ADTRAN NetVanta 1000, NetVanta 1000R User Manual

NetVanta 1000 Series and

NetVanta 1000R Series

Hardware Installation Guide

1200500E1 NetVanta 1224 1200504E1 NetVanta 1224ST 1200510L1 NetVanta 1224STR (AC) 1200520E1 NetVanta 1224R 1200530L1 NetVanta 1224R PoE 1200560E2 NetVanta 1524ST 1200570L1 NetVanta 1224STR PoE 1200580L1 NetVanta 1224 PoE 1200584L1 NetVanta 1224ST PoE 1200590L1 NetVanta 1224STR (DC) 1700515E2 NetVanta 1335 1700515E12 NetVanta 1335 WiFi 1700525E2 NetVanta 1335 PoE 1700525E12 NetVanta 1335 WiFi PoE 4200368L1 Enhanced Feature Pack (Hardware and Software) for IPSec VPN Upgrade for

NetVanta 1224STR (AC/DC), 1224R, 1224R PoE, and 1224STR PoE 1200861L1 NetVanta 56K/64K Network Interface Module 1200862L2#NEBS NetVanta T1/FT1 NEBS Network Interface Module 1202862L1 NetVanta T1/FT1 Network Interface Module 1202863L1 NetVanta T1/FT1 + DSX-1 Network Interface Module 1200872L1 NetVanta Dual T1 Network Interface Module 1200868E1/L1 NetVanta E1/FE1 Network Interface Module 1200878E1/L1 NetVanta E1/FE1 + G.703 Drop Network Interface Module 1200866E1 NetVanta Serial Network Interface Module 1200936E1 NetVanta SHDSL Network Interface Module, Annex A 1200937E1 NetVanta SHDSL Network Interface Module, Annex B 1202869E1 NetVanta ADSL Network Interface Module, Annex A 1202889E1 NetVanta ADSL Network Interface Module, Annex B 1700801G1 NetVanta 3G CDMA Network Interface Module (NetVanta 1335 only) 1200864L1 NetVanta Analog Modem Dial Backup Interface Module 1200865L1 NetVanta ISDN BRI Dial Backup Interface Module 1200875L1 NetVanta ISDN S/T Dial Backup Interface Module 1200480E1 1000BaseSX Multi-Mode SFP Module 1200481E1 1000BaseLX Single-Mode SFP Module 1200816E1, 817E1, 818E1, 819E1

CompactFlash

, 128, 256, 512, and 1024 MB, respectively (NetVanta 1335 only)

61200500L1-34N November 2008

Trademarks NetVanta 1000/1000R Series Hardware Installation Guide

Trademarks

Any brand names and product names included in this manual are trademarks, registered trademarks, or trade names of their respective holders.

To the Holder of the Manual

The contents of this manual are current as of th e date of publication. ADTRAN reserves the right to change the contents without prior notice.

In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.

Software Licensing Agreement

Each ADTRAN product contains a single license for ADTRAN supplied software. Pursuant to the Licensing Agreement, you may: (a) use the software on the purchased ADTRAN device only and (b) keep a copy of the software for backup purposes. This Agreement covers all software installed on the system, as well as any software available on the ADTRAN website. In addition, certain ADTRAN systems may contain additional conditions for obtaining software upgrades.

Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

901 Explorer Boulevard

P.O. Box 140000

Huntsville, AL 35814-4000

Phone: (256) 963-8000

Printed in U.S.A.

NetVanta 1000/1000R Series Hardware Installation Guide Conventions

Conventions

Notes provide additional useful information.

Cautions signify information that could prevent service interruption or damage to the equipment.

Warnings provide information that could prevent injury or endangerment to human life.

Safety Instructions NetVanta 1000/1000R Series Hardware Installation Guide

Safety Instructions

When using your telephone equipment, please follow these basic safety precautions to reduce the risk of fire, electrical shock, or personal injury:

1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) during an electrical storm. There is a remote risk of shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord, power supply, and batteries indicated in the manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for special disposal instructions.

5. The socket-outlet shall be installed near the equipment and shall be easily accessible.

This equipment incorporates double pole/neutral fusing. If the neutral fuse opens and the line fuse does not open, voltage could still be present in the unit.

Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE) are given in the NetVanta Safety and Regulatory Information document on the AOS Documentation CD.

Save These Important Safety Instructions

NetVanta 1000/1000R Series Hardware Installation Guide FCC-Required Information

FCC-Required Information

FCC regulations require that the following information be provided in this manual:

1. This equipment complies with Part 68 of Federal Communications Commission (FCC) rules and requirements adopted by America’s Carriers Telecommunications Association (ACTA). Each registered interface has a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. If requested, provide this information to the telephone company.

2. If this equipment causes harm to the telephone network, the telephone company may temporarily discontinue service. If possible, advance notification is given; otherwise, notification is given as soon as possible. The telephone company will advise the customer of the right to file a complaint with the FCC.

3. The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the proper operation of this equipment. Advance notification and the opportunity to maintain uninterrupted service are given.

4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is corrected, or it is certain the equipment is not malfunctioning.

5. This unit contains no user-serviceable parts.

6. This equipment is designed to connect to the telephone network or premises wiring using an FCC-compatible modular jack, which is compliant with Part 68 and requirements adopted by ACTA.

7. The following information may be required when applying to the local telephone company for leased line facilities:

Registration

Part Number

1200861L1 US: HDCDENAN1200861L1 1202862L1

1202863L1 1200872L1 US: HDCDENAN1200872L1

1200864L1 US: HDCMM04A1200864L1 Analog Loop Start 0.4A/9.0Y 02LS2 RJ-11C 1200865L1 US: HDCDENAN1200865L1 Basic Rate ISDN 6.0F 02LS5 RJ-49C 1200869E1 US: HDCDL01A1200869L1 ADSL Modem 0.1A Metallic RJ-11C

US: HDCDENAN1202863L1

Number Service Type REN/SOC FIC USOC

56 kbps Digital Interface 64 kbps Digital Interface

1.544 Mbps - SF

1.544 Mbps - SF and B8ZS

1.544 Mbps - ESF

1.544 Mbps - ESF and B8ZS

6.0F

6.0N

04DU5-56 04DU5-64

04DU9-BN

04DU9-DN 04DU9-1KN 04DU9-1SN

RJ-48S

RJ-48C

8. The ringer equivalence number (REN) is useful in determining the quantity of devices you may connect to your telephone line and still have all of those devices ring when your number is called. In most areas, the sum of the RENs of all devices should not exceed five. To be certain of the number of devices you may connect to your line as determined by the REN, call your telephone company to determine the maximum REN for your calling area.

9. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs. Contact your state public utility commission or corporation commission for information.

FCC Radio Frequency Interference Statement NetVanta 1000/1000R Series Hardware Installation Guide

FCC Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio frequencies. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Electromagnetic Compatibility (EMC) Table

NetVanta Module P/N and Name NetVanta 1224STR (AC) / 1200861L1 56K/64K NIM FCC Part 15 Class A 1200862L2#NEBS T1/FT1 NEBS NIM N/A FCC Part 15 Class A,

1202862L1 1202863L1 1200872L1

1200868E1/L1 1200878E1/L1

1200866E1 Serial NIM FCC Part 15 Class A

1200936E1 1200937E1

1202869E1 1202889E1

1700801G1 3G CDMA NIM N/A N/A FCC Part 15 Class A 1200864L1

1200865L1 1200875L1

1202368L1 VPN Accelerator Card

T1/FT1 NIM T1/FT1 + DSX-1 NIM Dual T1 NIM

E1/FE1 NIM E1/FE1 + G.703 Drop NIM

SHDSL NIM, Annex A SHDSL NIM, Annex B

ADSL NIM, Annex A ADSL NIM, Annex B

Analog Modem DIM ISDN BRI DIM ISDN S/T DIM

(included in P/N 4200368L1)

1224R EN 55022 Class A

FCC Part 15 Class A EN 55022 Class A

FCC Part 15 Class A EN 55022 Class A EN 55024 EN 61000-3-2 EN 61000-3-3

EN 55022 Class A EN 55024 EN 61000-3-2 EN 61000-3-3

FCC Part 15 Class A EN 55022 Class A EN 55024 EN 61000-3-2 EN 61000-3-3

NetVanta 1224STR (DC) NetVanta 1335 N/A FCC Part 15 Class A

EN 55022 Class A GR-1089-CORE, Sections 2 and 3

N/A FCC Part 15 Class A

EN 55022 Class A N/A

EN 55022 Class A

EN 55022 Class A EN 55024 EN 61000-3-2 EN 61000-3-3

NetVanta 1000/1000R Series Hardware Installation Guide Wireless Radio Channel Ranges

Wireless Radio Channel Ranges

The following table lists by country the channels support by the ADTRAN WiFi products (NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE only).

Country

Asia 149, 153, 157, 161 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 Australia 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 Canada 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11

Denmark Europe 34, 38, 42, 46 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 Finland France 34, 38, 42, 46 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 Germany

Ireland

Italy Japan 34, 38, 42, 46 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13

Mexico 36, 40, 44, 48, 149, 153, 157, 161, 165 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11 Netherlands New Zealand 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 Norway Puerto Rico 36, 40, 44, 48, 149, 153, 157, 161, 165 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11

South America 802.11a not supported 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 Spain

Sweden Switzerland 34, 38, 42, 46 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 United Kingdom United States 36, 40, 44, 48, 149, 153, 157, 161, 165 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11

36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140

802.11a (5 GHz)

Wireless Radios Channels

1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13

802.11bg (2.4 GHz)

Wireless Radios Channels

Industry Canada Compliance Information NetVanta 1000/1000R Series Hardware Installation Guide

Industry Canada Compliance Information

Notice: The Industry Canada label applied to the product (identified by the Industry Canada logo or the “IC:” in front of the certification/registration number) signifies that the Industry Canada technical specifications were met.

Notice: The REN for this terminal equipment is supplied in the documentation or on the product labeling/ markings. The REN assigned to each terminal device indicates the maximum number of terminals that can be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices should not exceed five (5).

Canadian Emissions Requirements

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications.

Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques de Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee par le ministre des Communications.

