ADI Systems AT-201 User Manual
AT-201
AT-401
USER'S MANUAL
HAND-HELD Transceiver
ADI
Communications
CONTENTS
The VHF/UHF Hand-Held Transceiver is engineered
and manufactured with highest quality of
microelectronics technology and workmanship. We are
confident that you will be entirely satisfied with the
superb performance and reliability of this Hand-Held
(H/H) Transceiver.
Our very strict quality control and inspection ensure
that each transceiver unit have left the factory-in
perfect condition. However, if your transceiver does not
operate properly or if you find any difficulty in its
operation, contact your dealer immediately.
Read this instruction carefully before use to make the
unit perform fully and last long.
(THIS DEVICE COMPLIES WITH PART 15 OF THE
FCC RULES OPERATION IS SUBJECT TO THE
CONDITION THAT THIS DEVICE DOES NOT CAUSE
HARMFUL INTERFERENCE.)
BEFORE OPERATION
Features............
Optional Accessories.................................................... 5
Controls and Connections
Getting Ready
Operation Controls.......................................................13
(1) Setting an Operating Frequency.
Expanding the receive frequency.
Changing the memory to the channel mode...........16
(2) Programming Frequency in Memory.
(3) Recalling a Memory Frequency
(4) Moving a Memory Frequency to VFO
(5) Changing a Memory Frequency.
(6) Deleting a Memory Frequency
(7) Recalling a Call Frequency....................................20
(8) Moving a Call Frequency.......................................21
(9) Changing a Call Frequency to the VFO................21
(10) Scanning.............................................................22
(11) Switching the Transmit Power..........................28
(12) Dual-Watch Operation
(13) MHz Rotary Step
(14) Changing the Frequency Step
(15) Battery-Save Function
(16) Frequency Lock
(17) PTTLock..............................................................35
(18) Switching Pause Scan and Busy Scan
(19) Tone Squelch Control........................................36
...............................................................
...................................................
.............................................................
...........................................
..........................
..........................
...................
............................
...................
...........................
..............................
..........................................
................................................
..........................
.......................................
.................................................
............
6
10
14
15
16
17
18
18
19
29
32
33
34
34
35
2
4
BEFORE OPERATION
(20) Special Functions with SET Button
........................
37
(21) Pager and Code Squelch.........................................41
(22) Repeater Operation.................................................. 49
(23) Exchange the Transmit and Receive Frequency
during Repeater Operation
.....................................
51
(24) Setting a Shift Frequency.........................................52
Troubleshooting...........................................................53
Specification.................................................................54
Warranty Card
.............................................................
56
Make sure that batteries are
. inserted .with correct polarity.
I
Do not disassemble and
1 tamper with cores and trim
2
mers The Transceiver is pro
duced under strict control and
fully adjusted.
r
X,
0 Keep out of high temperature,
humidity and dust.
FT
I Apply 5.0 to 16.0V DC power
k supply only
EQUIPMENT SUPPLIED
Do not use a new and used
batteries together
5
.
Do not dispose a battery in
■ fire.
6
The Transceiver is normally supplied with the items listed
below. When unpacking the unit carton check the all items are
included. If items are missing, please notify your dealer
immediately.
©User’s Manual
© Antenna
© Jack Cover
© Belt Clip (Installed)
* Optional item, it may not be shipped with your radio,
please consult your local dealer.
** DTMF, Tone Squelch Unit (CTCSS) is installed for
North America.
® Hand Strap (Installed)
® Battery Pack
* ©Wall Charger
**® DTMF
**@ Tone Squelch Unit
TABLE OF CONTENTS
This is a highly versatile, yet compact hand-held transceiver
that is built and tested to stringent specifications. The
following features are built into your Transceiver.
☆ Smallest and lightest transceiver in this class.
Dimensions: 83.5mm (height)x55mm(width)x31mm(depth)
(excluding protrusions and battery case).
Weight: 185g (excluding battery case and antenna)
☆ Paging function is available when an optional DTMF is
installed. This feature allows you to page one specific
station or all group stations via a 3-figured DTMF signal.
When a paging signal is received, a beep sound and the
display will inform you that someone has you paged. The
paging station can be identified by means of its individual
code.
☆ Code Squelch operation is available with when an optional
DTMF is installed. The Transceiver will hear only stations
using the identical code.
☆ Tone Squelch operation is available with an optional
CTCSS. The Radio will hear only stations using the
specific tone frequency. Tone frequencies can be selected
via the rotary channel selector.
☆ DTMF and CTCSS can used together.
