Package contents

AMP 7000-XX 1

AC Power Supply 1

AC Power Cable 1

Li-ion Battery 1 (if supplied)

Thermal paper roll 1

Quick Reference Guide 1

Electrical Considerations

Use only approved power supply that is provided with this device, using other

power supply may cause damage to the device or risk of fire.

Avoid using this product during electrical storms.

Avoid locations near electrical appliances or other devices that cause excessive

voltage fluctuations or emit electrical noise (for example, air conditioners,

electric motors, neon signs, high-frequency or magnetic security devices, or

computer equipment).

Do not use the terminal near water or in moist conditions.

Unpacking the shipping carton

Open the shipping carton and inspect all its contents for possible tampering or damage.

The AMP 7 Series terminal is a secure device and any tampering may cause cease to

function properly.

To unpack the shipping carton

Remove and inspect the following items

Terminal

Power Supply

Power chord

Telephone cable (if available)

Remove plastic wrapping from the terminal

Remove plastic protective film from the LCD

2015 Advanced Mobile Payment Inc. (AMP) All rights reserved. AMP, the AMP logo, vTerminal

are either trademarks or registered trademarks of AMP in Canada and/or other countries. All other

trademarks or brand names are the properties of their respective holders. All features and

specifications are subject to change without notice. Product display image for representation

purposes only. Actual product display may vary. Reproduction or posting of this document without

prior AMP approval is prohibited.

Advanced Mobile Payment Inc.

Do not use a terminal that has been damaged or tampered. AMP 7 Series terminal

comes equipped with tamper-evident labels. If a label or component appears

damaged, please notify the shipping company and your AMP representative or

service provider immediately.

Keep the shipping carton and packing materials for feature packing or moving

terminal.

Advanced Mobile Payment Inc.

DQ-7000-1-EAMP 7 Series Countertop / Mobile Terminal Quick Reference Guide

Examining terminal features before starting the installation

Sty lus penLan yard ho le

DQ-7000-1-EAMP 7 Series Countertop / Mobile Terminal Quick Reference Guide

Pap er hold er Lid

han dle

Top Antenna

ind uctiv e zone

LCD d ispla y

Key pad

Use r smart c ard slo t

Mag netic s tripe c ard

Rub ber pad

Power Port

RS- 232 Por t

LAN /PSTN

Por t

Bac k cover

Tag Lab el

Bar code

Lab el

Ban d Label

Description

Paper holder lid: Container for thermal paper roll ( Φ38X57mm)

Handle: Pull handle to open the paper holder lid

LCD display: 2.8 inch and 320*240 TFT LCD. Optional signature capture function.

Antenna inductive zone: The zone for tapping contactless card

Key pad: 10 alphanumeric keys, 8 functional keys, 1 power switch key.

User smart card slot: Supporting EMV card with contact surface facing up.

Magnetic Card Reader: ISO7812, 1/2 Tracks or 2/3 Tracks or 1/2/3 Tracks, bi-directional

swiping with the magnetic stripe facing LCD.

Rubber pad: Four pads, anti-vibration/non-slip.

Tag label: Showing model name, rated device parameter.

Barcode Label: Device serial number.

Band Label: Frequency bands of communication module.

Back cover: Remove the cover to install battery or SIM/UIM/SAM card.

Power port: Approved power supply for AMP 7 Series

RS-232 port: 1 RS-232(up to 2), output: 5VDC, 500mA.

LAN/PSTN port: An optional communication between LAN Port and PSTN Port.

Lanyard hole: Slide lanyard through and make a loop on the outside.

Internal wireless: GPRS

USB P ort

LED indicator: Power status indicator of device

USB Port: USB communication interface

Battery installation (if supplied)

Place the terminal face down and remove the battery cover.
