WIFLY PAR QA5
WiFly Par QA5 Introduction
Unpacking: Thank you for purchasing the WiFly Par QA5 by ADJ Products, LLC. Every WiFly Par QA5 has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are missing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without rst contacting customer support.
Introduction: The WiFly Par QA5 is a rechargeable lithium battery
powered, DMX intelligent, LED par fixture with ADJ’s WiFly TransCeiver
with wireless DMX built-in. This unit give you the freedom to set up
your fixture where ever you wish without the restrictions of power or
DMX cabling. The built-in battery will keep charge for up to 6 hours (full
on) from a full, single charge. This xture can be used in a stand alone
mode or connected in a Master/Slave conguration. This wash has five
operating modes: Sound Active mode, Auto mode, RGB mode, Static
Color mode, and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or suggestions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@AmericanDJ.com
4/13
User Instructions
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures warranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 2
WiFly Par QA5 Features
WiFly Par QA5 Safety Precautions
• Rechargeable Lithium Battery
• Mulit-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 8 DMX Channel Modes: 1 Channel Mode, 2 Channel Mode, 3
Channel Mode, 4 Channel Mode, 5 Channel Mode, 6 Channel
Mode, 7 Channel Mode, & 8 Channel Mode
• Built-In ADJ’s WiFly TransCeiver Wireless DMX
• ADJ RFC compatiable (Not Included)
• Power Cord Daisy Chain (See page 14)
WiFly Par QA5 Warranty Registration
The WiFly Par QA5 carries a 3 year limited warranty. Please fill out the
enclosed warranty card to validate your purchase. All returned service
items whether under warranty or not, must be freight pre-paid and
accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our customer support number. All packages returned to the service department not displaying a R.A. number
on the outside of the package will be returned to the shipper.
WiFly Par QA5 Installation
The unit should be mounted using a mounting clamp (not provided),
afxing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break off the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 25 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 4ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 3
WiFly Par QA5 Battery Precautions WiFly Par QA5 Battery Precautions
1. Handling of Batteries
1.1 Do Not Short Circuit the Battery
Try to never short circuit the battery. It generates a very high
current which could cause the battery to overheat which may
result in electrolyte gel leakage, harmful fumes, or explosion.
The LIR tabs may easily short-circuit by placing them on conductive surface. A short circuit may lead to heat build up and
damage of the battery. An appropriate circuitry with PCM is
employed to protect accidental short circuit of the battery pack.
1.2 Mechanical shock
Droping the unit, impact hit, bending, etc. may cause failure or
shortend life of the LIR battery.
3. Other
3.1 Battery connection
1). Direct soldering of wire leads or devices to the battery is
strictly prohibited.
2). Lead tabs with pre-soldered wiring shall be spot welded to
the batteries. Direct soldering may cause damage of components, such as separator and insulator, by heat build up.
3.2 Prevention of short circuit within a battery pack
There is enough insulation layers between wiring and the bat-
teries to provide extra safety protection. The battery pack is
constructed in a way that no short circuit will occur which may
cause smoke or re.
3.3 Do No Disassemble the Batteries
1). Never disassemble the batteries.
Doing this may cause a internal short circuit in the battery,
which may lead to harmful fumes, re, explosion, or other problems.
2). Electrolyte Gel is harmful
Electrolyte Gel should not leak from the LIR battery. Should the
electrolyte gel come into contact with the skin or eyes, ush the
area of contact immediately with fresh water and seek medical
attention immediately.
3.4 Do Not Expose the Battery to Heat or Fire
Never incinerate or dispose of the batteries in re. This may
cause an explosion, which would be very dangerous.
3.5 Do Not Expose the Battery to water or liquids
Never soak/drop the batteries in liquids such as water, seawater, drinks such as soft drinks, juices, coffee or other.
3.6 Battery Replacement
For battery replacement please contact ADJ customer support
(800) 322-6337.
