Advance Security CA 4055, CA 4555 Users Manual
PROFESSIONAL
SERIES
Owner’s Guide
For Models:
CA 4055
CA 4555
Vehicle Remote Start System
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
12017 Voxx Electronics Corporation. All rights reserved.
Table of Contents
Using Your Remote Starter ..................................................................... 3
Remote Starting Your Vehicle ............................................................3
Remote Start Shutdown .................................................................... 3
Unlocking the Vehicle (optional) ........................................................3
Entering Your Vehicle while it is Running via Remote Start ..............3
Programmed Transmitter Notication (PTN) .....................................4
Valet Mode ........................................................................................4
Preheating or Precooling the Vehicle’s Interior .................................4
Using the “Quick-Stop” Feature ......................................................... 4
Operating the 2 / 3 Hour Start Up Timer Mode ..................................5
Car Find Feature - ca4555 Only ........................................................ 5
Remote Start Safety Features ........................................................... 6
Status LED, Light Flashes and Horn Chirp Indications ....................... 6
Remote Control Buttons & Functions ................................................... 7
2WayRemoteControlNotication-ca4555Only ...............................7
Replacing Remote Control Batteries ..................................................... 8
Warranty Information ..............................................................................9
2 ca4055 - ca4555 Owners
Using Your Remote Starter
Remote Starting Your Vehicle
To activate the remote start function, press and release the button 2 times within 2
seconds. The system will sound, the parking lights will ash 1 time and the system
will check the vehicle to ensure it is safe to start. If all safety parameters are correct,
the vehicle will start. The vehicle’s parking lights will turn on (or ash depending on
system settings) as a visual indication that the vehicle has started and is running.
If your vehicle stalls or does not start, the system will pause 5 seconds, then try
3 more times to start the vehicle (a total of 4 attempts). The system will pause 5
seconds between each start attempt.
Note: This is the default conguration for remote start activation, the system can also
be congured in option programming to remote start with a single press of the
button.
Remote Start Shutdown
Press and hold the button for 3 seconds to turn the vehicle off. Pressing the brake
pedal will also shutdown the remote start.
Note: The system can also be congured in option programming as a single or double
press and release of the button.
Unlocking the Vehicle (optional)
To unlock the vehicle’s doors press and hold the button for 3 seconds anytime the
vehicle is remote started.
Note: The system can also be congured in option programming as a single or
double press and release of the button.
Note: Additional parts and/or labor may be necessary, see your installing dealer for
details.
Entering the Vehicle while it is Running via Remote Vehicle Start
1. Unlock the vehicle’s doors.
2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!
3. Insert the key into the ignition switch and turn to the ON or RUN
position.
4. Press the brake pedal. The remote start system will disengage and
the vehicle will operate normally.
32017 Voxx Electronics Corporation. All rights reserved.
Programmed Transmitter Notication - PTN
As a security precaution each time the vehicle’s ignition is turn on the status LED
light with ash the number of transmitters programmed into the system. This helps
to identify unauthorized transmitters from accessing your vehicle. If you believe an
unauthorized transmitter has been programmed to your system, contact your installing
dealer for assistance.
Valet Mode
When valet mode is activated the status LED will light solid and all remote start
functions will be disabled. To enter or exit valet mode simply follow the steps
outlined below:
1. Turn the vehicle’s ignition ON.
2. Push and hold the programming/valet button.
3. The LED will turn on solid when valet mode is active
4. Release the programming/valet button.
Preheating or Precooling the Vehicle’s interior
Before exiting the vehicle, set the temperature controls to the desired setting and
operation. After the system starts the vehicle, the heater or air conditioner will
activate and heat or cool the vehicle’s interior to your setting.
Using the “Quick-stop” Feature
If you want to make a short stop and keep your vehicle running (to keep the interior
warm or cool), the quick-stop feature allows you to do this while keeping your vehicle
secure and your keys with you.
To engage Quick Stop:
1. Stop the vehicle and place the transmission in PARK.
2. With your foot off the brake pedal, press and release the button 2
times within 2 seconds. The LED will ash 3 times to conrm quick
stop is entered.
3. Remove the keys from the ignition and exit the vehicle. Press the
button to lock the vehicle’s doors if desired.
Note: Do not leave children or animals unattended in the vehicle when using the
quick-stop feature.
4 ca4055 - ca4555 Owners
