ADLINK ACL-8112 User Manual

Enhanced Multi-Function

Data Acquisition Card

NuDAQ®

ACL-8112 Series

User’s Manual

Recycled Paper

©Copyright 2004 ADLINK TECHNOLOGY INC.

All Rights Reserved.

Manual Rev. 3.70: August 02, 2004

Part No.: 50-11012-202

The information in this document is subject to change without prior notice in
order to improve reliability, design, and function and does not represent a
commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such
damages.

This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.

Trademarks

NuDAQ and ACL-8112 are registered trademarks of ADLINK TECHNOLOGY
INC.. Other product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their
respective companies.

Getting Service from ADLINK

Customer Satisfaction is top priority for ADLINK TECHNOLOGY INC. If you
need any help or service, please contact us.

ADLINK TECHNOLOGY INC.

Web Site http://www.adlinktech.com

Sales & Service [e-mail]

TEL [phone] FAX [phone]

Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan

Please email or FAX your detailed information for prompt, satisfactory, and
consistent service.

Detailed Company Information

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL FAX

Web Site

Questions

Product Model

OS:
Computer Brand:
M/B: CPU:

Environment

Detail Description

Chipset: BIOS:
Video Card:
NIC:
Other:

Suggestions for ADLINK

Table of Contents

Chapter 1 Introduction...................................................................... 1

1.1 Features...............................................................................................3

1.2 Applications..........................................................................................4

1.3 Specifications .......................................................................................4

1.4 Software Support .................................................................................8

Chapter 2 Installation........................................................................ 9

2.1 What You Have ....................................................................................9

2.2 Unpacking ..........................................................................................10

2.3 ACL-8112's Layout.............................................................................11

2.4 Jumper and DIP Switch Description...................................................13

2.5 Base Address Setting.........................................................................13

2.6 Analog Input Channel Configuration ..................................................15

2.7 DMA Channel Setting.........................................................................16

2.8 Internal/External Trigger Setting.........................................................17

2.9 Clock Source Setting..........................................................................18

2.10 IRQ Level Setting ...............................................................................18

2.11 D/A Reference Voltage Setting ..........................................................19

2.12 A/D Input Range Setting ....................................................................20

Chapter 3 Signal Connections ....................................................... 21

3.1 Connectors Pin Assignment ...............................................................21

3.2 Analog Input Signal Connection .........................................................24

3.3 Analog Output Signal Connection ......................................................26

3.4 Digital I/O Connection ........................................................................26

3.5 Timer / Counter Connection ...............................................................27

3.6 Daughter Board Connection...............................................................28

Chapter 4 Registers.........................................................................29

4.1 I/O Port Address.................................................................................30

4.2 A/D Data Registers ............................................................................31

4.3 A/D Channel Multiplexer Register ......................................................31

4.4 A/D Range Control Register...............................................................33

4.5 A/D Operation Mode Control Register................................................35

4.6 Interrupt Status Register ....................................................................36

4.7 Software Trigger Register ..................................................................36

4.8 Digital I/O register ..............................................................................37

4.9 D/A Output Register ...........................................................................38

4.10 Internal Timer/Counter Register .........................................................39

Table of Contents • i

Chapter 5 Operation Theory...........................................................41

5.1 A/D Conversion ..................................................................................41

5.2 D/A Conversion ..................................................................................44

5.3 Digital Input and Output .....................................................................44

5.4 Timer/Counter Operation ...................................................................45

Chapter 6 Calibration & Utilities ....................................................49

6.1 What you need...................................................................................49

6.2 VR Assignment ..................................................................................50

6.3 D/A Adjustment ..................................................................................50

6.4 A/D Programmable Gain Amplifier adjustments.................................51

6.5 A/D Adjustment ..................................................................................51

Chapter 7 C Language Library ....................................................... 53

7.1 _8112_Initial.......................................................................................54

7.2 _8112_Switch_Card_No ....................................................................56

7.3 _8112_DI ...........................................................................................57

7.4 _8112_DI _Channel ...........................................................................58

7.5 _8112_DO..........................................................................................59

7.6 _8112_DA ..........................................................................................60

7.7 _8112_AD_Input_Mode .....................................................................61

7.8 _8112_AD_Set_Channel ...................................................................63

7.9 _8112_AD_Set_Range ......................................................................64

7.10 _8112_AD_Set_Mode........................................................................67

7.11 _8112_AD_Soft_Trig..........................................................................69

7.12 _8112_AD_Aquire..............................................................................70

7.13 _8112_CLR_IRQ................................................................................71

7.14 _8112_AD_DMA_Start.......................................................................72

7.15 _8112_AD_DMA_Status ....................................................................74

7.16 _8112_AD_DMA_Stop.......................................................................75

7.17 _8112_AD_INT_Start.........................................................................76

7.18 _8112_AD_INT_Status ......................................................................77

7.19 _8112_AD_INT_Stop .........................................................................78

7.20 _8112_AD_Timer ...............................................................................79

7.21 _8112_TIMER_Start ..........................................................................80

7.22 _8112_TIMER_Read .........................................................................81

7.23 _8112_TIMER_Stop...........................................................................81

Appendix A Demo Programs..........................................................83

Warranty Policy .....................................Error! Bookmark not defined.

ii • Table of Contents

How to Use This Guide

This manual is designed to help you use the ACL-8112. The manual
describes how to modify various settings on the ACL-8112 card to meet your
requirements. It is divided into seven chapters:

Chapter 1

Gives an overview of the product features, applications, and

Chapter 2

Describes how to install the ACL-8112. The layout of the ACL-

Chapter 3

Describes the connectors' pin assignment and how to connect

Chapter 4

Describes the details of register format and structure of the

Chapter 5

Describes how to operate the ACL-8112. The A/D, D/A, DIO

Chapter 6

Describes how to calibrate the ACL-8112 for accurate

Chapter 7

Describes how to program the ACL-8112 by using the C

Appendix A

Introduction

specifications.

Installation

8112 is shown, the switch setting for base address, and jumper
setting for analog input channel configuration, reference
voltage setting, trigger source, interrupt level and DMA channel
are specified.

Signal Connection

the outside signal and devices with the ACL-8112.

Registers

ACL-8112, this information is very important for programmers
who want to control the hardware by low-level programming.

Operation Theory

and timer/counter functions are introduced. Also, some
programming concepts are specified.

Calibration & Utility

measurement.

C Language Library

language library in DOS environment.

Demo Program

Describes some demonstration programs.

How to Use This Guide ● iii

1

Introduction

The ACL-8112 is a high performance, high speed multi-function data
acquisition card for IBM PC or compatible computers.

The ACL-8112 series is designed to combine all data acquisition functions,
such as A/D, D/A, DIO and timer/counter into a single board. The high-end
specifications of the card makes it ideal for a wide range of applications
requiring high speed. Figure 1.1 shows the block diagram of ACL-8112.

The ACL-8112 Series consists of three models, the ACL-8112HG, ACL­8112DG and ACL-8112PG. The ACL-8112HG provides special high-gain
programmable instrument amplifier for low level input applications, such as
measurement of thermo-coupling signals. The ACL-8112DG provides high
speed sampling rates ( up to 100 KHz) at all gains ( x1, x2, x4, and x8) and
the ACL-8112PG provides 16 single-ended inputs with sampling up to 100
KHz with 5 levels of gain (x1, x2, x4, x8, x16)

All ACL-8112 Series feature 16 single-ended inputs or 8 differential inputs,
two12-bit double-buffered analog outputs, 16 digital inputs and 16 digital
outputs, and one timer/counter channel.

Introduction • 1

...

DI 1

D/I 0

16 BIT

EXT.CLK

TO PACER TRIG

OUT 0

<

16 BIT

16 BIT

16 BIT

COUNTER #0

COUNTER #2

COUNTER #1

FR/2

2MHz

OSC.

4 MHz

REGISTER

DIGITAL INPUT

12 Bit

A/D Converter

...

DI 15

16 BIT

DIGITAL INPUT

PACER

REGISTER

DO 15

D/O 0

DO 1

EOC

INPUT

BUFFER

(B.B 774)

INTERNAL BUS

TRIG

TRIG

SOFTWARE

TRIG

LOGIC

CONTROL

DACK

DRQ

TRIG

EXTERNAL

LOGIC

INTERRUPT

IRQ SELECT

#1 OR #3

DMA SELECT

DATA

BUFFER

PC/AT BUS

+5V

GAIN

12-Bit

Code Latch

+15

12-Bit

Code Latch

AMP

SELECT

-15

DC/DC

CONVERTER

I/O PORT DECODER

Figure 1.1 ACL - 8112 BLOCK DIAGRAM

D/A #0 12 BIT

MULITIPLYING D/A

<

GND

REF 0 IN

D/A 0 OUT

2 • Introduction

D/A #1 12 BIT

MULITIPLYING D/A

or

Analog

8 Differential

...

Multiplexer

>

16 channel

Single-ended

>

>

MUX SCAN

CONTROL

<

GND

CH 0

CH 1

REF 1 IN

D/A 1 OUT

CH 2

ANALOG

INPUT

CH 15

1.1 Features

The ACL-8112 series Enhanced Multi-function Data Acquisition Card
provides the following advanced features:

• AT-Bus

• 16 single-ended or eight differential analog input channels for ACL-

8112DG/HG, 16 single-ended for ACL-8112PG

• Bipolar or unipolar input signals for ACL-8112DG/HG, bipolar for ACL­8112PG

• Programmable gain

• High gain for ACL-8112HG:( x0.5, x1, x5, x10, x50, x100, x500,

x1,000)

• Normal gain for ACL-8112DG (x0.5, x1, x2, x4, x8)

• Five Levels programmable gain for ACL-8112PG (x1, x2, x4, x8, x16),

x0.5 gain can be set by jumper

• On-chip sample & hold

• Two 12-bit monolithic multiplying analog output channels

• 16 digital output channels

• 16 digital input channels

• Three programmable 16-bit down counters

• Programmable sampling rate of up to 100KHz

• Three A/D trigger modes: software trigger, programmable pacer

trigger, and external pulse trigger

• AT interrupt IRQ capability: nine IRQ levels (IRQ3~IRQ15) are jumper
selectable

• Integral DC-to-DC converter for stable analog power source

• 37-pin D-type connector

• Compact size: half-size PCB

Introduction • 3

1.2 Applications

• Industrial and laboratory ON/OFF control

• Energy management

• Annunciation

• 16 TTL/DTL compatible digital input channels

• Security controller

• Product test

• Period and pulse width measurement

• Event and frequency counting

• Waveform and pulse generation

• BCD interface driver

1.3 Specifications

Analog Input (A/D)

♦

Converter:

•

Resolution:

•

Number of channels:

•

ACL-8112DG/HG: 16 single-ended or eight differential

ACL-8112PG: 16 single-ended

Input Range:

•

ACL-8112HG

•

Bipolar : ±10V, ± 5V, ±1V, ±500 mV, ±100mV, ±50mV, ±10mV, ±5mV

Unipolar: 0 to 10V, 0 to 1V, 0 to 0.1V, 0 to 0.01V

ACL-8112DG:

•

Bipolar : ±10V, ± 5V, ±2.5V, ±1.25V, ±0.625

ADS774 or equivalent, successive approximation type

12-bit

(Programmable)

:

Unipolar: 0 to 10V, 0 to 5V, 0 to 2.5V, 0 to 1.25V

4 • Introduction

ACL-8112PG:

•

Bipolar : ± 10V, ± 5V, ±2.5V, ±1.25V, ±0.625V

Or

Bipolar : ± 5V, ±2.5V, ±1.25V, ±0.625V, ±0.3125V

Conversion Time:

•

Overvoltage protection:

•

Accuracy:

•

(ACL-8112HG)

GAIN = 0.5, 1
GAIN = 5, 10
GAIN = 50, 100
GAIN = 500, 1000

(ACL-8112DG)

GAIN = 0.5, 1
GAIN = 2, 4
GAIN = 8

(ACL-8112PG)

GAIN = 0.5, 1, 2, 4
GAIN = 8, 16

Input Impedance:

•

8µs

Continuous ± 35V maximum

0.01% of FSR ±1 LSB

0.02% of FSR ±1 LSB

0.04% of FSR ±1 LSB

0.04% of FSR ±1 LSB

0.01% of FSR ±1 LSB

0.02% of FSR ±1 LSB

0.04% of FSR ±1 LSB

0.015% of FSR ±1 LSB

0.02% of FSR ±1 LSB

10MΩ

AD conversion trigger modes:

•

Data Transfer:

•

Sampling Rate:

•

• 100 KHz maximum for single channel

• 100 KHz maximum for multiplexing on ACL-8112PG

• 20 KHz maximum for multiplexing on ACL-8112DG/HG

Analog Output (D/A)

Converter:

•

Number of channels:

•

Resolution:

•

Pooling, DMA, Interrupt

DAC7541 or equivalent, monolithic multiplying

Two double-buffered analog outputs

12-bit

Software, Pacer, and External trigger

Introduction • 5

Output Range:

•

Internal reference: (unipolar) 0 to 5V or 0 to 10V

External reference: (unipolar) max. +10V or -10V

Settling Time:

•

Linearity:

•

Output driving capability:

•

Digital I/O (DIO)

♦

Number of channels:

•

Input Voltage:

•

Low: Min. 0V; Max. 0.8V

High: Min. +2.0V

Input Load:

•

Low: +0.5V @ -0.2mA max.

High: +2.7V @+20mA max.

Output Voltage:

•

Low: Min. 0V; Max. 0.4V

High: Min. +2.4V

Driving Capacity:

•

Low: Max. +0.5V at 8.0mA (Sink)

High: Min. 2.7V at 0.4mA (Source)

30µs

±1/2 bit LSB

±5mA max.

16 TTL compatible inputs and outputs

Programmable Counter

♦

Device:

•

A/D pacer:

•
2MHz time base

Pacer Output:

•

Counter:

•
clock source

6 • Introduction

8254

32-bit timer (two 16-bit counter cascaded together) with a

0.00046 Hz to 100 KHz

One 16-bit counter with internal 2MHz time base or external

General Specifications

♦

I/O Base Address:

•

Interrupt IRQ:

•

DMA Channel

•

Connector:

•

Operating Temperature:

•

Storage Temperature:

•

Humidity:

•

Power Consumption:

•

ACL-8112DG/HG: +5 V @ 430 mA typical

+12V @ 150 mA typical

ACL-8112PG: +5 V @ 450 mA typical

12 V @ 150 mA typical

Dimension:

•

ACL-8112DG/HG: 162mm(L) x 115mm(W)

ACL-8112PG: 163 mm(L) x 123 mm(W)

5 to 95%, non-condensing

16 consecutive address location

IRQ3, 5, 6, 7, 9, 10, 11, 12, 15 (nine levels)

: CH1 and CH3 (Jumper selectable)

37-pin D-type connector

0°C to 55°C

-20°C to 80°C

Introduction • 7

1.4 Software Support

Programming Library

For users who are writing their own programs, we provide MS-DOS Borland
C/C++ programming library.

ACLS-DLL2 is the Development Kit for NuDAQ ISA-Bus Cards with Analog
I/O for windows 3.1/95(98)/NT. ACLS-DLL2 can be used in many
programming environments, such as VC++, VB, and Delphi. ACLS-DLL2 is
included in the ADLINK CD. To use this package a license is required.

LabView Driver

The ACLS-LVIEW includes the ACL-8112’s Vis, which is used to interface
with NI’s LabView software package. The ACLS-LVIEW supports Windows­95(98)/NT. ACLS-LVIEW is included in the ADLINK CD. To use this package
a license is required.

8 • Introduction

2

Installation

This chapter describes how to install the ACL-8112 series products. Please
use the following steps to install the product.

• Check what you have (section 2.1)

• Unpacking (section 2.2)

• Check the PCB and jumper location(section 2.3)

• Install the hardware and setup the jumpers and switches (sections 2.4

to 2.12)

• Cabling with external devices (section 2.13)

2.1 What You Have

In addition to this User's Manual, the package includes the following items:

• ACL-8112 Enhanced Multi-function Data Acquisition Card

• ADLINK CD

If any of these items are missing or damaged, contact ADLINK or the dealer
from whom the product was purchased. Save the shipping materials and
carton for future shipping or storage.

Note:

The utilities and libraries in the CD-ROM only support the ACL-8112
series under DOS environment. If you need to develop applications
under Windows 3.1, Windows 95 or Windows NT, please contact our
dealer for purchasing software development kit ACLS-DLL2.

Installation • 9

2.2 Unpacking

The card contains electro-static sensitive components that can be easily be
damaged by static electricity.

Therefore, the card should be handled on a grounded anti-static mat. The
operator should be wearing an anti-static wristband, grounded at the same
point as the anti-static mat.

Inspect the card module carton for obvious damage. Shipping and handling
may cause damage to the module. Ensure there is no shipping and handling
damage on the modules carton before continuing.

After opening the card module carton, extract the system module and place it
only on a grounded anti-static surface with component side up.

Again, inspect the module for damages. Press down on all the socketed IC's
to make sure that they are properly seated. Do this only with the module
place on a firm flat surface.

Note:

You are now ready to install your card.

DO NOT ATTEMPT TO INSTALL A DAMAGED BOARD IN THE
COMPUTER

.

10 • Installation

2.3 ACL-8112's Layout

INT

EXT1 EXT2

-5V

-10V

JP2

JP1

DIFF

SING

JP3

CN3

VR6

VR5

VR3 VR4

VR1 VR2

ADS774

INTTRG

JP4

CN1

. . . . . . . .

JP6

EXTCLK

INTCLK

SW1

EXTTRG

CN2

. . . . . . . .

8254

DACK

DRQ

JP5

JP7

1 3 X

1 3 X

JP8

3 5 6 7910111215NC

8112 Ver C.

Figure 2.1-1 PCB Layout of the ACL-8112DG/HG Ver C.

Installation • 11

12 • Installation

Figure 2.1-2 PCB Layout of the ACL-8112PG

2.4 Jumper and DIP Switch Description

ACL8112's channels and base address can be changed by setting jumpers
and DIP switches on the card. The card's jumpers and switches are preset at
the factory. The jumper settings can be changed for the user’s applications.

A jumper switch is closed (sometimes referred to as "shorted") with the
plastic cap inserted over two pins of the jumper. A jumper is open when the
plastic cap is inserted over one or no pin(s) of the jumper.

2.5 Base Address Setting

The ACL-8112 requires 16 consecutive address locations in the I/O address
space. The base address of the ACL-8112 is restricted by the following
conditions.

1. The base address must be within the range Hex 200 to Hex 3FF.

2. The base address should not conflict with any PC reserved I/O
address. See Appendix A.

3. The base address must not conflict with any add-on card on the
user’s PC. Please check your PC before installing the ACL-8112.

The ACL-8112's base address of registers is selected by a 6-positions DIP

SW1

switch
possible base address combinations are listed as Table 2.2. The base
address may be modified if the address HEX 220 has been occupied by
another add-on card.

. The default setting of base address is set to be HEX 220. All

SW1 : Base Address = Hex 220

ON

2 3 4 5

1

DIP

A ( 8 7 6 5

Figure 2.2 Default Base Address Setting

Installation • 13

I/O port

Address(Hex) A9

200-20F

--

(1)

210-21F

--

(1)

220-22F

(default)

230-23F

--

(1)

--

(1)

:

300-30F

--

(1)

:

3F0-3FF

--

(1)

1

A8

ON

(0)

ON

(0)

ON

(0)

ON

(0)

OFF

(1)

OFF

(1)

2

A7

ON

(0)

ON

(0)

ON

(0)

ON

(0)

ON

(0)

OFF

(1)

3

A6

ON

(0)

ON

(0)

ON

(0)

ON

(0)

ON

(0)

OFF

(1)

4

A5

ON

(0)

ON

(0)

OFF

(1)

OFF

(1)

ON

(0)

OFF

(1)

5

A4

ON

(0)

OFF

(1)

ON

(0)

OFF

(1)

ON

(0)

OFF

(1)

Table 2.2 Possible Base Address Combinations

A0, ..., A9 corresponds to the PC Bus address lines
A9 is fixed at “1”.

How to define/determine the base address of the ACL-8112?
DIP1 to DIP5 of SW1 corresponds to the PC bus address line A8 to
A4 respectively. A9 is always 1 and A0 to A3 are always 0. If you want
to change the base address, you can only change the values of A8 to
A4 (the shadow area of the table below). The following table is an
example, of how to set a base address of Hex 220

Base Address: Hex 220

2 2 0

1 0 0 0 1 0 0 0 0 0

A9 A8 A7 A6 A5 A4 A3 A2 A1 A0

14 • Installation

2.6 Analog Input Channel Configuration

(This section applies to ACL-8112DG and ACL-8112HG only.)

The ACL-8112 offers 16 single-ended or eight differential analog input
channels. JP3 controls the analog input channel configuration. The setting of
JP3 is illustrated below:

SING

Single-ended
(default setting)

Differential Input

Figure 2.3 Analog Input Channels Configuration

JP3

DIFF

SING

JP3

DIFF

Installation • 15

2.7 DMA Channel Setting

The A/D data transfer of the ACL-8112 is designed with DMA transfer
capabilities. The setting of the DMA for channel 1 or channel 3 is controlled
by JP7 and JP8 on the ACL-8112DG/HG, and JP1 and JP2 on the ACL­8112PG. Possible settings are shown below:

Note:

On floppy disk only machine, we suggest you set the DMA to level 3.
If you have a hard disk installed on the computer, level 1 is
preferable.

NO

DMA

DRQ
JP8/JP2

3

1

X

DACK
JP7/JP1

1 3 X

DMA 1

(Default)

DMA 3

Figure 2.4 DMA Channel Setting

16 • Installation

2.8 Internal/External Trigger Setting

The A/D conversion trigger source of the ACL-8112 can come from an
internal or external source. The internal or external trigger source is set by
JP4 on the ACL-8112DG/HG and by JP5 on the ACL-8112PG, as shown
on Figure 2.5. Note that there are two internal trigger sources, one is by
software trigger and the other is by the programmable pacer trigger, which
is controlled by the mode control register (see section 4.5).

Internal Trigger
(default setting)

INTTRG

EXTTRG

JP4 / JP5

JP4 / JP5

External Trigger

INTTRG

EXTTRG

Figure 2.5 Trigger Source Setting

Internal Clock
Source : 2MHz

(default setting)

External Clock
Source

INTCLK

EXTCLK

INTCLK

EXTCLK

JP6 / JP4

JP6 / JP4

Figure 2.6 Timer's Clock Source Setting

Installation • 17

2.9 Clock Source Setting

Q

The 8254 programmable interval timer is used in the ACL-8112. It provides
three independent 16-bit programmable down counters. The input of
counter 2 is connected to a precision 2MHz oscillator which is the internal
pacer. The input of counter 1 is cascaded from the output of counter 2.
Channel 0 is free for user's applications. There are two selections for the
clock source of channel 0: the internal 2MHz clock or an external clock
signal from connector CN3 pin 37. The setting for the clock is shown in
Figure 2.6.

