AEG 2842-6 I User Manual
ÖKO - SANTO 2842-6 i
Integrating Fridge Freezer
Operating and Installation Instructions
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
2222 020-54
2
Dear customer,
Before placing your new refrigerator/freezer into operation please
read these operating instructions carefully. They contain important
information for safe use, for installation and for care of the appliance.
Please keep these operating instructions for future reference. Pass
them on to possible new owners of the appliance.
Notes which are important for your safety or for the proper functioning
of the appliance are stressed with a warning triangle and/or words
(Warning!, Important!, Caution!). Please observe the following instructions carefully.
Additional information regarding operation and practical applications
of the appliance appear after this symbol.
Tips and notes concerning economical and environmentally sound
use of the appliance are marked with the cloverleaf.
In the event of a malfunction, these operating instructions contain
information on how to rectify faults yourself, see the “Something Not
Working” section.
For futher assistance contact your local AEG Service Force Centre,
see the chapter 2Service and Spare Parts”.
Printed on paper manufactured with environmentally sound processes.
who thinks ecologically acts accordingly ...
3
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Appliance Packaging Information . . . . . . . . . . . . . . . . . . . . . . . 5
Disposal of old Appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Remove transport safeguard . . . . . . . . . . . . . . . . . . . . . . . . . 6
Starting up and temperature regulation . . . . . . . . . . . . .....7
Ambient temperature switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Interior Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Storage shelves . . . .................................. 8
Door rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ........... 8
Fresh food refrigeration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Freezing and storing frozen food . . . . . . . . . . . . . . . . . . . . . . 9
Ice pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Preparation of Ice Cubes . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Storage goods Symbols/ Freezing calendar . . . . . . . . . . . . .11
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . ..............11
Switching off the appliance . . . . . . ..................... 12
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Energy Saving Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Something Not Working. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Changing the light bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Service and Spare Parts.............................. 17
Guarantee Conditions ............................... 18
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ....20
Your appliance needs air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Reversing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Housing dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Instructions for building in . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Regulations, Standards, Guidelines. . . . . . . . . . . . . . . . . . . . 25
2222 020-54
4
Safety
Please read this instruction book before using the appliance and retain
for future reference. These warnings are provided in the interests of your
safety, ensure you understand them fully before using the appliance.
Intended use
• The appliance is intended for use in the home. It is suitable for the
cooling, freezing and storing of frozen food, as well as for making
ice. If the appliance is used for purposes other than those intended
or used incorrectly, no liability can be accepted by the manufacturer
for any damage that may be caused.
• Alterations or changes to the appliance are not permitted for reasons
of safety.
Prior to initial start–up
• Check the appliance for transport damage. Under no circumstance
should a damaged appliance be plugged in! In the event of damage,
please contact your retailer.
Refrigerant
The refrigerant isobutane (R600a) is contained within the refrigerant
circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable.
• During transportation and installation of the appliance, be certain that
none of the components of the refrigerant circuit become damaged.
• If the refrigerant circuit should become damaged:
– avoid open flames and sources of ignition;
– thoroughly ventilate the room in which the appliance is situated.
Safety of children
• Keep packaging material away from children.
• Please make old appliances unusable prior to disposal. Pull out the
mains plug, cut off the mains cable and remove any locks or catches, to prevent young children being trapped inside.
• Do not allow children to tamper with the controls or play with the product.
Daily Operation
• Containers with flammable gases or liquids can leak at low temperatures. There is a risk of an explosion! Do not store any containers
with flammable materials such as, for example, spray cans, fire
25
Regulations, Standards, Guidelines
This appliance was designed for household use and was manufactured in accordance with the appropriate standards. The necessary
measures in accordance with appliance safety legislation regulations
(GSG), accident prevention regulations for refrigeration appliances
(VBG 20) and the regulations of the German Society of Electrical
Engineers (VDE) were observed in the manufacture of this appliance.
The refrigerant circuit has been checked for leaks.
This appliance is in accordance with the following EU guidelines:
– 73/23/EWG dated 19 February 1973 - low voltage guidelines.
– 89/336/EWG dated 3 May 1989
(including guideline change notice 92/31/EWG) - EMV guideline
PR167/1
D
B
Fix cover (D) on guide (B) until it
clips into place.
5
extinguisher refill cartridges etc in the refrigerator/freezer.
• Bottles and cans must not be placed in the freezer compartment.
They can burst when the contents freeze, high carbonate content
drinks can even explode! Never store lemonade, juices, beer, wine,
sparkling wine etc. in the freezer compartment.
• Ice cream or ice cubes can cause “frost/freezer” burns if consumed
straight from the freezer.
• Do not touch frozen food with wet hands. Your hands could freeze
to the food.
• Do not operate any electrical appliances in the refrigerator/freezer
(e.g. electric ice cream makers, mixers etc.).
• Before cleaning the appliance, always switch off the appliance and
disconnect from the electricity supply.
• When unplugging always pull the plug from the mains socket, do not
pull on the cable.
Service
• Under no circumstances should you attempt to repair the appliance
yourself. Repairs carried out by inexperienced persons may cause
injury or serious malfunctioning. Contact your local AEG Service
Force Centre.
Disposal
Appliance Packaging Information
All materials are environmentally sound.
The plastics can be recycled and are identified as follows:
>PE< for polyethylene, e.g. the outer covering and the bags in the
interior.
>PS< for polystyrene foam, e.g. the pads, which are all free of chlo-
rofluorocarbon.
The carton parts are made from recycled paper and should be dispo-
sed of at a waste-paper recycling collection location.
Disposal of old Appliances
For environmental reasons, refrigeration appliances must be disposed of properly. This applies to your old appliance, and - at the end of
its service life - to your new appliance as well.
24
Open the appliance door and the
furniture door at 90°. Insert the
small square (B) into guide (A).
Put together the appliance door
and the furniture door and mark
the holes as indicated in the figure. Remove the squares and drill
holes with ø 2 mm at 8 mm from
the outer edge of the door. Place
the small square on the guide
again and fix it with the screws
supplied.
8mm
PR167
A
B
PR168
Should the lining up of the furniture door be necessary, use the
clearance of slots.
At the end of operations, it is
necessary to check if the door of
the furniture closes properly.
PR33
C
A
Fix cover (C) on guide (A) until it
clips into place.
