FCC ID: MNLAM160020021025
AM 1600 Manual
The Federal Communication Commission Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction, may cause harmful interference to radio communication.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment of f and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
l Reorient or relocate the receiving antenna.
l Increase the separation between the equipment and receiver.
l Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
l Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user‘s authority to operate the equipment.
Use only shielded cables to connect I/O devices to this equipment.
You are cautioned that change or modifications not expressly approved by the
party responsible for complies could void your authority to operate the
equipment.
THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITION:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Welcomed!
Thank you for purchasing this RF Wireless Optical Mouse. Utilizing the latest
wireless RF technology, this mouse can work from any directions or angles
even when objects hinder between your mouse & the receiver. You can
locate the device freely and enjoy its convenience.
Install Your Wireless Mouse
Hardware Installation
Installing Batteries
1. Remove the battery cover from the bottom of your mouse.
(1)（Press down the lid on the bottom of the mouse）
(2)（The top shell pops out automatically. Push forward the top shell. ）
2. Insert two AA Alkaline Batteries into the battery compartment.
3. Replace the cover carefully.
l Once the battery is placed correctly in the mouse, the optical LED located
at the mouse bottom will light up.
Connect the Mouse
To connect to a USB port (Windows 98 or higher required), connect the USB
receiver to the USB port on the computer.
To connect to a PS/2 port, TURN OFF your computer before installation.
1. Connect the PS/2 adapter to the USB receiver.
2. Insert the receiver into the PS/2 port on the computer.
3. Turn on your computer.
If you work under Windows environment, you may be prompted to insert the
Windows software CD. Please insert this CD into the computer’s CD-ROM
when you are asked to do so and follow the on-scree n instructions.
Establishing a Communication Link
First of all, please find out if you bought a 400 cpi or 800 cpi mouse. (Please
refer to the label on the box.)
For 400 cpi mouse
1. After you insert the receiver to your computer, the receiver will not light up or
blink;
2. Please press the reset button on the back of your mouse in 3 minutes;
reset button
3. When the receiver link with the mouse successfully, the LED of the receiver
will blink.
For 800 cpi mouse
connected, please relocate the receiver and press the reset button again within 3
1. After you insert the receiver to your computer, the LED of the receiver will
flash slowly;
2. Press the reset button on the back of your mouse in 3 minutes;
reset button
3. Once the receiver link with the mouse successfully, the LED of the receiver
will blink quickly.
If the reset button was not pressed within 3 minutes after the receiver is
minutes.
Software Installation (Optional)
This mouse is totally compatible with Windows 98/ 2000/ ME/ XP without driver
installation. When driver supports, this mouse will be able to work under
Windows 95. Additional functions will also be available for the middle wheel.
1. Click Start and uninstall your previous mouse program.
2. Insert software diskette into drive A or B.
3. Click Start on the Taskbar and select “Run.”
4. From the Run dialogue box, select (or type) A:\SETUP and press ENTER.
5. From the Select Device Type dialogue box, choose USB Port or PS/2 Port
and then click NEXT.
To access the software, double-click the white mouse icon on the Taskbar to
display the Mouse Properties tabs.
Software Functions
1. Wheel Mode:
l System (Intelli-Mouse) Mode.
l Enhanced Scroll Mode.
P.S. Please click “Help” for further information.
2. Scroll Speed:
l Scroll 1 to 10 lines per scrolling unit.
l Scroll one page per scrolling unit.
3. Universal Scroll:
Control the directions and speed of scrolling bar by moving your mouse.
You can set up the vertical or horizontal scrolling directions and speed.
4. Universal Zoom:
Magnify or minimize any characters or illustrations. You can adjust the
zoomed area or zoom factor by pushing the wheel forward or backward.
5. Auto Scroll:
Move the mouse once in the direction you want to scroll.
6. Horizontal Wheel:
You can press the wheel button to change the scroll direction from vertical
to horizontal. Just exchange the scroll directions by clicking the wheel
button once. It’s specially designed for long documents reading.
7. Others:
There are 38 kinds of other functions for the middle wheel assignment.
Important Note
l To optimize the performace of your RF reception, please make your
receiver at least 8 inches (20 cm) away from electronical devices, such as
monitor, speakers or external storage devices.
l Please avoid your RF optical mouse to work on a metal surface. Metals
such as iron, aluminum or copper shield the radio frequency transmission
and may slow down the response of the mouse or cause the mouse to fail
temporarily.
* This RF mouse will enter a suspend mode as your computer sleeps. For
400 cpi users, please slightly press the bu ttons to wake up the mouse. For
800 cpi users, please move the mouse for a while and the mouse will wake up.
l Never use the RF mouse on a glass or mirrored surface.
l Each time after you insert the new batteries, please reconnect the
receiver and press the reset channel button to scan for the best
performed ID.
* Battery detection system and middle wheel indicator light warn you when
the battery power is low and requires replacement.
Mouse Software Un-installation
1. Click Start on the Taskbar and select PERFECT SERIES from Program
Files.
2. Please choose “Uninstall RF Wireless Optical Mouse and follow the
on-screen instructions.