2.10 IRQ Level Setting

The ACL-8112 can connect to any one of the interrupt lines of the PC I/O
channel. The interrupt line is selected by JP5 of ACL-8112DG/HG or JP3 of
ACL-8112PG. If the user wishes to use the interrupt capability of ACL-8112,
select an interrupt level and place the jumper in the appropriate position to
enable the particular interrupt line.

The default interrupt level is IRQ15, which is selected by placing the jumper
on the pins in row number 15. Figure 2.7 shows the default interrupt jumper
setting IRQ15. The jumper can be removed from IRQ15 to other new pins to
change to another IRQ level.

Note:

Please note that no other add-on cards can share the same interrupt
level simultaneously.

JP5 / JP3

No Interrupt :

56 791011 1215 X

3

IRQ

JP5 / JP3

Interrupt level :

15

IR

(default setting)

IRQ

Figure 2.7 IRQ Level Setting

18 • Installation

5 6 7 9 10 11 12 15 X

3

2.11 D/A Reference Voltage Setting

The D/A converter's reference voltage source can be internally or externally
generated. The external reference voltage is connected via CN3 pin 31
(ExtRef1) and pin 12 (ExtRef2), see section 3.1. The D/A reference source of
channel 1 and channel 2 are selected using JP2 for the ACL-8112DG/HG
and JP6 and JP7 for the ACL-8112PG respectively. Possible settings are
shown below:

D/A CH1 is External

D/A CH2 is External

D/A CH1 is External

D/A CH2 is Internal

D/A CH1 is Internal

D/A CH2 is External

D/A CH1 is Internal

D/A CH2 is Internal

JP2 or JP7 JP6

INTREF

JP2 or JP7 JP6

INTREF

JP2 or JP7 JP6

INTREF

JP2 or JP7 JP6

INTREF

INTREF

ExtRef2 ExtRef1

INTREF

ExtRef2 ExtRef1

INTREF

ExtRef2 ExtRef1

INTREF

ExtRef2 ExtRef1

Figure 2.8 D/A Voltage Setting

Installation • 19

The internal voltage can be set to -5V or -10V which is selected by JP1 for

A

A

the ACL-8112DG/HG and JP8 for the ACL-8112PG. Possible configurations
are specified in Figure 2.9. Note that the internal reference voltage is used
only when JP2 of the ACL-8112DG/HG or JP6 and JP7 of the ACL-8112PG
is set to internal reference.

Reference Voltage is

-10V

-5V (default setting)

-5V

-10V

Reference Voltage is

-10V

Figure 2.9 Internal Reference Voltage Setting

-5V

JP1 /
JP8

JP1 /
JP8

2.12 A/D Input Range Setting

(This section is for the ACL-8112PG only)

The A/D input range of the ACL-8112PG can be set to ±5V or ±10V using
JP9.

10

/D Input Range is +/-

5V (default setting)

/D Input Range is +/-

10V

JP9

5

10

JP9

5

20 • Installation

3

Signal Connections

This chapter describes the connectors of the ACL-8112. Signal connections
between the ACL-8112 and external devices, such as daughter boards or
other devices are also outlined.

3.1 Connectors Pin Assignment

The ACL-8112 comes equipped with two 20-pin insulation displacement
connectors - CN1 and CN2 and one 37-pin D-type connector - CN3. CN1 and
CN2 are located on the board and CN3 is located at the rear plate.

CN1 is used for digital output signals, CN2 is used for digital input signals
and CN3 is used for analog input, analog output and timer/counter's signals.
The pin assignment for each connector is illustrated in Figures 3.1 to 3.3.

CN2:

•

Digital Signal Input (DI 0 to 15 )

CN2

DI 0
DI 2
DI 4
DI 6
DI 8
DI 10
DI 12
DI 14

GND
+5V

Figure 3.1 Pin Assignment of CN2

1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20

DI 1
DI 3
DI 5
DI 7
DI 9
DI 11
DI 13
DI 15

GND
+ 12V

Registers • 21

CN1:

AI2

AI3AI1AI0

AI6

AI7

AI5

A

A

A

A

AI10

AI9AI8

A

A

AI12

A

A

A

AI15

A

AO2

•

Digital Signal Output (DO 0 to 15 )

CN1

DO 0
DO 2
DO 4
DO 6
DO 8
DO 10
DO 12
DO 14

GND
+5V

1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20

DO 1
DO 3
DO 5
DO 7
DO 9
DO 11
DO 13
DO 15

GND
+12V

Figure 3.2 Pin Assignment of CN1

Note:

DO n: Digital output signal channel n
DI n: Digital input signal channel n

GND: Digital ground

CN3:

•

Analog Input/Output & Counter/Timer

(for single-ended connection: ACL-8112DG/HG/PG)

CN3

.GND
.GND

V.R E F

ExtRef2

+12V

.GND

D.GND

COUT0

ExtTrg
N/C

+5V

1
2
3
4

I4

5

6
7
8

9
10
11
12
13
14
15

16
17
18
19

20
21
22

23
24
25

26
27
28
29
30
31
32
33
34
35
36
37

Figure 3.3a Pin Assignment of CN3

I11

I13
I14

.GND
.GND

O1

ExtRef1

GATE0
GATE
N/C
N/C
ExtCLK

22 • Registers

CN 3:

A

A

A

A

A

A

A

A

A

A

A

AIL2

A

AIL0

AIL5

AIL6

A

A

A

A

AIL7

A

AO2

•

Analog Input/Output & Counter/Timer

(for differential connection:: ACL-8112DG/HG)

CN3

IH0
IH1
IH2
IH3
IH4
IH5
IH6
IH7

.GND
.GND

V.R EF

ExtRef2

+12V

.GND

D.GND

COUT0

ExtTrg
N/C

+5V

1
2
3
4
5

6
7
8
9

10
11
12
13
14
15

16
17
18
19

20
21
22

23
24
25

26
27
28
29
30
31
32
33
34
35
36
37

IL1

IL3
IL4

.GND
.GND

O1

ExtRef1

GATE0
GATE
N/C
N/C
ExtCLK

Figure 3.3b Pin Assignment of CN3

Note:

AIn: Analog Input Channel n (single-ended)
AIHn: Analog High Input Channel n (differential)
AILn: Analog Low Input Channel n (differential)
ExtRef n: External Reference Voltage for D/A CH n
AOn: Analog Output Channel n
ExtCLK: External Clock Input
ExtTrig: External Trigger Signal
CLK: Clock input for 8254
GATE: Gate input for 8254
COUT n: Signal output of Counter n

V.ERF: Voltage Reference
A.GND: Analog Ground
GND: Ground

Registers • 23

3.2 Analog Input Signal Connection

AINA

Amp

r

The ACL-8112 provides 16 single-ended or eight differential analog input
channels. The analog signal can be converted to digital value by the A/D
converter. To avoid ground loops and obtain a more accurate measurement
of the A/D conversion, it is quite important to understand the signal source
type and how to choose the correct analog input mode: signal-ended or
differential. The ACL-8112 allows for the configuration through jumpers.

Single-ended Mode:

For single-ended mode, only one input is connected relative to ground and is
suitable for connecting with a floating signal source. Floating source means it
does not have any connection to ground. Figure 3.4 shows a single-ended
connection. Note that when two or more floating sources are connected, the
sources must be connected to common ground.

Floating
Signal
Source

V1

V2

Input Multipexer

Opertiona

lifie

To A/D Conve

n = 0, ..., 15

GND

Figure 3.4 Floating source and single-ended

Differential input mode:

The differential input mode provides two inputs that respond to signal voltage
differences between them. If the signal source is ground-referenced, the
differential mode can be used to reduce ground loops. Figure 3.5 shows the
connection for differential input mode. However, even if the signal source is
locally grounded, the single-ended configuration can still be used when the
Vcm (Common Mode Voltage) is very small and the effect of ground loop is
negligible .

24 • Registers

A

A

r

A

A

Groun
Signal
Sourc

n = 0, ..., 8

VG1 VG2

IHn

ILn

Vcm = VG1 - VG2

+

-

GND

To A/D Converte

Figure 3.5 Ground source and differential input

A differential mode must be used when the signal source is differential. A
differential source means the ends of the signal are not grounded. To avoid
dangerously high voltages between the local ground of the signal and the
ground of the PC system, a shorted ground path must be connected.
Figure 3.6 shows the connection for a differential source.

Differentia
Signal
Sourc

n = 0, ..., 8

IHn

ILn

To A/D Converter

+

-

GND

Vcm = VG1 - VG2

VG1 VG2

Figure 3.6 Differential source and differential input

Registers • 25

If your signal sources contain both a floating and a local ground, the

A

A

g

A

differential mode should be used, with the floating signal source connected
as Figure 3.7.

Floatin
Si

nal

Sourc

n = 0, ..., 8

IHn

ILn

High

Low

GND

To A/D Converter

Figure 3.7 Floating source and differential input

3.3 Analog Output Signal Connection

The ACL-8112 has two unipolar analog output channels. To make the D/A
output connections from the appropriate D/A output, please refer Figure 3.8.

Ref In

-5 or -10
INT or Ext

D/A Converter

Pin-30 ( AO0)

­+

Pin-32 ( AO1)

To D/A Output

Pin-14 ( A.GND)

nalog GND

Figure 3.8 Connection of Analog Output Connection

3.4 Digital I/O Connection

The ACL-8112 provides 16 digital input and 16 digital output channels
through CN1 and CN2 onboard. The digital I/O signals are fully TTL/DTL
compatible. Details of the digital I/O signal specification can be referred to
in section 1.3.

26 • Registers

74LS244

74LS373

Digital Input(DI)

From TTL Signal

Digital Output (DO)

To TTL D evices

Digital GND (DGND)

ACL-8112

Outside Device

Figure 3.9 Digital I/O Connection

3.5 Timer / Counter Connection

The ACL-8112 has an interval 8254 timer/counter on board. It offers three
independent 16-bit programmable down counters; counter 1 and counter 2
are cascaded together as a timer pacer trigger for A/D conversions and
counter 0 is free for user applications. Figure 3.10 shows the 8254
timer/counter connection.

CN3 Pin-37

CN3 Pin-33 CN3 Pin- 16

CN3 Pin-34

2MHz
Oscillator

EXT

INT

Vcc

8254 Timer/Counter

Counter 0

CLK0
GAT E0

Counter 1

CLK1
GAT E1

Counter 2

CLK2
GAT E2

OUT0

OUT1

OUT2

A/D Tri gge r
CN3 Pin-35

Figure 3.10 Block Diagram of 8254 Timer/Counter

Registers • 27

The clock source of counter 0 can be internal or external, with the gate
being controlled externally and the output sent to CN3. As for counter 1
and counter 2, the clock source is internally fixed, while the gate can be
controlled externally and the output sent to CN3 too. All timer/counter
signals are TTL compatible.

3.6 Daughter Board Connection

The ACL-8112 can be connected with any of the five following daughter
boards, ACLD-8125, ACLD-9137, ACLD9182, ACLD9185, and ACLD9188.
The functionality and connections are specified below.

Connect with ACLD-8125

The ACLD-8125 has a 37-pin D-sub connector, which can be connected to
the ACL-8112HG through a 37-pin assemble cable. The most outstanding
feature of this daughter board is the CJC (cold junction compensation)
circuit on board. The thermo-coupler can be directly connected to the ACL­8125 board.

Connect with ACLD-9137

The ACLD-9137 is a direct connector for the ACL-8112 card which is
equipped with a 37-pin D-sub connector. This board provides a simple way
for connecting simple applications that do not need complex signal
conditioning before an A/D conversion is performed.

