MEGA GO PAR64 RGBA
MEGA GO PAR64 RGBA Introduction
Unpacking: Thank you for purchasing the MEGA GO PAR64 RGBA
by ADJ Products, LLC. Every MEGA GO PAR64 RGBA has been
thoroughly tested and has been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have
occurred during shipping. If the carton appears to be damaged, care-
fully inspect your xture for any damage and be sure all accessories
necessary to operate the unit has arrived intact. In the case damage
has been found or parts are missing, please contact our toll free customer support number for further instructions. Do not return this unit to
your dealer without rst contacting customer support.
Introduction: The MEGA GO PAR64 RGBA is a rechargeable lithium
battery powered, DMX intelligent, LED par fixture. This unit give you the
freedom to set up your fixture where ever you wish without the restric-
tions of power. The built-in battery will keep charge for up to 8 hours
(full on) from a full, single charge. This xture can be used in a stand
alone mode or connected in a Master/Slave conguration. This wash
has five operating modes: Sound Active mode, Auto Run mode, RGB
mode, Static Color mode, and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or suggestions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
Rev. 4/14
User Instructions
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures warranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
ADJ Products, LLC - www.adj.com - MEGA GO PAR64 RGBA User Manual Page 2
MEGA GO PAR64 RGBA Features
MEGA GO PAR64 RGBA Safety Precautions
• Rechargeable Lithium Battery
• Mulit-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 7 DMX Modes: 1 Channel Mode, 2 Channel Mode, 4 Channel
Mode, 5 Channel Mode, 6 Channel Mode, 7 Channel Mode, and
8 Channel Mode.
• ADJ RFC compatiable (Not Included)
• Power Cord Daisy Chain (See page 14)
MEGA GO PAR64 RGBA Warranty Registration
The MEGA GO PAR64 RGBA carries a 2 year limited warranty. Please
fill out the enclosed warranty card to validate your purchase. All
returned service items whether under warranty or not, must be freight
pre-paid and accompany a return authorization (R.A.) number. The
R.A. number must be clearly written on the outside of the return package. A brief description of the problem as well as the R.A. number
must also be written down on a piece of paper included in the shipping carton. If the unit is under warranty, you must provide a copy of
your proof of purchase invoice. You may obtain a R.A. number by contacting our customer support team on our customer support number.
All packages returned to the service department not displaying a R.A.
number on the outside of the package will be returned to the shipper.
MEGA GO PAR64 RGBA Installation
The unit should be mounted using a mounting clamp (not provided),
axing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 22 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
ADJ Products, LLC - www.adj.com - MEGA GO PAR64 RGBA User Manual Page 4ADJ Products, LLC - www.adj.com - MEGA GO PAR64 RGBA User Manual Page 3
MEGA GO PAR64 RGBA Battery Precautions MEGA GO PAR64 RGBA Battery Precautions
1. Handling of Batteries
1.1 Do Not Short Circuit the Battery
Try to never short circuit the battery. It generates a very high
current which could cause the battery to overheat which may
result in electrolyte gel leakage, harmful fumes, or explosion.
The LIR tabs may easily short-circuit by placing them on conductive surface. A short circuit may lead to heat build up and
damage of the battery. An appropriate circuitry with PCM is
employed to protect accidental short circuit of the battery pack.
1.2 Mechanical shock
Droping the unit, impact hit, bending, etc. may cause failure or
shortend life of the LIR battery.
3. Other
3.1 Battery connection
1). Direct soldering of wire leads or devices to the battery is
strictly prohibited.
2). Lead tabs with pre-soldered wiring shall be spot welded to
the batteries. Direct soldering may cause damage of components, such as separator and insulator, by heat build up.
3.2 Prevention of short circuit within a battery pack
There is enough insulation layers between wiring and the bat-
teries to provide extra safety protection. The battery pack is
constructed in a way that no short circuit will occur which may
cause smoke or re.
3.3 Do No Disassemble the Batteries
1). Never disassemble the batteries.
Doing this may cause a internal short circuit in the battery,
which may lead to harmful fumes, re, explosion, or other problems.
2). Electrolyte Gel is harmful
Electrolyte Gel should not leak from the LIR battery. Should the
electrolyte gel come into contact with the skin or eyes, ush the
area of contact immediately with fresh water and seek medical
attention immediately.
3.4 Do Not Expose the Battery to Heat or Fire
Never incinerate or dispose of the batteries in re. This may
cause an explosion, which would be very dangerous.
3.5 Do Not Expose the Battery to water or liquids
Never soak/drop the batteries in liquids such as water, seawater, drinks such as soft drinks, juices, coee or other.
3.6 Battery Replacement
For battery replacement please contact ADJ customer support
(800) 322-6337.
3.7 Do Not use a damaged Battery
The battery could be damaged during shipping, caused by
shock. Should the battery be found damaged, including damages to the plastic casing of the battery, deformation of the
battery package, smelling of an electrolyte, or leakage of the
electrolyte gel, or other, DO NOT use the battery. A battery with
a odor of electrolyte or a gel leakage should be placed away
from re to avoid re or explosion.
4. Battery Storage
When storing the battery, it should be stored at room tempera-
ture, with a charge of at least 50%. We recommend that during
long periods of storage that the battery be charged every 6
months. Doing this will prolong the life of the battery and will
also make sure that the battery charge does not fall below the
30% mark.
5. Other Chemical Reaction
Because batteries utilize a chemical reaction, battery performance will deteriorate over time even if stored for a long
period of time without being used. In addition, if the various
usage conditions such as charge, discharge, ambient tempera-
ture, etc. are not maintained within the specied ranges, the
ADJ Products, LLC - www.adj.com - MEGA GO PAR64 RGBA User Manual Page 5
ADJ Products, LLC - www.adj.com - MEGA GO PAR64 RGBA User Manual Page 6
MEGA GO PAR64 RGBA Battery Precautions
MEGA GO PAR64 RGBA Set Up
life expectancy of the battery maybe shortened or the device
in which the battery is used may be damaged by electrolyte
gel leakage. If the batteries cannot maintain a charge for long
periods of time, even when they are charged correctly, this may
indicate it is time to change the battery.
6. Battery Disposal
Please dispose of battery according to local regulations.
Power Supply: The ADJ MEGA GO PAR64 RGBA contains a auto-
matic voltage switch, which will auto sense the voltage when it is
plugged into the power source. With this switch there is no need to
worry about the correct power voltage, this unit can be plugged in
anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures
and controllers. A DMX controller sends DMX data instructions from
the controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
dierent manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compli-
ant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
ADJ Products, LLC - www.adj.com - MEGA GO PAR64 RGBA User Manual Page 7
Data Cable (DMX Cable) Requirements (For DMX Operation):
The MEGA GO PAR64 RGBA can be controlled via DMX-512 protocol.
The MEGA GO PAR64 RGBA has 7 DMX channel modes, please see
page 12-13 for the dierent modes. The DMX address is set on the back
panel of the MEGA GO PAR64 RGBA. Your unit and your DMX controller require a standard 3-pin XLR connector for
data input and data output (Figure 1). We recommend Accu-Cable DMX cables. If you are making
your own cables, be sure to use standard 110-120
Ohm shielded cable (This cable may be purchased
at almost all pro lighting stores). Your cables should
be made with a male and female XLR connector on
either end of the cable. Also remember that DMX
cable must be daisy chained and cannot be split.
ADJ Products, LLC - www.adj.com - MEGA GO PAR64 RGBA User Manual Page 8
Figure 1
Loading...