3.7 Do Not use a damaged Battery
The battery could be damaged during shipping, caused by
shock. Should the battery be found damaged, including damages to the plastic casing of the battery, deformation of the
battery package, smelling of an electrolyte, or leakage of the
electrolyte gel, or other, DO NOT use the battery. A battery with
a odor of electrolyte or a gel leakage should be placed away
from re to avoid re or explosion.
4. Battery Storage
When storing the battery, it should be stored at room tempera-
ture, with a charge of at least 50%. We recommend that during
long periods of storage that the battery be charged every 6
months. Doing this will prolong the life of the battery and will
also make sure that the battery charge does not fall below the
30% mark.
5. Other Chemical Reaction
Because batteries utilize a chemical reaction, battery performance will deteriorate over time even if stored for a long
period of time without being used. In addition, if the various
usage conditions such as charge, discharge, ambient tempera-
ture, etc. are not maintained within the specied ranges, the
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 5
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 6
WiFly Par QA5 Battery Precautions
WiFly Par QA5 Set Up
life expectancy of the battery maybe shortened or the device
in which the battery is used may be damaged by electrolyte
gel leakage. If the batteries cannot maintain a charge for long
periods of time, even when they are charged correctly, this may
indicate it is time to change the battery.
6. Battery Disposal
Please dispose of battery according to local regulations.
Power Supply: The ADJ WiFly Par QA5 contains a automatic voltage
switch, which will auto sense the voltage when it is plugged into the
power source. With this switch there is no need to worry about the correct power voltage, this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures
and controllers. A DMX controller sends DMX data instructions from
the controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
different manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compliant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 7
Data Cable (DMX Cable) Requirements (For DMX Operation):
The WiFly Par QA5 can be controlled via DMX-512 protocol. The WiFly
Par QA5 has 8 DMX channel modes, please see page 12-13 for the dif-
ferent modes. The DMX address is set on the back panel of the WiFly
Par QA5. Your unit and your DMX controller require a standard 3-pin XLR
connector for data input and data output (Figure
1). We recommend Accu-Cable DMX cables.
If you are making your own cables, be sure to
use standard 110-120 Ohm shielded cable (This
cable may be purchased at almost all pro lighting
stores). Your cables should be made with a male
and female XLR connector on either end of the
cable. Also remember that DMX cable must be
daisy chained and cannot be split.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 8
Figure 1
WiFly Par QA5 Set Up
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
POWER
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
WiFly Par QA5 Operating Instructions
Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
COMMON
1
DMX512 IN
3
3-PIN XLR
2
Figure 2
XLR Pin Conguration
1 Ground
3 Hot
Pin 1 = Ground
Pin 2 = Data Compliment (negative)
Pin 3 = Data True (positive)
When longer runs of cable are
Figure 4
Pin 1
Pin 2
Pin 3
Do Not Use
Do Not Use
XLR Male Socket
1 Ground
DMX512 OUT
3-PIN XLR
2 Cold
3 Hot
1
3
2
DMX +
DMX -
XLR Female Socket
2 Cold
Figure 3
Special Note: Line Termination.
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is connected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
5-Pin XLR DMX Connectors.
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Ground/Shield
Data Compliment (- signal)
Data True (+ signal)
Not Used
Not Used
Termination reduces signal errors and
1
avoids signal transmission problems
3
and interference. It is always advisable
2
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
Some manufactures use 5-pin DMX-
3-Pin XLR to 5-Pin XLR Conversion
Pin 1
Pin 2
Pin 3
Operating Power:
There are two ways to supply power to this unit; battery power or AC
power.
• AC Power - To run the unit using AC power, plug the unit into a
power source, and put the Load Switch into the ON position. When
using AC power make sure the Battery Switch is in the OFF position.
• Battery Power - To run the unit using Battery power, put the Load
and Battery Switches in the ON position.
LED Display On/Off:
To set the LED display to turn off after 60 seconds, press the MODE button until “don” is displayed, press the UP button to display “doff”. Now
the display will disappear after 60s. Press any button to turn the display
on again. Be advised though that the display will turn off automatically
after 10 seconds.
