TRC760A
CAR LOCATOR
Under armed mode, press the
siren will chirp 6 times. The parking light will flash 12 times, for you to
easily locate your car.
PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger
the alarm in case of emergency.
Press and hold the
sound.
To stop the alarm, press the trunk
If the button is not pressed, the alarm will automatically stop after 30 seconds.
TRIGGER THE SYSTEM
When armed, your vehicle is protected as follows:
Light impact will trigger the warn-away signal.
Heavy impacts / Doors open /(if installed) Hood open / (if installed) Trunk
open / Turning on the ignition key will trigger the programmed sequence.
The starter disable relay (if installed) prevents the vehicle’s starter from
cranking. The siren, horn, parking lights, and dome light will turn on alerting
of an intrusion for 30 seconds. Then it will stop and automatic reset and rearm. If the any one of the sensors or detectors is still active, the alarm
system will sound a maximum of 3 times of 30 seconds cycles.
NOISE ABATEMENT CIRCUIT: Your system has a “Noise Abatement
Circuit”. It prevents annoying repetitive trigger sequences due to faulty door
pin switches or environmental conditions such as thunder, jackhammers
airport noise, etc.
Here’s how “Noise Abatement Circuit” works: The alarm triggers five times.
Each time, the same sensor or switch has triggered the alarm; the “Noise
Abatement Circuit” will interpret this pattern of triggers as a false alarm.
After the third trigger, the “Noise Abatement Circuit” ignores, or bypasses,
that sensor or switch until a different sensor or switch is trigger.
button for 3 second. The alarm will immediately
SYSTEM’S TRIGGER CHECK (For two-way transceiver operation only)
Press and hold F button of LCD remote until 3 beeps sound , release and
re-press F button again, the LCD remote will show “ALARM “ icon flashing
on text area (see advanced users mode), then press
system trigger check.
SYSTEM’S STATUS CHECK (For two-way transceiver operation only)
Press F button of LCD remote until 3 beeps sound , the LCD remote will
show “STATUS “ icon flashing in the text area (see advanced users
mode), then press
button to activate system status check.
It responds with one melody sound and all vehicles’ status records will
immediately displayed on the LCD screen.
Note: If it has no response then you are out of range.
TRUNK RELEASE: Press and hold
seconds to remotely control the trunk release.
CHANNEL 4,5,6 OUTPUTS.
Press the transmitter
and buttons at the same time to active Channel
4 function. or
Press and hold F button of LCD remote until 2 beeps sound , release and
re-press F button the LCD remote will show “CH 4” icon flash, then press
button to activate channel 4 function.
Channel 4, 5 & 6 are user-programmable timer outputs. You may program
the built-in timer to send a ground signal for any time duration from 1
second to 120 seconds. For instance, this timer output may be used to turn
on the headlight, power window or sunroof. (Factory defaults setting at
momentary output.)
Press the transmitter
Channel 5 function. or
Press and hold F button of LCD remote until 2 beeps sound , release and
re-press F button the LCD remote will show “CH 5” icon flash, then press
button to activate channel 5 function.
Press the transmitter
Channel 6 function. or
Press and hold F button of LCD remote until 2 beeps sound , release and
re-press F button the LCD remote will show “CH 6” icon flash, then press
button to activate channel 6 function.
Clear the Flashing Icon and Melody Sound: The Transmitter will reset the
flashing icons the next time the Ignition is cycled to the ON position.
Stopping The Trigger Melody Sound: When the alarm is triggered, the LCD
screen will alert the user through a melody sound and a flashing trigger icon.
Press any button on the LCD remote transmitter to stop melody sound only.
button to active car locator function. The
button on the remote control.
button to activate
button on the transmitter for two
and buttons at the same time to active
and buttons at the same time to active
WARNINGS:
As with any product that performs automatic functions, there are certain safety
precautions that you must practice and be aware of.
1. Keep the transmitter out of children’s reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started
automatically.
4. Do not start the vehicle by remote while it’s in an enclosed area or
garage.
5. Always apply the parking brake and lock the vehicle as you exit the
vehicle.
6. The vehicle windows must be rolled up.
7. Should the unit malfunction, disconnect the fuse until the problem is
corrected.
8. The use and operations of this system is the sole responsibility of the
operator.
9. Some areas may have local ordinances that prohibit leaving a vehicle
running on public streets.
10.It is not safe to remote start the vehicle if the vehicle is parked on a
steep incline.
TO REMOTE START THE VEHICLE:
When you want to start your vehicle,
1. Press
2. The parking light will activate to indicate the remote start received the
signal.
