Page 1
Revised 11/01
Los Angeles Ca. 90058
www.americandj.com
American DJ
4295 Charter Street
American DJ®
Dual Gem
User Instructions
®
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
your nearest American DJ dealer.
PLEASE do not discard the shipping carton in the trash. Please
recycle when ever possible.
©American DJ Supply® - www.americandj.com - Dual Gem™ Instruction Manual Page 2
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
Warning! To prevent or reduce the risk of electrical shock or fi re, do
Voice: (800) 322-6337
Fax: (323) 582-2610
related issue please contact American DJ®. Service Hours are Monday
through Friday 9:00 a.m. to 5:00 p.m. Pacifi c Standard Time.
American DJ® provides a toll free customer support line, to provide set
up help and to answer any question should you encounter problems
during your set up or initial operation. You may also visit us on the web
at www.americandj.com for any comments or suggestions. For service
return the unit to your dealer without fi rst contacting customer support.
Customer Support:
Thank you for purchasing the Dual Gem™ by American DJ®. Every
of this unit. These instructions contain important safety information
regarding the use and maintenance of this unit. Please keep this
manual with the unit, for future reference.
Unpacking:
Dual Gem™ has been thoroughly tested and has been shipped in
perfect operating condition. Carefully check the shipping carton for
damage that may have occurred during shipping. If the carton appears
to be damaged, carefully inspect your unit for any damage and be sure
all equipment necessary to operate the system has arrived intact. In the
event damage has been found or parts are missing, please contact our
toll free customer support number for further instructions. Please do not
General instructions:
To optimize the performance of this product, please read these operat-
ing instructions carefully to familiarize yourself with the basic operations
DUAL GEM™ Introduction
Page 2
D. The fixture does not appear to operate normally or exhibits a
marked change in performance.
Dual Gem™ Halogen Lamp Warning
This fixture is fitted with halogen lamps which are
highly susceptible to damage if improperly handled.
Never touch the lamps with your bare fingers as
the oil from your hands will shorten lamp life. Also,
never move the fixture until the lamps have had
ample time to cool. Remember, lamps are not cov-
ered under warranty conditions.
fuse replacement guidelines on page 5.
• Be sure the local power outlet match the required voltage of the unit.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no
user serviceable parts inside.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• To reduce the risk of electrical shock or fi re, do not expose this unit
rain or moisture
• This unit is intended for indoor use only, use of this product outdoors
voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-Cord Protection - Power-supply cords should be routed
so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit from
the fixture. Do not attempt to remove or break off the ground prong
from the electrical cord. This prong is used to reduce the risk of
electrical shock and fi re in case of an internal short.
• The fixture should be serviced by qualified service personnel when:
A. The power cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
Safety Issue: This unit may blow a fuse if the maximum allotted load
of 3 amps is reached. If the fuse needs replacement, please see the
DUAL GEM™ Precautions
for a R.A. number.
©American DJ Supply® - www.americandj.com - Dual Gem™ Instruction Manual Page 4©American DJ Supply® - www.americandj.com - Dual Gem™ Instruction Manual Page 3
freight pre-paid and accompany a return authorization (R.A.) number.
If the unit is under warranty you must provide a copy of your proof
of purchase invoice. Please contact American DJ
® customer support
The Dual Gem™ carries a one year (365 days) limited warranty.
Please fill out the enclosed warranty card to validate your purchase.
All returned service items whether under warranty or not, must be
Dual Gem™ Warranty Registration
is preset at the factory for optimum performance and is not user
adjustable.
wheels will rotate continuously. Mode 2: When the switch is in the
down position the two internal dichroic dishes will rotate back and forth
to an audio source via an internal microphone. The audio sensitivity
unit. This unit is sound active and has two different operating modes.
General Operation: This fixture is designed to operate as a stand
alone unit, there is no need of a controller. It has been tested and the
lamp has been installed at the factory there is no assembly necessary.
