ADJ APX12-GO-BT Users Manual

APX12 GO BT

user manual

©2020 ADJ PRODUCTS LLC all rights reserved. Information, specifications, diagrams, images, and

Date

Document Version

Notes

06/09/20

1.0

Initial Release.

APX12 GO BT CONTACT INFORMATION

instructions herein are subject to change without notice. ADJ logo and identifying product names and
numbers herein are trademarks of ADJ PRODUCTS LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information now allowed by statutory or judicial law
or hereinafter granted. Product names used in this document may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged. All non-ADJ brands and
product names are trademarks or registered trademarks of their respective companies.

ADJ PRODUCTS LLC and all affiliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as
a result of the improper, unsafe, insufficient and negligent assembly, installation, rigging, and operation
of this product.

ADJ PRODUCTS LLC USA

6122 S. Eastern Ave. Los Angeles, CA 90040
323-582-2650 | Fax [phone] | www.adj.com | [e-mail]

ADJ SUPPLY Europe B.V
Junostraat 2 6468 EW Kerkrade, The Netherlands
[phone] | Fax [phone] | www.adj.eu | [e-mail]

ADJ PRODUCTS GROUP Mexico
AV Santa Ana 30 Parque Industrial Lerma, Lerma, Mexico 52000
[phone] | [e-mail]

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is key to protecting the environment. Please turn off all electrical products when
they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment from
power when not in use. Thank you!

DOCUMENT VERSION

Due to additional product features and/or enhancements, an
updated version of this document may be available online.
Please scan the QR Code with your mobile device or visit

www.adj.com for the latest revision/update of this manual, before

installation and/or programming.

2

General Information

4

Handling

5

Unpacking

7

Safety

8

Key Features | Included Items | Product Registration

9

Controls and Features

10

Operation

12

Installation

14

Tech ni ca l Sp ec if ic at ions

15

Dimensional Drawings

16

APX12 GO BT CONTENTS

3

Introduction:

APX12 GO BT GENERAL INFORMATION

Congratulations and thank you for purchasing the American Audio® APX 12 GO BT professional battery
powered speaker. This speaker is a representation of American Audio’s continuing commitment to
produce the best and highest quality audio products possible at an affordable price. The APX 12 GO
BT is a 12-inch active speaker featuring battery power, Bluetooth pairing, flash drive playback, built-in
FM radio, and an LCD screen. This speaker’s extremely high efficiency design, low power consumption,
and strong output power is ideal for small and mid-size events. The speaker includes a pole mount cup
and an integrated trolley and handle. Please read and understand this manual completely before
attempting to operate your new speaker system. This booklet contains important information
concerning the proper and safe operation of your new speaker.

Customer
Support:

American Audio® provides a toll free customer support line, to provide set up help and answer any
questions should you encounter problems during your initial set up or operation. You may also visit us
on the web at www.adj.com for any comments or suggestions. Service Hours are Monday through
Friday 8:00 a.m. to 4:30 p.m. Pacific Standard Time.
Phone: [phone]
E-mail: [e-mail]

Caution! There are no user serviceable parts inside this speaker. Do not attempt any repairs without
being instructed to do so by an authorized American Audio technician. Doing so will void your
manufacturer’s warranty. In the unlikely event your speaker may require service, please contact
American Audio®.

4

APX12 GO BT HANDLING

RIS K OF ELE CTR IC SH OCK

DO NOT OPEN

CAUTION

The lightning flash symbol is intended to alert the user to the presence
of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to a person or persons.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE THE COVER (OR BACK COVER). THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICE TO YOUR
AUTHORIZED AMERICAN AUDIO SERVICE TECHNICIAN

The exclamation point symbol is intended to alert the user to the
presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.

Electrical Precautions:

5

APX12 GO BT HANDLING

IMPORTANT SAFETY INSTRUCTIONS

READ INSTRUCTIONS – All the safety and operating instructions should be reviewed before operating the product.
RETAIN INSTRUCTIONS – The safety and operating instructions should be retained for future reference.
HEED WARNINGS – All warnings on the products and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS – All operating and use instructions should be followed.
CLEANING – The product should be cleaned only with a polishing cloth or a soft dry cloth. Never clean with furniture

wax, benzine, insecticides, or other volatile liquids since they may corrode the cabinet.

ATTAC HM EN TS – Do not use attachment that have not been recommended by the product manufacturer, as they may

cause hazards.

WATER AND MOISTURE – Do not use this product near water – for example, near a bath tub, wash bowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming pool, or in any other similar conditions.

ACCESSORIES – Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall,

causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod,
bracket, or table that has been recommended by the manufacturer, or sold with the product. Any mounting of the
product should follow the manufacturer’s instructions, and should use a mounting accessory that has been
recommended by the manufacturer.

CART – A product and cart combination should be moved only with care. Quick stops, excessive

force, and uneven surfaces may cause the product and cart combination to overturn.

VENTILATION – Slots and openings in the cabinet are provided for ventilation and to ensure reliable

operation of the product, and to protect it from overheating, and these openings must not be
blocked or covered. The openings should never be blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

POWER SOURCES – This product should be operated only from the type of power source indicated on the product

label. If you are not sure of the type of power supply available, consult your product dealer or local power company.

LOCATION – The appliance should be installed in a stable location.
NON-USE PERIODS – The power cord of the appliance should be unplugged from the outlet when left unused for a long

period of time.

GROUNDING OR POLARIZATION

- If this product is equipped with a polarized alternating current line plug (a plug having one blade wider than the
other), it will fit into the outlet only one way. This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug should still fail to fit, contact you electrician to replace your obsolete
outlet. DO NOT DEFEAT THE SAFETY PURPOSE OF THE POLARIZED PLUG.

- If this product is equipped with a three-wire grounding type plug (a plug having a third pin for grounding), it will
only fit into a grounding type power outlet. This is a safety feature. If you are unable to insert the plug into the
outlet, contact your electrician to replace your obsolete outlet. DO NOT DEFEAT THE SAFETY PURPOSE OF
THE GROUNDING TYPE PLUG.

POWER CORD PROTECTION – Power supply cords should be routed so that they are not likely to be walked on or

pinched by items placed upon or against them, paying particular attention to cords at plug, convenience
receptables, and the point where they exit from the product.

OUTDOOR ANTENNA GROUNDING – If an outside

antenna or cable system is connected to the product,
be sure the antenna or cable system is grounded so as
to provide some protection against voltage surges and
built-up static charges. Article 810 of the National
Electrical Code, ANSI/NFP A70, provides information
with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements
for the grounding electrode. See Figure A to the right
for reference.

6
