PCA-6752 Series
Super7™ Half-size card PC with
VGA/LCD and Ethernet
Copyright Notice
This document is copyrighted, 2000. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result from
its use.
Acknowledgements
A ward is a trademark of A ward Software International, Inc.
IBM, PC/A T , PS/2 and VGA are trademarks of International Business
Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp.
UMC is a trademark of United Microelectronics Corporation.
All other product names or trademarks are properties of their
respective owners.
For more information on this and other Advantech products please
visit our website at: http://www.advantech.com
http://www.advantech.com/epc
For technical support and service for please visit our support website
at: http://www.advantech.com/support
This manual is for the PCA-6752F/6752N
Part No. 2006675200 1st Edition
Printed in T aiwan May 2000
Packing List
Before installing your board, ensure that the following materials have
been received:
• 1 PCA-6752 all-in-one single board computer
• 1 Ultra ATA (HDD) cable (457 mm) p/n: 1701400453
• 1 floppy disk drive interface cable (700 mm) p/n: 1701340700
• 1 COM port/Parallel port cable p/n: 1701260303
• 1 Y cable for AT-keyboard, PS/2 mouse (190 mm)
p/n: 1700060201
• 1 A TX/AT power cable p/n: 1700040052
• 1 startup manual
• CD-ROM or disks for utility, drivers, and manual (in PDF format)
• W arranty certificate
• Optional devices:
IrdA adapter: p/n : 9089000042
1 USB cable: p/n: 1700100177
If any of these items are missing or damaged, contact your distributor
or sales representative immediately .
Contents
Chapter 1 General Information ........................................1
1.1 Introduction............................................................................. 2
1.2 Specifications.......................................................................... 3
1.3 Board Layout: Dimensions ..................................................... 5
Chapter 2 Installation ........................................................7
2.1 Safety Precautions .................................................................. 8
2.2 Jumpers................................................................................... 9
2.3 Connectors ............................................................................ 10
2.4 Board Layout: Connector Locations (Component Side) ...... 11
2.5 Board Layout: Connector Locations (Solder Side) .............. 12
2.6 Board Layout: Jumper Locations (Component Side) ........... 13
2.7 Jumper Settings ................................................................... 14
2.8 Watchdog timer configuration (JP12) ................................. 21
2.9 Parallel Port Connector (CN1) ............................................ 22
2.10 Floppy Drive Connector (CN2) ............................................. 22
2.1 1 Enhanced IDE Connector (CN3) ........................................... 23
2.12 LCD Inverter Connector (CN4)............................................ 23
2.13 Inverter VR Connector (CN5) .............................................. 24
2.14 USB Connector (CN6) .......................................................... 24
2.15 18/24-bit LCD Display Connector (CN7)............................. 24
2.16 VGA Display Connector (CN8) ............................................ 25
2.17 IR Connector (CN9) .............................................................. 25
2.18 Audio Out/AC' 97 Connector (CN10).................................. 25
2.19 Ethernet Configuration (CN11)............................................ 26
2.20 ATX Feature Connector (CN12) .......................................... 26
2.21 Serial Ports COM1/RS- 232 (CN15)COM2/RS-232/422/485
(CN13) ................................................................................... 27
2.21.1 RS-232 connection (COM1-CN15) .............................27
2.22 AT Power Connector (CN14)................................................ 28
2.23 Keyboard & PS/2 Mouse Connector (CN16) ....................... 28
2.24 ISA Go ldf in ge r (C N1 8)......................................................... 28
2.25 CompactFlash Disk (CN19).................................................. 28
Chapter 3 Award BIOS Setup......................................... 29
3.1 A WARD BIOS Setup ................................................................ 30
3.1.1 Entering setup ...............................................................3 0
3.1.2 Standard CMOS setup ..................................................3 1
3.1.3 BIOS features setup ......................................................3 2
3.1.4 CHIPSET features setup................................................3 6
3.1.5 Power management setup..............................................37
3.1.6 PnP PCI configuration setup .........................................3 8
3.1.7 Load BIOS defaults .......................................................3 8
3.1.8 Load setup defaults.......................................................38
3.1.9 Integrated Peripherals ...................................................3 9
3.1.10 Password setting .........................................................3 9
3.1.11 IDE HDD auto detection..............................................4 0
3.1.12 Save & exit setup.........................................................4 0
3.1.13 Exit without saving ......................................................4 0
Chapter 4 AGP SVGA Setup (for PCA-6752F only).....41
4.1 Introduction........................................................................... 42
4.1.1 Chipset ...........................................................................4 2
4.1.2 Display memory ..............................................................42
4.1.3 Display types .................................................................4 2
4.1.4 Dual/Simultaneous display ............................................4 3
4.2 Installation ............................................................................ 44
4.2.1 Installation for Windows 95/98 ......................................4 4
4.2.2 Installation for Windows NT..........................................51
4.3 Further information.............................................................. 55
Chapter 5 AGP VGA Setup (for PCA-6752N only).....57
5.1 Introduction........................................................................... 58
5.1.1 Chipset ...........................................................................5 8
5.1.2 Display memory ..............................................................58
5.2 Installation ............................................................................ 59
5.2.1 Installation for Windows 95/98 ......................................5 9
5.2.2 Installation 0f VIA 4 In 1 Service Pack ...........................6 3
5.2.3 Installation for Windows NT..........................................66
5.3 Further information.............................................................. 70
Chapter 6 PCI Bus Ethernet Interface (for PCA-6752F/N
only)............................................................. 71
6.1 Introduction........................................................................... 72
6.2 Installation of Ethernet driver .............................................. 72
6.2.1 Installation for MS-DOS and Windows 3.1....................7 2
6.2.2 Installation for Windows 95/98 ......................................7 3
6.2.3 Installation for Windows NT..........................................76
6.3 Further information.............................................................. 80
Appendix A Programming the Watchdog Timer............ 81
A.1 Programming the W atchdog Timer ..................................... 82
Appendix B System Assignments ................................. 85
B.1 System I/O Ports .................................................................. 86
B.2 DMA Channel Assignments ................................................. 86
B.3 Interrupt Assignments ......................................................... 87
B.4 1st MB Memory Map ............................................................ 88
Appendix C Pin Assignments ......................................... 89
C.1 Parallel Port Connector (CN1) ............................................ 90
C.2 Floppy Drive Connector (CN2) ............................................. 91
C.3 Enhanced IDE connector (CN3) ............................................ 92
C.4 LCD inverter connector (CN4)............................................. 93
C.5 Inverter VR connector (CN5) ............................................... 93
C.6 USB Connector (CN6) .......................................................... 94
C.7 18/24-bit LCD display connector (CN7) .............................. 95
C.8 CRT Display Connector (CN8)............................................. 96
C.9 IR Connector (CN9) .............................................................. 96
C.10 Audio Out/AC97 Connector (CN10) .................................... 97
C.11 ATX Power Connector (CN12)............................................. 98
C.13 COM2 Serial Port (CN13)................................................... 98
C.14 A T Power Connector (CN14)................................................ 99
C.15 COM1 RS-232 Serial Port (CN15).................................... 100
C.16 Keyboard and Mouse Connnector (CN16).......................... 101
C.17 CompactFlash Card Connector (CN19) ............................. 102
C.18 F AN1 Con nector ................................................................. 103
Appendix D LCD Services ............................................ 105
D.1 LCD Services...................................................................... 106
Tables
Table 2-1: Jumper Assignments ...................................................................... 9
Table 2-2: Connector Assignments ................................................................10
Table 2-3: Serial port connections (COM1, COM2) ........................................ 27
Table B-1: System I/O ports ...........................................................................86
Table B-2: DMA channel assignments ............................................................ 87
Table B-3: Interrupt assignments ................................................................... 87
Table B-4:1st MB memory map ......................................................................88
Table C-1: Parallel port connector .................................................................. 90
Table C-2: Floppy drive connector .................................................................91
Table C-3: Enhanced IDE connector (CN3) .................................................... 92
Table C-4: LCD inverter connector (CN4) ....................................................... 93
Table C-5: Inverter VR connector (CN5) ......................................................... 93
Table C-6: USB1/USB2 connector (CN 6) ....................................................... 94
Table C-7: 24-bit LCD display connector (CN7) ............................................. 95
Table C-8: CRT display connector (CN 8) ....................................................... 96
Table C-9: IR connector (CN 9) ...................................................................... 96
Table C-10: AC97 connector (CN 10) ............................................................. 97
Table C-11: ATX power connector (CN 12) .....................................................98
Table C-12: COM2 RS-232/422/485 serial port (CN 13) ................................98
Table C-13: AT power connector (CN 14) ...................................................... 99
Table C-14: COM1 RS-232 serial port (CN 15) .............................................100
Table C-15: Keyboard and mouse connector (CN16) ...................................101
Table C-16: CompactFlash card connector (CN 19) ..................................... 102
Table C-16: ATX power connector ................................................................103
Figures
Figure 1-1: PCA-6752 board layout: Dimensions ............................................5
Figure 3-1: Setup program initial screen .................................................. 30
Figure 3-2: CMOS setup screen ............................................................. 31
Figure 3-3: BIOS features setup screen .................................................... 32
Figure 3-4: CHIPSET features setup screen ............................................... 36
Figure 3-5: Power management setup screen ............................................ 37
Figure 3-6: PCI configuration screen ....................................................... 38
Figure 3-7: Integrated peripherals .......................................................... 39
Figure 3-8: Load and Save .................................................................. 40
Figure 4-1: Selecting display settings ....................................................... 43
1
CHAPTER
General
Information
This chapter gives background
information on the PCA-6752 Series. It
then shows you how to configure the card
to match your application and prepare it
for installation into your PC.
