Quad Phase HP General Information

Unpacking: Thank you for purchasing the Quad Phase HP by ADJ

Products, LLC. Every Quad Phase HP has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.

If the carton appears to be damaged, carefully inspect your xture for

any damage and be sure all equipment necessary to operate the unit
has arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur­ther instructions. Please do not return this unit to your dealer without

contacting customer support rst.

Introduction: The Quad Phase HP is a four channel, DMX intelligent

LED moonflower fixture. The fixture can operate in as a stand alone
fixture or in a Master/Slave configuration. The Quad Phase HP has two

operating modes; sound active and DMX Control. For best results use
fog or special effects smoke to enhance the beams projections.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: [phone]

Fax: [phone]

E-mail: [e-mail]

1/13

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! This may cause eye damage. Avoid looking directly into the

light source. Use sensible precaution.

User Instructions

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 2

Quad Phase HP General Instructions

Quad Phase HP Safety Precautions

To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.

Quad Phase HP Features

• DMX-512 Protocol Compatible (Four DMX Channels)

• RGBW

• Bright 32 Watt LED

• 2 Operating Modes - Sound Active & DMX Control

• Internal Microphone

• Digital Display for Address and Function Setting

• UC3 Controller (Not Included)

• Power Cord Daisy Chain

Quad Phase HP Warranty Registration

The Quad Phase HP carries a 3 year (1095 days) limited warranty.
Please fill out the enclosed warranty card to validate your purchase
and warranty. You may also register your product online at www.
americandj.com. All returned service items whether under warranty or
not, must be freight pre-paid and accompany a return authorization
(R.A.) number. If the unit is under warranty you must provide a copy
of your proof of purchase invoice. Please contact ADJ customer sup­port for a R.A. number.

Quad Phase HP Handling Precautions

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ Products, LLC.

During operation the housing may become extremely hot. Avoid
touching the unit with bare hands while in use.

ADJ Products, LLC will not accept any liability for any resulting dam­ages caused by the non-observance of this manual or any unauthor-

ized modication to this unit.

For Your Own Personal Safety, Please Read and Understand This

Manual Completely Before You Attempt To Install Or Operate

This Unit!

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken.

• Do not attempt to remove or break off the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-

tacles, and the point where they exit from the appliance.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 16 for cleaning details.

• Heat -This fixture should be situated away from heat sources such

as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. Objects have fallen, or liquid has been spilled into the appliance.

B. The appliance has been exposed to rain or water.
C. The appliance does not appear to operate normally or exhibits a

marked change in performance.

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 3

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 4

Quad Phase HP Set Up

REMOTE

CONTROL

INPUT

POWER

INPUT OUTPUT

SOUND

REMOTE

CONTROL

INPUT

POWER

INPUT OUTPUT

SOUND

REMOTE

CONTROL

INPUT

POWER

INPUT OUTPUT

DMX512

DMX+,DMX-,COMMON

1

2

3

Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.

POWER

SOUND

REMOTE

CONTROL

INPUT

POWER

INPUT OUTPUT

and PIN 3 (DMX +) of the last fixture.

Quad Phase HP Set Up

Power Supply: The ADJ Quad Phase HP contains a automatic volt-

age switch, which will auto sense the voltage when it is plugged into

the power source. With this switch there is no need to worry about the

correct power voltage, this unit can be plugged in anywhere.

DMX-512: DMX is short for Digital Multiplex. This is a universal pro-

tocol used by most lighting and controller manufactures as a form of
communication between intelligent fixtures and controllers. A DMX

controller sends DMX data instructions from the controller to the fix­ture. DMX data is sent as serial data that travels from fixture to fixture
via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX
fixtures (most controllers only have a DATA “OUT” terminal).

DMX Linking: DMX is a language allowing all makes and models of
different manufactures to be linked together and operate from a sin­gle controller, as long as all xtures and the controller are DMX com­pliant. To ensure proper DMX data transmission, when using several

DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1

may be placed anywhere in a DMX line, at the beginning, at the end,

or anywhere in the middle. When a fixture is assigned a DMX address

of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.

