Customer Support: American DJ® provides a toll free customer sup-

Warning! The 1/4” phone plug on the unit is for the optional

Progressor II/C. Do not attempt to connect an audio signal to this jack,

this will damage the PC board and void your manufactures warranty!

machine to enhance the beam output. An optional Progressor II/C con-

troller may be purchased separately.

figuration. The Progressor II™ comes with several build in programs

that will trigger when operating in master/slave mode. This unit is best

used in multiples of four. This piece is best used with a fog or haze

Introduction: The Progressor II™ is an intelligent, DMX compatible

version of the standard Progressor.™ This fixture can run in DMX

mode, as a stand alone sound active piece, or in a Master/Slave con-

Unpacking: Thank you for purchasing the Progressor II™ by Ameri-

can DJ®. Every Progressor II™ has been thoroughly tested and has

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your ﬁ xture for any

damage and be sure all accessories necessary to operate the unit have

arrived intact. In the event damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Please, do not return this unit to your dealer without ﬁ rst

Progressor II™ Introduction

Page 2

The Progressor II™ carries a one year (365 days) limited warranty.

We recommend you fill out the enclosed warranty card to validate your

purchase. All returned service items whether under warranty or not,

must be freight pre-paid and accompany a return authorization (R.A.)

number. If the unit is under warranty, you must provide a copy of your

proof of purchase invoice. Please contact American DJ

support for a R.A. number.

©American DJ® www.americandj.com Progressor II™ Instruction Manual Page 3 ©American DJ® www.americandj.com Progressor II™ Instruction Manual Page 4

® customer

• Optional Progressor II/C Blackout Controller.

Progressor II™ Warranty Registration

• Audio Sensitivity Knob.

• Sound-Active.

• DMX-512 Protocol Compatible.

• Full Focusing.

• Master/Slave Built-In Programs.

• Linkable.

Progressor II™ Features

manual with the unit, for future reference.

Warranty.....................................................................15

Progressor II™ General Instructions

Cleaning............................................................................12

Trouble Shooting............................................................12

DMX Traits............................................................................14

Set-Up................................................................................7

Controls & Functions..........................................................10

Lamp Replacement..............................................................11

Operation..............................................................................5

DMX Addressing.............................................................6

Introduction..........................................................................2

Features................................................................................3

Safety Precautions...................................................................4

Progressor II™ Contents

To optimize the performance of this product, please read these operat-

ing instructions carefully to familiarize yourself with the basic operations

of this unit. These instructions contain important safety information

regarding the use and maintenance of this unit. Please keep this

serviceable parts inside

• Never operate this unit when it’s cover is removed

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall

• Do not attempt to operate this unit, if it becomes damaged

• This unit is intended for indoor use only, use of this product outdoors

voids all warranties

• During long periods of non-use, disconnect the unit’s main power

• Always mount this unit in safe and stable matter

• Power cords should be routed so they are not likely to be walked on,

pinched by items placed upon or against them.

• Cleaning -The ﬁ xture should be cleaned only as recommended by

the manufacturer. See page 7 for cleaning details

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances

(including ampliﬁ ers) that produce heat.

• The ﬁ xture should be serviced by qualiﬁ ed service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

• Do not remove the cover under any conditions. There are no user

Progressor II™ Safety Precautions

• This unit may blow a fuse if the maximum allotted load of 10 amps

(220v = 5 amps) is reached. If the fuse needs replacement, always

replace the fuse with same exact type that was remove. Use of a

different type fuse from that which is recommended may cause fire or

electric shock and will void the manufactures warranty

• To reduce the risk of electrical shock or ﬁ re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit

• Be sure that the local power outlet match that of the required voltage

for your unit

• Do not attempt to operate this unit if the power cord has been frayed

or broken

• Do not attempt to remove or break off the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

shock and ﬁ re in case of an internal short

• Disconnect from main power before making any type of connection

Page 3

1. To operate a single unit or several units as individuals in stand

alone mode, turn dip switch number 10 to the on position (see

page 13) and plug the unit(s) in. If you are running more than one

unit in stand alone mode do not link the units together.

2. Adjust the sensitivity knob on the bottom of the unit so the unit

will react to sound and cycle through the internal chases. Turning

the sensitivity knob in a clockwise direction will make the fixture

more sensitive to sound, turning the sensitivity knob in counter-

clockwise direction will make the fixture less sensitive to sound.