3. The engine will start in approximately 5 seconds.
4. Once the engine is running, after couple seconds the parking lights will
turn on and the climate controls will activate and adjust the vehicle’s interior
temperature to your preset setting. (While the vehicle is running, the
“minutes” digit on the LCD screen will flash and the will indicate countdown
timer based on the 5, 10, 20 or 30 minute run time set up by your
installation center.)
5. The vehicle will run for a programmable 5 to 30 minute cycle before
shutting down. (When the unit shuts off the countdown timer will turn off
and the transmitter will play a melody.)
NOTE: The Remote Start Unit will not start the vehicle if any one of the
following conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. The optional remote start enable toggle is switched to the “OFF” position.
(If installed)
4. The gear selector is in any gear other then “PARK” or “NEUTRAL”.
SAFE START (Child safety mode)
Factory default is set to press the
the vehicle. You can program this feature to eliminate an accidental remote
start:
1. The user presses the transmitter
start the vehicle. or
2. The user presses the transmitter
start the vehicle.
NOTE: Contact your installing dealer to activate this feature.
OPERATE THE VEHICLE WHILE RUNNING FROM THE REMOTE START:
To operate the vehicle while the engine is running from the remote start,
Insert the ignition key and turn it to “ON” (not the start) position.
Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON position, the
engine will shut down.
TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been
removed from the ignition. This feature is useful for occasions when you wish
to exit and lock the vehicle for short periods of time, but would like to leave the
motor running and the climate control on.
1. Before turning off the engine, press the
transmitter and the LED indicator will flash 3 times to confirm enter.
2. Turn the ignition key to OFF position. (The engine will stay running.)
3. The engine will run until the pre-programmed time elapsed or shutdown
input is received.
TURBO CHARGE MODE:
Turbo charger mode keeps the engine running after arriving at your
destination for a programmable period of 1, 3 or 5 minutes, This allows the
vehicle’s engine time to conveniently cool down the turbo after you have
Remote Start Operation:
button once on the transmitter.
button once on the transmitter to start
buttons twice within 3 seconds to
and buttons at the same time to
left the vehicle. For use, Please download the complete manual.
button once on the
TIMER START: Please download the complete manual.
This unit can be programmed to start and run the engine every 3 hours or
punctually at the same time next morning, the engine will run for the
programmed running time and then shut down.
IMPORTANT: Timer Start should be used only in open areas, never
start and run the vehicle in on enclosed space as a garage or carport.
Please be sure you fully understand this feature before use.
TEMPERATURE and VOLTAGE CHECK
Please see advanced user menu below
TO TURN OFF THE REMOTE START:
When the engine is running (by remote start), if you want to stop it,
Press
button once on the remote transmitter under the remote start mode.
Press this button twice if the unit is programmed to child safety start.
Press the brake pedal
The vehicle will shut down and turn off the parking light to indicate the
engine has stopped.
SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the
engine will not start or will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. The parking (hand) brake is released (For Turbo Timer Mode)
4. Engine is over-revved. {“Tachometer checking type” only}
5. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
6. Press
button on the remote transmitter under remote start mode.
7. The system triggers.
8. The vehicle refused to start running after {3} unsuccessful
attempts.
ADVANCED USER’S MODE:
LCD REMOTE TRANSCEIVER OPERATION:
Enter: Press and hold F Button until beep sound respond from LCD
transceiver indicate into table 1 – 5 as below.
Exit: Press the
Table 1: ONE beep to confirm (Press & hold “ F “ button until 1 Beep is
heard)
F Button LCD Display
Press once Backlight turns on for 5 seconds
Press twice within 5
seconds
Press three times
within 5 seconds
Press four times
within 5 seconds
Table 2: TWO beeps to confirm (Press & hold “ F “ button until 2 Beeps
are heard)
F Button LCD display
Press and hold the F
Button for 2 second until 2
beeps sounded
Press one more time within
5 seconds
Press twice within 5
seconds
Press three time within 5
seconds
Table 3: THREE beeps to confirm(Press & hold “F” button until THREE
Beeps are heard)
F Button LCD display
Press and hold the F
Button for 3 second
until 3 beeps
sounded
Press ONE more
time within 5
seconds
Press TWO more
times within 5
seconds
Press THREE more
times within 5
seconds
Press Six more
times within 5
seconds
, or button to exit this mode.
