AEG AGS77200F0 User Manual [en, ru, es, it]

SKD71800F0

EN

REFRIGERATOR USER MANUAL

IT

FRIGORIFERO ISTRUZIONI PER L’USO

RU ХОЛОДИЛЬНИК ИНСТРУКЦИЯ ПО

ES

FRIGORÍFICO MANUAL DE INSTRUCCIONES

ЭКСПЛУАТАЦИИ

18
35

52

2

2

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have
created it to give you impeccable performance for many
years, with innovative technologies that help make life
simpler – features you might not find on ordinary
appliances. Please spend a few minutes reading to get the
very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to
keep all your AEG appliances looking spotless and
working perfectly. Along with a wide range of accessories
designed and built to the high quality standards you
would expect, from specialist cookware to cutlery baskets,
from bottle holders to delicate laundry bags…

Visit the webshop at:
www.aeg-electrolux.com/shop

CONTENTS

4 Safety information

6 Control panel
10 First use
10 Daily use
12 Helpful hints and tips
13 Care and Cleaning
14 What to do if…
16 Technical data
16 Installation
17 Environmental concerns

Contents

3

The following symbols are used in this user
manual:

Important information concerning your
personal safety and information on how to
avoid damaging the appliance.

General information and tips

Environmental information

Subject to change without notice

4 Safety information

SAFETY INFORMATION

In the interest of your safety and to ensure the correct use, before installing and first using
the appliance, read this user manual carefully, including its hints and warnings. To avoid
unnecessary mistakes and accidents, it is important to ensure that all people using the ap­pliance are thoroughly familiar with its operation and safety features. Save these instruc­tions and make sure that they remain with the appliance if it is moved or sold, so that ev­eryone using it through its life will be properly informed on appliance use and safety.
For the safety of life and property keep the precautions of these user's instructions as the
manufacturer is not responsible for damages caused by omission.

Children and vulnerable people safety

• This appliance is not intended for use by persons (including children) with reduced physi­cal, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person re­sponsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

• Keep all packaging well away from children. There is risk of suffocation.

• If you are discarding the appliance pull the plug out of the socket, cut the connection
cable (as close to the appliance as you can) and remove the door to prevent playing chil­dren to suffer electric shock or to close themselves into it.

• If this appliance featuring magnetic door seals is to replace an older appliance having a
spring lock (latch) on the door or lid, be sure to make that spring lock unusable before
you discard the old appliance. This will prevent it from becoming a death trap for a child.

General safety

CAUTION!

Keep ventilation openings clear of obstruction.

• The appliance is intended for keeping foodstuff and/or beverages in a normal household
as explained in this instruction booklet.

• Do not use a mechanical device or any artificial means to speed up the thawing process.

• Do not use other electrical appliances (such as ice cream makers) inside of refrigerating
appliances, unless they are approved for this purpose by the manufacturer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the appli­ance, a natural gas with a high level of environmental compatibility, which is neverthe­less flammable.

During transportation and installation of the appliance, be certain that none of the com­ponents of the refrigerant circuit become damaged.

If the refrigerant circuit should become damaged:
– avoid open flames and sources of ignition
– thoroughly ventilate the room in which the appliance is situated

Safety information 5

• It is dangerous to alter the specifications or modify this product in any way. Any damage
to the cord may cause a short-circuit, fire and/or electric shock.

WARNING!

Any electrical component (power cord, plug, compressor) must be replaced by a certified
service agent or qualified service personnel to avoid hazard.

1. Power cord must not be lengthened.

2. Make sure that the power plug is not squashed or damaged by the back of the appli-

ance. A squashed or damaged power plug may overheat and cause a fire.

3. Make sure that you can come to the mains plug of the appliance.

4. Do not pull the mains cable.

5. If the power plug socket is loose, do not insert the power plug. There is a risk of elec-

tric shock or fire.

6.

You must not operate the appliance without the lamp cover

1)

of interior lighting.

• This appliance is heavy. Care should be taken when moving it.

• Do not remove nor touch items from the freezer compartment if your hands are damp/
wet, as this could cause skin abrasions or frost/freezer burns.

• Avoid prolonged exposure of the appliance to direct sunlight.

•

Bulb lamps

2)

used in this appliance are special purpose lamps selected for household ap-

pliances use only. They are not suitable for household room illumination.