To set the display press the MODE button until “dXX” is displayed. Use
the UP or DOWN buttons to select either:
“don” = LED display on at all times.
“doFF” = LED display shuts off after 60 seconds.
LED Display Inversion:
Follow these instructions to flip the display 180° so that the display can
be read upside down.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “Stnd” or “rev” is displayed.
3. Press the UP or DOWN buttons to reverse the display 180°.
Operating Modes:
The WiFly Par QA5 has five operating modes:
• Static Color Mode - There are 15 colors to choose from.
• RGBA Mode - Choose one of the four colors to remain static or
adjust the intensity of each color to make your desired color.
• Auto Mode - There are 3 Auto Modes to choose from.
• Sound-Active mode - The unit will react to sound, chasing through
the built in programs.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 10ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 9
WiFly Par QA5 Operating Instructions
WiFly Par QA5 Operating Instructions
as the ADJ Show Designer™.
RGBA Dimmer Mode:
1. Plug the fixture in and press the MODE button until:
2. When “r.XXX” is displayed you are in Red dimming mode. Press
the UP and DOWN buttons to adjust intensity.
3. When “G.XXX” is displayed you are in Green dimming mode.
Press the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press
the UP and DOWN buttons to adjust intensity.
5. When “U.XXX” is displayed you are in Amber dimming mode.
Press the UP and DOWN buttons to adjust intensity.
6. After you have adjusted the RGBA colors to make your desired
color you can then activate strobing by pressing the SET UP but ton to enter the Flash (strobe) mode.
7. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Sound Active Mode:
In this mode the WiFly Par QA5 will react to sound, and chase
through the different colors.
1. Plug the fixture in and press the MODE button until “SoXX” is
displayed. “XX” represents the sound active mode (01-16) cur-
rently displayed.
2. The fixture will now change via sound.
3. Press the SET UP button to adjust the sound sensitivity. “SJ-X”
should be displayed. Use the UP or DOWN buttons to adjust the
sensitivity. “SJ-1” is the least sensitive, “SJ-8” is the most.
Auto Run Mode:
In this mode the WiFly Par QA5 will run a auto program. There are 3
types of Auto Run Modes to choose from; Color
and both modes running together.
The running
Fade, Color Change,
speed is adjustable in
all 3 modes.
1. Plug the fixture in and press the MODE button until either “AFXX”,
“AJXX”, or “A-JF” is displayed.
• AFXX = Color Fade mode, there are 16 Color Fade modes to
choose from. Use the UP or DOWN buttons to scroll through the
different Auto Fade modes.
• AJXX = Color Change mode, there are 16 Color Change modes to
choose from. Use the UP or DOWN buttons to scroll through the
different Auto Change modes.
• A-JF = Both Color Fade and Color Change modes running.
2. After you have chosen your desired running mode press the SET
UP button until “SP.XX” is displayed. When this is displayed you
can adjust the running speed of your desired program. Use the
UP or DOWN button to adjust the speed between “SP.01” (slow est) and “SP.16” (fastest). Once you have set your desired running
speed, press the SET UP button to return to your desired Auto
Run Mode.
Static Color Mode:
1. Plug the fixture in and press the MODE button until “CLXX” is
displayed. “XX” represents the current color number displayed.
2. There are 15 colors to choose from. Select your desired color by
pressing the UP and DOWN buttons. After you have selected
your desired color you can activate strobing by pressing the SET
UP button to enter the Flash (strobe) mode.
3. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
DMX Mode:
Operating through a DMX controller gives the user the freedom to
create their own programs tailored to their own individual needs. This
function also allows you to use your fixtures as spot lights. The WiFLY
Par QA5 has 8 DMX modes: 1 Channel mode, 2 Channel mode, 3
Channel mode, 4 Channel mode, 5 Channel mode, 6 Channel mode,
7 Channel mode, and a 8 Channel mode. See pages 18-23 for each
modes’ DMX traits.