Connect with ACLD-9182

The ACLD-9182 is a 16 channel isolated digital input board. This board is
connected to CN1 of the ACL-8112 via a 20-pin ribbon cable. The
advantage of this board is the 500Vdc isolation voltage that it provides,
thus it can protect your PC system from damage when an abnormal input
signal occurs.

Connect with ACLD-9185

The ACLD-9185 is a 16 channel SPDT relay output board. This board is
connected to CN2 of the ACL-8112 via a 20-pin ribbon cable. By using this
board, the external devices an be controlled through digital output signals.

Connect with ACLD-9188

The ACLD-9188 is a general purpose terminal board for all cards which
comes equipped with a 37-pin D-sub connector.

28 • Registers

4

Registers

A detailed description of the registers and its structure for the ACL-8112
are specified in this chapter. This information is useful for programmers
who wish to handle the card through low-level programming. Hence, a low
level programming syntax is also introduced. This information can also
assist beginners operate the ACL-8112 in the shortest possible time.

Registers • 29

4.1 I/O Port Address

The ACL-8112 requires 16 consecutive addresses in the PC I/O address
space. Table 4.1 shows the I/O address of each register with respect to the
base address. The function of each register is also listed.

I/O Address Read Write

Base + 0 Counter 0 Counter 0
Base + 1 Counter 1 Counter 1
Base + 2 Counter 2 Counter 2
Base + 3 Not Used 8254 Counter Control
Base + 4 A/D low byte CH1 D/A low byte
Base + 5 A/D high byte CH1 D/A high byte
Base + 6 DI low byte CH2 D/A low byte
Base + 7 DI high byte CH2 D/A high byte
Base + 8 Not Used Clear Interrupt Request

Base + 9 Not Used A/D Range Control
Base + 10 Not Used Channel MUX
Base + 11 Not Used Mode Control
Base + 12 Not Used Software A/D trigger
Base + 13 Not Used DO low byte
Base + 14 Not Used DO high byte
Base + 15 Not Used Not Used

Table 4.1 I/O Address

30 • Registers

4.2 A/D Data Registers

The ACL-8112 series has a 12-bit resolution for each analog input channel,
the digital data is store in the A/D data registers after an A/D conversion.
The A/D data is put into two 8 bits registers. The lowest byte data (8 LSBs)
are placed in address BASE+4 and the highest byte data (4 MSBs) are
placed in address BASE+5. A DRDY bit is used to indicate the status of the
A/D conversion. When the DRDY goes low, it means an A/D conversion is
complete.

Address : BASE + 4 and BASE + 5
Attribute: read only
Data Format:

Bit 7 6 5 4 3 2 1 0

BASE+4 AD7 AD6 AD5 AD4 AD3 AD2 AD1 AD0
BASE+5 0 0 0 DRDY AD11 AD10 AD9 AD8

AD11 …. AD0: Analog to digital data. AD11 is the Most Significant

Bit(MSB). AD0 is the Least Significant Bit(LSB).

DRDY: Data Ready Signal.

1: A/D data is not ready
0: A/D conversion is completed.
It will be set to 1, when reading the low byte.

4.3 A/D Channel Multiplexer Register

This register is used to control the A/D channels. It's a write only register.
When a channel number is written to the register, the multiplexer switches
to another channel and waits until there’s a conversion and switches again.

Address : BASE + 10
Attribute: write only
Data Format:

Bit 7 6 5 4 3 2 1 0

BASE+10 X X CS1 CS0 CL3 CL2 CL1 CL0

CLn: multiplexer channel number (n=0~3).
CL3 is MSB, and CL0 is LSB.
CS0, CS1: Single-ended and Differential Selection (ACL-8112DG/HG only)

Registers • 31

CS0 and CS1 are used to determine which MPC508A chip is selected. The
MPC508A is used to multiplex between channels, when CS0 is set as 1,
the analog input channels from 0 to 7 are selectable, and when CS1 is set
to 1, channels 8 to 15 are selectable. When both CS0 and CS1 are set to 1,
it means the analog inputs are in differential mode. The possible analog
input channel selections combination is listed in the table below.

For ACL-8112PG, CS0 and CS1 is always set to zero, CL3~CL0 is used to
select the 16 single-ended channels.

Bit

Channel 7 X

S.E. CH0 X X 0 1 0 0 0 0
S.E. CH1 X X 0 1 0 0 0 1
S.E. CH2 X X 0 1 0 0 1 0
S.E. CH3 X X 0 1 0 0 1 1
S.E. CH4 X X 0 1 0 1 0 0
S.E. CH5 X X 0 1 0 1 0 1
S.E. CH6 X X 0 1 0 1 1 0
S.E. CH7 X X 0 1 0 1 1 1

S.E. CH8 X X 1 0 1 0 0 0

S.E. CH9 X X 1 0 1 0 0 1
S.E. CH10 X X 1 0 1 0 1 0
S.E. CH11 X X 1 0 1 0 1 1
S.E. CH12 X X 1 0 1 1 0 0
S.E. CH13 X X 1 0 1 1 0 1
S.E. CH14 X X 1 0 1 1 1 0
S.E. CH15 X X 1 0 1 1 1 1

D.I. CH0 X X 1 1 0 0 0 0
D.I. CH1 X X 1 1 0 0 0 1
D.I. CH2 X X 1 1 0 0 1 0
D.I. CH3 X X 1 1 0 0 1 1
D.I. CH4 X X 1 1 0 1 0 0
D.I. CH5 X X 1 1 0 1 0 1
D.I. CH6 X X 1 1 0 1 1 0
D.I. CH7 X X 1 1 0 1 1 1

S.E.

: Single-ended Analog Input

D.I.

: Differential Analog Input

6

X 5 CS1 4 CS0 3 CL3 2 CL2 1 CL1 0 CL0

32 • Registers

4.4 A/D Range Control Register

The A/D range register is used to adjust the analog input ranges for the
A/D channels. Two factor effects the input range: Gain and Polarity. For
ACL-8112PG, this register controls the PGA (programmable gain) directly
and there is no Unipolar setting. When a different gain value is set, the
analog input range is changed. For the ACL-8112DG/HG, both the PGA
and polarity are controlled by this register. Table 4.2 shows the relationship
between the register data and the A/D input range.

Address : BASE + 9
Attribute: write only
Data Format:

Bit 7 6 5 4 3 2 1 0

BASE+9 X X X X G3 G2 G1 G0

G0 to G3: Gain / Range selection, G3 is not used for ACL-8112PG

(This table is only for the ACL-8112HG: High Gain Card)

G3 G2 G1 G0 GAIN

0 0 0 0 1 Bipolar
0 0 0 1 10 Bipolar
0 0 1 0 100 Bipolar
0 0 1 1 1,000 Bipolar
0 1 0 0 1 Unipolar 0V ~ 10V

0 1 0 1 10 Unipolar 0V ~ 1V
0 1 1 0 100 Unipolar 0V ~ 0.1V
0 1 1 1 1,000 Unipolar 0V ~ 0.01V
1 0 0 0 0.5 Bipolar

1 0 0 1 5 Bipolar
1 0 1 0 50 Bipolar
1 0 1 1 500 Bipolar
1 1 0 0 1 Unipolar N/A

1 1 0 1 10 Unipolar N/A
1 1 1 0 100 Unipolar N/A
1 1 1 1 1,000 Unipolar N/A

Bipolar

or

Unipolar

Input Range

5V

±

0.5V

±

0.05V

±

0.005V

±

10V

±

1V

±

0.1V

±

0.01V

±

Table 4.2-1 Function of the Gain Control Bits

Registers • 33

(This table is only for the ACL-8112DG: Low Gain Card)

G3 G2 G1 G0 GAIN

1 0 0 0 0.5 Bipolar
0 0 0 0 1 Bipolar
0 0 0 1 2 Bipolar
0 0 1 0 4 Bipolar
0 0 1 1 8 Bipolar
0 1 0 0 1 Unipolar 0V ~ 10V

0 1 0 1 2 Unipolar 0V ~ 5V
0 1 1 0 4 Unipolar 0V ~ 2.5V
0 1 1 1 8 Unipolar 0V ~ 1.25V

Table 4.2-2 Function of the Gain Control Bits

For the ACL-8112PG, the maximum range is changed by hardware jumper
configuration. JP9 is used to change the maximum analog input range form

5V or ±10V. If JP9 is set as ±5V, the analog input range is listed as below.

±

G3 G2 G1 G0 GAIN Analog Input Range

0 0 0 0 1
0 0 0 1 2
0 0 1 0 4
0 0 1 1 8
0 1 0 0 16

Bipolar

or

Unipolar

±

2.5V

±

1.25V

±

0.625V

±

0.3125V

±

Input Range

10V

±

5V

±

2.5V

±

1.25V

±

0.625V

±

5V

Table 4.2-3 Analog Input Range ( max. is ±5V)

If JP9 is set as ±10V, the analog input range is listed as below

G3 G2 G1 G0 GAIN Analog Input Range

0 0 0 0 1
0 0 0 1 2
0 0 1 0 4
0 0 1 1 8
0 1 0 0 16

Table 4.2-4 Analog Input Range (max. is ±10V)

34 • Registers

10V

±

5V

±

2.5V

±

1.25V

±

0.625V

±

4.5 A/D Operation Mode Control Register

The A/D operation includes the analog signal conversion and the data
transformation. This register controls the internal trigger mode and data
transformation method. It is initialized by a software trigger or program polling
transfer when the PC is reset or powered on. The details of the A/D operation
are described in Chapter 5. There are four operation modes.

Address : BASE + 11

Attribute: write only

Data Format:

Bit 7 6 5 4 3 2 1 0

BASE+11 X X X X X S2 S1 S0

S2 S1 S0 Operation Mode Description

0 0 0 Internal trigger is disable
0 0 1 software trigger and program polling (default)
0 1 0 timer pacer trigger and DMA transfer
1 1 0 timer pacer trigger and interrupt transfer.

Note:

1. When the system is powered on or reset, the A/D operation will be
initialized as "software trigger or program polling" mode.

2. No matter which mode is selected, the external trigger is available if JP4
is set as external trigger.

3. As long as the DMA mode is not used, the program polling mode is
always selectable. The synchronization of the A/D conversion and data
transfer should be of a concern when using program polling mode.

4. An interrupt will occur at the end of each conversion when the "timer
pacer trigger and interrupt transfer" mode is selected. If you want to use
the pacer trigger and interrupt transfer mode, you must enable the IRQ
level.

Registers • 35

4.6 Interrupt Status Register

The Interrupt Status Register is used to clear the interrupt status so a new
interrupt can be generated. If the ACL-8112 is in interrupt data transfer mode,
a hardware status flag will be set after each A/D conversion. You must clear
the status flag by writing any data to this register, so that the ACL-8112 can
generate a new or next interrupt if a new A/D conversion is to happen.

Address : BASE + 8

Attribute: write only

Data Format:

Bit 7 6 5 4 3 2 1 0

BASE+8 X X X X X X X X

4.7 Software Trigger Register

If you want to generate a trigger pulse for the ACL-8112 to perform an A/D
conversion, you need to write data to this register, this will trigger the A/D
converter.

Address : BASE + 12

Attribute: write only

Data Format:

Bit 7 6 5 4 3 2 1 0

BASE+12 X X X X X X X X

36 • Registers

4.8 Digital I/O register

There are 16 digital input channels and 16 digital output channels provided
by the ACL-8112. The address Base + 6 and Base + 7 are used for the digital
input channels, and the address Base + 13 and Base + 14 are used for digital
output channels.

