Perimeter Plus Vehicle Security
and Remote Start Systems
Owner’s Manual
4280760
Rev P6 04/17
4280760 Phase 2 VSS_RMST Owners Guide_P6.indd 14280760 Phase 2 VSS_RMST Owners Guide_P6.indd 1 4/27/2017 9:41:21 AM4/27/2017 9:41:21 AM
Contents
Welcome ............................................................................................3
Perimeter Plus Vehicle Security (optional) ....................................4
Arming the Security System ....................................................................4
Disarming the Security System ...............................................................4
When the Security System is Armed .......................................................5
Security LED Indicator (optional).............................................................5
Shock / Impact Sensor (optional) ............................................................5
Starter Interrupt (optional) .......................................................................5
Shock Sensor Disable .............................................................................6
Intrusion Attempt Alert .............................................................................6
Disarming the System if Your RKE Keyfob is Lost or Inoperative ..........6
Basic Remote Start Feature (optional) ...........................................7
Starting Your Vehicle with the factory RKE Transmitter...........................7
Stopping Your Vehicle with the factory RKE Transmitter .........................7
Long-Range 1-Way and 2-Way Remote Start System (optional) ..8
Starting Your Vehicle with the 1-Way Transmitter ...................................8
Starting Your Vehiclewith the 2-Way Transmitter ....................................8
Stopping Your Vehicle with the 1-Way and 2-Way Transmitter ...............8
2-Way Transmitter Feedback Indicators ..................................................9
Car Find / Panic Mode (2-Way Transmitter Only) ...................................9
Remote Start Operation (optional) ................................................10
Entering the Vehicle While it is Running via Remote Start ....................10
Pre-Heating or Pre-Cooling the Interior of the Vehicle ..........................10
Remote Start Safety Features .......................................................10
Remote Start Prevention and Shut down ..............................................10
Power Window / Moon Roof Disable .....................................................10
Automatic Door Locking ........................................................................10
Remote Start System Maintenance...............................................11
Changing the Remote Control Transmitter Battery ...............................11
Adding Remote Control Transmitters to Your System ...........................11
Deleting Lost or Stolen Remote Control Transmitters from
Your System ..........................................................................................11
User Selectable Options ................................................................12
Optional Activation Method (1-Way & 2-Way Transmitters) ..................12
Additional User Notes ....................................................................12
Extending Run Time ..............................................................................12
Why Your Vehicle May Not Start Via Remote ........................................12
Warranty Information .....................................................................13
2
4280760 Phase 2 VSS_RMST Owners Guide_P6.indd 24280760 Phase 2 VSS_RMST Owners Guide_P6.indd 2 4/27/2017 9:41:34 AM4/27/2017 9:41:34 AM
Welcome
Congratulations on your purchase of a Ford Motor Company Perimeter
Plus Vehicle Security and/or Remote Start System. This technology
represents the latest in automotive convenience and protection
systems. Your system, purchased today, is ready to accept tomorrow’s
advancements in technology.
The Ford Motor Company vehicle security and remote start system is a
scalable product that can be confi gured based on personal preference
and vehicle model. All features contained in this manual may not have
been installed at time of purchase. Please consult your Ford dealer to
determine which features have been confi gured on your vehicle and
how to expand the functionality of your chosen system.
NOTE:
The Perimeter Plus vehicle security system can be upgraded to include
long-range (up to 1,000 ft. range) remote start features by adding the
long range 1-way or 2-way transmitters to your system.*
The 1-way and 2-way remote start system can also be upgraded to
include ultra-range (up to 2,500 ft.) features.*
* Require additional components and labor, see your dealer for details.
4280760 Phase 2 VSS_RMST Owners Guide_P6.indd 34280760 Phase 2 VSS_RMST Owners Guide_P6.indd 3 4/27/2017 9:41:34 AM4/27/2017 9:41:34 AM
3
Perimeter Plus Vehicle Security (optional)
NOTE:
Using your factory supplied Remote Keyless Entry (RKE) keyfob is the primary
method of arming and disarming your Perimeter Plus security system. The system is
armed when the doors are locked with the RKE keyfob. The system is disarmed when
the doors are unlocked with the RKE keyfob.
Arming the Security System:
The Vehicle Security System may be armed using any of the methods below.
1. By pressing the
2. Pressing the lock area on the door handle (intelligent access equipped vehicles
only).
3. By entering the “Lock” code into the keypad located on the outside of the driver’s
door (if equipped).
The front and rear lights will fl ash and the security LED (optional) will illuminate for
10 - 20 seconds (pre-arm mode), after which the security system will arm. The
security LED will begin to “blink” and all closed entry points will be protected.
If an entry point is left open, the security system will continue to ignore that entry point
until it is closed.
(Lock Button) on the factory RKE keyfob.
Disarming the Security System:
The Vehicle Security System will be disarmed if any of the following actions are taken.
1. Pressing the
2. Touching the inside of the exterior door handle (intelligent access equipped
vehicles only).
3. Entering the “Unlock” code into the keypad located on the outside of the driver’s
door (if equipped).
4. Turning the ignition “On” (must have a valid key read if equipped).
If there were no vehicle intrusion attempts while the security system was armed,
the security LED (optional) will turn off when the security system is disarmed. If
any vehicle intrusion attempts were made while the security system was armed, the
vehicle’s horn will honk and the exterior lights will fl ash two (2) times and the security
LED (optional) will fl ash a fast on/off sequence indicating an intrusion attempt.
(Unlock Button) on the factory RKE keyfob.
4