Master-Slave Operation (Sound Active): In Master-Slave opera-

tion one unit will act as the controlling unit, the others will react to the

controlling units programs. Any unit can act as a master or a slave.

1. Using standard XLR microphone cables, daisy chain your units

together via the XLR connectors on the rear of the unit. Remem-

ber the Male XLR connector is the input and the Female XLR is the

output. The ﬁ rst unit in (master) will use the female XLR connector

only. Refer to the set-up procedures beginning on page 8.

2. Follow the Master-Slave dip-switch chart on page 13 for proper

©American DJ® www.americandj.com Progressor II™ Instruction Manual Page 5 ©American DJ® www.americandj.com Progressor II™ Instruction Manual Page 6

fixtures DMX traits with a standard DMX 512 controller such as

the American DJ® Show Designer™ or DMX Operator.

NOTE: Stand-Alone and Master/Slave operation require a sound

source to operate properly. The units will blackout to conserve lamp

life when inactive for more than 60 seconds. A single sound source

will reactivate the units.

Stand Alone Mode:

™

• DMX control mode - This function will allow you to control each

• Master/Slave mode - Allows you to daisy chain up to 4 fixtures

will react to sound, chasing through the several built in programs.

You can also use the optional Progressor II/C remote control to

blackout the unit.

together for a synchronized light show. The fixtures will react to

sound chasing through several built in programs. You can also use

the optional Progressor II/C remote control to change programs and

blackout the units.

different modes:

• Stand-Alone mode (Usually for single unit operation) - The unit

Operating Modes: You can operate the Progressor II

Progressor II™ Operation

™

in three

the last fixture in you DMX chain.

Universal DMX Control: Operating through a DMX controller allows

PROGRESSOR II /C ONLY

DMX Indicator

Dipswitch

ON 1 2 3 4 5 6 7 8 9 10

M / S

256

128643216842

1 = Ground

2 = Data -

3 = Data +

DMX Link

DMX In

DMX Out

120 V / 10 A

240 V / 5 A

Fuse

Black = Hot

White = Neutral

Green = Earth

Power

PROGRESSOR II /C ONLY

DMX Indicator

Dipswitch

ON 1 2 3 4 5 6 7 8 9 10

M / S

256

128643216842

1 = Ground

2 = Data -

3 = Data +

DMX Link

DMX In

DMX Out

To next Progressor II™ if applicable

120 V / 10 A

240 V / 5 A

Fuse

Black = Hot

White = Neutral

Green = Earth

Power

PROGRESSOR II /C ONLY

DMX Indicator

Dipswitch

ON 1 2 3 4 5 6 7 8 9 10

M / S

256

128643216842

1 = Ground

2 = Data -

3 = Data +

DMX Link

DMX In

DMX Out

the freedom to create unique programs tailored to one’s individual

needs.

1. The Progressor II™ uses one DMX channel. This channel con-

trols the rotation of the unit’s internal wheel. Please refer to page

14 for a detailed description of the DMX traits.

2. To control your fixture in DMX mode, follow the unit set-up proce-

dures beginning on page 8 as well as the set-up specifications

that are included with your DMX controller.

3. Use the controller’s faders to control the various DMX fixture traits.

4. This will allow you to create custom programs.

5. When using a DMX controller and setting up for DMX operation

follow the dip switch settings on page 13.

6. For help operating in DMX operation consult the manual included

with your DMX controller.

7. For longer cable runs (more than a 100 feet) use a terminator on

react to sound.

Master/Slave Linking:

Progressor II™ Operation

MICROPHONE

For a more dramatic effect, link several Color units together.

SENSITIVITY

dip-switch settings.

3. The optional Progressor II/C Controller may be used in this

operation mode to control a blackout function.

4. After the unit settings have been set and are plugged in, adjust

the sensitivity knob on the rear of the master unit to make them

Optional Progressor II/C or Progressor II/C blackout controller

ON ON

Master/Slave Chart

Master

Slave 1

Slave 3Slave 2

MICROPHONE

SENSITIVITY

ON ON

Master/Slave Chart

Master

Slave 1

Slave 3Slave 2

MICROPHONE

SENSITIVITY

ON ON

Master/Slave Chart

Master

Slave 1

Slave 3Slave 2

120 V / 10 A

240 V / 5 A

Fuse

Black = Hot

White = Neutral

Green = Earth

Power

Page 4

be placed anywhere in a DMX line, at the beginning, at the end, or

DMX-512: DMX is short for Digital Multiplex. This is a universal

venue, you should be sure your unit voltage matches the wall outlet

voltage before attempting to operate you ﬁ xture.