Sections include:
• Card specifications
• Board layout: dimensions
• Board layout: jumper locations
• Board layout: connector locations
• Safety precautions
• Jumper settings
1.1 Introduction
The PCA-6752 Series is a half-size ISA-bus CPU card designed for a
Pentium® level CPU. Featuring powerful on-board functions such as
VGA, LCD, LAN and SSD, the versatile PCA-6752 Series can meet the
needs of different applications.
Well-Rounded Functionality
Advantech continues to expand its product line by integrating new
technology into our products and by offering customers multiple
combinations of features in a single product. The new PCA-6752 is a
perfect example of this. Packed with innovation, the PCA-6752 provides reasonably priced all-in-one functionality and high performance
operation. Several models of the PCA-6752 are offered as well as the
associated chassis, power supply and backplane to give customers a
"best fit" solution for their particular application.
Super7 ™ adds to Impressive list of features
Leading the list of features is the VIA MVP4 chipset for Super7
provided on the PCA-6752 Series models. The PCA-6752F is comprised
of a VIA VT82C686 (Super South Bridge) with a Trident CyberBlade i7
(North Bridge). The PCA-6752N-00A1 is comprised of a VT82C686
(Super South Bridge) with a VT82C501 (North Bridge). This chipset
provides an integrated 2D/3D AGP graphics engine with DVD hardware acceleration, Super I/O, advanced sound and hardware monitoring features. This integration is a cost effective way to increase the
number of features offered.
All PCA-6752 models support Super7 for Intel P54/P55C, AMD K5/K6/
K6-2/K6-3, NS MI/MII and IDT Winchip CPUs. W ith a 100 MHz bus
and AGP support, the Super7 platform offers great performance at a
reduced cost compared to Slot 1 solutions. The AGP interface is a
dedicated port between the PC's graphics controller and system
memory and gives a more robust scalable solution that provides
superior video performance without taxing overall system stability and
performance. There is a 10/100 Mbps Ethernet interface as well as SIR
2 PCA-6752 Series User's Manual
IrDA compliant infrared support. Ultra DMA 66 mode up to 66 MB/sec
is also supported. This high-speed interface helps designers and
integrators improve system performance by retrieving and sending
data faster.
1.2 Specifications
Standard SBC functions
• CPU: Socket 7 Intel P54C/P55C, AMD K5/K6/K6-2/K6-3, NS MI/MII and
IDT Winchip, supports 66/75/83/100 MHz FSB
• BIOS: A W ARD 256 KB Flash BIOS
• Chipset: PCA-6752F: VIA VT82C686 + Trident CyberBlade
PCA-6752N: VIA MVP4 (VIA VT82C686 +VT82C501)
• 2nd level cache: 512 KB/1 MB PBSRAM (66/100 MHz)
• System memory: DIMM x 1 Max. 128 MB
• IDE interface: One Enhanced IDE interface, Ultra DMA mode up to 66 MB/
sec.
• Floppy disk drive interface: Supports up to two FDDs (360 KB/1.2 MB/720
KB/1.44 MB/2.88 MB)
• Parallel port: One parallel port, supports EPP/ECP
• IR port: 115 Kbps SIR, IrDA 1.0 compliant
• Serial ports: One RS-232, One RS-232/422/485
• Watchdog timer: 62 level timer interval, generates system reset or IRQ1 1
AGP SVGA/Flat Panel Interface
PCA-6752F:
• Controller: Trident™ CyberBlade i7 VGA/LCD controller , 2 x AGP , Acceler-
ator Graphics port 1.0 compliant
• Display memory: UMA structure. 2 ~ 8 MB, shared with system memory .
Chapter 1 Hardware Configuration 3
• Display type: Simultaneously supports CRT and flat panel
(EL, LCD and gas plasma) displays
• LCD Interface: 18 bit resolution
• Display mode:
LCD panel supports up to 1024 x 768 @ 24 bpp
CR T display supports up to 1024 x 768 @ 18 bpp
PCA-6752N
• Controller: VIA MVP4 Built-in VGA controller, 2 x AGP , Accelerator
Graphics port 1.0 compliant
• Display memory: 2 ~ 8 MB
• Resolution: CRT display supports up to 1024 x 768 @ 24 bpp
Ethernet Interface (6752F/N)
• Ethernet interface: PCI 10/100 Mbps Ethernet. IEEE 802.3 u protocol
compatible
• Connection: On-board RJ-45 connector
• I/O address switchless setting
• Built-in boot ROM
Solid State Disk
• Supports DiskOnChip™ 2000/CompactFlash™ (OEM)
Mechanic and Environmental Specifications
• Standard Mode Power Consumption:
6.68 A @ 5 V w/ K6-3 / 450 MHz, 64 MB SDRAM
• Operating temperature:
0 ~ 60° C (32 ~ 140° F)
• Size: 185 mm x 122 mm (7.3 x 4.8")
• Weight: 0.27 kg (.594 lbs)
4 PCA-6752 Series User's Manual
1.3 Board Layout: Dimensions
Unit: mm
Figure 1-1: PCA-6752 board layout: Dimensions
Chapter 1 Hardware Configuration 5
6 PCA-6752 Series User's Manual
2
CHAPTER
Installation
This chapter tells how to connect
peripherals, switches and indicators to
the PCA-6752 Series boards. Y ou can
access most of the connectors from the
top of the board while it is installed in the
chassis. If you have a number of cards
installed, or your chassis is very tight,
you may need to partially remove the card
to make all the connections.
2.1 Safety Precautions
Follow these simple precautions to protect yourself from harm and your
PC from damage.