Service and Warranty

For information on the service and warranty of ADTRAN products, visit the ADTRAN website at

http://www.adtran.com/support

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Power over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Wireless Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

SFP Module Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Physical Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

NetVanta 1224 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

NetVanta 1224ST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

NetVanta 1224R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

NetVanta 1224STR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

NetVanta 1335 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

NetVanta 1524ST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Option Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Network Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Dial Backup Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Supplying Power to the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Installing Dial Backup and Network Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1) . . . . . . . . . . . . . . . . . . 60

Installing a CompactFlash Card (NetVanta 1335 Series only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Installing Wireless Access Antennas (NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE only) . . . 62

Installing the 3G CDMA NIM Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Appendix A. Connector Pin Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Table of Contents NetVanta 1000/1000R Series Hardware Installation Guide

List of Figures

Figure 1. NetVanta 1224 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 2. NetVanta 1224 PoE Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 3. NetVanta 1224 and NetVanta 1224 PoE Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 4. NetVanta 1224ST Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Figure 5. NetVanta 1224ST PoE Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Figure 6. NetVanta 1224ST and NetVanta 1224ST PoE Rear Panel Layout . . . . . . . . . . . . . . . . . . . . 19

Figure 7. NetVanta 1224R Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 8. NetVanta 1224R PoE Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 9. NetVanta 1224R and NetVanta 1224R PoE Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . 22

Figure 10. NetVanta 1224STR (AC) Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 11. NetVanta 1224STR (DC) Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 12. NetVanta 1224STR PoE Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 13. NetVanta 1224STR (AC) and NetVanta 1224STR PoE Rear Panel Layout . . . . . . . . . . . . . 25

Figure 14. NetVanta 1224STR (DC) Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 15. NetVanta 1335 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 16. NetVanta 1335 PoE Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 17. NetVanta 1335 WiFi Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 18. NetVanta 1335 WiFi PoE Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 19. NetVanta 1335 and NetVanta 1335 PoE Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 20. NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE Rear Panel Layout . . . . . . . . . . . . . . . . 29

Figure 21. NetVanta 1524ST Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Figure 22. NetVanta 1524ST Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Figure 23. NetVanta 56K/64K NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 24. NetVanta T1/FT1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Figure 25. NetVanta T1/FT1 NEBS NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Figure 26. NetVanta T1/FT1 + DSX-1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Figure 27. NetVanta Dual T1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Figure 28. NetVanta E1/FE1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Figure 29. NetVanta E1/FE1 + G.703 Drop NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Figure 30. NetVanta Serial NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Figure 31. NetVanta SHDSL NIM, Annex A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Figure 32. NetVanta SHDSL NIM, Annex B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Figure 33. NetVanta ADSL NIM, Annex A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Figure 34. NetVanta ADSL NIM, Annex B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Figure 35. NetVanta 3G CDMA NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Figure 36. Wallmount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Figure 37. Grounding the NetVanta 1224STR (DC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Figure 38. Installing DIMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Figure 39. NIM and DIM Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Figure 40. NetVanta VPN Accelerator Card Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Figure 41. CompactFlash Card Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Figure 42. 3G CDMA NIM Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Figure 43. Proper Antenna Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

List of Figures NetVanta 1000/1000R Series Hardware Installation Guide

List of Tables

Table 1. Front Panel LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Table 2. 3G CDMA NIM LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Table 3. Primary Antenna Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Table 4. Diversity Antenna Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Table 5. Antenna-to-Antenna Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Table A-1. CONSOLE Port Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Table A-2. SFP Slot Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Table A-3. 10/100Base-T Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Table A-4. 1000Base-T Gigabit Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Table A-5. WAN-DDS Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Table A-6. WAN-T1 Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Table A-7. WAN-E1 Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Table A-8. DSX-1 Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Table A-9. G.703 Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Table A-10. WAN-SHDSL Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Table A-11. WAN-ADSL Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Table A-12. Serial to Cable Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Table A-13. Analog Station (FXS) and Analog Trunk (FXO) Port Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . 72

Table A-14. Analog Modem and ISDN BRI DBU Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Table A-15. ISDN S/T DBU Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

List of Tables NetVanta 1000/1000R Series Hardware Installation Guide

1. INTRODUCTION

The NetVanta 1000 Series includes the NetVanta 1224, NetVanta 1224 PoE, NetVanta 1224ST, NetVanta 1224ST PoE, NetVanta 1335, NetVanta 1335 PoE, NetVanta 1335 WiFi, NetVanta 1335 WiFi PoE, and the NetVanta 1524ST. The NetVanta 1000R Series includes the NetVanta 1224R, NetVanta 1224R PoE, NetVanta 1224STR (AC), NetVanta 1224STR (DC), and NetVanta 1224STR PoE.

This hardware installation guide lists the NetVanta 1000 and 1000R Series units’ specifications, describes the physical characteristics of the units, introduces basic functionality, and provides installation instructions. All NetVanta 1000 and 1000R Series units run the ADTRAN Operating System (AOS), and are managed through an EIA-232

Power over Ethernet

The NetVanta 1000 and 1000R Series power over Ethernet (PoE) devices provide the same basic functionality as the NetVanta 1000 Series products. PoE provides the ability to detect attached powered devices (PDs), and deliver 48 VDC to the PD via existing CAT 5 cabling. The PoE devices are fully compliant with the IEEE 802.3af PoE standard. By default, the PoE switches discover and provide power to IEEE-compliant PDs.

Wireless Access

The NetVanta 1335 Wireless Fidelity (WiFi) Series provides a single access point for connection with IEEE 802.11a/b/g wireless networks. A dual radio design with two dual-band external antennas is used to support concurrent 802.11a and 802.1 1b/g connections.

CONSOLE port (DB-9) located on the rear panel.

SFP Module Slots

The NetVanta 1224ST, NetVanta 1224STR PoE, NetVanta 1335, and NetVanta 1335 PoE support two small form-factor pluggable (SFP) slots; the NetVanta 1224STR, NetVanta 1335 WiFi, and NetVanta 1335 WiFi PoE have one; and the NetVanta 1524ST has four. All accept a number of industry standard SFP modules. The SFP modules provide Gigabit Ethernet fiber connectivity for high-speed uplinks or switch stacking. The following modules are available for purchase (both of these modules require fiber optic cable with LC connectors):

• 1200480E1 1000BaseSX Multi-Mode SFP Module

• 1200481E1 1000BaseLX Single-Mode SFP Module

In this document, the term NetVanta means all NetVanta 1000 and NetVanta 1000R Series products. If a statement only applies to one particular unit, the text refers to the unit individually. Additionally, unless otherwise specified, descriptions for a NetVanta 1000 or 1000R Series device also applies to the PoE and WiFi versions of that device.

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

2. PHYSICAL DESCRIPTIONS

NetV anta 1224

The NetVanta 1224 is a managed switch housed in a 1U-high rack-mountable metal enclosure that includes a universal AC power supply . The front panel contains 24 10/100BaseT Ethernet interfaces (RJ-45). The NetVanta 1224 PoE version provides the ability to detect attached PDs, and deliver 48 VDC to the PDs via existing CAT 5 cabling.

This section includes a list of features, a list of shipping contents, and a description of the unit’s front and rear panel designs. For additional information, refer to the following sections:

• Product Specifications on page 34

• Mounting Options on page 54

• Supplying Power to the Unit on page 56 For information on switch configuration for a specific application, refer to the quick configuration documents

provided on the AOS Documentation CD shipped with your base unit. For details on the command line interface (CLI), refer to the AOS Command Reference Guide (also included on your CD).

NetVanta 1224 Shipping Contents

Each NetVanta 1224 unit is shipped in its own cardboard shipping carton. Open each carton carefully , and avoid deep penetration into the carton with sharp objects.

After unpacking the unit, inspect it for possible shipping damage. If the equipment has been d amaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Repair and Replacement section of the Support page on the ADTRAN website at http://www .adtran.com/support).

Domestic shipments of the NetVanta 1224 include the following items:

• NetVanta 1224 base unit

• AOS Documentation CD

• A detachable po wer cable with a grounded, three-prong plug

• Quick Start Guide

• Warranty card International shipments of the NetVanta 1224 include the following items:

• NetVanta 1224 base unit

• AOS Documentation CD

• All necessary power cords

• Quick Start Guide

• Warranty card

NetVanta 1224 Front Panel Design

The NetVanta 1224 and NetVanta 1224 PoE front pan els are shown below. Table 1 on page 33 describes all of the LEDs, and Appendix A on page 67 shows the connector pinouts.

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

NetVanta 1224 Front Panel Features 10/100BaseT Ethernet Interfaces

The NetVanta 1224s contain 24 10/100BaseT Ethernet interfaces (RJ-45). These interfaces are consecutively numbered 1 through 24, from left to right, with the numbers screened directly above each port. Status LEDs for each of these interfaces are located directly over these numbers.

The NetVanta 1224 PoE also has green and red PoE status LEDs located in the upper left and upper right corners (respectively) of each Ethernet connector.

Status LED

The STAT LED, which indicates the unit’s status, is located to the lower left of RJ-45 port 1.

Figure 1. NetVanta 1224 Front Panel Layout

Figure 2. NetVanta 1224 PoE Front Panel Layout

NetVanta 1224 Rear Panel Design

The NetVanta 1224 and NetVanta 1224 PoE re ar panel is shown below. Refer to Appendix A on page 67 for pinouts.

Figure 3. NetVanta 1224 and NetVanta 1224 PoE Rear Panel Layout

NetVanta 1224 Rear Panel Interfaces CONSOLE Interface

The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and configuration (via a DB-9 female connector).

Connection directly to an external modem requires a cross-over cable.

Power Connection

The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to the Unit on page 56 for connection details.

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

NetV anta 1224ST

The NetVanta 1224ST and NetVanta 1224ST PoE are managed switches housed in a 1U-high rack-mountable metal enclosure that includes a universal AC power supply . The front panel contains 24 10/100BaseT Ethernet interfaces (RJ-45). The NetVanta 1224ST front panel contains two Gigabit Ethernet interfaces that provide two fixed RJ-45 connectors and two standard SFP slots for fiber connectivity . The Ne tVanta 1224ST PoE version provides the ability to detect attached PDs, and deliver 48 VDC to the PDs via existing CAT 5 cabling.

This section includes a list of features, a list of shipping contents, and a description of the unit’s front and rear panel designs. For additional information, refer to the following sections:

• Product Specifications on page 34

• Mounting Options on page 54

• Supplying Power to the Unit on page 56 For information on switch configuration for a specific application, refer to the quick configuration documents

provided on the AOS Documentation CD shipped with your base unit. For details on the CLI, refer to the AOS Command Reference Guide (also included on your CD).

NetVanta 1224ST Shipping Contents

Each NetVanta 1224ST unit is shipped in its own cardboard shipping carton. Open each carton carefully, and avoid deep penetration into the carton with sharp objects.

After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damag ed in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Repair and Replacement section of the Support page on the ADTRAN website at http://www .adtran.com/support).

Domestic shipments of the NetVanta 1224ST include the following items:

• NetVanta 1224ST base unit

• AOS Documentation CD

• A detachable po wer cable with a grounded, three-prong plug

• Quick Start Guide

• Warranty card International shipments of the NetVanta 1224ST include the following items:

• NetVanta 1224ST base unit

• AOS Documentation CD

• All necessary power cords

• Quick Start Guide

• Warranty card

NetVanta 1224ST Front Panel Design

The NetVanta 1224ST and the NetV anta 1224ST PoE front panels are shown below. Table 1 on page 33 describes all of these LEDs, and Appendix A on page 67 shows the connector pinouts.

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

NetVanta 1224ST Front Panel Features 10/100BaseT Ethernet Interfaces

The NetVanta 1224STs contain 24 10/100BaseT Ethernet interfaces (RJ-45). These interfaces are consecutively numbered 1 through 24, from left to right, with the numbers screened directly above each port. Status LEDs for each of these interfaces are located directly over these numbers.

The NetVanta 1224ST PoE also has green and red PoE status LEDs located in the upper left and upper right corners (respectively) of each Ethernet connector.

Gigabit Ethernet Interfaces/SFP Slots

The NetVanta 1224STs also contain two Gigabit Ethernet interfaces that provide two fixed RJ-45 connectors and two standard SFP slots for fiber connectivity. (Use either the RJ-45 connectors or the SFP slots. The fiber slots have precedence.) These interfaces are labeled LEDs (also labeled

Status LED

G1 and G2) are located to the left of RJ-45 port 1, above the STAT LED.

G1 and G2, and their status

The STAT LED, which indicates the unit’s status, is located to the lower left of RJ-45 port 1.

Figure 4. NetVanta 1224ST Front Panel Layout

Figure 5. NetVanta 1224ST PoE Front Panel Layout

NetVanta 1224ST Rear Panel Design

The NetVanta 1224ST and NetV anta 1224ST PoE rear panel is shown below. Refer to Appendix A on page 67 for pinouts.

Figure 6. NetVanta 1224ST and NetVanta 1224ST PoE Rear Panel Layout

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

NetVanta 1224ST Rear Panel Interfaces CONSOLE Interface

The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and configuration (via a DB-9 female connector).

Connection directly to an external modem requires a cross-over cable.

Power Connection

The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to the Unit on page 56 for connection details.