Power Supply: Before plugging your unit in, be sure the source

voltage in your area matches the required voltage for your American

DJ® Progressor II.™ Because line voltage may vary from venue to

Progressor II™ Set Up

protocol used as a form of communication between intelligent fixtures

and controllers. A DMX controller sends DMX data instructions from

the controller to the fixture. DMX data is sent as serial data that

travels from ﬁ xture to ﬁ xture via the DATA “IN” and DATA “OUT” XLR

terminals located on all DMX ﬁ xtures (most controllers only have a

DATA “OUT” terminal).

DMX Linking: DMX is a language allowing all makes and models of

different manufactures to be linked together and operate from a single

controller, as long as all ﬁ xtures and the controller are DMX compliant.

To ensure proper DMX data transmission, when using several DMX

fixtures try to use the shortest cable path possible. The order in which

fixtures are connected in a DMX line does not influence the DMX

addressing. For example; a fixture assigned a DMX address of 1 may

Typical DMX Linking:

Progressor II™ Operation

©American DJ® - www.americandj.com - Progressor II™ Instruction Manual Page 7

PROGRESSOR II /C ONLY

DMX Indicator

MICROPHONE

Dipswitch

ON 1 2 3 4 5 6 7 8 9 10

M / S

256

128643216842

1 = Ground

2 = Data -

3 = Data +

DMX Link

DMX In

DMX Out

120 V / 10 A

240 V / 5 A

Fuse

Black = Hot

White = Neutral

Green = Earth

DMX Indicator

Dipswitch

ON 1 2 3 4 5 6 7 8 9 10

M / S

256

128643216842

1 = Ground

2 = Data -

3 = Data +

DMX Link

DMX In

DMX Out

120 V / 10 A

240 V / 5 A

Fuse

Black = Hot

White = Neutral

Green = Earth

SENSITIVITY

ON ON

Master/Slave Chart

Master

Slave 1

Slave 3Slave 2

Power

PROGRESSOR II /C ONLY

MICROPHONE

SENSITIVITY

ON ON

Master/Slave Chart

Master

Slave 1

Slave 3Slave 2

Power

To next DMX unit or terminate.

PROGRESSOR II /C ONLY

DMX Indicator

MICROPHONE

Dipswitch

ON 1 2 3 4 5 6 7 8 9 10

M / S

256

128643216842

1 = Ground

2 = Data -

3 = Data +

DMX Link

DMX In

DMX Out

120 V / 10 A

240 V / 5 A

Fuse

Black = Hot

White = Neutral

Green = Earth

SENSITIVITY

ON ON

Master/Slave Chart

Master

Slave 1

Slave 3Slave 2

Power

with a male and female XLR connector on either end of the cable. Also

Data Cable Requirements (For DMX and Master/Slave Opera-

tion): The Progressor II™ can be controlled via DMX-512 protocol.

= 201

3 = 4 4 = 8

5 = 16 7 = 64

= 21 8 = 128

The DMX address is set using the dip-switches on the rear panel of the

Progressor II™. Your unit excepts 3-pin XLR connector for data input

and data output (Figure 5). When using a DMX controller with 5-Pin

XLR output jacks or when linking from a DMX ﬁ xture with 5-Pin XLR

jack to the Progressor II™, be sure to follow the pin conversion chart

on page 12. If you are making your own cables, be sure to use stan-

dard two conductor shielded cable (This cable may be purchased at

almost all pro sound and lighting stores). Your cables should be made

©American DJ® - www.americandj.com - Progressor II™ Instruction Manual Page 8

combining the dip switches that sum your desired value. For example:

To achieve a DMX address of 21, combine dip switches 1, 3, and 5.

Sense dip switch 1 has a value of 1, dip switch 3 has a value of 4,

and dip switch 5 has a value of 16, the combination of the create a

DMX value of 21.

Set DMX address 21: Set DMX address 201:

Dip-switches # 1 = 1 Dip-switches # 1 = 1

DMX address. Each dip switch represents a binary value.