Daily use

• Do not put hot pot on the plastic parts in the appliance.

• Do not store flammable gas and liquid in the appliance, because they may explode.

• Appliance's manufacturers storage recommendations should be strictly adhered to. Refer
to relevant instructions.

Care and cleaning

• Before maintenance, switch off the appliance and disconnect the mains plug from the
mains socket.

• Do not clean the appliance with metal objects.

• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean
the drain. If the drain is blocked, water will collect in the bottom of the appliance.

Installation

For electrical connection carefully follow the instructions given in specific paragraphs.

• Unpack the appliance and check if there are damages on it. Do not connect the appli­ance if it is damaged. Report possible damages immediately to the place you bought it.
In that case retain packing.

• It is advisable to wait at least four hours before connecting the appliance to allow the oil
to flow back in the compressor.

1) If the lamp cover is foreseen.

2) If the lamp is foreseen.

6 Control panel

• Adequate air circulation should be around the appliance, lacking this leads to overheat­ing. To achieve sufficient ventilation follow the instructions relevant to installation.

• Wherever possible the back of the product should be against a wall to avoid touching or
catching warm parts (compressor, condenser) to prevent possible burn.

• The appliance must not be located close to radiators or cookers.

• Make sure that the mains plug is accessible after the installation of the appliance.

•

Connect to potable water supply only.

3)

Service

• Any electrical work required to do the servicing of the appliance should be carried out by
a qualified electrician or competent person.

• This product must be serviced by an authorized Service Centre, and only genuine spare
parts must be used.

Environment Protection

This appliance does not contain gasses which could damage the ozone layer, in either its
refrigerant circuit or insulation materials. The appliance shall not be discarded together
with the urban refuse and rubbish. The insulation foam contains flammable gases: the ap­pliance shall be disposed according to the applicable regulations to obtain from your local
authorities. Avoid damaging the cooling unit, especially at the rear near the heat exchang­er. The materials used on this appliance marked by the symbol

are recyclable.

CONTROL PANEL

1 2 3 4 5 6

1 ON/OFF button
2 Mode button
3 OK button
4 Temperature colder button
5 Temperature warmer button

6 Display

It is possible to change predefined sound of buttons to a loudly one by pressing together
Mode button and Temperature colder button for some seconds. Change is reversible.

3) If a water connection is foreseen.

Display

78

5 64321

1 Timer function

2 DYNAMICAIR function

3 Minute Minder function

4 Child Lock function

5 Alarm indicator

6 Temperature indicator

7 Holiday function

8 COOLMATIC function

Switching on

To switch on the appliance do these steps:

1. Connect the mains plug to the power socket.

2. Press the ON/OFF button if the display is off.

3. The alarm buzzer could operate after few seconds.

To reset the alarm refer to "High temperature alarm".

4. The temperature indicators show the set default temperature.
To select a different set temperature refer to "Temperature regulation".

Control panel

7

Switching off

To switch off the appliance do these steps:

1. Press the ON/OFF button for 5 seconds.

2. The display switches off.

3. To disconnect the appliance from the power disconnect the mains plug from the power

socket.

Temperature regulation

The set temperature of the fridge may be adjusted by pressing the temperature button.
Set default temperature:

• +5°C for the fridge
The temperature indicator shows the set temperature.
The set temperature will be reached within 24 hours.

After a power failure the set temperature remains stored.

DYNAMICAIR function

To switch on the function:

1. Press the Mode button until the corresponding icon appears.

8 Control panel

The DYNAMICAIR indicator flashes.

2. Press the OK button to confirm.

The DYNAMICAIR indicator is shown.

To switch off the function:

1. Press the Mode button until the DYNAMICAIR indicator flashes.

2. Press the OK button to confirm.

3. The DYNAMICAIR indicator goes off.
If the function is activated automatically the DYNAMICAIR indicator is not shown (refer to

"Daily use").
The activation of the DYNAMICAIR function increase the energy consumption.

Minute Minder function

The Minute Minder function is to be used to set an acoustic alarm at the preferred time,
useful for example when a recipe requires to cool down a mixture for a certain lenght of
time.
To switch on the function:

1. Press the Mode button until the corresponding icon appears.

The Minute Minder indicator flashes.
The Timer shows the set value (30 minutes) for a few seconds.