Data Cable (DMX Cable) Requirements (For DMX and Master/Slave
Operation): The Quad Phase HP can be controlled via DMX-512

protocol. The Quad Phase HP is a four channel DMX unit. The DMX
address is set electronically using the controls on the back panel of
the unit. Your unit and your DMX controller require a approved DMX-

512 110 Ohm Data cable for data input and data output (Figure 1).
We recommend Accu-Cable DMX cables. If you are

making your own cables, be sure to use standard
110-120 Ohm shielded cable (This cable may be
purchased at almost all professional sound and
lighting stores). Your cables should be made with
a male and female XLR connector on either end of
the cable. Also remember that DMX cable must be
daisy chained and cannot be split.

Figure 1

Notice: Be sure to follow gures two and three when making your own

cables. Do not use the ground lug on the XLR connector. Do not con-

nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding

the shield could cause a short circuit and erratic behavior.

COMMON

1

DMX512 IN

3

3-PIN XLR

2

Figure 2

XLR Pin Conguration

Pin 1 = Ground

Pin 2 = Data Compliment (negative)

Pin 3 = Data True (positive)

Figure 4

XLR Male Socket

1 Ground

DMX512 OUT

3-PIN XLR

2 Cold

3 Hot

1

3

2

XLR Female Socket

2 Cold

DMX +

DMX -

1 Ground

3 Hot

Figure 3

Special Note: Line Termination.

When longer runs of cable are

used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con­nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last

unit in your daisy chain to terminate the line. Using a cable terminator

(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.

Termination reduces signal errors and

1

avoids signal transmission problems

3

and interference. It is always advisable

2

to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 6ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 5

Quad Phase HP Set Up

Quad Phase HP System Menu

5-Pin XLR DMX Connectors.

Some manufactures use 5-pin XLR

connectors for DATA transmission in place of 3-pin. 5-pin XLR xtures
may be implemented in a 3-pin XLR DMX line. When inserting stan­dard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be

used, these adaptors are readily available at most electric stores. The
chart below details a proper cable conversion.

3-Pin XLR to 5-Pin XLR Conversion

Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)

Ground/Shield

Data Compliment (- signal)

Data True (+ signal)

Not Used

Not Used

Pin 1

Pin 2

Pin 3

Pin 1

Pin 2

Pin 3

Pin 4 - Do Not Use

Pin 5 - Do Not Use

Quad Phase HP Installation

The unit should be mounted using a mounting clamp (not provided),

afxing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-

ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10

times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.

The equipment must be installed by a professional, and it must be

installed in a place where it is out of the reach of people’s grasp.

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 7 ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 8

Quad Phase HP System Menu

Quad Phase HP System Menu

ADDR - DMX Address Setting.

1. Press the either the MENU, UP, or DOWN buttons until
“ADDR” is displayed, press ENTER.

2. “1” will now be displayed and ashing. Press the UP or
DOWN buttons to nd your desired address. Press ENTER to

set your desired DMX address.

SLND - This will let you set unit as a master or slave in a

master/slave conguration.

1. Press the either the MENU button until “SLnd” is displayed,
press ENTER. “MAST”, “SL 1” or “SL 2” will be displayed.

2. Tap the UP or DOWN buttons until your desired setting is
displayed, press ENTER to conm and exit.

SOUN - Sound Active mode.

1. Press the MENU button until “SOUN” is displayed, press
ENTER.

2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to activate sound active mode,

or “OFF” to deactivate sound active mode.

3. Press ENTER to conrm.

DNST - This mode can be used as a precaution mode, that

in case the DMX signal is lost, the operating mode chosen

in the setup is the running mode the xture will go into when

the DMX signal is lost. You can also set this as the operat-

ing mode you would like the unit to return to when power is

applied.

1. Press the MENU button until “DNST” is displayed, press
ENTER.

2. Either “MAST”, “BLND”, or “LAST” will be displayed. Choose

an operating mode you would like the unit to start up in when
power is applied or the DMX signal is lost.