Address : BASE + 6 & BASE + 7

Attribute: read only

Data Format:

Bit 7 6 5 4 3 2 1 0

Base + 6 DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
Base + 7 DI15 DI14 DI13 DI12 DI11 DI10 DI9 DI8

Address : BASE + 13 & BASE + 14

Attribute: write only

Data Format:

Bit 7 6 5 4 3 2 1 0

Base + 13 DO7 DO6 DO5 DO4 DO3 DO2 DO1 DO0
Base + 14 DO15 DO14 DO13 DO12 DO11 DO10 DO9 DO8

Registers • 37

4.9 D/A Output Register

The D/A converter will convert the D/A output register data to an analog
signal. The register data at address Base + 4 and Base + 5 are used for D/A
channel 1 and Base +6 and Base +7 for D/A channel 2.

Address : BASE + 4 & BASE + 5

Attribute: write only

Data Format: (for D/A Channel 1)

Bit 7 6 5 4 3 2 1 0

Base + 4 DA7 DA6 DA5 DA4 DA3 DA2 DA1 DA0
Base + 5 X X X X DA11 DA10 DA9 DA8

Address : BASE + 6 & BASE + 7

Attribute: write only

Data Format: (for D/A Channel 2)

Bit 7 6 5 4 3 2 1 0

Base + 6 DA7 DA6 DA5 DA4 DA3 DA2 DA1 DA0

Base + 7 X X X X DA11 DA10 DA9 DA8
DA0 is the LSB and DA11 is the MSB of the 12 bits data.
X: does not matter

Note:

The D/A registers are "double buffered" so that the D/A analog output
signals will not updated until the second (high) byte contains data or
written to. This will ensure a single step transition for a D/A conversion.

38 • Registers

4.10 Internal Timer/Counter Register

Two 8254 counters are used for periodical triggering of the A/D converter,
with one left for user applications. The 8254 occupies four I/O address
locations in the ACL-8112 as listed below. Users may refer to NEC's or Intel's
data sheet for full detail of the 8254. A summary of the information is
specified in Appendix B.

Address : BASE + 0 ~ BASE + 3

Attribute:

Data Format:

read / write

Base + 0 Counter 0 Register ( R/W)
Base + 1 Counter 1 Register ( R/W)
Base + 2 Counter 2 Register ( R/W)
Base + 3 8254 CONTROL BYTE

Registers • 39

5

Operation Theory

The operation theory of the ACL-8112 card is described in this chapter. The
function description includes the A/D conversion, D/A conversion, digital I/O
and counter/timer. The operation theory can assist the user understand how
to manipulate or program the ACL-8112.

5.1 A/D Conversion

Before programming the ACL-8112 to perform an A/D conversion, you need
to understand the following issues:

• A/D conversion procedure

• A/D trigger mode

• A/D data transfer mode

• Signal Connection

A/D Conversion Procedure

An A/D conversion is initiated when a trigger source is triggered, the A/D
converter will start to convert the signal to a digital value. The ACL-8112
provides three trigger modes as discussed below.

During an A/D conversion, the DRDY bit of the A/D data register is cleared to
indicate the data is not ready. After a conversion is completed, the DRDY bit
will return a low (0) signal. This indicates users now can read the converted
data from the A/D data registers. Please refer to section 4.2 for the A/D data
format.

Operation Theory • 41

The A/D data should now be transferred into the PC's memory for further
processing. The ACL-8112 provides three data transfer modes that allow
users to optimize their DAS system. Refer to section 5.1.3 for data transfer
modes.

A/D Trigger Modes

The ACL-8112’s A/D conversion can be triggered by either an Internal or
External trigger source. JP5 is used to set either internal or external triggers.

Please refer to section 2.8 for details. Whenever an external source is set,
the internal sources are disabled.

The two internal sources can either be software or timer pacer triggered
which is controlled by the A/D operation mode control register (BASE+11). In
total there are three different trigger sources available to the ACL-8112. The
trigger conditions are described below:

Software trigger

This trigger source is software controllable. That is, the A/D conversion is
initiated when any value is written into the software trigger register
(BASE+12). This trigger mode is suitable for low speed A/D conversions.
Under this mode, the timing of the A/D conversion is fully controlled by the
software. However, it is difficult to have total control over a fixed A/D
conversion rate unless another timer interrupt service routine is used to
generate a fixed trigger rate.

Timer Pacer Trigger

An onboard 8254 timer/counter chip is used to provide a trigger source for
the A/D conversion at a fixed rate. Two counters are cascaded together to
generate a trigger pulse at precise intervals. Refer to section 5.4 for details of
the 8254 architecture. This mode is ideal for high speed A/D conversions. It
can be combined with DMA or interrupt data transfer. It is recommended that
this mode be used for applications that require a fixed and precise A/D
sampling rate.

External Trigger

Through pin-17 of CN3 (ExtTrig), the A/D conversion can also be performed
when a rising edge from an external source occurs. The conversion rate of
this mode is more flexible than the previous two modes, because users can
easily control an external device. An external trigger can be combine with
DMA transfer, interrupt data transfer, or even program polling data transfer.
Generally, the interrupt data transfer is used when external trigger mode is
used.

42 • Operation Theory

A/D Data Transfer Modes

On the ACL-8112, there are three A/D data transfer modes that can be used
when A/D conversion is completed. The data transfer mode is controlled by
the mode control register (BASE+11). The transfer modes are described
below:

Software Data Transfer

Usually, this mode is used with software A/D trigger mode. After the A/D
conversion is triggered by the software, the software will poll the DRDY bit
until it becomes high. Whenever the low byte of the A/D data is read, the
DRDY bit will be cleared to indicate the data has been read.

It is possible to read the A/D converted data without polling. The A/D
conversion time will not excess 8µs on the ACL-8112 card. Hence, after a
software trigger, the software can wait for at least 8µs then read the A/D
register without polling.

Interrupt Transfer

The ACL-8112 provides hardware interrupt capability. Under this mode, an
interrupt signal is generated when an A/D conversion has ended and the data
is ready to be read. It is useful to combine the interrupt transfer mode with
the timer pacer trigger mode. Under this combination, the data transfer is
essentially asynchronous with the controlling software.

When the interrupt transfer mode is used, you have to set the interrupt IRQ
level using hardware jumpers. Refer to section 2.10 for IRQ jumper setting.
After an A/D conversion is completed, a hardware interrupt will be inserted
and its corresponding ISR (Interrupt Service Routine) will be invoked and
executed. The converted data is transferred by the ISR program.

DMA Transfer

The DMA (Direct Memory Access) allows data to be transferred directly
between the ACL-8112 and the PC memory at the fastest possible rate,
without using any CPU time. The A/D data is automatically transferred to
PC's memory after conversion is completed.

The DMA transfer mode is very complex to program. It is recommended that
a high level programming library be used to operate this card in this mode. If
you wish to program a software which can handle DMA data transfer, refer to
information about the 8237 DMA controller.

Operation Theory • 43

5.2 D/A Conversion

The operation of the D/A conversion is simpler than the A/D operation. You
only need to write the digital values into the D/A data registers and the
corresponding voltage will be outputted through AO1 or AO2. Refer to
section 4.9 for information about the D/A data registers. The mathematical
relationship between the digital number DAn and the output voltage is
formulated as follows:

Vout Vref

=− ×

where Vref is the reference voltage, Vout is the output voltage, and DAn is
the digital value in the D/A data registers.

Before performing the D/A conversion, users should be aware of the D/A
reference voltage which is set by JP1, JP2 and JP3. Please refer to section

2.11 for jumper setting. The reference voltage will effect the output voltage. If
the reference voltage is -5V, the D/A output scaling will be from 0 to 5V. If the
reference voltage is -10V, the D/A output scaling will be 0 to 10V.

Note that the D/A registers are "double buffered" so that the D/A analog
output signals will not be updated until the high byte is written. When writing
12-bit data to the D/A registers, the low byte must be written to first before
the high byte. This procedure will ensure a single step transition for a D/A
conversion.

DAn

4096

5.3 Digital Input and Output

To program the digital I/O operation is fairly straight forward. The digital input
operation just reads data from its corresponding registers, and the digital
output operation just writes data to its corresponding registers. The digital I/O
registers are shown in section 4.9. Note that the DIO data channel can only
be read or written in forms of 8-bits. It is impossible to access individual bits.

44 • Operation Theory

5.4 Timer/Counter Operation

The ACL-8112 has an 8254 interval timer/counter onboard. Refer to section

3.5 for signal connection and the configuration of the counter.

The 8254 Timer / Counter Chip

The Intel (NEC) 8254 contains three independent, programmable, multi­mode 16 bit counter/timers. The three independent 16 bit counters can be
clocked at rates from DC to 5MHz. Each counter can be individually
programmed with six different operating modes by appropriately formatted
control words. The most commonly uses for the 8254 in microprocessor
based systems are:

• programmable baud rate generator

• event counter

• binary rate multiplier

• real-time clock

• digital one-shot

• motor control

For more information about the 8254, please refer to the NEC
Microprocessors and peripherals or Intel Microsystems Components
Handbook.

Pacer Trigger Source

Counter 1 and 2 are cascaded together to generate a timer pacer trigger for
the A/D conversion. The frequency of the pacer trigger is software
controllable. The maximum pacer signal rate is 2MHz/4=500K which exceeds
the maximum A/D conversion rate of the ACL-8112. The minimum signal rate
is 2MHz/65535/65535, which is a very slow frequency that user may never
use.

General Purpose Timer/ Counter

Counter 0 is free for user applications. The clock source, gate control signal
and the output signal are sent via CN3. The general purpose timer/counter
can be used as an event counter, used for measuring frequency or other
functions. Please refer to 'Timer/Counter Applications' section for examples.

Operation Theory • 45

I/O Address

The 8254 in the ACL-8112 occupies four I/O address as shown below.

BASE + 0 LSB OR MSB OF COUNTER 0
BASE + 1 LSB OR MSB OF COUNTER 1
BASE + 2 LSB OR MSB OF COUNTER 2
BASE + 3 CONTROL BYTE

The programming of the 8254 is control by registers BASE+0 to BASE+3.
The function of each register is specified in this section. For more detailed
information, refer to the 8254 handbook.

Control Byte

Before loading or reading any of these individual counters, the control byte
(BASE+3) must be loaded first. The format of the control byte is:

Bit 7 6 5 4 3 2 1 0

SC1 SC0 RL1 RL0 M2 M1 M0 BCD

SC1 & SC0 - Select Counter ( Bit7 & Bit 6)

SC1 SC0 COUNTER

0 0 Select Counter 0
0 1 Select Counter 1
1 0 Select Counter 2
1 1 ILLEGAL

RL1 & RL0 - Select Read/Load operation ( Bit 5 & Bit 4)

RL1 RL0 OPERATION

0 0 COUNTER LATCH FOR STABLE READ
0 1 READ/LOAD LSB ONLY
1 0 READ/LOAD MSB ONLY
1 1 READ/LOAD LSB FIRST, THEN MSB

46 • Operation Theory

M2, M1 & M0 - Select Operating Mode ( Bit 3, Bit 2, & Bit 1)

M2 M1 M0 MODE

0 0 0 0
0 0 1 1

x 1 0 2

x 1 1 3
1 0 0 4
1 0 1 5

BCD - Select Binary/BCD Counting ( Bit 0)

0

1

Note: The count of the binary counter is from 0 up to 65,535 and the count

Mode Definitions

With the 8254, six operating modes can be selected:

Mode 0

•

Mode 1

•

Mode 2

•

Mode 3

•

Mode 4

•

Mode 5

•

Detail description of these six modes can be found in the Intel Microsystems
Components Handbook Volume II Peripherals.