PASS and
PASS icon flashing
HIDDEN ALARM and
icon flashing
NTI CAR- JACK and
icon flashing
MENU flashing
CH 4 flashing
CH 5 flashing
CH 6 flashing
STATUS and
icon is flashing
LARM and
icon flashing
oltage and
Check icon flashing
TEMP and
icon flashing
Start timer and
icon flashing
Press button to check the Vehicle
Status.
Press
trigger condition.
Press button to check the Vehicle
Battery condition.
Press
Temperature of the vehicle
Press button to activate or cancel
daily start.
Button
Press button to arm the
alarm and bypass the sensor 1.
Press button to arm system
and with Hidden Alarm Function.
Ignition in "on" position press and
hold button for 2 seconds to
activate anti carjacking functions.
Button
Press button to enter the
menu mode
Press button to activate
channel 4 function
Press button to activate
channel 5 function
Press button to activate
channel 6 function
Button
button to check the system
button to check the Interio
Table 4: FOUR beeps to confirm (Press & hold “F” button until 4 beeps
are heard)
F Button LCD display
Press and hold the F
Button for 4 second
until 4 beeps sounded
DEMO mode
Button
Press button to activate Backlight
will be ON until DEMO operation end.
Table 5: Do-Re-Mi sounds to confirm
F Button LCD
Press and hold the F Button for 6
second until Do-Re-Mi sounded
. PROGRAMMING LCD REMOTE (Transmitter Manual mode):
Selecting and Adjusting Menu options:
Press and hold F button for 1 second until 2 beeps sound, then release the F button.
The text will flash on the LCD screen, press button to enter the menu.
Press button to move up in the menu or button to move down in the menu.
Press button to select the option you would like to adjust.
Press button to increase the value, to activate or deactivate a function or to toggle through the
selection.
Press button to decrease the value, to activate or deactivate a function or to toggle
through the selection.
Press button to move to the next sub-option or go back to the main menu.
EXIT: Press button to exit the menu mode.
Trans.
mode
1 Parking Menu PARK METER
2 Illumination Menu
3 Second Vehicle Default is CAR 1
4 Clock Menu
5 Alarm Clock Menu
6 Confirmation Menu
7 Button Lock Menu
8 Power Save Menu
9 Daily Start Timer Setting
To Exit: Do not push any buttons for 15 seconds
Menu Option LCD displa
- Parking hours
- Parking minutes
- Toggle Parking
countdown
- Toggle Illumination
Mode
- Car Select
- Clock hours
- Clock minutes
- Alarm hours
- Alarm minutes
- Toggle alarm
- Toggle Buzzer and
Vibrate
- Toggle button lock
- Toggle power
save
- Daily Start Hour
- Daily Start Minute
display
DEFLT
flashing
0:30
0 is flashing
0:30
30 is flashing
+ or
3 SEC. or
5 SEC. or
OFF
CAR 1 or
CAR 2
12:00AM
12 is flashing
12:00AM
00 is flashing
12:00AM
12 is flashing
12:00AM
00 is flashing
ON + or
OFF
VIBRATE
VIBRATE +
7:30AM
7 is flashing
7:30AM
30 is flashing
+ or
+ +
Button
Press & hold button for 2
seconds to back to default setting and
1 chip for confirm
Functions
Default is
, - Adjusts parking hour
(value from 0 to 2).
, - Adjusts parking minute
(value from 0 to 59).
- Enables parking countdown.
There is a beep 5 min. before the
Parking countdown reaches 0.
- Disables parking countdown.
Default is
, Basic operation with backlight
Illumination 3 or 5 sec. or OFF
-CAR 1 operation.
- CAR 2 operation.
Default is
, - Adjusts clock hour from 0 to
12
, - Adjusts clock minute from 0
to 59
Default is
, - Adjusts alarm clock hour from
0 to 12
, - Adjusts alarm clock minute
from 0 to 59
- Enable alarm clock or
- Disable alarm clock
Default is
or
, - Buzzer or Vibration
Default is
- button lock / Disable the
transmitter temporarily
- button unlock / Enable the
transmitter function
Default is
- While the power save mode,
the LCD remote transceiver uses “0”
current to save the battery
power.
- Power save OFF
Exit: Press any button to exit the
“Power Save Mode”.
Daily Start Time Adjust Only (ex.
7:30AM)
, - Adjusts clock hour from 0 to
12
, - Adjusts clock minute from 0
to 59
A
QUICK START USERS GUIDE
If you do not understand any part of this quick start users
manual and would like the complete version,
The complete manual is necessary for advanced users and not all user
functions are covered in this quick start guide.
