AIRSTREAM DMX BRIDGE

©2015 ADJ Products, LLC all rights reserved. Information,

specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis­claim any and all liabilities for property, equipment, building,
and electrical damages, injuries to any persons, and direct or
indirect economic loss associated with the use or reliance of
any information contained within this document, and/or as a
result of the improper, unsafe, unsucient and negligent as­sembly, installation, rigging, and operation of this product.

12/15

User Instructions

Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!

Airstream DMX Bridge Introduction

Airstream DMX Bridge General Instructions

Introduction: Congratulations and thank you for purchasing the
ADJ Airstream DMX Bridge. The Airstream DMX Bridge is a wire­less bridge between your Wi-Fi device and ADJ lighting products
equipped with WiFly or wired DMX512. The ADJ Airstream DMX
Bridge is the ideal solution for DJ’s, nightclubs, bars or for any
event where you don’t want data cables to be seen, and when it
is not easy to run data cables to your fixture(s) location. The Air­stream DMX Bridge creates its own local secure Wi-Fi network
so that you can use your IPhone or IPad as a lighting controller
using the Airstream DMX app. A single shared DMX512 universe
is transmitted over both the DMX512 connector and the Wifly
network.

Customer Support: ADJ Products, LLC provides a toll free cus­tomer support line, to provide set up help and to answer any
question should you encounter problems during your set up or
initial operation. You may also visit us on the web at www.adj.
com for any comments or suggestions. For service related issue
please contact ADJ Products, LLC. Service Hours are Monday
through Friday 8:00 a.m. to 4:30 p.m. Pacific Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]

Warning! To prevent or reduce the risk of electrical shock or fire,
do not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do
not attempt any repairs yourself, doing so will void your manu­factures warranty. In the unlikely event your unit may require ser­vice please contact ADJ Products, LLC.

PLEASE recycle the shipping carton whenever possible.

To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the
basic operations of this unit. These instructions contain impor­tant safety information regarding the use and maintenance of this
unit. Please keep this manual with the unit, for future reference.

Airstream DMX Bridge Precautions

• Do not attempt to remove or break o the ground prong from the
electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short.

• Do not remove the unit cover under any conditions. There are no
user serviceable parts inside.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.

• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture.

• This unit is intended for indoor use only, use of this product out­ doors voids all warranties.

• During long periods of non use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-Cord Protection - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
fixture.

• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer.

• The fixture should be serviced by qualified service personnel
when:
A. The power cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The fixture does not appear to operate normally or exhibits a
marked change in performance.

ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 2

ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 3

Airstream DMX Bridge Indicators, Connections, & Functions

Airstream DMX Bridge Bridge Settings

All setup is done from inside the Airstream DMX app. With the
bridge turned on, you should be able to nd the “ADJ Airstream
DMX” network using the Wi-Fi settings on your IPhone or IPad.
The default password to join is “airstream”. After joining the net­work you can start the Airstream DMX app. You should see the
“connected” message when the app starts. The bridge setup
view can be found by selecting the “Fixtures” tab at the bottom
then selecting “Patch” in the upper right, and then “Bridge” in the

upper right. A view will appear
similar to the following gure.

1

65432

7

1. Wi-Fi Antenna – signal between bridge and Wi-Fi device.

2. Wiy Antenna – signal to Wiy equipped lighting equipment.

3. Power Supply Connection - Connect the provided power

supply to this jack.

4. Activity Indicator LED - This LED indicates activity on the

device.

5. USB connector – used for rmware updates.

6. 3 Pin DMX Out - Output the DMX512 signal (Wiy and DMX512

universes are the same)

7. Power Switch – power on/o switch.

From the Bridge Settings view,
you can congure the Wiy
and Wi-Fi network settings. If
you are only using the wired
DMX512 output and not using
Wiy to control your lights,
it is recommended that you
turn Wiy enable o. This will

improve the performance of

the Wi-Fi connection. When
Wiy is enabled, you can
select the Wiy channel (0-14).
Set the Wiy channel on your
lights to this same value. On
the example here you can see
that Wiy is enabled and the
channel is set to 3. It is recom­mended that you set the Wiy
channel as far as possible from
the Wi-Fi channel.

From this view you can also

change the Wi-Fi network
name, password and channel. It is recommended that you
change the password for the security of your lighting system.

ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 4 ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 5

Airstream DMX Bridge Bridge Settings

Changes will take eect after you turn the bridge o and then
back on again. It is recommended that you use the upper chan­nels for Wi-Fi and lower channels for Wiy. When making the
channel selection you will notice a bar graph next to each chan­nel showing the current radio activity on that channel. Try to
choose a channel with the least amount of activity. In the U.S.
Wi-Fi channels 1-11 are available for use.

The network name can be 1-32 characters in length and the
password can be 8-16 characters in length. Only alphanumeric
characters or space characters are allowed.