2. Press the Timer regulator button to change the Timer set value from 1 to 90 minutes.

3. Press the OK button to confirm.

The Minute Minder indicator is shown.

The Timer start to flash (min).
At the end of the countdown the Minute Minder indicator flashes and an audible alarm
sounds:

1. press OK button to switch off the sound and terminate the function.
It is possible to deactivate the function at any time during the countdown:

1. Press the Mode button until the Minute Minder indicator flashes.

2. Press the OK button to confirm.

3. The Minute Minder indicator goes off.
It is possible to change the time at any time during the countdown and at the end by press­ing the Temperature colder button and the Temperature warmer button.

Child Lock function

To lock the buttons from unintentional operation select the Child Lock function.
To switch on the function:

1. Press the Mode button until the corresponding icon appears.

2. The Child Lock indicator flashes.

3. Press the OK button to confirm.

The Child Lock indicator is shown.
To switch off the function:

1. Press the Mode button until the Child Lock indicator flashes.

Control panel

2. Press the OK button to confirm.

3. The Child Lock indicator goes off.

COOLMATIC function

If you need to insert a large amount of warm food, for example after doing the grocery
shopping, we suggest activating the COOLMATIC function to chill the products more rapidly
and to avoid warming the other food which is already in the refrigerator.
To switch on the function:

1. Press the Mode button until the corresponding icon appears.

The COOLMATIC indicator flashes.

The fridge temperature indicator shows the set temperature of +2°C .

2. Press the OK button to confirm.

The COOLMATIC indicator is shown.
The COOLMATIC function shuts off automatically after approximately 6 hours.
To switch off the function before its automatic end:

1. Press the Mode button until the COOLMATIC indicator flashes.

2. Press the OK button to confirm.

3. The COOLMATIC indicator goes off.
The function switches off by selecting a different fridge set temperature.

Holiday function

This function allows you to keep the refrigerator closed and empty during a long holiday
period without the formation of a bad smell.

The fridge compartment must be empty with holiday function on.

9

To switch on the function:

1. Press the Mode button until the corresponding icon appears.

The Holiday indicator flashes.

The fridge temperature indicator shows the set temperature.

2. Press the OK button to confirm.

The Holiday indicator is shown.
To switch off the function:

1. Press the Mode button until the Holiday indicator flashes.

2. Press the OK button to confirm.

3. The Holiday indicator goes off.
The function switches off by selecting a different fridge set temperature.

Door open alarm

An acoustic alarm will sound if the door is left open for a few minutes. The door open alarm
conditions are indicated by:

10 First use

• flashing Alarm indicator

• acoustic buzzer
When normal conditions are restored (door closed), the alarm will stop.
During the alarm, the buzzer can be switched off by pressing any button.

FIRST USE

Cleaning the interior

Before using the appliance for the first time, wash the interior and all internal accessories
with lukewarm water and some neutral soap so as to remove the typical smell of a brand­new product, then dry thoroughly.

Do not use detergents or abrasive powders, as these will damage the finish.

DAILY USE

this appliance is sold in France.
In accordance with regulations valid in this country it must be provided with a special de­vice (see figure) placed in the lower compartment of the fridge to indicate the coldest zone
of it.

DYNAMICAIR

The refrigerator compartment is equipped with a
device that allows for rapid cooling of foods and
more uniform temperature in the compartment.
This device activates by itself when needed, for
example for a quick temperature recovering after
door opening or when the ambient temperature
is high.
Allows you to switch on the device manually
when needed (refer to "DYNAMICAIR Function").

The DYNAMICAIR device stops when the door is
open and restarts immediately after the door
closing.

Movable shelves

The walls of the refrigerator are equipped with a
series of runners so that the shelves can be posi­tioned as desired.
For better use of space, the front half-shelves can
lie over the rear ones.

Daily use 11

Positioning the door shelves

To permit storage of food packages of various sizes, the door shelves can be placed at dif­ferent heights.

Positioning the sliding box

The sliding box can be placed at different heights.
To make these adjustments proceed as follow:

12 Helpful hints and tips

1. lift the shelf with the sliding box upwards

and out of the holders in the door

2. remove the retaining bracket out of the

guide under the shelf

3. Reverse the above operation to insert the

sliding box at a different height.

HELPFUL HINTS AND TIPS

Hints for energy saving

• Do not open the door frequently or leave it open longer than absolutely necessary.

