SKD71800F0 EN User manual 2

IT Istruzioni per l’uso 16 RUИнструкция по эксплуатации 31

www.aeg.com

CONTENTS

1. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

6. WHAT TO DO IF… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

7. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

8. NOISES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

9. TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com

www.aeg.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts. When contacting Service, ensure that you have the following data available. The information can be found on the rating plate. Model, PNC, Serial Number.

Warning / Caution-Safety information General information and tips Environmental information

Subject to change without notice.

ENGLISH 3

SAFETY INSTRUCTIONS

In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. Save these instructions and make sure that they remain with the appliance if it is moved or sold, so that everyone using it through its life will be properly informed on appliance use and safety. For the safety of life and property keep the precautions of these user's instructions as the manufacturer is not responsible for damages caused by omission.

1.1 Children and vulnerable people safety

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

• Keep all packaging well away from children. There is risk of suffocation.

• If you are discarding the appliance pull the plug out of the socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent playing children to suffer electric shock or to close themselves into it.

• If this appliance featuring magnetic door seals is to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make that spring lock unusable before you discard the old appliance. This will prevent it from becoming a death trap for a child.

1.2 General safety

WARNING!

Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

• The appliance is intended for keeping foodstuff and/or beverages in a normal household and similar applications such as:

– staff kitchen areas in shops, offices

and other working environments;

– farm houses and by clients in hotels,

motels and other residential type environments;

– bed and breakfast type environ-

ments;

– catering and similar non-retail appli-

cations.

• Do not use a mechanical device or any artificial means to speed up the thawing process.

• Do not use other electrical appliances (such as ice cream makers) inside of refrigerating appliances, unless they are approved for this purpose by the manufacturer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable.

During transportation and installation of the appliance, be certain that none of the components of the refrigerant circuit become damaged.

If the refrigerant circuit should become damaged:

– avoid open flames and sources of

ignition

– thoroughly ventilate the room in

which the appliance is situated

• It is dangerous to alter the specifications or modify this product in any way. Any damage to the cord may cause a short-circuit, fire and/or electric shock.

www.aeg.com

WARNING!

Any electrical component (power cord, plug, compressor) must be replaced by a certified service agent or qualified service personnel to avoid hazard.

Power cord must not be lengthened.

Make sure that the power plug is not squashed or damaged by the back of the appliance. A squashed or damaged power plug may overheat and cause a fire.

Make sure that you can come to the mains plug of the appliance.

Do not pull the mains cable.

If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock or fire.

You must not operate the appliance without the lamp cover (if foreseen) of interior lighting.

• This appliance is heavy. Care should be taken when moving it.

• Do not remove nor touch items from the freezer compartment if your hands are damp/wet, as this could cause skin abrasions or frost/freezer burns.

• Avoid prolonged exposure of the appliance to direct sunlight.

• Bulb lamps (if foreseen) used in this appliance are special purpose lamps selected for household appliances use only. They are not suitable for household room illumination.

1.3 Daily use

• Do not put hot pot on the plastic parts in the appliance.

• Do not store flammable gas and liquid in the appliance, because they may explode.

• Appliance's manufacturers storage recommendations should be strictly adhered to. Refer to relevant instructions.

1.4 Care and cleaning

• Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket.

• Do not clean the appliance with metal objects.

• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean the drain. If the drain is blocked, water will collect in the bottom of the appliance.

1.5 Installation

For electrical connection carefully follow the instructions given in specific paragraphs.

• Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it. In that case retain packing.

• It is advisable to wait at least four hours before connecting the appliance to allow the oil to flow back in the compressor.

• Adequate air circulation should be around the appliance, lacking this leads to overheating. To achieve sufficient ventilation follow the instructions relevant to installation.

• Wherever possible the back of the product should be against a wall to avoid touching or catching warm parts (compressor, condenser) to prevent possible burn.

• The appliance must not be located close to radiators or cookers.

• Make sure that the mains plug is accessible after the installation of the appliance.

• Connect to potable water supply only (If a water connection is foreseen).

1.6 Service

• Any electrical work required to do the servicing of the appliance should be carried out by a qualified electrician or competent person.

• This product must be serviced by an authorized Service Centre, and only genuine spare parts must be used.

1.7 Environment Protection

This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. The insulation foam contains flammable

2. CONTROL PANEL

Display

Temperature warmer button

Temperature colder button

OK button

Mode button

ON/OFF button

It is possible to change predefined sound of buttons to a loudly one by pressing together Mode button and Temperature colder button for some seconds. Change is reversible.