1. T o avoid electric shock, always disconnect the power from your PC
chassis before you work on it. Don't touch any components on the
CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card may
damage sensitive electronic components.
3. Always ground yourself to remove any static charge before you touch
your CPU card. Be particularly careful not to touch the chip connectors.
Modern integrated electronic devices, especially CPUs and memory chips,
are extremely sensitive to static electric discharges and fields. Keep the
card in its antistatic packaging when it is not installed in the PC, and place
it on a static dissipative mat when you are working with it. W ear a
grounding wrist strap for continuous protection.
8 PCA-6752 Series User's Manual
2.2 Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below lists the function of each of the jumpers.
Table 2-1: Jumper Assignments
Label Function
JP1 HDD LED connector
JP2 Power LED connector
JP3 LCD/Panel select
JP4 V
JP5 CPU internal clock select
JP6 Wake On Lan (WOL) select
JP7 Clock select
JP8 AT/ATX power select
JP9 RS-232/485 select (Part 2)
JP10 RS-232/422/485 select (Part 1)
JP11 DOC address select
JP12 Watch Dog function select
JP13 Multi/System functions Jumper
JP15 CMOS clear
JP16 COM2 for RS-232/485 setting (Part 3)
(CPU voltage) select
core
Chapter 2 Connecting Peripherals 9
2.3 Connectors
The following table lists the connectors on the PCA-6752 Series
Table 2-2: Connector Assignments
Label Function
CN 1 Parallel port connector
CN 2 Floppy drive connector
CN 3 IDE hard drive connector
CN 4 LCD Inverter Power connector
CN5 Inverter VR connector
CN 6 USB connector
CN 7 LCD 18-24 bit connector
CN8 VGA connector
CN9 FIR/SIR connector
CN10 Audio Out/AC97 connector
CN11 10/100Base-T Ethernet connector
CN12 ATX feature connector
CN13 COM2 232/422/485 connector
CN14 AT (Big 4P) power connector
CN15 COM1 232 connector
CN16 Keyboard and PS/2 mouse connector
CN18 ISA Bus Gold Finger connector
CN19 CompactFlash™ connector
FAN1 Fan connector
10 PCA-6752 Series User's Manual
2.4 Board Layout: Connector Locations (Component Side)
CN4
Figure 2-1: PCA-6752 locating Jumpers (component side)
Chapter 2 Connecting Peripherals 11
2.5 Board Layout: Connector Locations (Solder Side)
Figure 2-2: PCA-6752 locating Connectors (Solder side)
12 PCA-6752 Series User's Manual
2.6 Board Layout: Jumper Locations (Component Side)
Figure 2-3: PCA-6752 locating Jumpers (component side)
Chapter 2 Connecting Peripherals 13
2.7 Jumper Settings
This section tells how to set the jumpers to configure your card. It
gives the card default configuration and your options for each jumper.
After you set the jumpers and install the card, you will also need to run
the BIOS Setup program (discussed in Chapter 3) to configure the serial
port addresses, floppy/hard disk drive types and system operating
parameters. Connections, such as hard disk cables, appear in Chapter 2.
For the locations of each jumper, see the board layout diagram depicted
earlier in this chapter.
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal cap (often protected by a
plastic cover) that slides over the pins to connect them. To "close" a
jumper you connect the pins with the cap. T o "open" a jumper you
remove the cap. Sometimes a jumper will have three pins, labeled 1, 2 and
3. In this case you connect either pins 1 and 2 or 2 and 3.
2
1
3
OpenOpen
Open
OpenOpen
ClosedClosed
Closed
ClosedClosed
Closed 2-3Closed 2-3
Closed 2-3
Closed 2-3Closed 2-3
Y ou may find a pair of needle-nose pliers useful for setting the jumpers.
If you have any doubts about the best hardware configuration for your
application, contact your local distributor or sales representative before
you make any changes.
14 PCA-6752 Series User's Manual
JP1: HDD LED connector
Pin Result
1 LED +
2 LED -
JP2: Power LED connector
Pin Result
1 LED +
2 LED -
JP3: LCD/Panel Select
Pin Result
None 640 x 480 TFT*
1-2 800 x 600 TFT
3-4 1024 x 768 TFT
1
1
* Default Setting
640 x 480*
1
2
1
2
800 x 600
Chapter 2 Connecting Peripherals 15
1024 x 768
1
2
JP4: Vcore (CPU voltage) select
1.30 V
1.45 V
1.60 V
1.75 V
1.90 V
2.05 V
1 2
1 2
1 2
1 2
1 2
1 2
2.80 V
3.10 V
3.40 V
1.35 V
1.50 V
1.65 V
1 2
1 2
1 2
1 2
1 2
1 2
0.00 V
2.30 V
2.60 V
2.90 V
3.20 V
3.50 V
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1.70 V
1 2
1.85 V
1 2
2.0 V
1 2
2.10 V
1 2
2.40 V
1 2
2.70 V
1 2
2.20 V 1.80 V
1 2
2.50 V
1.95 V
1 2
1 2
16 PCA-6752 Series User's Manual
1.40 V
1.55 V
1 2
1 2
1 2
3.00 V
1 2
3.30 V
JP5: CPU Internal Clock Select
Pin Result
None 1.5X/3.5X
1-2 2.0X
1-2, 3-4 2.5X
3-4 3.0X
1-2, 5-6 4.0X
1-2, 3-4, 5-6 4.5X
3-4, 5-6 5.0X
5-6 5.5X
1 2
1.5/3.5x
1 2
4.0 x
JP6: Wake On LAN Select
1 2
2.0 x
1 2
4.5 x
Pin Result
1-3, 2-4 Normal (AT, ATX)*
3-5, 4-6 WOL Enable (ATX Only)
1 2
AT, ATX*
1 2
2.5 x
1 2
5.0 x
1 2
WOL (ATX only)
1 2
3.0 x
1 2
5.5 x
Chapter 2 Connecting Peripherals 17
JP7: Clock Select
Pin CPU PCI
None 60 MHz 30 MHZ
1-2 66.8 MHz 33.4 MHz
3-4 70 MHz 35 MHz
1-2, 3-4 75 MHz 25 MHz
5-6 80 MHz 26.67 MHz
1-2, 5-6 83.3 MHz 27.76 MHz
3-4, 5-6 95.25 MHz 31.75 MHz
1-2, 3-4, 5-6 100 MHz 33.33 MHz
7-8 75 MHz 37.5 MHz
1-2, 7-8 80 MHz 40 MHz
3-4, 7-8 83.3 MHz 41.66 MHz
1-2, 3-4, 7-8 105 MHz 35 MHz
5-6, 7-8 110 MHz 36.67 MHz
1-2, 5-6, 7-8 115 MHz 38.33 MHz
3-4, 5-6, 7-8 120 MHz 40 MHz
1-2, 3-4, 5-6, 7-8 124 MHz 41.33 MHz
1
60/30 MHz
75/25 MHz
95.25/31.75 MHz
18 PCA-6752 Series User's Manual
2
1
2
1
2
1
66.8/33.4 MHz
80/26.67 MHz
100/33.3 MHz
2
1
2
1
2
1
70/35 MHz
83.3/27.76 MHz
75/37.5 MHz
2
1
2
1
2
80/40 MHz
1
2
83.3/41.66 MHz
1
2
105/35 MHz
1
2
1
110/36.67 MHz
124/41.33 MHz
JP8: AT/ATX Power Select
2
115/38.33 MHz
1
2
Pin Result
1-3, 2-4 Use ATX power
3-5, 4-6 Use AT power*
1
ATX power
JP9, JP10, JP16: RS-232/422/485 Select for COM2
1 2
JP9
RS-232*
1 2
JP10
RS-232*
1 2
JP16
2
1 2
RS-422
1
2
AT power*
120/40 MHz
1
2
1 2
RS-485
1 2
RS-485
1 2
1
2
RS-232*
RS-485
Chapter 2 Connecting Peripherals 19
JP11: DOC Address Select
1-2, 3-4 DOC address at CC000h
1-2, 5-6 DOC address at D0000h*
1-2 DOC address at D4000h
3-4, 5-6 DOC address at D8000h
3-4 DOC address at DC000h
1
2
CC000h
1
2
D8000h
JP12: Watch Dog Function Select
D0000h*
DC000h
1
2
1
2
Pin Result
1- 2 Select Reset System*
2- 3 Select IRQ-11
1
Reset*
JP13: System Function Switch Connector
IRQ-11
Pin Result
1,2 System Reset Switch
3,4 System Power Switch (ATX)
5,6 Suspend Switch (reserve)
1
D4000h
1
2
1
2
RESET SW
20 PCA-6752 Series User's Manual
1
2
ATX PWR SW
1
2
Suspend resv
JP15: CMOS Clear
Pin Result
1-2 Normal*
3- 4 Clear CMOS
1
Normal*
1
Clear CMOS
2.8 Watchdog timer configuration (JP12)
An on-board watchdog timer reduces the chance of disruptions which
EMP (electro-magnetic pulse) interference can cause. This is an invaluable protective device for standalone or unmanned applications. Setup
involves two jumpers and running the control software. (Refer to
Appendix A.)
