Advance Tabco BBBJ1050 Specifications

14 GAUGE STAINLESS STEEL

14

TWO STATION FLOOR MOUNTED SINK

WITH TUBULAR LEGS

TOE-PUSH OPERATED

Item #: Qty #:

Model #:

Project #:

Gauge

TOE-PUSH OPERATED

FEATURES:

8 1/2” high backsplash.
8” sink bowl depth.
Two stainless steel “Z” brackets supplied each unit.
One K-6 3 1/2” rear basket drain.
Four tubular stainless steel legs with stainless steel bullet feet.
One stainless steel support shelf with rear turn-up.

Toe-Push Operated: Includes two K-104 toe-push valves & two
K-121 spouts.

Single holes provided.

CONSTRUCTION:

All TIG welded.
Welded areas blended to match adjacent surfaces and

to a satin finish.
Die formed tubular wall brackets.

MULTI-STATION ACCESSORIES & REPLACEMENT PARTS

Model Description QTY:

K-6

K-06

K-13

K-104

K-121

K-411

K-508

TA-19

3 1/2” Drain (1 1/2” I.P.S.)

Splash Mount Faucet Mounting Kit

Stainless Steel Soap Dispenser (Wall Mount Only)

Toe-Push Valve Assembly

Single Hole, Splash Mounted 3-1/2” Gooseneck Spout

Strainer Plate for 3-1/2” Drain

Special Sizing Charge

Cut Down To Smaller Size)

Adjustable Stainless Steel Flanged Bullet Foot

(Larger Size

______

______

______

______

______

______

______

______

MATERIAL:

All 14 gauge type “304” stainless steel.

1 5/8” tubular “304” stainless steel legs.

Stainless steel gussets.

MECHANICAL:

Single faucet holes.

# of

Model # Length

FS-WM-40FV

Click Here For Install Guide

K-121

Spouts

40” 2 2 106 lbs. 30

K-411

TA-19

Wall Supports Wt. Cu.Ft.

K-104

# of

K-13

K-06

= Ships UPS

www.advancetabco.com

Standard Faucets conform to NSF 61 Standard 9 and compliance to AB 1953 Standards.

Customer Service Available To Assist You 1-800-645-3166 8:30 am - 8:00 pm E.S.T.

For Orders & Customer Service:

Email: [e-mail] or Fax: [phone]

Email: [e-mail] or Fax: [phone]

For Smart Fabrication™ Quotes:

REF-JJ

DETAILS and SPECIFICATIONS

TOL ± .500” ALL DIMENSIONS ARE TYPICAL

FS-WM-40FV

40"

1

1

16"

"

2

C

L

37"

C

L

18"

18

C

1

"

2

1

L

11"

2"

1

"

19

2

1

"

2

34"

C

1

"

8

2

8"

1

6

"

2

C

L

1

"

C

9

2

L

18"

L

5"

C

L

42

1
2

"

106 Lbs.

REF-JJ

200 Heartland Boulevard, Edgewood, NY 11717-8380

ADVANCE TABCO is constantly engaged in a program of
improving our products. Therefore, we reserve the right to
change specifications without prior notice.

© ADVANCE TABCO, MAY 2018