Dip Switch 1 address equals 1

Dip Switch 2 address equals 2

Dip Switch 3 address equals 4

Dip Switch 4 address equals 8

Dip Switch 5 address equals 16

Dip Switch 6 address equals 32

Dip Switch 7 address equals 64

Dip Switch 8 address equals 128

Dip Switch 9 address equals 256

Each dip switch has a preset value. A specific DMX address is set by

198765432 10

DMX CHANNEL

Dip-switches in DMX mode: This unit uses dip switches to assign a

Progressor II™ Set Up

anywhere in the middle. When a fixture is assigned a DMX address of

1, the DMX controller knows to send DATA assigned to address 1 to

that unit, no matter where it is located in the DMX chain.

12828 32

256651641

Page 5

below details a proper cable conversion.

©American DJ® - www.americandj.com - Progressor II™ Instruction Manual Page 9

Data Compliment (- signal)

Data True (+ signal)

Ground/Shield

Not Used

Do Not Use

Pin 3

Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)

3-Pin XLR to 5-Pin XLR Conversion

Pin 1

Pin 2

Pin 1

5-Pin XLR DMX Connectors.

and PIN 3 (DMX +) of the last fixture.

Some manufactures use 5-pin XLR

behavior.

Termination reduces signal errors and

avoids signal transmission problems

and interference. It is always advisable

to connect a DMX terminal, (Resistance

120 Ohm 1/4 W) between PIN 2 (DMX-)

connectors for DATA transmission in place of 3-pin. 5-pin XLR ﬁ xtures

may be implemented in a 3-pin XLR DMX line. When inserting standard

5-pin XLR connectors in to a 3-pin line a cable adaptor must be used,

these adaptors are readily available at most electric stores. The chart

Special Note: Line Termination.

used, you may need to use a terminator on the last unit to avoid erratic

behavior. A terminator is a 90-120 ohm 1/4 watt resistor which is con-

nected between pins 2 and 3 of a male XLR connector (DATA + and

DATA -). This unit is inserted in the female XLR connector of the last

unit in your daisy chain to terminate the line. Using a cable terminator

(ADJ part number ZDMX/T) will decrease the possibilities of erratic

DMX512 OUT

3-PIN XLR

COMMON

DMX +

DMX -

When longer runs of cable are

DMX512 IN

3-PIN XLR

3 Hot

2 Cold

3 Hot

Pin 3 = Data True (positive)

1 Ground

Pin 1 = Ground

Pin 2 = Data Compliment (negative)

the shield could cause a short circuit and erratic behavior.

1 Ground

XLR Male Socket

XLR Female Socket

XLR Pin Conﬁ guration

remember that DMX cable must be daisy chained and can not be split.

Notice: Be sure to follow ﬁ gures 6 and 7 when making your own

Progressor II™ Set Up

cables. Do not use the ground lug on the XLR connector. Do not con-

nect the cable’s shield conductor to the ground lug or allow the shield

conductor to come in contact with the XLR’s outer casing. Grounding

Figure 8

address to the unit. In DMX mode each switch corresponds to a

speciﬁ c value based on binary code. See page 7 for a detailed

explanation of DMX binary code.

5. Power Indicator - This LED will ﬂ ash when it receives either an

audio or DMX signal.

6. DMX Output Jack - This jack is used to send the incoming DMX or

Master/Slave signal to another DMX ﬁ xture.

7. Fan Grill - Keep this grill clean and clear of obstacles at all times.

8. DMX Input Jack - This jack is used to accept an incoming DMX or

Master/Slave signal.

9. Power Cord - Connect only to a matching power outlet. Never use

this ﬁ xture is the ground prong has been removed or broken off.

10. Fuse Holder - This housing stores the protective fuse. Always

replace with the exact same type fuse, unless otherwise instructed

to do so by an authorized American DJ® service technician.

©American DJ® - www.americandj.com - Progressor II™ Instruction Manual Page 10

Figure 7

Figure 6

1. Mic Sensitivity - This adjust audio sensitivity of the internal

mic (2). Turning the sensitivity knob in the clockwise direction will

increase sound sensitivity. Turning the knob in a counter clockwise

direction will decrease sound sensitivity.

2. Internal Mic - This microphone receives external low frequencies

to trigger the unit in Sound-Active and Master/Slave mode.

3. Remote Control Input - Do not attempt to connect an audio

signal to this jack, this will damage the unit! This jack is

for use with the optional Progressor II/C controller only. Connect-

ing an audio signal this jack, this will damage the PC board and

void your manufactures warranty!