• MAST (Master Slave) - If the DMX signal is lost or power is

applied, the unit will automatically go into Master Slave mode.

• BLND (Blackout) - If the DMX signal is lost or power is applied,

the unit will automatically go into stand by mode.

• LAST (Last State) - If the DMX signal is lost the xture will stay

in the last DMX set up. If power is applied and this mode is set,
the unit will automatically go into the last DMX set up.

3. Press ENTER to conrm your desired set up

LED - With this function you can switch the LED on or off

via the control board.

SENS - Using this mode, you can set the sound sensitiv-

ity level. 0 for least sensitive, 100 for more sensitive.

1. Press the MENU button until “SENS” is displayed, press ENTER.

2. Using the UP or DOWN buttons adjust the sensivity level to your

desire.

3. When you found your desired level, press the ENTER, and then press
and hold the MENU button for at least 3 seconds to conrm.

1. Press the either the MENU button until “LED” is displayed,
press ENTER.

2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to switch on the LED, or “OFF”

to switch off the LED.

3. Press ENTER to conrm and exit.

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 10ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 9

Quad Phase HP System Menu

Quad Phase HP Operation

DISP - This function will reverse the display 180º.

1. Pres the either the MENU button until “DISP” is displayed,
press ENTER.

2. Press the UP button to select “DSIP” to activate this func-

tion, or “DISP” to deactivate this function.

3. Press ENTER to conrm.

TEST - This function will run a self test program .

1. Press the MENU button until “TEST” is displayed, press ENTER.

2. The unit will now run a self test. Press the MENU button to exit.

TEMP - With this function you can display the running

temperature of the unit.

1. Press the MENU button until “TEMP” is displayed, press
ENTER.

2. The current running temperature of the xture will now be
displayed. Press MENU to exit.

Universal DMX Control: This function allows you to use a Elation®

universal DMX-512 controller to control the chases and patterns,
dimmer and strobe. A DMX controller allows you to create unique
programs tailored to your individual needs.

1. The Quad Phase HP is a four DMX channel DMX fixture. See

page 14 for detailed description of the DMX values and traits.

2. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-7 as well as the set-up specifications that are

included with your DMX controller.

3. Use the controller’s faders to control the various DMX fixture traits.

4. This will allow you to create your own programs.

5. Follow the instructions on page 8 to set the DMX address.

6. For longer cable runs (more than a 100 feet) use a terminator on

the last fixture.

7. For help operating in DMX mode consult the manual included
with your DMX controller.

Sound Active Mode: This mode allows a single unit or several units

linked together, to run to the beat of the music.

1. Tap the MENU button until “SOUN” is displayed, and press ENTER.

FHRS - With this function you can display the running

time of the unit.

1. Press the either the MENU button until “FHRS” is displayed,
press ENTER.

2. The display shows the running time of the unit. Press MENU
to exit.

VER - Use this function to display the Software version of

the unit.

1. Press the either the MENU button until “VER” is displayed,
press ENTER.

2. The display will show the software version.

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 11

2. Press the UP or DOWN button so that “ON” is displayed. The unit

will now run to the beat of the music.

3. The sound sensitivity can be adjusted by pressing the MENU
button until “SENS” is displayed, and then press ENTER. Use the
UP or DOWN buttons to adjust the sound sensitivity, 1 being the

least sensitive, and 100 being the most sensitive.

4. The optional UC3 Controller (not included) may be used to con­ trol different functions including blackout.

Master-Slave Operation (Sound Active): This function will allow

you to link up to 16 units together and operate without a controller. The
units will be sound activated. In Master-Slave operation one unit will
act as the controlling unit and the others will react to the controlling
units programs. Any unit can act as a Master or as a Slave.

1. Using standard XLR microphone cables, daisy chain your units

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 12

Quad Phase HP Operation

Mode

Strobe(LED OFF)

Chase(LED ON)

Quad Phase HP DMX Traits

together via the XLR connector on the rear of the units. Remem­ ber the Male XLR connector is the input and the Female XLR

connector is the output. The rst unit in the chain (master) will use

the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a

terminator at the last fixture.