NetV anta 1224R

The NetVanta 1224R and NetV anta 1224R PoE are managed switches housed in a 1U-high rack -mountable metal enclosure that includes a universal AC power supply . The front panel contains 24 10/100BaseT Ethernet interfaces (RJ-45). The NetVanta 1224R PoE version provides the ability to detect attached PDs, and deliver 48 VDC to the PDs via existing CA T 5 cabling. Both units contain a single network interface mo dule (NIM) slot on the rear panel to support the following modules:

• 1200861L1 56K/64K NIM

• 1202862L1 T1/FT1 NIM

• 1202863L1 T1/FT1 + DSX-1 NIM

• 1200872L1 Dual T1 NIM

• 1200868E1/L1 E1/FE1 NIM

• 1200878E1/L1 E1/FE1 + G.703 Drop NIM

• 1200866E1 Serial Interface Module

• 1200936E1 SHDSL NIM, Annex A

• 1200937E1 SHDSL NIM, Annex B

• 1202869E1 ADSL NIM, Annex A

• 1202889E1 ADSL NIM, Annex B

• 1200864L1 Analog Modem DIM

• 1200865L1 ISDN BRI DIM

• 1200875L1 ISDN S/T DIM This section includes a list of features, a list of shipping contents, and a description of the unit’s front and rear

panel designs. For additional information, refer to the following sections:

• Product Specifications on page 34

• Mounting Options on page 54

• Supplying Power to the Unit on page 56 For information on router configuration for a specific application, refer to the quick configuration documents

provided on the AOS Documentation CD shipped with your base unit. For details on the CLI, refer to the AOS Command Reference Guide (also included on your CD).

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

NetVanta 1224R Shipping Contents

Each NetV anta 1224R and NetVanta 1224R PoE unit is shipped in its own cardboard shipping carton. Open each carton carefully , and avoid deep penetration into the carton with sharp objects.

Domestic shipments of the NetVanta 1224R include the following items:

• NetVanta 1224ST base unit

• AOS Documentation CD

• A detachable po wer cable with a grounded, three-prong plug

• Quick Start Guide

• Warranty card International shipments of the NetVanta 1224R include the following items:

• NetVanta 1224ST base unit

• AOS Documentation CD

• All necessary power cords

• Quick Start Guide

• Warranty card

NetVanta 1224R Front Panel Design

The NetVanta 1224R and the NetV anta 1224R PoE front panels are shown below. Table 1 on page 33 describes all of these LEDs, and Appendix A on page 67 shows the con nector pinouts.

NetVanta 1224R Front Panel Features 10/100BaseT Ethernet Interfaces

The NetV anta 1224R and the NetV anta 1224R PoE contain 24 10/100BaseT Ethernet interfaces (RJ-45). These interfaces are consecutively numbered 1 through 24, from left to right, with the numbers screened directly above each port. Status LEDs for each of these interfaces are located directly over these numbers.

The NetVanta 1224R PoE also has green and red PoE status LEDs located in the upper left and upper right corners (respectively) of each of the Ethernet connectors.

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

Status LEDs

The status LEDs are located to the lower left of RJ-45 port 1. The WAN LED reflects the status of an installed NIM. The The

STAT LED indicates the unit’s status.

DBU LED reflects the status of an installed dial backup interface module (DIM).

Figure 7. NetVanta 1224R Front Panel Layout

Figure 8. NetVanta 1224R PoE Front Panel Layout

NetVanta 1224R Rear Panel Design

The NetVanta 1224R and NetV anta 1224R PoE rear panel is shown below. Refer to Appendix A on page 67 for pinouts.

Figure 9. NetVanta 1224R and NetVanta 1224R PoE Rear Panel Layout

NetVanta 1224R Rear Panel Interfaces NIM Option Slot

The NIM option slot accepts a variety of NIM option modules (refer to Option Modules on page 35).

CONSOLE Interface

The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and configuration (via a DB-9 female connector).

Connection directly to an external modem requires a cross-over cable.

Power Connection

The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to the Unit on page 56 for connection details.

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

NetV anta 1224STR

The NetVanta 1224STR (AC and DC versions) and NetV anta 1224STR PoE are managed switches housed in a 1U-high rack-mountable metal enclosure that includes either a universal AC or a DC power supply . The NetVanta 1224STR PoE version provides the ability to detect attached PDs, and deliver 48 VDC to the PDs via existing CAT 5 cabling. Both front panels contain 24 10/100BaseT Ethernet interfaces (RJ-45). The NetVanta

1224STR front panel contains one Gigabit Ethernet interface that provides one fixed RJ-45 connector and one standard SFP slot for fiber connectivity . The NetVanta 1224STR PoE front panel contains two Gigabit Ethernet interfaces and two standard SFP slots. Both units contain a single NIM slot on the rear panel to support the following modules:

• 1200861L1 56K/64K NIM

• 1202862L1 T1/FT1 NIM

• 1200862L2#NEBS T1/FT1 NEBS NIM (NetVanta 1224STR PoE only)

• 1202863L1 T1/FT1 + DSX-1 NIM

• 1200872L1 Dual T1 NIM

• 1200868E1/L1 E1/FE1 NIM

• 1200878E1/L1 E1/FE1 + G.703 Drop NIM

• 1200866E1 Serial Interface Module

• 1200936E1 SHDSL NIM, Annex A

• 1200937E1 SHDSL NIM, Annex B

• 1202869E1 ADSL NIM, Annex A

• 1202889E1 ADSL NIM, Annex B

• 1200864L1 Analog Modem DIM

• 1200865L1 ISDN BRI DIM

• 1200875L1 ISDN S/T DIM This section includes a list of features, a list of shipping contents, and a description of the unit’s front and rear

panel designs. For additional information, refer to the following sections:

• Product Specifications on page 34

• Mounting Options on page 54

• Supplying Power to the Unit on page 56 For information on router configuration for a specific application, refer to the quick configuration documents

provided on the AOS Documentation CD shipped with your base unit. For details on the CLI, refer to the AOS Command Reference Guide (also included on your CD).

NetVanta 1224STR Shipping Contents

Each NetVanta 1224STR and NetV anta 1224STR PoE units are shipped in their own cardboard shipping cartons. Open each carton carefully, and avoid deep penetration into the carton with sharp objects.

Domestic shipments of the NetVanta 1224STR include the following items:

• NetVanta 1224STR base unit

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

• AOS Documentation CD

• A detachable po wer cable with a grounded, three-prong plug

• Quick Start Guide

• Warranty card International shipments of the NetVanta 1224STR include the following items:

• NetVanta 1224STR base unit

• AOS Documentation CD

• All necessary power cords

• Quick Start Guide

• Warranty card

NetVanta 1224STR Front Panel Design

The NetVanta 1224STR and the NetV anta 1224STR PoE front panels are shown below. Table 1 on page 33 describes all of the LEDs, and Appendix A on page 67 shows the connector pinouts.

NetVanta 1224STR Front Panel Features 10/100BaseT Ethernet Interfaces

The NetVanta 1224STRs contain 24 10/100BaseT Ethernet interfaces (RJ-45). These interfaces are consecutively numbered 1 through 24, from left to right, with the numbers screened directly above each port. Status LEDs for each of these interfaces are located directly over these numbers.

The NetVanta 1224STR PoE also has green and red PoE status LEDs located in the upper left and upper right corners (respectively) of each Ethernet connector.

Gigabit Ethernet Interfaces/SFP Slots

The NetVanta 1224STR front panel contains one Gigabit Ethernet interface that provides one fixed RJ-45 connector and one standard SFP slot for fiber connectivity. (Use either the RJ-45 connector or the SFP slot. The fiber slot has precedence.) This interface is labeled to the left of RJ-45 port 1, above the

STAT LED.

G1, and the status LED is located

The NetVanta 1224STR PoE front panel contains two Gigabit Ethernet interfaces and two standard SFP slots. (Use either the RJ-45 connectors or the SFP slots. The fiber slots have precedence.) These interfaces are labeled

G1 and G2, and the status LEDs are located above the SFP slots.

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

-48V....., 1.2A

+24V....., 2.5A

USE COPPER

CONDUCTORS ONLY

WAN-T1

Status LEDs

The status LEDs are located to the lower left of RJ-45 port 1. The WAN LED reflects the status of an installed NIM. The

DBU LED reflects the status of an installed DIM. The STAT LED indicates the

unit’s status.

Figure 10. NetVanta 1224STR (AC) Front Panel Layout

Figure 11. NetVanta 1224STR (DC) Front Panel Layout

Figure 12. NetVanta 1224STR PoE Front Panel Layout

NetVanta 1224STR Rear Panel Design

The NetV anta 1224STR and NetVanta 1224STR PoE rear panels are shown below. Refer to Appendix A on page 67 for pinouts.

Figure 13. NetVanta 1224STR (AC) and NetVanta 1224STR PoE Rear Panel Layout

Figure 14. NetVanta 1224STR (DC) Rear Panel Layout

NetVanta 1224STR Rear Panel Interfaces NIM Option Slot

The NIM option slot accepts a variety of NIM option modules (refer to Option Modules on page 35).

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

CONSOLE Interface

The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and configuration (via a DB-9 female connector).

Connection directly to an external modem requires a cross-over cable.

Power Connection

The rear panel of the NetVanta 1224STR (AC) and NetVanta 1224STR PoE have a power input for connection to an AC universal power supply. The NetVanta 1224STR (DC) connects to a centralized DC power source via a four-position power connector. Please refer to Supplying Power to the Unit on page 56 for connection details.

NetV anta 1335

All NetVanta 1335 Series units are managed switches, plus multiservice routers housed in a 1U-high rack-mountable metal enclosure that includes a universal AC power supply . The NetVanta 1335 PoE and NetVanta 1335 WiFi PoE provide the ability to detect attached PDs, and deliver 48 VDC to the PDs via existing CAT 5 cabling. The NetVanta 1335 WiFi Series units operate as wireless bridges for local area networks (LANs). A dual radio design with two dual-band external antennas is used to support concurrent 802.1 1a and

802.11b/g connections. The NetVanta 1335 Series front panels contain 24 10/100BaseT Ethernet interfaces and two Gigabit Ethernet interfaces accessed via a fixed RJ-45 connector or SFP slots for fiber connectivity. The NetVanta 1335 WiFi Series front panels contain 24 10/100BaseT Ethernet interfaces and one Gigabit Ethernet interface accessed via a fixed RJ-45 connector or SFP slot. All NetVanta 1335 Series units include IPSec VPN support (without further software upgrades) and expandable memory via CompactFlash and SODIMM slots. NetVanta 1335 Series units also contain one NIM slot on the rear panel to support the following modules in data applications:

• 1200861L1 56K/64K NIM

• 1202862L1 T1/FT1 NIM

• 1202863L1 T1/FT1 + DSX-1 NIM

• 1200872L1 Dual T1 NIM

• 1200868E1/L1 E1/FE1 NIM

• 1200878E1/L1 E1/FE1 + G.703 Drop NIM

• 1200866E1 Serial Interface Module

• 1200936E1 SHDSL NIM, Annex A

• 1200937E1 SHDSL NIM, Annex B

• 1202869E1 ADSL NIM, Annex A

• 1202889E1 ADSL NIM, Annex B

• 1700801G1 3G CDMA NIM, 1xRTT, 1xEV-DO Revision 0, 1xEV-DO Revision A

• 1200864L1 Analog Modem DIM

• 1200865L1 ISDN BRI DIM

• 1200875L1 ISDN S/T DIM This section includes a list of features, a list of shipping contents, and a description of the front and rear panel

designs. For additional information, refer to the following sections:

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

• Product Specifications on page 34

• Mounting Options on page 54

• Supplying Power to the Unit on page 56 For information on router configuration for a specific application, refer to the quick configuration documents

provided on the AOS Documentation CD shipped with your base unit. For details on the CLI, refer to the AOS Command Reference Guide (also included on your CD).

NetVanta 1335 Shipping Contents

Each NetVanta 1335 unit is shipped in its own cardboard shipping carton. Open each carton carefully , and avoid deep penetration into the carton with sharp objects.

After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Repair and Replacement section of the Support page on the ADTRAN website at http://www .adtran.com/support).