4. Dip Switches - These switches serve two functions. In master

slave mode these switches are used to assign a speciﬁ c head

address. In DMX mode these switches are used to assign a DMX

PROGRESSOR II /C ONLY

ON ON

Slave 3Slave 2

MICROPHONE

Master/Slave Chart

Master

Slave 1

DMX Out

546

DMX Indicator

Dipswitch

ON 1 2 3 4 5 6 7 8 9 10

M / S

256

128643216842

1 = Ground

2 = Data -

3 = Data +

DMX Link

DMX In

Progressor II™ Controls and Functions

SENSITIVITY

120 V / 10 A

240 V / 5 A

Fuse

Black = Hot

White = Neutral

Green = Earth

Power

9210

Page 6

with halogen lamps.

2. Remove the single thumb screw located in the top of the unit.

3. Flip-down the front cover to access the lamp socket assembly. The

cover is on hinges and will not fall off.

4. Carefully remove the old lamp and discard it in the trash.

5. Replace the lamp with an exact match and reassemble.

©American DJ® - www.americandj.com - Progressor II™ Instruction Manual Page 11 ©American DJ® - www.americandj.com - Progressor II™ Instruction Manual Page 12

Halogen Lamp Warning:

This fixture is fitted with a halogen lamp which

is highly susceptible to damage if improperly han-

dled. Never touch the lamp with your bare ﬁ ngers

as the oil from your hands will shorten lamp life.

Also, never move the ﬁ xture until the lamp has

had ample time to cool. Remember, lamps are not

covered under warranty conditions.

unless otherwise specified by an authorized American DJ® technician.

Lamp Replacement: Caution! Never attempt to change the lamp

while the fixture is plugged in. Always disconnect the main power and

allow the unit ample time to cool before attempting to replace the

lamp. Lamp replacement has been made simple by incorporating the

use of a flip-up top cover that is retained by a single thumb screw.

1. Be sure to follow the proper handling procedures that deal

unit and will void the manufactures warranty.

Warning: If, after replacing the lamp or fuse either one continues

to blow, STOP using the unit. Contact customer support for further

instructions, you may have to return the unit for servicing. Continuing

to use the unit may cause serious damage.

Fuse Replacement: Disconnect the unit’s main power supply. Insert

a standard flat head screw driver in to the fuse holder housing. Turn

the screwdriver in counter-clockwise direction to remove the fuse

holder. Remove the fuse holder to expose the fuse. Remove the old

fuse and discard it. Replace the fuse with the same type. Insert the

fuse holder back into it’s housing and turn it in clockwise direction to

lock the holder in place.

Replacing with anything other than the specified part can damage the

Caution: Always replace with the exact same type lamp and fuse,

Progressor II™ Fuse & Lamp Replacement

5. Always be sure to dry all parts completely before plugging the unit

back in.

4. Clean the internal lens with glass cleaner and a soft cloth every

30-60 days.

20 days.

Fixture Cleaning:

Progressor II™ Cleaning

2. Be sure the SENSITIVITY KNOB (1) is not set to the maximum

position.

1. Low frequencies (bass) should cause the unit to react to sound.

Ta p ping o n t he microphone, quiet or high pitched sounds may not

activate the unit.

4. Be sure the fuse holder is completely and properly seated.

Unit does not respond to sound;

to touch the lamp with your bare fingers.

be sure the lamp is push in to its socket all the way. Remember not

socket properly. Occasionally lamps become loose during shipping

2. Be sure the external fuse has not blown. The fuse is located on the

rear panel of the unit.

3. Remove the lamp cover and be sure the lamp is seated in its

220v depending on the models voltage requirements) wall outlet.

1. Be sure you have connected your unit into a standard 120V (or

No light output from the unit;

Troub l e S h ooting:

Listed below are a few common problems that you may encounter,

with solutions.

Progressor II™ Trouble Shooting

Due to fog residue, smoke, and dust cleaning the internal and external

optical lenses and mirror should be carried out periodically to optimize

light output. Cleaning frequency depends on the environment in which

the fixture operates (I.e. smoke, fog residue, dust, dew). In heavy club

use we recommend cleaning on a monthly basis. Periodic cleaning will

ensure longevity, and crisp output.

1. Use normal glass cleaner and a soft cloth to wipe down the outside

casing.

2. Use a brush to wipe down the cooling vents and fan grill.

3. Clean the external lens with glass cleaner and a soft cloth every

Page 7

illustrated dip switch setting (10 to the on position - all others off).

