Adtran WLAN194XF2 User Manual
User Manual
802.11 an PCIe Module
WLAN194XF2
Confidential Page 1
PRODUCT DESCRIPTION
The WLAN194XF2 is utilizing Qualcomm Atheros
AR9590B (i-Temp) solution, and is targeting
enterprise-class platforms. It is acting at 5GHz
frequency band.
P
RODUCT SPECIFICATION
Chipset Atheros AR9590B
PA SiGe SE5003L
Interface PCIe
General information
Support both 3.3V and 5V power voltage input
Operating voltage
Antenna connectors 3 MMCX connectors
Temperature range
Security
Data rates
Tx channel width support 20MHz / 40MHz
PCIe Slot : DC 3.3 V ± 5% with Advanced DC Power management support
PA: Extended DC power supply 5V
-40°C to + 55 °C (Operating temperature)
-45°C to + 85°C (Storage temperature)
WPA, WPA2, 64/128 bit WEP, TKIP, and AES. hardware-based IEEE 802.11i
encryption engine
802.11a: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11n: 20MHz channel:
• 1Nss: 65Mbps @ 800ns GI; 72.2Mbps @ 400ns GI (Max);
• 2Nss: 130Mbps @ 800ns GI; 144.44Mbps @ 400ns GI (Max);
• 3Nss: 195Mbps @ 800ns GI; 216.7Mbps @ 400ns GI (Max);
802.11n: 40MHz channel:
• 1Nss: 135Mbps @ 800ns GI; 150Mbps @ 400ns GI (Max.);
•
2Nss: 270Mbps @ 800ns GI; 300Mbps @ 400ns GI (Max.);
•
3Nss: 405Mbps @ 800ns GI; 450Mbps @ 400ns GI (Max.);
Standard/Compliance WECA (Wi-Fi & Wi-Fi5 compliance), IEEE802.11,a/n, RoHS and WEEE
Regulation Certifications FCC Part 15
PCB dimension L x W 58 x 31 mm
Confidential Page 2
Preliminary Radio Specification
Channel Data rate
802.11a 6 ~ 24 Mbps 24 +/- 1.5dBm
36 Mbps 22.5 +/- 1.5dBm
48 Mbps 21.5 +/- 1.5dBm
54 Mbps 19.5 +/- 1.5dBm
802.11n_HT20 MCS 0/8/16 22.5 +/- 1.5dBm
MCS 1/9/17 22.5 +/- 1.5dBm
MCS 2/10/18 21.5 +/- 1.5dBm
MCS 3/11/19 21.5 +/- 1.5dBm
MCS 4/12/20 21.5 +/- 1.5dBm
MCS 5/13/21 20.5 +/- 1.5dBm
MCS 6/14/22 19.5 +/- 1.5dBm
MCS 7/15/23 18.5 +/- 1.5dBm
802.11n_HT40 MCS 0/8/16 22.5 +/- 1.5dBm
MCS 1/9/17 22.5 +/- 1.5dBm
Typical AVG. Power
Tolerance
@ per chain (dBm)
Typical Rx Sensitivity
@combined (dBm)
≦-92 dBm
≦-76 dBm
≦-92 dBm
≦-76 dBm
≦-86 dBm
MCS 2/10/18 21.5 +/- 1.5dBm
MCS 3/11/19 21.5 +/- 1.5dBm
MCS 4/12/20 21.5 +/- 1.5dBm
MCS 5/13/21 20.5 +/- 1.5dBm
MCS 6/14/22 19.5 +/- 1.5dBm
MCS 7/15/23 18.5 +/- 1.5dBm
≦-72 dBm
Current consumption information
Tx current consumption
(without Jump wire)
Sleep Current Sleep mode
OS support Windows 2000/XP/Vista, Linux
Continuous TX (99% duty) 7 W
≦ 100 mA
Confidential Page 3
PCIE C
ONNECTOR PIN DEFINITION
Confidential Page 4