2.1 Display

Timer function

DYNAMICAIR function

Minute Minder function

Child Lock function

Alarm indicator

Temperature indicator

Holiday function

COOLMATIC function

ENGLISH 5

gases: the appliance shall be disposed according to the applicable regulations to obtain from your local authorities. Avoid damaging the cooling unit, especially at the rear near the heat exchanger. The materials used on this appliance marked by the

symbol

56 4 3 2

are recyclable.

2.2 Switching on

To switch on the appliance do these steps:

Connect the mains plug to the power socket.

Press the ON/OFF button if the display is off.

The alarm buzzer could operate after few seconds.

To reset the alarm refer to "High temperature alarm".

If "dEMo" appears on the display, the appliance is in demonstration mode. Refer to "What to do if..." paragraph.

The temperature indicators show the set default temperature.

To select a different set temperature re-

5 64321

fer to "Temperature regulation".

2.3 Switching off

To switch off the appliance do these steps:

Press the ON/OFF button for 5 seconds.

The display switches off.

To disconnect the appliance from the power disconnect the mains plug from the power socket.

www.aeg.com

2.4 Temperature regulation

The set temperature of the fridge may be adjusted by pressing the temperature button. Set default temperature: +5°C for the fridge. The temperature indicator shows the set temperature. The set temperature will be reached within 24 hours.

After a power failure the set temperature remains stored.

2.5 DYNAMICAIR function

To switch on the function:

Press the Mode button until the corresponding icon appears.

The DYNAMICAIR indicator flashes.

Press the OK button to confirm. The DYNAMICAIR indicator is

shown.

To switch off the function:

Press the Mode button until the DYNAMICAIR indicator flashes.

Press the OK button to confirm.

The DYNAMICAIR indicator goes off.

If the function is activated automatically the DYNAMICAIR indicator is not shown (refer to "Daily use"). The activation of the DYNAMICAIR function increases the energy consumption.

2.6 Minute Minder function

The Minute Minder function is to be used to set an acoustic alarm at the preferred time, useful for example when a recipe requires to cool down a mixture for a certain length of time. To switch on the function:

Press the Mode button until the corresponding icon appears.

The Minute Minder indicator flashes. The Timer shows the set value (30

minutes) for a few seconds.

Press the Timer regulator button to change the Timer set value from 1 to 90 minutes.

Press the OK button to confirm. The Minute Minder indicator is

shown.

The Timer start to flash (min). At the end of the countdown the Minute Minder indicator flashes and an audible alarm sounds:

press OK button to switch off the

sound and terminate the function. It is possible to deactivate the function at any time during the countdown:

Press the Mode button until the Mi-

nute Minder indicator flashes.

Press the OK button to confirm.

The Minute Minder indicator goes

off. It is possible to change the time at any time during the countdown and at the end by pressing the Temperature colder button and the Temperature warmer button.

2.7 Child Lock function

To lock the buttons from unintentional operation select the Child Lock function. To switch on the function:

Press the Mode button until the cor-

responding icon appears.

The Child Lock indicator flashes.

Press the OK button to confirm.

The Child Lock indicator is shown. To switch off the function:

Press the Mode button until the

Child Lock indicator flashes.

Press the OK button to confirm.

The Child Lock indicator goes off.

2.8 COOLMATIC function

If you need to insert a large amount of warm food, for example after doing the grocery shopping, we suggest activating the COOLMATIC function to chill the products more rapidly and to avoid warming the other food which is already in the refrigerator. To switch on the function:

Press the Mode button until the cor-

responding icon appears.

The COOLMATIC indicator flashes.

Press the OK button to confirm.

The COOLMATIC indicator is

shown. The COOLMATIC function shuts off automatically after approximately 6 hours. To switch off the function before its automatic end:

Press the Mode button until the

COOLMATIC indicator flashes.

Press the OK button to confirm.

The COOLMATIC indicator goes off.

The function switches off by selecting a different fridge set temperature.

2.9 Holiday function

This function allows you to keep the refrigerator closed and empty during a long holiday period without the formation of a bad smell.

The fridge compartment must be empty with holiday function on.

To switch on the function:

Press the Mode button until the cor-

responding icon appears.

ENGLISH 7

The Holiday indicator flashes. The fridge temperature indicator

shows the set temperature.

Press the OK button to confirm. The Holiday indicator is shown.

To switch off the function:

Press the Mode button until the Holiday indicator flashes.

Press the OK button to confirm.

The Holiday indicator goes off.

The function switches off by selecting a different fridge set temperature.

2.10 Door open alarm

An acoustic alarm will sound if the door is left open for a few minutes. The door open alarm conditions are indicated by:

• flashing Alarm indicator

• acoustic buzzer When normal conditions are restored (door closed), the alarm will stop. During the alarm, the buzzer can be switched off by pressing any button.