• If the ambient temperature is high and the Temperature Regulator is set to low tempera-

ture and the appliance is fully loaded, the compressor may run continuously, causing
frost or ice on the evaporator. If this happens, set the Temperature Regulator toward
warmer settings to allow automatic defrosting and so a saving in electricity consump­tion.

Hints for fresh food refrigeration

To obtain the best performance:

• do not store warm food or evaporating liquids in the refrigerator

• do cover or wrap the food, particularly if it has a strong flavour

• position food so that air can circulate freely around it

Hints for refrigeration

Useful hints:
Meat (all types) : wrap in polythene bags and place on the glass shelf above the vegetable
drawer.
For safety, store in this way only one or two days at the most.
Cooked foods, cold dishes, etc..: these should be covered and may be placed on any shelf.
Fruit and vegetables: these should be thoroughly cleaned and placed in the special draw­er(s) provided.
Butter and cheese: these should be placed in special airtight containers or wrapped in alu­minium foil or polythene bags to exclude as much air as possible.
Milk bottles: these should have a cap and should be stored in the bottle rack on the door.
Bananas, potatoes, onions and garlic, if not packed, must not be kept in the refrigerator.

Care and Cleaning

CARE AND CLEANING

CAUTION!

Unplug the appliance before carrying out any maintenance operation.

This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must
therefore only be carried out by authorized technicians.

Periodic cleaning

The equipment has to be cleaned regularly:

• clean the inside and accessories with lukewarm water and some neutral soap.

• regularly check the door seals and wipe clean to ensure they are clean and free from

debris.

• rinse and dry thoroughly.
Do not pull, move or damage any pipes and/or cables inside the cabinet.

Never use detergents, abrasive powders, highly perfumed cleaning products or wax polishes
to clean the interior as this will damage the surface and leave a strong odour.

Clean the condenser (black grill) and the compressor at the back of the appliance with a
brush or a vacuum cleaner. This operation will improve the performance of the appliance
and save electricity consumption.

Take care of not to damage the cooling system.

13

Many proprietary kitchen surface cleaners contain chemicals that can attack/damage the
plastics used in this appliance. For this reason it is recommended that the outer casing of
this appliance is only cleaned with warm water with a little washing-up liquid added.
After cleaning, reconnect the equipment to the mains supply.

Defrosting of the refrigerator

Frost is automatically eliminated from the evaporator of the refrigerator compartment ev­ery time the motor compressor stops, during normal use. The defrost water drains out
through a trough into a special container at the back of the appliance, over the motor com­pressor, where it evaporates.

14 What to do if…

It is important to periodically clean the defrost
water drain hole in the middle of the refrigerator
compartment channel to prevent the water over­flowing and dripping onto the food inside. Use
the special cleaner provided, which you will find
already inserted into the drain hole.

Periods of non-operation

When the appliance is not in use for long periods, take the following precautions:

• disconnect the appliance from electricity supply

• remove all food

defrost

4)

and clean the appliance and all accessories

•

• leave the door/doors ajar to prevent unpleasant smells.
If the cabinet will be kept on, ask somebody to check it once in a while to prevent the food
inside from spoiling in case of a power failure.

WHAT TO DO IF…

WARNING!

Before troubleshooting, disconnect the mains plug from the mains socket.
Only a qualified electrician or competent person must do the troubleshooting that is not in
this manual.

There are some sounds during normal use (compressor, refrigerant circulation).

Problem Possible cause Solution

The appliance is noisy The appliance is not supported

The appliance does not
operate. The lamp does
not operate.

The mains plug is not connected

4) If foreseen.

properly

The appliance is switched off. Switch on the appliance.

to the mains socket correctly.

Check if the appliance stands sta­ble (all the four feet should be on
the floor)

Connect the mains plug to the
mains socket correctly.

What to do if… 15

Problem Possible cause Solution

The appliance has no power.

The lamp does not work. The lamp is in stand-by. Close and open the door.
The lamp is defective. Refer to "Replacing the lamp".

The compressor operates
continually.

The door is not closed correctly. Refer to "Closing the door".
The door has been opened too

The product temperature is too

The room temperature is too

The compressor does not
start immediately after
pressing the COOLMATIC
switch, or after changing
the temperature.

Water flows on the rear
plate of the refrigerator.