Domestic shipments of the NetVanta 1335 include the following items:

• NetVanta 1335 base unit

• AOS Documentation CD

• Two dual-band RP-SMA detachable antennas (NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE only)

• A detachable po wer cable with a grounded, three-prong plug

• Quick Start Guide

• Warranty card International shipments of the NetVanta 1335 include the following items:

• NetVanta 1335 base unit

• AOS Documentation CD

• Two dual-band RP-SMA detachable antennas (NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE only)

• All necessary power cords

• Quick Start Guide

• Warranty card

NetVanta 1335 Front Panel Design

The NetVanta 1335 Series front panels are shown on page 29. Table 1 on page 33 describes all of the LEDs, and Appendix A on page 67 shows the connector pinouts.

NetVanta 1335 Front Panel Features 10/100BaseT Ethernet Interfaces

The NetVanta 1335 Series units contain 24 10/100BaseT Ethernet interfaces (RJ-45). These interfaces are consecutively numbered 1 through 24, from left to right, with the numbers screened directly above each port. Status LEDs for each of these interfaces are located directly over these numbers.

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

Gigabit Ethernet Interfaces/SFP Slots

The NetVanta 1335 and NetVanta 1335 PoE contain two Gigabit Ethernet interfaces t hat provide two fixed RJ-45 connectors and two standard SFP slots for fiber connectivity. These interfaces are labeled

G1 and G2, and the status LEDs are located above the SFP slots. The NetVanta 1335 WiFi and

NetVanta 1335 WiFi PoE contain one Gigabit Ethernet interface that provides one fixed RJ-45 connector and one standard SFP slot for fiber connectivity. This interface is labeled

G1, and the status

LED is located above the SFP slot. (Use either the RJ-45 connector or the SFP slot. The fiber slot has precedence.)

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

NetVanta 1335

WAN-T1 DSX-1 DBU

Status LEDs

The status LEDs are located to the lower left of RJ-45 port 1. The WLAN LED (NetVanta 1335 WiFi Series only) reflects the status of the wireless network. The NIM. The

DBU LED reflects the status of an installed DIM. The STAT LED indicates the unit’s status.

Figure 15. NetVanta 1335 Front Panel Layout

Figure 16. NetVanta 1335 PoE Front Panel Layout

WAN LED reflects the status of an installed

Figure 17. NetVanta 1335 WiFi Front Panel Layout

Figure 18. NetVanta 1335 WiFi PoE Front Panel Layout

NetVanta 1335 Rear Panel Design

The NetVanta 1335 Series rear panels are shown below. Refer to Appendix A on page 67 for pinouts.

Figure 19. NetVanta 1335 and NetVanta 1335 PoE Rear Panel Layout

Figure 20. NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE Rear Panel Layout

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

NetVanta 1335 Rear Panel Interfaces NIM Option Slot

The NIM option slot accepts a variety of NIM option modules (refer to Option Modules on page 35).

CompactFlash

The CompactFlash slot supplies nonvolatile configuration and compressed code storage. The NetVanta 1335 supports only ADTRAN-provided CompactFlash (16 MB to 1 GB) (refer to the part number on

the front cover of this manual).

CONSOLE Interface

The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and configuration (via a DB-9 female connector).

Connection directly to an external modem requires a cross-over cable.

Antenna Connectors

The ANT 1 and ANT 2 ports (NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE only) support two dual-band antennas for concurrent 802.11a and 802.11b/g connections.

Power Connection

The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to the Unit on page 56 for connection details.

NetV anta 1524ST

The NetVanta 1524ST is a Layer 2 managed switch housed in a 1U-high rack-mountable metal enclosure that includes a universal AC power supply . The front panel contains 24 10/100/1000BaseT Ethernet interfaces that are accessed via standard RJ-45 connectors. Four of these twenty-four interfaces can be used in either copper or fiber mode. Four industry standard SFP slots (supporting industry standard SFP modules) are available for high-speed uplink or stacking requirements. The switch is managed through an EIA-232 (DB-9).

This section includes a list of features, a list of shipping contents, and a description of the unit’s front and rear panel designs. For additional information, refer to the following sections:

• Product Specifications on page 34

• Mounting Options on page 54

• Supplying Power to the Unit on page 56 For information on switch configuration for a specific application, refer to the quick configuration documents

provided on the AOS Documentation CD shipped with your base unit. For details on the CLI, refer to the AOS Command Reference Guide (also included on your CD).

CONSOLE port

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

NetVanta 1524ST Shipping Contents

Each NetVanta 1524ST unit is shipped in its own cardboard shipping carton. Open each carton carefully, and avoid deep penetration into the carton with sharp objects.

After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damag ed in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Repair and Replacement section of the Support page on the ADTRAN website at http://www .adtran.com/support).

Domestic shipments of the NetVanta 1524ST include the following items:

• NetVanta 1524ST base unit

• AOS Documentation CD

• A detachable po wer cable with a grounded, three-prong plug

• Quick Start Guide

• Warranty card International shipments of the NetVanta 1524ST include the following items:

• NetVanta 1524ST base unit

• AOS Documentation CD

• All necessary power cords

• Quick Start Guide

• Warranty card

NetVanta 1524ST Front Panel Design

The NetVanta 1524ST front panel is shown below. Table 1 on page 33 describes all of the LEDs, and Appendix A on p a g e 6 7 shows the connector pinouts.

NetVanta 1524ST Front Panel Features 10/100/1000BaseT Ethernet Interfaces

The NetVanta 1524ST front panel contains 24 10/100/1000BaseT Ethernet interfaces (RJ-45). These interfaces are consecutively numbered 1 through 24, from left to right, with the numbers screened directly above each port. Status LEDs for each of these interfaces are located directly over these numbers.

SFP Slots

The NetVanta 1524ST front panel contains four standard SFP slots for fiber connectivity. These interfaces are numbered 21 through 24. Status LEDs for each of these slots are located directly over these numbers.

Status LEDs

The status LEDs are located to the lower left of RJ-45 port 1. The STK LED indicates whether the unit is a member of a stack. The

STAT LED indicates the unit’s status.

Figure 21. NetVanta 1524ST Front Panel Layout

Physical Descriptions NetVanta 1000/1000R Series Hardware Installation Guide

NetVanta 1524ST Rear Panel Design

The NetVanta 1524ST rear panel is shown below. Refer to Appendix A on page 67 for pinouts.

Figure 22. NetVanta 1524ST Rear Panel Layout

NetVanta 1524ST Rear Panel Interfaces 10/100BaseT Ethernet Interface

The Ethernet port (ETH 0/0) is an RJ-45 connector. The Ethernet port provides the following:

• 10BaseT or 100BaseT with a single connector

• Auto-negotiation

• CSMA/CD

• IEEE 802.3 compatibility

CONSOLE Interface

The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and configuration (via a DB-9 female connector).

Connection directly to an external modem requires a cross-over cable.

Power Connection

The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to the Unit on page 56 for connection details.

NetVanta 1000/1000R Series Hardware Installation Guide Physical Descriptions

Table 1. Front Panel LED Descriptions

LED Color Indication

STAT

Off Unit is not receiving power. Green (solid) Power is on and self-test passed. Green (flashing) On power-up the STAT LED flashes rapidly for five

seconds, during which time the user may escape to boot mode from the CONSOLE port.

Red (solid) Power is on, but the self-test failed or the boot code could

not be booted.

STK (1524ST only)

Off Unit is not a member of a stack. Green (solid) Unit is a member of a stack.

Port LEDs (i.e., 1 through 24, G1, G2, etc.)

Off Port is administratively disabled or does not have a

connection. Green (solid) Port is enabled and has a connection. Amber (flashing) Port has activity (transmit or receive).

DBU

(1224R, 1224STR, and 1335 only)

Off No DIM is installed. Green (solid) DIM is ready. For the ISDN BRI DIM, green solid indicates

that the negotiation with the switch is complete. Green (flashing) Unit is in dial backup. Amber (solid) Unit is in test. Red (solid) Alarm condition is occurring on the DBU interface, or there

is a self-test failure.

WAN

(1224R, 1224STR, and 1335 only)

Off No NIM is installed, or interface is administratively down. Green (solid) NIM is up and everything is operational. Green (flashing) Port has activity (transmit or receive). Amber (solid) Unit is in test. Red (solid) Alarm condition is occurring on the WAN inter face, or ther e

is a self-test failure.

Power over Ethernet Status LEDs

(PoE units only)

WLAN

(1335 WiFi and 1335 WiFi PoE)

Green (solid) Power is being ap plie d (4 8 V) to the int er fa ce . Red (solid) Fault is detected on the interface.

Off WLAN is inactive or disabled. Green (solid) WLAN card is enabled and active. Amber (flashing) Activity (transmit or receive) is detected on the WLAN.

Product Specifications NetVanta 1000/1000R Series Hardware Installation Guide

3. PRODUCT SPECIFICATIONS

1224

1224ST

1224STR (AC)

1224STR (DC)

Physical Interfaces

10/100BaseT Ethernet interfaces on the front panel 24 24 24 24 24 24 24 24 0 1000BaseT Gigabit Ethernet interfaces on the front panel

(SFP slots for fiber connectivity/RJ-45 connectors for copper connectivity)

Integrated DB-9, EIA-232 console port (DCE) on the rear panel

Modular network interface on the rear panel N/A N/A 1 1 1 1 1 1 N/A

Stacking Spanning Tree Support (802.1D and 802.1w) Link Aggregation (802.3ad) VLAN Support (802.1Q), up to 255 active VLANs Priority QoS (802.1p) Management

Console Telnet CLI SSH CLI SNMP V2 Port mirroring

Power

AC Power: 100 to 250 VAC, 50/60 Hz DC Power: 24 to 48 VDC

Mechanical Specifications

Housing: 1U-high metal enclosure (1.72-inch H x 17.22-inch W x 7.8-inch D) (The 1224STR PoE and 1335 PoE Series are 12.8-inches deep.)

10/100BaseT Ethernet: 24 ganged RJ-45 jacks 10/100/1000BaseT Ethernet: SFP slots/standard RJ-45

jacks Console Port: DB-9, female

Dual-band Antenna Connections 000000020 CompactFlash

Environmental Specifications

AC Input Power: 100 to 250 VAC DC Input Power: 24 to 48 VDC at 2.5 A Storage Temperature: -20°C to 70°C Operating Temperature: 0°C to 50°C Relative Humidity: Up to 95 percent, noncondensing

0211202124

111111111

DDDDDDDDD

DDD DDDDD

DDDDDDDDD

DDDDDDDD

0211102124

DDDDDDDDD

DDD DDDDD

DDDDDDDDD

1224STR PoE

1224R

1335, 1335 PoE

1524ST

1335 WiFi Series

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

4. OPTION MODULES

The NetVanta 1224STR, 1224R, and 1335 support several option modules designed to meet a variety of networking requirements. The option modules include plug-in NIMs and plug-on DIMs.

NIMs are cards that plug directly into the option module slot located on the rear of the base unit. These cards provide the following types of interfaces:

• NetVanta 56K/64K NIM (P/N 1200861L1) on page 36

• NetVanta T1/FT1 NIM (P/N 1202862L1) on page 37

• NetVanta T1/FT1 NEBS NIM (P/N 1200862L2#NEBS) on page 38

• NetVanta T1/FT1 + DSX-1 NIM (P/N 1202863L1) on page 39

• NetVanta Dual T1 NIM (P/N 1200872L1) on page 40

• NetVanta E1/FE1 NIM (P/N 1200868E1/L1) on page 41

• NetVanta E1/FE1 + G.703 Drop NIM (P/N 1200878E1/L1) on page 42

• NetVanta Serial NIM (P/N 1200866E1) on page 43

• NetVanta SHDSL NIM, Annex A (P/N 1200936E1) on page 44

• NetVanta SHDSL NIM, Annex B (P/N 1200937E1) on page 45

• NetVanta ADSL NIM, Annex A (P/N 1202869E1) on page 46

• NetVanta ADSL NIM, Annex B (P/N 1202889E1) on page 47

• NetVanta 3G CDMA NIM (P/N 1700801G1) on page 48 DIMs are plug-on cards that plug directly on to the NIM prior to installation into the base unit. A DIM must be

plugged on to a NIM in order for the interfaces on the NIM to be active. The NetVanta supports the following DIMs:

• NetVanta Analog Modem DIM (P/N 1200864L1) on page 50

• NetVanta ISDN BRI DIM (P/N 1200865L1) on page 51

• NetVanta ISDN S/T DIM (P/N 1200875L1) on page 52 This section describes each module, providing individual card specifications and features. Refer to Connector

Pin Definitions on page 67 for pinout information. Installing Dial Backup and Network Interface Modules on page 57 provides information on card installation.

