Advance Tabco ECC-1442 Specifications
CHROME or GREEN EPOXY COATED
Width
Length
WIRE SHELVING COMBO
Item #: Qty #:
Model #:
Project #:
Includes 4 Shelves
and 4 - 74” Posts
3 Truss Design
(Shelves with 24”, 30” & 36” Lengths have two trusses)
CHROME
MODEL # MODEL #
ECC-1436
ECC-1442
ECC-1448
ECC-1460
ECC-1472
ECC-1836
ECC-1842
ECC-1848
ECC-1854
ECC-1860
ECC-1872
ECC-2436
ECC-2442
ECC-2448
ECC-2454
ECC-2460
ECC-2472
GREEN EPOXY
COATED
EGG-1436
EGG-1442
EGG-1448
EGG-1460
EGG-1472
EGG-1836
EGG-1842
EGG-1848
EGG-1854
EGG-1860
EGG-1872
EGG-2436
EGG-2442
EGG-2448
EGG-2454
EGG-2460
EGG-2472
Shelf
Size
14” x 36”
14” x 42”
14” x 48”
14” x 60”
14” x 72”
18” x 36”
18” x 42”
18” x 48”
18” x 54”
18” x 60”
18” x 72”
24” x 36”
24” x 42”
24” x 48”
24” X 54”
24” x 60”
24” x 72”
FEATURES:
3 truss design (Shelves with 36” Lengths have two trusses)
Each shelf holds up to 800 lbs. evenly distributed weight.
NSF approved.
Posts are numbered for easy assembly and are included.
CONSTRUCTION:
Unit assembles using tapered split sleeves.
MATERIAL:
Chrome plated or green epoxy coating.
DIMENSIONS
and SPECIFICATIONS
TOL ± .500” ALL DIMENSIONS ARE TYPICAL
Weight
64 lbs.
69 lbs.
75 lbs.
93 lbs.
107 lbs.
68 lbs.
73 lbs.
81 lbs.
88 lbs.
99 lbs.
115 lbs.
75 lbs.
81 lbs.
89 lbs.
97 lbs.
111 lbs.
127 lbs.
Customer Service Available To Assist You 1-800-645-3166 8:30 am - 8:00 pm E.S.T.
Customer Service Available To Assist You 1-800-645-3166 8:30 am - 8:00 pm E.S.T.
Email Orders To: customer@advancetabco.com. For Smart Fabrication™ Quotes, Email To: smartfab@advancetabco.com or Fax To: 631-586-2933
www.advancetabco.com
ADVANCE TABCO is constantly engaged in a program of improving our products. Therefore, we reserve the right to change specifications without prior notice. © ADVANCE TABCO, NOV. 2009