1. This function will allow you to control each individual fixture’s
traits with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
“A.XXX” is displayed. “XXX” represents the current displayed ad dress. Use the UP or DOWN buttons to select your desired DMX
address. then press the SET UP button to select your DMX
Channel mode.
3. When you press SET UP “ChXX” should be displayed. “XX” repre-
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 11 ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 12
WiFly Par QA5 Operating Instructions WiFly Par QA5 Operating Instructions
sent the current DMX Channel Mode.
4. Use the UP or DOWN buttons to scroll through the DMX Channel
modes. The Channel modes are listed below:
To run the 1 Channel Mode, press the MODE button until “Ch01”
is displayed. This is the 4 Channel DMX Mode.
To run the 2 Channel Mode, press the MODE button until “Ch02”
is displayed. This is the 2 Channel DMX Mode.
To run the 3 Channel Mode, press the MODE button until “Ch03”
is displayed. This is the 3 Channel DMX Mode.
To run the 4 Channel Mode, press the MODE button until “Ch04”
is displayed. This is the 4 Channel DMX Mode.
To run the 5 Channel Mode, press the MODE button until “Ch05”
is displayed. This is the 5 Channel DMX Mode.
To run the 6 Channel Mode, press the MODE button until “Ch06”
is displayed. This is the 6 Channel DMX Mode.
To run the 7 Channel Mode, press the MODE button until “Ch07”
is displayed. This is the 7 Channel DMX Mode.
To run the 8 Channel Mode, press the MODE button until “Ch08”
is displayed. This is the 8 Channel DMX Mode.
5. Please see pages 18-23 for DMX values and traits.
6. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX control-
ler.
Battery Life:
This menu is used to check/display the battery life.
1. Plug the fixture in and press the MODE button until “bXXX” is dis-
played. “XXX” represents a number between 0-100. The number
that is displayed is the remaining battery life. If “b---” is displayed,
it means either the battery is dead or your running the unit on AC
power.
Default Running Mode:
This is a default running mode. When this mode is activated all modes
will return to their default settings.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “dEFA” is displayed.
3. Press the UP and DOWN buttons simultaneously. Press the
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 13 ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 14
MODE button to exit.
ADJ RFC:
This function is used to activate and deactivate the ADJ RFC (Remote
Control). When this function is activated you can control the fixture
using the ADJ RFC. Please see the next page for ADJ RFC controls
and functions.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played.
2. Press the SET UP button until “rFXX” is displayed. “XX” repre-
sents either “on” or “oF”.
3. Press the UP or DOWN buttons to either activate the remote func tion (On) or deactivate it (Off).
WiFLY Address:
This function is used to set the WiFly address. This address must
match the address that is set to WiFly TransCeiver or WiFly controller.
1. Plug the fixture in and press the MODE button until “rCXX” is dis-
played. “XX” represents a number between 00-15.
2. Press the UP or DOWN buttons to either activate the remote func tion (On) or deactivate it (Off).
Dimmer Curve Setting:
1. Plug the fixture in and press the MODE button until “d.XXX” is dis played. Now press the SET UP button until “dr-X” is displayed,
“X” representing a number between 0-4.
2. There are 5 dimmer curve settings to choose from. Please see the
Dimmer Curve Diagram Chart on page 23 to see the settings and
their respective beginning and ending fade times.
WiFly Par QA5 Power Cord Daisy Chain
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 10 xtures maximum. After 10 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
NOTE: Fixtures cannot be power cord daisy chained and run by
battery power.
WiFly Par QA5 Master-Slave Configuration
WiFly Par QA5 WiFly Set Up
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave
mode. In Master-Slave operation one unit will act as the controlling unit
and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be pro-
grammed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Set the “Master” unit to your desired mode of operation.
3. On the “Slave” units press the MODE button until “SLAu” is dis-
played. The unit is now set as the “Slave” unit. Each slave unit
must be set to the same setting.
4. Connect the rst “Slave” unit to the “Master”, and the “Slave” unit
should now start follow the “Master”.