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

Features and Specifications

Operating Modes

• Dedicated DDS (leased line)

DDS Interface

• Supported Standards: AT&T TR 62310

• 4-wire, full-duplex

• Receiver Sensitivity: -45 dB, all rates

• Data Rates: 56K, 64K, and auto

• Connector: RJ-48S

Clock Source

•Network

•Internal

Diagnostics

• CSU and DSU Loopbacks

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ACTA/FCC Part 68

• IC CS-03

• UL/CUL 60950

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4. 25-inch D

Network Interface Modules

NetVanta 56K/64K NIM (P/N 1200861L1)

The 56K/64K NIM (shown in Figure 23) provides a DDS WAN interface for the NetVanta. This module provides a single 56K or 64K DDS network interface. See Table A-5 on page 69 for the WAN-DDS connector pinouts, and page 73 for the DBU connector pinouts. An optional DIM is required for dial backup applications.

Figure 23. NetVanta 56K/64K NIM

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

Features and Specifications

Operating Modes

• Frame Relay, Multilink Frame Relay

• PPP, Multilink PPP

• HDLC

T1/FT1 Interface

• Supported Standards: AT&T TR 62411, AT&T TR 65016, ANSI T1.403, Bellcore TR 194

• Line Rate: 1.544 Mbps +

75 bps

• Line Code: AMI or B8ZS

• Framing: D4 (SF) or ESF

• FT1 Line Rate: DS0 channelized (multiples of 64 kbps)

• Input Signal: 0 to -36 dB (DS1)

• Line Build-Out: 0, -7.5, -15, -22.5 dB (long), 0 to 655 ft (short)

• DS0 Assignment: Programmable

• Connector: RJ-48C

Clock Source

•Network

•Internal

Diagnostics

• Test Pattern Generation and Detection: 511, QRSS, all ones, all zeros

• Network loopbacks (local and remote); responds to both inband and FDL loop codes

• Alarm generation and detection

• Network and user sets of performance data (15 minutes and 24 hours)

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ACTA/FCC Part 68

• IC CS-03

• UL/CUL 60950

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4. 25-inch D

NetVanta T1/FT1 NIM (P/N 1202862L1)

The T1/FT1 NIM (shown in Figure 24) provides a T1 WAN interface for the NetVanta. This module provides a full T1 or fractional T1 network interface. See Table A-6 on page 69 for the W AN-T1 connector pinouts, an d page 73 for the DBU connector pinouts. An optional DIM is required for dial backup applications.

WAN-T1 DBU

Figure 24. NetVanta T1/FT1 NIM

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

Features and Specifications

Operating Modes

• Frame Relay, Multilink Frame Relay

• PPP, Multilink PPP

• HDLC

T1/FT1 Interface

• Supported Standards: AT&T TR 62411, AT&T TR 65016, ANSI T1.403, Bellcore TR 194

• Line Rate: 1.544 Mbps +

75 bps

• Line Code: AMI or B8ZS

• Framing: D4 (SF) or ESF

• FT1 Line Rate: DS0 channelized (multiples of 64 kbps)

• Input Signal: 0 to -36 dB (DS1)

• Line Build-Out: 0, -7.5, -15, -22.5 dB (long), 0 to 655 ft (short)

• DS0 Assignment: Programm able

• Connector: RJ-48C

Clock Source

•Network

•Internal

Diagnostics

• Test Pattern Generation and Detection: QRSS, 511, 2

- 1, 2

- 1, all ones,

all zeros

• Network loopbacks (local and remote); responds to inband and FDL loop codes

• Alarm generation and detection

• Network and user sets of performance data (15 minutes and 24 hours)

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• NEBS Level 3

•GR-63-CORE

• GR-1089-CORE

• UL/CUL 60950

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature : -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta T1/FT1 NEBS NIM (P/N 1200862L2#NEBS)

The T1/FT1 NEBS NIM (see Figure 25) T1 W AN interface for the NetVanta 1224STR DC. The T1 NEBS NIM is NEBS Level 3 compliant, and provides a full T1 or fractional T1 network interface. See Table A-6 on page 69 for the WAN-T1 connector pinouts.

Although the T1/FT1 NEBS NIM is compliant with NEBS Level 3, the NetVanta 1224STR DC unit supports only NEBS Level 1.

WAN-T1

Figure 25. NetVanta T1/FT1 NEBS NIM

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

Features and Specifications

Operating Modes

• Frame Relay, Multilink Frame Relay

• PPP, Multilink PPP

• HDLC

T1/FT1 Interface

• Supported Standards: AT&T TR 62411, AT&T TR 65016, ANSI T1.403, Bellcore TR 194

• Line Rate: 1.544 Mbps +

75 bps

• Line Code: AMI or B8ZS

• Framing: D4 (SF) or ESF

• FT1 Line Rate: DS0 channelized (multiples of 56/64 kbps)

• Input Signal: 0 to -36 dB (DS1)

• Line Build-Out: 0, -7.5, -15, -22.5 dB (long), 0 to 655 ft (short)

• DS0 Assignment: Programmable

• Connector: RJ-48C

DSX-1 Interface

• Line Interface: DSX-1 per ANSI T1.102

• DSX Receiver Input Range: -10 dB dsx to +6 dBdsx

• Line Rate: 1.544 Mbps

• Capacity: 1 to 24 DS0s

• Line Codes: AMI, B8ZS

• DSX-1 Interface to PBX

• Framing: D4 (SF) or ESF

• Line Length: 0 to 655 feet and -7.5 dB

• Connector: RJ-48C

Clock Source

•Network

•Internal

• Through

Diagnostics

• Test Pattern Generation and Detection: 511, QRSS, all ones, all zeros

• Network loopbacks (local and remote); responds to inband and FDL loop codes (T1 interface only)

• Alarm generation and detection

• Network and user sets of performance data (15 minutes and 24 hours)

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ACTA/FCC Part 68

• IC CS-03

• UL/CUL 60950

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4. 25-inch D

NetVanta T1/FT1 + DSX-1 NIM (P/N 1202863L1)

The T1/FT1 + DSX-1 NIM (see Figure 26) provides a T1 WAN interface for the NetVanta, a full or fractional T1 network interface, and a DSX-1 interface. See the pinouts in Table A-6 on page 69 for the WAN-T1 connector, Table A-8 on page 70 for the DSX-1 connector, and page 73 for the DBU connector pinouts. An optional DIM is required for dial backup applications.

WAN-T1 DSX-1 DBU

Figure 26. NetVanta T1/FT1 + DSX-1 NIM

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

Features and Specifications

Operating Modes

• Frame Relay, Multilink Frame Relay

• PPP, Multilink PPP

• HDLC

T1 Interface

• Supported Standards: AT&T TR 62411, AT&T TR 65016, ANSI T1.403, Bellcore TR 194

• Line Rate: 1.544 Mbps +

75 bps

• Line Code: AMI or B8ZS

• Framing: D4 (SF) or ESF

• FT1 Line Rate: DS0 channelized (multiples of 64 kbps)

• Input Signal: 0 to -36 dB (DS1)

• Line Build-Out: 0, -7.5, -15, -22.5 dB (long), 0 to 655 ft (short)

• DS0 Assignment: Programm able

• Connector: RJ-48C

Clock Source

•Network

•Internal

• Through

Diagnostics

• Test Pattern Generation and Detection: QRSS, 511, 2

- 1, 2

- 1, all ones,

all zeros

• Network loopbacks (local and remote); responds to both inband and FDL loop codes

• Alarm generation detection

• Network performance data (15 minutes and 24 hours)

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ACTA/FCC Part 68

• IC CS-03

• UL/CUL 60950

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20 °C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta Dual T1 NIM (P/N 1200872L1)

The NetVanta Dual T1 NIM (see Figure 27) provides two T1 W AN interfaces for the NetVanta. See Table A-6 on page 69 for the pinouts. See page 73 for the DBU connector pinouts. An optional DIM is required for dial backup applications.

WAN T1/1 DBUWAN T1/2

Figure 27. NetVanta Dual T1 NIM

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

Features and Specifications

Operating Modes

• Frame Relay, Multilink Frame Relay

• PPP, Multilink PPP

• HDLC

WAN-E1 Interface

• Supported Standards : ITU G.703 , ITU-T G.704 (CRC-4), ITU-T G.823, ITU-T G.797

• Line Rate: 2.048 Mbps +

50 PPM

• Line Code: AMI or HDB3

• Framing: FAS with optional CRC-4

• FE1 Line Rate: Channelized timeslot (in multiples of 64 kbps)

• Receiver Sensitivity: -30 dB

• Connector: RJ-48C

Clock Source

•Network

•Internal

Diagnostics

• Test Pattern Generation and Detection: QRSS, 511, all ones, all zeros

• Network loopbacks

• Network performance data (15 minutes and 24 hours)

• Alarm generation and detection

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

•AS/ACIF S016

• ETSI TBR 12/TBR 13

• EN 60950

• IEC 60950

• AS/NZS 60950

• RoHS Compliant (Telecommu nications exemption)

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta E1/FE1 NIM (P/N 1200868E1/L1)

The NetVanta E1/FE1 module (see Figure 28) provides a W AN-E1 interface for the NetVanta meeting the requirements of ITU-T G.703/G .704. The module provides a single 2.048 Mbps network interface. See Table A-7 on page 69 for the pinouts. See page 73 for the DBU connector pinouts. An optional DIM is required for dial backup applications.

WAN-E1 DBU

Figure 28. NetVanta E1/FE1 NIM

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

Features and Specifications

Operating Modes

• Frame Relay, Multilink Frame Relay

• PPP, Multilink PPP

• HDLC

WAN-E1 Interface

• Supported Standards: ITU G.703 , ITU-T G.704 (CRC-4), ITU-T G.823, ITU-T G.797

• Line Rate: 2. 048 Mbps +

50 PPM

• Line Code: AMI or HDB3

• Framing: FAS with optional CRC-4

• FE1 Line Rate: Channelized timeslot (in multiples of 64 kbps)

• Receiver Sensitivity: -30 dB

• Connector: RJ-48C

G.703 Interface

• Receiver Sensitivity: -30 dB

• Line Rate: 2. 048 Mbps +

50 PPM

• Line Code: AMI or HDB3

• Framing: FAS with optional CRC-4

• Capacity: 1 to 31 timeslots

• Connector: RJ-48C

Clock Source

•Network

•Internal

• Through

Diagnostics

• Test Pattern Generation and Detection: QRSS, 511, all ones, all zeros

• Network loopbacks

• Network performance data (15 minutes and 24 hours)

• Alarm generation and detection

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• AS/ACIF S016

• ETSI TBR 12/TBR 13

• EN 60950

• IEC 60950

• AS/NZS 60950

• RoHS Compliant (Telecommunications exemption)

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature : -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta E1/FE1 + G.703 Drop NIM (P/N 1200878E1/L1)

The NetVanta E1/FE1 + G .703 Drop NIM (see Figure 29) provides a single WAN-E1 interface (2.043 Mbps) with user-selectable TS0 assignment, and a G.703 drop port that may be used to drop and insert traffic to an E1 PBX. See Table A-7 on page 69 for the WAN-E1 pinouts. See Table A-9 on page 70 for the G.703 pinouts. See page 73 for the DBU connector pinouts. An optional DIM is required for dial backup applications.