When the watchdog timer is enabled and the CPU shuts down, the
watchdog timer will automatically either reset the system or generate
an interrupt on IRQ 11, depending on the setting of jumper JP12, as
shown below:
Chapter 2 Connecting Peripherals 21
2.9 Parallel Port Connector (CN1)
The parallel port is normally used to connect the CPU card to a
printer. The PCA-6752 Series include an on-board parallel port,
accessed through a 26-pin flat-cable connector, CN1. The card
comes with an adapter cable which lets you use a traditional
DB-25 connector. The cable has a 26-pin connector on one end
and a DB-25 connector on the other, mounted on a retaining
bracket. The bracket installs at the end of an empty slot in your
chassis, giving you access to the connector.
The parallel port is designated as LPT1, and can be disabled or
changed to LPT2 or LPT3 in the system BIOS setup.
T o install the bracket, find an empty slot in your chassis.
Unscrew the plate that covers the end of the slot. Screw in the
bracket in place of the plate. Next, attach the flat-cable connector to CN1 on the CPU card. Wire 1 of the cable is red or blue,
and the other wires are gray. Make sure that wire 1 corresponds
to pin 1 of CN1. Pin 1 is on the right side of CN1.
2.10 Floppy Drive Connector (CN2)
You can attach up to two floppy disk drives to the PCA-6752
Series' on-board controller. You can use any combination of
5.25" (360 KB/1.2 MB) and/or 3.5" (720 KB/1.44/2.88 MB)
drives.
The card comes with a 34-pin daisy-chain drive connector
cable. On one end of the cable is a 34-pin flat-cable connector.
On the other end are two sets of floppy disk drive connectors.
Each set consists of a 34-pin flat-cable connector (usually used
for 3.5" drives) and a printed-circuit-board connector (usually
used for 5.25" drives). You can use only one connector in each
set. The set on the end (after the twist in the cable) connects to
the A: floppy. The set in the middle connects to the B: floppy.
22 PCA-6752 Series User's Manual
2.11 Enhanced IDE Connector (CN3)
Y ou can attach two IDE (Integrated Device Electronics) drives to the
PCA-6752 Series internal controller. The PCA-6752 Series CPU card has
an EIDE connector, CN3.
Wire number 1 on the cable is red or blue, and the other wires are gray.
Connect one end to connector CN3 on the CPU card. Make sure that
the red (or blue) wire corresponds to pin 1 on the connector (on the
right side). See Chapter 1 for help in finding the connector.
Unlike floppy drives, IDE hard drives can connect in either position on
the cable. If you install two drives, you will need to set one as the
master and one as the slave. You do this by setting the jumpers on the
drives. If you use just one drive, you should set it as the master. See
the documentation that came with your drive for more information.
Connect the first hard drive to the other end of the cable. Wire 1 on the
cable should also connect to pin 1 on the hard drive connector, which
is labeled on the drive circuit board. Check the documentation that
came with the drive for more information.
Connect the second drive, as described above, on CN3.
2.12 LCD Inverter Connector (CN4)
The LCD inverter is connectoed to CN4 via a 5-pin connector to
provide +12 V power to the LCD display . Pin 4 of CN4 provides LCD
brightness control and can be ajusted via the VR1 (located on the
uppper right corner of CN4)
Chapter 2 Connecting Peripherals 23
2.13 Inverter VR Connector (CN5)
The inverter VR connector allows integrators to apply an
external resistive circuit to this connector to obtain a varible
Voltage supply .
2.14 USB Connector (CN6)
The PCA-6752 Series board provides two USB (Universal Serial
Bus) interfaces, which give complete plug and play and also hot
attach/detach for up to 127 external devices. The USB interfaces
comply with USB specification rev. 1.0 and are fuse protected.
The USB interfaces are accessed through a 10-pin flat-cable
connector, CN6. The adapter cable has a 10-pin connector on
one end and a USB connector on the bracket.
The USB interfaces can be disabled in the system BIOS setup.
2.15 18/24-bit LCD Display Connector (CN7)
CN7 is a 40-pin dual-in-line header and is used to connect an
LCD display to the PCA-6752 Series. The PCA-6752 Series has
bias control which can be used to control the LCD signal
voltage. Pin 7 of CN7 is for LCD contrast adjustments, the LCD
contrast can be adjusted via the VR (located on the upper right
corner of CN5).
The LCD interface is done completely with the softare utiliity
provided, please refer to Chapter 4 for details.
24 PCA-6752 Series User's Manual
2.16 VGA Display Connector (CN8)
The PCA-6752 Series provide a VGA controller for a high
resolution VGA interface. The PCA-6752 Series CN8 is a DB-15
connector for VGA monitor input. Pin assignments for the CRT
display are detailed in Appendix C.
2.17 IR Connector (CN9)
This connector supports the optional wireless infrared transmitting and receiving module. This module mounts on the system
case. You must configure the setting through BIOS setup.
2.18 Audio Out/AC' 97 Connector (CN10)
AC' 97 is a audio codec specification which creates a strong
foundation for modular digital acceleration of audio and
communication functions on the SBC. AC '97 permits a more
rapid transition to PCI audio by enabling designs which
support both PCI and ISA. AC' 97 uses two separate chips, one
primarily analog, the other digital.
This "chip-level" partioning provides benefits at many levels.
The first benefit is that it helps eliminate interference between
analog and digital signals, which reduces on-chip noise, which
increases the quality of the audio output through speakers or
other devices users prefer. Another important benefit is a
realized cost savings by only having to design and tune the
analog portion of an entire line of products once. The analog
component is also less expensive to manufacturer, which is one
of the common benefits with single chip designs.
Chapter 2 Connecting Peripherals 25
2.19 Ethernet Configuration (CN11)
The PCA-6752 Series is equipped with a high performance 32bit PCI-bus Fast Ethernet interface which is fully compliant with
IEEE 802.3u 100/10Base-T specifications. It is supported by all
major network operating systems.
The medium type can be configured via the Rset8139.EXE
program included on the utility disk. (See Chapter 5 for detailed
information.)