WiFly Par QA5 WiFly Master-Slave Set Up
This feature will let you link units to run in a master-slave mode without the use of XLR cables.
NOTE: The ADJ RFC control must be set to OFF to use this function.
1. Follow the instructions on page 14 to set the Wireless address.
The addresses on each fixture must be the same.
2. After you have set the WiFly address, select your master unit and
set your desired operating mode.
3. Put the attenna to a upright position then turn the WiFly On, using
the WiFly power switch.
4. For the Slave units, put the unit in Slave mode. See page 15
Master-Slave configuration when setting the unit as a Slave. Then
switch ON the WiFly power switch.
4. If everything is set up correctly, the Master units WiFly status LED
will glow orange, and the slave units Wireless status LED will glow
green.
NOTE: If they do not sync up master-slave, switch the Master fixtures WiFly power switch off then on again.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 15 ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 16
With this feature you are able to control the unit with DMX without the
need of XLR cables. Your DMX controller must be connected to a ADJ
WiFly TransCeiver to use this function. You are able to communicate
up to 400 feet (open line of sight)
NOTE: The ADJ RFC control must be set to OFF to use this function.
1. Turn on the WiFly function using the WiFly On/Off switch and
set the attenna to a upright position.
2. Follow the instructions on page 14 to set the Wireless address.
The address must match the address set on the WiFly Transceiver.
3. After you have set the WiFly address, follow the DMX instructions
on pages 12-13 to select your desired DMX Channel mode and
set your DMX address.
4. Apply power to the ADJ WiFly Transceiver. The fixture must be set
up first before you apply power to WiFly Transceiver.
5. If everything is set up properly and the fixture is receiving a
Wireless signal, Wireless status LED next to LED screen will glow
green. Note: If the sync does not work, switch the WiFly power off
then on again.
WiFly Par QA5 ADJ RFC Operation
The ADJ RFC remote (sold seperately) has many different functions and
allows you to control your WiFly Par QA5 from long distance. The ADJ
RFC remote can control your system up to 150 ft. To use the RFC you
must first activate the fixtures receiver, to activate the receiver please
see the instructions on page 14.
BLACKOUT - Pressing this button will blackout the fixture.
AUTO RUN - This button will run an automatic program. There are 3
Auto Run programs to choose from. Each press of the button will switch
between the different modes. You can control the speed of the Auto Run
modes by pressing the SPEED button and then pressing the “+” and “-”
buttons.
• AFXX = Color Fade mode, there are 16 Color Fade modes to choose
from. Use the UP or DOWN buttons to scroll through the different
Auto Fade modes.
• AJXX = Color Change mode, there are 16 Color Change modes to
choose from. Use the UP or DOWN buttons to scroll through the
different Auto Change modes.
• A-JF = Both Color Fade and Color Change modes running.
PROGRAM SELECTION - This button will activate Static Color mode.
Use the “+” or “-” to scroll through the 15 colors. Once you have found
your color, you can press the FLASH button to activate strobing and use
the “+” or “-” to adjust the Flash rate.
WiFLY Par QA5 1 Channel - DMX Values & Functions
Channel Value Function
1 COLOR MACROS
0 - 15 OFF
16 - 31 RED
32 - 47 GREEN
48 - 63 BLUE
64 - 79 AMBER
80 - 95 RED & GREEN
96 - 111 RED & BLUE
112 - 127 RED & AMBER
128 - 143 GREEN & BLUE
144 - 159 GREEN & AMBER
160 - 175 BLUE & AMBER
176 - 191 RED & GREEN & BLUE
192 - 207 RED & GREEN & AMBER
208 - 223 RED & BLUE & AMBER
224 - 239 GREEN & BLUE & AMBER
240 - 255 RED & GREEN & BLUE & AMBER
WiFLY Par QA5 2 Channel - DMX Values & Functions
Channel Value Function
FLASH - This button will activate the flash (strobe) effect. You can con-
trol the flash speed by pressing the “+” and “-” buttons.
