tighten the forks using the screws.
Inserting the rotary spit
1. Place the drip tray in the first shelf position from
the bottom.
2. Insert the rotary spit support at the front on the right-hand side in shelf position five from the bot­tom.
3. Place the handle on the spit and press the clip down.
3 The clip must be kept pressed down to keep the
handle secure on the rotary spit.
4. Push the tip of the spit into the power unit on the left-hand side of the back wall of the oven until it locks into place.
5. Place the groove in front of the handle on the notch provided on the rotary spit support.