3. DAILY USE

3.1 Cleaning the interior

Before using the appliance for the first time, wash the interior and all internal accessories with lukewarm water and some neutral soap so as to remove the typical smell of a brand-new product, then dry thoroughly.

Do not use detergents or abrasive powders, as these will damage the finish.

If “dEMo” appears on the Display, the appliance is in demonstration mode: refer to “WHAT TO DO IF...” paragraph.

www.aeg.com

3.2 DYNAMICAIR

The refrigerator compartment is equipped with a device that allows for rapid cooling of foods and more uniform temperature in the compartment. This device activates by itself when needed, for example for a quick temperature recovering after door opening or when the ambient temperature is high. Allows you to switch on the device manually when needed (refer to "DYNAMICAIR Function").

The DYNAMICAIR device stops when the door is open and restarts immediately after the door closing.

3.3 Movable shelves

The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired. For better use of space, the front halfshelves can lie over the rear ones.

3.4 Positioning the door shelves

To permit storage of food packages of various sizes, the door shelves can be placed at different heights.

3.5 Positioning the sliding box

The sliding box can be placed at different heights. Do make these adjustments proceed as follow:

lift the shelf with the sliding box upwards and out of the holders in the door

remove the retaining bracket out of the guide under the shelf

Reverse the above operation to insert the sliding box at a different height.

4. HELPFUL HINTS AND TIPS

ENGLISH 9

4.1 Hints for energy saving

• Do not open the door frequently or

leave it open longer than absolutely necessary.

• If the ambient temperature is high and

the Temperature Regulator is set to low temperature and the appliance is fully loaded, the compressor may run continuously, causing frost or ice on the evaporator. If this happens, set the Temperature Regulator toward warmer settings to allow automatic defrosting and so a saving in electricity consumption.

4.2 Hints for fresh food refrigeration

To obtain the best performance:

• do not store warm food or evaporat-

ing liquids in the refrigerator

• do cover or wrap the food, particularly

if it has a strong flavour

• position food so that air can circulate

freely around it

4.3 Hints for refrigeration

Useful hints:

Meat (all types) : wrap in polythene bags and place on the glass shelf above the vegetable drawer. For safety, store in this way only one or two days at the most. Cooked foods, cold dishes, etc.: these should be covered and may be placed on any shelf. Fruits and vegetables: these should be thoroughly cleaned and placed in the special drawer(s) provided. When in contact, lemon juice can discolor the plastic parts of your fridge. It is therefore recommended to keep citruses in separate containers. Butter and cheese: these should be placed in special airtight containers or wrapped in aluminium foil or polythene bags to exclude as much air as possible. Bottles: these should have a cap and should be stored in the bottle rack on the door. Bananas, potatoes, onions and garlic, if not packed, must not be kept in the refrigerator.

5. CARE AND CLEANING

CAUTION!

Unplug the appliance before carrying out any maintenance operation.

This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must therefore only be carried out by authorized technicians.

5.1 Periodic cleaning

The equipment has to be cleaned regularly:

• clean the inside and accessories with

lukewarm water and some neutral soap.

• regularly check the door seals and wipe clean to ensure they are clean and free from debris.

• rinse and dry thoroughly.

Do not pull, move or damage any pipes and/or cables inside the cabinet. Never use detergents, abrasive powders, highly perfumed cleaning products or wax polishes to clean the interior as this will damage the surface and leave a strong odour.

Clean the condenser (black grill) and the compressor at the back of the appliance with a brush. This operation will improve

www.aeg.com

the performance of the appliance and save electricity consumption.

Take care of not to damage the cooling system.

Many proprietary kitchen surface cleaners contain chemicals that can attack/ damage the plastics used in this appliance. For this reason it is recommended that the outer casing of this appliance is only cleaned with warm water with a little washing-up liquid added. After cleaning, reconnect the equipment to the mains supply.

5.2 Periods of non-operation

When the appliance is not in use for long periods, take the following precautions:

5.3 Defrosting of the refrigerator

• disconnect the appliance from electricity supply

• remove all food

• defrost (if foreseen) and clean the appliance and all accessories

• leave the door/doors ajar to prevent unpleasant smells.

If the cabinet will be kept on, ask somebody to check it once in a while to prevent the food inside from spoiling in case of a power failure.

Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates. Periodically clean the defrost water drain hole in the middle of the refrigerator compartment channel to prevent the water overflowing and dripping onto the food inside. Use the special cleaner provided, which you will find already inserted into the drain hole.

6. WHAT TO DO IF…

WARNING!

