Advance Tabco BBBJ1048 Specifications

16 GAUGE STAINLESS STEEL

16

14

Gauge

TWO STATION A.D.A. WALL MOUNTED SINK

WITH TUBULAR SUPPORTS

ELECTRONIC OPERATED

Item #: Qty #:

Model #:

Project #:

Gauge

A.D.A.

COMPLIANT

Hands-Free Electronic Faucet

FEATURES:

8 1/2” high backsplash.
6” sink bowl depth.
Two stainless steel “Z” brackets supplied each unit.
One K-6 3 1/2” rear basket drain.
Two tubular stainless steel support brackets that allow full

clearance underneath.
Electronic Operated: Includes two K-175 Electronic Faucets.
Single hole provided.

CONSTRUCTION:

All TIG welded.
Welded areas blended to match adjacent surfaces and

to a satin finish.
Die formed tubular wall brackets.

MULTI-STATION ACCESSORIES & REPLACEMENT PARTS
MULTI-STATION ACCESSORIES & REPLACEMENT PARTS

K-175

Model Description QTY:

K-6

K-13

K-175

K-411

K-508

TA-19

3 1/2” Drain (1 1/2” I.P.S.)

Stainless Steel Soap Dispenser (Wall Mount Only)

Single Hole, Splash Mounted 3-1/2” Electronic Faucet

Strainer Plate for 3-1/2” Drain

Special Sizing Charge

Cut Down To Smaller Size)

Adjustable Stainless Steel Flanged Bullet Foot

K-411 K-13

(Larger Size

______

______

______

______

______

______

MATERIAL:

All 16 gauge type “304” stainless steel.

1 5/8” tubular “304” stainless steel wall brackets.

Stainless steel gussets.

MECHANICAL:

Single faucet holes.

Model # Length

FC-WM-40EFADA

Click Here For Install Guide

Faucets

40” 2 2 62 lbs. 15

# of

# of

Wall Supports Wt.

FLOOR STANDING LEGS MODIFICATION

Converts Wall Mounted FS-WM SERIES Sink To A Free Standing Floor Unit.

• Stainless Steel Legs with Flanged Feet

• Sides and Rear Cross Bracing

Model #

FS-CB-40

Fits Sink

Length QTY:

40”

______

Cu.

Ft.

= Ships UPS

www.advancetabco.com

Standard Faucets conform to NSF 61 Standard 9 and compliance to AB 1953 Standards.

Customer Service Available To Assist You 1-800-645-3166 8:30 am - 8:00 pm E.S.T.

For Orders & Customer Service:

Email: [e-mail] or Fax: [phone]

Email: [e-mail] or Fax: [phone]

For Smart Fabrication™ Quotes:

REF-JJ

DETAILS and SPECIFICATIONS

TOL ± .500” ALL DIMENSIONS ARE TYPICAL

FC-WM-40EFADA

40"

1

16"

1

"

2

37"

C

L

18

1

"

2

2"

19

A.D.A.

1

"

2

COMPLIANT

C

L

18"

30"

(CLEAR)

1

"

1

2

C

L

11"

5"

12"

C

L

1

26

"

2

C

L

6"

1

8

"

2

1

6

"

2

C

L

62 Lbs.

REF-JJ

200 Heartland Boulevard, Edgewood, NY 11717-8380

ADVANCE TABCO is constantly engaged in a program of
improving our products. Therefore, we reserve the right to
change specifications without prior notice.

© ADVANCE TABCO, MAY 2018
