Page 1
Commander
INFLATABLE BOAT
OWNER'S INFORMATION PACKET
COMMANDER 9 FH301
COMMANDER 12 FH302
READ THIS MANUAL CAREFULLY
Save these instructions for future reference
SIERRA STERLING 2010
IMPORTANT!
BEFORE PROCEEDING
Page 2
CAUTIONS:
· GET BOATING INSTRUCTIONS SPECIFIC TO THIS TYPE OF CRAFT.
· OBTAIN CERTIFIED FIRST AID TRAINING AND CARRY FIRST AID AND RESCUE/SAFETY EQUIPMENT.
· ALWAYS WEAR A NATIONALLY APPROVED PERSONAL FLOTATION DEVICE.
· USE THE BOAT ONLY IN PROTECTED SHORE-ZONES, AVOID OPEN WATER AND STREAMS WITH
STRONG CURRENTS.
· DRESS APPROPRIATELY FOR WEATHER CONDITIONS; COLD WATER AND/OR COLD WEATHER CAN
RESULT IN HYPOTHERMIA.
· CHECK YOUR EQUIPMENT PRIOR TO EACH USE FOR SIGNS OF WEAR OR FAILURE.
· POOR WEIGHT DISTRIBUTION CAN RESULT IN DESTABILIZATION OF THE BOAT.
· DO NOT GO BOATING IN FLOOD CONDITIONS.
· BE AWARE OF DANGEROUS CURRENTS, WEATHER CHANGES, AND STRONG OFF SHORE WINDS.
· SCOUT UNFAMILIAR WATER; PORTAGE WHERE APPROPRIATE.
· IF NOT CAREFUL, CHILDREN COULD BECOME ENTANGLED IN THE BOAT’S ROPES. DO NOT LEAVE
CHILDREN UNSUPERVISED IN BOAT.
· DO NOT EXCEED YOUR ROWING ABILITY; BE HONEST WITH YOURSELF.
· CONSULT YOUR PHYSICIAN PRIOR TO BEGINNING YOUR BOATING TRAINING.
· YOU MUST NOT USE ALCOHOL OR MIND ALTERING DRUGS PRIOR TO USING THIS PRODUCT.
· FOLLOW THE MANUFACTURER'S RECOMMENDATIONS FOR THE USE OF THIS PRODUCT.
· IF ADDITIONAL OUTFITTING IS REQUIRED, USE MANUFACTURER'S APPROVED MATERIALS
ONLY; DO NOT IMPAIR ENTRY OR EXIT ACCESS.
· READ OWNER'S INFORMATION PACKET PRIOR TO USING THIS PRODUCT.
Always practice safety, and take the time to learn about the area where you are
boating. Be careful that you do not over-estimate your strength, your endurance,
or your skill. Be careful never to under-estimate weather conditions. Be aware
of the dangers before you begin. Be aware of your skill level. Be sure you
understand and accept the risk of these dangers. There are many boating clubs
all over the world. These can be a great source of information on places to boat,
people to boat with, and most importantly continued safety practices.
4. GUIDELINES FOR USAGE
BOATING CAN BE VERY DANGEROUS AND PHYSICALLY DEMANDING. THE USER
OF THIS PRODUCT SHOULD UNDERSTAND THAT PARTICIPATION IN BOATING MAY
INVOLVE SERIOUS INJURY OR DEATH. OBSERVE THE FOLLOWING SAFETY
STANDARDS WHENEVER USING THIS PRODUCT. THE USER OF THIS PRODUCT
ACKNOWLEDGES BOTH AN UNDERSTANDING AND AN ASSUMPTION OF THE RISK
INVOLVED IN BOATING.
After you have inflated your boat, and before you put it in the water, inspect
your equipment for obvious signs of wear or failure, review local rules and
regulations, and read again the “CAUTION” statement.
Most areas have local laws and regulations about the use and equipment of
small boats. Usually a phone call to the local authorities will provide you with
the needed information. Some areas may require that you register, and display a
registration number on the front of the boat. Once you have been issued a
number, it is best to affix it to the boat by printing it on the material with a
permanent ink marker. If you are required to display a sticker or vinyl letters, an
inflatable boat ID kit can be purchased at most marine stores.