☆ An optional High Power Rechargeable Battery Pack or an
external power supply of 13.8V enable powerful
transmission.
☆ A wide range of acceptable external power supply
voltages (5 to 16V DC) allows you to power it from an
automobile battery.
☆ High Sensitivity.
☆ Up to 40 memory channels are available.
☆ Independent tone frequencies and offset frequencies can
be programmed in any memory.
☆ Internal Dual-Watch allows the Transceiver to watch.
• the selected dial-frequency and the stored frequency in
memory address Ml;
• the selected dial-frequency and any other memory
frequency
• the selected dial-frequency and each memory frequency
under scanning in sequence, (up to 40 channels)
• the selected dial-frequency and call frequency
☆ Either Pause or Busy scan functions can be selected.
Scanning the dial-frequency provides a VFO full band
scan. Scanning of a memory frequency provides all
memories scan.
☆ A single pushbutton press opens the squelch so you can
easily check the volume setting.
☆ A Battery-Save function allows you to reduce the current
drain during receiver standby.
OPTIONAL ACCESSORIES
☆ An Auto-Power Off function reduces the current drain if you
forget to turn the transceiver off. DTF145
☆ Frequencies can be entered directly from the keyboard or RBP072
via a rotary channel selector. RBP120
☆ A Function button allows you to change the frequency with SOOmAh)
a 1 MHz step when you turn the rotary channel selector. CHA072
☆ Selected frequencies and operating mode may be locked CHA120
to prevent inadvertent key operation. PCA145
☆ PTT button may be locked to prevent inadvertent SBC 145
transmission. CMP145
☆ A full line-up of optional accessories. DTC120
CTS145
DTMF Encoder/Decoder
Standard Rechargeable Battery Pack (7.2V, 700mAh)
High Power Rechargeable Battery Pack (12V,
AC Charger (for RBP072)
AC Charger (for RBP120)
Power Cable for an-automobile
Standard Battery Case (for 6 size AA batteries)
Compact Microphone/Speaker with PTT
Desk Top Charger (Rapid Charger)(for RBP072,
RBP120)
CTCSS encoder & decoder
We offer various accessories to increase your communication
efficiency. Consult your dealer for further details. (Some
items below might be shipped with your radio as standard
accessories)
CONTROLS AND CONNECTIONS
®
© Power On-OFF SwitchA^olume Control
This is to turn the power on and off and to control the
volume. Rotate the control clockwise to turn the power
on,and rotate it clockwise further to increase the volume.
The Squelch Off button should be held depressed or the
Squelch Control rotated fully counterclockwise while
controlling the volume.
© Squelch Control
This is to control white noise. Rotate it clockwise slowly
and set the control where the noise stops.
NOTE:
(1) DO not rotate the control clockwise too far.
(2) The control should be placed where the white noise is not
heard during following operations; Scanning, Dual-Watch,
Battery-Save, Paging and Code Squelch.
(3) Adjust the control with the channel which is not receiving
the signal.
© Rotary Channel Selector
This is to select the transmit/receive frequency. It is also
used to change the tone frequency, channel step and
memory address number. Rotate the selector clockwise
to increase the frequency and counterclockwise to lower
it. The interval by which the frequency changes is referred
to as "Channel Step". The Channel Step which is
initially set to 10kHz can be changed to 5, 12.5, 20, 25 or
50kHz. (Refer to Changing the Channel Step, contents 14).
0 External Speaker Jack: S
This is to connect Microphone/Speaker or Head Set with
PTT. Any other external speaker with 8 ohm load or an
earphone can be connected. A built-in speaker is disabled
when an external speaker is connected to this jack.
© External Microphone Jack: M
This is to connect Microphone Speaker Head Set with PTT.
© Antenna Jack: ANT
This is a BNC connector to connect the attached helical
antenna.
© Transmission/Battery Indicator
This indicator lights up in red when the transmitter is
keyed. When weakened batteries, it becomes darker
recommending battery replacement.
© Function Button
Special functions are available by pressing each button
on the front panel with the function button held depressed.
® PTT Button
For transmission, press this button and speak into the
microphone. Release the PTT button to receive.
When operated with Head Set with PTT, press the PTT
button on Head Set to transmit.
® Lock Button
This is to lock the battery case. Push up this button to
remove the battery case.
@ External Power Connector: DC IN
This is for Power Cable for an Automobile (PCA145).
When PCA145 is connected, power is not supplied from
the battery
NOTE:
Connect the PCA145 only to
this connector, as its plug is
the peculiar one.
CAUTION:
Turn the power switch off before connecting the cables.