Progressor II™ Single Unit Operation Chart

ON ON

This chart list the DMX dip switch setting for single head operation.

When using this fixture as a stand alone unit or when using multiple

Progressor IIs as stand alone units, be sure all the fixtures match the

198765432 10

Head 3

Master - Head 1

be using two or more fixtures in a Master/Slave configuration. The

“Master - Head 1” settings should only be used once.

ON ON

19876543210

Master - Head 1

This chart details the Master/Slave dip switch setting for Master/Slave

configuration for four units. Use these dip switch setting when you will

Progressor II™ Master/Slave Chart

CW Fast CCW FastCW Slow CCW Slow

The Progressor II™ is a single DMX channel fixture

01 128

Progressor II™ DMX Traits

Stop

129127

198765432 10

10234567891

Head 4

The center numbers of this chart (1-511) represent a DMX address. The "X"'s

and "O"'s along the top and side of the chart represent dip switch poistion ("X"

for off and "O" for on). Find your desired DMX address from the center chart.

Identify the position for dip switches 1-5 from the chart on the left and dip

switches 6-9 from the chart on the top. Adjust the dip switches on your fixture to

match the position settings of the chart. For fixtures with 10 dip switches; dip

switch 10 is reserved for special functions.

OOOOO

X OOOO

OXOOO

XXOOO

28 60 92 124 156 188 220 252 284 316 348 380 412 444 476 508

30 62 94 126 158 190 222 254 286 318 350 382 414 446 478 510

31 63 95 127 159 191 223 255 287 319 351 383 415 447 479 51

29 61 93 125 157 189 221 253 285 317 349 381 413 445 4 77 509

OOXOO

XOXOO

O XXOO

25 57 89 121 153 185 217 249 281 313 345 377 409 441 473 505

27 59 91 123 155 187 219 251 283 315 347 379 411 443 475 507

26 58 90 122 154 186 218 250 282 314 346 378 410 442 4 74 506

XXXOO

24 56 88 120 152 184 216 248 280 312 344 376 408 440 472 504

OOOXO

23 55 87 119 151 18 3 215 247 279 311 343 37 5 407 439 471 503

X OOX O

22 54 86 118 150 182 214 246 278 310 342 374 406 438 470 502

OXOX O

21 53 85 117 149 181 213 245 277 309 341 373 405 437 469 501

Head 2

Dip Switch Position

OOXXO

XOXXO

XXOXO

18 50 82 114 146 178 210 242 274 306 338 370 402 434 466 498

19 51 83 115 147 179 211 243 275 307 339 371 403 435 467 499

20 52 84 116 148 18 0 212 244 276 308 340 37 2 404 436 468 500

X OOOX

O XXXO

XXXXO

OOOOX

OXOOX

XXOOX

12 44 76 108 140 172 204 236 268 300 332 364 396 428 460 492

13 45 77 109 141 173 205 237 269 301 333 365 397 429 461 493

15 47 79 111 143 175 207 239 271 303 335 367 399 431 463 495

16 48 80 112 144 176 208 240 272 304 336 368 400 432 464 496

14 46 78 110 142 17 4 206 238 270 302 334 36 6 398 430 462 494

17 49 81 113 145 17 7 209 241 273 305 337 36 9 401 433 465 497

XOXOX

OOXOX

10 42 74 106 138 170 202 234 266 298 330 362 394 426 458 490

11 4 3 75 107 139 171 203 235 2 67 299 331 363 395 427 459 491

O XXOX

94173105137 169 201 233 265 297 329 36 1 393 425 457 489

XXXOX

84072104 136 168 200 232 264 296 328 360 392 424 456 488

OOOXX

73971103135 167 199 231 263 295 327 35 9 391 423 455 487

X OOX X

63870102134 166 198 230 262 294 326 35 8 390 422 454 486

XXOXX

OXOX X

43668100132 164 196 228 260 292 324 35 6 388 420 452 484

53769101 133 165 197 229 261 293 325 357 389 421 453 485

O XXXX

OOXXX

XOXXX

XXXX

1336597129161193225 257 28932135 3 385 417 449 481

3356799131163195227 259 29132335 5 387 419 451 483

2346698130 162 194 226 258 290 322 354 386 418 450 482

36496128160192224 256 288320352 384 416 448 480

#1 #2 #3 #4 #5

O = ON

X = OFF

DIP SWITCHES

DMX DIP Switch Settings

255

This chart list the DMX dip switch setting for DMX address 1 through

511. Follow the instructions below to configure fixture dip switches with

your desired DMX address.