ANTENNAS:

The antenna angles can be adjusted for optimum performance.
For best results the Wiy antenna should be set to the same ori­entation as the light xture’s antennas. You can experiment with
dierent angles to see what works the best. Both antennas set
to a 45 degree angle is a good compromise starting point. Make
sure both antennas are tightened into their sockets as far as they
can go. Grab the inside base of the antenna next to the body of
the bridge to tighten.

Airstream DMX Bridge Installation

Before attaching the bracket to the xture, rst attach install
a clamp to the bracket. Next, attach the bracket to the xture
using the included screws. The xture should be mounted using
the clamp attached to the bracket. Always ensure that the x­ture is rmly xed to avoid vibration and slipping while operat­ing. Always ensure that the structure to which you are attaching
the xture is secure and is able to support a weight of 10 times
of the xture’s weight. Also always use a safety cable that can
hold 12 times the weight of the xture when installing the x­ture. The unit also has a magnetic bottom that can be axed to

anything metal.

Airstream DMX Bridge Warranty Registration

The Airstream DMX Bridge carries a 1 year (365 day) limited war-

ranty

. We recommend you fill out the enclosed warranty card
to validate your purchase. All returned service items whether
under warranty or not, must be freight pre-paid and accompany
a return authorization (R.A.) number. If the unit is under warran­ty, you must provide a copy of your proof of purchase invoice.
Please contact ADJ Products, LLC customer support for a R.A.
number.

ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 6

ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 7

Airstream DMX Bridge Warranty

MANUFACTURER’S LIMITED WARRANTY

A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products
to be free of manufacturing defects in material and workmanship for a prescribed period from
the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the
product is purchased within the United States of America, including possessions and
territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.

B. For warranty service you must obtain a Return Authorization number (RA#)
before sending back the product–please contact ADJ Products, LLC Service Department
at 800-322-6337. Send the product only to the ADJ Products, LLC factory. All
shipping charges must be pre-paid. If the requested repairs or service (including
parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return
shipping charges only to a designated point within the United States. If the entire instrument is
sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If
any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for
loss of or damage to any such accessories, nor for the safe return thereof.

C. This warranty is void if the serial number has been altered or removed; if the product is modified in any
manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the
product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior
written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because
not properly maintained as set forth in the instruction manual.

D. This is not a service contract, and this warranty does not include maintnance, cleaning or periodic check
up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense
with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole
discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August
15, 2012, and bear indentifying marks to that effect.

E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products
without any obligation to include these changes in any products theretofore manufactured.

No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with
products described above. Except to the extent prohibited by applicable law, all implied warranties made
by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness,
are limited in duration to the warranty period set forth above. And no warranties, whether expressed or
implied, including warranties of merchantability or fitness, shall apply to this product after said period
has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is
expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or
damage, direct or consequential, arising out of the use of, or inability to use, this product.

This warranty is the only written warranty applicable to ADJ Products, LLC Products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published.

MANUFACTURER’S LIMITED WARRANTY PERIODS:

 •LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent

Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing,
Lighting Stands etc. excluding LED and lamps)

 •LaserProducts=1Year(365Days)LimitedWarranty(excluding laser diodes which have a 6 month

limited warranty)

 •L.E.D.Products=2-year(730days)LimitedWarranty(excluding motors, PCB boards, and power
supplies, which have a 1-year (365 day Limited Warranty) batteries which have a 180 day limited war-

ranty). Only the L.E.D.s carry a 2-year warranty (excludingStarTecSerieswhichacarriesa1Year

LimitedWarranty)Note:2YearWarrantyonlyappliestopurchaseswithintheUnitedStates.

•ADJDMXControllers=2Year(730Days)LimitedWarranty(excluding faders and tact switches)

ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 8

Airstream DMX Bridge Notes

ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 9

Airstream DMX Bridge Specifications

Model: Airstream DMX Bridge

Voltage: DC 9-12V 1Amp
Wireless Frequency: 2.4 GHz
WiFly Range: 2500 Ft.
Wi-Fi Range: 75 Ft.
Dimensions: 5” L x 7” W x 2.5” H

125 x 175 x 62mm

Weight: 2 Lbs. / 0.75 kgs.
Warranty: 1 year (365 Days)

Please Note: Specications and improvements in the design

of this unit and this manual are subject to change without any
prior written notice.

ADJ Products, LLC - www.adj.com - Airstream DMX Bridge Instruction Manual Page 10

ADJ Products, LLC

6122 S. Eastern Ave. Los Angeles, CA 90040 USA

Tel: [phone] / Fax: [phone]

Web: www.adj.com / E-mail: [e-mail]

A.D.J. Supply Europe B.V.

Junostraat 2

6468 EW Kerkrade

The Netherlands

[e-mail] / www.adj.eu

Tel: [phone] / Fax: [phone]