Water flows into the re­frigerator.

Products prevent that water

Temperature cannot be
set .

The temperature in the
appliance is too low/high.

The door is not closed correctly. Refer to "Closing the door".
The product temperature is too

Many products are stored at the

The temperature in the re­frigerator is too high.

There is no voltage in the mains
socket.

The temperature is not set cor­rectly.

frequently.

high.

high.
This is normal, no error has oc-

curred.

During the automatic defrosting
process, frost defrosts on the
rear plate.

The water outlet is clogged. Clean the water outlet.

flows into the water collector.
COOLMATIC function switched

on.

The temperature regulator is not
set correctly.

high.

same time.
There is no cold air circulation in

the appliance.

Connect a different electrical ap­pliance to the mains socket.
Contact a qualified electrician.

Set a higher temperature.

Do not keep the door open longer
than necessary.

Let the product temperature de­crease to room temperature be­fore storage.

Decrease the room temperature.

The compressor starts after a pe­riod of time.

This is correct.

Make sure that products do not
touch the rear plate.

Switch off COOLMATIC manually,
or wait to set the temperature
until the function has reset auto­matically. Refer to "COOLMATIC
function"..

Set a higher/lower temperature.

Let the product temperature de­crease to room temperature be­fore storage.

Store less products at the same
time.

Make sure that there is cold air
circulation in the appliance.

16 Technical data

Replacing the lamp

The appliance is equipped with a longlife LED interior light.
Only service is allowed to replace the lighting device. Contact your Service Center

Closing the door

1. Clean the door gaskets.

2. If necessary, adjust the door. Refer to "Installation".

3. If necessary, replace the defective door gaskets. Contact the Service Center.

TECHNICAL DATA

Dimension of the recess
Height 1780 mm
Width 560 mm
Depth 550 mm
Voltage 230-240 V
Frequency 50 Hz

The technical information are situated in the rating plate on the internal left side of the
appliance and in the energy label.

INSTALLATION

Positioning

WARNING!

If you are discarding an old appliance that has a lock or catch on the door, you must ensure
that it is made unusable to prevent young children being trapped inside.

The appliance shall have the plug accessible after installation.

Install this appliance at a location where the ambient temperature corresponds to the cli­mate class indicated on the rating plate of the appliance:

Climate class Ambient temperature

SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C

Environmental concerns 17

Electrical connection

Before plugging in, ensure that the voltage and frequency shown on the rating plate corre­spond to your domestic power supply.
The appliance must be earthed. The power supply cable plug is provided with a contact for
this purpose. If the domestic power supply socket is not earthed, connect the appliance to a
separate earth in compliance with current regulations, consulting a qualified electrician.
The manufacturer declines all responsibility if the above safety precautions are not ob­served.
This appliance complies with the E.E.C. Directives.

Ventilation requirements

The airflow behind the appliance must be suffi­cient.

50 mm

min.
200 cm

2

min.
200 cm

2

ENVIRONMENTAL CONCERNS

The symbol on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it should be taken to the appropriate collection point
for the recycling of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of this product,
please contact your local council, your household waste disposal service or the shop where
you purchased the product.

18

PER RISULTATI PERFETTI

Grazie per aver scelto di acquistare questo prodotto AEG.
Lo abbiamo creato per fornirvi prestazioni impeccabili per
molti anni, grazie a tecnologie innovative che vi
semplificheranno la vita - funzioni che non troverete sui
normali elettrodomestici. Vi invitiamo di dedicare qualche
minuto alla lettura per sapere come trarre il massimo dal
vostro elettrodomestico.

ACCESSORI E PRODOTTI DI CONSUMO

All'interno del webshop AEG troverete tutto ciò che vi
serve per fare in modo che i vostri elettrodomestici AEG
siano sempre perfettamente puliti e funzionanti. Non
mancano inoltre una vasta gamma di accessori studiati e
realizzati conformemente agli elevati standard qualitativi
che vi aspettate: pentole, scolaposate, portabottiglie e
sacchi biancheria delicati...