The Dual Gem™ is ready to be plugged in out of the box, there is no
power switch. When this fixture is plugged in, the units two internal
dichroic colored dishes will rotate. After plugging the unit if there is no
lamp output check the fuse and bulbs. If the fuse and bulbs are good,
please contact customer support for further instructions. This fixture
features a light weight case design and an adjustable hanging bracket.
This fixture can be operated in two different modes.
Operating Modes: This unit comes with a 2-way operating switch
located on the bottom of the unit. The switch controls two (2) different
operating modes one of which is a sound active mode. Mode 1: When
the switch is in the up position the unit's two internal dichroic color
Power Supply: Before plugging your unit in, be sure the source
voltage in your area matches the required voltage for your American
DJ® Dual Gem™ before attempting operation.
Introduction: The American DJ® Dual Gem
Dual Gem™ Operation
™
fl ower effect. This unit is sound-active and has two different operating
modes. This fixture is designed for mobile DJ’s, clubs, bands, roller
rinks and any arena that requires a compact, light weight, easy to use
is a dual output moon-
Page 3
3. Carefully pull up the front cover.
4. Remove and replace the bad lamp, then close and tighten the
cover.
©American DJ Supply® - www.americandj.com - Dual Gem™ Instruction Manual Page 5
Lift the top cover to expose the
lamp socket assembly.
2. Loosen the thumb screws located on the front sides of the unit.
lamps. Never touch the new lamp with your bare fingers.
lamps. Lamp replacement has been made simple by incorporating the
use of a flip-up front cover that is retained by thumb screws.
1. Be sure to follow the proper procedures when handling halogen
Lamp Replacement: Caution! Never attempt to change the lamps
when the fixture is plugged in. Always disconnect the main power
and allow the unit ample time to cool before attempting to replace the
the fuse holder.
holder. Remove the fuse holder to expose the fuse. Remove the old
fuse and discard it. Replace the fuse with the same type and insert
Fuse Replacement: Disconnect the unit’s main power supply. Insert
a standard flat head screw driver in to the fuse holder housing. Turn
the screwdriver in counter-clockwise direction to unscrew the fuse
servicing. Continuing to use the unit may cause serious damage.
continue to blow either one, STOP using the unit. Contact customer
support for further instructions, you may have to return the unit for
Warning: If after you have replaced the lamp or fuse and you
unless otherwise specified by an authorized American DJ® technician.
Caution: Always replace with the exact same type lamp and fuse,
Replacing with anything other than the specified part can damage
your unit and will void your manufactures warranty.
1. Be sure you have connected your unit into a matching wall power
outlet.
2. Be sure the external fuse has not blown. The fuse is located on the
rear panel.
3. Remove the lamp cover and be sure the lamps are seated in the
socket properly. Occasionally lamps become loose during shipping
be sure the lamps are pushed in to their sockets all the way.
Unit does not respond to sound;
1. Low frequencies (bass) should cause the unit to react to sound.
Tappin g on the microphone, quiet or high pitched sounds may not
activate the unit.
2. The unit is not in sound active mode, flip the mode switch to the
other position. The mode switch is located on the rear of the unit.
©American DJ Supply® - www.americandj.com - Dual Gem™ Instruction Manual Page 6
with solutions.
No light output from the unit;
5. Always be sure to dry all parts completely before plugging the unit
Trouble Shooting:
Listed below are a few common problems that you may encounter,
back in.
Dual Gem™ Trouble Shooting
cloth every 20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
3. Clean the external optics and mirror with glass cleaner and a soft
Fixture Cleaning:
Dual Gem™ Cleaning Dual Gem™ Fuse & Lamp Replacement
Due to fog residue, smoke, and dust cleaning the internal and external
optical lenses and mirror should be carried out periodically to optimize
light output. Cleaning frequency depends on the environment in which
the fixture operates (I.e. smoke, fog residue, dust, dew). In heavy club
use we recommend cleaning on a monthly basis. Periodic cleaning will
ensure longevity, and crisp output.