2. On the Master unit find your desired show and set that show by

pressiing the ENTER button.

3. On the slave units tap the MENU button until “SLND” is dis-

played, select your desired slave mode and Press ENTER.

4. The slave units will now follow the Master unit.

5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.

Quad Phase HP Power Cord Daisy Chain

With this feature you can connect the xtures to one another

using the IEC input and output sockets. The quantity that can be

connected is 5 xtures maximum. After 5 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.

Quad Phase HP UC3 Control

Blackout Blackout the unit

Function

1. Synchronous strobe.

2. Two light strobe.

3. Sound control.

Rotation speed (1-8).

Channel Value Function

1 0 - 255 COLOR SELECTION

1 - 16 COLOR 1
17 - 33 COLOR 2

34 - 50 COLOR 3
51 - 67 COLOR 4
68 - 84 COLOR 5
85 - 101 COLOR 6

102 - 118 COLOR 7

119 - 135 COLOR 8
136 - 152 COLOR 9
153 - 169 COLOR 10

170 - 186 COLOR 11
187 - 203 COLOR 12
204 - 220 COLOR 13
221 - 237 COLOR 14

238 - 255 COLOR 15

2 ROTATION

0 - 9 NO ROTATION
10 - 120 CLOCKWISE FAST - SLOW
121 - 134 NO ROTATION
135 - 245 COUNTER-CLOCKWISE
SLOW - FAST
246 - 249 NO ROTATION
250 - 255 SOUND ACTIVE

3 STROBING

0 OFF

1 - 255 STROBING SLOW - FAST

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 13 ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 14

4 SHUTTER OPEN
0 - 15 OFF
16 - 255 OPEN

Quad Phase HP ADJ-RC1 Operation

Quad Phase HP Fuse Replacement

The ADJ-RC1 infrared remote (sold seperately) has many differnet
functions and gives you complete control of your Mega Tri 60. To

control the your desired fixture you must aim the controller at the
front of the fixture and be no more the 30 feet away. To use the ADJ
LED RC you must first activate the fixtures infrared receiver, to acti-

vate the receiver please see the instructions on page 10.

STAND BY - Pressing this button will blackout the fixture.

FULL ON - Hold this button down to fully light up the unit. When you

let the button go, the unit will return to its previous state.

COLOR - Press this button to enter Dimmer mode. Adjust the output
intensity using either the number buttons, or using the “DIMMER +”
and “DIMMER -” buttons.

STROBE - This button will activate the strobe effect. You can control
the flash rate by pressing the “DIMMER +” and “DIMMER -” buttons.
If you press and hold this button the unit will begin to strobe.

SPEED - Press this button and use the “+” & “-” buttons to adjust the
speed of the Auto run.

SOUND ON & OFF - These buttons activate and deactivate the
sound active mode.

SHOW - This designates the fixture as a slave fixture in a master/

slave configuration.

“DIMMER +” and “DIMMER -” - Use these buttons to adjust the out-
put intensity and to adjust the strobe speed.

Disconnect the unit from its power source. Remove the power cord
from the unit. Once the cord has been removed, you will find that
the fuse holder is located inside the power socket. Insert a flat-head
screw driver into the power socket and gently pry out the fuse holder.
Remove the bad fuse and replace with a new one. The fuse holder also
has a holder for a spare fuse.

Quad Phase HP Cleaning

Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the

internal and external optical lenses and mirror should be carried out

periodically to optimize light output. Cleaning frequency depends on

the environment in which the fixture operates (I.e. smoke, fog residue,

dust, dew). In heavy club use we recommend cleaning on a monthly
basis. Periodic cleaning will ensure longevity, and crisp output.

1. Use normal glass cleaner and a soft cloth to wipe down the out-

side casing.