16-BITS BINARY COUNTER

BINARY CODED DECIMAL (BCD) COUNTER (4
DIGITAL)

of the BCD counter is from 0 up to 9,999

: Interrupt on Terminal Count

: Programmable One-Shot.

: Rate Generator

: Square Wave Rate Generator

: Software Triggered Strobe

: Hardware Triggered Strobe

Operation Theory • 47

6

Calibration & Utilities

With data acquisition processes, knowing how to calibrate your
measurement devices to maintain its accuracy is of high importance. Users
can calibrate the analog input and analog output channels under user’s
operating environment to optimize the accuracy of the equipment. This
chapter will guide you through calibrating the ACL-8112.

6.1 What you need

Equipment required for the calibration of the ACL-8112 card:

• Calibration program: The calibration program 8112util.exe. Once the
program is executed, it will guide you through the calibration
process. This program is included in the delivered package.

• A 5 1/2 digit multimeter (6 1/2 is recommended)

• A voltage calibrator or a very stable and noise free DC voltage

generator.

Calibration & Utilities • 49

6.2 VR Assignment

There are six variable resistors (VR) on the ACL-8112DG/HG board.
These allow the user to make adjustments to the A/D and D/A channels.
The function of each VR is specified as Table 6.1-1.

VR1 A/D full scale adjustment
VR2 A/D bipolar offset adjustment
VR3 D/A channel 1 full scale adjustment
VR4 D/A channel 2 full scale adjustment
VR5 A/D programmable amplifier offset adjustment
VR6 A/D unipolar offset adjustment

Table 6.1-1 Function of VRs in ACL-8112DG/HG

There are five variable resistors (VR) on the ACL-8112PG board. These
allow the user to make adjustment to the A/D and D/A channels. The
function of each VR is specified as Table 6.1-2.

VR1 A/D full scale adjustment
VR2 A/D offset adjustment
VR3 D/A channel 1 full scale adjustment
VR4 D/A channel 2 full scale adjustment
VR5 A/D programmable amplifier offset adjustment

Table 6.1-2 Function of VRs in ACL-8112PG

6.3 D/A Adjustment

D/A CH1 calibration

1. Connect the DVM <+> to CN3.AO1<PIN 30>, and the VDM<-> to

CN3.GND <PIN 10>.

2. Write a digital value into the D/A register (BASE+4 and BASE+5).

3. Trim VR3 until +5 V appears on the DVM.

50 • Calibration & Utilities

D/A CH2 calibration

1. Connect the DVM <+> to CN3.AO2<PIN 32>, and the DVM<-> to
CN3.GND <PIN 10>.

2. Write a digital value into the D/A register (BASE+6 and BASE+7).

3. Trim VR4 until +5 V appears on the DVM.

6.4 A/D Programmable Gain Amplifier adjustments

This setup is to reduce the PGA offset voltage.

1. Connect CN3.AI0 <PIN 2> to CN3.GND <PIN 9>

2. Trim VR5 until the reading displayed on the monitor of the
8112UTIL.exe software is approximately 0 and below 0.50.

6.5 A/D Adjustment

Bipolar Calibration

1. Adjust the voltage calibrator’s voltage output to –4.9987V. Connect
the voltage calibrator’s <+> to CN3.AI0 <PIN 1> and the voltage
calibrator’s<-> to CN3.AGND<PIN 9>.

2. Trim VR2 to obtain a reading that toggles between 0 and 1. This
value is displayed on the monitor of the calibration program
8112UTIL.exe. Then proceed to the next step.

3. Adjust the voltage calibrator’s voltage output to +4.9963V. Connect
the voltage calibrator’s <+> to CN3.AI0 <PIN 1> and the voltage
calibrator’s <-> to CN3.AGND<PIN 9>.

4. Trim VR1 to obtain a reading that toggles between 4094 and 4095.
This value is displayed on the monitor of the calibration program
8112UTIL.exe.

Calibration & Utilities • 51

Unipolar Calibration(Only for ACL-8112DG/HG)

1. Adjust the voltage calibrator’s voltage output to –4.9987V. Connect
the voltage calibrator’s <+> to CN3.AI0 <PIN 1> and the voltage
calibrator’s<-> to CN3.AGND<PIN 9>.

2. Trim VR2 to obtain a reading that toggles between 0 and 1. This
value is displayed on the monitor of the calibration program
8112UTIL.exe. Then proceed to the next step.

3. Adjust the voltage calibrator’s voltage output to +1.22mV. Connect
the voltage calibrator’s <+> to CN3.AI0 <PIN 1> and the voltage
calibrator’s<-> to CN3.AGND<PIN 9>.

4. Trim VR6 to obtain a reading that toggles between 0 and 1. This
value is displayed on the monitor of the calibration program
8112UTIL.exe. Then proceed to the next step

5. Adjust the voltage calibrator’s voltage output to +9.9963V. Connect
the voltage calibrator’s <+> to CN3.AI0 <PIN 1> and the voltage
calibrator’s<-> to CN3.AGND<PIN 9>

6. Trim VR1 to obtain a reading that toggles between 4094 and 4095.
This value is displayed on the monitor of the calibration program
8112UTIL.exe.

A calibration utility software diskette is included in the product package.
Detail calibration procedures and description can be found in the utility.
Users need to execute the calibration utility and follow the procedures
carefully to obtain best results and accurate measurements.

52 • Calibration & Utilities

7

C Language Library

There are 23 call functions available in the C programming Library, all
functions associated with the ACL-8112 are covered, it includes A/D
conversions, D/A conversions, Digital Inputs and Outputs, etc.

Much of the programming time is saved under the C Language library. The
library also covers support for data collection on the interrupt or DMA from
the internal time clock for A/D conversions. Note that the DMA data transfer
processes only on a fixed A/D channel.

Example programs are also included in this disk, this will help fast track users
to understand the library. A detailed description of each function in the library
is discussed in the following sections.

Note that each function name uses the following conventions:

_8112XX_function(). Where XX is substituted for the particular 8112 model.
For example ACL-8112DG, ACL-8112HG and ACL-8112PG.

C Language Library • 53

7.1 _8112_Initial

Description

All ACL-8112 cards are initialized according to its card number and its
corresponding base address. Every ACL-8112 Multi-Function Data
Acquisition Card must be initialized using this function before any other
function calls are permitted.

Syntax

int _8112_Initial(int card_number, int type, int

base_addresss )

int _8112pg_Initial(int card_number, int

base_addresss )

Argument:

card_number:

Type :

A8112B_HG: 8112 High Gain card Ver. B

A8112B_DG: 8112 Low Gain card Ver. B
A8112C_HG: 8112 High Gain card Ver. C
A8112C_DG: 8112 Low Gain card Ver. C
Note: the difference between Ver.B and

base_address:

Return Code:

ERR_NoError
ERR_InvalidBoardNumber
ERR_BaseAddressError

the card number to be initialized, only

two cards can be initialized, the card
number must be CARD_1 or CARD_2.
there are 4 different types of ACL-8112

cards, they are:

Ver.C is the Multi-Scan Register. The
control code for each version is
slight different. For details, please
refer to the hardware manual for the
specific ACL-8112 card.

the I/O port base address of the card

is set at 220 Hex default.

54 • C Language Library

Example:

#include "8112.h"

main()
{
int ErrCode;

Errcode = _8112_Initial( CARD_1, A8112B_HG, 0x210 );
if ( ErrCode != ERR_NoError )
exit(0);

ErrCode = _8112_Initial( CARD_2, A8112B_DG, 0x220 );
if ( ErrCode != ERR_NoError )
exit(0);
.
.
.
}

C Language Library • 55

7.2 _8112_Switch_Card_No

Description

This function is used on a system that has two ACL-8112 cards inserted.
After initializing the two ACL-8112 cards, this function is called upon to
select the default card.

Note:

This library only has support for two ACL-8112 because only two DMA
channels are supported by the card.

Syntax

int _8112_Switch_Card_No(int card_number)
int _8112pg_Switch_Card_No(int card_number)

Argument:

card_number:

Return Code:

ERR_NoError
ERR_InvalidBoardNumber

Example:

#include “8112.h”

main()

{

}

The card number to be initialized, only

two cards can be initialized, the card
number must be CARD_1 or CARD_2.

_8112_Initial( CARD_1, A8112B_HG, 0x210 );
_8112_Initial( CARD_2, A8112B_DG, 0x220 );
/* Assume NoError when Initialize ACL-8112 */

_8112_Switch_Card_No( CARD_1 );

/*..... You can perform certain functions

to Card_1 here*/

_8112_Switch_Card_No( CARD_2 );

/*..... You can perform certain functions

to Card_2 here*/

56 • C Language Library

7.3 _8112_DI

Description

This function is used to read data from the digital input port. There are
16 bits available for the digital inputs. Bit 0 to bit 7 of the register is
defined as the low byte and bit 8 to bit 15 are defined as the high byte.

Syntax

int _8112_DI( int port_number, unsigned char *data )
int _8112pg_DI( int port_number, unsigned char *data )

Argument:

port_number:

DI_LO_BYTE
or DI_HI_BYTE.
DI_LO_BYTE: bit 0 ~ bit 7,
DI_HI_BYTE: bit8 ~ bit15

data:

return value from digital port.

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_PortError

To indicate which port is read,

Example:

See Demo program . Demo Program 'DI_DEMO.C'

C Language Library • 57

7.4 _8112_DI _Channel

Description

This function is used to read data from the digital input channels (bit).
There are 16 digital input channels on the ACL-8112. When performing
this function, the digital input port is read and the value of the
corresponding channel is returned.

* channel means each bit of the digital input ports.

Syntax

int _8112_DI_Channel(int di_ch_no, unsigned int
*data )
int _8112pg_DI(int di_ch_no, unsigned int *data )

Argument:

di_ch_no:

data:

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_InvalidDIChannel

the DI channel number, the value is

between from 0 to 15.

return value, either 0 or 1.

Example:

#include “8112.h”

main()
{
unsigned int data;
int ch;

_8112_Initial( CARD_1, A8112B_HG, 0x220 );
/* Assume NoError when Initialize ACL-8112 */
.
.
for( ch=0; ch<16; ch++ )
{
_8112_DI_Channel( ch , &data );
printf( "The value of DI channel %d is
%d.\n" , ch , data );
}

}

58 • C Language Library

7.5 _8112_DO

Description

This function is used to write data to the digital output port. There are 16
digital outputs on the ACL-8112, they are divided into two categories,
DO_LO_BYTE and DO_HI_BYTE. Channel 0 to channel 7 is defined as
the DO_LO_BYTE port and channels 8 to 15 are defined as the
DO_HI_BYTE port.

Syntax

int _8112_DO(int port_number, unsigned char data )
int _8112pg_DO(int port_number, unsigned char data )

Argument:

port_number:
data:

value will be written to digital output port

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_PortError

Example:

#include “8112.h”

main()
{

_8112_Initial( CARD_1, A8112B_DG, 0x220 );
/* Assume NoError when Initialize ACL-8112/DG ver.B
card */
.
.
_8112_DO( DO_LO_BYTE , 0x55 );
printf( "The low byte is now 0x55.\n" );

_8112_DO( DO_HI_BYTE , 0xAA );
printf( "The high byte is now 0xAA.\n" );

}

A more detailed program is provided in this software
'DO_DEMO.C'

DO_LO_BYTE or DO_HI_BYTE

C Language Library • 59

7.6 _8112_DA

Description

This function is used to write data to the D/A converter. There are two
Digital-to-Analog conversion channels on the ACL-8112. The resolution
of each channel is 12-bit, thus the digital data ranges is from 0 to 4095.