Network boot
The network boot feature is built into the BIOS. It can be
enabled or disabled in the chipset setup of the CMOS configu-
2.20 ATX Feature Connector (CN12)
If the PCA-6752 Series are used as a stand alone card both the
4-pin main power connector (CN14) and the A TX power
connector (CN12) must be connected to the power supply . If
the PCA-6752 Series is used with a passive backplane, the main
power connector (CN14) should not be connected as the card
will be powered from the backplane.
Use the ATX adapter cable (provided) to connect the PCA-6752
Series with the ATX power supply. The ATX adapter cable has
two different connectors at either end. The ATX 20-pin (female
To ATX feature
(P8) 6-pin in
backplane
(P9) 6-pin in backplane
Figure 2-4: A TX Adaptor cable
26 PCA-6752 Series User's Manual
•
P9 P8 P9
P8
•
•
•
20-pin female connector
ATX power supply
•
2.21 Serial Ports COM1/RS- 232 (CN15) COM2/RS-232/422/485 (CN13)
The PCA-6752 Series offer two serial ports: COM1 in RS-232
and COM2 (CN13: RS-232/422/485). These ports let you
connect to serial devices (a mouse, printers, etc.) or a communication network.
Y ou can select the address for each port (for example, 3F8H
[COM1], 2F8H [COM2]) or disable each port. Use the BIOS
Advanced Setup program, which is covered in Chapter 4.
The card mounting bracket holds the serial port connector for
the one port. The parallel port and serial port adapter kit
(supplied with the card) holds the connector for the other port.
This lets you connect and disconnect cables after you install
the card. The DB-9 connector on the bottom of the bracket is
the first RS-232 port, COM1. The DB-9 connector on the
adapter kit is the second serial port, COM2.
Table 2-3: Serial port connections (COM1, COM2)
Connector Function
COM1 RS-232
COM2 RS-232/422/485
2.21.1 RS-232 connection (COM1-CN15)
Different devices implement the RS-232 standard in different
ways. If you are having problems with a serial device, be sure to
check the pin assignments for the connector.
Chapter 2 Connecting Peripherals 27
2.22 AT Power Connector (CN14)
If you prefer not to acquire power through PCA-6752 Series
backplane via the gold H-connectors, CN14 also provides
power input connectors for +5 V and +12 V. Pin 8 of the PS/2
power supply can be used, too.
2.23 Keyboard & PS/2 Mouse Connector (CN16)
The PCA-6752 Series board provides a keyboard connector. A
6-pin mini-DIN connector (CN16) on the card mounting bracket
supports single-board computer applications. The card comes
with an adapter to convert from the 6-pin mini-DIN connector to
a standard DIN connector and to a PS/2 mouse connector.
2.24 ISA Goldfinger (CN18)
The 16-bit ISA goldfingers are used for connecting the
PCA-6752 Series to an ISA passive backplane.
2.25 CompactFlash Disk(CN19)(optional)
The PCA-6752 Series are equipped with a CompactFlash disk
socket on the solder side that supports the IDE interface for
CompactFlash cards. The on-board CompactFlash socket is
designed to prevent incorrect installation. Be sure that the
system power is off when installing and removing CompactFlash cards.
The CompactFlash card is defaulted as the E drive on your PC
system.
28 PCA-6752 Series User's Manual
3
CHAPTER
Award BIOS Setup
This chapter describes how to set the
card’s BIOS configuration data.
3.1 AWARD BIOS Setup
There are three situations in which you will need to change the CMOS
settings:
1 . You are starting your system for the first time
2. You have changed the hardware attached to your system
3 . The CMOS memory has lost power and the configuration informa-
tion has been erased.
The PCA-6752 Series memory has an integral lithium battery backup.
The battery backup should last ten years in normal service, but when it
finally runs down, you will need to replace the complete unit.
Figure 3-1: Setup program initial screen
A ward’s BIOS ROM has a built-in Setup program that allows users to
modify the basic system configuration. This type of information is
stored in battery-backed RAM so that it retains the Setup information
when the power is turned off.
3.1.1 Entering setup
Turning on the computer and pressing <DEL> immediately will allow
you to enter Setup.
30 PCA-6752 Series User's Manual
3.1.2 Standard CMOS setup
Choose the “ST ANDARD CMOS SETUP” option from the INITIAL
SETUP SCREEN Menu, and the screen below is displayed. This
standard Setup Menu allows users to configure system components
such as date, time, hard disk drive, floppy drive, display, and memory.
Figure 3-2: CMOS setup screen
Chapter 3 Award BIOS Setup 31
3.1.3 BIOS features setup
The “BIOS FEA TURES SETUP” screen appears when choosing the
BIOS FEA TURES SETUP item from the CMOS SETUP UTILITY Menu.
It allows the user to configure the PCA-6752 according to his
particular requirements.
Below are some major items that are provided in the BIOS FEATURES SETUP screen:
Figure 3-3: BIOS features setup screen
Virus Warning
During and after the system boots up, any attempt to write to the boot
sector or partition table of the hard disk drive will halt the system. In
this case, a warning message will be displayed. You can run the antivirus program to locate the problem.
If Virus Warning is Disabled, no warning message will appear if
anything attempts to access the boot sector or hard disk partition.
CPU Internal Cache/External Cache
Depending on the CPU/chipset design, these options can speed up
memory access when enabled.
32 PCA-6752 Series User's Manual
Quick Power On Self Test
This option speeds up the Power-On Self Test (POST) conducted as
soon as the computer is turned on. When enabled, BIOS shortens or
skips some of the items during the test. When disabled, normal POST
procedures assumes.
Boot Sequence
This function determines the sequence in which the computer will
search the drives for the disk operating system (i.e. DOS). The default
value is “C, A”.
A,C System will first search the FDD, then the HDD.
C,A System will first search the HDD, then the FDD.
C only System will only search the HDD.
• •
• •
• •
Boot Up Floppy Seek
During POST, BIOS will determine if the floppy disk drive installed is
40 or 80 tracks. 360 KB type is 40 tracks while 720 KB, 1.2 MB, and
1.44 MB are all 80 tracks.
Enabled BIOS searches the floppy drive to determine if it is 40 or 80
tracks. Note that BIOS cannot differentiate 720 KB, 1.2 MB,
and 1.44 MB type drives as they are all 80 tracks.
Disabled BIOS will not search for the floppy drive type by track
number. Note that there will not be any warning message if
the drive installed is 360 KB.
Boot Up NumLock Status
The default is “On”.
On Keypad boots up to number keys.
Off Keypad boots up to arrow keys.
Chapter 3 Award BIOS Setup 33
Gate A20 option
Normal The A20 signal is controlled by the keyboard controller or
chipset hardware
Fast Default: Fast. The A20 signal is controlled by Port 92 or
chipset specific method.
Typematic Rate Setting
The typematic rate determines the characters per second accepted by
the computer. Typematic Rate setting enables or disables the typematic rate.
Typematic Rate (Char/Sec)
BIOS accepts the following input values (character/second) for
Typematic Rate: 6, 8, 10, 12, 15, 20, 24, 30.
Typematic Delay (msec)
When holding down a key , the T ypematic Delay is the time interval
between the appearance of the first and second characters. The input
values (msec) for this category are: 250, 500, 750, 1000.
34 PCA-6752 Series User's Manual
Security Option
This setting determines whether the system will boot if the password
is denied, while limiting access to Setup.
System The system will not boot, and access to Setup will be
denied if the correct password is not entered at the prompt.
Setup The system will boot, but access to Setup will be
denied if the correct password is not entered at the prompt.
Note: T o disable security , select P ASSWORD SETTING in the main
menu. At this point, you will be asked to enter a password. Simply hit
the <ENTER> key to disable security. When security is disabled, the
system will boot, and you can enter Setup freely.