INFLATABLE BOAT INSTRUCTION MANUAL
COMMANDER 9 FH301 & COMMANDER 12 FH302
CONTENTS
1. CAUTION - SAFETY WARNING/
CAPACITY
2. INFLATING INSTRUCTIONS
3. HARDWARE FEATURES
4. GUIDELINES FOR USAGE
5. PROPER CARE
6. REPAIRS
FOR ADDITIONAL INFORMATION PLEASE CALL US AT:
888-545-1424
Page 3
1. CAUTION - SAFETY WARNING/CAPACITY
Users of this product agree by their use to accept the inherent risks
involved in this boating activity and agree to follow all instructions,
cautions, and warnings carefully before using this boat.
(PLEASE READ CAUTION STATEMENT CAREFULLY)
C A U T I O N
SAFETY WARNING
BOATING CAN BE VERY DANGEROUS AND PHYSICALLY DEMANDING. THE USE R OF THI S
PRODUCT SHOULD UNDERSTAND THAT PARTICIPATION IN BOATING MAY INVOLVE SERIOUS INJURY
OR DEATH. OBSERVE THE FOLLOWING SAFETY STANDARDS WHENEVER USING THIS PRODUCT.
· GET B OATING INSTRUCTIONS SPECIFIC TO THIS TYP E OF CRA FT.
· OBTAIN CERTIFIED FIRST AID TRAINING AND CARRY FIRST AID AND RESCUE/SAFETY EQUIPMENT.
· ALWAYS WEAR A NATIONALLY APPROVED PERSO NAL FLOTATION DEVICE.
· USE T HE BOAT ONLY IN PROTECTED SHORE-ZONE S, AVOID OPEN WATER AND STREAMS WITH
STRON G CURRENTS.
· DRESS APPR OPRIATELY FOR WEATHER CONDITIONS ; COLD WATER AND/OR CO LD WEATHER
CAN RESULT IN HYPOT HERMIA.
· CHECK YOU R EQUIPMEN T PRIOR TO EACH USE FOR SIG NS OF WE AR OR FAILURE.
· POOR WEIGHT DISTR IBUTION CAN RESULT IN DESTABILIZATION OF THE BOAT.
· DO NO T GO BOATING I N FLOOD CONDITIONS.
· BE AWARE OF DANGEROUS CURRENTS, WEATHER CHANGES, AND STRONG OFF SHORE WINDS.
· SCOUT UNFAMILIAR WATER; PORTAGE WHERE APPROP RIATE.
· IF NO T CAREFUL, CHILDREN COULD BECOME ENTANGLED IN THE BOAT’S ROPES. DO NOT
LEAVE CHILD REN UNSUPERVIS ED IN BO AT.
· DO NO T EXCEED YOU R ROWING ABI LITY; BE HONEST WITH YOURSEL F.
· CONSULT YOUR P HYSICIAN PR IOR TO BEGI NNING YOUR BOATING TRAINING.
· YOU MUST NOT USE ALCOHOL OR MIND ALTERING DRUGS PRIOR TO USING THIS PRODUCT.
· FOLLOW THE MANUFACTURER' S RECOMMENDATIONS FOR THE USE OF T HIS PRODUCT.
· IF ADDITION AL OUTFITTING IS REQUI RED, USE MANUFACTURER'S APPROVE D MATERIALS
ONLY; DO NOT IMPAIR E NTRY OR EXIT ACCE SS.
· READ OWNER'S INFO RMATION PACKET PRIOR TO USING THI S PRODUCT.
THE USER OF THIS PRODUCT AC KNOWLEDGES BOTH AN UNDERSTANDING AND AN ASSUMPTION
OF THE RISK INVOLVED IN BOATING.
MAXIMUM CAPACITIES
MAXIMUM CAPACITIES
The person/load capacity is
determined by the availability
4
PERSONS OR
700 LBSPERSONS, MOTOR, GEAR
2.5 H.P. MOTOR
MODELFH301 - FRIDAY HARBOR - COMMANDER9
THIS BOAT COMPLIES WITH U.S. COAST GUARD SAFETY
STANDARDS IN EFFECT ON THE DATE OF CERTIFICATION
MANUFACTURER: SIERRASTERLING / CONCORD, CA USA 94524
+
+ =
0,07 bar (main chambers)
1.0 psi (main chambers)
600
317 kg
LBS.