SPEED - Press this button and use the “+” & “-” buttons to adjust the
speed of the Auto run mode.
SOUND ACTIVE - This button activates sound active mode. Use the
“+” or “-” to choose from 1 of 16 sound active modes. Press this button
again to enter sound sensitivity adjustment. Use the “+” or “-” buttons to
adjust the sound sensitivity.
R G B W/A - Press either one of these buttons and the press the “+” or
“-” to adjust the brightness. Press the FLASH button to activate strobing
and use the “+” or “-” to adjust the Flash rate.
“+” and “-” - Use these buttons to adjust the flash rate, speed of the
Auto Run mode, Auto Run program selection, sound sensitivity, and
color select.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 17 ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 18
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 MASTER DIMMER
0 - 255 0% - 100%
WiFLY Par QA5 3 Channel - DMX Values & Functions
Channel Value Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 MASTER DIMMER
0 - 255 0% - 100%
3 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
WiFLY Par QA5 4 Channel - DMX Values & Functions
Channel Value Function
WiFLY Par QA5 6 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
WiFLY Par QA5 5 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 19 ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 20
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
Channels 1, 2, 3, and 4 will not work, when Channel 6 is being
used.
WiFLY Par QA5 7 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
7 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
Channels 1, 2, 3, and 4 will not work, when Channel 7 is being
used.
WiFLY Par QA5 8 Channel - DMX Values & Functions
Channel Value Function
WiFLY Par QA5 8 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 STROBING/PROGRAM SPEED/
SOUND SENSITIVITY
0 - 15 NO FUNCTION
16 - 255 STROBING SLOW - FAST
0 - 255 SPEED CONTROL SLOW - FAST
SOUND SENSITIVITY
0 - 31 NO FUNCTION
32 - 255 LEAST SENSITIVE - MOST SENSITIVE
7 PROGRAM SELECTION MODE
0 - 51 DIMMING MODE
52 - 102 COLOR MACRO MODE
103 - 153 COLOR CHANGE MODE
154 - 204 COLOR FADE MODE
205 - 255 SOUND ACTIVE MODE
8 COLOR MACROS/PROGRAMS/
SOUND ACTIVITY
0 - 255 COLOR MACRO MODE
(See 1 Channel DMX mode for colors)
COLOR CHANGE MODE
0 - 15 COLOR CHANGE 1
16 - 31 COLOR CHANGE 2
32 - 47 COLOR CHANGE 3
48 - 63 COLOR CHANGE 4
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 21 ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 22