Syntax

int _8112_DA(int da_ch_no, unsigned int data )
int _8112pg_DA(int da_ch_no, unsigned int data )

Argument:

da_ch_no:

data:

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_InvalidDAChannel

Example:

#include “8112.h”

main()
{

_8112_Initial( CARD_1, A8112B_DG, 0x220 );
/* Assume NoError when Initialize ACL-8112 */
/* if the hardware setting for DA output range
is 0~5V */

_8112_DA( DA_CH_1 , 0x800 );
printf( "The output voltage of CH1 is 2.5V \n" );

_8112_DA( DA_CH_2 , 0xFFF );
printf( "The output voltage of CH2 is 5V \n" );

}A more complete program is provided in this software.
'DA_DEMO.C'

D/A channel number, DA_CH_1 or DA_CH_2.

D/A converted value, if the value is greater

than 4095, the higher 4-bits are negligent.

60 • C Language Library

7.7 _8112_AD_Input_Mode

Description

This function is only used with the ACL-8112 ver. B series.

The ACL-8112 offers either 16 single-ended analog input channels or
eight differential analog input channels. If the ACL-8112 ver B card is
used, you have to call this function to initialize the A/D operation.

Syntax

int _8112_AD_Input_Mode( int ad_mode )

Argument:

ad_ch_mode:

SINGLE_ENDED

mode.

DIFFERENTIAL

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_InvalidADChannel

Example:

#include “8112.h”

main()
{
int j;

_8112_Initial( CARD_1, A8112B_DG, 0x210 );
/* Assume ERR_NoError when Initialize ACL-8112 */

_8112_Initial( CARD_2, A8112B_HG, 0x220 );
/* Assume ERR_NoError when Initialize ACL-8112 */

_8112_AD_Input_Mode( DIFFERENTIAL) ;
/* set analog input mode as “differential” mode */
/* if this function is not called, the default input
mode is single-ended mode */

: the analog inputs are single-ended

: the analog inputs are differential.

C Language Library • 61

for( j = 0; j < 7 ; j++)
{
_8112_AD_Set_Channel( j );

printf( "AD channel %d is now selected.\n“, j );
}
_8112_Switch_Card_No(CARD_1);
_8112_AD_Input_Mode( SINGLE_ENDED) ;
for( j = 0; j < 7 ; j++)
{
_8112_AD_Set_Channel( j );

printf( "AD channel %d is now selected.\n“, j );
}
/* the following A/D's operation is based on channel
3 */
}

62 • C Language Library

7.8 _8112_AD_Set_Channel

Description

This function is used to set the AD channel by means of writing data to
the multiplexer scan channel register. There are 16 single-ended A/D
channels for the ACL-8112, so the channel number must be set
between 0 and 15. The initial state is channel 0, which is the default
setting for the ACL-8112.

Syntax

int _8112_AD_Set_Channel( int ad_ch_no )
int _8112pg_AD_Set_Channel( int ad_ch_no )

Argument:

ad_ch_no:

for single-ended mode: 0-15
for differential mode: 0-7

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_InvalidADChannel

Number of channels to perform AD

conversions:

Example:

#include “8112.h”
main()
{
_8112_Initial( CARD_1, A8112B_DG, 0x220 );
/* Assume NoError when Initialize ACL-8112 */

_8112_AD_Input_Mode( DIFFERENTIAL) ;
/* set analog input mode as “differential” mode */

_8112_AD_Set_Channel( 3 );
printf( "AD channel 3 is now selected.\n" );

...

/* the following A/D's operation is based on channel
3 */
}

C Language Library • 63

7.9 _8112_AD_Set_Range

Description

This function is used to set the A/D analog input range by means of writing
data to the A/D range control register. There are two factors that will effect
the analog input range - Gain and Input type.

The Gain can be any of the following factors 0.5, 1, 5, 10, 50, 100, 500,
and 1,000 for the ACL-8112HG card.

The input type is either Bipolar or Unipolar.

The initial value of the gain is '1‘ and input type is bipolar, which is pre-set
by the ACL-8112 hardware. The relationship between analog input voltage
range, gain and input mode are specified in the following tables:

** this table only applies to the ACL-8112HG ( high gain) card.

AD_INPUT

AD_B_5_V 1 Bipolar

AD_B_0_5_V 10 Bipolar

AD_B_0_05_V 100 Bipolar

AD_B_0_005_V 1,000 Bipolar

AD_U_10_V 1 Unipolar 0V ~ 10V

AD_U_1_V 10 Unipolar 0V ~ 1V

AD_U_0_1_V 100 Unipolar 0V ~ 0.1V

AD_U_0_01_V 1,000 Unipolar 0V ~ 0.01V

AD_B_10_V 0.5 Bipolar

AD_B_1_V 5 Bipolar

AD_B_0_1_V 50 Bipolar

AD_B_0_01_V 500 Bipolar

GAIN

Input type

(Bipolar or

Unipolar)

Input Range

±5V

±0.5V

±0.05V

±0.005V

±10V

±1V

±0.1V

±0.01V

64 • C Language Library

For the ACL-8112DG card, the gain values supported are 1, 2, 4, and 8.
The relationship between analog input voltage range, gain and input
type are specified in the table below.

** this table only applies for the ACL-8112DG ( low gain) card.

Input type

AD_INPUT GAIN

AD_B_5_V 1 Bipolar

AD_B_2_5_V 2 Bipolar

AD_B_1_25_V 4 Bipolar

AD_B_0_625_V 8 Bipolar

AD_U_10_V 1 Unipolar 0V to 10V

AD_U_5_V 2 Unipolar 0V to 5V

AD_U_2_5_V 4 Unipolar 0V to 2.5V

AD_U_1_25_V 8 Unipolar 0V to 1.25V

For the ACL-8112PG card, the gain values supported are 1, 2, 4, 8, and

16.

The initial value of the gain is '1'. The relationship between gain and
input voltage ranges is specified by following tables:

When input voltage range is set to ±5 V (JP9),

Gain Code Gain Input Range (V)
AD_GAIN_1 X 1
AD_GAIN_2 X 2
AD_GAIN_4 X 4
AD_GAIN_8 X 8
AD_GAIN_16 X 16

When input voltage range is set to ±10 V(JP9),

Gain Code Gain Input Range (V)
AD_GAIN_1 X 1
AD_GAIN_2 X 2
AD_GAIN_4 X 4
AD_GAIN_8 X 8
AD_GAIN_16 X 16

(Bipolar or

Unipolar)

±5 V
±2.5 V
±1.25 V
±0.625 V
±0.3125V

±10 V
±5 V
±2.5 V
±1.25 V
±0.625 V

Input Range

±5V

±2.5V

±1.25V

±0.625V

C Language Library • 65

Syntax

int _8112_AD_Set_Range( int ad_range )
int _8112pg_AD_Set_Gain( int ad_range )

Argument:

int ad_range: the programmable range of A/D
conversion, pleas refer to above tables for the
possible values .

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_AD_InvalidRange

Example:

#include “8112.h”
main()
{
_8112_Initial( CARD_1, A8112B_HG, 0x220 );
/* Assume NoError when Initialize ACL-8112 */

_8112_AD_Input_Mode( DIFFERENTIAL) ;
/* set analog input mode as “differential” mode */

_8112_AD_Set_Range( AD_B_5_V );
printf( "The A/D analog input range is +/- 5V \n" );

for( j = 0; j < 7; j++)
{
_8112_AD_Set_Channel( j );
printf( "AD channel j is now selected.\n" );

/* all analog input operations are based on
analog differential mode,
input range is from -5V to +5V */
}
...
}

66 • C Language Library

7.10 _8112_AD_Set_Mode

Description

This function is used to set the A/D trigger and data transfer mode by
means of writing data to the mode control register. The hardware initial
state for the ACL-8112 is set as AD_MODE_1 software (internal) trigger
with program polling data mode.

A/D Mode Description

AD_MODE_0 External Trigger, Software Polling
AD_MODE_1 Software Trigger, Software Polling
AD_MODE_2 Timer Trigger, DMA Transfer
AD_MODE_3 External Trigger, DMA Transfer
AD_MODE_4 External Trigger, Interrupt Transfer
AD_MODE_5 Software Trigger, Interrupt Transfer
AD_MODE_6 Timer Trigger, Interrupt Transfer
AD_MODE_7 Not Used

Note:

All analog input modes selection should match with the hardware

settings, which is described in the hardware users manual.

Syntax

int _8112_AD_Set_Mode(int ad_mode )
int _8112pg_AD_Set_Mode(int ad_mode )

Argument:

ad_mode:

( please refer above table.)

AD trigger and data transfer mode

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_InvalidMode

C Language Library • 67

Example:

#include “8112.h”

main()
{
_8112_Initial( CARD_1, A8112B_HG, 0x220 );
/* Assume NoError when Initialize ACL-8112 */

_8112_AD_Input_Mode( DIFFERENTIAL) ;
/* set analog input mode as “differential” mode */

_8112_AD_Set_Range( AD_B_5_V );
printf( "The A/D analog input range is +/- 5V \n" );

_8112_AD_Set_Mode( AD_MODE_6 );
printf( "Now, disable internal trigger.\n" );

/* All A/D conversion will be trigger by internal
timer pacer, and the converted data should be
transfered in the interrupt service routine. ( ISR).
*/

}

68 • C Language Library

7.11 _8112_AD_Soft_Trig

Description

This function is used to trigger an A/D conversion using software trigger.
When the function is called, a trigger pulse will be generated and the
converted data will be stored at base address Base+4 and Base+5, and
can be retrieved using function _8112_AD_Acquire(). Refer to section

7.12.

Syntax

int _8112_AD_Soft_Trig( void )
int _8112pg_AD_Soft_Trig( void )

Argument:

None

Return Code:

ERR_NoError
ERR_BoardNoInit

Example:

#include “8112.h”

main()
{
_8112_Initial( CARD_1, 8112DG, 0x220 );
/* Assume NoError when Initialize ACL-8112 */

_8112_AD_Soft_Trig();
printf( "Now, AD is triggered.\n" );
.
.
_8112_AD_Aquire( &data);

}

C Language Library • 69

7.12 _8112_AD_Aquire

Description

This function is used to poll an AD conversion. It will trigger an AD
conversion, and read a 12-bit A/D data when the data is ready ('data
ready' bit becomes low).

Syntax

int _8112_AD_Aquire( int *ad_data )
int _8112pg_AD_Aquire( int *ad_data )

Argument:

ad_data:

should
within 0 to 4095.

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_AD_AquireTimeOut

Example:

#include “8112.h”
main()
{
int ad_data;
int ErrCode;

_8112_Initial( CARD_1, 8112B-DG, 0x220 );
/* Assume NoError when Initialize ACL-8112 */

/* Set to software trigger at first*/
_8112_AD_Set_Mode( AD_MODE_1 );
/* then trigger the AD */
_8112_AD_Soft_Trig();
/* wait for AD data ready then read it */
ErrCode = _8112_AD_Aquire( &ad_data );
if( ErrCode == ERR_NoError )
printf( "The AD value is %d.\n", ad_data );
else
printf( "AD conversion error happen\n" );
}
Also see deme program 'AD_DEMO.C'

12-bit A/D converted value, the value

70 • C Language Library

7.13 _8112_CLR_IRQ

Description

This function is used to clear an interrupt request which gets requested
by the ACL-8112. If an interrupt is used to transfer an A/D converted
data, this function should be used to clear the interrupt request status,
otherwise new interrupts will not be generated.