OS Select for DRAM>64 MB
This setting is under OS/2 system.
Video BIOS Shadow
This determines whether video BIOS will be copied to RAM, which is
optional according to the chipset design. When enabled, Video
Shadow increases the video speed.
C8000 - CFFFF Shadow/DC000-DFFFF Shadow
These determine whether optional ROM will be copied to RAM in
blocks of 16 KB.
Enabled Optional shadow is enabled
Disabled Optional shadow is disabled
Chapter 3 Award BIOS Setup 35
3.1.4 CHIPSET features setup
By choosing the “CHIPSET FEA TURES SETUP” option from the
INITIAL SETUP SCREEN Menu, the screen below is displayed. This
sample screen contains the manufacturer’s default values for the
PCA-6752.
Figure 3-4: CHIPSET features setup screen
36 PCA-6752 Series User's Manual
3.1.5 Power management setup
The power management setup controls the CPU cards’ “green”
features. The following screen shows the manufacturer’s default.
Figure 3-5: Power management setup screen
Power Management
This option allows you to determine if the values in power management are disabled, user-defined, or predefined.
HDD Power Management
You can choose to turn the HDD off after a one of the time interval
listed, or when the system is in Suspend mode. If in a power saving
mode, any access to the HDD will wake it up.
Note: HDD will not power down if the Power Management
option is disabled.
IRQ Activity
IRQ can be set independently. Activity on any enabled IRQ will wake
up the system.
Chapter 3 Award BIOS Setup 37
3.1.6 PnP PCI configuration setup
Figure 3-6: PCI configuration screen
3.1.7 Load BIOS defaults
“LOAD BIOS DEF AUL TS” indicates the most appropriate values for
the system parameters for minimum performance. These default values
are loaded automatically if the stored record created by the Setup
program becomes corrupted (and therefore unusable).
3.1.8 Load setup defaults
“LOAD SETUP DEF AUL TS” loads the values required by the system
for maximum performance.
38 PCA-6752 Series User's Manual
3.1.9 Integrated Peripherals
Figure 3-7: Integrated peripherals
Note: If you enable the IDE HDD block mode, the en-
hanced IDE driver will be enabled.
3.1.10 Password setting
T o change, confirm, or disable the password, choose the “PASSWORD SETTING” option form the Setup main menu and press
[Enter]. The password can be at most 8 characters long.
Remember, to enable this feature. You must first select the Security
Option in the BIOS FEATURES SETUP to be either “Setup” or
“System.” Pressing [Enter] again without typing any characters can
disable the password setting function.
Chapter 3 Award BIOS Setup 39
3.1.11 IDE HDD auto detection
“IDE HDD AUTO DETECTION” automatically self-detect for the
correct hard disk type.
3.1.12 Save & exit setup
If you select this and press the [Enter] key, the values entered in the
setup utilities will be recorded in the CMOS memory of the chipset.
The microprocessor will check this every time you turn your system on
and compare this to what it finds as it checks the system. This record
is required for the system to operate.
Figure 3-8: Load and Save
3.1.13 Exit without saving
Selecting this option and pressing the [Enter] key lets you exit the
Setup program without recording any new values or changing old
ones.
40 PCA-6752 Series User's Manual
CHAPTER
4
AGP SVGA Setup
(for PCA-6752F only)
• Introduction
• Installation of SVGA driver for
- Windows 9x
- Windows NT
4.1 Introduction
The PCA-6752F has an on-board AGP flat panel/VGA interface. The
specifications and features are described as follows:
4.1.1 Chipset
The PCA-6752F uses a Trident Cyber i7 chipset for its AGP/SVGA
controller. It is AGP 1.0 compliant with 2x AGP speed. It supports
many popular LCD and gas plasma flat panel displays and
conventional analog CRT monitors. The Cyber i7 VGA BIOS
supports monochrome LCD, color TFT and DSTN LCD flat panel
displays. In addition, it also supports interlaced and non-interlaced
analog monitors (color and monochrome VGA) in high-resolution
modes while maintaining complete IBM VGA compatibility. Digital
monitors (i.e. MGA, CGA, and EGA) are NOT supported. Multiple
frequency (multisync) monitors are handled as if they were analog
monitors.
4.1.2 Display memory
With UMA 2 - 8 MB shared with system memory on chip, the VGA
controller can drive CRT displays with resolutions up to 1024 x 768
@ 18 bpp or color panel displays with resolutions up to 1024 x 768 at
24 bpp. (With an option of 8 MB display memory on chip). This
yields true-color resolution of 1280 x 1024.
4.1.3 Display types
CRT and panel displays can be used simultaneously. The PCA-6752F
can be set in one of three configurations: on a CRT, on a flat panel
display, or on both simultaneously. The system is initially set to
simultaneous display mode. The BIOS setup can be used to configure
the display. In BIOS, select “Integrated Peripherals”, then “Boot-up
display type.” You can then choose one of the following modes:
“CRT only”, “Panel only”, or “Simultaneous.”
42 PCA-6752 Series User's Manual
4.1.4 Dual/Simultaneous display
The PCA-6752F uses a Trident Cyber i7 VGA/LCD controller that is
capable of providing multiple views and simultaneous display with
mixed video and graphics on a flat panel and CRT. The setup for
choosing the display you want to use will be shown later in this
chapter. In the next section of this chapter, instructions and
illustrations are given to help with the PCI SVGA setup for the PCA6752F for Windows 95/98 and Win NT..
Important: The following windows illustrations are e xamples
only. You must follow the provided instructions and
also pay attention to the instructions which then
appear on your screen.
Note: <Enter> means pressing the “Enter” k ey on the
keyboard.
Figure 4-1: Selecting display settings
Chapter 4 PCA-6752F AGP Setup 43
4.2 Installation
4.2.1 Installation for Windows 95/98
1.a. Select “Start”, “Settings”, “Control Panel”
b. Double click “Display”
2.a. Click “Settings”
b. Click “Advanced”
44 PCA-6752 Series User's Manual
3.a. Choose the “Adaptor” tab
b. Click “Change”
4.a. Click “Have Disk” to install the Driver.
Chapter 4 PCA-6752F AGP Setup 45
5.a. Insert the utility CD ROM.
b. Fill in the correct path.
c. Click “OK”
6.a. Select the “Trident Blade 3D/MVP4 AGP {v6.50.5482-3}”
b. Click “OK”
46 PCA-6752 Series User's Manual
7.a. Trident Blade 3D/MVP4 AGP appears in the adaptor label.
b. Click “Apply”
8. Click “Yes” to reboot.
Chapter 4 PCA-6752F AGP Setup 47
9.a. Repeat Step 1
b. Adjust resolution and color
c. Click “Advanced”
10. Click “Display Device” to set CRT and Flat Panel.
48 PCA-6752 Series User's Manual
11.a. Choose the Display device you have.
b. Click “OK”
12.a. Click “Monitor”
b. Click “Change” to set your monitor.