Nominal input voltage for this H/H Transceiver is from 5V to
16V DC. Do not apply voltage beyond the range.
A pin at the center is negative
® Front Panel
A: Squelch Off Button: SQL
This button opens the radio squelch. While this button is
held depressed, the squelch operation is turned off and
the sound is heard from the speaker regardless of the
position of the squelch control.
B: Call Button: CALL
Press this button to switch the operating frequency and call
frequency.
C: Lamp Button: LAMP
Press the LAMP key to illuminate the LCD and keypad.
Pressing this switch only will activate the lamp for 5
seconds. Pressing Function and LAMP at the same time,
turns the lamp on full time.
D: Speaker
This is a built-in speaker, which is disabled when the
external speaker is connected.
E: Microphone
This is a built-in condenser micrpohone.
F: Key buttons for various operations
(D—
o o
o o o o o
o o o o o o
^CD O O O O O O
o o o o o o
O O CD
yicy AT-201
—(B
ri
(m CT) rri r»n )
CTCSS SAVE LOCK PWR/PL |
(GD CD CD CI3 )
(ED
MR/E№~ SET
((X] ['o"] c«] CdT^)
/-/BS
REV/T
SHFT/A VSCAN
CD CD )
Display
The display indicates followings,
I Frequency
II Channel Step
III Special Functions
PAG, DUAL, APO, DUP F L, TSQ,
IV Mennory Address Number
V Memory Mode
VI. Scanning
VII Shift Frequency
VIII Busy Scanning
IX S-meter and RF Output Indicator
It functions as a S-meter when receiving the signal and idicates
the RF output power while transmitting "1" is indicated
regardless the input signal when the squelch control is rotated
fully counterclockwise.
PL, CSQ, S B, +. -
^ cebehedebqeeqsbdd^sbd
r/^ O 0*0 O S5
b b LI LI.U LI IS
ISII@I
maH M L Olisi
GETTING READY
® Battery Case
Depending on what model radio you purchased. The
AT-201 may have come with a 7.2 Volt NiCad. a 12 Volt
NiCad or a battery pack for 6 AA batteries.
© Jack Cap
Cover the jacks with this cap when the external
microphone and external speaker are not in use.
© Belt Clip Holder
The belt clip is fixed to the Transceiver at the factory.
Remove the belt clip when unnecessary and fasten the
screws solely.
1
. Install the included antenna.
■ Detach the battery case
2
a) Hold the Transceiver and place your thumb on the
Lock button.
b) Push up the Lock Button and pull the battery case as
illustrated to clear the lock.
c) Pull the battery case further and remove it from the
Transceiver.
10
If you are using the battery pack for 6 AA battery, insert
3
size AA batteries into the battery pack. Be sure that the
batteries are inserted with correct polarity.
NOTE:
Apply the new batteries only.
4
.
Attach the battery to the Transceiver. Engage the battery
on the slot of the bottom of the Transceiver and push the
battery case until it latches in the proper position.
■ Turn the power switch on and set the volume control to a
5
comfortable listening level.
Rotate the squelch control clockwise slowly until the
6
noise from the speaker stops.
NOTE:
Do not rotate the control clockwise too far. Excessive
squelch reduces the radio sensitivity and may prevent
reception.
11
Press the PTT button to transmit and release it to receive
7
.
12
OPERATION
Operating Controls
Key buttons on the front panel function as described below.
When operated correctly a high short beep tone will be
generated. A low beep tone will warn you the wrong operation.
Button
CALL
LAMP
A/MHZ
B/PWFVPL
C/VSCAN
D/MSCAN
*/MR/ENT
Independent Function Function + Button
Switches the operating
frequency and call frequency
Illuminates the LCD and
keypads for 5 seconds
Turns on/off the 1 MHz tuning
step operation
Switches the transmit power
level
Scanning operation
Turns on/off the memory scan
Switches the operating frequ
ency and the memory frequ
ency, and accesses the oper
ating frequency
Turns on/off the lamp
full time
Turns on/off the 1 MHz
Turning step operation
Disables the PIT button
Switches the memory
channel group
Sets the MS.M scan
frequency and turns on/off
the MS.M scan
Store or release the memory
frequencies in memory mode
Button
#/PAGE
0/SET
1/DUAL
2/DUP
3/STEP
4/CTCSS
5/SAVE
6/LOCK
7/-^/-/BS
8/REV/T
9/SHIFT/A
Independent Function
Turns on/off and switches the
paging and code squelch
operation
Input "0" Selects the set mode
Input "1"
Input "2''
Input "3"
Input "4“ Turn on/off the tone squelch
Input "5” Turns on/off the save function
Input “6" Turns on/off the frequency
Input "7“
•While scanning, switches the
pause scan and busy scan
Input "8"
•Scans downwards
Input "9"
•Scans upwards
Function + Button
Recalls the stored code in
memory for paging and code
squelch operation
Turns on the dual watch
Turns on/off autorepeater
mode
Recall the channel step
operation
lock function
Turns on/off the repeater
operation
Exchanging the transmit and
receive frequency during
repeater operation
Setting a shift frequency
13
1 Setting an Operating Frequency
0 With a rotary channel selector
You can change the operating (transmit and/or receive)
frequency by rotating the rotary channel selector. As the
selector rotated, the displayed frequency changes in
10kHz steps. It changes in 1MHz steps when rotated with
the function button held depressed.
