AED CR-T Quick Start Manual

Physio-Control
CR-T Quick Start
Guide

Read the Physio-Control CR-T Quick Start Guide for a brief
overview of the device's operation from the manufacturer.
Read about features, specifications, and usage.

Preset Scenarios:

LIFEPAK® CR-T AED TrAining SySTEm

F1 – SNNN

F2 – SSNN

F3 – NSNN

F4 – NNNN

S=Shock advised

N=No shock advised

C1 – Custom #!:

SSSSSSSSS

C2 – Custom #2:

SSSSSSSSS

Other options:

OP – Sets operating

settings for trainer

T1 – CPR time 1

T2 – CPR time 2

L – Language

During Training Session:

Not used for CR-T

Simulates pads are placed correctly and will

move on to analyzing the patient’s heart rhythm

Changes “SHOCK ADVISED” to “NO SHOCK

ADVISED” during analysis

Displays CHARGE-PAKsymbol to simulate need

to replace CHARGE-PAK

Simulates low internal battery condition

Simulates a need for service

Simulates motion and will prompt the user to

stop moving the patient during the analysis

Pause

Adjusts volume

Please refer to the C R -T Trainer Operating Instructions for

complete directions for use.

™

battery charger

Physio-Control
Headquarters

11811 Willows Road NE

Redmond, WA 98052
www.physio-control.com

Customer Support

P. O. Box 97006
Redmond, WA 98073
Toll free 80 0 442 1142

Fax [phone]

©2013 Physio-Control, Inc.
GDR 3308002_B

Physio-Control
Canada Sales, Ltd.

7111 Syntex Dri ve, 3rd Flo or
Mississauga, ON
L5N 8C3
Canada
Toll free 80 0 895 589 6
Fax [phone]

Setting Up Your CR-T

LIFEPAK® CR-T AED TrAining SySTEm

Setting Up Your CR-T

Slide the power switch on the right side of the device forward to turn on device.
OK symbol should now be in the readiness display.

Use the remote control to set your device into the following settings:

Sequence - Shock then No Shock Advised
(Fixed setting #1)

•

Press on the remote

• Press F1 ( )

• On the LED display you should see the first bars as

green and the second, third and fourth bars as red

• Press on the remote. It is now set for Shock,

No Shock Advised.

To configure other shock scenarios, go to Page 19 in the
CR -T Operating Instructions.

Set to Fully-Automatic
(no use of shock button) mode

•

Press on the remote

• Press OP ( )

• Use to make the first bar in the LED display red

• Press

• Be sure to put plastic cover over shock button

on device

To configure for the semi-automatic setting, go to page 20
in the C R-T Operating Instructions.

For a faster demo, set CPR time to 15 seconds

•

Press on the remote

• Press T1 ( )

• Move the red bar in the LED display to the first

position using the

• Press on the remote

To set other CPR time options, go to page 21 in the CR -T
Operating Instructions.

Tip:

When using the remote, be sure it is within range of the
LED display/IRDA port so it will read commands.

button