6
PERSONS OR
1200 LBS PERSONS, MOTOR, GEAR
2.5 H.P. MOTOR
MODELFH302 - FRIDAY HARBOR - COMMANDER12
THIS BOAT COMPLIES WITH U.S. COAST GUARD SAFETY
STANDARDS IN EFFECT ON THE DATE OF CERTIFICATION
MANUFACTURER: SIERRASTERLING / CONCORD, CA USA 94524
+
+ =
0,07 bar (main chambers)
1.0 psi (main chambers)
900
544 kg
LBS.
of proper seating in the boat.
Acceptable seating determines
the number of passengers, not
the overall capacity.
Please read this entire manual for additional safety information.
Please pay close attention to items marked Important, Caution,
Warning, Never, and Always.
Page 4
2. INFLATING INSTRUCTIONS
Use either a bellows style foot pump or two-way hand pump to inflate your boat.
Be sure that the fitting on the pump hose fits snug in the valves on the boat.
NEVER USE COMPRESSORS, CO2, OR COMPRESSED AIR AS THEY
MAY DAMAGE YOUR BOAT.
1. Inner Main Chamber
2. Floor Chamber
3. Side Stabilization Chamber
4. Side Stabilization Chamber
5. Outer Main Chamber
Figure 1. (5 CHAMBERS)
2.1 Understanding Your Valves
1. The Commander uses standard Boston valves for inflation of the Main
Air Chambers (Marked as 1 and 5). The following figures give details on
how to operate these valves.
1
tom side
2
Stabiliz
ed on b
Valve for
locat
4
3
located on bot
3
Valve for Stabilization Chamber
5
WARNING
USE ONLY IN PROTECTED WATERS TO WITHIN 300M OF THE SHORE
ber
ation Cham
side
tom
ot
4
2.2 Inflation
Inflate your boat in the following order: FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY CAUSE DAMAGE TO YOUR BOAT. DO NOT OVER
INFLATE.
1. Inflate Chamber 1 until it feels firm to the touch.
2. Inflate Chamber 2, “floor”, (using appropriate fitting). Fill with air until firm.
CAUTION: Do Not Over Inflate. The floor should still be a little soft, not
rock hard.
3. Inflate Chamber 3 and 4 until they protrude from the underside of the boat and
become firm.
Page 5
4. Inflate Chamber 5 until it feels firm to the touch.
5. Inflate the seats until firm. CAUTION: Do Not Over Inflate.
IMPORTANT:
DO NOT OVER-INFLATE THE BOAT. OVER-INFLATION IS THE
PRIMARY CAUSE OF DAMAGE. INFLATE THE BOAT UNTIL MOST OF
THE WRINKLES ARE GONE OR UNTIL IT FEELS FIRM TO THE
TOUCH.
CAUTION: Water temperature and weather will affect the air pressure of the
boat. In cold weather your boat will lose some pressure as the air inside
contracts. If this occurs, you may want to add a bit more air to improve your
boat's performance. However in hot weather, or prolonged direct sunlight, the
air inside will expand. You must let some air out of the appropriate chambers to
prevent the boat from failing due to overpressure. You should avoid exposing
your boat to extreme temperatures (hot or cold).
3. HARDWARE FEATURES
The following illustration has been provided to asist you in identifying some of
the more important hardware features located on your boat.
Swivel
Oarlock
Oar Holders
Figure 3.
Swivel
Oarlock
Fishing Rod
tom side
ation Chamber
2
or Stabilization Chamber
Valve f
located on bot
4
Motor Mount
Fitting
Holder
ed on bot
locat
Stabiliz
3
Valve for
tom side
Motor Mount
Drain Plug
5
WARNING
USE ONLY IN PROTECTED WATERS TO WITHIN 300M OF THE SHORE
Fittings
Page 6
4. GUIDELINES FOR USAGE
BOATING CAN BE VERY DANGEROUS AND PHYSICALLY DEMANDING. THE USER
OF THIS PRODUCT SHOULD UNDERSTAND THAT PARTICIPATION IN BOATING MAY
INVOLVE SERIOUS INJURY OR DEATH. OBSERVE THE FOLLOWING SAFETY
STANDARDS WHENEVER USING THIS PRODUCT. THE USER OF THIS PRODUCT
ACKNOWLEDGES BOTH AN UNDERSTANDING AND AN ASSUMPTION OF THE RISK
INVOLVED IN BOATING.