( Procedure)
Rotate the rotary channel selector clockwise to increase the
displayed frequency and counter clockwise to decrease it.
• Although the channel step is initially set to 10kHz at the
factory,you may use any one of six options, 5, 10,12.5, 20,
25 and 50kHz. How to select the channel step is outlined
under "Changing the Channel Step”, contents.
0 With buttons on the front panel
You can change the operating frequency with numeral
buttons of “0” to “9”.
( Procedure )
Example:To set 145.80MHz
a) a 10MHz figure
b) a MHz figure......................press”5”
c) a 100kHz figure.................press”8”
d) a 10kHz figure
..................
..................
press”4”
[14] will be displayed.
[145] will be displayed.
[145.8] will be displayed.
press”0”
[145.80] will be displayed.
(information)
• The frequency step rate as the selector rotated is referred
to as a channel step.
14
When four numeral buttons are pressed correctly, a long
beep tone will be generated informing you that frequency
setting is complete.
(information)
If you want to cancel the setting in the middle of the
operation, press the */MR /ENT button. The display will return
to the previous frequency.
This is called the dial-frequency mode.
Expanding the receive frequency:
For receiving 130-170 MHz.
( Procedure )
1. Turn power off.
2. Press [3]+[CALL] while turning power back on.
(information)
Returning the receiving range to normal:
CAUTION! This resets the radio and erases all memories.
Press [FUNC]+[CALL] while turning power back on.
15
Changing the memory to the 40 channel mode
This function changes the memory size from 20 to 40
channels. Turn off the radio. Press and hold [CALL] and [6] at
the same time. Turn on the radio.
/ U C D ~i I
I I L U I
Note: “6" is display. Turn radio off, then back on. Normal
display returns. Call channel can not be changed
while in 40 channel mode. If you wish to use the call
channel in 40 channel mode, you must program it
before you put the radio in 40 channel mode.
Programming Frequency in
Memory [*/MR/ENT Button]
Up to 40 memories may be programmed. They are saved
under the addresses 0 through 39 (in 40 channel mode) or 0
through 9 and 0 through 9 (in 20 channel mode).
( Procedure)
(When the memory is vacant)
1. Select VFO mode (no “M” in display)
2. Input frequency, tone, and offset (if needed) and press
[MR/ENT]
3. Select memory 0-9, 0-9, or 0-39 by rotating dial knob.
4. Hold [FUNC] and press [MR/ENT] to store the memory. A
long beep tone notifies you that the operation is complete.
16
b) cl flashing -i ▼
MR/ENT
^ ! I-I .L U
MR/ENT
----------------------------
MR/ENT
, U I- J I I I
/ I LI I
dial-frequency
' , U L D ri
I I /_/.L U ^
remain turned on
^ , U C II I~ I
I 1 !_/
memory mode
I
Recalling a Memory Frequency
[*/MR/ENT Button]
( Procedure )
0 Example: To recall “M1 ”
a) Press the */ MR /ENT button for the memory mode.
b) Press the number 1 button or rotate the channel
selector for the address number “M1”. The stored
frequency under “M1” will be displayed.
till n n
I I Zl.LI LI
\ dial-frequency
@ Example: To recall the memory frequency
successively
Keep the Transceiver in the memory mode. Press the
numeral button or rotate the channel selector for the
desired address number. The stored frequency under the
address number will be displayed.
(information)
• In 20 channel mode the numeral button can only recall
the address number within either M or M memory groups.
When the recalled address number is vacant (i.e. no
frequency is stored), “M” on the display will flash and the
dial-frequency will be indicated.
The */ MR /ENT button switches the dial-mode and
memory mode.
17
Loading...
