Chapter 1 Introduction

Congratulations on your purchase of this outstanding Wireless Broadband Router. This
product is specifically designed for Small Office and Home Office needs. It provides a
complete SOHO solution for Internet surfing, and it is easy to configure and operate for
even non-technical users. Instructions for installing and configuring this product can be
found in this manual. Before you install and use this product, please read this manual
carefully for fully exploiting the functions of this product.

1.1 Functions and Features

l High speed for wireless LAN connection

11Mbps data rate by incorporating Direct Sequence Spread Spectrum (DSSS).

l Roaming

Provides seamless roaming within the IEEE 802.11b WLAN infrastructure.

l IEEE 802.11b compatible

allowing inter-operation among multiple vendors.

l Auto fallback

11M, 5M, 2M, 1M data rate with auto fallback.

l Broadband modem and IP sharing

connects multiple computers to a broadband (cable or DSL) modem or an
Ethernet router to surf the Internet.

l Auto-sensing Ethernet Switch

equipped with a 4-port auto-sensing Ethernet switch.

l VPN supported

supports multiple PPTP sessions and allows you to setup VPN server and VPN
clients.

l Firewall

all unwanted packets from outside intruders are blocked to protect your Intranet.

-5-

l DHCP server supported

all of the networked computers can retrieve TCP/IP settings automatically from
this product.

l Web-based configuring

configurable through any networked computer’s web browser using Netscape or
Internet Explorer.

l Access Control supported

allows you to assign different access right for different users.

l Virtual Server supported

enables you to expose WWW, FTP and other services on your LAN to be
accessible to Internet users.

l User-Definable Application Sensing Tunnel

user can define the attributes to support the special applications requiring
multiple connections, like Internet gaming, video conferencing, Internet
telephony and so on, then this product can sense the application type and open
multi-port tunnel for it.

l DMZ Host supported

Lets a networked computer to be fully exposed to the Internet; this function is
used when special application sensing tunnel feature is insufficient to allow an
application to function correctly.

1.2 Packing List

l One wireless broadband router unit
l One installation CD-ROM
l One power adapter
l Two CAT-5 UTP Fast Ethernet cable

-6-

Chapter 2 Hardware Installation

2.1 Panel Layout

2.1.1. Front Panel

The front panel features three 10/100 Mbps Ethernet ports, one Wide Area network
(WAN) port and diagnostic LED indicators. The WAN port connects your DSL or cable
modem to the router. The LAN ports are used to connect to your computers or other
network devices. LEDs monitor the status of each port.

Figure 2-1 Front Panel

Port:

WAN: the port where you will connect your cable (or DSL) modem or Ethernet router.
Port 1-3: the ports where you will connect networked computers and other devices.

-7-

LED:

This product is working for some

LED Function Color

Status Description

M1 System status 1 Orange Blinking

On

M2 System status 2 Orange

Blinking

On The WAN port is linked

Blinking

On The LAN port is linked

Blinking

WAN

LAN

W-Link

WAN port

activity

LAN port

activity

Backbone

activity

Green

Green

Green Blinking

W-Act Wireless activity Green Blinking

On

1~3

10/100

1~3

Link status Green

Data Rate Green

Blinking

On

This product is functioning
properly

service
This product is being configured

or upgraded. Don’t turn it off !

The WAN port is sending or
receiving data

The LAN port is sending or
receiving data

Sending or receiving data from
wireless to wired backbone

Sending or receiving data via
wireless

An active station is connected to
the corresponding LAN port. Link/Act.

The corresponding LAN port is
sending or receiving data

Data is transmitting in 100Mbps
on the corresponding LAN port.

-8-

2.1.2. Rear Panel

Figure 2-2 Rear Panel

Ports:

Port Description

ON/OFF Power switch
DC IN Power inlet (DC 5V)
COM Serial port (connect analog modem or console cable)

PRINTER Printer Port

2.2 Procedure for Hardware Installation

1. Decide where to place your Wireless Broadband Router:

You can place your Wireless Broadband Router on a desk or other flat surface, or you
can mount it on a wall. For optimal performance, place your Wireless Broadband Router
in the center of your office (or your home) in a location that is away from any potential
source of interference, such as a metal wall or microwave oven. This location must be
close to power and network connection.

-9-

2. Setup LAN connection:

a. Wired LAN connection: connect an Ethernet cable from your computer’s Ethernet

port to one of the LAN ports of this product.

b. Wireless LAN connection: make sure the antennas are in a vertical position (if not,

rotate over 90 degrees).

Figure 2-3 Setup of LAN and WAN connections for this product.

3. Setup WAN connection: prepare an Ethernet cable for connecting this product to

your cable/xDSL modem or Ethernet backbone. Figure 2-3 illustrates the WAN

connection.

-10-

4. Power on:

Connecting the power cord to power inlet and turning the power switch on, this

product will automatically enter the self-test phase. When it is in the self-test phase,

the indicators M1 and M2 will be lighted ON for about 10 seconds, and then M1 and

M2 will be flashed 3 times to indicate that the self-test operation has finished. Finally,

the M1 will be continuously flashed once per second to indicate that this product is in

normal operation.

-11-

Chapter 3 Network Settings and Software Installation

To use this product correctly, you have to properly configure the network settings of your
computers and install the attached setup program into your MS Windows platform
(Windows 95/98/NT/2000).

3.1 Make correct network settings of your computer

The default IP address of this product is 192.168.123.254, and the default subnet mask is

255.255.255.0. These addresses can be changed on your need, but the default values are
used in this manual. If the TCP/IP environment of your computer has not yet been
configured, you can refer to Appendix A to configure it. For example,

1. configure IP as 192.168.123.1, subnet mask as 255.255.255.0 and gateway as

192.168.123.254, or more easier,

2. configure your computers to load TCP/IP setting automatically, that is, via DHCP
server of this product.

After installing the TCP/IP communication protocol, you can use the ping command to
check if your computer has successfully connected to this product. The following example
shows the ping procedure for Windows 95 platforms. First, execute the ping command

ping 192.168.123.254

If the following messages appear:

Pinging 192.168.123.254 with 32 bytes of data:
Reply from 192.168.123.254: bytes=32 time=2ms TTL=64

a communication link between your computer and this product has been successfully
established. Otherwise, if you get the following messages,

Pinging 192.168.123.254 with 32 bytes of data:
Request timed out.

-12-