Progressor II™ DMX Dip Switch Chart

DMX Address Quick Reference Chart

DMX Address

XOXXOOOXOXXOXOX

Dip Switch Position

OOOOOXOOOXXXXXXX

OOOOOOOOXXXXXX XX

OXOXOOXXOOXX XXOO

Page 8

supersedes all prior warranties and written descriptions of warranty terms and conditions

heretofore published.

H. All lamps and fuses are not covered under this warranty.

damage, direct or consequential, arising out of the use of, or inability to use, this product.

G. This warranty is the only written warranty applicable to American DJ® Products and

sumer’s and or Dealer’s sole remedy shall be such repair or replacement as is expressly

provided above; and under no circumstances shall American DJ® be liable for any loss or

warranties of merchantability or ﬁ tness, are limited in duration to the warranty period set

forth above. And no warranties, whether expressed or implied, including warranties of mer-

chantability or ﬁ tness, shall apply to this product after said period has expired. The con-

manufactured.

F. No warranty, whether expressed or implied, is given or made with respect to any acces-

sory supplied with products described above. Except to the extent prohibited by applicable

law, all implied warranties made by American DJ

were manufactured after January 1, 1990, and bear identifying marks to that effect.

E. American DJ

its products without any obligation to include these changes in any products theretofore

® reserves the right to make changes in design and/or improvements upon

including parts, at the sole discretion of American DJ®. All products covered by this warranty

D. This is not a service contract, and this warranty does not include maintenance, cleaning

or periodic check-up. During the period speciﬁ ed above, American DJ

tive parts at its expense, and will absorb all expenses for warranty service and repair labor

by reason of defects in material or workmanship. The sole responsibility of American DJ®

under this warranty shall be limited to the repair of the product, or replacement thereof,

American DJ® factory unless prior written authorization was issued to purchaser by Ameri-

can DJ®; if the product is damaged because not properly maintained as set forth in the

instruction manual.

to a designated point within the United States. If the entire instrument is sent, it must be

shipped in its original package. No accessories should be shipped with the product. If any

accessories are shipped with the product, American DJ® shall have no liability whatsoever

charges must be pre-paid. If the requested repairs or service (including parts replacement)

are within the terms of this warranty, American DJ® will pay return shipping charges only

responsibility to establish the date and place of purchase by acceptable evidence, at the

time service is sought.

B. For warranty service, send the product only to the American DJ

free of manufacturing defects in material and workmanship for a period of 1 Year (365 days)

from the date of purchase. This warranty shall be valid only if the product is purchased

within the United States of America, including possessions and territories. It is the owner’s

1-YEAR LIMITED WARRANTY

A. American DJ® hereby warrants, to the original purchaser, American DJ® products to be

Progressor II™ Warranty

for loss of or damage to any such accessories, nor for the safe return thereof.

C. This warranty is void if the serial number has been altered or removed; if the product

is modiﬁ ed in any manner which American DJ

ability of the product; if the product has been repaired or serviced by anyone other than the

® in connection with this product, including

Web: www.americandj.com E-mail: [email protected]

® concludes, after inspection, affects the reli-

FUSE: 120V = 10 AMP GMA

220V = 5 AMP GMA

® factory. All shipping

DIMENSIONS:

WEIGHT: 24 LBS

LAMP: ZB-64514 120v/300w or

ZB-64516 220v/300w

VOLTAGE

: 120V~60Hz / 220V~50Hz

MODEL: PROGRESSOR II™

SPECIFICATIONS:

® will replace defec-

Please Note: Speciﬁ cations and improvements in the design of

this unit and this manual are subject to change without any prior

written notice.

WARRANTY: 1 YEAR (365 DAYS)

* Voltage is preset at the factory

COLORS: MULTIPLE

DMX CHANNELS: 1

SOUND ACTIVE: YES

GOBOS: NONE

DUTY CYCLE: 30 MIN. ON, 10 MIN. OFF

WORKING POSITION: ANY SAFE POSITION

COOLING: FAN COOLED

4295 Charter Street Los Angeles, CA 90058 USA

Tel: 323-582-2650 Fax: 323-582-2610

American DJ® World Headquarters:

©American DJ

16"H x 11"W x 14.5"L