Visitate il webshop su
www.aeg-electrolux.com/shop

INDICE

Indice

20 Informazioni per la sicurezza
22 Pannello dei comandi
26 Primo utilizzo
26 Utilizzo quotidiano
28 Consigli e suggerimenti utili
29 Pulizia e cura
30 Cosa fare se…
32 Dati tecnici
32 Installazione
33 Considerazioni ambientali

19

In questo manuale sono riportati i seguenti
simboli:

Informazioni importanti relative alla
prevenzione dei rischi per la salute personale
e dei danni alle apparecchiature.

Informazioni e consigli generali

Informazioni in materia di sicurezza
ambientale

Con riserva di modifiche

20 Informazioni per la sicurezza

INFORMAZIONI PER LA SICUREZZA

Per garantire un impiego corretto e sicuro dell'apparecchio, prima dell'installazione e del
primo utilizzo leggere con attenzione il libretto istruzioni, inclusi i suggerimenti e le avver­tenze. Per evitare errori e incidenti, è importante garantire che tutte le persone che utilizza­no l'apparecchio ne conoscano il funzionamento e le caratteristiche di sicurezza. Conservare
queste istruzioni e accertarsi che rimangano unite all'apparecchio in caso di vendita o tra­sloco, in modo che chiunque lo utilizzi sia correttamente informato sull'uso e sulle norme di
sicurezza.
Per la sicurezza delle persone e delle cose osservare le precauzioni indicate nelle presenti
istruzioni per l'utente, il produttore non è responsabile dei danni provocati da eventuali
omissioni.

Sicurezza dei bambini e delle persone fragili

• Questo apparecchio non deve essere usato da persone, bambini inclusi, con ridotte capa­cità fisiche, sensoriali o psichiche, oppure prive di conoscenza e esperienza, a meno che
non siano state istruite all'uso dell'apparecchio da parte dei responsabili della loro sicu­rezza, oppure sotto vigilanza di questi.

I bambini devono essere sorvegliati per assicurarsi che non giochino con l'apparecchio.

• Tenere i materiali di imballaggio al di fuori della portata dei bambini. Alcuni materiali
possono creare rischi di soffocamento.

• Qualora l'apparecchio venga demolito, estrarre la spina dalla presa, tagliare il cavo di col­legamento (il più vicino possibile all'apparecchio) e smontare lo sportello per evitare che i
bambini giocando possano subire scosse elettriche o chiudersi dentro l'apparecchio.

• Se questo nuovo apparecchio, che è dotato di guarnizioni magnetiche nello sportello, va
a sostituirne uno più vecchio avente sportello o coperchio con chiusure a molla, si deve
rendere inutilizzabili tali chiusure prima di eliminare l'apparecchio sostituito, per evitare
che diventi una trappola mortale per i bambini.

Norme di sicurezza generali

ATTENZIONE

Accertarsi che le aperture di ventilazione non siano ostruite.

• L'apparecchiatura è progettata per la conservazione domestica di alimenti e/o bevande
nelle modalità descritte nelle presenti istruzioni.

• Non utilizzare dispositivi meccanici o altri mezzi artificiali per accelerare lo sbrinamento.

• Non utilizzare altre apparecchiature elettriche (per esempio gelatiere) all'interno del fri­gorifero, salvo quelle approvate per tale scopo dal produttore.

• Non danneggiare il circuito refrigerante.

• Il circuito refrigerante dell'apparecchiatura contiene isobutano (R600a), un gas naturale
con un elevato livello di compatibilità ambientale che, tuttavia, è infiammabile.

Durante il trasporto e l'installazione dell'apparecchiatura, assicurarsi che nessuno dei
componenti del circuito refrigerante venga danneggiato.

In caso di danneggiamento del circuito refrigerante:

Informazioni per la sicurezza 21

– Evitare fiamme libere e scintille
– Aerare bene il locale in cui si trova l'apparecchiatura

• È pericoloso cambiare le specifiche o modificare il prodotto in qualunque modo. Un dan­neggiamento del cavo potrebbe provocare cortocircuiti, incendi e/o scosse elettriche.

AVVERTENZA

Tutti i componenti elettrici (cavo di alimentazione, spina, compressore) devono essere sosti­tuiti da un tecnico certificato o da personale d'assistenza qualificato.

1. Non collegare prolunghe al cavo di alimentazione.

2. Evitare che il lato posteriore dell'apparecchiatura possa schiacciare o danneggiare la

spina, causandone il surriscaldamento con un conseguente rischio di incendio.