After you have inflated your boat, and before you put it in the water, inspect
your equipment for obvious signs of wear or failure, review local rules and
regulations, and read again the “CAUTION” statement.
Most areas have local laws and regulations about the use and equipment of
small boats. Usually a phone call to the local authorities will provide you with
the needed information. Some areas may require that you register, and display a
registration number on the front of the boat. Once you have been issued a
number, it is best to affix it to the boat by printing it on the material with a
permanent ink marker. If you are required to display a sticker or vinyl letters, an
inflatable boat ID kit can be purchased at most marine stores.
CAUTIONS:
· GET BOATING INSTRUCTIONS SPECIFIC TO THIS TYPE OF CRAFT.
· OBTAIN CERTIFIED FIRST AID TRAINING AND CARRY FIRST AID AND RESCUE/SAFETY EQUIPMENT.
· ALWAYS WEAR A NATIONALLY APPROVED PERSONAL FLOTATION DEVICE.
· USE THE BOAT ONLY IN PROTECTED SHORE-ZONES, AVOID OPEN WATER AND STREAMS WITH
STRONG CURRENTS.
· DRESS APPROPRIATELY FOR WEATHER CONDITIONS; COLD WATER AND/OR COLD WEATHER CAN
RESULT IN HYPOTHERMIA.
· CHECK YOUR EQUIPMENT PRIOR TO EACH USE FOR SIGNS OF WEAR OR FAILURE.
· POOR WEIGHT DISTRIBUTION CAN RESULT IN DESTABILIZATION OF THE BOAT.
· DO NOT GO BOATING IN FLOOD CONDITIONS.
· BE AWARE OF DANGEROUS CURRENTS, WEATHER CHANGES, AND STRONG OFF SHORE WINDS.
· SCOUT UNFAMILIAR WATER; PORTAGE WHERE APPROPRIATE.
· IF NOT CAREFUL, CHILDREN COULD BECOME ENTANGLED IN THE BOAT’S ROPES. DO NOT LEAVE
CHILDREN UNSUPERVISED IN BOAT.
· DO NOT EXCEED YOUR ROWING ABILITY; BE HONEST WITH YOURSELF.
· CONSULT YOUR PHYSICIAN PRIOR TO BEGINNING YOUR BOATING TRAINING.
· YOU MUST NOT USE ALCOHOL OR MIND ALTERING DRUGS PRIOR TO USING THIS PRODUCT.
· FOLLOW THE MANUFACTURER'S RECOMMENDATIONS FOR THE USE OF THIS PRODUCT.
· IF ADDITIONAL OUTFITTING IS REQUIRED, USE MANUFACTURER'S APPROVED MATERIALS
ONLY; DO NOT IMPAIR ENTRY OR EXIT ACCESS.
· READ OWNER'S INFORMATION PACKET PRIOR TO USING THIS PRODUCT.
Always practice safety, and take the time to learn about the area where you are
boating. Be careful that you do not over-estimate your strength, your endurance,
or your skill. Be careful never to under-estimate weather conditions. Be aware
of the dangers before you begin. Be aware of your skill level. Be sure you
understand and accept the risk of these dangers. There are many boating clubs
all over the world. These can be a great source of information on places to boat,
people to boat with, and most importantly continued safety practices.
Page 7
CAUTIONS:
· GET BOATING INSTRUCTIONS SPECIFIC TO THIS TYPE OF CRAFT.
· OBTAIN CERTIFIED FIRST AID TRAINING AND CARRY FIRST AID AND RESCUE/SAFETY EQUIPMENT.
· ALWAYS WEAR A NATIONALLY APPROVED PERSONAL FLOTATION DEVICE.
· USE THE BOAT ONLY IN PROTECTED SHORE-ZONES, AVOID OPEN WATER AND STREAMS WITH
STRONG CURRENTS.
· DRESS APPROPRIATELY FOR WEATHER CONDITIONS; COLD WATER AND/OR COLD WEATHER CAN
RESULT IN HYPOTHERMIA.
· CHECK YOUR EQUIPMENT PRIOR TO EACH USE FOR SIGNS OF WEAR OR FAILURE.
· POOR WEIGHT DISTRIBUTION CAN RESULT IN DESTABILIZATION OF THE BOAT.
· DO NOT GO BOATING IN FLOOD CONDITIONS.
· BE AWARE OF DANGEROUS CURRENTS, WEATHER CHANGES, AND STRONG OFF SHORE WINDS.