WAN-E1 G.703 DBU

Figure 29. NetVanta E1/FE1 + G.703 Drop NIM

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

Features and Specifications

Operating Mode

• DTE only

Serial Interface

• Supported Standards: ISO 4903 (X.21), CCITT V.35 Synchronous (V.35), EIA 530 Synchronous

• Provides V.35, X.21 (V.11), or EIA 530 electrical interface

• Connector: 26-pin smart serial (DTE)

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ETSI TBR1

• ETSI TBR2

• EN 60950

• IEC 60950

• UL/CUL 60950

• AS/NZS 60950

• RoHS Compliant (Telecommunications exemption)

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature : -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta Serial NIM (P/N 1200866E1)

The NetV anta Serial NIM (shown in Figure 30) can be configured by the user as a V.35, X.21 (V.11), or EIA 530 interface. This module supports rates up to a maximum of 10 Mbps. An additional V.35 (ADTRAN P/N 1200873L1), X.21 (ADTRAN P/N 1200874L1), or EIA 530 (ADTRAN P/N 1200883L1) cable is required (refer to Caution, below). See Table A-12 on page 71 for the serial connector pinouts, and page 73 for the DBU connector pinouts. An optional DIM is required for dial backup applications.

Cable length for the Serial NIM should not exceed 25 feet.

SERIAL DBU

Figure 30. NetVanta Serial NIM

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

Features and Specifications

Operating Mode

• Line termination (CO)

• Network termination (CPE)

SHDSL Interface

• Supported Standards: ITU-T G.991.2 SHDSL, Annex A M-pair bonding of 2 pairs - ITU.T G.991.2

• Line Rate (2-wire mode): 192 to 2304 kbps in 64k increments

• Line Rate (4-wire mode): 384 to 4608 kbps in 128k increments

• Payload: ATM (AAL5)

• Line Code: TC-PAM

• Connector: RJ-45

Clock Source

• CPE Operating Mode: Network

• CO Operating Mode: Internal

Diagnostics

• Network loopbacks (local and remote)

• Alarm generation and detection

• Programmable alarm threshold setting for loop attenuation and signal-to-noise ratio

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ACTA/FCC Part 68

• UL/CUL 60950

• RoHS compliant (Telecommunications exemption)

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta SHDSL NIM, Annex A (P/N 1200936E1)

The NetVanta SHDSL NIM, Annex A (shown in Figure 31) provides a W AN SHDSL interface for the NetVanta. See Table A-10 on page 70 for the SHDSL connector pinouts.

WAN-SHDSL

ANNEX A

Figure 31. NetVanta SHDSL NIM, Annex A

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

Features and Specifications

Operating Mode

• Line termination (CO)

• Network termination (CPE)

SHDSL Interface

• Supported Standards: ITU-T G.991.2 SHDSL, Annex B M-pair bonding of 2 pairs - ITU.T G.991.2

• Line Rate (2-wire mode): 192 to 2304 kbps in 64k increments

• Line Rate (4-wire mode): 384 to 4608 kbps in 128k increments

• Payload: ATM (AAL5)

• Line Code: TC-PAM

• Connector: RJ-45

Clock Source

• CPE Operating Mode: Network

• CO Operating Mode: Internal

Diagnostics

• Network loopbacks (local and remote)

• Alarm generation and detection

• Programmable alarm threshold setting for loop attenuation and signal-to-noise ratio

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

•AS/ACIF S043

• EN 60950

• AS/NZS 60950

• RoHS compliant (Telecommunications exemption)

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta SHDSL NIM, Annex B (P/N 1200937E1)

The NetVanta SHDSL NIM, Annex B (shown in Figure 32) provides a WAN SHDSL interface for the NetVanta. See Table A-10 on page 70 for the SHDSL connector pinouts.

WAN-SHDSL

ANNEX B

Figure 32. NetVanta SHDSL NIM, Annex B

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

Features and Specifications

ADSL Interface

• ADSL over POTS, Annex A

• Supported Standards: – ITU G.992.1 (G.dmt)

– ITU G.992.2 (G.lite) – ITU G.992.3 ADSL2 (G.dmt.bis) – ITU G.992.5 ADSL2+ – ANSI T1.413 Issue 2 – Reach Extended ADSL (READSL2)

• Connector: RJ-11C (6-pin jack, inner pair)

ATM

• Multiple Protocol over AAL5 (RFC2684)

• PPP over ATM (RFC2364)

• PPP over Ethernet (RFC2516)

• ATM Forum UNI 3.1/4.0 PVC

• ATM Class of Service (UBR)

• ATM F5 OAM

• Up to 16 Virtual Circuits

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ACTA/FCC Part 68

• AS/ACIF S043

• AS/ACIF S002

• IC CS-03

• EN 60950

• IEC 60950

• UL/CUL 60950

• AS/NZS 60950

• RoHS Compliant (Telecommunications exemption)

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature : -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta ADSL NIM, Annex A (P/N 1202869E1)

The NetVanta ADSL NIM, Annex A (see Figure 33) adds ADSL capability to the NetVanta. The module provides a single ADSL, ADSL2, or ADSL2+ network interface to support rates up to 25 Mbps. See T able A-11 on page 71 for the pinouts. The ADSL NIM supports an optional DIM for dial backup applications. See page 73 for the DBU connector pinouts.

WAN-ADSL DBU

Figure 33. NetVanta ADSL NIM, Annex A

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

Features and Specifications

ADSL Interface

• ADSL over ISDN, Annex B

• Supported Standards: ITU G.992 .1 (G.dmt)

• Connector: RJ-11C (6-pin jack, inner pair)

ATM

• Multiple Protocol over AAL5 (RFC2684)

• PPP over ATM (RFC2364)

• PPP over Ethernet (RFC2516)

• ATM Forum UNI 3.1/4.0 PVC

• ATM Class of Service (UBR)

• ATM F5 OAM

• Up to 16 Virtual Circuits

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• AS/ACIF S043

• EN 60950

• IEC 60950

• AS/NZS 60950

• RoHS Compliant (Telecommunications exemption)

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature : -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

NetVanta ADSL NIM, Annex B (P/N 1202889E1)

The NetVanta ADSL NIM, Annex B (see Figure 34) adds ADSL capability to the NetVanta. See Table A-1 1 on page 71 for the pinouts. The ADSL NIM supports an optional DIM for dial backup applications.See page 73 for the DBU connector pinouts.

WAN-ADSL DBU

Figure 34. NetVanta ADSL NIM, Annex B

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

Features and Specifications

Wireless Technologies

• 1xRTT

• 1xEV-DO Rev 0

• 1xEV-DO Rev A

Frequency Bands

• Band Class 0 (Cellular 800 MHz)

• Band Class 1 (PCS 1.9 GHz)

Compliance

• FCC Part 15, Class A

• FCC Parts 2, 22, 24

• UL/CUL 60950-1

•RSS 102

• RSS 129/133

• RSS 132/133

• IC ES-003

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.75-inch W x 4.25-inch D

• Standard SMA antenna connectors

NetVanta 3G CDMA NIM (P/N 1700801G1)

The NetVanta 3G CDMA NIM (shown in Figure 35) provides a cellular interface for the NetVanta 1335 and NetVanta 1335 PoE. Refer to Installing the 3G CDMA NIM Antennas on page 62 for information about the specifications and installation of the 3G CDMA NIM antennas. For specific connection and configuration instructions, refer to the 3G CDMA NIM Quick Start Guide or the 3G NIM Configuration Guide available on the AOS Documentation CD shipped with the base unit or on the Web at www.adtran.com.

ANT1

WWAN

1xRTT

RSSI

EVDO

ANT2

3G NIM (CDMA)

Figure 35. NetVanta 3G CDMA NIM

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

Table 2. 3G CDMA NIM LED Descriptions

LED Label LED Color Indication

Off 3G modem is not powered. Green (solid) 3G modem is powered, associated, and authenticated, but not

transmitting or receiving.

WWAN

Green (slow flash) 3G modem is powered and searching, but not associated or

authenticated.

RSSI (Received Signal Strength Indication)

1xRTT

EVDO

Green (intermittent flash)

3G modem activity proportional to transmitting/receiving speed

(3 Hz minimum rate, 20 Hz maximum rate). Off No service or no signal detected. Red (solid) Low signal strength. Amber (solid) Medium signal strength. Green (solid) High signal strength. Off No 1xRTT service is available. Green (solid) 1xRTT service is available. Off No 1xEV-DO service is available. Green (solid) 1xEV-DO service is available.

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

Dial Backup Interface Modules

NetVanta Analog Modem DIM (P/N 1200864L1)

The Analog Modem DIM provides a modem with data rates up to 33.6 kbps for the NetVanta. This DIM is a plug-on card that connects to the NIM. For installation instructions, refer to Installing Dial Backup and Network Interface Modules on page 57.

Features and Specifications

Features

• Supported Standards: ITU V.90

•Async

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ACTA/FCC Part 68

• IC CS-03

• UL/CUL 60950

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.5-inch W x 3.75-inch D

The Analog Modem DIM can be used in two different modes:

1. Backup interface for a primary connection.

2. CONSOLE port for remote dial-in access.

NetVanta 1000/1000R Series Hardware Installation Guide Option Modules

NetVanta ISDN BRI DIM (P/N 1200865L1)

The NetVanta ISDN BRI DIM provides dial backup access to the public switched telephone network (PSTN) via Basic Rate ISDN for the NetVanta. This DIM is a plug-on module that connects to the NIM. For installation instructions, refer to Installing Dial Backup and Network Interface Modules on page 57.

Features and Specifications

Features

• Clear channel and bonding mode 1 call protocols

• Network support for 64 kbps (1 B-channel) or 128 kbps (2 B-channels)

• D-channel switch compatibility with AT&T 5ESS, Northern Telecom DMS-100, and National ISDN-1

• V.54 network loopback support

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• ACTA/FCC Part 68

• IC CS-03

• UL/CUL 60950

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.5-inch W x 3.75-inch D

Option Modules NetVanta 1000/1000R Series Hardware Installation Guide

NetVanta ISDN S/T DIM (P/N 1200875L1)

The NetVanta ISDN S/T DIM provides dial backup access to the PSTN via Basic Rate ISDN for the NetV anta. This DIM is a plug-on module that connects to the NIM. For installation instructions, refer to Installing Dial Backup and Network Interface Modules on page 57.

Features and Specifications

Features

• Clear channel and bonding mode 1 call protocols

• Network support for 64 kbps (1 B-channel) or 128 kbps (2 B-channels)

• D-channel switch compatibility with AT&T 5ESS, Northern Telecom DMS-100, National ISDN-1, and Euro-ISDN

• V.54 network loopback support

Compliance

• EMC - see Electromagnetic Compatibility (EMC) Table on page 6.

• AS/ACIF S031

• ETSI TBR 3

• EN 60950

• IEC 60950

• AS/NZS 60950

Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 70°C

• Relative Humidity: Up to 95 percent, noncondensing

Physical

• Dimensions: 2.5-inch W x 3.75-inch D

NetVanta 1000/1000R Series Hardware Installation Guide Unit Installation

5. UNIT INSTALLATION

The instructions and guidelines provided in this section cover hardware installation topics, such as mounting options, supplying power to the unit, and installing option cards. These instructions are presented as follows:

• Mounting Options on page 54

• Supplying Power to the Unit on page 56

• Installing Dial Backup and Network Interface Modules on page 57

• Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1) on page 60 For information on configuring a specific application, refer to the quick configuration documents provided on

the AOS Documentation CD, or the AOS Command Reference Guid e (also included on your CD).