Before troubleshooting, disconnect the mains plug from the mains socket. Only a qualified electrician or competent person must do the troubleshooting that is not in this manual.

ENGLISH 11

Problem Possible cause Solution

The appliance is noisy

The appliance is not supported properly

Check if the appliance stands stable (all the four feet should be on the floor)

The appliance does not operate. The

The appliance is switched off.

Switch on the appliance.

lamp does not operate.

The mains plug is not

connected to the mains

Connect the mains plug to the mains socket correctly.

socket correctly.

The appliance has no

power. There is no voltage in the mains socket.

Connect a different electrical appliance to the mains socket. Contact a qualified electrician.

The lamp does not

The lamp is in stand-by. Close and open the door.

work.

The lamp is defective. Refer to "Replacing the

lamp".

The compressor operates continually.

The door is not closed

The door has been

The temperature is not set correctly.

correctly.

opened too frequently.

Set a higher temperature.

Refer to "Closing the door".

Do not keep the door open longer than necessary.

The product temperature

is too high.

Let the product temperature decrease to room temperature before storage.

The room temperature is

too high.

The compressor does not start im-

This is normal, no error has occurred.

Decrease the room temperature.

The compressor starts after a period of time.

mediately after pressing the COOLMATIC switch, or after changing the temperature.

Water flows on the rear plate of the refrigerator.

Water flows into the refrigerator.

During the automatic defrosting process, frost defrosts on the rear plate.

The water outlet is clogged.

This is correct.

Clean the water outlet.

www.aeg.com

Problem Possible cause Solution

Products prevent that wa-

ter flows into the water collector.

The temperature in the appliance is too

Many products are stored at the same time.

Make sure that products do not touch the rear plate.

Store less products at the same time.

low/high.

The temperature in the refrigerator is too high.

Upper or lower square is shown in the temperature Display.

There is no cold air circulation in the appliance.

An error has occurred in measuring the temperature.

Make sure that there is cold air circulation in the appliance.

Call your service representative (the cooling system will continue to keep food products cold, but temperature adjustment will not be possible).

dEMo appears on

the Display.

The appliance is in demonstration mode (dEMo).

Keep pressed approximately 10 sec. the OK button since a long sound of buzzer is heard and the Display shut off for a short while: appliance start works regularly.

The buzzer sounds. The Display is red.

6.1 Replacing the lamp

The appliance is equipped with a longlife LED interior light. Only service is allowed to replace the lighting device. Contact your Service Center.

The door is not closed correctly.

Refer to "Door open alarm".

If necessary, adjust the door. Refer to "Installation".

If necessary, replace the defective door gaskets. Contact the Service Center.

6.2 Closing the door

Clean the door gaskets.

7. INSTALLATION

7.1 Positioning

WARNING!

If you are discarding an old appliance that has a lock or catch on the door, you must ensure that it is made unusable to prevent young children being trapped inside.

The appliance shall have the plug accessible after installation.

Install this appliance at a location where the ambient temperature corresponds to the climate class indicated on the rating plate of the appliance:

Climate class

SN +10°C to + 32°C N +16°C to + 32°C ST +16°C to + 38°C T +16°C to + 43°C

Ambient temperature

7.2 Electrical connection

Before plugging in, ensure that the voltage and frequency shown on the rating

7.3 Ventilation requirements

ENGLISH 13

plate correspond to your domestic power supply. The appliance must be earthed. The power supply cable plug is provided with a contact for this purpose. If the domestic power supply socket is not earthed, connect the appliance to a separate earth in compliance with current regulations, consulting a qualified electrician. The manufacturer declines all responsibility if the above safety precautions are not observed. This appliance complies with the E.E.C. Directives.

8. NOISES

There are some sounds during normal running (compressor, refrigerant circulation).

5 cm

min. 200 cm

The airflow behind the appliance must

min. 200 cm

be sufficient.

SSSRR

HISSS!

CLICK!

BRRR!

CRACK!

BLUBB!

www.aeg.com

SSSRRR!

HISSS!

BLUBB!

SSSRRR!

HISSS!

BLUBB!

CLICK!

BRRR!

CLICK!

BRRR!

CRACK!CRACK!

9. TECHNICAL DATA

Dimension of the recess Height 1780 mm Width 560 mm Depth 550 mm Voltage 230-240 V Frequency 50 Hz

The technical information are situated in the rating plate on the internal left side of the appliance and in the energy label.

10. ENVIRONMENT CONCERNS

ENGLISH 15

Recycle the materials with the symbol applicable containers to recycle it. Help protect the environment and human health and to recycle waste of electrical and electronic

. Put the packaging in

appliances. Do not dispose appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.

+ 33 hidden pages