8 COLOR CHANGE MODE CONT.
64 - 79 COLOR CHANGE 5
80 - 95 COLOR CHANGE 6
96 - 111 COLOR CHANGE 7
112 - 127 COLOR CHANGE 8
128 - 143 COLOR CHANGE 9
144 - 159 COLOR CHANGE 10
160 - 175 COLOR CHANGE 11
176 - 191 COLOR CHANGE 12
192 - 207 COLOR CHANGE 13
208 - 223 COLOR CHANGE 14
224 - 239 COLOR CHANGE 15
240 - 255 COLOR CHANGE 16
COLOR FADE MODE
0 - 15 COLOR FADE 1
16 - 31 COLOR FADE 2
32 - 47 COLOR FADE 3
48 - 63 COLOR FADE 4
64 - 79 COLOR FADE 5
80 - 95 COLOR FADE 6
96 - 111 COLOR FADE 7
112 - 127 COLOR FADE 8
128 - 143 COLOR FADE 9
144 - 159 COLOR FADE 10
160 - 175 COLOR FADE 11
176 - 191 COLOR FADE 12
192 - 207 COLOR FADE 13
208 - 223 COLOR FADE 14
224 - 239 COLOR FADE 15
240 - 255 COLOR FADE 16
SOUND ACTIVE MODE
0 - 15 SOUND ACTIVE MODE 1
16 - 31 SOUND ACTIVE MODE 2
WiFLY Par QA5 8 Channel - DMX Values & Functions
Channel Value Function
8 SOUND ACTIVE MODE CONT.
32 - 47 SOUND ACTIVE MODE 3
48 - 63 SOUND ACTIVE MODE 4
64 - 79 SOUND ACTIVE MODE 5
80 - 95 SOUND ACTIVE MODE 6
96 - 111 SOUND ACTIVE MODE 7
112 - 127 SOUND ACTIVE MODE 8
128 - 143 SOUND ACTIVE MODE 9
144 - 159 SOUND ACTIVE MODE 10
160 - 175 SOUND ACTIVE MODE 11
176 - 191 SOUND ACTIVE MODE 12
192 - 207 SOUND ACTIVE MODE 13
208 - 223 SOUND ACTIVE MODE 14
224 - 239 SOUND ACTIVE MODE 15
240 - 255 SOUND ACTIVE MODE 16
WiFly Par QA5 Battery Status & Charging
Battery Status:
This function is used to check the life status of the battery.
Plug the fixture in and press the MODE button until “bXXX” is
displayed. “XXX” represents an number between “000” and
“100”. The number that is displayed is the remaining battery
life. If “b---” is displayed, it means the battery is dead or you are
running the unit on AC power. Please do not let the battery
fully die, this severly shortens the life of the battery.
Example: If “b050” is displayed, the battery is at half life. If
“b025” is displayed, the battery is at 25% life.
NOTE: When the battery is charging or if the battery life is
below 30% the digital display will flash.
NOTE: After 20 seconds of inactivity, the display will revert
back to the battery life display.
When Channel 7 is between the values of 0-51, Channels 1-4 are
used, and Channel 6 will control strobing.
When Channel 7 is between the values of 52-102, Channel 8 is in
Color Macros Mode, and Channel 6 will control strobing.
When Channel 7 is between the values of 103-153, Channel 8 is in
Color Change Mode, and Channel 6 will control the color change
speed.
When Channel 7 is between the values of 154-204, Channel 8 is
in Color Fade Mode, and Channel 6 will control the color fade
speed.
When Channel 7 is between the values of 205-255, Channel 8 is in
Sound Active Mode, and Channel 6 will control the sound sensitivity.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 23 ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 24
Battery Recharge: To recharge the battery, plug the supplied
AC cord into the AC input on the side of the unit and plug the
other end into a matching power supply. It takes about 9 hours
to reach full charge. The display will STOP ashing when the
unit reaches 100% charge.
Note: When unplugging the unit from charging and then
applying power via battery, there will be a minimal charge
drop.
For a faster recharge, put the Load Switch in the “Off” position
and the Battery Switch in the “ON” position.
WiFly Par QA5 Photometric Chart
WiFly Par QA5 Dimmer Curve Chart
Dimmer
Dimmer
Dimmer
Dimmer
100
%
100
%
100
100
%
%
50
%
50
%
50
50
%
%
10
%
10
%
10
10
%
%
WiFly Par QA5 Battery Replacement
1. Uscrew the four thumbscrews
that hold the battery door in
place.
2. Remove the battery door to
access the battery.
3. Carefully remove the battery
from the compartment.
4. Carefully pull out the battery
connector cables.
0
0
0
0
Delay mode
dr-0
dr-1
dr-2
dr-3
dr-4
T
rise
DMX delay
T
dow n
Trise(ms) Tdown(ms)
0 0
800 1300
1010 1560
1200 1950
1280 2600
t
t
t
t
(
ms
(
ms
(
(
ms
ms
)
)
)
)
5. Carefully disconnect the battery cables.
6. Once the cables have been disconnected you can now connect your new battery. Put everything back together in reverse
order.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 26ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 25
WiFly Par QA5 Fuse Replacement
Disconnect the unit from its power source. Remove the power cord
from the unit. Once the cord has been removed, you will find that the
fuse holder is located inside the power socket. Insert a flat-head screw
driver into the power socket and gently pry out the fuse holder. Remove
the bad fuse and replace with a new one. The fuse holder also has a
holder for a spare fuse.