Chapter 4 PCA-6752F AGP Setup 49
13.a. Select “Standard”, “Super VGA 800 x 600”, or “XGA”
b. Click “OK”
50 PCA-6752 Series User's Manual
4.2.2 Installation for Windows NT
1.a. Select “Start”, “Settings”, “Control Panel”
b. Double click “Display”
2.a. Choose the “Settings” label
b. Click the “Display Type”
Chapter 4 PCA-6752F AGP Setup 51
3. Click “Change....”
4. Click “Have Disk”
52 PCA-6752 Series User's Manual
5.a. Insert the Utility CD-ROM
b. Fill in the correct path
c. Click “OK”
6.a. Select the highlighted item
b. Click “OK”
7. Click “Yes” to proceed.
Chapter 4 PCA-6752F AGP Setup 53
8. Click “OK” to reboot.
9.a. Repeat step 1
b. Adjust resolution and color
c. Click “Test” to see the result
d. Click “OK” to save the settings
54 PCA-6752 Series User's Manual
4.3 Further information
For further information about the AGP/SVGA installation in your
PCA-6752F, including driver updates, troubleshooting guides and
FAQ lists, visit the following web resources:
Trident website: www.trid.com
Advantech websites: www.advantech.com
www.advantech.com.tw
Chapter 4 PCA-6752F AGP Setup 55
56 PCA-6752 Series User's Manual
CHAPTER
5
AGP VGA Setup
(for PCA-6752N only)
• Introduction
• Installation of SVGA driver for
- Windows 9x
- Windows NT
5.1 Introduction
The PCA-6752N has an on-board AGP VGA interface. The
specifications and features are described as follows:
5.1.1 Chipset
The PCA-6752N uses a built-in VIA MVP4 for its AGP VGA
controller. It is AGP 1.0 compliant with 2x AGP speed provide
support for analog CRT monitors. The VIA MVP4 VGA BIOS
supports interlaced and non-interlaced analog monitors (color and
monochrome VGA) in high-resolution modes while maintaining
complete IBM VGA compatibility. Digital monitors (i.e. MDA, CGA,
and EGA) are NOT supported. Multiple frequency (multisync)
monitors are handled as if they were analog monitors.
5.1.2 Display memory
With 2 - 8 MB shared with system memory, the VGA controller can
drive CRT displays with resolutions up to 1024 x 768 @ 24 bpp.
(With an option of 8 MB display memory on chip). This yields truecolor resolution of 1280 x 1024.
58 PCA-6752 Series User's Manual
5.2 Installation
5.2.1 Installation for Windows 95/98
1.a. Select “Start”, “Settings”, “Control Panel”
b. Double click “Display”
2.a. Click “Settings”
b. Click “Advanced”
Chapter 4 PCA-6752N AGP VGA Setup
59
3.a. Choose the “Adapter” tab
b. Click “Change”
4. Click “Have Disk” to install the Driver.
60 PCA-6752 Series User's Manual
5.a. Insert the utility CD ROM.
b. Fill in the correct path.
c. Click “OK”
6.a. Select the “Trident Blade 3D/MVP4 AGP {v6.50.54952ICD}” .
b. Click “OK”
Chapter 4 PCA-6752N AGP VGA Setup
61
7.a. Trident Blade 3D/MVP4 AGP appears in the adapter label.
b. Click “Apply”
8. Click “Yes” to reboot.
62 PCA-6752 Series User's Manual
5.2.2 Installation 0f VIA 4 In 1 Service Pack
1.a. Select “Start”, “Run”
b. Insert Utility CD ROM
c. Fill in correct path
d. Click “OK”
2. Click “Next” to continue the Setup
Chapter 4 PCA-6752N AGP VGA Setup
63
3. Click “Yes” to continue the process.
4.a. Choose the drivers you need
b. Click “Next” to continue
64 PCA-6752 Series User's Manual
5.a. Choose “Install”
b. Click “Next”
6.a. Choose “Yes” to restart
b. Click “Finish” to reboot
Chapter 4 PCA-6752N AGP VGA Setup
65
5.2.3 Installation for Windows NT
1.a. Select “Start”, “Settings”, “Control Panel”
b. Double click “Display”
2.a. Choose the “Settings” label
b. Click the “Display Type”
66 PCA-6752 Series User's Manual
3. Click “Change....”
4. Click “Have Disk”
Chapter 4 PCA-6752N AGP VGA Setup
67
5.a. Insert the Utility CD-ROM
b. Fill in the correct path
c. Click “OK”
6.a. Select the highlighted item
b. Click “OK”
7. Click “Yes” to proceed.
68 PCA-6752 Series User's Manual
8. Click “OK” to reboot.
9.a. Repeat step 1
b. Adjust resolution and color
c. Click “Test” to see the result
d. Click “OK” to save the settings
Chapter 4 PCA-6752N AGP VGA Setup
69
5.3 Further information
For further information about the AGP/VGA installation in your
PCA-6752N, including driver updates, troubleshooting guides and
FAQ lists, visit the following web resources:
Via website: www.via.com.tw
Advantech websites: www.advantech.com
www.advantech.com.tw
70 PCA-6752 Series User's Manual
CHAPTER
6
PCI Bus Ethernet
Interface (for PCA6752F/N only)
This chapter provides information on Ethernet
configuration.
• Introduction
• Installation of Ethernet driver for Windows
95/98/NT
• Further information
6.1 Introduction
The PCA-6752F/N is equipped with a high performance 32-bit
Ethernet chipset which is fully compliant with IEEE 802.3 100 Mbps
CSMA/CD standards. It is supported by major network operating
systems. It is also both 100Base-T and 10Base-T compatible. The
medium type can be configured via the RSET8139.exe program
included on the utility disk.
The Ethernet port provides a standard RJ-45 jack on board. The
network boot feature can be utilized by incorporating the boot ROM
image files for the appropriate network operating system. The boot
ROM BIOS files are combined with system BIOS, which can be
enabled/disabled in the BIOS setup.
6.2 Installation of Ethernet driver
Before installing the Ethernet driver, note the procedures below. You
must know which operating system you are using in your PCA-6752,
and then refer to the corresponding installation flow chart. Then just
follow the steps described in the flow chart. You will quickly and
successfully complete the installation, even if you are not familiar
with instructions for MS-DOS or Windows.
Note: The windows illustrations in this chapter are
examples only. You must follow the flow chart
instructions and pay attention to the instructions
which then appear on your screen.
6.2.1 Installation for MS-DOS and Windows 3.1
If you want to set up your Ethernet connection under the MS-DOS or
Windows 3.1 environment, you should first check your server system
model. For example, MS-NT, IBM-LAN server, and so on.
Then choose the correct driver to install in your panel PC.
The installation procedures for various servers can be found on
CD-ROM, the correct path being:
D:\slotpc\6752\Lan.100\8139B\wfw311
72 PCA-6752 Series User's Manual
6.2.2 Installation for Windows 95/98
1.a. Select “Start”, “Settings”, “Control Panel”
b. Double click “Network”
2. Click "Add" and prepare to install network functions
Chapter 5 PCI Bus Ethernet Interface 73
3. Select the "Adapter" item to add the Ethernet card.
4. Click "Have Disk" to install the driver.
5.a. Insert the Utility CD ROM
b. Fill in the correct path
c. Click "OK"
74 PCA-6752 Series User's Manual
6.a. Choose the "Realtek RTL8139(A/B/C/8130) PCI Fast
Ethernet".
b. Click "OK"
7.a. Make sure the configurations of the relative items are set
correctly.
b. Click "OK" to reboot.
Chapter 5 PCI Bus Ethernet Interface 75
6.2.3 Installation for Windows NT
1.a. Select “Start”, “Settings”, “Control Panel”
b. Double click “Network”
2.a. Choose the type of network
b. Click "next"
76 PCA-6752 Series User's Manual
3. Click "Select from list..."
4. Click "Have Disk"
5.a. Insert the Utility CD ROM
b. Fill in the correct path
c. Click "OK"
Chapter 5 PCI Bus Ethernet Interface 77
6.a. Choose the highlighted item
b. Click "OK"
7. Click "Next" to continue setup
78 PCA-6752 Series User's Manual
8.a. Choose the networking protocols
b. Click "Next"
9.a. Choose the Network Services
b. Click "Next"
Chapter 5 PCI Bus Ethernet Interface 79
10. Click "Next" to continue setup
11. Click "Next" to start the network
6.3 Further information
Realtek website: www.realtek.com.tw
Advantech website: www.advantech.com
www.advantech.com.tw
80 PCA-6752 Series User's Manual
APPENDIX
A
Programming
the Watchdog
Timer
The PCA-6752F is equipped with a
watchdog timer that resets the
CPU or generates an interrupt if
processing comes to a standstill
for any reason. This feature
ensures system reliability in
industrial standalone or unmanned
environments.