To prevent electrical shock, do not install equipment in a wet location or during a lightning storm.

Electronic modu les can be damaged by static electrical discharge. Before handling modules, put on an antistatic discharge wrist strap to prevent damage to electrical components. Place modules in antistatic packing material when transp orting or storing. When working on modules, always place them on an approved antistatic mat that is electrically grounded.

Tools Required

The customer-provided tools required for the hardware installation of the NetVanta are:

• Ethernet cables

• Network cables (module dependent)

• DSX-1 cable (T1/FT1 + DSX-1 module only)

• DBU cable (dial backup functions require an optional DIM)

• Phillips-head screwdriver (rack-mounted applications only)

To access the CLI of the NetVanta, you will also need a VT100 terminal or PC with terminal emulation software and a console port cable. Instructions on how to access the CLI are given in the AOS Command Reference Guide (provided on the AOS Documentation CD).

Unit Installation NetVanta 1000/1000R Series Hardware Installation Guide

Mounting Options

The unit may be installed in rackmount, wallmount, or tabletop configurations. The following sections provide step-by-step instructions for rack mounting and wall mounting.

If you have purchased the VPN Accelerator Card for your NetVanta 1224STR, install it first (refer to Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1) on page 60).

Rack Mounting the NetVanta

The NetVanta is a 1U-high, rack-mountable unit that can be installed into a 19-inch equipment rack. The following steps guide you in mounting the NetVanta into a rack.

Instructions for Rack Mounting the NetVanta

Step Action

1 To allow proper grounding, scrape the paint from the rack around the mounting holes where the

NetVanta will be positioned. 2 Position th e Net Vanta in a stationary equipment rack. This unit occupies 1U of space. 3 Have an assistant hold the unit in position as you install two mounting bolts through the unit’s

brackets and into the equipment rack using a #2 phillips-head screwdriver. 4 Apply powe r to the unit (r efe r to Supplying Power to the Unit on page 56).

Be careful not to compromise the stability of the equipment mounting rack when installing this product.

NetVanta 1000/1000R Series Hardware Installation Guide Unit Installation

Wall Mounting the NetVanta

By following these instructions exactly , the NetVanta can be safely mounted to the wall.

Instructions for Wall Mounting the NetVanta

Step Action

1 Remove the mounting ears. Rotate them 90 de gr ees so that the portion of the bracket with the

mounting holes is flush with the bottom of the chassis. Reattach the mounting ears to the chassis (see Figure 36).

2 Decide on a location for the NetVanta. All NetVanta 1000 and 1000R Series units are mounted

with the front panel facing down (see Figure 36). Keep in mind that the unit needs to be mounted at or below eye-level so that the LEDs are viewable.

3 Prepare the mounting surface by attaching a board (typically plywood, 3/4-inch to 1-inch thick)

to a wall stud.

Important! Mounting to a stud ensures stability. Using sheetrock anchors may not provide sufficient long-term stability.

4 Have an assistant hold the unit in position as you install two #6 to #10 (1 1/2 inches or greater

in length) wood screws through the unit’s brackets and into the mounted board (see Figure 36) .

5 Proceed to the steps given in Supplying Power to the Unit on page 56.

To avoid damaging the unit, use only the screws included in the shipment when attaching mounting ears to the chassis.

50-60Hz

100-250 VAC

CONSOLE

SLOT 1 NIM/VIM

Figure 36. Wallmount Installation

Unit Installation NetVanta 1000/1000R Series Hardware Installation Guide

Supplying Power to the Unit

NetVanta 1000 and 1000R Series AC-Powered Units

The AC-powered NetVanta 1000 and 1000R Series units come equipped with an auto-sensing 100 to 250 VAC, 50/60 Hz power supply for connecting to a properly grounded power receptacle. (A detachable power cable with a grounded, three-prong plug comes with the shipment.) T o power these units, connect the power cable to an appropriate AC power source.

NetVanta 1224STR (DC)

The DC-powered NetVanta 1224STR connects to a centralized DC power source via the four-position power connector on the rear of the chassis (see Figure 37 on page 57). Power and ground connections require copp er conductors and a ring lug.

Instructions for Connecting DC Power Source to the NetVanta 1224STR

Step Action

1 With the power disconnected, connect the primary power source to input A of the power

connector.

2 Connect a ground wire (fitted with a loop terminal end) to the grounding point using the screw

provided. Connect the other end of the ground wire to a protective ea rth ground. See Figure 37 on page 57.

3 If using a backup power source, connect it to input B of the power connector.

• Power to the NetVanta 1224STR DC System must be from a reliably grounded 24 or 48 VDC.

• Use only copper conductors when making power connections.

• Install unit in accordance with the requirements of NEC NFPA 70.

• The branch circuit overcurrent protection shall be a fuse or circuit breaker rated minimum 48 VDC, maximum 10 A.

• A readily accessible disconnect device, that is suitably approved and rated, shall be incorporated in the field wiring.

• Maximum recommended ambient operating temperature is 50

°C.

The 10/100BaseT and Gigabit Ethernet interfaces MUST NOT be metallically connected to interfaces that connect to the Outside Plant or its wiring. These interfaces are designed for use as intra-building interfaces only. The addition of primary protectors is not sufficient protection in order to connect this interface metallically to OSP wiring.

NetVanta 1000/1000R Series Hardware Installation Guide Unit Installation

To comply with GR-1089-CORE, Issue 3, this equipment MUST only be installed in a DC-C (common) bonding and grounding environment. It may not be utilized in a DC-I (isolated) bonding and grounding environment.

Figure 37. Grounding the NetVanta 1224STR (DC)

Installing Dial Backup and Network Interface Modules

The DIM plugs on to the NIM. The NIM is then installed into the rear panel option module slot. The following tables list the installation steps. Also, see Figure 38 on page 58 and Figure 39 on page 59.

For NetVanta modules with outside plant connections, ensure that all cables are removed from the module before installing or removing it from the NetVanta chassis.

Always remove power from the unit prior to removing or installing a module.

Improper installation may result in damage to the modules.

Unit Installation NetVanta 1000/1000R Series Hardware Installation Guide

Instructions for Installing the DIMs

Step Action

1 Remove power from the unit. 2 If the NIM is already in the NetVanta chassis, remove all cables, release the pins at both edges

of the NIM front panel and slide the module out of the chassis.

3 Carefully align the P1 connector on the NIM with the J1 connector on the DIM. Using only fingertip

pressure so that neither circuit board bends or flexes, ensure that the connectors are firmly seated. Secure the DIM to the NIM using the screws and standoff posts supplied. See Figure 38.

4 Slide the NIM with the DIM attached into the NetVanta chassis, continuing with the normal NIM

installation (refer to Instructions for Installing the NIMs on page59).

Figure 38. Installing DIMs

NetVanta 1000/1000R Series Hardware Installation Guide Unit Installation

Instructions for Installing the NIMs

Step Action

1 Remove power from the unit. 2 Slide the option module into the option slot until the module is firmly seated aga inst the chassis. 3 Secure the pins at both edges of the module. 4 Connect the cables to the associated device(s). 5 Restore power to the unit.

WAN-T1 DSX-1

DBU

Figure 39. NIM and DIM Installation

Unit Installation NetVanta 1000/1000R Series Hardware Installation Guide

Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1)

The optional VPN Accelerato r card plugs into a 32-bit PCI slot an d is designed to be used in the NetVanta 1224STR to provide encryption/decryption and security acceleration services. The card provides the following security services to the host processor: DES, triple-DES (3DES), AES, SHA-1, MD5, and random number generation. Performance metrics include 528 Mbps (DES), 176 Mbps (3DES), and 422 Mbps (AES). The power consumption of the card does not exceed 2 watts.

The AOS Enhanced Feature Pack software is required to take advantage of the VPN acceleration features of this card.

The NetVanta VPN accelerator card is intended to be serviced/installed by qualified service personnel only.

Instructions for Installing the NetVanta VPN Accelerator Card

Step Action

1 Remove power from the unit. 2 Remove the nine screws and, if necessary, two mountin g brackets (see Figure 40). 3 Using a 3/16-inch hex driver, remove the two jack screws located on either side of the DB-9 port. 4 Carefully lift and remove the unit’s cover to expose the circuit board. 5 Gently slide the accelerator card into the PCI slot as shown. The card is keyed to fit into the slot

only one way. To avoid damaging the card pins, do not use excessive force. 6 Replace the unit cover, screws, and mounting brackets. 7 Restore power to the unit.

Figure 40. NetVanta VPN Accelerator Card Installation

NetVanta 1000/1000R Series Hardware Installation Guide Unit Installation

Installing a CompactFlash Card (NetVanta 1335 Series only)

The CompactFlash slot on the NetVanta 1335 Series supports CompactFlash cards (16 MB to 1 GB). ADTRAN supports only ADTRAN-provided Com pactFlash (16 MB to 1 GB) (refer to the list of part numbers on the front cover). Follow these instructions when installing a card.

The CompactFlash card is hot-swappable and can be inserted or removed while power is applied to the unit.

Instructions for Installing a CompactFlash Card

Step Action

1 Slide the module into the CompactFlash slot until the card is firmly seated against the chassis. 2 The CompactFlash options will now be available in the GUI and the AOS CLI.

CompactFlash

512 MB

Figure 41. CompactFlash Card Installation

Unit Installation NetVanta 1000/1000R Series Hardware Installation Guide

SMA Antenna Connectors

Installing Wireless Access Antennas (NetVanta 1335 WiFi and NetVanta 1335 WiFi PoE only)

The NetVanta 1335 WiFi Series units are shipped with two dual-band RP-SMA detachable antennas. These must be installed before operating the unit.

Instructions for Inst alling Antennas

Step Action

1 Place either of the two antennas directly onto the antenna port labeled ANT 1 on the rear panel.

See Figure 20 on page 29 for port locations.

2 Twist the antenna onto the threads until it is secure. 3 Repeat Step 2 with the second antenna, attaching it to the ANT 2 port.

Installing the 3G CDMA NIM Antennas

The optional 3G CDMA NIM is installed into the rear panel of the base unit following the instructions on page 57. The 3G NIM ships with two detachable dual-band dipole antennas (one primary antenna and one diversity antenna). These must be installed before attempting to connect to a cellular network. Figure 42 shows the antenna connectors on the 3G NIM rear panel.

ANT1

WWAN

1xRTT

RSSI

EVDO

ANT2

3G NIM (CDMA)

Figure 42. 3G CDMA NIM Rear Panel

Notification for Devices with Detachable Antennas

The 3G CDMA NIM has been designed to operate in the 800/1900 frequency CDMA bands with the dual-band dipole antennas shipped with the card. Antennas that do not match the following antenna specifications are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. T able 3 describes the specifications of the primary antenna (transmit and receive). T able 4 describes the specifications of the diversity antenna (receive only). T able 5 desc ribes the ante nna-to-antenna requirements.

To reduce potential radio interference to other users, the antenna type and its gain should be chosen so that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication.

NetVanta 1000/1000R Series Hardware Installation Guide Unit Installation

Table 3. Primary Antenna Specifications

Description Minimum Maximum Unit

Peak Antenna Gain 1.0 dBi Average Gain -3.0 dBi Efficiency -4.0 (40) dB (%) Polarization

(Ratio Gv: Gh) Input VSWR 2.5:1 Average Power Handling 2.0 watts

Table 4. Diversity Antenna Specifications

Description Minimum Maximum Unit

Average Gain -9.0 dBi Efficiency -10.0 (10) dB (%) Polarization (Ratio Gv: Gh) 0.0 dB Input VSWR 2.5:1

Table 5. Antenna-to-Antenna Requirements

Description Minimum Maximum Unit

Isolation -8.0 dB Fading Correlation Coefficient 0.5 dB (%)

0.0 dB

This device has been designed to operate with the antennas listed below, and having a maximum gain of 2 dB. Antennas not included in this list or having a gain greater than 2 dB are strictly prohibited for use with this device. The required antenna impedance is 50 ohms.