WiFly Par QA5 Trouble Shooting
Listed below are a few common problems the user may encounter,
with solutions.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are
wired correctly (pin 3 is “hot”; on some other DMX devices
pin 2 may be ‘hot’). Also, check that all cables are connected
to the right connectors; it does matter which way the inputs
and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
2. Make sure that Sound Active mode is activated.
WiFly Par QA5 Warranty
MANUFACTURER’S LIMITED WARRANTY
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products
to be free of manufacturing defects in material and workmanship for a prescribed period from
the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the
product is purchased within the United States of America, including possessions and
territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before sending back the
product–please contact ADJ Products, LLC Service Department at 800-322-6337. Send the product
only to the ADJ Products, LLC factory. All shipping charges must be pre-paid. If the requested repairs or
service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay
return shipping charges only to a designated point within the United States. If the entire instrument is
sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If
any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for
loss of or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modified in any
manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the
product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior
written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because
not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintnance, cleaning or periodic check
up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense
with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole
discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August
15, 2012, and bear indentifying marks to that effect.
WiFly Par QA5 Cleaning
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses must be carried out periodically to optimize light
output.
1. Use normal glass cleaner and a soft cloth to wipe down the
outside casing.
2. Clean the external optics with glass cleaner and a soft cloth
every 20 days.
3. Always be sure to dry all parts completely before plugging
the unit back in.
Cleaning frequency depends on the environment in which the fixture
operates (i.e. smoke, fog residue, dust, dew).
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 27
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products
without any obligation to include these changes in any products theretofore manufactured.
No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with
products described above. Except to the extent prohibited by applicable law, all implied warranties made
by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness,
are limited in duration to the warranty period set forth above. And no warranties, whether expressed or
implied, including warranties of merchantability or fitness, shall apply to this product after said period
has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is
expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or
damage, direct or consequential, arising out of the use of, or inability to use, this product.
This warranty is the only written warranty applicable to ADJ Products, LLC Products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
•LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing,
Lighting Stands etc. excluding LEDs and lamps)
•LaserProducts=90-DayLimitedWarranty
•L.E.D.Products=3-year(1095days)LimitedWarranty(excluding motors, PCB boards, and power
supplies, which have a 1-year (365 day Limited Warranty) and batteries which have a 180 day
limited warranty). Only the L.E.D.s carry a 3-year warranty
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 28
WiFly Par QA5 Notes
WiFly Par QA5 Notes
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 29
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 30
WiFLY Par QA5 Specifications
Model:
WiFLY Par QA5
Voltage: 100V ~ 240V/50~60Hz
Battery Life: 6 Hours Full On (Full Charge)
Battery Lifetime*: Average Lifetime is 500 Charges
LEDs: 5 x 5W Quad LEDs (RGBA 4-in-1)
Beam Angle: 25 Degrees
Working Position: Any safe working position
Power Draw: 58W
Power Cord Daisy Chain: 10 Fixtures Max.
Fuse: 2 Amp
Weight: 10lbs./ 4.2Kgs.
Dimensions: 10.5” (L) x 9.5” (W) x 6.5” (H)
265 x 240 x 164mm
Colors: RGBA Color Mixing
DMX Channels: 8 DMX Modes: 1 Channel Mode,
2 Channel Mode, 3 Channel Mode,
4 Channel Mode, 5 Channel Mode
6 Channel Mode, 7 Channel Mode,
& 8 Channel Mode
Warranty**: 3 Year (1,095 days) Limited
Warranty
* This depends on charging frequency
**See Warranty page for more details
Auto Sensing Voltage: This xture contains a automatic voltage switch, which
will auto sense the voltage when it is plugged into the power source.
Please Note: Specications and improvements in the design of this unit and
this manual are subject to change without any prior written notice.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 User Manual Page 31
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@adj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
Netherlands
www.adj.com
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Loading...