A.1 Programming the Watchdog Timer
T o program the watchdog timer , you must write a program which
writes I/O port address 443 (hex). The output data is a value of time
interval. The value range is from 01 (hex) to 3E (hex), and the related
time interval is 1 sec. to 62 sec.
Data Time Interval
01 1 sec.
02 2 sec.
03 3 sec.
04 4 sec.
••
••
••
3E 62 sec.
82 PCA-6752 Series User's Manual
After data entry, your program must refresh the watchdog timer by
rewriting the I/O port 443 (hex) while simultaneously setting it. When
you want to disable the watchdog timer, your program should read I/O
port 443 (hex).
The following example shows how you might program the watchdog
timer in BASIC:
10 REM Watchdog timer example program
20 OUT &H443, data REM Start and restart the watchdog
30 GOSUB 1000 REM Your application task #1,
40 OUT &H443, data REM Reset the timer
50 GOSUB 2000 REM Your application task #2,
60 OUT &H443, data REM Reset the timer
70 X=INP (&H443) REM, Disable the watchdog timer
80 END
1000 REM Subroutine #1, your application task
••
••
••
1070 RETURN
2000 REM Subroutine #2, your application task
••
••
••
2090 RETURN
Appendix A Programming the Watchdog Timer
83
84 PCA-6752 Series User's Manual
B
APPENDIX
System
Assignments
This appendix contains information of a
detailed or specialized nature. It includes:
• System I/O ports
• DMA channel assignments
• Interrupt assignments
• 1st MB memory map
B.1 System I/O Ports
Table B-1: System I/O ports
Addr. range (Hex) Device
000-01F DMA controller
020-021 Interrupt controller 1, master
022-023 Chipset address
040-43 8254 timer
060-64 8042 (keyboard controller)
070-07F Real-time clock, non-maskable interrupt (NMI)
mask
080-08F DMA page register
0A0-A1 Interrupt controller 2
0C0-0DF DMA controller
0F8-0FF Math co-processor
1F0-1F7 Fixed disk
200-207 Game I/O
278-27F Parallel printer port 2 (LPT 3)
2F8-2FF Serial port 2
300-31F Prototype card
360-36F Reserved
378-37F Parallel printer port 1 (LPT 2)
380-38F SDLC, bisynchronous 2
3A0-3AF Bisynchronous 1
3B0-3BF Monochrome display
3C0-3CF Reserved
3D0-3DF Color/graphics monitor adapter
3F0-3F7 Diskette controller
3F8-3FF Serial port 1
B.2 DMA Channel Assignments
86 PCA-6752 Series User's Manual
Table B-2: DMA channel assignments
Channel Function
0 Available
1 Available
2 Floppy disk (8-bit transfer)
3 Available
4 Cascade for DMA controller 1
5 Available
6 Available
7 Available
* Audio DMA select 0, 1 or 3
B.3 Interrupt Assignments
Table B-3: Interrupt assignments
Interrupt# Interrupt source
IRQ 0 Interval timer
IRQ 1 Keyboard
IRQ 2 Interrupt from controller 2 (cascade)
IRQ 8 Real-time clock
IRQ 9 Cascaded to INT 0A (IRQ 2)
IRQ 10 Available
IRQ 11 Watchdog Timer
IRQ 12 PS/2 mouse (non-releasable)
IRQ 13 INT from co-processor
IRQ 14 Fixed disk controller (primary)
IRQ 15 Fixed disk controller (secondary)
IRQ 3 Serial communication port 2
IRQ 4 Serial communication port 1
IRQ 5 Parallel port 2
IRQ 6 Diskette controller (FDC)
IRQ 7 Parallel port 1 (print port)
* PNP audio IRQ select: 5, 7, 9 or 10
* Ethernet function is auto-sensing
Appendix D System Assignments 87
B.4 1st MB Memory Map
Table B-4:1st MB memory map
Addr. range (Hex) Device
F000h - FFFFh System ROM
CB00h - EFFFh available
C000h - CAFF Expansion ROM
B800h - BFFFh CGA/EGA/VGA text
B000h - B7FFh Unused
A000h - AFFFh EGA/VGA graphics
0000h - 9FFFh Base memory
88 PCA-6752 Series User's Manual
C
APPENDIX
Pin Assignments
This appendix contains information of a
detailed or specialized nature. It includes:
• CRT display connector
• LCD display/inverter connector
• RS-232/422/485 serial port connector
• Keyboard and mouse connector
• External keyboard connector
• Main power connectors (AT/ATX)
• IDE connector
• RS-232 serial port connector
• Ethernet RJ-45 connector
• Floppy connector
• Parallel connector
• IR connector
• HDD LED connector
• CompactFlash card connector
• Fan Connector
C.1 Parallel Port Connector (CN1)
25 23 3 1
26 24 4 2
Table C-1: Parallel port connector
Pin Signal
1 STROBE*
2 AUTOFD*
3D0
4 ERR
5D1
6 INIT*
7D2
8 SLCTINI*
9D3
10 GND
11 D4
12 GND
13 D5
14 GND
15 D6
16 GND
17 D7
18 GND
19 ACK*
20 GND
21 BUSY
22 GND
23 PE
24 GND
25 SLCT
26 N/C
* low active
90 PCA-6752 Series User's Manual
C.2 Floppy Drive Connector (CN2)
33 31 .... 3 1
34 32 .... 4 2
Table C-2: Floppy drive connector
Pin Signal Pin Signal
1 GND 2 DENSITY SELECT*
3 GND 4 N/C
5 GND 6 N/C
7 G N D 8 INDEX*
9 GND 10 MOTOR 0*
11 GN D 12 DRIVE SELECT 1*
13 GN D 14 DRIVE SELECT 0*
15 GND 16 MOTOR 1*
17 GND 18 DIRECTION*
19 GND 20 STEP*
21 GND 22 WRITE DA T A*
23 GND 24 WRITE GATE*
25 GND 26 TRACK 0*
27 GND 28 WRITE PROTECT*
29 GND 30 READ DAT A*
31 GN D 32 HEAD SELECT*
33 GND 34 DISK CHANGE*
* low active
Appendix C Pin Assignments 91
C.3 Enhanced IDE connector (CN3)
37
39
38
40
Table C-3: Enhanced IDE connector (CN3)
Pin Signal Pin Signal
1 IDE RESET* 2 GN D
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9 DATA 4 10 DATA 11
11 DAT A 3 12 DAT A 12
13 DAT A 2 14 DAT A 13
15 DAT A 1 16 DAT A 14
17 DAT A 0 18 DAT A 15
19 SIGNAL GND 20 N/C
21 N/C 22 GND
23 IO WRITE 24 GND
25 IO READ 26 GND
27 IO CHANNEL READY 28 N/C
29 HDACKO* 30 GND
31 IRQ14 32 IOCS16
33 ADDR 1 34 N /C
35 ADDR 0 36 ADDR 2
37 HARD DISK SELECT 0* 38 HARD DISK SELECT 1*
39 IDE ACTIVE* 40 GND
13
2
4
* low active
92 PCA-6752 Series User's Manual