Proper antennas are: Pulse/Larson Dipole Antenna Part Number: SPDA24850/1900

Unit Installation NetVanta 1000/1000R Series Hardware Installation Guide

Antenna Extensions

Coaxial cable can be connected to the standard SMA antenna connectors to extend the placement distance of the antennas from the 3G NIM base unit. Using cables introduces signal loss in the antenna system, but can be minimized by minimizing the length of cable used and using low-loss or ultralow-loss antenna cables. Cables that do not match the antenna specifications are strictly prohibited for use with this device.

Using improper cables may hinder the ability of the 3G NIM to communicate with a cellular network. Refer to the documentation accompanying your cables to ensure you have the right cables for this usage and that the cables meet the requirements specified above.

Additional Warnings

The following are guidelines and warnings for wireless access devices.

1. Do not operate RF devices in an environment that may be susceptible to radio interference resulting in danger, specifically:

Areas where prohibited by law. Areas where explosive atmospheres may be present. Areas where medical or life support equipment may be present. On an aircraft, either on the ground or airborne. While operating a vehicle.

2. Do not touch or move antennas while the unit is transmitting. Do not hold any unit containing a radio so that the antenna is close to, or touching, exposed parts of the body while the unit is transmitting.

3. The antennas and units are designed to operate in an indoor environment only.

4. Avoid connecting or disconnecting cables during periods of lightning activity.

5. When handling the 3G NIM and antennas, wear grounding straps to avoid ESD damage to the card. Touching the rear panel with your hand or any metal tool can result in a shock.

6. Always disconnect the power to the unit before handling the NIM card, antennas, or cables.

NetVanta 1000/1000R Series Hardware Installation Guide Unit Installation

Antenna Installation Instructions

Instructions for Installing the 3G NIM Antennas

Step Action

1 Remove power from the base unit. 2 Place either of the two antennas directly onto the antenna port labeled ANT1 on the rear panel. 3 Using the thumb screws only, carefully thread the antenna onto the connector until it is secure. 4 Repeat Step 2 with the second antenna, attaching it to the ANT2 (diversity) port. 5 Once both antennas are secured, the antennas can be flexed at the joint to increase reception. 6 Position antennas in a “V” shape at a 90 degree angle to each other, as shown in Figure 43.

ANT1 ANT2

RSSI

WWAN

EVDO

1xRTT

3G NIM (CDMA)

Figure 43. Proper Antenna Alignment

Your NetVanta is now ready to be configured and connected to the network. For more information on configuration for a specific application, refer to the quick configuration documents provided on the AOS Documentation CD. For details on the CLI, refer to the AOS Command Reference Guide (also included on your CD).

Unit Installation NetVanta 1000/1000R Series Hardware Installation Guide

APPENDIX A. CONNECTOR PIN DEFINITIONS

The following tables provide the pin assignments for the base unit, NIMs, and DIMs.

Base Unit Pinouts

Table A-1. CONSOLE Port Pinouts

Pin Name Description

1 DCD Data Carrier Detect (output) 2 RD Receive Data (output) 3 TD Transmit Data (input) 4 DTR Data Terminal Ready (input) 5 SG Signal Ground 6 DSR Data Set Ready Tied to pin 1 (output) 7 — Unused 8 CTS Clear to Send Tied to pin 1 (output) 9 — Unused

Table A-2. SFP Slot Pinouts

Pin Name Pin Name

1TGND11RGND 2 TX FAULT 12 RX3 TX DISABLE 13 RX+ 4 MOD DEF(2) 14 RGND 5MOD DEF(1)15 VccR 6MOD DEF(0)16 VccT 7 RATE SELECT 17 TGND 8LOS18TX+ 9RGND19TX-

10 RGND 20 TGND

Appendix A. Connector Pin Definitions NetVanta 1000/1000R Series Hardware Installation Guide

Table A-3. 10/100Base-T Ethernet Port Pinouts

Pin Name Description

1 TX1 Transmit Positive 2 TX2 Transmit Negative 3 RX1 Receive Positive

4, 5 — Unused

6 RX2 Receive Negative

7, 8 — Unused

Table A-4. 1000Base-T Gigabit Ethernet Port Pinouts

Pin Name Description

1 TRD0+ Transmit/Receive Positive 2 T RD0- Transmit/Receive Negative 3 TRD1+ Transmit/Receive Positive 4 TRD2+ Transmit/Receive Positive 5 T RD2- Transmit/Receive Negative 6 T RD1- Transmit/Receive Negative 7 TRD3+ Transmit/Receive Positive 8 T RD3- Transmit/Receive Negative

NetVanta 1000/1000R Series Hardware Installation Guide Appendix A. Connector Pin Definitions

Network Interface Module Pinouts

Table A-5. WAN-DDS Connector Pinouts

Pin Name Description

1 R1 Transmit data to the network–Ring 1 2 T1 Transmit data to the network–Tip 1

3-6 — Unused

7 T Receive data from the network–Tip 8 R Receive data from the network–Ring

Table A-6. WAN-T1 Connector Pinouts

Pin Name Description

1 R1 Receive data from the network–Ring 1 2 T1 Receive data from the network–Tip 1 3 — Unused 4 R Transmit data toward the network–Ring 5 T Transmit data toward the network–Tip

6-8 — Unused

Table A-7. WAN-E1 Connector Pinouts

Pin Name Description

1 R1 Receive data from the network–Ring 1 2 T1 Receive data from the network–Tip 1 3 — Unused 4 R Transmit data toward the network–Ring 5 T Transmit data toward the network–Tip

6-8 — Unused

Appendix A. Connector Pin Definitions NetVanta 1000/1000R Series Hardware Installation Guide

Table A-8. DSX-1 Connector Pinouts

Pin Name Description

1 R Transmit data toward the DTE–Ring 2 T Transmit data toward the DTE–Tip 3 — Unused 4 R1 Receive data from the DTE–Ring 1 5 T1 Receive data from the DTE–Tip 1

6-8 — Unused

Table A-9. G.703 Connector Pinouts

Pin Name Description

1 R Transmit data toward the DTE–Ring 2 T Transmit data toward the DTE–Tip 3 — Unused 4 R1 Receive data from the DTE–Ring 1 5 T1 Receive data from the DTE–Tip 1

6-8 — Unused

Table A-10. WAN-SHDSL Connector Pinouts

Pin Name Description

1 T2 Loop 2–Tip 2 R2 Loop 2–Ring 3 — Unused 4 T1 Loop 1–Tip 5 R1 Loop 1–Ring

6-8 — Unused

NetVanta 1000/1000R Series Hardware Installation Guide Appendix A. Connector Pin Definitions

Table A-11. WAN-ADSL Connector Pinouts

Pin Name Description

1, 2 — Unused

3 R ADSL Ring 4 T ADSL Tip

5, 6 — Unused

Table A-12. Serial to Cable Connector Pinouts

Serial

V.35

X.21

EIA 530

Pin Name

1P22 TD_A 2UN/A24 ETC_A 3 Y N/A 15 TCLK_A 4 V 6 17 RCLK_A 5 R 4 3 RD_A 6 F N/A 8 DCD_A 7HN/A20 DTR_A 8C34 RTS_A 9 N/A 10 19 RTS_B (V.11 only)

10 N/A 12 13 CTS_B (V.11 only)

11 D 5 5 CTS_A 12 E N/A 6 DSR_A 13 K N/A 25 TM_A 14 S 9 14 TD_B 15 W N/A 11 ETC_B 16 AA N/A 12 TCLK_B 17 X 13 9 RCLK_B 18 T 11 16 RD_B

19-25 N/A N/A N/A Unused

26 B 8 7 Ground

Appendix A. Connector Pin Definitions NetVanta 1000/1000R Series Hardware Installation Guide

Table A-13. Analog Station (FXS) and Analog Trunk (FXO) Port Pinouts

Pin Name Description

1, 2 — Unused

3 Ring Ring lead of the 2-wire interface 4 Tip Tip lead of the 2-wire interface

5, 6 — Unused

NetVanta 1000/1000R Series Hardware Installation Guide Appendix A. Connector Pin Definitions

Dial Backup Interface Module Pinouts (DBU Connector)

An optional DIM is required for dial backup applications.

Table A-14. Analog Modem and ISDN BRI DBU Connector Pinouts

Pin Name Description

1-3 — Unused

4 R Network–Ring 5 T Network–Tip

6-8 — Unused

Table A-15. ISDN S/T DBU Connector Pinouts

Pin Name Description

1, 2 — Unused

3 R1 Network Receive–Ring 1 4 R Network Transmit–Ring 5 T Network Transmit–Tip 6 T1 Network Transmit–Tip 1

7, 8 — Unused

Appendix A. Connector Pin Definitions NetVanta 1000/1000R Series Hardware Installation Guide

Index

Numerics

1000BaseLX single-mode SFP module 15 1000BaseSX multi-mode SFP module 15 56K/64K NIM

ADSL, Annex A module 46 ADSL, Annex B module 47 ADTRAN operating system antenna connectors 30 antennas 15, 26

command line interface 53 CompactFlash

installing a CompactFlash card

console port description

26, 30

DBU LED 33 Dial Backup Interface Modules

Analog Modem ISDN BRI 51 ISDN S/T

DIMs, installing 57 dual T1 NIM 40

E1/FE1 + G.703 drop module 42 E1/FE1 module 41 EMC table 6

front panel

LEDs 33

grounding NetVanta 1224STR (DC) 56

installation

rack mounting instructions wall mounting instructions 55

installing a CompactFlash card installing DIMs installing NIMs 59 installing the unit installing VPN accelerator card installing wireless access antennas

LEDs, description of 33

mounting options 54

NetVanta 1224

brief description front panel 16 rear panel 17 shipping contents

NetVanta 1224R

brief description 20 front panel rear panel 22 shipping contents 21

NetVanta 1224ST

brief description front panel rear panel shipping contents 18

NetVanta 1224STR

brief description front panel 24 rear panel shipping contents 23

NetVanta 1335

brief description front panel 27 rear panel 29 shipping contents

NetVanta 1524ST

brief description 30 front panel rear panel 32 shipping contents 31

NetVanta VPN Accelerator Card Network Interface Modules

56K/64K ADSL, Annex A ADSL, Annex B 47 Dual T1

E1/FE1 E1/FE1 + G.703 serial 43

44, 45

SHDSL

T1/FT1 T1/FT1 + DSX-1 39 T1/FT1 NEBS

Network Interface Modules (NIMs)

NetVanta SHDSL NIM

features and specifications

NIMs, installing 59

option modules discussion 35

Index NetVanta 1000/1000R Series Hardware Installation Guide

pinouts

10/100Base-T ports 68 1000Base-T ports 68 ADSL connector console port 67 DBU connector DDS connector 69 DSX-1 connector 70 E1 connector FXS and FXO 72 G.703 connector 70 serial to cable connector SFP slots 67 SHDSL connector 70 T1 connector

port LEDs 33 power

NetVanta AC-powered units NetVanta DC-powered unit 56 supplying to unit 56

power over Ethernet product registration 8 product specifications 34

physical interfaces

rack mounting instructions 54 radio channels 7

safety instructions 4 serial module 43

SFP module descriptions SHDSL interface 44 SHDSL module, Annex A 44 SHDSL module, Annex B shipping contents

NetVanta 1224 16 NetVanta 1224R NetVanta 1224ST 18 NetVanta 1224STR NetVanta 1335 27 NetVanta 1524ST 31

specifications STAT LED 33 STK LED 33

T1, dual module 40 T1/FT1 + DSX-1 module 39 T1/FT1 module 37 T1/FT1 NEBS module tools required for installation 53

VPN accelerator card 60

wall mounting instructions 55 WAN LED 33 warranty 8

WiFi wireless access 15