Encore E-9 Remote Transceiver
STANDARD LCD ICON CONFIGURATIONS:
The lock icon will be
displayed when
system is ARMED
Sensor Bypass
Shock sensor bypassed
Hood Trigger
Hood is illegally
opened (Zone 1)
Door Open
Warning
Doors are illegally
opened (Zone 3)
Ignition Trigger
Ignition switch is
illegally turned on
(Zone 5)
Remote
Transmission
You are transmitting
to the control unit.
Anti Car-Jack
Mode Activated
Engine Cranking
Your vehicle engine
Cranking by remote
control
Timer Control
Start
Engine will start
automatically every
2 or 3 hours.
The unlock icon
will be displayed
when the system is
disarmed.
Hidden Alarm
Mode (silent
Alarm)
Trunk Trigger
Trunk is illegally
opened (Zone 2)
Sensor Trigger
Trigger on shock
Sensor 1 (Zone 4)
System trigger
In – Range
Indicator
You are within the
range of the
remote control.
Systems Check
Mode
Engine Running
Your vehicle's
engine is running
Daily Start
Engine will start
automatically at
the same time next
day
Temperature
Start
Engine will start
automatically
when the
programmed
temperature is
reached
Manual Gear
Memorizing
condition for
manual gear start.
Activate Channel
5
Time Monitor
Turbo Timer
Turbo timer was set
up.(programmable)
ctivate Channel 3
(Trunk Release).
Activate Channel 4
Activate Channel 6
Parking Meter
Parking meter
reminder time.
Melody Mode
Remote Control
alerts user through
a melody sound
Valet Mode
Remote start and
alarm functions
temporarily
12:00
BATTERY CHANGING:
Depending on the usage, the remote batteries should be changed at least
once a year in the one way remote and once every 3-8 months for the twoway remote.
The 1-way remote, (E-9s) is powered by a pair of 3V, CR2016 batteries.
These batteries are available at most locations batteries are sold and can
be replaced by the user.
Battery Level Indicator (2-way remote)
The Battery Level indicator has three level indicators that serve as a visual
indication of battery charge. When the battery reaches a low charge level
that requires changing, the remote control will generate a single notification
chirp, and the Battery Level indicator
battery voltage is LOW, the range of the remote will be reduced by 50% to
conserve battery life. The two way remote requires 2, 3 Volt CR2032
batteries. The operation lives of these batteries are affected by many
factors including, temperature, usage, back-light ON time and
programmable “in range status settings”. Do not allow these batteries to
corrode or become wet for any extended period of time.
will flash continuously. If the
Alarm Clock
Alarm clock set.
Low Battery
You have to change
the battery of
remote control.
Vibration Mode
Remote Control
vibrates when the
system is triggered
ACTIVE ARMING – LOCK & ARM:
1. Press
2. The siren will chirp once and parking light will flash once indicating that
DEFECTIVE SENSOR REMINDER: If the siren sounds 3 chirps, then you
have left a door, trunk, or hood lid ajar.
SILENT ARMING / DISARMING: Press the transmitter
REMOTE TRANSMITTER OPERATION:
Transmitter
Button
-
- Arm System and Silent Alarm
+
+
-
-
+
+
+
+
CHIRP INDICATORS: PARKING LIGHT:
Chirp Function Parking light Function
1 chirp
2 chirps
3 chirps
4 chirps
6 chirps
System Function Remark
Lock Doors & Arm System
Panic function
Car Locator Press when in armed mode
Arm and Delete The 2 Stage
Shock Sensor
Function
Silent Arming / Disarming Ignition in "off" position.
Active Anti Car-Jacking Mode
Unlock Doors & Disarm System
Two Steps Door Unlock &
Disarm System (optional)
Trunk Release (Channel 3) Press and Hold for 2 seconds
Passive Arming By-pass While the system Disarmed.
Activate or Turn Off The
Remote Start
Channel # 4 Timer Output (4) Optional
Channel # 5 Timer Output (5) Optional
Channel # 6 Timer Output (6) Optional
Switching code For 2nd Car
Defective Reminder
Disarm / Triggered
Car Locator
Arm
Disarm
Operation.
1 flash
2 flashes
3 flashes
12 flashes
Constant On
Press and Hold for 3
seconds. Press Trunk
button to stop panic function
Press
seconds. Pass will appear on
Press within 3 seconds and
Hold the button
Ignition in "on" position press
and hold for 2 seconds
Press twice within 3 seconds.