1. Use normal glass cleaner and a soft cloth to wipe down the outside
casing.
2. Use a brush to wipe down the fan grill.
Page 4
tive parts at its expense, and will absorb all expenses for warranty service and repair labor
damage, direct or consequential, arising out of the use of, or inability to use, this product.
sumer’s and or Dealer’s sole remedy shall be such repair or replacement as is expressly
provided above; and under no circumstances shall American DJ® be liable for any loss or
G. This warranty is the only written warranty applicable to American DJ® Products and
supersedes all prior warranties and written descriptions of warranty terms and conditions
heretofore published.
H. Lamps are not covered under this or any other warranty either written or implied.
©American DJ Supply® - www.americandj.com - Dual Gem™ Instruction Manual Page 7
warranties of merchantability or fi tness, are limited in duration to the warranty period set
forth above. And no warranties, whether expressed or implied, including warranties of mer-
chantability or fi tness, shall apply to this product after said period has expired. The con-
manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any acces-
sory supplied with products described above. Except to the extent prohibited by applicable
law, all implied warranties made by American DJ
were manufactured after January 1, 1990, and bear identifying marks to that effect.
E. American DJ
its products without any obligation to include these changes in any products theretofore
® reserves the right to make changes in design and/or improvements upon
by reason of defects in material or workmanship. The sole responsibility of American DJ®
under this warranty shall be limited to the repair of the product, or replacement thereof,
including parts, at the sole discretion of American DJ®. All products covered by this warranty
instruction manual.
D. This is not a service contract, and this warranty does not include maintenance, cleaning
or periodic check-up. During the period specifi ed above, American DJ
American DJ® factory unless prior written authorization was issued to purchaser by Ameri-
can DJ®; if the product is damaged because not properly maintained as set forth in the
to a designated point within the United States. If the entire instrument is sent, it must be
shipped in its original package. No accessories should be shipped with the product. If any
accessories are shipped with the product, American DJ® shall have no liability whatsoever
charges must be pre-paid. If the requested repairs or service (including parts replacement)
are within the terms of this warranty, American DJ® will pay return shipping charges only
responsibility to establish the date and place of purchase by acceptable evidence, at the
time service is sought.
B. For warranty service, send the product only to the American DJ
free of manufacturing defects in material and workmanship for a period of one year (365
days) from the date of purchase. This warranty shall be valid only if the product is purchased
within the United States of America, including possessions and territories. It is the owner’s
1 YEAR (365 DAYS) LIMITED WARRANTY
A. American DJ® hereby warrants, to the original purchaser, American DJ® products to be
Dual Gem™ Warranty
for loss of or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product
is modifi ed in any manner which American DJ
ability of the product; if the product has been repaired or serviced by anyone other than the
® in connection with this product, including
Web: www.americandj.com / E-mail: [email protected]
American DJ Group of Companies World Headquarters:
4295 Charter Street Los Angeles, CA 90058 USA
® concludes, after inspection, affects the reli-
Duty Cycle: None
Fuse: 3 Amp GMA
® factory. All shipping
Weight: 6 Lbs.
Gobos: None
Colors: Multi-Colored Dichroic Dish
Dimensions: 4.5” H x 11” W x 9.25” D
Voltage*: 120v~60Hz or 220v~50/60Hz
Model: Dual Gem™
Lamps: 2 x LL-64610 12v/50w
Technical Specifications:
® will replace defec-
Please Note: Specifi cations and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Warranty: One Year (365 Days)
* Voltage is preset at the factory and is not user selectable
Reflective Dichroic Mirror Dish
Ventilation: Fan Cooled
Operating Mode: Two operating modes
Optics: Quality Glass Lens and
Tel: 323-582-2650 / Fax: 323-582-2610
©American DJ Supply®
Loading...