Syntax

int _8112_CLR_IRQ( void )
int _8112pg_CLR_IRQ( void )

Argument:

None

Return Code:

ERR_NoError
ERR_BoardNoInit

C Language Library • 71

7.14 _8112_AD_DMA_Start

Description

The function will perform an A/D conversion N times with DMA data
transfer using the pacer trigger (internal timer trigger). It takes place in
the background and will not stop until the Nth conversion has been
performed or your program executes the _8112_AD_DMA_Stop()
function to stop the process. After executing this function, it is
necessary to check the status of the operation by using the function
_8112_AD_DMA_Status(). This function can only be performed on an
A/D channel with a fixed analog input range.

Syntax

int _8112_DMA_Start( int ad_ch_no, int ad_range,
intdma_ch_no, int irq_ch_no
int count , int *ad_buffer
unsigned int c1, unsigned int c2)
int _8112pg_DMA_Start( int ad_ch_no, int ad_gain,
intdma_ch_no, int irq_ch_no
int count , int *ad_buffer
unsigned int c1, unsigned int c2)

Argument:

ad_ch_no:

ad_range:

dma_ch_no

A/D channel number

A/D analog input range, please refer to

the Section 7.9 to find the possible
values.

: DMA channel number, DMA_CH_1 or DMA_CH_3

Note:

Make sure your hardware configuration is set to the correct DMA
channel.

irq_ch_no

Note:

Make sure your hardware configuration is set to the correct IRQ

interrupt level.

72 • C Language Library

: IRQ channel number, used to stop DMA

count:

ad_buffer:

c1:

c2:

the number of A/D conversion

the start address of the memory buffer

to store the AD data, the buffer size
must large than the numbers of AD
conversion.

the 16-bit timer frequency divider of

timer channel #1

the 16-bit timer frequency divider of

timer channel #2

Return Code:

ERR_NoError
ERR_BoardNoInit,
ERR_InvalidADChannel,
ERR_AD_InvalidRange,
ERR_InvalidDMAChannel,
ERR_InvalidIRQChannel,
ERR_InvalidTimerValue

Example:

See Demo Program 'AD_Demo4.C

C Language Library • 73

7.15 _8112_AD_DMA_Status

Description

Since the _8112_AD_DMA_Start function is executed in the
background, the function _8112_AD_DMA_Status can be issued to
check its operation status.

Syntax

int _8112_AD_DMA_Status( int *status , int *count )
int _8112pg_AD_DMA_Status( int *status , int *count )

Argument:

status:

0: AD DMA is not completed
1: AD DMA is completed

count:

transferred.

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_AD_DMANotSet

Example:

See demo program 'AD_Demo4.C'

status of the DMA data transfer

the number of A/D data which has been

74 • C Language Library

7.16 _8112_AD_DMA_Stop

Description

This function is used to stop the DMA data transfer. After executing this
function, the internal A/D trigger is disabled and the A/D timer (timer #1
and #2) is stopped. The function returns the number of data’s which
have been transferred, regardless if the A/D DMA data transfer is
stopped by this function or by the DMA terminal count ISR.

Syntax

int _8112_AD_DMA_Stop( int *count )
int _8112pg_AD_DMA_Stop( int *count )

Argument:

count:

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_AD_DMANotSet

Example:

See demo program 'AD_Demo4.C'

the number of A/D converted data which

has beentransferred.

C Language Library • 75

7.17 _8112_AD_INT_Start

Description

The function will perform an A/D conversion N times with interrupt data
transfer using the pacer trigger. It takes place in the background which
will not stop until the Nth conversion is completed or the program
executes the _8112_AD_INT_Stop() function to stop the process. After
executing this function, it is necessary to check the status of the
operation by issuing the 8112_AD_INT_Status() function. The function
can only be performed on an A/D channel with a fixed analog input
range.

Syntax

int _8112_INT_Start( int ad_ch_no, int ad_range,
int irq_ch_no, int count, int
*ad_buffer, unsigned int c1, unsigned int c2)
int _8112pg_INT_Start( int ad_ch_no, int ad_gain,
int irq_ch_no, int count, int
*ad_buffer, unsigned int c1, unsigned int c2)

Argument:

ad_ch_no
ad_range

irq_ch_no

count:

ad_buffer:

c1:

timer channel #1

c2:

timer channel #2

: A/D channel number
: A/D analog input range, please refer

to section 7.9 for the possible
values.

: IRQ channel number, used to stop DMA

the number of A/D conversion

the start address of the memory buffer

to store the A/D data, the buffer
size must be larger than the number
of A/D conversions.

the 16-bit timer frequency divider of

the 16-bit timer frequency divider of

76 • C Language Library

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_InvalidADChannel
ERR_AD_InvalidRange
ERR_InvalidIRQChannel
ERR_InvalidTimerValue

Example:

See demo Program 'AD_Demo2.C'

7.18 _8112_AD_INT_Status

Description

Since the _8112_AD_INT_Start() function is executed in the
background, the function _8112_AD_INT_Status can be used to check
the status of the interrupt operation.

Syntax

int _8112_AD_INT_Status( int *status , int *count )
int _8112pg_AD_INT_Status( int *status , int *count )

Argument:

status:

0: A/D INT is completed
1: A/D INT is not completed

count:

status of the INT data transfer

current conversion count number.

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_AD_INTNotSet

Example:

See demo program 'AD_Demo2.C'

C Language Library • 77

7.19 _8112_AD_INT_Stop

Description

This function is used to stop the interrupt data transfer function. After
executing this function, the internal AD trigger is disabled and the AD
timer is stopped. The function returns the number of data which has
been transferred, regardless of whether the AD interrupt data transfer is
stopped by this function or by the _8112_AD_INT_Start() itself.

Syntax

int _8112_AD_INT_Stop( int *count )
int _8112pg_AD_INT_Stop( int *count )

Argument:

count: the number of A/D data which has been
transferred.

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_AD_INTNotSet

Example:

See Demo Program 'AD_Demo2.C'

78 • C Language Library

7.20 _8112_AD_Timer

Description

This function is used to setup Timer #1 and Timer #2.

Timer #1 & #2 are used as frequency dividers for generating constant
A/D sampling rate. It is possible to stop the pacer trigger by setting any
one of the dividers to 0. The AD conversion rate is limited by the
conversion time of the AD converter, the highest sampling rate of the
ACL-8112 can not exceed 100KHz, thus the multiplication of the
dividers must be larger than 20.

Syntax

int _8112_AD_Timer( unsigned int c1 , unsigned int
c2 )
int _8112pg_AD_Timer( unsigned int c1 , unsigned int
c2 )

Argument:

c1: frequency divider of timer #1
c2: frequency divider of timer #2,

Note:

The A/D sampling rate is equal to: 2MHz / (c1 * c2), if c1 = 0 or c2 =
0, the pacer trigger will be stopped.

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_InvalidTimerValue

Example:

main()
{
int ErrCode;
_8112_Initial( CARD_1, A8112B_HG, 0x220 );
/* Assume ERR_NoError when Initialize ACL-8112 */

_8112_AD_Timer( 10 , 10 );
/* set AD sampling rate to 2MHz/(10*10) */
..
_8112_AD_Timer( 0 , 0 );
/* stop the pacer trigger */
}

C Language Library • 79

7.21 _8112_TIMER_Start

Description

Timer #0 on the ACL-8112 is freely available to be programmed by the
users. This function is used to program Timer #0. This timer can be
used as a frequency generator if an internal clock is used. It can also be
used as an event counter if an external clock is used.

Syntax

int _8112_TIMER_Start( int timer_mode, unsigned int
c0 )
int _8112pg_TIMER_Start( int timer_mode, unsigned int
c0 )

Argument:

timer_mode:

values are:
TIMER_MODE0, TIMER_MODE1,
TIMER_MODE2, TIMER_MODE3,
TIMER_MODE4, TIMER_MODE5.

c0:

the counter value of timer

Return Code:

ERR_NoError
ERR_BoardNoInit
ERR_InvalidTimerMode
ERR_InvalidTimerValue

the 8253 timer mode, the possible

Example:

See demo program 'TMR_DEMO.C'

80 • C Language Library

7.22 _8112_TIMER_Read

Description

This function is used to read the counter value of Timer #0.

Syntax

int _8112_TIMER_Read( unsigned int *counter_value )
int _8112pg_TIMER_Read( unsigned int *counter_value )

Argument:

counter_value:

the counter value of the Timer #0

Return Code:

ERR_NoError
ERR_BoardNoInit

Example:

See demo program 'TMR_DEMO.C'

7.23 _8112_TIMER_Stop

Description

This function is used to stop the timer operation. The timer is set to
'One-shot' mode with counter value ' 0 '. That is, the clocks’ output
signal will be set high after executing this function.

Syntax

int _8112_TIMER_Stop( unsigned int *counter_value )
int _8112pg_TIMER_Stop( unsigned int *counter_value )

Argument:

*counter_value: the current counter value of the
Timer #0

Return Code:

ERR_NoError
ERR_BoardNoInit

Example:

See demo program 'TMR_DEMO.C'

C Language Library • 81

Appendix A. Demo Programs

In this software CD, there are eight example programs provided. Using the C
Language Library would greatly assist with programming applications. The
programs are described below:

AD_DEMO1.C:

AD_DEMO2.C

AD_DEMO3.C: A/D conversion using DMA data transfer.

AD_DEMO4.C:

DA_DEMO.C: D/A conversion

DI_DEMO.C: Read data from digital input channels

DO_DEMO.C: Write data to digital output channels

TMR_DEMO.C: Handle 8253 Timer/Counter

A/D conversion using software trigger and program
data transfer.
A/D conversion using interrupt and program data
transfer.

A/D conversion using multiple channels and input
range programmable, trigger using the PC timer,
and saves all data to a file called 'ad_demo4.data'.

Demo Programs • 83

Warranty Policy

Thank you for choosing ADLINK. To understand your rights and enjoy all the
after-sales services we offer, please read the following carefully.

1. Before using ADLINK’s products please read the user manual and follow
the instructions exactly. When sending in damaged products for repair,
please attach an RMA application form which can be downloaded from:
http://rma.adlinktech.com/policy/.

2. All ADLINK products come with a limited two-year warranty, one year for
products bought in China.

• The warranty period starts on the day the product is shipped from

ADLINK’s factory.

• Peripherals and third-party products not manufactured by ADLINK will

be covered by the original manufacturers' warranty.

• For products containing storage devices (hard drives, flash cards,

etc.), please back up your data before sending them for repair.
ADLINK is not responsible for any loss of data.

• Please ensure the use of properly licensed software with our systems.

ADLINK does not condone the use of pirated software and will not
service systems using such software. ADLINK will not be held legally
responsible for products shipped with unlicensed software installed by
the user.

• For general repairs, please do not include peripheral accessories. If

peripherals need to be included, be certain to specify which items you
sent on the RMA Request & Confirmation Form. ADLINK is not
responsible for items not listed on the RMA Request & Confirmation
Form.

3. Our repair service is not covered by ADLINK's guarantee in the following
situations:

• Damage caused by not following instructions in the User's Manual.

• Damage caused by carelessness on the user's part during product

transportation.

• Damage caused by fire, earthquakes, floods, lightening, pollution,

other acts of God, and/or incorrect usage of voltage transformers.

• Damage caused by inappropriate storage environments such as with

high temperatures, high humidity, or volatile chemicals.

84 • Warranty Policy

• Damage caused by leakage of battery fluid during or after change of

batteries by customer/user.

• Damage from improper repair by unauthorized ADLINK technicians.

• Products with altered and/or damaged serial numbers are not entitled

to our service.

• This warranty is not transferable or extendible.

• Other categories not protected under our warranty.

4. Customers are responsible for all fees necessary to transport damaged
products to ADLINK.

For further questions, please e-mail our FAE staff: [e-mail]

Warranty Policy • 85