Press button once or
Press Twice if set to start
safety mode
twice within 3
the remote
For regular remote
transmitter
Arm
Disarm
Disarm / Triggered
Car Locator
Under Remote Start
-
ALARM OPERATING CONDITION:
1. Arming
2. Disarming
3. Trigger Alarming Flashes Slow Flash Disable Flashes
4. Passive
Starter
Disable
5. Panic Alarming Flashes Flashes
6. Car-Jacking Alarming Flashes Disable Flashes
7. Car Locator 6 Chirps
Siren /
Horn
1 or 3
Chirps
2 or 4
Chirps
Parking
Light
1 Flash Slow Flash Locking Disable
2 or 3
Flashes
Fast Flash Disable
12
Flashes
LED Doors Starter
Unlocking
Locking
Dome
Light
Turns on
for 30 second
at the same time. This will arm or disarm your security system, No chirp
sound will be heard, arm / disarm confirmation will be through the vehicles
parking lights only.
SENSOR BY-PASS: Press the
arm the security system and by-pass the shock sensor.
HIDDEN ALARM FUNCTION: Silent Alarm
Press the
the hidden alarm function. The security system will arm and with “Hidden
Alarm Mode” The siren / horn will be silenced even if the sensor is
triggered in the armed mode. Alarm indication will only appear on the LCD
Transmitter.
PASSIVE ARMING (Programmable)
Active arming / disarming is controlled by your security system via the
remote transmitter. This security system is equipped with an optional
Passive Arming feature which allows the security system to arm 30
seconds after the last door is closed. Operation is as follows.
1. Turn the ignition to the “OFF” position and exit the vehicle.
2. After all entrances are closed, the security system LED will flash fast for
3. After the 30-second time has elapsed, the security system will
PASSIVE ARMING WITH PASSIVE DOOR LOCKING
The vehicle doors will automatically lock after the passive arming cycle
has been completed.
PASSIVE ARMING BY-PASS: While the system is disarmed, Press the
“ON”. The security system will remain in this temporary state for as long
as you wish. To exit passive by-pass, press the transmitter
buttons and the system will return to normal status.
ACTIVE DISARMING – UNLOCK & DISARM:
1. Press
2. The siren will chirp twice and the parking lights will flash twice
TAMPER DISARMING: If the alarm is triggered, upon disarm the system’s
siren will chirp 4 times, and the parking lights will flash 3 times telling you
the alarm has been triggered during the last armed state.
PATHWAY ILLUMINATION: When receiving an unlock /disarm signal, this
feature will turn the parking lights “ON” for 30 seconds and for 10 seconds
upon the lock signal. (Programmable)
AUTOMATIC RE-ARM: If this feature is selected, the security system will
automatically re-arm itself in 60 seconds after disarming with remote
transmitter. Automatic rearm will cancel if any door is opened before the 60
seconds timer has elapsed.
DISARMING WITHOUT A TRANSMITTER:
The Override function may be used if the remote transmitter is lost or
inoperative.
1. Enter the vehicle and turn the ignition switch to the 'ON’ position.
2. (Alarm will sound.)
3. Within 10 seconds push and release the valet switch. The alarm will stop
VALET MODE: (System is in Disarm Mode)
button on the transmitter.
the system is now armed. The vehicle’s doors will lock upon arming if
interfaced with the security system.
and buttons
button two times within 5 seconds will
button first; within 3 seconds press the button to activate
30 seconds. If you reopen any door / hood / trunk, the security system
LED will stop flashing. It will begin flashing again once all vehicle
entrances are closed.
automatically “ARM”. The siren will chirp [1] time and the parking lights
will flash [1] time.
button twice, the system will respond with [1] chirp and LED will turn
or
button on the transmitter.
indicating that the security system is now disarmed. The vehicle’s
doors will unlock.
sounding and enter the disarm mode. You can now start and operate the
vehicle normally.
The valet switch allows you to temporarily bypass all alarm function,
eliminating the need to hand your transmitter to parking attendants or
garage mechanics. When the system is in valet mode, all alarm functions
and remote start functions are bypassed, however, the remote panic
feature and remote door locks will remain operational. To use the valet
mode, the system must first be disarmed either by using your remote
transmitter, or by operating the Manual Override sequence.
a). Under disarm mode, turn the ignition to “ON” position.
b). Press and hold valet switch for 2 seconds until the LED turns ON
solid. The LED will remain on as long as the system is in 'valet mode'.
Exit Valet Mode:
a). Turn ignition 'ON'.
b). Push and hold valet switch for 2 seconds, The LED will turn off
indicate the system are exiting the valet mode.
Loading...