2. Use a brush to wipe down the cooling vents and fan grill.

3. Clean the external optics and mirror with glass cleaner and a soft

cloth every 20 days.

4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.

5. Always be sure to dry all parts completely before plugging the unit

back in.

Quad Phase HP Trouble Shooting

Trouble Shooting: Listed below are a few common problems that
you may encounter, with solutions.

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 15

No light output from the unit;

1. Be sure the external fuse has not blown. The fuse is located on
the rear panel of the unit.

2. Be sure the fuse holder is completely and properly seated.

Unit does not respond to sound;

1. Low frequencies (bass) should cause the unit to react to sound.
Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.

2. Check the sound sensitivity level.

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 16

Quad Phase HP Warranty

MANUFACTURER’S LIMITED WARRANTY

A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products
to be free of manufacturing defects in material and workmanship for a prescribed period from
the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the
product is purchased within the United States of America, including possessions and
territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.

B. For warranty service you must obtain a Return Authorization number (RA#) before sending back
the product–please contact ADJ Products, LLC Service Department at 800-322-6337. Send the pro­ duct only to the ADJ Products, LLC factory. All shipping charges must be pre-paid. If the requested repairs
or service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay
return shipping charges only to a designated point within the United States. If the entire instrument is
sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If
any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for
loss of or damage to any such accessories, nor for the safe return thereof.

C. This warranty is void if the serial number has been altered or removed; if the product is modified in any
manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the
product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior
written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because
not properly maintained as set forth in the instruction manual.

D. This is not a service contract, and this warranty does not include maintenance, cleaning or periodic check
up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense
with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole
discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August
15, 2012, and bear indentifying marks to that effect.

Quad Phase HP Notes

E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon it’s products
without any obligation to include these changes in any products theretofore manufactured.

No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with
products described above. Except to the extent prohibited by applicable law, all implied warranties made
by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness,
are limited in duration to the warranty period set forth above. And no warranties, whether expressed or
implied, including warranties of merchantability or fitness, shall apply to this product after said period
has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is
expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or
damage, direct or consequential, arising out of the use of, or inability to use, this product.

This warranty is the only written warranty applicable to ADJ Products, LLC Products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published. This warranty was revised after December 1, 2012.

MANUFACTURER’S LIMITED WARRANTY PERIODS:

 •LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent

Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing,
Lighting Stands etc. excluding LED, Laser Products and lamps)

 •LaserProducts=90-DayLimitedWarranty
 •L.E.D.Products=3-year(1095days)LimitedWarranty(excluding motors, PCB boards, and power

supplies, which have a 1-year (365 day Limited Warranty) and batteries which have a 180 day
limited warranty). Only the L.E.D.s carry a 3-year warranty

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 17 ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 18

Quad Phase HP Specifications

Model: Quad Phase HP

Voltage*: 100V ~ 240V 50/60Hz

LED: 1 x 32 4-in-1 Watt LED
Power Draw: 64W

Fuse: 7A

Power Cord Daisy Chain: 5 Fixtures Max.
Dimensions: 12.5”(L) x 8”(W) x 11”(H)

312mm x 198mm x 279mm

Weight: 9 lbs. / 4 kgs.
Colors: RGBW
Beam Angle: 65 Degree

Duty Cycle: None
DMX Channels: 4

Sound Active: Ye s
Working Position: Any Safe, Secure Position
Warranty: 3 Year (1095 days)

*Auto Sensing Voltage: This xture contains a automatic volt-

age switch, which will auto sense the voltage when it is plugged
into the power source.

Please Note: Specications and improvements in the design

of this unit and this manual are subject to change without any
prior written notice.

ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 19

ADJ Products, LLC

6122 S. Eastern Ave. Los Angeles, CA 90040 USA

Tel: [phone] / Fax: [phone]

Web: www.adj.com / E-mail: [e-mail]

A.D.J. Supply Europe B.V.

Junostraat 2

6468 EW Kerkrade

Netherlands

[e-mail] / www.adj.com

Tel: [phone] / Fax: [phone]