3. La spina dell'apparecchiatura deve trovarsi in una posizione accessibile.

4. Evitare di tirare il cavo di alimentazione.

5. Se la presa elettrica non è perfettamente stabile, non inserire la spina. Il collegamen-

to potrebbe provocare scosse elettriche o creare un rischio di incendio.

6.

L'apparecchiatura non deve essere messo in funzione senza il coprilampada interno
della luce interna.

• Questa apparecchiatura è pesante. Prestare attenzione quando occorre spostarla.

• Evitare di estrarre o di toccare gli alimenti riposti nel vano congelatore con le mani ba­gnate o umide; il contatto potrebbe provocare abrasioni o ustioni da freddo.

• Evitare un'esposizione prolungata dell'apparecchiatura alla luce solare diretta.

•

Lampadine

6)

utilizzate in questa apparecchiatura sono lampadine speciali selezionate per
essere usate unicamente negli elettrodomestici. Non sono adatte per l'illuminazione degli
ambienti.

5)

Uso normale

• Non appoggiare pentole calde sulle parti in plastica dell'apparecchiatura.

• Non riporre gas o liquidi infiammabili nell'apparecchio: i contenitori potrebbero esplode­re.

• Osservare rigorosamente le raccomandazioni del produttore riguardo alla conservazione
degli alimenti. Leggere attentamente le relative istruzioni.

Pulizia e cura

• Prima di eseguire qualunque intervento di manutenzione, spegnere l'apparecchiatura ed
estrarre la spina dalla presa.

• Non pulire l'apparecchiatura con oggetti metallici.

• Ispezionare regolarmente lo scarico dell'acqua di sbrinamento. Lo scarico deve essere
sempre perfettamente libero. L'ostruzione dello scarico può causare un deposito di acqua
sul fondo dell'apparecchiatura.

Installazione

Per il collegamento elettrico, seguire attentamente le istruzioni dei paragrafi corrispondenti.

5) Per le apparecchiature che prevedono il coprilampada.

6) Nel caso in cui la lampadina sia prevista.

22 Pannello dei comandi

• Disimballare l'apparecchio e assicurarsi che non presenti danni. Non collegare l'apparec­chio se è danneggiato. Segnalare immediatamente gli eventuali danni al negozio in cui è
stato acquistato. In questo caso conservare l'imballaggio.

• Si consiglia di attendere almeno due ore prima di collegare l'apparecchio per consentire
all'olio di arrivare nel compressore.

• Attorno all'apparecchio vi deve essere un'adeguata circolazione dell'aria, altrimenti si può
surriscaldare. Per ottenere una ventilazione sufficiente seguire le istruzioni di installazio­ne.

• Se possibile il retro dell'apparecchio dovrebbe essere posizionato contro una parete per
evitare di toccare le parti calde o di rimanervi impigliati (compressore, condensatore),
evitando così possibili scottature.

• L'apparecchio non deve essere posto vicino a radiatori o piani di cottura a gas.

• Installare l'apparecchio in modo che la presa rimanga accessibile.

•

Per il collegamento idrico, usare solo sorgenti d'acqua potabile.

7)

Assistenza tecnica

• Gli interventi elettrici sull'apparecchiatura devono essere eseguiti esclusivamente da elet­tricisti qualificati o da personale competente.

• Gli interventi di assistenza devono essere eseguiti esclusivamente da tecnici autorizzati e
utilizzando solo ricambi originali.

Tutela ambientale

Questo apparecchio non contiene gas che potrebbero danneggiare lo strato di ozono nel
circuito refrigerante o nei materiali isolanti. L'apparecchio non deve essere smaltito assieme
ai rifiuti urbani e alla spazzatura. La schiuma dell'isolamento contiene gas infiammabili: lo
smaltimento dell'apparecchio va eseguito secondo le prescrizioni vigenti da richiedere alle
autorità locali. Evitare di danneggiare il gruppo refrigerante, specialmente nella parte po­steriore vicino allo scambiatore di calore. I materiali usati su questo apparecchio contrasse­gnati dal simbolo

sono riciclabili.

PANNELLO DEI COMANDI

1 2 3 4 5 6

1 ON/OFF tasto
2 Mode tasto
3 OK tasto
4 Tasto Temperatura più fresca
5 Tasto Temperatura più calda

7) Per gli apparecchi che prevedono un collegamento alla rete idrica.