· SCOUT UNFAMILIAR WATER; PORTAGE WHERE APPROPRIATE.
· IF NOT CAREFUL, CHILDREN COULD BECOME ENTANGLED IN THE BOAT’S ROPES. DO NOT LEAVE
CHILDREN UNSUPERVISED IN BOAT.
· DO NOT EXCEED YOUR ROWING ABILITY; BE HONEST WITH YOURSELF.
· CONSULT YOUR PHYSICIAN PRIOR TO BEGINNING YOUR BOATING TRAINING.
· YOU MUST NOT USE ALCOHOL OR MIND ALTERING DRUGS PRIOR TO USING THIS PRODUCT.
· FOLLOW THE MANUFACTURER'S RECOMMENDATIONS FOR THE USE OF THIS PRODUCT.
· IF ADDITIONAL OUTFITTING IS REQUIRED, USE MANUFACTURER'S APPROVED MATERIALS
ONLY; DO NOT IMPAIR ENTRY OR EXIT ACCESS.
· READ OWNER'S INFORMATION PACKET PRIOR TO USING THIS PRODUCT.
Always practice safety, and take the time to learn about the area where you are
boating. Be careful that you do not over-estimate your strength, your endurance,
or your skill. Be careful never to under-estimate weather conditions. Be aware
of the dangers before you begin. Be aware of your skill level. Be sure you
understand and accept the risk of these dangers. There are many boating clubs
all over the world. These can be a great source of information on places to boat,
people to boat with, and most importantly continued safety practices.
4. GUIDELINES FOR USAGE
BOATING CAN BE VERY DANGEROUS AND PHYSICALLY DEMANDING. THE USER
OF THIS PRODUCT SHOULD UNDERSTAND THAT PARTICIPATION IN BOATING MAY
INVOLVE SERIOUS INJURY OR DEATH. OBSERVE THE FOLLOWING SAFETY
STANDARDS WHENEVER USING THIS PRODUCT. THE USER OF THIS PRODUCT
ACKNOWLEDGES BOTH AN UNDERSTANDING AND AN ASSUMPTION OF THE RISK
INVOLVED IN BOATING.
After you have inflated your boat, and before you put it in the water, inspect
your equipment for obvious signs of wear or failure, review local rules and
regulations, and read again the “CAUTION” statement.
Most areas have local laws and regulations about the use and equipment of
small boats. Usually a phone call to the local authorities will provide you with
the needed information. Some areas may require that you register, and display a
registration number on the front of the boat. Once you have been issued a
number, it is best to affix it to the boat by printing it on the material with a
permanent ink marker. If you are required to display a sticker or vinyl letters, an
inflatable boat ID kit can be purchased at most marine stores.
5. PROPER CARE
Your inflatable boat is made of very durable materials. However, like anything
else, proper use and care will increase the life of your boat. Before storing your
boat make sure it is both CLEAN and DRY. You may clean your boat with a
mild liquid soap and water. Never use strong solvents to clean your boat as they
will destroy the material. If your boat has been used in salt-water, rinse it off
with fresh water and allow it to dry before storing. Use a dry towel to wipe up
all moisture. It should be deflated and kept out of direct sunlight when stored.
Avoid exposure to extreme temperatures (hot or cold). If your boat is exposed
to freezing temperatures while storing, allow it to warm before unfolding.
6. REPAIRS
All boats come with a repair kit that includes glue and several patches. This
should remain with the boat in the event that you may need it.
TO REPAIR SMALL PUNCTURES AND CUTS:
1. Cut a rounded patch at least ¼” or ½” larger than the hole or cut.
2. Clean the area where the patch will be placed with water and/or mild soap.
3. Make sure all surfaces are dry.
4. Spread a thin layer of glue on both the patch and on the damaged area and let
it sit for three to five minutes or until tacky.
5. Press the patch onto the desired area, making sure that no air bubbles form.
6. Apply pressure evenly to the patch by placing weight on it. Do not peel back.
7. Do not inflate the boat for at least twelve (12) hours.
It is always a good idea to keep notes of your boating experiences. Your
notes can serve as a reminder of what to look out for, as well as what gear to
bring along, and what conditions are like.
Date Time Location Notes
Boating Notes
Page 8
SIERRA STERLING
toll free 888-545-1424
Loading...
